Grand Royale HGI08ALP-1 User manual

Manual#P80180001D-Date:2013/02/27
Ÿ
Ÿ
NOTETOASSEMBLER/INSTALLER:
Leavethismanualwiththe consumer.
NOTETO CONSUMER:
Keepthismanualforfuturereference.
RECORDYOURSERIAL# __________________
(see silverCSAlabelonmain bodyofgrill)
IMPORTANT:
Ÿ
OPERATOR'SMANUAL
FREEHELP
FROMTHEGRILLEXPERTS
Donotreturntothestore. AtGrand Hall we're
theexpertson thisproduct andtrained tohelp
youwith:
Assemblyquestions
Grill operation
Replacementofdamagedormissingparts
Ÿ
Ÿ
Ÿ
visit www.grandhall.com orcall:
1-877-934-7455
Monday-Friday8:00am-4:30pmCST
WARNING
! !
Failuretocomplywiththeseinstructionscould
resultinafireorexplosionthatcouldcause
seriousbodilyinjury,deathorpropertydamage.
Whetherthisgrill wasassembled byyouor
someone else,you mustread thisentiremanual
beforeusing yourgrilltoensurethe grillis
properlyassembled,installed andmaintained.
Use yourgrill atleast3feetaway fromany
wall orsurface. Useyourgrill atleast 3feet
away fromcombustibleobjectsthatcan meltor
catchfiresuchasvinylorwood siding,fences
and overhangsorsourcesof ignition including
pilotlightson waterheatersand liveelectrical
appliances.
THISGASAPPLIANCEISDESIGNEDFOROUT-
DOORUSE ONLY.
Never useyourgasgrillinagarage,porch,
shed,breezewayoranyotherenclosedarea.
Never obstructtheflowofventilation air
around yourgasgrill housing.
Never disconnectthe gasregulatororanygas
fitting while yourgrillislit.Alitgrill canignite
leakinggasand causeafireorexplosionwhich
couldresultinpropertydamage,personal injury
ordeath.
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
LiquidPropane Gas(LPG)Grill Island
Model HGI08ALP-1
NaturalGas(NG)Grill Island
Model HGI08ANG-1

TableofContents
PrimarySafetyWarnings...........................1-3
Pre-AssemblyInstructions..............................3
PartDiagramsandLists..........................4-8
AssemblyInstructions...............................9-10
Use&CareInstructions:
•GasSafetyand LeakTests............11-13
•NaturalGasConnection..........................14
•LightingInstructions............................15-16
•Troubleshooting.........................................16
•Rotisserie Instruction...........................17-19
•CleaningandMaintenance................20-21
•CookingGuide...................................A1-A5
•FrequentlyAsked Questions............A6-A7
WarrantyTerms............................BackCover
2
DANGER
!!
1.
2.
3.
4.
Ifyousmell gas:
Shutoff gas totheappliance.
Extinguishanyopenflame.
Openlid.
Ifodorcontinues,keepawayfrom
theappliance andimmediatelycall
yourgas supplieroryourfire
department.
WARNING
! !
WARNING
! !
Thisappliance,when installed,mustbe electri-
callygrounded inaccordancewithlocalcodes
or,inthe absenceoflocalcodes,withthe
National Electrical Code,ANSI/NFPA 70, orthe
Canadian Electrical Code,CSA C22.1.
Keep anyelectricalsupplycordand the fuel
supplyhoseawayfromanyheated surfaces.
•
•
WARNING
! !
Donotstoreoruse gasolineorother
flammableliquidsorvaporsinthevi-
cinityofthisoranyotherappliances.
AnLPcylindernotconnectedforuse
shall notbestoredinthevicinityof
thisoranyotherappliance.
1.
2.
•
•
•
•LPGmodelsmustbeusedwithLiquidPropane
Gasandtheregulatorassemblysupplied.
NaturalGas modelsmustbeusedwithNatural
Gasonly.Anyattempttoconvertthegrillfrom
onefueltypetoanotherisextremelyhazardous
andwill voidthewarranty.
Keepgas regulatorhose awayfromhotgrill
surfaces and dripping grease.Avoidunneces-
sarytwisting ofhose.Visuallyinspecthose prior
toeach use forcuts,cracks,excessivewearor
otherdamage.Ifthehose appearsdamageddo
notuse thegas grill.Call Grand Hall at1-877-
934-7455foracertifiedreplacementhose.
CaliforniaProposition 65
Combustion byproductsproducedwhenusing
thisproductcontainchemicalsknowntothe State
ofCaliforniatocausecancer,birthdefects,orother
reproductiveharm.
Brass componentson thegrill,such as hose
fittings,propanecylindervalves(soldseparately)
andburnervalvestems,containleadwhichis
knowntotheStateofCaliforniatocausecancer,
birthdefects,orotherreproductiveharm.
Neveruse charcoal or lighter fluidinthisgas grill.
Failuretocomplywiththeseinstructionscould
resultinagrease fireor explosion thatcouldcause
seriousbodilyinjury,deathorpropertydamage.
TheGreaseTraymustbe visuallyinspectedbe-
foreeachgrilluse.Removeanygreaseandwash
GreaseTraywithamildsoap and warmwater
solution. Failuretocomplywiththeseinstruc-
tions couldresult inagreasefireorexplosion
thatcouldcauseseriousbodilyinjury,deathor
propertydamage.
•

