Gemini EX-26 User manual

www.geminidj.com
SERVICE MANUAL
Features, Operating Instructions………………. Page 2
Specifications……………………………………. Page 3
Diagrams………………………………………… Page 4
Parts List…………………………………………. Page 7
Schematics………………………………………. Page 12
EX-26

Congratulations on purchasing the Gemini EX-26 mixer!
This state of the art mixer is backed by a three-year
warranty, excluding crossfader and channel slides. We
know you’re anxious to hook everything up and start mixing
beats and cranking up the volume on those hot dance
tracks, but we suggest reading this instruction manual first
as there are really cool features on this mixer that we
wouldn’t want you to miss!
The EX-26 Mixer features a crossfader which controls a
super-quiet photo coupler to give you smooth operation and
the cleanest possible sound, along with a "hamster" switch
that is easily accessible on the front of the mixer. This
“hamster” switch reverses the direction of the main
crossfader. This mixer also features individual “hamster”
switches for the separate channel input faders as well.
For additional information, refer to the diagrams on pages 1
& 2 for crossfader adjustment and channel slide curve.
• 2 Stereo Channels
• State of the Art Cue Section
• 2 Phono & 2 Line Inputs
• Channel Slide Curve Control
• Crossfader with Curve Control
• Adjustable Input Assign Switches
• Crossfader Reverse (Hamster) Button
• Individual Channel Fader Reverse (Hamster) Buttons
• LED Display
• Gain, High, Mid and Low tone controls for each channel
• Balanced and Unbalanced Master Outputs
• Record outputs
1. All operating instructions should be read before using
this equipment.
2. Treat this unit as you would any other piece of electrical
equipment and use good common sense!
3. To reduce the risk of electrical shock, do not open the
unit. There are NO USER REPLACEABLE PARTS INSIDE.
Please refer servicing to a qualified service technician.
INTRODUCTION
FEATURES
4. Do not expose this unit to direct sunlight or to a heat
source such as a radiator or stove.
5. This unit should be cleaned only with a damp cloth.
Avoid solvents or other cleaning detergents.
6. When moving this equipment, it should be placed in its
original carton and packaging. This will reduce the risk of
damage during transit.
7. Do not expose this unit to rain or moisture.
8. Do not use any spray cleaner or lubricant on any controls
or switches.
Okay, let’s hook everything up!
1. Make sure that the POWER
(1)
switch is in the “OFF”
position. This unit comes supplied with a 15 volt AC
adaptor. Plug the adaptor into the rear panel power jack.
Then plug the adaptor into your power strip or outlet.
2. The EX-26 mixer is supplied with 3 sets of output jacks.
The BALANCED MASTER OUTPUT
(2)
jacks are used to
connect to your main amplifier using standard cables with
1/4” connectors. We recommend using the balanced amp
outputs if the cables to your amp are 25 feet or more.
BALANCED MASTER OUTPUTS have three separate
conductors, two of which are signal (positive and negative)
and one shield (ground). The balanced line uses a tip-ring-
sleeve connection. Tip = hot or positive (+), ring = cold or
negative (-), and sleeve = shield/ground.
The MASTER OUTPUT
(3)
jacks are unbalanced and are
also used to connect to your main amplifier. The REC
OUTPUT
(4)
jacks can be used to connect the mixer to the
record input of your recorder enabling you to record your
mix.
CAUTIONS
In the U.S.A., if you have any problems with this
unit, call 1-732-738-9003 for customer service.
Do not return equipment to your dealer.
CONNECTIONS

Pa
g
e 2
3. On the rear panel are 2 stereo LINE
(5,6)
inputs and
2 stereo PHONO
(7,8)
inputs. The phono inputs will accept
only turntables with a magnetic cartridge. GROUND
SCREWS (9) for you to ground your turntables are located
on the rear panel. The stereo line inputs will accept any line
level input such as a CD player, cassette player, etc.
4. Headphones can be plugged into the front panel
mounted PHONES (10) jack.
1. POWER ON: Once you have made all the equipment
connections to your mixer, press the POWER (1) switch.
2. CHANNEL 1: The GAIN
(11),
HIGH
(12),
MID
(13),
and
LOW
(14)
controls allow you to fully adjust the volume and
EQ of the sound source. The Channel 1 REVERSE
SWITCH
(15)
allows you to reverse the direction of the
Channel 1 slide fader.
(17)
The Channel 1 SLIDE FADER
(
17)
controls the input level of this channel.
