GeoVision GV-Mini System V2 User manual
GV-Mini System V2
UseUser’s Manual
MIV2-UM-A
© 2023GeoVision, Inc. All rights reserved.
Under the copyright laws, thismanual may not be copied, inwhole or inpart,
without the written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is
accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind
and assumes no responsibility for errors or omissions. No liability is assumed
for incidental or consequential damages arising from the use of the information
or products contained herein. Features and specifications are subject to
change without notice.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: +886-2-8797-8377
Fax: +886-2-8797-8335
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV
series products are trademarks of GeoVision, Inc. Windows is the registered
trademark of Microsoft Corporation.
February 2023
Scan the following QR codes for product warranty and technical support
policy:
[Warranty] [Technical Support Policy]
i
Welcome to the GV-Mini System V2 User’s Manual.
The Manual provides an overview of the GV-Mini System V2 and its accessories. It
also includes the instructions to guide you through the installation and use of the
GV-Mini System V2:
•Chapter 1, Introduction
Identifies the accessories and options of the GV-Mini System V2.
•Chapter 2, Overview
Identifies the components of the GV-Mini System V2.
•Chapter 3, Getting Started
Provides step-by-step instructions on setting up the GV-Mini System V2.
•Chapter 4, Troubleshooting
Suggests courses of action if the GV-Mini System V2 doesn’t seem to be working
properly.
User’s Manual for GV-Mini System V2
ii
Contents
Safety Instructions .................................................................................................. iii
Chapter 1 Introduction........................................................................................... 1
1.1Packing List .................................................................................................1
1.2Options ........................................................................................................1
1.3 Supported Software.....................................................................................1
Chapter 2 Overview ............................................................................................... 2
2.1 Front View....................................................................................................2
2.2Rear View....................................................................................................3
Chapter 3 Getting Started...................................................................................... 4
3.1 Basic Installation..........................................................................................4
3.2Windows Setup Installation..........................................................................5
3.3System Restoration......................................................................................7
3.4Updating GV-Mini System V2 ......................................................................8
3.5 Installation of 2.5-inch HDD/SSD.................................................................9
Chapter 4 Troubleshooting ..................................................................................11
Appendix ……………………………………………………………………………….. 13
A. Frame Rate Limit for GV-NVR / VMS.............................................................13
B. Total Frame Rate and Max. No. of Channels Supported for GV-NVR / VMS.14
iii
Safety Instructions
Observe these safety instructions to help ensure against injury to yourself and damage
to the product.
⚫Read all safety and installation instructions before you operate the product.
⚫Do not operate the product in high humidity areas or expose it to water or moisture.
⚫Do not put the product in an unstable, a slanting or vibrated place.
⚫Do not block any ventilation opening.
⚫Do not install the product near any heat sources such as radiator, heat register or
other apparatus that produce heat.
⚫Operate the product using only the type of power source indicated on the marking label.
➢If you are in an area with unstable voltage, make sure to install an automatic voltage
regulator (AVR) or a UPS power supply with AVR function, to maintain a constant
voltage.
➢All damages to the power supply caused by unstable voltage are not included in the
2-year warranty service.
⚫Do not defeat the safety purpose of the grounding-type plug. Agrounding plug has
two blades and a third grounding prong. The third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
⚫Do not overload wall outlets or extension cords, as this may cause fire or electric
shock.
⚫Do not use the product when abnormality occurs, such as emitting smoke from the
product, smelling burning, being damaged by drop, invasion of foreign objects inside the
product, etc. Be always sure to remove the AC adaptor at once and contact your dealer.
⚫Do not use accessories or attachments not recommended by the manufacturer, as they
may cause hazards and void the warranty.
⚫Do not attempt to service the product yourself, as removing the casing may expose
you to dangerous voltage and void the warranty.
Introduction
1
1
Chapter 1 Introduction
1.1 Packing List
The GV-Mini System V2 package includes the following items. If any of the items are missing
or damaged, contact your dealer to arrange a replacement.
Important: Please keep the original carton and all packing materials for future shipping need.
1. GV-Mini System V2
2. 19V, 120W Power Adapter
3. Power Cord (by region)
4. Download Guide
1.2 Options
Optional devices can expand your system’s capabilities and versatility.