Pre-AssemblyInstructionsForYourSafety
Spidersand small insectscanspinwebsand nest
inthegrill BurnerTubes during transitand ware-
housing which canleadtoagas flowobstruction
resulting inafireinand around theBurnerTubes.
Thistypeof"FLASHBACK FIRE"cancause serious
grill damageand createanunsafeoperating con-
dition fortheuser.
Toreduce thechance ofFLASHBACK FIRE
you mustcleantheBurner Tubes as follows
before initialuse. Alsodo thisatleastoncea
monthinsummerand fall orwheneverspidersare
activeinyourarea,and ifyourgrill has notbeen
usedforanextendedperiod oftime.
WARNING
! !
Failuretocomplywiththeseinstructionsmay
resultinahazardoussituationwhich,ifnot
avoided,mayresultininjury.
Forsafeoperation ensuretheGas ValveAssembly
OrificeisinsidetheBurnerTubebeforeusing your
grill.See figure.IftheOrificeisnotinsidethe
BurnerTube,lighting theBurnermaycause explo-
sion and/orfireresulting inseriousbodilyinjury
and/orpropertydamage.
METHOD 1:Bend astiff wireorwirecoat
hangerintoasmall hook as shownand run
thehook through theBurnerTubeand inside
theBurnerseveraltimes toremovedebris.
METHOD 2:Use abottlebrushwithaflexible
handleand run thebrushthrough theBurner
Tubeand insidetheBurnerseveraltimes to
removeanydebris.
METHOD 3:Use anairhose toforceairthrough
each BurnerTube.Theforcedairshouldpass
debrisorobstructionsthrough theBurnerand
outthePorts.
TOCLEAN BURNERTUBE,
INSERTHOOK
HERE
BurnerTube
9
Orifice BurnerTubeGasValveAssembly
CarefullylifteachBurnerupandawayfromtheGas
ValveOrifice.
Check andcleanBurner/VenturiTubesforinsects
andinsectnests.Aclogged tube canleadtoafire
beneaththegrill.
Refertothefigurebelowand performoneof
these 3cleaning methods:
Remove thescrewsfromtherearofeachMain
BurnerusingaPhillipsHeadScrewdriver.
1.
2.
3.
4.
3
BurnerPort Foot
Toexpeditethe assemblyprocess followthese
generalguidelines:
GrillInformationCenter 1-877-934-7455
8am-4:30pmCST,MondaythroughFriday
Grill Installation Codes
Theinstallationmustconformwithlocalcodes or,inthe
absenceoflocalcodes,withthe NationalFuelGas Code,
ANSIZ223.1/NFPA54,Storage and Handling ofLique-
fiedPetroleumGases,ANSI/NFPA58,NaturalGasand
Propane InstallationCode,CSA B149.1, Propane Stor-
age and Handling Code,B149.2.
PhillipsHeadScrewdriver
ToolsRequiredforAssembly :
protectiveworkgloves
Whileit ispossibleforone person tounpack thisgas
grill,obtainassistancefromanotherperson when
handling thelargepieces.
Usethe Hardwareand Part Diagramstoensureall
itemsareincludedand freeofdamage.
Donotassembleoroperatethegrill ifitappearsdam-
aged.Iftherearedamagedormissing partswhen
youunpacktheshippingboxoryouhavequestions
duringtheassemblyprocess,callthe:
•
•
1.
WARNING
! !
DonotstorespareLPcylinderwithin
10 feet(3m)ofthisappliance.
Donotstoreoruse gasolineorother
flammableliquidsandvaporswithin25
feet(8m)ofthisappliance.
Whencookingwithoil/grease,do not
allowtheoil/grease togethotter350°F
(177°C)
Donotleaveoil/grease unattended.
4.
2.
3.
CAUTION !
Whenusing electricalappliances,basic
safetyprecautionsshould always beused.
!

*TwoBatteries/AA includedintheHardwarePack.
HardwarePack PartsList forModelHGI08ALP-1 &HGI08ANG-1
PhillipsHeadScrew1/4"x3/8"
Qty.4
Part#S112G0406E
Wrench
Qty.1
Part#P05515017L
Alreadypackedin theCooking ComponentsBox
Wing Bolt1/4"x1/2"
Qty.2
Part#S233G04084
Hardware alreadyinstalledon theTankHolder
4
PART# PARTDESCRIPTION QTY PURPOSEOFPART
P06016003A HardwarePack 1 Foruseinassembly(Gril)
S112G0406E PhillipsHead Screw1/4"x3/8" 4 InstallCartFrametoGrillLeftCartLegs
S233G04084 Wing Bolt1/4"x1/2" 2 SecuresGasTanktoTankHolder
P05515017L Wrench 1 AdjustlevelonIsland AssemblySet
AlreadyInstalledon TankHolder
AlreadypackedintheCooking ComponentsBox
HardwarePack DiagramforModelHGI08ALP-1 &HGI08ANG-1

PartsDiagramforModelHGI08ALP-1 &HGI08ANG-1 Grill
5
82
65
64
66
67
75
53
76
55
77
58
79
78
1
2
3
4
5
6
9
7
8
13
15
18
25
26
24
27
28
29
30
31
34
49
57
56
43
47
54
52
50
51
41
46
45
48
42
39
37
36
35
22
17
16
14
12
11
23
71
44
49
60
10
38
72
59
69
61 62
40
40
74
73
33
70
68
19
21 20
32
18a
63
52a
52b

PartsList forModelHGI08ALP-1 &HGI08ANG-1 Grill
6
KEY DESCRIPTION PART# QTY
1LidAssembly P001474134 1
2TemperatureGauge P00601297A 1
3LidHandle P00205069M 1
4ProtectivePad P05518011I 2
5Cooking Rack/Secondary P01516004J 1
6Cooking Grid13" P01604013B 2
7Cooking Grid6.5" P01604031B 1
8Burner P020080324 3
9InfraredBurnerAssembly P020050104 1
10 Thermocouple P05305019A 1
11 SavorPlate®P017080074 3
12 BurnerBracket P0220342DD 1
13 RotisserieBurnerAssembly P02007068A 1
14 RotisserieBurnerWind Shield P06906046B 1
15 RotisserieBurnerElectrode P02614025A 1
RotisserieBurnerOrifice(LPG) P06534005A 1
RotisserieBurnerOrifice(NG) P06534009A 1
17 RotisserieBurnerExtension Tube P03717045B 1
18 Bowl P0071334P4 1
18a BowlWind Shield P069060754 1
19 ThermocoupleBracket P03343008C 1
20 Cart PanelBracketA P03327038C 1
21 Cart PanelBracketB P03327039C 1
22 BurnerHeat ShieldP07523003P 1
23 GreaseTrayHeatShield P069040204 1
GasValve/ManifoldAssembly/Grill(LPG) Y0060412 1
GasValve/ManifoldAssembly/Grill(NG) Y0060663 1
25 ElectricWireSet P02615103A 1
26 GasCollector BoxwithElectrode P02609010B 3
27 ControlPanelExtension P0290976HS 1
28 ControlPanel,Upper/Grill P0290977FS 1
29 ControlPanel/Grill P0290978FA 1
30 ControlKnob P03411503L 3
31 ControlKnob For BackBurner/InfraredBurner P03411513L 2
32 ControlKnob Spring P05504021A 5
33 Cart Frame, Left/Grill P01303016B 1
34 ControlKnob Seat P03415014S 5
35 LightingStickAssembly P05507008A 1
36 RegulatorwithHose(LPG) P03601004A 1
37 GreaseTray/Grill P02717454A 1
38 BowlSupport Bracket,Left P01301007K 1
39 Cart Panel,Top P07801027A 1
40 Cart Panel,Lower/Left&Middle P07604016B 2
41 Cart Panel,Right P07620001D 1
42 Cart Frame, Right/Grill P03344007D 1
43 Cart Panel,Front/Grill P07621004D 1
44 Cart FrameforFrontPanel/Grill P03344003D 1
45 Cart Panel,Rear/Left/Grill P07702082M 1
46 Cart Panel,Rear/Right/Grill P07702083M 1
47 Cart Frame, Front/Grill P00907003C 1
48 Cart Frame, Rear/Grill P00907004C 1
49 DrawerSlide Set P05516012C 1
50 Door P04301030J 1
24
16