3. CHANNEL 2: The GAIN
(11),
HIGH
(12),
MID
(13),
and
LOW
(14)
controls allow you to fully adjust the volume and
EQ of the sound source. The Channel 2 REVERSE
SWITCH
(16)
allows you to reverse the direction of the
Channel 2 slide fader.
(18 )
The Channel 2 SLIDE FADER
(
18 )
controls the input level of this channel.
4. EQ CONTROLS: There is Low, Mid and High
equalization for each channel with an extremely wide range
of adjustment.
5. INPUT ASSIGN SWITCHES: You can adjust the position
of the INPUT ASSIGN SWITCHES
(21, 22)
to move left to
right, up and down, or at a 45 degree angle.
Make these adjustments with the power OFF.
1) Remove the channel slide knobs, crossfader knobs and
the 4 screws from the sides of the lower faceplate. Then
remove the lower faceplate.
2) Remove the 2 screws in the corners of the assign switch
plate. Rotate the switch plate to the desired position, and
replace the screws and tighten down.
3) To position the switch at a 45-degree angle, you need to
reposition the switch on the assign switch plate. First,
remove the 2 screws in the corners of the assign switch
plate. Then, lift the switch plate up and remove the 2
smaller screws next to the switch. Rotate the switch plate to
the right until the 45-degree holes align with the switch
holes, replace the screws and tighten down. Replace the
switch plate and tighten down.
NOTE: Keep track of where you position the input
assign switches.
OPERATION
6. CHANNEL SLIDE CURVE SWITCHES: Use the 3
position CHANNEL SLIDE CURVE SWITCHES (23,24) to
adjust the kind of curve the channel slides have. Move the
selected channel slide curve switch to the 6 (top) position to
make the increase in level gradual and even. Move the
channel slide curve switch to the 20 (center) position to
make the increase in level less gradual as you move
channel slide up. Move the channel slide curve switch to
the 30 (bottom) position to make the increase in level even
less gradual, especially at the top of the slide.
7. CROSSFADER SECTION: The CROSSFADER (25)
allows the mixing of one source into another. The left side
of the CROSSFADER (25) is CHANNEL 1 and the right
side is CHANNEL 2. The CROSSFADER CURVE
CONTROL (26) allows you to adjust the kind of curve the
crossfader has. Move the CROSSFADER CURVE
CONTROL (26) to the right to make the curve steep and
cutting (perfect for scratching). Move the CROSSFADER
CURVE CONTROL(26) to the left to make the curve
gradual and gentle. The CROSSFADER REVERSE
BUTTON (27) allows you to reverse the crossfader so that
CHANNEL 2 is controlled by the left side of the crossfader
and CHANNEL 1 is controlled by the right side of the
crossfader. When REVERSE is activated the REVERSE
LED (28) will light.
NOTE: When the CROSSFADER REVERSE BUTTON is
activated (depressed), only the crossfader reverses.
The Channel Slides, Gain,
and EQ controls do not
reverse.
8. OUTPUT CONTROL SECTION: The level of the
MASTER OUTPUT (2, 3) is controlled by the MASTER
CONTROL (20). The BALANCE CONTROL KNOB (19)
controls the balance between the output of the left and right
channels.
NOTE: The RECORD OUT (4) has no level control. The
level is set by the channel slides and the gain controls
of the selected channel. The EQ of the channels is set
by the low, mid and high controls of that same channel.
9. CUE SECTION: By connecting a set of headphones to
the PHONES JACK
(10)
, you can monitor the music
coming out of each channel separately or both channels
together. Move the CUE FADER (29) to the left to hear
CHANNEL 1 and to the right to hear CHANNEL 2. Move
the CUE FADER (29) to the center to listen to both
channels together. The PHONES MUTE BUTTON
(30)
will
instantly mute your cue mix.
10. DISPLAY: The red LED in the center of the display tells
you that the power in your EX-26 Mixer is on.
The multi-colored LED DISPLAY
(31)
on either side of the
center tells you the output level of your 2 channels.
Okay, that’s it! NOW you’re ready to grab a couple of great
CD’s or records, crank it up and get the party started!