VESA Bracket
The bracket allows for mounting the unit on the rear of a computer monitor.
1.3 Supported Software
1. GV-NVR
2. GV-VMS
3. GV-ASManager
4. GV-AI FR Server
5. GV-AI Server
2
Chapter 2 Overview
2.1 Front View
4
5
1
2
3
6
7
Figure 2-1
No.
Name
No.
Name
1
Power Button
5
USB 3.2 Gen 2 x 2 (Type-C)
2
Power LED
6
USB 3.2 Gen 2 (Type-A)
3
HDD LED
7
Headphone/Headset
4
MIC-In
Overview
3
2
2.2 Rear View
3
1
8
2
5
7
4
9
10
6
Figure 2-2
No.
Name
No.
Name
1.
DC Jack (for 19V 120W Power Adapter)
6.
USB 2.0 Port
2.
VGA Port
7.
USB 3.2 Gen1 (Type-A)
3.
USB 3.2 Gen 2 Type-C Port (USB-C /
DisplayPort alt mode)
8.
Gigabit LAN port
4.
HDMI Port
9.
Key Lock (Anti-tampering)
5.
DisplayPort 1.4
10.
Kensington Lock (Anti-theft)
4
Chapter 3 Getting Started
3.1 Basic Installation
This section describes all the equipment required to program and operate the GV-Mini System
V2.
1
4
2
3
Figure 3-1
1. Using the supplied power cord, connect one end to the AC input and the other end to the
power outlet.
2. Using the VGA / DisplayPort / DisplayPort alt mode / HDMI cable supplied by the monitor
manufacturer, connect up to 4 monitors for simultaneous displays.
3. Connect the mouse and keyboard to the USB ports.
4. Using the RJ-45 cable, connect one end to the Ethernet port and the other end to Network.
Once the above hardware is properly connected, press the Power button on the front panel to
start the system. It takes about 1 minute for startup.
Getting Started
5
3
3.2Windows Setup Installation
The Windows setup is preparing your computer for first use.
1. After the Windows starts, this setup screen appears. Select your language and click Next
to continue.
Figure 3-2
2. Select your regional settings and time zone and click Next to continue.
Figure 3-3
6
3. ClickAccept to accept Microsoft software license terms.
4. Select between “Customize” and “Use Express settings” for your Windows 10 installation.
5. Type your account name. It is recommended that you create a password for your account
and click Next.
Figure 3-4
6. When the above setup process is complete, Windows will finalize your settings
automatically in the background and restart
IMPORTANT: In case of any problems causing you unable to access Windows operating
system, it is highly recommended to back up the OS before you start any settings or
operations. For details, see 3.3 System Restoration.
Getting Started
9
3
3.5 Installation of 2.5-inch HDD/SSD
1. Unscrew the four screws on the back panel. Pull out the motherboard tray.
Figure 3-7
2. Remove the motherboard by unscrewing the four screws of each corner.
3. Flip the motherboard over with the reverse side up. Place the HDD/SSD onto trays (A)
and (B).
Figure 3-8
4. Secure the HDD/SSD of tray A with the four screws.
Figure 3-9
10
5. Flip the motherboard right side up and secure the HDD/SSD of tray B in place.
Figure 3-10
6. Ensure the SATA Data and Power Cable is connected to the HDD/SSD.
Figure 3-11
7. Connect the ends of the SATA Cables to the SATA Connectors as shown in Figure 3-12.
Figure 3-12
Troubleshooting
11
4
Chapter 4 Troubleshooting
GV-Mini System V2 stops responding (aka “crashed” or “froze”)
1. Check if your mouse and keyboard are working properly.
If they cease functioning, following steps 2 and 3 to restart the system.
If they work, open the Task Manager (Ctrl+Alt+Del) and end the task of a
non-responding program.
2. Push the Power button for 10 to 20 seconds until the GV-Mini System V2 turns off.
3. Push the Power button again to turn the GV-Mini System V2 back on.
GV-Mini System V2 is unable to start.
If your GV-Mini System V2 is unable to start after you push the Power button, try these steps:
1. Remove the AC power adapter from the DC Jack.
2. Wait for 30 seconds before plugging the AC power adapter back in.
3. Push the Power button to see if the GV-Mini System V2 can start.
No screen image
If your GV-Mini System V2 is able to start properly but images cannot be displayed on the
connected monitor(s), try these steps:
1. Check if the blue power LED is lit.
Figure 4-1
2. Use a different monitor output and see if it works.
12
GV-Mini System V2 suffers virus attack.