PartsList forModelHGI08ALP-1 &HGI08ANG-1 Grill
7
Important: Use onlyGrand Hall certifiedreplacementparts. Theuse ofanypart thatisnotafactory
authorizedpart canbedangerousand will alsovoidyourproductwarranty.KeepthisOperator'sManual
forconvenientreferraland forpart replacement.
ToOrderGrand Hall CertifiedReplacementParts,Call 1-877-934-7455
To obtainthecorrectreplacementpartsforyourgrill,please refertothepart numbersinthispartslist.
Thefollowing information isrequiredtoensureyou receivethecorrectparts:
1.Modeland SerialNumber(see CSA labelon grill)
2.Part Number
3.Part Description
4.Quantityofpartsneeded
KEY DESCRIPTION PART# QTY
51 Door Handle P00215031A 1
52 TankTray(LPG) P04009030B 1
52a Cart Basket Bottom(NG) P01001053D 1
52b Cart Basket (NG) P05203007G 1
53 Slide Set P05516013C 1
54 Slide Bracket A P03311011D 2
55 HoseHolder(LPG) P055360014 1
56 Drawer P01901008I 1
57 DrawerHandle P00215032A 1
58 ProtectiveCap A P05535008I 1
59 NamePlate P00407031T 1
60 LevelAdjuster P05322004A 4
61 Door Bracket, Left P033020274 1
62 Door Bracket, Right P033020284 1
63 ElectricWire/Grill P02616011D 1
64 SavorPlateBracket, Front P033280504 3
65 SavorPlateBracket, Rear P033280514 3
66 BackBurner Thermocouple P05305022A 1
67 BackBurner ThermocoupleBracket P033280474 1
68 GreaseDraining Plate P069020094 2
69 ElectricIgnitor, 6-port P02502075C 1
70 ElectricIgnitor Protector P05545002A 1
71 GreaseTrayHandle/Grill P00213012M 1
72 BowlSupport Bracket,Right P01302007K 1
73 Cart Panel,Upper/Left P01304009D 1
74 Cart Panel,Upper/Middle P01305009D 1
75 TankHolder (LPG) P05358002Y 1
76 GreaseTrayHeatShield, Lower P06903050M 1
77 Door TrimPanel P07510023H 1
78 LBracket,Left P033020314 1
79 LBracket,Right P033020324 1
80 NGRegulator Y0080023 1
81 Hose,12FT/NG P03703001A 1
82 InfraredBurnerElectrode P02614057A 1
Cover/Grill P07002064B 1
Cover/Range P07002065B 1
RotisserieAssembly Y0250152 1
HardwarePack P06016003A 1
Operator'sManual/Grill P80180001D 1

GrillInformationCenter:Ifyouhavequestionsaboutassemblyorgrilloperation,oriftherearedamaged
ormissingpartswhenyouunpackthisunitfromtheshippingbox,callus8:00am-4:30pmCST,Monday
throughFridayat:1-877-934-7455
Y0250152 RotisserieAssemblyPartsDiagram
Y0250152 RotisserieAssemblyPartsList
HardwareforRotisserie
Rot. Screw#10-24x3/4"
UNC
Qty.2
Part #S112G10124
Rot. Thumbscrew
1/4"x1/2"
Qty.3
Part #S196G04084
Rot.Washer
Qty.2
Part #S411G03084
Rot. Nut.#10-24
Qty.2
Part #S362G10124
KEY PART#
DESCRIPTION QTY
Rot.Bushing
Rot. Thumbscrew1/4"x1/2"
Rot.Collar
Rot. Spit
Rot. Holding Fork
Rot. MotorBracket
Rot.Motor/AC
Rot. Screw#10-24x3/4"UNC
Rot. Washer
Rot. Nut#10-24
1.
2.
3.
4.
5.
6.
7.
8.
9.
1
3
1
1
2
1
1
2
2
2
P05508092F
S196G04084
P05508091F
P05508175F
P05508090F
P05508174F
P07101048A
S112G10124
S411G03084
S362G10124
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
7
8
9
3
10
6
2
2
5
4
1
2
8

AssemblyInstructions
Install CartFrame
9
Install IgnitorBattery
UnscrewIgnitorCapfromControlPanel.
PlacesuppliedAA batteryintotheIgnitorSlot
withpositivepolefacing you.
Position theCapand Spring overtheAA
batteryand tightenontoControlPanel.
3
Spring
IgnitorCap IgnitorSlot
AA Battery
Besureall ControlKnobsaresetto"OFF"
and opentheGrill Lid.
Haveyourassistantstand behind tothe
rightofthegrill and look towardthefrontof
thegrill bowl. Never putyourfaceinsidethe
Grill Head.
Press theIgnitorCap.You shouldheara
"clicking"sound.Yourassistantshouldsee
abluesparkwithineach Gas CollectorBox.
IfasparkispresenttheElectrodeTipsare
properlypositioned.
Ifno sparkisseen,theSparkGapneeds
tobeadjustedas follows:
Withtheassistance ofanother person,
perform thisElectrodeCheck before
proceeding.
Thistestwillensurethatthe SparkElectrode Tips
areproperlypositionedsoyourgrilllightseasily
andproperly.
4
SparkElectrodeTip
SparkReceiver
SparkGap
GasCollectorBox
•
•
IfthegapbetweentheSparkElectrode
Tipand Receiverismorethan3/16"wide
use long nose plierstogentlysqueeze
theGas CollectorBoxtonarrowgap.
Recheck theElectrodeagain, if no "clicking"
sound isheard:
AA Batterymaybeinstalledbackwards.
Electricwires maybeloose.Remove
theAABatteryandinspecttheIgnitor
JunctionBoxfound behindtheControl
Paneland reconnectanyloose wires.
-
-
PhillipsHeadScrew
1/4"x3/8"
Qty.4
Part#S112G0406E
Align the4holes intheCart Frameand the
Cart Frame,Left/Grill.Insert the4Phillips
HeadScrews1/4"x3/8"and tightensecurely.
1
ConnecttheSwivelnutofthe12'NaturalGas
Hose totheInletfitting ofNG Regulatoras
shown.Connecttheotherend ofthehose
tothegas supplyline.
Connectthe12'NaturalGasHose
2
12' NaturalGasHose
NGHose
GasInlet
InletFitting
Swivel Nut
KeeptheventilationopeningsoftheTank
Traycabinetfree and clearofdebris.
Useyourgrill atleast 3feetaway from
anywall orsurface.
Donotobstructthe flowofairforcombustion
andventilation.
CAUTION
! !
CAUTION
! !

