Generay RGB Series User manual

USER MANUAL
BL-5X7-RGB
5 × 7 ON-CAMERA RGBAW LED PANEL
RGB SERIES

BL-5X7-RGB 5 × 7 On-Camera RGBAW LED Panel - USER MANUAL
2
THANK YOU FOR CHOOSING GENARAY
Genaray’s 5 × 7 RGB LED light is a powerful and versatile
solution for advanced lighting effects with a compact on-
camera light.
Four operating modes offer lighting options for any
situation or effect. Use CCT mode to set a color
temperature that simulates the warmth of a tungsten bulb
or bright sunlight, and everything in between. HIS and
Color Wheel modes let you manually select any color from
the color wheel and adjust its saturation and brightness
levels. And the BL-5X7-RGB is loaded with 10 animated
effects that realistically simulate police car lights or
flashing paparazzi cameras for your videos.
The BL-5X7-RGB light is equipped with Bluetooth that
pairs with your tablet or smartphone the moment you
open Genaray’s RGB mobile app. The mobile app provides
access to even more powerful features, including group
and individual light control, and effects.
For the latest version of the RGB mobile app, visit
genaray.com.
BL-5X7-RGB
INTRODUCTION

BL-5X7-RGB 5 × 7 On-Camera RGBAW LED Panel - USER MANUAL 3
· Please read and follow these
instructions, and keep this manual in
a safe place.
· Keep this product away from water
and flammable gases or liquids.
· Use only the correct, recommended
voltage.
· Do not attempt to disassemble or
repair this product.
· Clean this product with only a soft, dry
cloth.
· To avoid damage to this product,
be careful not to overtighten or
improperly thread any of the threaded
fittings.
· All images are for illustrative purposes
only.
PRECAUTIONS
Precautions

BL-5X7-RGB 5 × 7 On-Camera RGBAW LED Panel - USER MANUAL
4
PRODUCT
OVERVIEW
Mounting foot
1/4-20 mount
Locking ring
Angle adjustment lock
LED array
Diffuser

BL-5X7-RGB 5 × 7 On-Camera RGBAW LED Panel - USER MANUAL 5
Product overview
Power input socket Power switch
Battery plate
LED screen
Mode selector
Adjustment
dial

BL-5X7-RGB 5 × 7 On-Camera RGBAW LED Panel - USER MANUAL
6
MOUNTING THE
LIGHT
MOUNTING TO A TRIPOD
OR LIGHT STAND
Use the 1/4-20 socket on the bottom
of the shoe mount to screw the light
onto a light stand’s stud until secure.
MOUNTING TO A CAMERA
Slide the mounting foot completely
into the camera’s hot shoe. Tighten
the locking wheel until it’s tight,
and the mount is secure.
Slide the battery into the battery
slot until it locks in place.
To remove the battery, slide it out of the slot.
Tip
The battery loses some of its charge
when not in use. If the battery has not
been in use for several months,recharge
the battery before a shoot.
INSTALLING THE BATTERY
instructions

BL-5X7-RGB 5 × 7 On-Camera RGBAW LED Panel - USER MANUAL 7
USER INTERFACE
· If you encounter any problems, first try
turning the device off and then on.
· If the problem persists, remove the
battery for 15 seconds, and then restart.
· Go to genaray.com to make sure
you have the most recent firmware
update. If a new firmware version is
available, follow the instructions on
how to download it to your light.
MODE SELECTOR
Press the mode selector to cycle through
the operating modes CCT, HSI, Gel,
and EFX, and the Settings menu.
ADJUSTMENT DIAL
In all operating modes, the
adjustment dial changes the value
of the highlighted parameter.
Press the adjustment dial to
select the adjustable parameters
within each operating mode.
TROUBLESHOOTING
instructions

BL-5X7-RGB 5 × 7 On-Camera RGBAW LED Panel - USER MANUAL
8
CCT: Adjusts the color temperature in
50 K increments from 2800 to 8000 K.
Intensity: Adjusts the brightness from
0% to 100% in 1% increments.
Hue: Adjusts the hue from 0° to
359° of the color wheel.
Saturation: Controls the saturation of the
hue from 100% to 0% in 1% increments.
Intensity: Adjusts the brightness from
0% to 100% in 1% increments
CCT MODE HSI MODE
instructions
CCT G01 L01 M
CCT:
INT 8000
HSI G01 L01 M
HUE:
INT
SAT 359°

BL-5X7-RGB 5 × 7 On-Camera RGBAW LED Panel - USER MANUAL 9
Gel: Select one of 48 colored gels.
Intensity: Adjusts the brightness from
0% to 100% in 1% increments
EFX MODE
The BL-5X7-RGB is preset with 10
animated lighting effects that can be
accessed from the back panel of the light.
Use the adjustment dial to select
one of the 10 preloaded effects.
Press the adjustment dial to play
the effect. Press the adjustment
dial again to pause the effect.
Each effect’s parameters can be
edited in the Genaray RGB app.
GEL MODE
instructions
GEL:
INT
GEL G01 L01 M
BLUE
1/2 BLUE
3/4 BLUE
01
EFX G01 L01 M

BL-5X7-RGB 5 × 7 On-Camera RGBAW LED Panel - USER MANUAL
10
EFFECTS
Color Chase: Scrolls through the
entire color wheel from 0% to
359% on a continuous loop.
Lightning: Simulates lighting
with short bursts of light.
Cop Car: Simulates the flashing
lights of an emergency vehicle.
Paparazzi: Simulates multiple camera
flashes with short bursts of white light.
Strobe: Constant flashing white
light simulates strobe lighting.
Fireworks: Simulates the effect of fireworks
with pulses of color and/or white light.
Pulsing: A steady pulse of light.
Similar to the Strobe effect, but
the light fades on and off.
Explosion: Simulates the light
from explosions with bursts of
light that flash on and fade off.
Television: Simulates the glow from
a television with a constant light and
random color temperature changes.
Fire: Simulates the light of a campfire
or fireplace with a constant light
that randomly fades between a set
range of color temperatures.
