GGM gastro EMP.PLS.US-1 User manual

1
AMERICAN GAS GRILL
Kasap Tip Dik Buzdolapları
CONTENTS
A GENERAL INFORMATION Page 2
A1 PRODUCT DESCRIPTION Page 3
A2 TECHNICAL INFORMATION Page 3
A3 TRANSPORTATION Page 3
A4 UNPACKING Page 4
B INSTALLATION Page 4
C SAFETY INSTRUCTIONS Page 5
D OPERATION Page 6
E CLEANING & MAINTENANCE Page 7
F TROUBLESHOOTING Page 8
G INJECTOR CHANGE AND GAS SETTING Page 9
H GAS CONNECTION IMAGES Page 10
I SPARE PART LIST- EXPLODING DRAWING Page 12

2
AMERICAN GAS GRILL
Kasap Tip Dik Buzdolapları
A GENERAL INFORMATION
Before installing the appliance, read operation and maintenance instructions
carefully.Wrong installation and part changing may damage the product or may cause
injury on people.These are not in our company’s responsibility to damage the
appliance intentionally,negligence,detriments because of disobeying instructions and
regulations,wrong connections.Unauthorized intervention to appliance invalidates the
warranty.
1. This instruction manual should be kept in a safe place for future reference.
2. Installation should be made in accordance with ordinances and security rules of
that country by a qualified service personnel.
3. This appliance has to be used by trained person.
4. Please turn off the appliance immediately in the event of malfunction or failure.The
appliance should be repaired only by authorized service personnel.Please demand
original spare part.

3
AMERICAN GAS GRILL
Kasap Tip Dik Buzdolapları
A1 PRODUCT DESCRIPTION
*This device, which provides high efficiency,is a professional gas grill designed for use in
restaurants, dining halls and public kitchens.
Product Code
Dimensions (mm)
Weight (kg)
Packaging
Dimensions (mm)
EMP.PLS.US-1
800X920X1100
55
850X950X1200
EMP.PLS.US-2
1160X920X1100
105
1200X950X1200
A2 TECHNICAL INFORMATION
Product Code
Model
Power (KW)
Gas Consumption
(LPG)
EMP.PLS.US-1
American Gas Grill
25
0,51 kg/h –0,91 m³/h
EMP.PLS.US-2
American Gas Grill
37
1,02 kg/h –1,82 m³/h
A3 TRANSPORTATION
*This appliance can not be moved by hand from area to area. Therefore Use a hauling truck
(forklift or pallet jack) to move the appliance. ( The lifting arms of the of forklift or pallet jack
must reach up to more than half part of t appliance underneath.

4
AMERICAN GAS GRILL
Kasap Tip Dik Buzdolapları
A4 UNPACKING
*Please unpack the package according to the security codes and ordinances of current
country and get rid from the pack.Parts which contacts with food are produced by stainless
steel.All plastic parts are marked by material’s symbol.
*Please check that all the parts of appliance had come completely and if they are damaged or
not during the shipping.
B INSTALLATION
*Please place the product to straight and sturdy ground,please take necessary steps against
possibility of overturn.
*Technician who will serve for installation and service for the appliance must be professional
on this subject and must have installation and service licenses by the company.
*Connection to Gas Fitment must be done by authorized person.
*The area where the appliance is must have enough ventilation and vent-hole.
*The appliance must be connected correctly according to local and national gas standards of
your country.
*The appliance gas entrances are indicated with ‘’G’’ label on the body.
*Connection to gas fitment must be done with suitable diameter metal flex pipe and spheric
valve.The spheric valve must be immobilized to a place that is far away from heat and
accessible during the danger.After gas entrance connection done,gas leakages must be
checked.
*According to the datas on appliance information plate,gas and pressure must be adjusted.If
the gas type that is adjusted is not the suitable with gas type that is at installation place,apply
the instructions that is about adjustment of different gas type. (Event :G)
* If the place where the professional grill is located is covered with non-combustible thermal
insulation material, the distance should be 5 cm Otherwise it should be at least 20 cm The
device must be operated under the hood.