10
6AdjusttheGrill (On UnevenSurface Only)Install Cooking Components
PlacetheSavorPlates®abovethe Burners.
Place theCookingGridsontheledge
abovetheSavorPlates®.
PlacetheSecondaryCooking Rack intothe
holes on theupperleft and rightoftheBack
Burnerframewiththebottomresting inthe
slotson eithersideof
theGrill Bowl.
5
SecondaryCooking Rack
SavorPlates®
Cooking Grids
WARNING !
FailuretoreadandfollowtheUseand Care
Instructionscouldresultinafireorexplosion that
couldcauseseriousbodilyinjury,deathorprop-
ertydamage.
!
UndersideviewofGrill
Wrench
LevelAdjuster
Wrench
Qty.1
Part#P05515017L
LevelAdjustersarelocatedontheunderside
oftheGrillasshownbelow.
Adjustthe4preassembled LevelAdjusters
usingthe wrenchprovided.
-Turntheadjustersclockwisetoraisethe
heightofthe Grill.
-Turntheadjusterscounterclockwisetolower
the heightofthe Grill.
Important:Forillustrationpurposes,theGrill
isshownatatilted angle.FORYOURSAFETY
DONOTTILTyourGrillatanytime.
FinalGrill AssemblyStep
Whenyou have finishedassembling yourgrill
besure thatall screwsare tightenedforsafe
operation ofyourgrill.

11
USE AND CAREINSTRUCTIONS
CORRECTLPGASTANK USE
LPGasgrill modelsaredesignedforuse witha
standard20lb.LiquidPropane Gas(LPGas)tank(sold
separately). Never connectyourgasgrilltoanLPGas
tankthatexceeds thiscapacity.Atankofapproximately
12inchesindiameterby18-1/2incheshighisthe
maximumsizeLPGastanktouse. Youmustusean
"OPD"gastankwhichoffersalistedOverfill Preven-
tionDevice. Thissafetyfeaturepreventstankfrombeing
overfilled whichcancauseamalfunctionofthe LPGas
tank.
Never connectan unregulated LPgastanktoyourgas
grill. Thegasregulatorassemblysupplied withyourgas
grillisadjustedtohavean outletpressureof11"water
column(W.C.)forconnectiontoan LPgastank.Only
usethe regulatorandhoseassemblysupplied withyour
gasgrill. Replacementregulatorsandhoseassem-
bliesmustbethosespecifiedbytheManufacturer.
Have yourLPGasdealercheckthereleasevalve after
everyfillingtoensureitremains freeofdefects.
Always keepLPGastankinuprightposition.
DonotsubjecttheLPGastanktoexcessive heat.
Neverstorean LPGastankindoors.Ifyoustoreyour
gasgrillinthe garage always disconnectthe LPGas
tankfirstandstoreit safelyoutside.
LPGastanksmustbestored outdoorsinawell-
ventilated areaandoutofthe reachofchildren.
Disconnected LPGastanks mustnotbestoredina
building,garageoranyotherenclosed area.
The regulatorandhose assemblycanbe seenby
openingthe cartdoors.Theymustbe inspectedbefore
eachuseofthe grill. Ifthe hoseisdamaged inanyway,
it mustbereplacedpriortousingthe grillagain.
Never lightyourgasgrillwiththe lidclosed orbefore
checkingtoensuretheburnertubesarefullyseatedover
thegasvalve orifices.
The LPGastankmustbe constructed andmarkedin
accordancewiththe Specifications forLP-GasCylinders
oftheU.S.DepartmentofTransportation(D.O.T.)orthe
NationalStandardofCanada,CAN/CSA-B339,Cylin-
ders,SpheresandTubesforTransportationofDanger-
ous Goods;andCommission,asapplicable.
The LPGastankmusthave ashutoffvalve,terminating
inanLPGassupplytankvalveoutlet,thatiscompatible
withaType 1tankconnectiondevice.TheLPGastank
mustalsohave asafetyreliefdevicethathasadirect
connectionwiththe vaporspace ofthetank.
The tanksupplysystemmustbe arranged forvapor
withdrawal.
The LPGastankmusthave acollartoprotectthe tank
valve.
Useofalcohol,prescriptionornon-prescription
drugscanimpairyourabilitytoproperlyassemble
and safelyoperateyourgrill.
Keepfireextinguisherreadilyaccessible.Inthe
eventofaoil/grease fire,do notattempttoextin-
guishwithwater. Use typeBextinguisherorsmother
withdirt, sand orbaking soda.
Intheeventofrain,turnoff theburnersand thegas
supply,and thencoverthegrill.
Use yourgrill on alevel,stablesurfaceinanarea
clearofcombustiblematerials.
Donotleavegrill unattendedwheninuse.
Donotmovetheappliancewheninuse.
Allowthegrill tocoolbeforemoving orstoring.
Donotuse yourgrill as aheater.
Thisgrill isnotintendedtobeinstalledinoron
recreationalvehicles and/orboats.
Thegrill isnotintendedforcommercialuse.
Neveruse charcoalorlighterfluidinthisgrill.
!
DonotstoreaspareLP-Gastank underornear
thisappliance.
Neverfillthetankbeyond80percentfull; and
Ifthe information in"(a)"and"(b)"isnotfollowed
exactly,afirecausingdeathorseriousinjurymay
occur.
A.
B.
C.
!
WARNING !
WARNING !
WIND
DIRECTION
3ft. 3ft.
Neverallowchildrentooperateyourgrill.Donotallow
children orpetstoplay nearyourgrill.Always supervise
children andpetsiftheyareinthe vicinityoftheunit.
•
•
•
•
Use yourgrill atleast3feetawayfromanywall or
surface.
Use yourgrill 3feetawayfromanycombustible
objectsthatcanmeltorcatch firesuch as vinylor
wood siding,fences,overhangs(See DiagramBe-
low), oranyothersources ofignition;including pilot
lightsandliveelectricalappliances.
Donotuse yourgrill underanyoverheadcombus-
tibleconstruction.
Neveruse yourgas grill inagarage,porch,shed,
breezeway,oranyotherenclosedarea.
Inwindyconditions,alwaysposition thefrontofthe
grill tofaceoncoming wind toreduceheatand
smokeblowing inyourface,and topreventpotential
hazardstoyourselfand thegrill.
•

