Giada D230X series User manual

www.giadatech.com User’s Manual
All right reserved
Version 001
MINI-PC
For D230X series
(2) this device must accept any interference received, including interference that may cause undesired operation.
FCC ID:YIKD2301
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and

Gratitude ……………………………………………………………………………
Copyright and Trademark …………………………………………………………
I. Introduction to the Manual………………………………………………………
1. Precautions …………………………………………………………………
2. Accessories …………………………………………………………………
II. About the product ………………………………………………………………
1. Appearance …………………………………………………………………
2. Features ……………………………………………………………………
III. System setup……………………………………………………………………
1.Install an operating system…………………………………………………
2. Drivers install ………………………………………………………………
IV. Equipment expansion …………………………………………………………
1. Card Reader…………………………………………………………………
2.USB device …………………………………………………………………
3. Audio device…………………………………………………………………
4. Network device………………………………………………………………
V. Power supply and maintenance ………………………………………………
1.Adapter ………………………………………………………………………
2. Maintenance…………………………………………………………………
VI. Troubleshooting…………………………………………………………………
Contents
2
4
3
4
5
6
6
9
10
10
12
13
13
13
14
14
16
16
17
18
1
www.giadatech.com

32
Gratitude
Copyright and Trademark
Dear Users,
Thank you for choosing Giada product.
In such an epoch of PC development, we launched Giada Mini PC which is
characterized by the mini shape, vogue and ultra-thin structure, environment
friendly, powerful graphic processing ability and lower power consumption.
Giada provided with multiple functions, including serving as high-definition
movies broadcasting, exclusive downloader, small server, internet access for
office work and higher mobility when compared with traditional PCs. Giada will
allow you to undergo new experience in the field.
This User's Manual would allow you better understand the device. Therefore,
please carefully read the whole manual before you operate the device.
In case you have any questions concerning after-sales services in using the
product, please contact us according to the contact information below:
Website: www.giadatech.com
Add: 2/F, Building A, Tsinghua Information Harbor, North Section, Shenzhen
Hi-Tech Park, Nanshan, Shenzhen, China.
Shenzhen JIEHE Technology development Co., Ltd will try our best to ensure the
accuracy and intactness of this manual. However, as our products are being
upgraded all the time, we can't guarantee that this Manual is flawless and shall
bear no responsibility if it is misunderstood by the user. The User's Manual is
subject to change without prior notice.
Giada and the related mark are trademarks owned by Shenzhen JIEHE
Technology development Co., Ltd.
Windows®, MS, MS-DOS, Windows XP, Windows Vista and Windows 7 are
trademarks of USA Microsoft Corporation, which were registered in the US, other
countries or other regions in the world.
INTEL® Core™ and Atom™ are trademarks of USA's INTEL, which were
registered in the US, other countries or other regions in the world.
NVIDIA® ION™, Geforce, Geforce CUDA, PureVideo HD and PhysX are
trademarks of USA's NVIDIA, which were registered in the US, other countries
or other regions in the world.
Shenzhen JIEHE Technology development Co., Ltd reserves the right for final
interpretation of this Manual. Copying and reproduction of the contents in this
document, or storage and transfer in any form without the prior written permission
of Shenzhen JIEHE Technology development Co., Ltd is prohibited.
www.giadatech.com

54
I. Introduction to the Manual
1. Precautions
In order to prevent the PC from being damaged, extend its service time, and
ensure your normal use and personal safety, please carefully read the whole
User's Manual and the related safety information and strictly follow the
requirements in it. You should also keep the Manual well.
· Please read the documents attached to the product first. The page exclusively
inserted should be read firstly.
· Please observe all alarm information and marks on safety.
· Please use the original power adapter, or use special power supply mentioned
in the Manual.
· Place place the product correctly on your table and make sure the anti-sliding
base is installed.
· In lightning time, do not plug or unplug the phone cable, network cable, power
cord or other conductors connecting outside.
· Unplug the power cord before you clean the device. Never use liquid, sprayed
cleaning agent or wet cloth to clean the product.
· In order to protect the operating system, motherboard and hard disk, please
do not keep pressing the power switch or the reset key. Avoid interrupt power
failure during system's running, which might also physically damage the
operating system.
· Do not remove the shell or repair the product without permission. such work
should be done by professionals.
· Keep the PC away from heat source.
Never block the heat vents. Keep your PC away from direct sunshine.
· Keep the product away from moisture.
Never spill water or other liquid onto it. You should call the professional service
personnel under following circumstances:
a. The power cord or plug was damaged.
b. Conductive liquid went into the product.
c. The product was dropped onto the ground or its shell was damaged.
d. When unidentified errors occurred or the product's performance is obviously
deteriorated, please cut off power immediately and contact professional
technicians.
2. Accessories
Your Giada consists of the accessories in the table below. If any of them is missing,
please contact your local distributor or the customer service center timely.
· Host 1 unit · Adapter (with power cord) 1 piece
· Remote control 1 piece · HDMI cable 1 piece
· User’s Manual 1 copy · Disk 1 piece
· Certificate of Conformity 1 copy · Warranty Card 1 copy
Note: Picture is just for your reference, please subject to the physicals.
( PC ) ( Power Adapter ) ( User’s Manual )
( Drivers CD ) ( Certificate ) ( Warranty Card )
www.giadatech.com