INPUTS:
Phono.....................@ 1mHz.................……....2mV 47kΩ
Line.........................................….....……......100mV 20kΩ
OUTPUTS:
Master (balanced..................…………..…0 dB 2 V 800 Ω
Max.......................………………….....40 V Peak to Peak
Master (unbalanced).....................…..........0 dB 1V 400Ω
Max..........................…………………...20V Peak to Peak
Rec.........................……………........…….......150mV 5kΩ
GENERAL:
Low.........................……………................+ 12dB/- 32 dB
Mid..........................……………................+ 12dB/- 32 dB
High..........................………………...........+ 12dB/- 32 dB
Gain............................………………….. …......0 to -20dB
Frequency Response..………........20Hz – 20kHz +/- 2dB
Distortion.............................…………...…less than 0.08%
S/N Ratio................……………….…......better than 80dB
Power Adapter....................……........115V/15V AC 0.5A
230V/15V AC 0.5A
Dimensions.....6.5”W x 14.25”H x 3.00”D
SPECIFICATIONS
Pa
g
e 3

16
31
21 22
23 24
17 18
28
25
16
15
14 14
13 13
12 12
19
11
11 20

1
2
23
3
4
4
5
5
7
7
9
9
6
6
8
8
26
27
29
30
10
CH 1 CH 2 CH 1
CH 2
CUE 1 CUE 2

PART# QUANTITY NAME
1 012-026 1 PANEL CONTROL
2 012-027 1 PANEL CONTROL
3 024-165 1 PANEL FRONT
4 034-118 1 PANEL REAR
5 021-601 1 BRACKET VR
6 032-104 1 COVER BOTTOM
7 022-374 3 HOLDER FADER
8 022-376 2 HOLDER SWING
9 041-451 1 HEAT SINK
10
11 023-674 2 KNOB SWING
12 002-531 1 KNOB PUSH (SMALL)
13 002-532 1 BUSHING FOR KNOB
(SMALL)
14 002-580 3 KNOB PUSH
15 002-581 3 BUSHING FOR KNOB
16 002-728 3 KNOB SLIDE (BIG)
17 002-727 1 KNOB SLIDE (SMALL)
18
19 003-149 12 KNOB ROTARY (A)
20 148-313 12 KNOB INLAY (COP
PER)
21
22 003-745 1 BRIGHTENED
ACRYLIC
23 003-436 1 LIGHT PLATE
ACRYLIC
24 003-746 15 HOLDER LED
25 003-982 2 HOLDER LED 5φ
26 003-747 1 HOLDER LED
27 049-190 1 CLIP WIRE
28 049-206 4 PAD FOOT
29 146-716 2 GND SCREW (BIG)
30
31 159-216 2 SWING DUST PROOF
CLOTH
32 159-171 3 VR DUST PROOF
CLOTH
33 159-167 1 VR DUST PROOF
CLOTH (SMALL)
34
35 196-125 3 SERIAL NO:LABEL
36 255-198 1 GIFT BOX
37 157-994 1 OWNER’S MANUAL
38 156-089 1 WARRANTY CARD
39 153-216 1 POLYFORM
40 153-226 1 POLYFOAM CUBE
41
42 095-057 3 VDE LABEL
43 099-167 1 A LABEL
44 099-169 1 V LABEL
45 099-168 1 J LABEL
46 099-232 2 LABEL-GREEN
47 099-233 2 LABEL-RED
48 099-234 2 LABEL-YELLOW
49 099-266 1 CAUTION LABEL
50
51 099-014 1 LABEL - MADE IN
TAIWAN
52 099-214 1 LABEL-MADE IN
CHINA
53
54 190-062 1 SILICON GEL
PARTS LIST

65
66 170-350 1 MASTER CARTON
67
68 099-230 2 100V LABEL
74
75
1 262-323 1 PRINTED CIRCUIT
BOARD EX-26-1
2 262-324 1 PRINTED CIRCUIT
BOARD EX-26-2
3 262-325 1 PRINTED CIRCUIT
BOARD EX-26-3