12
USE AND CAREINSTRUCTIONS
Brushsoapysolution ontoLPGastank intheareas
indicated bythearrows.See diagram.
If growingbubblesappeardo notuseormove the
LPGastank.CallanLPGasSupplieroryourFire
Department.
NOTEaboutLPGas TankExchangePrograms
Manyretailersthatsellgrillsofferyouthe optionofre-
placingyouremptyLPGastankthroughanexchange
service.Use onlythosereputableexchange companies
thatinspect, precision fill,testand certifytheirtanks.Ex-
changeyour tank onlyfor anOPD safetyfeature-equipped
tankas described intheLPGas tanksection ofthis
manual.
Ÿ
How toLeak TestyourLPGas Tank
Use acleanpaintbrushand a50/50 mildsoapand
watersolution.
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Foryoursafety:
Leaktestnewand exchangedLPGas tanksBEFORE
connecting onetoyourgrill.
Alwayskeep newand exchangedLPGas tanksinan
uprightpositionduringuse,transitorstorage.
Ifgrowingbubbles appeardo notuseormovethe
LPGastank.Contactan LPGas Supplieroryour
firedepartment!
WARNING
!!
LPGas Modelonly:
Secure a20lb LPGas TanktoGas Grill
Slide open theTankTraydoors(asshown).
TurnyourLPGas Tank Valveclockwise totheclosed
orOFF positon.
UnscrewtheWing Boltfromrightbracketoftank holder.
PlaceLPGas tank intotank holderon theTank Tray.
Install thetank sotheTank Valvefaces therearright
cornerofcabinet.
Insert theWing Boltintorightbracketoftank holderto
securethegas tank.
Attach theRegulatorwithHose tothegas tank.
Pushthe TankTray doorclosed.
52.36"
27.15"
35"
Note:
All measurementsareininches
Wing Bolt1/4"x1/2"
Qty.1
Part# S233G04084
Gas Tank Installation
Tanktray
Tank
Holder
Allleaktestsmustberepeated each timeyourLPGas
tankisexchangedorrefilled.
Whencheckingforgas leaksdonotsmoke.
Donotusean openflametocheckforgas leaks.
Yourgrillmustbeleak tested outdoorsinawell-venti-
latedarea,away fromignitionsourcessuchas gasfired
orelectricalappliances.Duringtheleaktest, keepyour
grillawayfromopenflames orsparks.
Donotusehouseholdcleaningagents.Damagetogas
assemblycomponentscanresult.
Ÿ
Ÿ

13
USE AND CAREINSTRUCTIONS
LPGasModelonly:
ConnectRegulatorwithHosetoyourLPGTank
Turnall BurnerValves totheOFF position.
Inspectthevalveconnection port and regulatoras-
semblyfordamageordebris.Removeanydebris.
Neveruse damagedorpluggedequipment.
Connecttheregulatorassemblytothetank valveand
HAND TIGHTENnutclockwise toafull stop.DO NOT
use awrench totightenbecause itcoulddamage
theQuick Coupling Nutand resultinagas leak/fire
hazard.
Openthetank valve1/4to1/2ofafull turn(coun-
terclockwise)and useasoapywatersolutionto
check all connectionsforleaksbeforeattempting to
lightyourgrill.See "Check All ConnectionsforLP
Gas Leaks".Ifaleakisfound,turnthetank valve
off and do notuse yourgrill until theleakisrepaired.
Quick
Coupling Nut
CAUTION: Whentheapplianceisnotinuse thegas must
beturnedoff atthetank.Placedustcapon cylindervalve
outletwheneverthecylinderisnotinuse.Onlyinstall
thetypeofdustcapon thecylindervalveoutletthatis
providedwiththecylindervalve.Othertypes ofcapsor
plugsmayresultinleakageofpropane.
Type1connectionper
ANSIZ21.58-2007/CSA
1.6-2007
Checkall connectionsforLPGasLeaks
Grill
Disconnecting ALiquid PropaneGas (LPG)
TankFromYourGrill
MakesuretheBurnerValves and LPGas tank valve
areoff. (Turnclockwise toclose.)
Detach thehose and regulatorassemblyfromtheLP
Gas tank valvebyturning theQuick Coupling Nut
counterclockwise.Donotuse awrench oranytools
whenturning theQuick Coupling Nut.
1.RemovetheDrawerand Grease Tray.
Gas Valve/Manifold
Assembly
Regulator
withHose
(LPG)
LPGasTank
Air
shutter
Grill Model
Pushtenondown
ononesideand up
ontheothersideto
unlock
Angle toview
orificeand
adjustairshutter
L
R
Ifyou haveagas leakthatcannotberepairedby
tightening,turnoff thegas atthesource,disconnect
fuellinefromyourgrill and call 1-877-934-7455
oryourgas supplierforrepairassistance.
Neverdisconnectthegasregulatororanygas
fitting whileyourgrill islit. Alitgrill canignite
leaking gas and cause afireorexplosion which
couldresultinpropertydamage,personalinjury
ordeath.
WARNING !!
Viewfromunderthegrill head
Never testforleakswithanopen flame.Priortofirstuse,
atthebeginningofeachseason,oreverytimeyourLP
Gastankischanged,youmustcheckforgasleaks.Follow
thesethreesteps:
Make asoapsolutionbymixingone partliquid
detergentand onepart water.
Turnthegrill ControlKnobstothefull OFF position,
thenturnthegas ON atsource.
Applythesoapsolution toall gas connectionsindi-
catedbythearrows.Seediagram.Ifbubbles appear
inthesoapsolution theconnectionsarenotproperly
sealed.Check each fitting and tightenorrepairas
necessary.
Check thattheend ofeachBurner Tubeis
properlylocated over each Valve Orifice

NaturalGas Connection
NaturalGas Modelonly:
Connecting NaturalGas ToYourGrill
Check all connectionsforNaturalGas Leaks
Never testforleakswithan openflame.Priortofirstuse
andatthebeginningofeachseason,youmustcheck
forgasleaks.Followthesethreesteps:
Makeasoapsolution bymixing onepart liquid
detergentand onepart water.
Turnthegrill ControlKnobstothefull OFF position,
thenturnthegas ON atsource.
Applythesoapsolutiontoall gas connections
indicatedbythearrows.See Fig.3.Ifbubbles
appearinthesoapsolution theconnectionsare
notproperlysealed.Check each fitting and tighten
orrepairas necessary.
Fig.2
GasSupply
InsideWall
OutsideWall
MaleFitting
ToGrill
Locking
ShutOff
ShutOff
Quick
Disconnect
Yournaturalgas grill isdesignedforuse withnatural
gas (NG)only.Thegas pressureRegulatorsupplied
withthisappliance must beinstalledand usedon
yourgrill.Theunitand Regulatoraresettooperate
withanoutletpressureof4"W.C.
Install aShutoff Valveatthegas supplysourceout-
doorsatapointafterthegas pipeexitstheoutsidewall
and beforethequick-disconnecthose.Orinstall itat
thepoint beforethegas linepiping enterstheground.
See Fig.2.
Pipesealing compound orpipethreadtaperesistant
totheaction ofnaturalgas mustbeusedon all male
pipethreadconnections.
Disconnectyourgas grill fromfuelsourcewhenthe
gas supplyisbeing testedathigh pressures.This
gasgrillanditsindividualshutoff valve mustbe
disconnectedfromthegas supplypipesystemdur-
ing anypressuretesting ofthatsystematpressure
inexcess of1/2psi(3.5kpa).
Turnoff yourgas grill whenthegas supplyisbeing
testedatlowpressures.Thegrill mustbeisolated
fromthegas supplypipesystembyclosing itsindi-
vidualmanualshutoff valveduring anypressuretest-
ing ofthegas supplypipesystematpressures equal
toorless than1/2psi(3.5kpa).
NaturalGasSafetyInstructions
ConnecttheSwivelnutofthe 12'NaturalGas
Hose tothehorizontalfittingofNG Regulatoras
shownin Fig.1.Connecttheotherhose end (male
plug)tothe gassupplylinefromyourhome.
Readand followthe "NaturalGasSafetyInstruc-
tions"below.
14
Fig.3
GasValve/Manifold
Assembly
Hose,12 ft./ NG
NGRegulator
Fig.1
Verticalfitting
Hose,12 ft./ NG
Swivelnut

