GENEVO MAX User manual

GENEVO MAX
USER MANUAL

2 3
MAIN FEATURES OF YOUR
GENEVO MAX DETECTOR:
GENEVO MAX is the rst member
of new lineup of Genevo radar
detectors.
It is designed primarily to protect
the driver from unnecessary pen-
alties for speeding due to reliable
detection of:
• microwave radars (K, Ka).
• MultaRadars CT and CD.
• Gatso RT3 and RT4 radars.
• red-light cameras.
• Stationary speed cameras.
• Section speed cameras (using
GPS updatable database).
ALARM INTERPRETATION:
In the case of a radar alert, a
visual warning appears on the
display. A voice refers to the
frequency band and the intensity
of the intermittent tone (beep)
expresses the strength of the re-
ceived signal. The signal strength
has nine levels for better distance
expression. GPS points are report-
ed verbally, such as “section speed
cameras”.
ADVANCED FEATURES:
• Motion sensor for contactless
operation. Silence the alarm
without having to search for the
right button.
• Ambient light sensor for auto-
matic brightness adjustment.
The display automatically adjusts
the brightness according to the
amount of light in the cabin.
• Noise sensor in the cabin. The
detector automatically adjusts
the alarm volume according
to the level of noise inside the
vehicle.
CONGRATULATIONS
ON PURCHASING
GENEVO MAX
QUICK GUIDE:
Magnetic holder
surface
(horizontal
attachment)
Magnetic holder
surface
(Vertical
attachement)
1. 12V power input
2. 3.5mm jack for
headphones
3. USB-C input for PC
updates
4. Control buttons
5. Status indicator
6. Motion sensor
7. Control buttons
8. Menu button
9. Magnetic surface for
bracket
10. Laser sensor
1 2 3 4 5 6
7
8
9
10
Power through
the supplied
cable to a 12V
cigarette lighter
socket

4 5
HOME SCREEN:
MAIN MENU:
Brightness
control
Increase
the volume
Decrease
the volume
Move the
menu left
Move the
menu right
Short press: Main menu
Long press: Turn o
Short press:
Sensitivity setting
Long press:
Add a custom point
Short press:
Enter the submenu
Long press:
Return to the home screen.
CONTROL SETTING SUBMENU:
DURING ALERT:
Change
item
value
Change
item
value
When
pressed
repeatedly:
Brightness
control
When
pressed
repeatedly:
Sensitivity
setting
Move the
menu up
Move the
menu
down
When
pressed
repeatedly:
Increase
the volume
When
pressed
repeatedly:
Decrease
the volume
Short press:
Return to main menu
Long press:
Return to the home screen
When pressed repeatedly:
Main menu
Currently selected
item to edit
Hand gesture, or short press of any
button will silence the alarm
Any button will lockout false alarm
location when long pressed