76
1. Appearance
II. About the product
Giada mini PC with multiple interfaces can be connected to various types of
monitors, storage devices and so on. There are some brief for all kinds of
pictures in following table. The table will make you better understand the
structure of the product.
www.giadatech.com
14
15
16
18
17
19
20
2221
2324
2

98
2. Features
A. Slim appearance and High mobility
Giada mini PC is only one-thirtieth of the desktop PC and less than 2kg, easy to
be carried anywhere. Your space can be saved with the stylish appearance and
mini-size structure.
B. HD broadcasting / entertaining PC
The product can support 1080P resolution full HD and popular PC games, easily
setup your home entertainment center.
C. Household downloader/server
The product also features its environmental-friendly design, lower power
consumption (only 1/3 of traditional PC, less than that of ordinary power saving
lamps), improved laptop radiating technology and low noise. Low power
consumption and quiet running make it particularly suitable for downloading in
sleeping time.
www.giadatech.com
Power switch
Indicator LED
DVD-ROM eject
Slot-in DVD-ROM
Clear CMOS
MIC-in
Audio-out
USB3.0 port
Card reader
DC-in
Start the PC
Power, HDD working status
Eject disc in the DVD-ROM
Disc load in and out
Reset BIOS to default value
Connect audio input devices
Connect audio output devices
Connect USB3.0 devices
To read SD/MMC/MS/MS PRO storage card
Connect power adapter
Description
Icon Use Position
1
2
3
4
6
5
12
8
9
10
11
DVI port
13
15
Connect DVI digital monitor
TV antenna Mount the TV antenna (equip with TV card)
Network interface
USB2.0 port
e-SATA port
HDMI port
Kensington Lock
Rj45 port
Connect USB2.0 devices
Connect e-SATA devices
Connect DVI digital monitor
Anti-theft lock
S/PDIF out Connect digital audio output devices
Wi-Fi antenna Makes wireless signal better
Air vent Allow air well ventilated inside the PC
Stand the PC for safety purpose
Base
3.0
720
14
16
17
18
19
21
22 23
24

1110
Step3. Press “F12” on your keyboard while “Giada” logo appears on your screen
after starting up. (see the picture showed below)
Step4. A window pops up as the picture below. It lists all the possible booting
devices you've connected to the PC, choose the one with operating system disk
and press “enter”.
Step5. Follow the instructions to complete install.
www.giadatech.com
1. Install an operating system
Caution: NOT suitable for pre-install OS version users.
This product supports Windows XP, Windows Vista, Windows 7 and other normal
operating systems. If you want to install a new or change your current operating
system, you can consult your local distributor, or you can connect the PC to an
external CD-ROM or DVD-ROM and use the disk for installation.
Step1. Start up your PC.
Step2. Put your operating system disk in the CD-ROM.
III. System setup

