Naxa NAS-3080 User manual

VIBE METRO Bluetooth®Speaker
NAS-3080
Instruction Manual
Please read carefully before use and keep for future reference.

Page 2 Naxa Electronics
Thank You
We know you have many choices when it comes to
technology; thank you for choosing us here at Naxa
Electronics. Established in 2001 in Los Angeles, Califor-
nia, we are dedicated to delivering products that en-
tertain and delight.
We trust that you will be happy with your purchase.
Please read this manual carefully and save it for refer-
ence. You may also nd the latest FAQ, documentation,
and other product material at our website. Come visit
us on the web at www.naxa.com and see all that we
have to offer!
In the Box
Please take a moment to make sure that you have ev-
erything in the list below. Although we make every ef-
fort to ensure that each Naxa device is securely packed
and sealed, we know a lot can happen in between us
and you. If anything is missing, check back with your
local retailer to get immediate assistance. If they can-
not help you, please contact our Naxa Support team at
www.naxa.com/naxa_support.
•NAS-3080
•Combination USB charge + 3.5 mm AUX adapter
cable

www.naxa.com Page 3
At a Glance
1 3
2
Part Description
1DC 5 V Micro USB power connector. Connect to
a USB power source to charge/power the
unit.
Plug in the included cable to improve the
unit’s radio reception.
2 USB port Play compatible MP3 les from USB
ash memory drives.
3 Power switch Set to ON to turn the speaker on.
Set to OFF to turn the speaker off.

Page 4 Naxa Electronics
4
5
7
6
Part Description
4Previous: Press to skip to the previous
track or radio station.
Volume down: Press and hold to de-
crease the volume.
5LED Press to change the light mode (Mode 1,
Mode 2, Off).
6 Mode: Press and hold to switch between
Bluetooth, Radio, AUX, and Music Play
modes. (Music Play is only available
when a compatible microSD card is
installed.)
Play/pause: Press to start, pause, or
resume playback.
Phone: Control the speakerphone func-
tions when the speaker is connected to a
Bluetooth enabled phone.
7 Next: Press to skip to the next track.
Volume up: Press and hold to increase
the volume.

www.naxa.com Page 5
12
11
10
8
9
Part Description
8 Power LED Lights red when the speaker is charging.
9 MIC Built-in microphone for speakerphone
functions.
10 Status LED Flashing blue quickly: Bluetooth®Pairing
mode.
Flashing blue slowly: Playing a track or
Bluetooth device.
Steady blue: Connected to a Bluetooth
device.
11 TF Play compatible MP3 les from microSD
or microSDHC memory cards.
12 Multicolor
lights
Press [LED] to control the Multicolor
light effects.

Page 6 Naxa Electronics
Connecting Power
Your speaker has an integrated rechargeable battery.
Upon initial use, the battery should be charged fully to
ensure optimal performance and battery life.
Use the included USB cable to connect the speaker to a
USB power source to charge the battery.
•Connect the small end of the included USB charge
cable to the DC 5V port of the speaker [1].
•Connect the large end of the cable to a high-power
USB port of a computer. The computer should be
powered on.
 The Power LED will light red when the
speaker is charging.
It takes approximately 2 hours to fully
charge the battery.
⚠To optimize the performance and longev-
ity of the battery, do not charge it for more
than 4 hours.
⚠The battery used in this device may present
a re or chemical burn if mistreated. Do not
disassemble, incinerate, or heat the battery.
Do not leave the battery in a place subject
to direct sunlight, or in a car with its win-
dows closed.
Do not connect the unit to a power source
other than that which is indicated here or on
the label as this may result in the risk of re
or electric shock.
To turn the speaker on, set the Power switch [3] to the
ON position.
To turn the speaker off, set the Function switch [1] to
the OFF position.