Beforeeach use,check all hoses forcracks,nicks,cuts,
burnsorabrasions.Ifahose isdamagedinanyway,do
notuseyourgrillbeforereplacingthe hosewithan
authorizedpart fromthePartsList. Alsomakesureall gas
supplyconnectionsaresecurelytightened.
Familiarize yourselfwiththesafetyand Use and Care
instructionsinthismanual.Donotsmokewhilelighting
grill orchecking gas supplyconnections.
BesuretheLPGas tank isfilledortheNaturalGasLine
isattachedtothe gassource.
OpentheGrill Lidduring lighting.
4.
3.
2.
1.
SetControlKnobstoOFF andopentheLPGastank valve
SLOWLY1/4ofaturn.ForNaturalGas opentheShutOff
Valveatsource.
PushandturntheMainBurnerControlKnobtoHIGH/IGN.
AlwayslighttheLEFT MainBurnerfirst.
Press theelectricignitor3to4secondstolighttheburner.
Ifignition does notoccurin5seconds,turngas off at
sourceandturnControlKnobsOFF.Waitatleast5
minutes forgas toclear, thenretry.Ifyourgrill still failsto
light turntheburner Control Knob(s) and gas sourceOFF
and conductaleaktestofALL gas connectionsand gas
sources as explainedintheUse and Caresection ofthis
manual.Ifno leaksaredetected,wait5minutes forany
gas toclearand repeatthelighting procedure.
AfteroneBurnerislit, turnthetank valveSLOWLYone
more1/4ofaturn.
Repeatsteps tolighteach burnerindividually.Turnother
burnerstoHIGH/IGNtolightas youmove towardsthe
fuelsource.
5.
9.
8.
7.
HIGH/IGN
OFF
USE AND CAREINSTRUCTIONS
GrillLightingInstructions
Followsteps1through 5oftheGrillLightingInstruc-
tions.
Then,pushand turntheInfraredBurnerControlKnob
toHIGH/IGN and press theelectricignitor3to4sec-
ondstolighttheburner.Holdtheknob in10 seconds
beforereleasing.Ifignition does notoccurfollowstep
7beforeretrying.
AftertheInfraredBurnerislititwill reach cooking
temperaturequickly.Theorange/redglowwill even
outwithinminutes.
HIGH/IGN
HIGH/IGN
OFF
BackBurnerLightingInstructions
Followsteps1through 5oftheGrillLightingInstruc-
tions.
Then,pushand turntheBack BurnerControlKnob to
HIGH/IGN and press theelectricignitor 3to4seconds
tolight theBurner. Holdtheknob in10 secondsbefore
releasing.Ifignitiondoes notoccurfollowstep 7
beforeretrying.
1.
3.
2.
Afterthe Back Burnerislititwill reach cooking
temperaturequickly.Theorange/redglowwill even
outwithinminutes.
InfraredBurner Lighting Instructions
1.
3.
2.
IMPORTANT: Donotuse theBack Burnerand Main
Burnersatthesametime.Backburnerisfor
RotisserieCooking only.
BurnerControl KnobsonControl Panel
OFF
Grill
Main Burner Back Burner Infrared Burner
15
Failuretoreplaceafaultyhose,securegas supply
connectionsortoopentheLidbeforeproceeding to
the LightingProcedurescouldresultinafireor
explosion thatcouldcause seriousbodilyinjury,death,
orpropertydamage.
WARNING
!!
Open LP
gastank
OFF
6.
LOW

USE AND CAREINSTRUCTIONS
ManuallyLighting YourGrill By Paper Match
To lightyourgas grill bymatch,insert amatch intotheLighting
Stickandfollowsteps 1through5oftheGrillLighting
Instructions.Then,lightthematch and placeLighting Stick
through theCooking Gridon thegrill asshownbelow.Turn
thenearestControlKnob tothe
HIGH/IGN setting torelease gas.TheBurnershouldlight
immediately.
Troubleshooting
Topurgeairfromyourgas lineand/orreset
theregulatorexcess gas flow device:
Ifthegrill failstolight:
WARNING
MisalignmentofBurnerTubesoverOrifices
Correction: RepositionBurnerTubesoverOrifices.
Obstruction ingas line
Correction: Removefuelline fromgrill. Donotsmoke!Open
gassupplyforonesecondtoclearanyobstructionfromfuel
line.Closeoffgassupplyatsource andreconnectfuelline
togrill.
PluggedOrifice
Correction: RemoveBurnersfromgrill byremoving the
screwfromtherearofeach Burnerusing aPhillipsHead
Screwdriver. Carefullylift each Burnerup and awayfromgas
valveOrifice.RemovetheOrificefromgas valveand gently
clearanyobstructionwithafinewire.Then reinstall all
Orifices,Burners,screwsand cooking components.
If anobstruction issuspectedinGas Valves orManifold, call
theGrill Information Center 1-877-934-7455 8amto4:30pm
CST,Mondaythrough Friday.
Obstruction inBurnerTubes
Correction: FollowtheBurner Tubecleaning procedureon
page 21 ofthisOperator'sManual.
MisalignmentofIgnitoron Burner
Correction: Checkfor properpositionof theElectrodeTip
asshownin step 4page 9. ThegapbetweentheSpark
Electrode Tipand SparkReceivershouldbeapproxi-
mately3/16"wide.Adjustif necessary.Withthegas supply
closed,turnanyMainBurnerControlKnobtoHIGH/IGN
thenpushinandwatchforthepresenceofasparkatthe
Electrode.
DisconnectedElectricWires
Correction: InspecttheIgnitorJunctionBoxfoundbehindthe
ControlPanel. ConnectlooseElectricwirestoJunctionBox
andtrytolightthe grill.
WeakAAbattery
Correction: UnscrewtheIgnitorCapand replacethebat-
tery.
Ifthegrill still does notlightyou mayneedtopurgeair
fromthegas lineorresettheregulatorexcess gas flow
device. Note: Thisprocedureshouldbedoneeverytime
anewLPGas tank isconnectedtoyourgrill.
Turngas offatsource andturnControlKnobstoOFF.Wait
atleast5minutes forgastoclear,thenretry.
Ifyourgrillstillfailstolight,checkgas supplyand
connections.
Repeatlighting procedure.Ifyourgrill stillfailstooper-
ate, turnthegas off at source, turntheControlKnobsto
OFF,thencheckthefollowing:
1.
2.
3.
Match
Lighting
Stick
Never leanoverthegrill cooking area while
lighting yourgas grill.Keepyourfaceand body
asafedistance(atleast18 inches)fromthe
frontofgrill whenlighting yourgrill bymatch.
WARNING
!!
Ifignition does notoccurin5seconds,turntheControl
Knob(s)and gas sourceOFF and conductaleaktest
as explainedintheUse and Caresection of thismanual.
Ifno leaksaredetected,wait5minutes foranygas
toclearand repeatthelighting procedure.
WARNING
!!
WARNING !!
ShouldaFLASHBACKfireoccurinoraroundthe
BurnerTubes,followtheinstructionsbelow.Failure
tocomplywiththeseinstructionscouldresultin a
fireorexplosion that couldcauseseriousbodilyinjury,
death,orpropertydamage.
Shutoff gassupplytothe gasgrill.
Turnthe ControlKnobstoOFF position.
Open the Grill Lid.
PutoutanyflamewithaClass Bfire
extinguisher.
Oncethe grill hascooled down,clean the
BurnerTubesand Burnersaccording tothe
cleaning instructionsinthisOperator'sManual.
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
16
TurnControlKnobstotheOFF position.
Turnoff thegas atthetank valve.
DisconnectregulatorfromLPGas tank.
ForNaturalGas disconnectregulatorfrom12 ft. Natural
Gas Hose.
Letunitstand 5minutes toallowairtopurge.
ReconnectregulatortotheLPGas tank.ForNatural
Gas reconnectregulatorto12 ft. NaturalGas Hose.
Turntank valveon SLOWLY1/4ofaturn.
ForNaturalGas openShutOff valve.
OpentheGrill Lid.
PushandturntheLEFTMainBurnerControlKnob to
HIGH/IGN.
Press ElectricIgnitorfor3-4secondstolightthe
burners.
(Note:TheLighting Stick is
placedinthedrawer.)

