Generic SL-R6801 Series User manual

Page 1 of 10
150Mbps Wireless Router
SL-R6801 Series User Guide
l
1、Introduction
The 150Mbps Wireless-N Broadband Router is dedicated to Small Office/Home Office (SOHO) Wireless
network solution. It is 4 in 1 network device, which combines wireless access point, firewall, 4-port
Switch and the NAT-Router. It provides up to 150Mbps data transmission rate in 2.4GHz frequency,
complies with IEEE 802.11n, IEEE 802.11g and IEEE802.11b and backwards compatible with all IEEE
802.11n/g/b devices. And the router
lso supports wireless LAN up to 128-bit WEP, WPA/WPA2 encryption security. The 150Mbps Wireless-N
Broadband Router also provides WEB and Remote Management and system log so that network
administrators can manage and monitor the network in real time. The 150Mbps Wireless-N Broadband
Router also provides a hardware WPS (Wi-Fi protected setup) button, which helps you setup a secure
wireless network in a snap. The button lets you activate the wireless protection easily
2、login
To access the Router’s Web-based interface, launch a web browser such as Internet Explorer and enter
the Router’s default IP address, http://192.168.0.1. Press “Enter”. Input the “admin” in both User Name
and Password. Click “OK”. User:”admin” password:”admin”
3、WAN Medium Type

Page 2 of 10
4、Wireless Basic Settings

Page 3 of 10
5、Wireless Security Setting

Page 4 of 10
6、Wireless Distribution System(WDS)

Page 5 of 10
7、DMZ Settings

Page 6 of 10
一．Product features introduced
Ø wireless AP, routers, 4 port switches, firewall function four-in-one bucket ;
Ø Based on the latest IEEE802.11 n standards, compatibiliteIEEE802.11b IEEE802.11 g in back
ward;
Ø increases 6 times covered distance than the original 802.11 g standard , and effectively reduc
e coverage of the area's blind spots;
Ø offer over 3 times transmission rate than ordinary 802.11 g product
Ø support 64/128-bit data encryption.WEP, WPA, and WPA2 , WPA&WPA 2 mixed and so on ma
ny kinds of encryption and security mechanism;
Ø support RTS/CTS protocol (request to send/allow send agreement), data subdivision function;
Ø provide 1 10/100M adaptive Ethernet (WAN) interface, and WAN connection;
Ø provide four 10/100M adaptive Ethernet (LAN) interface, and LAN connections;
Ø support XDSL/Cable MODEM, residential broadband fixed IP, dynamic IP of residential broadba
nd access
Ø support MAC address filtering, IP address filtering, URL filtering;
Ø supports remote Web management, all Chinese configuration interface, simple way of Web upg
rading
Ø using wireless Roaming (Roaming) technology, efficient wireless connection;
Ø support hidden wireless SSID function and based on the MAC address of access control (as
many as 30 groups);
Ø support port automatic identification cross/direct （Auto MDI/MDIX）
Ø provide system security logs, can record routers use state;
Ø support IEEE802.11 b/IEEE802.11 g adaptive or manual settings mode;
Ø support universal plug and play (UPnP), DDNS function;
Ø support Firefox 1.0, IE5.5 and upgrade web browser;
Ø support banned LAN users to access the Internet;

Page 7 of 10
Ø support simple network time protocol (SNTP);
Virtual server;
Ø support DMZ host;
Ø support WDS wireless network expansion;
Ø support broadband control function
二、introduction of Product Parameters
basic parameter
System
requirements
The cable with Ethernet port or DSL modems configured
Computer :Windows XP SP2 or Windows 2000 SP4 or Mac OS X （v10.410.3
）or based on Linux OS
-Already installed Ethernet card
- Internet Explorer 6 or Firefox 2.0 or higher
Internet Official
Protocol
Standards
IEEE 802.11n、IEEE 802.11g、IEEE 802.11b;
IEEE 802.3、IEEE 802.3u、IEEE 802.3x
Wireless rate 300 Mbps
Wireless frequency
range 2.4 GHz～2.4835 GHz
Connector （Board
inside）
•one 10/100M self-adaption RJ45 WAN port（Auto MDI/MDIX）；
• four 10/100M self-adaption RJ45 LAN port（Auto MDI/MDIX）；
Button WPS(1 Sec)/Reset(5 Sec)
LED
•PWR Power indication
•WLAN status indication
•LAN Link/Act indication
Power supply input voltage range (VAC)：110V～240V
Output voltage range (VDC): 12V==1A
Antenna Detachable 5dBi antenna
Size (L×W×H) 130mm x 86.5mm x 18 mm
Wireless parameters
Fundamental
Function
•Wireless switch ；
•SSID Radio switch；
•channel selection：1～14；
•Band bandwidth optional：20MHz、40MHz、；
• Wireless mode optional：11n Only、11b/g/n Mixed、11b/g Mixed、11g Only、
11b Only；

