Giant 309 User manual

Giant -309 Operation Manual (2.4GHz Cordless + CID)
Revision 1
Page 1of 22
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should always be followed to reduce
the risk of fire, electric shock and injury to persons, including the following:
1. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or
laundry tub, in a wet basement or near a swimming pool.
2. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a
remote risk of electric shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire.
They may explode. Check with local codes for possible special disposal instructions.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF
USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
SAVE THESE INSTRUCTIONS

Giant -309 Operation Manual (2.4GHz Cordless + CID)
Revision 1
Page 2of 22
MAIN FEATURES
OLYMPIA OL2430 CORDLESS PHONE FEATURES:
1. 2.4GHz 40 channels auto scanning operation
2. Manual channel selection
3. 65536 Random combinations of security code
4. Last number re-dial (32 digits max.)
5. Power saving in standby mode. ( handset )
6. Page in base unit to locate the handset ( short and long page )
7. Temporary touch tone (pulse to tone dialing)
8. Tone / Pulse dialing mode selection in handset
9. Ringer ON /OFF selection in handset
10. Mixed mode dialing (auto insert of 4 sec. pause when mode change from Pulse to Tone)
11. 10 indirect memories store in handset (16-digits / phone no.)
12. Chained memory dialing of 32 digits max.
13. Flash key for call waiting and call transfer 600ms.
14. Handset LED for paging, ringing and on cradle (Enabled by setup menu)
15. Receiver volume control by software (Three level default at middle level)
16. Pause key ( pause time is 4 seconds )
17. Low battery warning tone
18. Handset ringing
19. Back-lighted LCD
20. Auto Standby feature
21. Auto Answer connection
22. Any key answer
23. Direct number dial out
24. Memory direct dial out
25. Direct redial
26. Redial & CID transfer to in-direct memory ( 16 digits long )
Auto Standby Allows the user to hang up by simply returning the handset to the base.
Auto Answer
Allows the user to answer a call by just removing the handset from the base so the user don’t have to waste
time pushing buttons. The ‘Talk” key will be disabled for 5 seconds to avoid accidental hang up. This
feature is activated while ringing and disable 5 seconds after the ring.
CALLER ID FEATURES :
1 Type I + Type II (call waiting)
2 64 name and number caller ID
3 3-line display
4 back-lit LCD (on handset)
5 Total call counter
6 New call LED indicator in handset
7 Repeat call indication (LCD icon)
8 3-language operation (English, Spanish & French)
9 Scroll review of CID records
10 Selective-erase / Erase-all function
11 Real time clock (date & time)
12 Private/ out-of-area indication
13 LCD contrast control 6 levels, default at 3.
14 Call back (CID dial back)

Giant -309 Operation Manual (2.4GHz Cordless + CID)
Revision 1
Page 3of 22
15 Battery low indication (‘Battery Low’ text display on the 3rd line )
CORDLESS OPERATION
Channel frequencies
CH. BASE TX H/S TX CH. BASE TX HS/TX
12401000000 2473500000 21 2403000000 2475500000
22401100000 2473600000 22 2403100000 2475600000
32401200000 2473700000 23 2403200000 2475700000
42401300000 2473800000 24 2403300000 2475800000
52401400000 2473900000 25 2403400000 2475900000
62401500000 2474000000 26 2403500000 2476000000
72401600000 2474100000 27 2403600000 2476100000
82401700000 2474200000 28 2403700000 2476200000
92401800000 2474300000 29 2403800000 2476300000
10 2401900000 2474400000 30 2403900000 2476400000
11 2402000000 2474500000 31 2404000000 2476500000
12 2402100000 2474600000 32 2404100000 2476600000
13 2402200000 2474700000 33 2404200000 2476700000
14 2402300000 2474800000 34 2404300000 2476800000
15 2402400000 2474900000 35 2404400000 2476900000
16 2402500000 2475000000 36 2404500000 2477000000
17 2402600000 2475100000 37 2404600000 2477100000
18 2402700000 2475200000 38 2404700000 2477200000
19 2402800000 2475300000 39 2404800000 2477300000
20 2402900000 2475400000 40 2404900000 2477400000