USE AND CAREINSTRUCTIONS
CORRECT ROTISSERIEUSE
Readall instructionsbeforeinitialuse.
IMPORTANT:Whenusingelectricalappliances,basicsafety
precautionsshouldalwaysbeused.
TheRotisserieMotorissetfor120V,60HzAC current.
TheRotisserieisforoutdooruse only.
Donotequipyourrotisseriewithmeatinexcess of10-12
pounds.
Donotletchildrenoperateorplaynearbyyourgrill or
Rotisserie.Alwayssupervise childrenand petsiftheyare
inthevicinityoftheunit.
ConnectingRotisserie
Alwaysattach theassembledRotisserietoyourgrill first
and thenplug theCordintoanoutlet.
Operating Rotisserie
DonotoperatetheRotisserieifthecordorplug becomes
damaged,oriftheRotisseriemalfunctionsorhas been
damagedinanymanner.
DonotoperatetheRotisserieifthecordorplug has been
damagedinanymanner. DonotusetheRotisserieif
cannotbeoperatedsafely.
Donotimmerse ElectricalCord,Plug orMotorinwateror
expose torain,as thismayresultinanelectricalshock.
DisconnectRotisserie
Use aflameretardant BBQmitt tohandletheRotisserie. Be
carefulas thegrill and Rotisseriewill behot.
Unplug theRotisseriefromelectricaloutletwhennotinuse
and beforecleaning.Allowtocoolbeforeadding orremov-
ing parts.
WhenRotisseriecooking placeaCooking Panunderthe
food tobecookedas thiswill capturethedrippingsand
keepyourgrill cleanofexcess grease which couldcause
afire.
CAUTION:Handlewithcarewhenmoving aCooking Pan
withhotoils
Shouldagrease fireoccur, turntheburnersand gas off and
leavethegrill lidcloseduntil thefireisout.
Storethe Rotisserieindoors
WhenRotisserieisnot inuse,storeitindoorsinadryplace.
17
Toprotectagainstelectricalshock,donotimmerse
electricalcord,plugsormotorinwaterorexposeto
rain.Protectelectricalelementsfromburners,hot
grill surfacesandgrease.
WARNING
! !
Toprotectagainstshock hazardrisk,connect
onlytoproperlyGroundedOutlet.
CAUTION
! !
Toprotectagainstelectricshock,do notimmerse
cordorplugsinwaterorotherliquid.
Unplug fromthe outletwhen notinuseand before
cleaning.AllowRotisserieand Grill tocoolbefore
putting on ortaking offparts.
Do notoperateanyoutdoorcooking gasappliance
withadamaged cord,plug,orafterthe appliance
malfunctionsorhasbeendamagedinanymanner.
Contactthemanufacturerforrepair.
Do notletthe cordhang overthe edge ofatableor
touchhotsurfaces.
Do notusean outdoorcooking gasappliancefor
purposesotherthan intended.
When connecting,firstconnectplug tothe outdoor
cooking gasappliancethen plug applianceintothe
outlet.
UseonlyaGroundFaultInterrupter(GFI)protected
circuitwiththisoutdoorcooking gasappliance.
Neverremovethe grounding plug orusewithan
adapterof2prongs.
Useonlyextension cordswitha3prong grounding
plug,rated forthe powerofthe equipment, and ap-
provedforoutdoorusewithaW-Amarking.
1.
2.
3.
4.
5.
6.
7.
8.
9.
ELECTRICALEQUIPMENTUSE

RotisserieInstructions
1. Removeallcomponentsfromthecarton.
Attachthe MotorBracketon the outside ofthe rightgrill bowlpanel.Align the twoholesofthe
Bracketwiththe holeson the grill bowl.Tighten securelyusing twoScrews#10-24x3/4"UNC,Plain
Washersand Nutsprovided.
2.
Slide the Spitthrough the pieceofmeat. Placethe Holding Forksontoeachend ofthe Spit. Adjust
spacing between Holding Forkstoaccommodateyourfood,then tighten the Thumbscrewstokeep
the Holding Forksinposition.Slide the Collarand Bushing ontothe threaded end ofthe Spit. Do
nottighten the CollarThumbscrewuntil the Rotisserieisplaced intoyourgrill.
3.
Rot.Thumbscrew1/4"x1/2"x3
Rot.Screw#10-24x3/4"UNCx2
Rot.Washerx2
Rot.Nut#10-24x2
#10-24Nut
Washer Outsideof RightGrillBowlPanel
Rot. Screw#10-24X3/4"UNC
withwashersandnuts
MotorBracket
Holding Forks
Collar
Bushing
Thumbscrew
1/4"x1/2"
Spit
Thumbscrew
1/4"x1/2"
18