5
AMERICAN GAS GRILL
Kasap Tip Dik Buzdolapları
C SAFETY INSTRUCTIONS
Do not use the appliance in insufficient lighted place.
*Do not touch the moving attachments while the appliance operates.
*Do not install the appliance in the presence of flammable or explosive materials.
*Do not operate the appliance when the machine is empty.
*Do not load so less or more than appliance’s capacity.
*Do not attempt to use the appliance without suitable protective equipments.
*Because of any reason if there is a fire or flame flare where the appliance is
used,turn off all gas valves and electric contactor switch quickly and use fire
extinguisher .Never use water to extinguish the fire.
*If there is a gas leak in the environment where the grill is located, do not burn a fire
or do not turn on the electricity.
* Definitely do not allow to check the sealing with flame.
* Before making the electrical connection of the device to be installed that are
connected amps cable cross-section of insurance to make sure correct insurance.
!

!
!
!
!
!
!
!
!

6
AMERICAN GAS GRILL
Kasap Tip Dik Buzdolapları
D OPERATION
*Control Panel; A: Half Flame
B: Full Flame
C : Lighter Position
D: Closed Position
E: Lighter
F : Maın TAP
For Gas Usege ;
It is because of the professional grill works with LPG and NG (natural gas), make the gas
inlet connection from the back of the appliance according to the usage pattern
Open the main gas valve.
When starting the device for the first time,for venting the air inside the gas line hold the
button in the pilot flame position for a while
Press the gas button lightly to bring the pilot into the flame position, press the ignition
button or fire with a suitable lighter
After the pilot has fired, press and hold the button for a few seconds (max. 10) to warm up
to the safety thermocouple tip.
Close the top cover of the device and preheat the burners to a certain degree in full
flame.
Remove the chimney lids on the top cover halfway open
For the desired temperature setting, adjust by turning the knob to half or full flame
position.
After the appliance has been sufficiently preheated, you can switch on the cooking
process with the top cover open or closed.
Place the meat to be cooked on the grill
Use a tong and other similar equipment to turn the meat during cooking..
After finishing cooking, remove and clean the grill.

7
AMERICAN GAS GRILL
Kasap Tip Dik Buzdolapları
E CLEANING & MAINTENANCE
CLEANING AND MAINTENANCE AFTER EVERY USE
Turn off the gas connection before cleaning.
Clean the outer surface of the appliance with moist cloth.
Do not use abrasive cleaning chemicals as these can leave harmful residues.
Do not wash the appliance with pressure water.
Do not clean the appliance with a materials that may damage chrome material.
After the cooking process, clean the BBQ grill with a spud.in order to stop collection
of corbonized food and reducing of cooking efficienty.
PERIODIC CLEANING AND MAINTENANCE
Maintenance should be done by qualified person.
These parts ; Gas storage,thermocouples,taps,burner,lighter and spark plug cable
are not maintained so they need to be changed when they have error.
Check the gas connection hoses in periodic time.If there is slit,hole..etc,change the
hoses.
Ventilate the area where the device is in periodic times.

8
AMERICAN GAS GRILL
Kasap Tip Dik Buzdolapları
F TROUBLESHOOTING
THE APPLIANCE DOESN’T OPERATE
1. Check if the gas connection is done or
not.
2. If there is no gas entrance to safety and
firing part,the appliance is not operated.
3. Check if the injector holes are opened or
not.
4. If the hoses that have gas entrance lose
gas due to slit,hole.etc.,the appliance is
not operated.
THE APPLIANCE DOESN’T COOK WELL
1. Check if it is operated at suitable gas
setting or not.
THE APPLIANCE STOPPED
1. Gas flow is stopped automatically when
the flame is off due to having gas tap
that has safety valve.In this situation the
appliance is not operated.
2. When there is gas leakage,if there is
solenoid gas stopper alarm,gas flow is
stopped and the appliance is not
operated.Ventilate the area through the
agency of vent-hole.
If cooking isn’t at the normal quality standarts
If any of safety functions are not stable or does not work
Do not run the device
*If these problems are still going on,contact with our authorized services.

9
AMERICAN GAS GRILL
Kasap Tip Dik Buzdolapları
G INJECTOR CHANGE AND GAS SETTING
Gas
Family
Gas
EMP.PLS.US-1
EMP.PLS.US-2
Injector mm
Injector mm
2
G20
Ø1,50 x 6
Ø1,50 x 9
G25
Ø1,50 x 6
Ø1,50 x 9
3
G30
30 mbar
Ø1,0 x 6
Ø1,0 x 9
50 mbar
Ø1,0 x 6
Ø1,0 x 9
G31
37 mbar
Ø1,0 x 6
Ø1,0 x 9
30 mbar
Ø1,0 x 6
Ø1,0 x 9
Change of Burner Injector;
1. Rip off the injector at the entrance of burner with suitable equipment
2. Change "A" injector by paying attention to the datas at chart with suitable injector.
( Image 1)
3. Set the burner air entrance "F" setting by loosening "B" bolt and moving venturi pipe
forward-back. (Image 2)
4. Change "C" injector by paying attention to the datas at chart with suitable injector.For
this it is enough to take off "D" fitting and pull the gas pipe to down. (Image 3)
Setting of Half Flame;
1. Remove the tap button and set by turning tap half flame screw "K" with suitable
screwdriver.(Image 4) Turn it to left for transformation from LPG to NG,turn it right for
transformation from NG to LPG.
2. After this process,operate the appliance and set it not to be deflated during transition
from full flame to half flame.

