Gibson GEF3015KWA Owner's manual

All about the
Use&Care
of your
TABLE OF CONTENTS
Electric Range
316902215 (Rev B Jan 2012)
Important Safety Instructions ........................... 3-5
Appliance Features ........................................... 6
Before Setting Oven Controls ........................... 7-8
Before Setting Surface Controls ....................... 8-9
Setting Surface Controls (Coil cooktop) .............. 10
Oven Control Functions (200)............................ 11
Setting Oven Controls ..................................12-15
Self-Cleaning ..............................................16-17
Care & Cleaning ..........................................18-21
Before You Call ............................................22-23
Warranty ............................................. back page
Electric Range

2
This Use & Care Guide is part of our commitment to customer
satisfaction and product quality throughout the service life of
your new appliance.We view your purchase as the beginning
of a relationship. To ensure our ability to continue serving you,
please use this page to record important product information.
TABLE OF CONTENTS AND PRODUCT RECORD
Need help??
Before you call for service, there are a few things you can
do to help us serve your better.
Read this Use & Care.
It contains instructions to help you use and maintain your
range properly.
If you received a damaged range ...
immediately contact the dealer (or builder) that sold you the
range.
Save time and money.
Check the section titled “Before you call”. This section helps
step you through some common problems that might occur.
Serial plate location and product record .......................... 2
Important Safety Instructions ............................ 3-5
Appliance Features ................................................ 6
Before Setting Oven Controls ............................... 7-8
Oven vent location ..................................................... 7
Removing, replacing & arranging the oven racks ........... 7
Before Setting Surface Controls ........................... 8-9
Cookware material types ............................................ 9
Element ON indicator light(s) ...................................... 9
Home Canning .......................................................... 9
Setting Surface Controls ....................................... 10
Oven Control Functions ......................................... 11
Setting Oven Controls ...................................... 12-15
Setting the clock ...................................................... 12
Changing between continuous bake or 12-Hour
Energy Saving features ............................................ 12
Changing oven temperature display (F° or C°) ............ 12
Timer .................................................................12-13
Setting oven lockout................................................. 13
Setting bake ........................................................... 13
Setting broil ............................................................ 14
Adjusting oven temperature ..................................... 15
Operating interior oven light ..................................... 15
Self-Cleaning .................................................... 16-17
Care & Cleaning ............................................... 18-21
Surface elements and drip bowls .............................. 19
Replacing the oven light ........................................... 20
Removing & replacing oven door ............................... 21
Before You Call
Solutions to common problems .............................22-23
Warranty .................................................. back page
Table of contents
Serial plate location:
open storage drawer (some models) or
removelower frontpanel(some models).
Serial plate location
Purchase date
Model number
Serial number
Record model & serial numbers here

3
Read all instructions before using this appliance.
Do not attempt to install or operate your appliance until you
have read the safety precautions in this manual. Safety
items throughout this manual are labeled with a WARNING
or CAUTION statement based on the risk type.
Save these instructions for future reference.
IMPORTANT SAFETY INSTRUCTIONS
• Proper installation—Be sure your appliance is
properly installed and grounded by a qualified
technicianin accordance withthe National Electrical
CodeANSI/NFPA No. 70latest edition andlocal
electrical code requirements. Install only per
installation instructions provided in the literature package
for this range.
WARNING
Stepping, leaning or sitting on the door or
drawers of a range can result in serious injuries
and also cause damage to the appliance. DO NOT
allow children to climb or play around the range. The
weight of a child on an open oven door may cause the
range to tip, resulting in serious burns or other injury.
Never use your appliance for warming or heating
the room.
Do not use the oven, warmer drawer or lower
oven (if equipped) for storage.
Definitions
• User servicing—Do not repair or replace any part
ofthe appliance unlessspecifically recommended in
the manuals. All other servicing should be done only by a
qualified technician. This may reduce the risk of personal
injury and damage to the range.
Ask your dealer to recommend a qualified technician and
an authorized repair service. Know how to disconnect the
power to the range at the circuit breaker or fuse box in
case of an emergency.
• Remove the oven door from any unused range if it
is to be stored or discarded.
• Never modify or alter the construction of a range by
removingthe levelinglegs,panels, wirecovers, anti-
tip brackets/screws, or any other part of the range.
WARNING indicates a potentially hazardous
situation which, if not avoided, may result in death
or serious injury.
WARNING
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
IMPORTANT
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in minor
or moderate injury.
CAUTION
IMPORTANT indicates installation, operation,
maintenance or valuable information that is not hazard
related.
• Remove all tape and packaging before using the
range. Destroy the carton and plastic bags after
unpacking the range. Never allow children to play with
packaging material.
WARNING
Tip Over Hazard
• A child or adult can tip the
rangeand bekilled.
• Verify the anti-tip device has
been installed to floor or wall.
To check if the anti-tip bracket is installed properly, use
both arms and grasp the rear edge of range back.
Carefully attempt to tilt range forward. When properly
installed, the range should not tilt forward.
Refer to the anti-tip bracket installation instructions
supplied with your range for proper installation.
• Ensure the anti-tip device is re-engaged when
the range is moved to floor or wall.
• Do not operate the range without the anti-tip
device in place and engaged.
• Failure to follow these instructions can result in
death or serious burns to children and adults.
Range
leveling leg Anti-Tip
bracket