4 262-319 2 PRINTED CIRCUIT
BOARD EX-18-4
5 262-320 1 PRINTED CIRCUIT
BOARD EX-18-5
6 262-326 1 PRINTED CIRCUIT
BOARD EX-26-6
7 262-327 1 PRINTED CIRCUIT
BOARD EX-26-7
8 262-322 2 PRINTED CIRCUIT
BOARD EX-18-7
( PC8)
9
10 074-109 5 INTEGRATED CIR-
CUIT NJM2068D
(C4570C)
11 074-163 7 INTEGRATED CIR-
CUIT NJM4558DD
(M5218A, BA15218)
12 074-113 1 INTEGRATED CIR-
CUIT NJM4556L
13 074-022 4 INTEGRATED CIR-
CUIT LB1403N
(BA6124)
14
15 074-107 1 INTEGRATED CIR-
CUIT NJM7812FA
16 074-114 1 INTEGRATED CIR-
CUIT NJM7912FA
17
18 076-002 2 SILICON TRANSIS-
TORS 2SC945
19 076-003 SILICON TRANSIS-
TORS OR 2SC1815
20 076-096 4 POWER MOSFETS
2SK363
21
22 079-501 2 PHOTO COUPLER
P873-13
23 079-003 10 SILICON DIODE
1N4148
24 079-027 2 RECTIFIER DIODE
1N4002
25
26 079-012 2 ZENER DIODE
RD12EB2 (MTZ12B)
27 079-011 1 ZENER DIODE
RD9.1EB2 (MTZ9.1B)
28
29 059-139 1 AC ADAPTER AC120V
60Hz/AC15V 500mA
30 059-140 1 AC ADAPTER AC230V
50Hz/AC15V 500mA
31 059-149 1 AC ADAPTER AC240V
50Hz/AC15V 500mA
32 059-151 1 AC ADAPTER AC100V
60Hz/AC15V 500mA
33
34 083-069 1 PUSH SWITCH
PHONO-ON, OFF
35 083-097 1 PUSH SWITCH
36 083-119 2 PUSH SWITCH
37 083-120 1 POWER SWITCH UL
38
39 081-049 2 SLIDE SWITCH 4P3C
CH1,CH2
40 082-019 2 LEVER SW 4P2C
P=18 PH/LN SW
41 072-113 3 SLIDE VR
CH1,CH2, FADER
42 072-092 1 SLIDE VR 30mm L=15
20KB×2
43 073-031 4 SEMI-FIXED VR
B10KΩ 67-5-5
44
45 071-166 I 4 ROTARY VR 14φ(F)
L=22.5 50KA×2
GAIN, MASTER
46 071-167 I 6 ROTARY VR L=22.5
50KE×2C.C
47 071-206 I 1 ROTARY VR L=22.5
20KMN×2C.C BAL-
ANCE
48 071-224 1 ROTARY VR L=22.5
250KC×2

49
50
51 080-106 5 LED (RED) 3.15φ
52 080-103 2 LED (YELLOW) 3.15φ
53 080-107 8 LED (GREEN) 3.15φ
54 080-111 3 LED (GREEN/RED) 3φ
55
56 092-141G 2 PHONE JACK 6.3φ
57 092-141 1 PHONE JACK 6.3φ
58 092-135 1 DC JACK 2.5φ
59 161-165 3 4P RCA JACK
60
61 066-518 18 1/8 W CARBON FILM
RESISTOR S 10Ω
62 066-525 2 1/8 W CARBON FILM
RESISTOR S 20Ω
63 066-536 2 1/8 W CARBON FILM
RESISTOR S 56Ω
64
65 066-548 4 1/8 W CARBON FILM
RESISTOR S 180Ω
66 066-557 6 1/8 W CARBON FILM
RESISTOR S 430Ω
67 066-559 2 1/8 W CARBON FILM
RESISTOR S 510Ω
68 066-560 2 1/8 W CARBON FILM
RESISTOR S 560Ω
69 066-563 2 1/8 W CARBON FILM
RESISTOR S 750Ω
70
71 066-571 10 1/8 W CARBON FILM
RESISTOR S 1KΩ
72 066-575 8 1/8 W CARBON FILM
RESISTOR S 1.5KΩ
73 066-577 8 1/8 W CARBON FILM
RESISTOR S 1.8KΩ
74 066-580 4 1/8 W CARBON FILM
RESISTOR S 2.4KΩ
75 066-581 4 1/8 W CARBON FILM
RESISTOR S 2.7KΩ
76 066-584 18 1/8 W CARBON FILM
RESISTOR S 3.6KΩ
77 066-587 4 1/8 W CARBON FILM
RESISTOR S 4.7KΩ
78 066-588 4 1/8 W CARBON FILM
RESISTOR S 5.1KΩ
79
80 066-589 6 1/8 W CARBON FILM
RESISTOR S 5.6KΩ
81 066-591 4 1/8 W CARBON FILM
RESISTOR S 6.8KΩ