www.naxa.com Page 7
Using Bluetooth®Mode
Pairing a Device with Bluetooth®
A device must be paired with the speaker before using
them together for the rst time.
Make sure Bluetooth is enabled on your device before
attempting to pair it.
Set your speaker to Bluetooth mode (press and hold
. The speaker will automatically search for a paired
device. If it nds a paired device, it will connect to it
automatically, and you’re ready to play music from
that device.
If it does not detect a paired device, it will switch to
Pairing mode (the Status LED will [10] ash blue and
the speaker will announce “The Bluetooth device isr
ready to pair”). When the speaker is in Pairing Mode,
it will announce itself to nearby Bluetooth devices and
accept pairing requests from them.
1. The speaker will announce itself as “NAXA NAS-
3080.” Use your device to search for nearby Blue-
tooth devices. (This function is usually in the
Bluetooth settings menu; refer to your device’s in-
struction manual to learn more.)
2. Select the speaker from the list of found devices.
3. If your device asks for a passcode, use “0000” to
complete the pairing process.
When the speaker is paired and connected to a device,
the speaker will announce “The Bluetooth device has
connected successfully” and the Status LED [10] will
blink blue slowly.
 If the pairing process fails, turn the speaker
off, set the speaker to Bluetooth mode, and
then repeast steps 1-3.
Make sure that the volume of your device is
set to its maximum level; use the speaker to
adjust the volume to a comfortable level.
The speaker cannot be paired with more
than one device at a time.

Page 8 Naxa Electronics
Bluetooth®Speaker Controls
When the speaker is connected to a Bluetooth® device:
To do this... ...do this
Start, pause, or resume audio
playback
Press .
Skip to the previous track Press .
Skip to the next track Press .
Decrease the volume level Hold .
Increase the volume level Hold .
 Your Bluetooth device must support re-
mote functions in order to use the play
controls on the speaker.
Bluetooth®Phone Controls
When the speaker is connected to a Bluetooth®phone:
To do this... ...do this
Answer or end a call Press .
Reject an incoming call Press and hold .
Call back the last number Press twice quickly.

www.naxa.com Page 9
Using the Radio (FM)
Your speaker can receive FM radio broadcasts. Press
and hold [6] to switch the speaker to Radio mode.
 For better reception, plug the small micro
USB connector of the included cable into
the DC 5V port of the speaker [1].
The rst time you use the FM radio, press to scan
for stations and save them to preset memory. You
should also do this if you move the speaker to a differ-
ent location as the available stations will change.
When listening to the FM radio:
To do this... ...do this
Scan for stations and save them to
preset memory
Press .
Tune to a lower preset station Press .
Tune to a higher preset station Press .
Decrease the volume level Hold .
Increase the volume level Hold .
Using the Music Player
(MP3)
Your speaker can play MP3 les from microSD/microS-
DHC memory cards as well as USB ash memory de-
vices. Load memory cards in the TF slot [5]; USB ash
drives should be plugged in to the USB port [4]. The
speaker will switch to Music Player mode automati-
cally when it detects a USB ash drive or memory card.
 Music Player mode is only available when
the speaker detects a compatible memory
card or USB device.
The memory card and USB reader cannot
be used at the same time. Please connect
only one type of memory device at a time.

Page 10 Naxa Electronics
When the speaker is in MP3 Music Player mode:
To do this... ...do this
Start, pause, or resume audio
playback
Press .
Skip to the previous track Press
Skip to the next track Press .
Decrease the volume level Hold .
Increase the volume level Hold .
⚠Do not remove memory cards from the
speaker while the speaker is on. Doing so
may damage the speaker system or mem-
ory card.
Using AUX Input Mode
Connect devices without Bluetooth®by using the AUX
connection. The included 3.5mm AUX adapter is re-
quired to make this connection.
1. Connect the 3.5mm plug of the included AUX adapt-
er to the device’s headphone or line-out jack.
2. Connect the small micro USB plug to the DC 5V port
of the speaker [1].
3. Press and hold to switch the speaker to AUX
Input mode.
4. Turn on the device. Lower the volume on both the
device and speaker.
5. Set the device volume to 80% of its maximum and
then start playback.
6. Press and hold to gradually increase the volume
of the speaker to a comfortable level.
 Use the connected AUX device to control
all functions in AUX mode. The speaker can
only be used to adjust the volume.