Install the AC(alternating current)RotisserieMotorontothe MotorBracketasshownbelow.Besure
the Motorattachestothe Bracketwiththe electricalcorddown.Thisinstallation insuresthatonce
the Spitisinserted intothe Motoritwill alsorestsecurelyintothe slotofyourgrill bowl.
4.
Insertthe assembled Rotisserieintothe Motorasshownbelow.The Motorshouldbe on the right
side ofyourgrill.Placethe Bushing intothe slotopening on the leftside ofyourgrill bowl,then
tighten the CollarThumbscrewtothe rightof the Bushing.The Collarwill stabilizethe Rotisserieduring
the cooking process and the Bushing allowsthe RotisserieSpittoturnsmoothly.Plug the Rotisserie
intoan outletand turnon totest.
5.
BEFORErotisseriecooking you will need toremovethe Cooking Grid(s)and possiblythe SavorPlates®
fromyourgrill.When rotisseriecooking placeaCooking Pan underthe food tobe cooked.Thiswill
capturethe drippingsand keep yourgrill clean ofexcess greasewhichcouldcauseafire.Usecaution
when moving aCooking Pan containing hotoils.
The Bushing and Collar mustalwaysbe used withthisRotisserie.
RotisserieMotor
RotisserieSpitmustrestsecurelyin
theslotofyourgrill bowl. Motor Bracket
Bushing
Thumbscrew Holding Forks Motor
Thumbscrew
Spit
19

20
Propercareandmaintenancewillkeepyourgrillintop
operating condition and prolong itslife.Followthese clean-
ing procedures on atimelybasisand yourgrill will stayclean
and operatewithminimumeffort.
CAUTION: Besureyourgrill isOFF and cool beforecleaning.
CLEANINGAND MAINTENANCE
Removeand cleanall cooking components;Savor
Plates®, Cooking Grids, Cooking Rack and Grill Burn-
ers.
ReplacetheBurnersandadjusttheGas Collector
Box.Theedge ofthe collectorboxshouldbe overlap-
ping theBurnerPort.
Brushtheinsideand bottomofthegrill withafiberpad
ornylon brushand washwithamildsoapand warm
watersolution.Rinse thoroughlyand letdry.
Check each SparkElectrode,adjusting as needed.
Thespacebetweenthe SparkElectrodeTipand
SparkReceivershouldbeapproximately3/16".
10. Replace all cooking components.
Reconnectthegas sourceand observethe
Burnerflameforcorrectoperation.
11.
1.
4.
5.
6.
7.
8.
9.
Burning-off excess food aftereverycookoutwill keep
itreadyforinstantuse.However,atleastevery3
months youmustgivetheentiregrillathorough
cleaning tominimize yourriskofgrease fireand keep
thegrill intop shape.Followthese steps:
TurntheLPgas tank valvetothefull OFF position.
Disconnecttheregulatorfromthegas tank.Inspect
thehose withregulatorassemblyforcracking,cuts
oranyotherdamage,and replaceas neccessary.
RefertothePartsListinthisOperator'sManual.
Covereach Gas ValveOrificewithaluminumfoil.
Removealuminumfoil fromOrifices and check each
Orificeforobstruction.
Turnall BurnerValves tothefull OFF position.
RoutineCleaning ofTheGrill Interior
CleaningTheCooking Grids
Beforeinitialuse,and periodicallythereafter, wash
yourCooking Gridsinamildsoapand warmwater
solution.You canuse awashclothorvegetable
brushtocleanyourCooking Grids.
Cleaning SavorPlates®
Periodicallyyou shouldwashtheSavorPlates® ina
soapand warmwatersolution.Useavegetable
brushtoremovestubbornburnt-on cooking residue.
DrytheSavorPlates® thoroughlybeforeyou reinstall
themintothecooking bowl.
Cleaning TheGrease Trays
To reducethechanceoffire,theGrease Draining
Traysshouldbevisuallyinspectedbeforeeach grill
orrangeuse.Removeanygrease and washGrease
Trayswithamildsoapand warmwatersolution.
Cleaning theInsideoftheGrill Lid
Grease canbuildup on theinsideoftheGrill lidover
time.Thisgrease candripontoyourdeck orpatio
whenthelidisopened.Visuallyinspecttheinsideof
theGrill Lidbeforeeach grill use.Removeanygrease
and washwithamildsoapand warmwatersolution.
3.
2.
Ifneeded,wesuggestyouwashthemanufactured
stonesurfaceusing amildsoap and warmwater
solutiononly.Youcan use asoftsoapyclothor
spongethenrinsewithwater.Neveruseabrasive
cleaners,anycleanercontainingbleach,scrubbers
orstiff wirebushes on thestonesurface.These can
cause discoloration and /orchipping ofthepainted
surface.
Cleaning ManufacturedStoneSurfaces:
Aftereveryuse(afteryourgrillhas cooled down),wipe
stainless surfaces withasoft, soapyclothorsponge
thenrinsewithwater.Besuretoremoveall foodpar-
ticles,saucesormarinadesfromstainlesssteelbe-
causethesecanbehighlyacidicanddamagingtostain-
less surfaces.
Neveruseabrasivecleaners,scrubbersorstiffwire
brushesofanytype onyourgrill.
UseaheatresistantStainless SteelCleanerand rub
orwipeinthedirection ofthestainless steelgrainor
polishlines.Donotpolish againstthegrain.
Cleaning ExteriorStainless SteelSurfaces:
Routinecareandmaintenanceisrequiredtopreserve
theappearanceand corrosion resistance ofstainless
steel. Thefactisstainlesssteelcancorrode,rustand
discolorundercertainconditions.Rustiscausedwhen
regularsteelparticles intheatmospherebecomeat-
tachedtothe stainlesssteelsurface.Steelparticles
canalso becomeattached toyourgrillif youusesteel
woolorstiff wirebrushes tocleanthegrill insteadof
non-abrasive cloth,sponge ornyloncleaning tools.In
coastalareas rustpitscandevelopon stainlesssur-
facesthatcannotbe fullyremoved.Bleachand other
chlorinebased solutions used forhouseholdandpool
cleaning canalsocause corrosiontostainless steel.
Weathering,extremeheat,smokefromcooking and
machine oilsusedinthemanufacturingprocessof
stainless steelcancause stainlesssteeltoturntanin
color.Althoughtherearemanyfactorswhichcanaffect
the surfaceappearanceofstainlesssteel, theydonot
affecttheintegrityofthe steelorthe performance ofthe
grill.
Tohelpmaintainthefinishofstainless steelfollow
these cleaning procedures forthebestresults:
1.
3.
2.
MAGNIFIEDVIEW OFGRILL MAINBURNER,INFRARED
BURNERFLAMETHROUGHOPENLID.
WARNING
!!
Failuretocomplywiththese instructionscouldresult
inafireorexplosionthatcouldcauseseriousbodily
injury,deathorpropertydamage.
Keepgrill area clearand free fromcombustiblemate-
rials,gasolineand otherflammablevaporsandliq-
uids.
Donotobstructtheflowofairforcombustion and
ventilation.
Keeptheventilation openingsofthetank enclosure
cabinetfree and clearofdebris.
Visuallycheck burnerflames occasionallytoensure
properflamepatternas shownbelow.