82 066-593 12 1/8 W CARBON FILM
RESISTOR S 8.2KΩ
83 066-594 2 1/8 W CARBON FILM
RESISTOR S 9.1KΩ
84
85 066-595 20 1/8 W CARBON FILM
RESISTOR S 10KΩ
86 066-601 2 1/8 W CARBON FILM
RESISTOR S 18KΩ
87 066-604 12 1/8 W CARBON FILM
RESISTOR S 24KΩ
88 066-607 16 1/8 W CARBON FILM
RESISTOR S 33KΩ
89
90 066-611 4 1/8 W CARBON FILM
RESISTOR S 47KΩ
91 066-612 4 1/8 W CARBON FILM
RESISTOR S 51KΩ
92 066-614 2 1/8 W CARBON FILM
RESISTOR S 62KΩ
93 066-617 2 1/8 W CARBON FILM
RESISTOR S 82KΩ
94
95 066-619 10 1/8 W CARBON FILM
RESISTOR S 100KΩ
96 066-621 6 1/8 W CARBON FILM
RESISTOR S 120KΩ
97 066-622 2 1/8 W CARBON FILM
RESISTOR S 130KΩ
98 066-636 2 1/8 W CARBON FILM
RESISTOR S 510KΩ
99 066-651 2 1/8 W CARBON FILM
RESISTOR S 1MΩ
100
101 051-010 2 CERAMIC CAPACI-
TOR 10P/50V
102 051-026 4 CERAMIC CAPACI-
TOR 47P/50V
103 051-028 4 CERAMIC CAPACI-
TOR 56P/50V
104 051-034 14 CERAMIC CAPACI-
TOR 100P/50V
105

106 054-006 2 POLYESTER CAPACI-
TOR 0.0027µ/50V
107 054-010 4 POLYESTER CAPACI-
TOR 0.0056µ/50V
108 054-011 4 POLYESTER CAPACI-
TOR 0.0068µ/50V
109 054-012 4 POLYESTER CAPACI-
TOR 0.0082µ/50V
110 054-013 8 POLYESTER CAPACI-
TOR 0.01µ/50V
111 054-018 4 POLYESTER CAPACI-
TOR 0.027µ/50V
112 054-028 8 POLYESTER CAPACI-
TOR 0.15µ/50V
113
114 050-125 2 ELECTROLYTIC
CAPACITOR 1µ/50V
115 050-029 10 ELECTROLYTIC
CAPACITOR 10µ/16V
116 050-036 10 ELECTROLYTIC
CAPACITOR 22µ/25V
117 050-038 1 ELECTROLYTIC
CAPACITOR 33µ/16V
118 050-043 4 ELECTROLYTIC
CAPACITOR 47µ/16V
119 050-049 1 ELECTROLYTIC
CAPACITOR 100µ/
16V
120 050-088 2 ELECTROLYTIC
CAPACITOR 2200µ/
25V
121
122 050-196 2 ELECTROLYTIC
CAPACITOR MINI
4φ×8 0.1µ/50V
123 050-130 4 ELECTROLYTIC
CAPACITOR MINI
4φ×8 4.7µ/50V
124 050-133 10 ELECTROLYTIC
CAPACITOR MINI
4φ×8 10µ/25V
125 050-111 18 ELECTROLYTIC
CAPACITOR MINI
4φ×8 22µ/16V
126 050-148 1 ELECTROLYTIC
CAPACITOR MINI
5φ×7 33µ/16V
127 050-134 2 ELECTROLYTIC
CAPACITOR MINI
6φ×8 47µ/25V
128 050-185 2 ELECTROLYTIC
CAPACITOR MINI
8φ×9 220µ/25V
129
130 060-702 5 JUMP WIRE “I” TYPE
0.5φP=5mm T/52
131 060-702 11 JUMP WIRE “I” TYPE
0.5φP=6mm T/52
132 060-702 16 JUMP WIRE “I” TYPE
0.5φP=7.5mm T/52
133 060-702 5 JUMP WIRE “I” TYPE
0.5φP=10mm T/52
134 060-702 8 JUMP WIRE “I” TYPE
0.5φP=12.5mm T/52
135
136 092-026 2 3P CONNECTOR
BASE B3B-XH-A 180°
137 092-031 2 4P CONNECTOR
BASE B4B-XH-A 180°
138 092-039 2 5P CONNECTOR
BASE B5B-XH-A 180°
139 092-029 1 7P CONNECTOR
BASE B7B-XH-A 180°
140
141 092-044 2 2P CONNECTOR
BASE B2B-XH-A 90°
142 092-045 1 3P CONNECTOR
BASE B3B-XH-A 90°
143 092-051 3 4P CONNECTOR
BASE B4B-XH-A 90°
144 092-072 2 6P CONNECTOR
BASE MOLEX 2600
90°
145 092-107 2 7P(P=2mm) CONNEC-
TOR BASE A2001-7P
90°
146
147 091-267 1 3P CONNECTOR
WITH WIRE XHP-03