www.naxa.com Page 11
Warnings and Precautions
The lightning ash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of unin-
sulated “dangerous voltage” within the product’s enclosure that
may be of signicant magnitude to constitute risk of electric
shock
The exclamation point within an equilateral triangle is intended
to alert the userto the presence of important operation and ser-
vicing instructions in the literature accompanying the appliance.
CAUTION
• Do not block the ventilation openings or holes.
• Do not place any naked ames (such as lighted candles) on the ap-
paratus.
• When discarding batteries, follow all local rules and laws governing the
disposal of batteries. Consider the environmental impact of your actions!
• To prevent re or shock hazard, do not expose this appliance to rain
or moisture.
Important Safety Information
1. Read Instructions: All the safety and operating instructions should be
read before the product is operated.
2. Retain Instructions: The safety and operating instruction should be
retained for future reference.
3. Heed Warnings: All warnings on the product and in the operating in-
structions should be adhered to.
4. Follow Instructions: All operating and usage instructions should be
followed.
5. Cleaning: Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
6. Attachments: Use only attachments recommended by the manufac-
turer. Use of other attachments may be hazardous.
7. Water and Moisture: Do not use this product near water (e.g., near a
bathtub, washbowl, kitchen sink, laundry tub, in wet basements, or
near a swimming pool and the like).
8. Accessories: Do not place this product on an unstable
cart, stand, tripod, bracket, or table. Use only with
carts, stands, tripods, brackets, or tables recom-
mended by the manufacturer or sold with the
product. Any mounting of the product should fol-
low the manufacturer’s instructions and should use
a mounting accessory recommended by the manu-
facturer. A product and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the
product and cart combination to overturn.

Page 12 Naxa Electronics
9. Ventilation: Slots and openings in the cabinet are provided for ven-
tilation to ensure reliable operation of the product and to protect it
from overheating. These openings should never be blocked by placing
the product on a bed, sofa, rug, or other similar surface. This product
should not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer in-
structions have been adhered to.
10. Power Sources: This product should be operated only from the type of
power source indicated on the rating label. If you are not sure of the
type of power supply to your home, consult your product dealer or
local power company. For products intended to operate from battery
power or other sources, refer to the operating instructions.
11. Grounding or Polarization: This product may be equipped with a po-
larized alternating-current line plug that has one blade wider than
the other. This plug will only t into the power outlet in one direction.
This is a safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the direction of the plug. If the plug should
still fail to t, contact an electrician to replace the obsolete outlet. Do
not defeat the safety purpose of the polarized plug.
12. Power-Cord Protection: Power supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon
or against them, paying particular attention to cords at plugs, conve-
nience receptacles, and at the point which they exit from the product.
13. Protective Attachment Plug: The product may be equipped with an at-
tachment plug with overload protection. This is a safety feature. See
the operating instructions for replacement or directions to reset the
protective device. If replacement of the plug is required, be sure the
service technician has used a replacement plug that has the same over-
load protection as the original plug as specied by the manufacturer.
14. Lightning: For added protection for this product, unplug it from the
wall outlet during a lightning storm or when it is left unattended and
unused for long periods oftime. This will prevent damage to the prod-
uct due to lightning or power-line surges.
15. Overloading: Do not overload wall outlets, extension cords, or inte-
gral convenience receptacles as this can result in a risk of re or elec-
tric shock.
16. Object and Liquid Entry: Never push objects of any kind into this prod-
uct through openings as they may touch dangerous voltage points or
short-out parts that could result in a re or electric shock. Never spill
liquid of any kind on the product.
17. Servicing: Do not attempt to service this product yourself as open-
ing or removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualied service personnel.
18. Damage Requiring Service: Unplug this product from the wall outlet
and refer servicing to qualied service personnel under the follow-
ing conditions: a) when the power-supply or plug is damaged; b) if
liquid has been spilled or if objects have fallen into the product; c) if
the product has been exposed to rain or water; d) if the product does
not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as
improper adjustment of other controls may result in damage and will
often require extensive work by a qualied technician to restore the
product to its normal operation; e) if the product has been dropped or
damaged in any way; f) when the product exhibits a distinct change in
performance—this indicates a need for service.
19. Replacement Parts: When replacement parts are required, be sure
that your service technician has used replacement parts specied
by the manufacturer or have the same characteristics as the original
part. Unauthorized substitutions may result in re, electric shock, or
other hazards.