Giant -309 Operation Manual (2.4GHz Cordless + CID)
Revision 1
Page 4of 22
1.Power Up
1.1. After power up, the handset should place on the cradle of the base unit for setting a new
security code for communication
1.2. Each time when the handset place on the cradle of the base unit, the base unit will generate
and transmit a new security code to the handset unit through the RF Link.(The both unit will
use the 1st channel for the security code transfer operation)
1.3. The completion of a successful security code transfer operation will be indicated by a flash
of the in use LED on the base unit and a beep sound generated by handset.
1.4. In case, the Transfer operation cannot be successful, please try again.
2.Answering Call
2.1. The incoming call is signaled by a ringing sound from the handset’s buzzer and by the
blinking of the base In use/Charge LED. At the same time ‘RINGING’ will be shown in the
display. The handset LED will be turned on during ringing
2.2. When the handset on the cradle, simply pick up the handset unit from the cradle of the base
to talk. The “TALK” button will be disabled for 5 seconds.
2.3. When the handset is away from the base unit, press the “TALK” button on the handset unit.
The handset will transmit the “talk on” command to base unit to establish the RF connection
with in use/charge LED turns on after connection is successful.
2.4. If the communication Link cannot establish within 8 seconds, three error beeps tone will be
heard from the handset to indicate communication is failed.
3.Make a call
3.1. Each new call must begin by pressing the “TALK” button in the handset and it will scanning
for a clear channel for communication. At the same time, ‘TALK’ will be shown on LCD
display. The handset will transmit the “talk on” command to the base unit to establish the
RF communication after connection is successful.
3.2. If the communication Link cannot establish within 8 seconds, there error beeps tone will be
heard from the handset to indicate the communication is failed.

Giant -309 Operation Manual (2.4GHz Cordless + CID)
Revision 1
Page 5of 22
4.Terminate a call
4.1. To terminate a call, either by pressing the “TALK” button, the handset will emit a beep
indicating call is terminated successfully.
4.2. By placing the handset on the cradle, call is terminated and ‘Security code set up’ procedure
will be performed.
4.3. Handset will emit a error beep if it cannot receive ‘talk off ACK’ from the base unit. In this
case, put the handset back to the base cradle to make sure base unit is going ON HOOK.
5.Short Paging (to locate the Handset)
5.1. Press the PAGE button of the base unit. The ‘PAGING’ will be shown on the LCD display
and output3 short beeps then followed by 1 second pause, followed by 3 short beeps.The handset LED
will be turned on during paging.
6.Long Paging (to find the handset)
6.1. Press the PAGE button of the base unit. The ‘PAGING’ will be shown on the LCD display
and output beep. If you hold the button for 5sec, the beep will be extended to 60sec. The
handset LED will be turned on during paging.
6.2. Press any key on handset to stop paging.
7.Selecting system language
7.1. Two cases you enter the system setup mode.
1) The handset is first time use or no any system data after power up.
2) Press and hold the ‘memory’ key for about 2sec in stand-by.
7.2. Setup mode begins with language selection. The device offers 3 languages, namely English,
French and Spanish. Press “#” or “*” button to choose the desired language and then press
the “MEMO” key to confirm. After confirmation, it will enter Setting local area code
S E T L A N G U A G E

Giant -309 Operation Manual (2.4GHz Cordless + CID)
Revision 1
Page 6of 22
8.Setting local area code
8.1. You need enter 3 digits from number pad. Three digits will be shift to left one by one, after
you enter one digit.
E.g. [Press “1”, display “ 001”] à[Press “2”, display “012”] à[Press “3”, display “123”]
8.2. Press “MEMO” key to confirm. After confirmation, it will enter Tone/Pulse setting.
9.Setting Tone/Pulse
9.1. It will display current T/P setting first
9.2. Press “#” or “*” button to set the desired setting, and the display will update to current
setting also, ”SET T/P? T”à” SET T/P? P”à”SET T/P? T”……..
9.3. Press “MEMO” key to confirm. After confirmation, It will enter ringer setting.
10. Setting RINGER ON/OFF
10.1. It will display current RINGER ON/OFF setting first
10.2. Press “#” or “*” button to set the desired setting, and the display will update to current setting
also, ”RINGER ON”à” RINGER OFF”à”RINGGER ON”……..
10.3. Press “MEMO” key to confirm. After confirmation, It will enter LED setting.
0 0 0
A R E A C O D E ?
S E T T / P ? T
R I N G E R O N

Giant -309 Operation Manual (2.4GHz Cordless + CID)
Revision 1
Page 7of 22
11. Setting handset LED ON/OFF/CON
11.1. It will display current “LED ON/OFF/CON” setting first.
11.2. Press “#” or “*” button to set the desired setting, and the display will update to current setting
also, ”LED ON”à” LED OFF”à”LED CON”à”LED ON”……..to control the handset
LED.
11.3. Press “MEMO” key to confirm. After confirmation, It will enter display contrast setting.
12. Setting display contrast
12.1. Two cases you can enter contrast setting.
1) From system setup mode.
2) Press “FLASH” button in stand-by.
12.2. Press “#” or “*” button to set the desired contrast.
12.3. Press “MEMO” key to confirm. After confirmation, display returns to standby.
* Press ‘CHANNEL’ button to return to stand-by.
13. CALLER ID OPERATION
Display :
C O N T R A S T 56
12-character text line (dot matrix)12-digit number line (7-segment)
1 2 3 4 5 6 7 8 9 0 1 2
ttA B C D E F G H I J K L uu
NEW
CALL
88
RPT
18:88
PM
AM
1 8/8 8
New-Call /
Call counter
Repeated-call
indicator
New
voice-mess
age
Clock
Clock ticker
Date
NEW CALL
INDICATOR
VIP
L E D O N