STRIP×6 150mm
148 091-480 1 3P CONNECTOR
WITH WIRE XHP-03
STRIP×6 120mm

146
147 091-267 1 3P CONNECTOR
WITH WIRE XHP-03
STRIP×6 150mm
148 091-480 1 3P CONNECTOR
WITH WIRE XHP-03
STRIP×6 120mm
149 091-478 1 3P CONNECTOR
WITH WIRE XHP-03
SCN-03 130mm
150 091-481 1 4P CONNECTOR
WITH WIRE XHP-04
STRIP×6 150mm
151 091-609 1 4P CONNECTOR
WITH WIRE XHP-04
STRIP×6 110mm
152 091-265 1 4P CONNECTOR
WITH WIRE XHP-04
STRIP×6 150mm
153
154 091-415 2 4P CONNECTOR
WITH WIRE XHP-04
STRIP×6 330mm
155 091-479 2 6P CONNECTOR
WITH WIRE 2510-6P
STRIP×6 210mm7P
156 091-428 2 7P CONNECTOR
WITH WIRE 160mm
A2001-7P, XH-5P
XH-2P
157 091-271 1 7P CONNECTOR
WITH WIRE XHP-07
STRIP×6 110mm
158
159 093-417 1 GROUND WIRE WITH
RING TONGUE
(BLACK) 170mm
157 091-271 1 7P CONNECTOR
WITH WIRE XHP-07
STRIP×6 110mm
158
159 093-417 1 GROUND WIRE WITH
RING TONGUE
(BLACK) 170mm

33/16 C45
V+V+
V-
X34
3 2 1
X33
3 2 1
D33
CAG
AR X22
X-FADER
X21
100KB VR24B
100KB VR24A
PH-OUT PCB
X23
3 2 1
H.PHONES J7
S
R T
X24
SW9B SW9A
X19
6
5
4
3
2
1
100KB VR22B
100KB VR22A
X20
6
5
4
3
2
1
100KB VR23B
100KB VR23A
SW2A SW2B
X9 X10
4 3 2 1
CH2 CH1
50KA VR3B 50KA VR3A
10/25 C61 10/25 C60
20KB VR2B 20KB VR2A
X11
3 2 1
V- V+
47/25 C64 47/25 C63
V-
V+
56 R89
56 R96
CUE LEVEL
10P C57 10P C59
4.7/25 C58 4.7/25 C62
220/25
C55
220/25 C56
10 R87
10 R88
560 R92
120K
R91
3K6 R90
4556 IC7B
7
5 6
560 R94
120K R93
3K6 R95
4556 IC7A
84
1
3 2
X25
7 6 5 4 3 2 1
SW7D SW7C SW7B SW7A
X26
7 6 5 4 3 2 1
SW8D SW8C SW8B SW8A
X32
5 4 3 2 1
X30 X28
7 6 5 4 3 2 1
X31
5 4 3 2 1
X29 X27
7 6 5 4 3 2 1
X5
V+
V-
V- V+
100/16 C50 33/16 C47
POWER
J6 750
R68 750 R69
Z 12V D5 Z 12V D4
AC15V-JACK
1/50 C48 1/50 C49
7912 IC5
3
Vout
1
GND
2Vin
7812 IC4
3
Vout
2GND
1Vin
2200/25 C44 2200/25 C46
1N4002 D3 1N4002 D6
X4
4 3 2 1
B-
B+
V- V+
22/16 C18
22/16
C23
10 R34 10 R20
A-
A+
V- V+
22/16 C2
22/16
C7
10 R16 10 R6
10K R35
10K R33
10/16 C32
10/16 C31
1K R36
1K R32
J2B
101 C29 101 C30
B- B+
47/16 C26
180 R30
10/16 C27
10/16 C22
47/16 C21
180 R24
J2A
1K R27
1K
R21
822 C24
273 C25
47P C28
273 C20
47P C17
822
C19
100K
R29
47K R26
8K2
R28
47K R25
8K2
R22
100K R23
2068 IC2A
8 4
1
3 2
2068 IC2B
84
7
5 6
X2
10K R31
10K R19
10K R17
10K R15
10/16 C16
10/16 C15
1K R18
1K R14
J1B
101 C13 101 C14
A- A+
47/16 C10
180 R12
10/16 C11
10/16 C6
47/16 C5
180 R5
J1A
1K R9
1K
R2
822 C8
273 C9
47P C12
273 C4
47P C1
822
C3
100K
R11
47K R8
8K2
R10
47K R7
8K2
R3
100K R4
2068 IC1A
8 4
1
3 2
2068 IC1B
84
7
5 6
X1
10K R13
10K R1
RCA4 J3A RCA4 J3B
2G
2R 2L
V+ V-
X3
7 6 5 4 3 2 1
5K1
R37
330
R43
330
R44
5K1
R40
10K R39
10/16 C33
10K R38
10/16 C34
V+
V-
30-
30+
22/16 C41
22/16
C40
10 R65 10 R64
4558LD
IC3B
84
7
5 6
4558LD IC3A
84
1
3 2
J5 J4