www.naxa.com Page 13
20. Safety Check: Upon completion of any service or repairs to this
product,ask the service technician to perform safety checks to ensure
that the product is in proper operating condition.
21. Wall or Ceiling Mounting: The product should be mounted to a wall or
ceiling only as recommended by the manufacturer.
22. Heat: The product should be situated away from heat sources such as
radiators,heat registers, stoves, or other products (including ampli-
ers) that produce heat.
WARNING:
This product contains lead, a chemical known to the State of California to
cause cancer and birth defects or other reproductive harm. Wash hands
after handling.
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the lim-
its for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful in-
terference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to ra-
dio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be de-
termined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION ON MODIFICATIONS
Any changes or modications not expressly approved by the grantee of
this device may void the authority granted by the FCC to operate the
equipment.
Trademark & Regulatory Statements
Bluetooth®is a registered trademark of Bluetooth SIG, Inc. Other trade-
marks and names are those of their respective owners.
microSD and microSDHC are trademarks or registered trademarks of SD-
3C, LLC in the United States, other countries or both.

Page 14 Naxa Electronics
Troubleshooting Guide
This guide lists common problems and their solutions. Please refer to this guide before requesting service. If you
need further assistance, please contact Naxa Technical Support (www.naxa.com/naxa_support/).
Symptom Possible Cause Possible Solution
There is no
power.
The battery is
exhausted.
Connect the unit to a USB
power source to charge it.
The speaker hasn’t
been turned on.
Set the Power switch to ON
to turn the speaker on.
The device
is unable to
connect to the
speaker.
The speaker is not in
pairing mode.
Reset the speaker (turn
it off and then on again.)
Switch to Bluetooth mode.
The speaker will announce
“The Bluetooth device is
ready to pair.”
Bluetooth may be
disabled on your
device.
Make sure Bluetooth is
enabled on your device.
Turn it on if it isn’t.
Symptom Possible Cause Possible Solution
The device is
connected but
there is no
sound.
The AUX connector
may be in use.
Disconnect all cables from
the DC 5V connector of the
speaker.
Your device may be
beyond the effective
range of the speaker.
Move closer to the speaker.
Range may be affected
adversely by environmen-
tal conditions.
Your device may not
be in playback mode.
Ensure that your device is
operating correctly. Start
playback on your device.

www.naxa.com Page 15
Specications
Speaker Output 3 W RMS
Frequency Response 180-20,000 Hz
Removable Memory
Support
microSD, microSDHC (max 32 GB)
USB
Playable Media
Formats
MP3
Radio Tuner FM
Input Bluetooth® 2.1 + EDR
3.5mm AUX audio (with included
adapter)
Built-in microphone
Power Rechargeable battery (600 mAh)
USB charge port (DC 5V)
Play Time* 5 hours
* Play time will vary depending on use and environmental conditions.
Note: Products are improved continuously. We reserve the right to modify
the product and specications without prior notice.
Support
If you have problems with your device, please consult
the instructions in this manual. Please also visit us
on the web at www.naxa.com to get up to the minute
news, alerts, and documentation for your device. For
additional assistance, please contact Naxa Technical
Support.
NAXA Technical Support
2320 East 49th St.
Vernon, CA 90058
http://www.naxa.com/naxa_support/
