Genius SW-G2.1 3000 User manual

Service Guide Model No : SW-G2.1 3000
SERVICE GUIDE
KYESYSTEMS CORP.
Page 1/17

Service Guide Model No : SW-G2.1 3000
Revision History
Version Date Change
1.0
16 / 11 /201 1 First Release
Page 2/17

Service Guide Model No : SW-G2.1 3000
Table of Contents
Revision History …………………………………………………………………….2
Table of Contents ……………….……………………………………………………3
Getting Started ……………………………………………………………………….4
Conventions Used in this Guide ……………………….…..………………....4
Safety Precautions …….……………………………………………………..4
Chapter 1. How to Handle Defective Returns……………………………………..5
1.1 Speaker no sound
1.2 Power LED no light
1.3 Headphone no sound
1.4 Bass/Volume no function
Chapter 2. Specifications ………………………………………………………….10
Chapter 3. Block Diagram ……………………………………………………….11
Chapter 4. Exploded View …………………………………………………12 & 13
Chapter 5. Part List ………………………………………………………………14
Chapter 6. Schematic Diagram …………………………………………………..15
Chapter 7. Important Notes ………………………………………………………16
7.1 Packing Requirement for Sending the PCB Assembly by Post …..16
7.2 Short of Spare Parts while Repairing a Speaker System …………16
Page 3/17

Service Guide Model No : SW-G2.1 3000
Getting Started
Conventions Used in this Guide
Pay Special Attention : Instructions that are important to remember and
may prevent mistakes .
Caution : Information that, if not followed, may result in damage to the
product .
Safety Precautions
The following precautions should be observed in handling the speaker
Described in this guide :
Place the speakers on a flat, level and stable surface.
Do not place the speakers in environments subject to mist, smoke,
vibration, excessive dust, salty or greasy air, or other corrosive gases
and fumes.
Do not drop or jolt the speakers.
Do not allow anything to drop into the subwoofer case through its
ventilator, as it could result in fatal electric shock or fire .
Place the unit far enough from other equipments for good heat
dissipation .
Disconnect the AC power cord from the AC outlet before performing
any maintenance on the speakers .
Do not perform any maintenance with wet hand .
Prevent foreign substances, such as water, other liquids or chemicals ,
From entering the speakers while performing maintenance procedures
on the speakers .
Page 4/17

Service Guide Model No : SW-G2.1 3000
Chapter 1. How to Handle Defective Returns
Overview
Receiving Defective speakers from
Customers
Function NG
__ __
Analyzing possible malfunction
causes
Function NG Deciding & proceeding the
rectification methods
Function OK
Replace necessary defective parts
Function OK
Return the speakers with proper
repackaging to customers
Page 5/17

Service Guide Model No : SW-G2.1 3000
Problems
Item Problem Description
1.1 Speaker no sound
1.2 Power LED no light
1.3 Headphone no sound
1.4 Bass/Volume no function
Page 6/17

Service Guide Model No : SW-G2.1 3000
Attention
Please follow the numbered sequence marked within parenthesis given in individual Flow
chat, in that this is the best-recommended sequence to rectify the problems.
1.1 One or more channels no sound (Line in/Audio in jack no function)
Problem
Analyze
and
Identify
Cause
Solution
Speaker no sound
Component cold
solder or Short
Circ
uit
Defective
U1,U2,U3,U4
&U5
,
Speaker cable disconnect,
JK_IN_D3.5&
JK1defective or speaker
damaged
Check solder
point on PCBA
Check and
Replace defective
IC
Reconnect speaker cable or
replace defective speaker
driver and component
Page 7/17

Service Guide Model No : SW-G2.1 3000
1.2 Power LED no light
Problem
Analyzer and
Identify the Causes
Solutions
1.3 Headphone no sound
Problem
Analyzer and
Identify the Causes
Solution
Power LED no light
Component cold
solder or Short
Circuit
Defective
D1,T1A,U1,U2,
Q1,TL431 or
F4*8
Power Switch(VR1) or
LED defective
Check solder
point on PCBA
Check and
Replace defective
IC
or Fuse
Replace defective Power
Switch or LED
Headphone no sound
Component cold
solder or Short
Circuit
J4 Phone jack defective
Check solder
point on PCBA
Replace defective J4 Phone
jack
Page 8/17

Service Guide Model No : SW-G2.1 3000
1.4 Bass/Volume no function
Problem
Analyzer and
Identify the Causes
Solution
Bass/Volume no function
Component cold
solder or Short
Circuit
VR1 or VR2 defective
Check solder
point on PCBA
Replace defective
VR1 or
VR2
Page 9/17

Service Guide Model No : SW-G2.1 3000
Chapter 2. Specifications
NO. Description Unit Specifications
1 Out Power at THD 10%(Sub) W
≧ 40
2 Out Power at THD 10%(Sat) W
≧ 15
3 Sensitivity(Sub) mV 130± 30
4 Sensitivity(Sat) mV
600± 60
5 Freq. Response (1KHz -3dB) Hz 23~126
6 Freq. Response (1KHz -3dB) Hz 119~20K
7 Separation dB
≧
≧≧
≧ 40
8 S/N ratio dB
≧
≧≧
≧ 70
9 Hum & Noise (Vol.: max) mV
≦
≦≦
≦ 2
Page 10/17

Service Guide Model No : SW-G2.1 3000
Chapter 3 Block Diagram
Audio in
LCH & RCH
Headphone output
LCH & RCH
Power Sw, Tone &
Volume control
Audio
Amplifier IC
TPA
3123D2
LCH
RCH
Page 11/17
PRE-Amplifier
Line in
LCH & RCH
Mic in
LCH & RCH
Mic out
LCH & RCH PC
SUB

Service Guide Model No : SW-G2.1 3000
Chapter 4. Exploded View
Page 12/17

Service Guide Model No : SW-G2.1 3000
Page 13/17

Service Guide Model No : SW-G2.1 3000
Page 14/17

Service Guide Model No : SW-G2.1 3000
Chapter 5. Part List
No
DESCRIPTION Qty UNIT Part No.
1
TPA3123D2 IC
1 U1,U2
2 JRC4558 SMD SOP8 IC 1 U3,U4,
U5
3 Photocoupler EL817A 1 U2
4 F09-1028009-00 Transformer 1 T1A
5 Bridge Rectifier 1 D1
6 STEREO CABLE 1
VMC700002-00
10
7 RCA CABLE 1
VRC220001-002
0
8 RCA CABLE 1
VRC155007-002
0
9 POWER CORD 2P 1
VPE003012-002
0
10 SPK UNIT 1 FSA511530-362
4
11 SPK UNIT 1
FSB524065-68
0
12 RCA CABLE 1
VRC155007-001
0
13 RCA CABLE
1
VRC155007-003
0
Page 14/16
Page 15/17

Service Guide Model No : SW-G2.1 3000
Chapter 6. Schematic Diagram
Pls refer to The Attachment
Page 16/17