Page 8 of 10
•Launch adjustable power；
Work Pattern
•Bridge mode；
•Gateway mode；
•Ethernet Converter mode；
•AP Client mode；
Power 19dBm （maximum）
EVM -29dB
Accept Sensitivity
135M:-70dBm@10% PER;65M:-72dBm@10% PER;
54M:-75dBm@10% PER; 11M:-86dBm@10% PER;
13M: -85dBm@10% PER; 6M:-87dBm@10% PER;
Wireless Security
•Wireless MAC address filtering；
•Wireless security function switch；
•64/128 WEP encryption；
•WPA/WPA2、WPA-PSK/WPA2-PSK security mechanism；
Other
Functions
•Support wireless roaming；
•Radio host status display；
Cable function
DHCP Settings
•DHCP server；
•DHCP clients；
•he client list；
•static address assignment；
Port Forwarding
•virtual server；
•special applications；
•DMZ host；
•UPnP Settings；
Security Settings
•IP and MAC address binding the ARP attack；
•IP address filtering；
•domain filtering；
•MAC address filtering；
•DoS attack prevention；
•FLOOD attack prevention；
•Ping control;
System Tools
•flow statistics；
•system safety diary；
•local Web management control；
•remote Web management；
•the configuration file introduction and export；
•Web software upgrade；
Other
Use environment
•working temperature：0℃～40℃
•storage temperature：-40℃～70℃
•working humidity：10%～90%RH no condensation
•storage humidity：5%～90%RH no condensation

Page 9 of 10
三．Software function profile
1. Wireless access
Support 54/48/36/24/18/12/9/6M or 11/5.5/2/1-m rate adaptive; Support 64/128/152 a WEP encryption;
Support 802.1 X, WPA, IEEE TKIP, AES encryption and security mechanism etc; Support SSID
broadcasting control and based on the MAC address of access control; Using wireless Roaming
(Roaming) technology, efficient wireless connection;
2. Intelligent NAT (optional, routing mode use)
Support NAPT, NAT and routing mixed use, meet various complex network address planning. Support
NAT static mapping and DMZ host, outward Telnet, provide WWW, FTP service etc; Support NAT Re -
ccna and reverse NAT; Provide NAT ALG function, support FTP, IPSec ESP PPTP, such special
application protocol.
3. Firewall function (optional, routing mode use)
Powerful defense internal/external attack ability, can effectively prevent the ARP deception, port scanning,
DoS/DDoS and other network attacks, prevent shock wave, shock waves, SQL worms etc virus attack,
maximum guarantee network stability and security.
Realized based on source/destination IP address, agreement, port, the source/purpose MAC address of
packet filtering, based on the URL and keyword application layer filter, can according to time filtered. By
using the filtering technology business management function, can not only control user Internet access
and the Internet time, can protect the internal network from foreign attack.
4. User management (optional, routing mode use)
Provide the user personalized management function, realization by the 100 percent of the on-demand
customization. In view of the user's actual demand, each machine internal hosts are can take different
strategy (can be a PC can use limited bandwidth, NAT session number, whether to ban QQ, MSN, P2P,
etc), solve the traditional division management enough flexible problem. This function can not only
greatly strengthen management flexibility, and to a certain extent, reduce administrator's workload.
Support IP/MAC address binding, filter illegal IP or MAC address, also support the IP/MAC address all
binding function, just a key operate, can one-time will all dynamic IP/MAC address to all bound, and can
effectively prevent the LAN host ARP deception attacked suffer.
5. Network monitor (optional, routing mode use)
Offers a variety of monitoring and diagnosis method, the dynamic monitoring network movement situation,
user Internet behavior, help the website operators quickly positioning and eliminate network fault,
especially to real-time found network anomalies and the anomalous host, such as infection virus or attack
mainframe.
Website operators through the real-time monitoring CPU utilization, memory utilization, NAT table, and
other key system resources, can in time found potential of various attacks; Through the real-time view
each interface bandwidth, check each user's upload/download bandwidth and NAT session number, view
the upload/download bandwidth list and NAT session number list, can quickly locate speeds slower, card

Page 10 of 10
and other network anomalies.
6. Allocation and management (optional, routing mode use)
Provide friendly all Chinese WEB interface, intuitive easy-using, function are rich; While still providing
traditional CLI interface, function more enrichment; And, two ways are supported through the Internet for
under simple, safe and remote management.
Support the configuration file backup and import, but will the current configuration file save to manage the
computer, may also will backup configuration files payload to AP, save the time repeat configuration;
Support WEB of upgrades, convenient and function expansion
FCC warning statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void
your authority to operate this equipment.