1312
IV. Equipment expansion
1. Card Reader
The card reader of this product can support SD, MS, MS PRO, MMC and other
mobile memory cards. It also supports PNP and hot swapping.
· Insert the mobile memory card into PC through the top port on it and pay
attention to the card's sides. Never use excessive force when inserting the
card. Otherwise the memory card or the slot may be damaged.
Note: SD/MMC: with the omitted angle facing the right; MS/MS PRO: with the
omitted angle facing the left.
· Exit of memory card:
(1) Stop operation on the card;
(2)“Safely remove” the card through the operating system;
(3) Take out the card gently.
2. USB device
We have both USB2.0 and USB3.0 port which can support various types of USB
devices, including USB CD-ROM, USB mobile device, USB mouse and
keyboard, etc.
www.giadatech.com
2. Drivers install
After the operating system has been installed, we need to install some hardware
drivers.
Step1. Put the drivers CD into CD-ROM, an user interface pop up automatically.
Click the “Drivers” button for next step. (for Windows XP, Windows Vista,
Windows 7 OS)
Step2. The driver install program will sense your PC, and list all the drivers you need.
Step3. Install all the listed drivers follow by the program instruction, and than
restart the computer.
Caution:
· If your wireless LAN card with Bluetooth, the Bluetooth function is NOT
supported under Windows VISTA.
· Some hardware have driver for Linux, they are in the document named “Linux”.

1514
up the network. To construct a LAN or other network, please refer to following photos.
Note: Before setting up the network, please make sure you have properly installed
the drivers for the network interface card and Wi-Fi.
A. Cabled network
· Insert the terminal of network cable, which comes from the hub or server, into
the RJ-45 port, and make sure the connection is correct and firm.
· Please refer to the related instructions of operating systems and properly
install the driver and related applications for the network.
B. Wireless network
With the embedded wireless network device, you can connect your PC to the
Internet through the access point.
Note: To form a small-scale LAN for home use or office work, you need both the
wireless network device embedded in the product and a wireless router.
· Start your wireless router, and make proper configurations for it in accordance
with the operating instructions or instructions from the carrier.
· Start the Wi-Fi device through the operating system of the host.
· Based on the instructions of operating system on network construction, select
the wireless network and make correct configurations for the software.
The wireless router
RJ - 45
www.giadatech.com
3. Audio device
You can connect the external microphone (or other audio input equipment) to
“MIC-in”, and connect the earphone or speaker to the “Audio-out” on front or
back panel.
For better sound quality, you can connect audio output device with digital decoder
inside to S/PDIF-out port.
4. Network device
The Wi-Fi device embedded in the product can help you set up a network, either
cabled or wireless. Make sure you have installed the hub or switch before you set
Caution: Excessive sound pressure from earphones and
headphones can cause hearing loss.

1716
2. Maintenance
As a high-tech product with sophisticated structure, Giada Mini PCs needs to be
maintained properly. Misuse or rough handling may result in damage or system
failure.
Caution: Risk of explosion if battery is replaced by an incorrect type. Dispose of
used batteries according to the instructions.
· Body
Please prevent sharp objects from scratching on it. Make sure the power supply
to the host is cut off before cleaning the body. Never use wet cloth for cleaning.
Otherwise, water drops or other conductive liquid may go into the host.
· Handling
Never place the product at the edge of the table. Otherwise, it may fall on the
ground and be damaged.
Always check the peripheral equipment and the connection cables to see
whether they are properly arranged, so that people might not be stumbled by
the wire or equipment and equipment not damaged.
· Radiation
Radiation is of great significance for PCs. Please place the product in a proper
position. Never block the air inlet and air outlet that are used for ventilation.
Do not place the product onto the bed, sofa or other soft objects for use.
Otherwise, the vents might be blocked and system halted because of the
overheating.
· Interfaces
Never use other objects to jam the interfaces on the host, nor use sharp
objects to scratch the pins. Otherwise, the pins might be damaged. If there is
any poor contact, you can use a soft brush to dust the place.
www.giadatech.com
Ripple& Noise
Max mVp-p
1. Adapter
In order to avoid personal injury and ensure the normal operation of the product,
please make sure the AC power you provide conforms to the specifications
described on the sign at the back of the adapter. Use three-core receptacle and
reliable grounding. In addition, you should also make sure the voltage from your
local power matches the respective rated value of the monitor and other external
equipment.
· It is recommended the attached adapter be used. If the attached adapter can't
be used under some special circumstances, you must use a adapter with the
same specification.
· Input Characteristics
Range of input voltage: 90Vac-264Vac, single phase
· Output Characteristics
Static Output Characteristics <Vo & R+N>
V. Power supply and maintenance
Max.
264Vac
63Hz
Voltage
regulation
±5% 190mV
Normal
100Vac~240Vac
60Hz/50Hz
Peak Load
/
Min.
90Vac
47Hz
Rated Load
Max.Load
3.42A
Input Voltage
Input Frequency
Output
+19V
Min.Load
0.0A
Rail