6 7
MAIN MENU ITEMS
SETTING THE DETECTOR
USER SETTINGS:
DISPLAY: Setting the information displayed on the right side
of the display:
• TIME 24H - Displays time in 24h format.
• VOLTAGE - Display the battery voltage.
• COMPASS - Displays driving direction.
• TIME AM/PM - Displays time in 12h format.
TIME: Setting local time zone.
USER BUTTON: The user button on the cable can be set to the
following functions: NONE/LOCKOUT/MUTE/MARK/
SENSITIVITY/BRIGHTNESS/POWER OFF
STARTUP SOUND: ON / OFF
GPS STATUS SOUND: ON/OFF. Notication of GPS
connection/disconnection status.
ALERTS: Set the alert type.
• VOICE PRIORITY - The detector announces
the detected band rst, then beeps according
to the alarm intensity.
• BEEP PRIORITY – The detector rst starts
beeping, then announces the detected band
and then continues beeping.
• BEEP ONLY – The detector only beeps with
the relevant band tone but does not report
the detected band type.
AUTO MUTE: ON/OFF. Automatically mutes the volume of alarm
messages after 5 seconds.
AUTO VOLUME: ON/OFF. Automatically adapts the selected vol-
ume to the noise in the vehicle cabin.
X TONE: 1-15 - Options for selecting dierent alert tone
K TONE: 1-15 - Options for selecting dierent alert tone
KA TONE: 1-15 - Options for selecting dierent alert tone
MD TONE: 1-15 - Options for selecting dierent alert tone
MT TONE: 1-15 - Options for selecting dierent alert tone
G3 TONE: 1-15 - Options for selecting dierent alert tone
G4 TONE: 1-15 - Options for selecting dierent alert tone
This option allow you to choose dierent sound
for each band separately.
MOTION SENSOR: Adjust the speed of waving hand to:
NORMAL/SLOW/FAST/OFF
UNITS: METRIC / IMPERIAL
LANGUAGE: ENGLISH / ČESKÝ / DEUTSCH
FACTORY RESET: Returns the detector settings
to the factory settings.
ALL USER AREAS DELETED: Deletes all saved user areas.
LOCKOUT RESET: Deletes all false alarm locations (lockouts).
ALERTS
NOTIFICATION SETTINGS:
SENSITIVITY: HIGHWAY - Maximum detector sensitivity.
CITY - Reduced sensitivity. We recommend using
the reduced sensitivity only in the case of
frequent alarms on a certain band (e.g. when
driving abroad with frequent false alarms on
the “K” band).
AUTO CITY - Automatically changes the maximum
and diminished sensitivity depending
on the speed.
CITY: Sets the limit of reduced sensitivity. (E.g.: If you
often encounter false alarms on the “K” band with
signal strength 2 when driving through the city,
then set K2, the detector will not warn of any signal
lower than and equal to the set intensity, OFF will
turn o this band in reduced sensitivity).
X: 0–9/OFF
K: 0–9/OFF
Ka: 0–9/OFF
ACITY (AUTO CITY): This feature enables the sensitivity limit on the
X, K, and Ka bands within the speed range set by
ACITY Speed (see ACITY Speed below).
X: 0–9/OFF
K: 0–9/OFF
Ka: 0–9/OFF

8 9
ACITY (AUTO CITY) SPEED: Automatically adjusts sensitivity to
your speed. E.g. When set to 30 50, the
detector will not notify you of any signal
at speeds of less than 30 km/h, at speeds
of 30-50 km/h, the detector will notify
you according to the ACITY setting, and
when driving at speeds over 50 km/h,
the detector will automatically notify you
with maximum sensitivity. When driving
below the set speed, the detector will not
warn of radars.
MIN SPEED: OFF/10-130KM/H - Sets the minimum
speed at which the detector starts to
alert on radars. E.g. when set to 20KM/H,
the detector will only start to warn when
this speed is exceeded.
X BAND: ON/OFF
K BAND: ON/OFF
K FILTER: NORMAL/HIGH/OFF
KA BAND: NARROW – Narrowed Ka band for more
specic band setup and fewer
false alarms.
WIDE – enables detection
of the whole Ka band.
OFF – disables Ka band detection.
KA BAND 34.0: ON/OFF
KA BAND 34.3: ON/OFF
KA BAND 34.7: ON/OFF
KA BAND 35.5: ON/OFF
KA FILTER: NORMAL/HIGH/OFF
LASER DETECTION: ON/OFF
MR CT: WIDE/NARROW/OFF
MR CD: WIDE/NARROW/OFF
GATSO RT3: ON/OFF
GATSO RT4: ON/OFF
MR FILTER: LOW/HIGH/OFF - This function lters out
false alarms of cars that use a blind-spot
assistant or adaptive cruise control.
When the MR Filter function is active,
detector sensitivity to MR CT/CD radars is
slightly reduced.
GPS POINT ALERTS:
ALERT DISTANCE: 250m/350m/ 450m (setting the distance of GPA
point warning).
OVERSPEED: -10 km/h to +10 km/h (setting of possible speed-
ing without warning).
SPEEDCAM: ON/OFF
AVERAGE SPEEDCAM: ON/OFF
RED-LIGHT CAM: ON/OFF
DANGEROUS SPOT: ON/OFF
INFO:
This section contains contacts and information about the rmware ver-
sion, database, device serial number, and more.
DATABASE UPDATE:
It is recommended to update the GPS database once a month. The detec-
tor can be updated in two ways:
1. Simply online for WIN and MacOS at:
www.genevoupdate.com
2. By downloading the updater software for Windows OS at:
www.genevo.com/en/updates/
On these websites you will nd not only help on how to update, but
also a newsletter form, so we will keep you informed about every newly
released update.