10
AMERICAN GAS GRILL
Kasap Tip Dik Buzdolapları
H GAS CONNECTION IMAGES
Image-2
Image-1

11
AMERICAN GAS GRILL
Kasap Tip Dik Buzdolapları
H GAS CONNECTION IMAGES
Image 3
E : Thermocouple
F: Lighter
Image-4

12
AMERICAN GAS GRILL
Kasap Tip Dik Buzdolapları
I SPARE PART LIST-EXPLODING DRAWING
EMP.PLS.US-01

13
AMERICAN GAS GRILL
Kasap Tip Dik Buzdolapları
I SPARE PART LIST- EXPLODING DRAWING
PRODUCT CODE :EMP.PLS.US-01
NO
PRODUCT NAME
PRODUCT CODE
1
TOP GRILL
Y.EMP.PLS.US-1.001
2
BURNER TOP CASTING
Y.EMP.PLS.US-1.002
3
BURNER
Y.EMP.PLS.US-1.003
4
GAS PIPE
Y.EMP.PLS.US-1.004
5
SPIRAL HOSE
Y.EMP.PLS.US-1.005
6
1/2 TAIL ELBOW YELLOW
Y.EMP.PLS.US-1.006
7
1/2 YELLOW ELBOW
Y.EMP.PLS.US-1.007
8
GAS VALVE
Y.EMP.PLS.US-1.008
9
THERMO ELEMENT
Y.EMP.PLS.US-1.009
10
PILOT
Y.EMP.PLS.US-1.010
11
INJECTOR
Y.EMP.PLS.US-1.011
12
PAN SHEET - 1
Y.EMP.PLS.US-1.012
13
PAN SHEET - 2
Y.EMP.PLS.US-1.013
14
PAN SHEET - 3
Y.EMP.PLS.US-1.014
15
BUTTON
Y.EMP.PLS.US-1.015
16
GAS TAP
Y.EMP.PLS.US-1.016
17
GAS TANK
Y.EMP.PLS.US-1.017
18
CHASSIS
Y.EMP.PLS.US-1.018

14
AMERICAN GAS GRILL
Kasap Tip Dik Buzdolapları
I SPARE PART LIST-EXPLODING DRAWING
EMP.PLS.US-02

15
AMERICAN GAS GRILL
Kasap Tip Dik Buzdolapları
I SPARE PART LIST-EXPLODING DRAWING
PRODUCT CODE : EMP.PLS.US-02
NO
PRODUCT NAME
PRODUCT CODE
1
TOP GRILL
Y.EMP.PLS.US-2.001
2
BURNER TOP CASTING
Y.EMP.PLS.US-2.002
3
BURNER
Y.EMP.PLS.US-2.003
4
GAS PIPE
Y.EMP.PLS.US-2.004
5
SPIRAL HOSE
Y.EMP.PLS.US-2.005
6
1/2 YELLOW ELBOW
Y.EMP.PLS.US-2.006
7
1/2 TAIL ELBOW YELLOW
Y.EMP.PLS.US-2.007
8
GAS VALVE
Y.EMP.PLS.US-2.008
9
THERMO ELEMENT
Y.EMP.PLS.US-2.009
10
PILOT
Y.EMP.PLS.US-2.010
11
INJECTOR
Y.EMP.PLS.US-2.011
12
PAN SHEET - 1
Y.EMP.PLS.US-2.012
13
PAN SHEET - 2
Y.EMP.PLS.US-2.013
14
PAN SHEET - 3
Y.EMP.PLS.US-2.014
15
PAN SHEET - 4
Y.EMP.PLS.US-2.015
16
BUTTON
Y.EMP.PLS.US-2.016
17
GAS TAP
Y.EMP.PLS.US-2.017
18
GAS TANK
Y.EMP.PLS.US-2.018
19
CHASSIS
Y.EMP.PLS.US-2.019