Giant -309 Operation Manual (2.4GHz Cordless + CID)
Revision 1
Page 8of 22
Display Descriptions Remarks
12-character text line
For display of callers’ name, system prompts (CID
and phone), call timer, dial number. Dot-matrix (5 x 5 )
12-digit number line 1, Display caller’s number (CID), or
2, Display dialed digits (phone). 7-segment
New-call / Call counter Shows the amount of calls / new calls in standby
mode
Example: to show # of old calls: CALL 18
to show # of new calls: NEW CALL 9
(The numbers are displayed at the left hand side of
the 12-digit number line)
CID only
Repeated-call icon
Lights on to indicate that the displayed call arrived
more than once. CID only
Clock 1, Shows the real time clock (AM/PM format), or,
2, the time stamp of a CID record.
Clock ticker Blinks when real time clock is being displayed.
(Frequency: 0.5sec. On / 0.5 sec. Off)
Date 1, Shows the date (month/date format), or,
2, the date stamp of a CID record.
CID related button Descriptions Remarks
“DEL” 13)Erase a single CID record in CID
browser.
2) Erase all CID records in stand-by.
“#” 1) Scroll-down CID records.
“*” 1) Scroll-up CID records.
“Calls” 1) Redial CID number in CID browser.
NEWCALL indicator-to indicate that there are unread/new calls stored in memory. The duty cycle
of the NEWCALL indicator is 60ms on / 2950ms off (500ms on / 2950ms off per CCL request).
Note1: All display illustrations in the document will be in English. However, the actual appearances of the screens will vary according
to the language selection during start-up (English, French or Spanish).
Note2: If the unit receives more than 64 calls, the oldest CID information will be erased except VIP calls.
13.1. RECEIVING CALLS
13.1.1. When Caller ID is activated, the Telephone Company sends the caller’s telephone
number (and name, if available) and the call’s date and time between the first and
second rings. The device receives and displays this information for each call and
updates the display with the current date and time. The NEWCALL indicator will be
flashed.

Giant -309 Operation Manual (2.4GHz Cordless + CID)
Revision 1
Page 9of 22
13.1.2. The display also indicates if caller information is not available or if the sender
intentionally blocks the number.
13.1.3. After 20 seconds, the display will return to standby mode and shows “NEW CALL
XX” where XX is the number of unread calls. NEW CALL LED indicator blinks until
the user retrieves all new messages.
Note: If the received CID number is 10 digit long and the first three digits match with the area code
set by user, the LCD shows the last 7 digits only (area code will be omitted).
13.2. REVIEWING NEW CALLS
13.2.1. In stand-by mode, NEW LED flashing, pressing “*” or “#” button, the LCD
displays the last new call information.
13.2.2. Repeatedly press “*” or “#” button to review all new call information in the order of
receiving until the LCD displays “END NEW CALL” and the NEW LED off.
CALL
E
D
L
L
C
A
W
E
N
N
N O C A L L E R I D
NEW
CALL
1
10:00
PM
1 0/3 0
CALL
NEW
CALL
S
I
H
N
J
H
T
O
M
2
10:00
AM
1 1/0 1
9
8
7
--
6
5
4
--
3
NEW CALL
2
1
CALL
NEW
CALL
S
I
H
N
J
H
T
O
M
0
9
8
7
--
6
5
3
4
--
1
10:00
PM
1 0/3 0
1
2
C I D B L O C K E D
NEW
CALL
1
10:00
PM
1 0/3 0

Giant -309 Operation Manual (2.4GHz Cordless + CID)
Revision 1
Page 10 of 22
13.2.3. If the received call information is same as any of the existing new calls, the ‘RPT’
icon will be on to indicate REPEAT CALL. The most recently arrived CID will be
saved attached with a new date / time stamp. The previously arrived record will be
deleted. After you review this call, the ‘RPT’ icon will be off.
13.2.4. If not review over all new calls, after 20 seconds the Time of Day will display and
the new call counter will show the total number of new calls including those already
reviewed.
* Press ‘CHANNEL’ button to return to stand-by.
* No press any button for 20 seconds, it will return stand-by mode.
13.3. REVIEWING OLD CALLS
13.3.1. In stand-by mode, press “*” or “#” button to review old call information from the
oldest to the newest (“*” button) or from the newest to oldest (“#” button).
13.3.2. When finish reviewing all calls, the “-END-” is displayed.
13.3.3. If there is no calls, the display shows “-NO CALLS-”
* Press ‘CHANNEL’ button to return to stand-by.
* No press any button for 20 seconds, it will return stand-by mode.
CALL
--
S
L
A
L
O
N
--
C
CALL
NEW
CALL
5
10:00
PM
1 0/3 0
CALL
CALL
S
I
H
N
J
H
T
O
M
0
9
8
7
--
6
5
3
4
--
1
10:00
PM
1 0/3 0
1
2
CALL
D
--
E
--
N