4
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
• Do not store items of interest to children in the
cabinets above a range or on the backguard of
the range. Children climbing on the range to reach
items could be seriously injured.
• Do not touch surface heating units or surface
cooking elements, areas near these units or
elements, or interior surface of the oven. Both
surface heating and oven heating elements may be hot
even though they are dark in color. Areas near surface
cooking units may become hot enough to cause burns.
During and after use, do not touch, or let clothing or
other flammable materials touch these areas until they
have had sufficient time to cool. Among these areas
are the cook top, surfaces facing the cook top, the
oven vent openings and surfaces near these openings,
oven door and oven door window.
• Wear proper apparel—loose-fitting or hanging
garments should never be worn while using the
appliance. Do not let clothing or other flammable
materials contact hot surfaces.
• Do not use water or flour on grease fires—
smother the fire with a pan lid, or use baking soda,
a dry chemical or foam-type extinguisher.
• When heating fat or grease, watch it closely. Fat
or grease may catch fire if allowed to become too hot.
• Use dry potholders - moist or damp potholders on
hot surfaces may result in burns from steam. Do
not let potholders touch hot heating elements. Do not use
a towel or other bulky cloth instead of a potholder.
• Do not heat unopened food containers - buildup of
pressure may cause container to burst and result
ininjury.
IMPORTANT INSTRUCTIONS FOR USING
YOUR OVEN
• Use care when opening oven door , lower oven
door or warmer drawer (if equipped)—Stand to the
side of the range when opening the door of a hot oven.
Let hot air or steam escape before you remove or replace
food in the oven.
• Keep oven vent ducts unobstructed. The oven vent
is located under the left rear surface element if your
model is equipped with coil elements. The oven vent is
located below the backguard for models equipped with
ceramic-glass cook tops. Touching the surfaces in this
area when the oven is operating may cause severe
burns. Also, do not place plastic or heat-sensitive items
on or near the oven vent. These items could melt or
ignite.
• Placement of interior oven racks. Always place oven
racks in desired location while oven is cool. If rack must
be moved while oven is hot use extreme caution. Use
potholders and grasp the rack with both hands to
reposition. Do not let potholders contact the hot heating
elements in the oven. Remove all utensils from the rack
before moving.
• Do not use the broiler pan without its insert. The
broiler pan and its insert allow dripping fat to drain and
be kept away from the high heat of the broiler. Do not
coverthe broilerinsertwith aluminumfoil. Exposed
fat and grease could ignite.
• Protective liners—Do not use aluminum foil to line the
oven bottom. Only use aluminum foil as recommended in
this manual. Improper installation of these liners may
result in risk of electric shock, or fire.
Do not attempt to operate the range during a
power failure. If the power fails, always turn off the
range. If the range is not turned off and the power
resumes, the range will begin to operate again. Once the
power resumes, reset the clock and oven function.
IMPORTANT
• DONOTLEAVECHILDREN ALONE —children
should not be left alone or unattended in the
area where appliance is in use. They should never
be allowed to sit or stand on any part of the appliance,
including the storage drawer, lower broiler drawer,
warmer drawer or lower double oven.
• Storagein oron appliance—flammablematerials
should not be stored in an oven, warmer
drawer, near surface units or in the storage
drawer. This includes paper, plastic and cloth items,
such as cookbooks, plasticware and towels, as well as
flammable liquids. Do not store explosives, such as
aerosol cans, on or near the range.
WARNING