24K R61 24K R58
180 R51
22/25 C39
180 R59
180 R55
22/25 C42
180 R62
101 C38
8K2 R52
8K2 R54
24K R56 24K R48
180 R41
22/25 C35
180 R49
180 R47
22/25 C37
180 R57
30- 30+
101 C36
8K2 R45
8K2 R42
V+
V+
3K6 R81
X7 X6
SW1D SW1C \ SW1B SW1A
V-
4558LD
IC6B
84
7
5 6
250KC VR1B
103 C52
272 C54
1448 D8
C1815 Q7
100K
R70
10K
R85
130K R74
51 R86
51K R76
51K R77
510 R83
9K1 R80
V-
V-
X8
4558LD
IC6A
84
1
3 2
250KC VR1A
A3
A2
A1
9.1V D9
103 C51
272 C53
1448 D7
C1815 Q6
100K
R72
10K
R84
130K R73
51 R82
51K R71
51K R75
510 R79
9K1 R78
1N4148 D35
1N4148 D34
V-
22/16 C96 22/16 C95
V+ V+
103 C105
103 C91
1M R179
10K R180
1M R149
510K R172
10K R181
510K R145
2SK363 Q11 2SK363 Q10
10K R137 10K R136
2SK363
Q9
2SK363
Q8
10K
VR14
10K
VR15
OPTOC VR21 OPTOC VR20
V- V+
G- G+
10 R156 10 R170
22/16 C103 22/16 C98
G+ G-
33K R169
101 C102
2068 IC14B
84
7
5 6
33K R158
101 C100
2068 IC14A
84
1
3 2
10K
VR11
10K VR10
X15
OPTOC VR9 OPTOC
VR8
V-
RED D21
3K6 R157
CH2
0.1/16 C106
+6+3+0-4-7-10-20
100K R163
2K7 R174
2K7 R175
3K6 R177
3K6 R178
3K6 R167
V-
10 R166
3K6 R176
3K6 R168
10/16 C104
10/16 C101
33K R173
10K R171 82K
R165
18K R164
10K R162
RED D28
RED D27
YEL D26
GRN D25
GRN D24
GRN D23
GRN D22
LB1403N
IC16
5
8
7
4
3
6
2
9
1
LB1403N
IC15
5
8
7
4
3
6
2
9
1
CH1
0.1/16 C90
100K R160
2K7 R139
2K7 R140
3K6 R142
3K6 R143
3K6 R154
V+
3K6 R141
3K6 R155
10 R153
10/16 C92
10/16 C99
33K R144
10K R147 82K
R152
18K R161
10K R159
RED D14
RED D15
YEL D16
GRN D17
GRN D18
GRN D19
GRN D20
LB1403N
IC12
5
8
7
4
3
6
2
9
1
LB1403N
IC13
5
8
7
4
3
6
2
9
1
V- V+
H- H+
10 R148 10 R129
22/16 C87 22/16 C97
V+
V-
H- H+
101 C89
101 C88
5K6 R135
1K R134
5K6 R138
1K R151 100K R146 100K R150
4.7/25 C94 4.7/25 C93
4558LD IC11B
84
7
5 6
4558LD IC11A
84
1
3 2
X16
7 6 5 4 3 2 120KMN
VR13B
L
20KMN
VR13A
R
50KA VR12B 50KA VR12A
V-
1N4148 D32 1N4148 D31 1N4148
D29
62K R215
CH2
E- E+
120K R212
22/16 C126
1K8 R205
6K8 R210
SW5C
4558LD IC19B
84
7
5 6
120K R204
22/16 C127
4558LD IC19A
84
1
3 2
1K8 R206
6K8 R216
SW5A
X18
5K1 R214
D30
CAG
AR
V+
SW6E SW6F
SW6D
SW6B SW6C
V-
V+
E- E+
10 R217
10 R213
22/16 C119 22/16 C123
101
C115
4558LD IC17B
84
7
5 6
50KA
VR16B
24K R192
1K8 R197
101
C122
E- E+
4558LD IC17A
84
1
3 2
50KA
VR16A
24K R189
1K8 R183 22/16
C112
5K6 R209
1K5 R186
33K R194
33K R211 33K R188
8K2 R198
56P C124
682
C125
103
C118
24K
R207
1K5 R196
2K4 R184
50KE
VR19B
154 C109
50KE
VR17B
562
C117
2068 IC18B
84
7
5 6
50KEVR18B
154 C107
3K6 R187
4K7 R208
10/16 C121
E+ E-
5K6 R190
1K5 R203
33K R191
33K R193 33K R195
8K2 R200
56P C113
682
C116
103
C111
24K
R202
1K5 R182
2K4
R185
50KE
VR19A
154 C108
50KE
VR17A
562
C110
2068 IC18A
84
1
3 2
50KEVR18A
154 C114
3K6 R201
4K7 R199
10/16 C120
22/16 C128
X14