10 11
CE - DECLARATION OF CONFORMITY
You can nd the Declaration of Conformity in its entirety at:
GENEVO.COM/EN/CE-MAX.pdf
OPERATING FREQUENCY:
GPS: GPS, GLONASS, Galileo a QZSS
Ka narrow: 34,0 GHz, 34,3 GHz, 34,7 GHz, 35,5 GHz (±120 MHz)
Ka wide: 33,4 GHz ~ 36,0 GHz
K narrow: 24,125 GHz (±70 MHz)
K wide: 24,125 GHz (±150 MHz)
X Band: 10,525 GHz (±50 MHz)
MultaRadar: CD/CT
Gatso: RT3/RT4
Laser: 904nm
TECHNICAL PARAMETERS:
Operation temperature: -20 °C to +85 °C
Storage temperature: -20 °C to +85 °C
Operation voltage: 11 V – 16 V
Power consumption: 250 mA normal, 330 mA max. (at 12 V)
Dimensions: 101 mm × 68 mm × 33 mm
EXPLANATORY NOTES:
Radar frequency bands: Dif-
ferent radar bands are used to
measure speed, most often Ka,
K, X, or newer MultaRadars and
Gatso Radars that have extreme-
ly low transmit power and are
thus hard to detect. Dierent
bands and frequencies are used
in each country, it is therefore
necessary to have the detector
set up correctly in each country.
• Ka - One of the most common-
ly used radar band for speed
measuring.
• K - The most widely used band
at all, is comonnly used for au-
tomatic doors at petrol stations
and shops, adaptive cruise con-
trol, etc. Devices operating in
the “K” band cause false alarms,
so their quality filtration is
essential.
• X – less and less used band,
used only in some Eastern Euro-
pean countries.
• CD/CT MultaRadars - modern
radars used in Slovakia, Austria,
Poland, the Netherlands, Spain,
Portugal, or Iceland. Their de-
tection is difficult and requires
a specially modified antenna.
• Gatso radars - are the worst
detectable ones, they can be sta-
tionary or mobile. They are used
in the Netherlands, Belgium,
France, Great Britain, Slovenia,
Lithuania and Finland. They are
divided into RT2/RT3/RT4 - a
higher number means a more
modern version. The detection of
these radars is possible only by
the most modern and sensitive
detector.
Narrow: narrowed bands (not
only Ka). The frequencies of a
specic part of the band are de-
tected in the narrowed Ka band to
increase sensitivity and eliminate
false alarms.
Wide: Broadband mode, on the
other hand, searches for exam-
ple the entire Ka band from 33.4
GHz to 36.0 GHz. Use this setting
only if absolutely necessary, as it
shortens the detection distance
and increases the number of false
alarms.
Filters and false alerts: For
the correct functioning of the
detector, it is essential to lter
unwanted radar signals so that
the detector reports only police
radars. The lter settings are
further described on page 7 in the
manual (ALERTS NOTIFICATION
SETTINGS).
Laser measurement: Laser
speed measurement is based
on emitting an ultra narrow and
short-time beam of electromag-
netic light at the level of infrared
radiation. The signal is trans-
mitted for a very short time at a
specic place (usually car’s licence
plate) and therefore, it is almost
imposible to detect it in advance.
The only eective protection
against laser speed measurement
is a laser jammer.
GPS: The GPS antenna also de-
tects measurements that do not
emit any signals. These include
section speed cameras, stationary
speed cameras (induction loops)
or “red-light cameras”. We keep
adding everything continuously
to the GPS database of stationary
threats - all you have to do is keep
the detector updated.

2 019 -11-2 2