5
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT INSTRUCTIONS FOR USING
YOUR COOKTOP
• Know which knob controls each surface heating
unit. Place a pan of food on the unit before turning it on,
and turn the unit off before removing the pan.
• Use proper pan size—This appliance is equipped with
one or more surface units of different sizes. Select
utensils having flat bottoms large enough to cover the
surface unit heating element. The use of undersized
utensils will expose a portion of the heating element to
direct contact and may result in ignition of clothing.
Proper relationship of utensil to element will also improve
efficiency.
• Utensil handles should be turned inward and not
extend over adjacent surface elements—To reduce
the risk of burns, ignition of flammable materials, and
spillage due to unintentional contact with the utensil, the
handle of the utensil should be positioned so that it is
turned inward, and does not extend over adjacent
surface units.
• Never leave surface elements unattended at high
heat settings—Boilovers cause smoking and greasy
spillovers that may ignite, or a pan that has boiled dry
may melt.
• Do not immerse or soak removable heating
elements—Heating elements should never be immersed
in water. Heating elements clean themselves during
normal operation.
•Glazed cooking utensils—Only certain types of glass,
glass/ceramic, ceramic, earthenware, or other glazed
utensils are suitable for cook top service without breaking
due to the sudden change in temperature. Check the
manufacturer’s recommendations for cook top use.
• When flaming foods under a ventilating hood, turn
the fan on.
IMPORTANTINSTRUCTIONSFORCLEANING
YOUR RANGE
•Clean the range regularly to keep all parts free of
grease that could catch fire. Pay particular attention
to the area around each surface element. Do not allow
grease to accumulate.
• Kitchen cleaners and aerosols—Always follow the
manufacturer’srecommended directionsfor use.
Be aware that excess residue from cleaners and aerosols
may ignite causing damage and injury.
•Clean ventilatinghoods frequently—Grease should
not be allowed to accumulate on the hood or filter.
Follow the manufacturer’s instructions for cleaning hoods.
IMPORTANT SAFETY NOTICE
The California Safe Drinking Water and Toxic Enforcement
Act requires the Governor of California to publish a list of
substances known to the state to cause cancer, birth
defects or other reproductive harm, and requires
businesses to warn customers of potential exposure to such
substances.
SELF-CLEANING OVENS
• Clean in the self-cleaning cycle only the parts
listed in this Use & Care Manual. Before self-cleaning
the oven, remove the broiler pan and any utensils or
foods from the oven.
• Do Not Use Oven Cleaners—No commercial oven
cleaner or oven liner protective coating of any kind should
be used in or around any part of the oven.
• Do Not Clean Door Gasket—The door gasket is
essential for a good seal. Care should be taken not to
rub, damage or move the gasket.
•The health of some birds is extremely sensitive to the
fumes given off during the self-cleaning cycle of any
range. Move birds to another well-ventilated room.
COIL COOK TOP MODELS
•MakeSureReflector Pans or DripBowlsAreinPlace—
Absence of these pans or bowls during cooking may subject
wiring or components underneath to damage.
•ProtectiveLiners—Do not usealuminum foilto line surface
unit drip bowls, or reflector pans. Only use aluminum foil as
recommended in this manual. Improper installation of these
liners may result in risk of electric shock, or fire.