4 3 2 1
X17
X12
V-
1N4148 D13 1N4148 D11 1N4148
D12
62K R122
D10
CAG
AR
D- D+
CH1
120K R109
22/16 C82
4558LD IC10B
84
7
5 6
SW3F SW3E
1K8 R103
6K8 R115
SW4A
4558LD IC10A
84
1
3 2
V+
5K1 R105
SW3D
120K R102
22/16 C70
SW3B SW3C
1K8 R113
6K8 R110
SW4C
22/16 C66
22/16 C84
V- V+
D- D+
10 R98 10 R104
22/16 C78 22/16 C71
5K6 R128
1K5 R133
33K R124
33K R117 33K R119
8K2 R107
56P C79
682
C75
103
C73
24K
R116
1K5 R112
2K4 R131
50KE
VR6B
154 C76
50KE
VR5B
562
C74
2068 IC8B
84
7
5 6
50KEVR7B
154 C77
3K6 R126
4K7 R118
10/16 C86
D+ D-
5K6 R127
1K5 R121
33K R108
33K R125 33K R120
8K2 R101
56P C65
682
C68
103
C69
24K
R100
1K5 R123
2K4
R130
50KE
VR6A
154 C80
50KE
VR5A
562
C72
2068 IC8A
84
1
3 2
50KEVR7A
154 C81
3K6 R132
4K7 R99
10/16 C85
101
C83
4558LD IC9B
84
7
5 6
50KA
VR4B
24K R114
1K8 R111
101
C67
D- D+
4558LD IC9A
84
1
3 2
50KA
VR4A
24K R106
1K8 R97
X13
Drawn By:C:ed\X1-4SCH\EX26SCH.DDB
File:
Sheet of4-Dec-2001
Date:
B
Size
Revision
Number
Title
A B C D
1234
D C
B A
4321

Parts of the design of this product may be protected by worldwide patents.
Information in this manual is subject to change without notice and does
not represent a commitment on the part of the vendor. Gemini Sound
Products Corp. shall not be liable for any loss or damage whatsoever
arising from the use of information or any error contained in this manual.
No part of this manual may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, electrical, mechanical,
optical, chemical, including photocopying and recording, for any purpose
without the express written permission of Gemini Sound Products Corp.
It is recommended that all maintenance and service on this product is
performed by Gemini Sound Products Corp. or its authorized agents.
Gemini Sound Products Corp. will not accept liability for loss or damage
caused by maintenance or repair performed by unauthorized personnel.
In the USA: If you experience problems with this unit,
call 1-732-738-9003 for Gemini Customer Service.
Do not attempt to return this equipment to your dealer.
Worldwide Headquarters • 120 Clover Place, Edison, NJ 08818 • USA
Tel: [phone] • Fax: [phone]
France • G.S.L. France • 11, Avenue Leon Harmel, Z.I. Antony, 92160 Antony, France
Tel: + 33 (0) 1 55 59 04 70 • Fax: + 33 (0) 1 55 59 04 80
Germany • Gemini Sound Products GmbH • Ottostrasse 6, 85757 Karlsfeld, Germany
Tel: 08131 - 39171-0 • Fax: 08131 - 39171-9
UK • Gemini Sound Products • Unit C4 Hazleton Industrial Estate, Waterlooville, UK P08 9JU
Tel: [phone] • Fax: [phone]
Spain • Gemini Sound Products S.A. • Mino, 112, Nave 1, 08223 Terrassa, Barcelona, Spain
Tel: [phone] • Fax: [phone]
© Gemini Sound Products Corp. 2001 All Rights Reserved