GV-Mini System V2 is designed and optimized for Windows 10 platform. It may be vulnerable
to newly created worms and exploits that attack any of the underlying operating system’s
previously undocumented flaws. If your GV-Mini System V2 suffers virus attack, try rebuilding
the operating system and the software. Refer to 3.3 System Restoration.
How can I find more help?
1. Visit our website at http://www.geovision.com.tw/
2. Write us at [email protected].tw
Appendix
13
Appendix
A. Frame Rate Limit for GV-NVR / VMS
The total of recording frame rates that you can assign to a single hard disk for GV-NVR / VMS
recording is listed as below:
Frame Rate Limit in a Single Hard Disk
Video
resolution
H.264
H.265
Frame Rate (fps)
Bitrate (Mbit/s)
Frame Rate (fps)
Bitrate (Mbit/s)
1.3 MP
660
5.05
N/A
N/A
2 MP
660
7.01
N/A
N/A
3 MP
440
10.48
660
5.35
4 MP
330
11.65
550
7.74
5 MP
220
16.48
660
6.73
8 MP
550
14.13
N/A
N/A
12 MP
330
14.47
N/A
N/A
Note: The data for GV-NVR / VMS were obtained using the bit rate listed above and hard disks
with average R/W speed above 110 MB/s, with the model of Core i7 and 16 GB RAM.
14
B. Total Frame Rate and Max. No. of Channels Supported
for GV-NVR / VMS
For GV-IP Camera (Dual Streams)
GV-NVR
Video
Resolution
Dual-stream Resolution
Max. Frame
Rate / Camera
Channel
Total Frame
Rate / System
Stream 1 (H.264)
Stream (H.264)
1.3 MP
1280 x 1024
320 x 256
30 fps
32
960 fps
2 MP
1920 x 1080
448 x 252
30 fps
32
960 fps
3 MP
2048 x 1536
320 x 240
20 fps
32
640 fps
5 MP
2560 x 1920
320 x 240
10 fps
32
320 fps
8 MP
3840 x 2160
1280 x 720
25 fps
32
800 fps
12 MP
4000 x 3000
1024 x 768
15 fps
32
480 fps
Video
Resolution
Dual-stream Resolution
Max. Frame
Rate / Camera
Channel
Total Frame
Rate / System
Stream 1 (H.265)
Stream (H.264)
1 MP
1280 x 720
640 x 360
30 fps
32
960 fps
2 MP
1920 x 1080
640 x 360
30 fps
32
960 fps
3 MP
2048 x 1536
640 x 480
30 fps
32
960 fps
4 MP
2560 x 1440
640 x 360
25 fps
32
800 fps
5 MP
2592 x 1944
640 x 480
30 fps
32
960 fps
Appendix
15
GV-VMS
Video
Resolution
Dual-stream Resolution
Max. Frame
Rate / Camera
Channel
Total Frame
Rate / System
Stream 1 (H.264)
Stream (H.264)
1.3 MP
1280 x 1024
320 x 256
30 fps
64
1920 fps
2 MP
1920 x 1080
448 x 252
30 fps
64
1920 fps
3 MP
2048 x 1536
320 x 240
30 fps
64
1920 fps
5 MP
2560 x 1920
320 x 240
25 fps
64
1600 fps
8 MP
3840 x 2160
1280 x 720
25 fps
64
1600 fps
12 MP
4000 x 3000
1024 x 768
15 fps
64
960 fps
Video
Resolution
Dual-stream Resolution
Max. Frame
Rate / Camera
Channel
Total Frame
Rate / System
Stream 1 (H.265)
Stream (H.264)
1 MP
1280 x 720
640 x 360
30 fps
64
1920 fps
2 MP
1920 x 1080
640 x 360
30 fps
64
1920 fps
3 MP
2048 x 1536
640 x 480
30 fps
64
1920 fps
4 MP
2560 x 1440
640 x 360
25 fps
64
1600 fps
5 MP
2592 x 1944
640 x 480
30 fps
64
1920 fps
Table of contents