6
The features shown for your appliance may
vary according to model type & color.
APPLIANCE FEATURES
NOTE
8
9
10
13
15
14
18
20
21
22
12
Your electric range features include:
1. Electronic oven control with kitchen timer.
2. Left front single element control.
3. Left rear single element control.
4. Right rear single element control.
5. Right front single element control.
6. Element On indicator light(s).
7. Oven interior light switch.
8. Oven interior light with removable cover (some
models).
9. Automatic oven door light switch (some models).
10. Self-cleaning oven interior.
11. Self-clean door latch.
12. Adjustable interior oven rack(s).
13. Large 1-piece oven door handle.
14. Full width oven door (styles vary by model).
15. Storage drawer with integrated handle (some models)
or cover panel (some models).
16. Easy to clean upswept coil element cooktop.
17. 6” single element(s).
18. 8” single element(s).
19. Removable element drip bowls (some models).
20. Broil pan (some models).
21. Broil pan insert (some models).
22. Leveling legs and anti-tip bracket (included).
1
2 3 4 5
6
6
11
16
16
17
17
18
19
19
19
19
7

7
Types of oven racks
Your range may be equipped with one or more of the
following oven rack styles shown.
BEFORE SETTING OVEN CONTROLS
Oven vent location
The oven vent is located under the left rear surface
element (See Fig. 1). When the oven is on, warm air
passes through the vent. This venting is necessary for
proper air circulation in the oven and good baking results.
Do not block the oven vent.
flat
oven rack
flat handle
oven rack
bottom
oven rack
offset
oven rack
Fig. 2
The flat oven rack (some models) or flat handle oven
rack (some models) may be used for most cooking needs.
The offset oven rack (some models) is designed to place
the base of the rack about 1/2 of a rack position lower than
normal. This rack design provides several additional
possible positions between the standard postions.
To maximize oven cooking space place the bottom oven
rack (some models) in the lowest rack position for baking
and when roasting large cuts of meat.
Removing, replacing & arranging oven
racks
To remove - pull the rack forward until it stops. Lift up
front of rack and slide out.
To replace - fit the rack onto the guides on the oven walls.
Tilt the front of the rack upward and slide the rack back into
place.
Arranging - always arrange the oven racks when the oven
is cool (prior to operating the oven).
Fig. 1
6
5
4
3
2
1
7
Recommended rack positions by food type
Food type Position
(See Fig. 2)
Broiling meats See broil section
Cookies, cakes, pies, biscuits & muffins 3 or 4
Frozen pies, angel food cake, yeast,
bread, casseroles 2 or 3
Small cuts of meat or poultry 2 or 3
Turkey, roast or ham 2
Always use oven mitts when using the oven. When
using the appliance, the oven, oven racks and cooktop
will become VERY HOT which can cause burns.
CAUTION

8
BEFORE SETTING OVEN CONTROLS
Air circulation in the oven
For best baking results allow 2-4" (5-10 cm) around the
cookware for proper air circulation and be sure pans and
cookware do not touch each other, the oven door, sides or
back of the oven cavity. Hot air must be able to circulate
around the pans and cookware in the oven for even heat to
reach around the food.
Fig. 1 Fig. 2
Using proper cookware
The size and type of cookware used will influence the
setting needed for best cooking results. Be sure to
follow the recommendations for using proper
cookware as illustrated in Figs. 3 & 4.
Cookware should have flat bottoms that make good
contact with the entire surface heating element . Check
for flatness by rotating a ruler across the bottom of the
cookware (See Fig. 3).
Fig. 4
Fig. 3
Baking layer cakes with 1 or 2 oven racks
For best results when baking cakes using 2 flat oven racks,
place cookware on rack positions 2 & 5 (See Fig. 1). For
best results when using a single oven flat rack, place
cookware on rack positions 2, 3 or 4 (See Fig. 2).
BEFORE SETTING SURFACE CONTROLS
• Flat bottom and straight
sides.
• Tight fitting lids.
•Weight of handle does not
tilt cookware. Cookware is
well balanced.
• Cookware size matches the
amount of food to be
prepared and the size of
the surface element.
• Made of material that
conducts heat well.
• Easy to clean.
• Always match cookware
bottom to element
diameter.
• Curved and warped pan
bottoms.
• Cookware overhangs element
by more than 1/2” (1.27 cm).
• Cookware is smaller than
element.
• Cookware weight is not
balanced.

9
Cookware material types
The cookware material determines how evenly and quickly
heat is transferred from the surface element to the pan
bottom. The most popular materials available are:
Aluminum - Excellent heat conductor. Some types of food
will cause it to darken (Anodized aluminum cookware
resists staining & pitting).
Copper - Excellent heat conductor but discolors easily (See
Aluminum).
Stainless - Slow heat conductor with uneven cooking
results. Is durable, easy to clean and resists staining.
Cast Iron - A slow heat conductor however will retain heat
very well. Cooks evenly once cooking temperature is
reached.
Porcelain-enamel onmetal - Heating characteristics will
vary depending on base material.
Glass - Slow heat conductor.
BEFORE SETTING SURFACE CONTROLS
Element ON indicator light(s)
Your range is equipped with one or more Element On
indicator light(s) that will glow on your range.
The Element On indicator light is located on the control
panel just above the surface control knobs (See Fig. 1) and
will glow when a surface element is turned ON. A quick
glance at this indicator light after cooking is an easy check
to be sure ALL surface controls are turned OFF.
Home Canning
Be sure to read and observe all the following points when
home canning with your appliance. Check with the USDA
(United States Department of Agriculture) website and be
sure to read all the information they have available as well
as follow their recommendations for home canning
procedures.
• Use only quality flat bottom canners when home canning.
Use a straight-edge to check canner bottom (see
“Cookware material types” in the Before setting
surface controls section).
• Use only a completely flat bottom canner with no
ridges that radiate from the bottom center when home
canning using a ceramic cooktop.
• Make sure the diameter of the canner does not
exceed 1 inch beyond the surface element
markings or burner. It is recommended to use smaller
diameter canners on electric coil and ceramic glass
cooktops.
• Start with hot tap water to bring water to boil more
quickly.
• Use the highest heat seating when first bringing the water
to a boil. Once boiling is achieved, reduce heat to lowest
possible setting to maintain that boil.
IMPORTANT
NEVER place or straddle a cooking utensil over 2 different
surface cooking elements at the same time. This can
cause uneven heating results. This can also cause the
ceramic cooktop to fracture (for Ceramic cooktop models
only).
Fig. 1

10
Operating surface elements
To operate surface elements:
1. Place correctly sized cooking utensil on surface
element.
2. Push in and turn the surface control knob in either
direction to the desired setting. Start most surface
cooking on a higher setting and then turn to a lower
setting to finish. The surface control knobs do not have
to be set exactly on a particular spot. Use the panel
graphics provided as a guide and adjust the control
knob as needed (Fig. 1). Each surface element provides
a constant amount of heat at each setting. For more
information see the Suggested surface element
settings table (Fig. 2).
3. When cooking is complete, turn the surface element
OFF before removing the cookware.
The suggested settings table provided below are based
when cooking with medium-weight aluminum pans with
lids. Settings may vary when using other types of pans.
Suggested surface element settings
NOTES
IMPORTANT
Donotallowaluminumfoil,or ANY material that can
melt to make contact with the surface element.
SETTING SURFACE CONTROLS
Fig. 1
CAUTION
• Surface elements may appear to have cooled after
they have been turned off. The element surface
may still be hot and burns may occur if the element
or the area surrounding the element is touched before
it has cooled sufficiently.
•Do not place flammable items such as plastic salt
and pepper shakers, spoon holders or plastic
wrappings on top of the range when it is in use. These
items could melt or ignite. Potholders, towels or
wooden spoons could catch fire if placed too close to
the surface elements.
•Protective liners—Do not use aluminum foil to line
surface drip bowls, or reflector pans. Improper
installation of these liners may result in risk of electric
shock, or fire. Only use aluminum foil as
recommended in this manual.
• The Element On indicator light(s) will glow when one
or more surface elements are turned ON. A quick
glance at this indicator light when finished cooking on
the cooktop is an easy check to be sure all surface
controls are turned OFF.
• The size and type of utensil used, and the amount and
type of food being cooked will influence the setting
needed for best cooking results.
Suggested surface element settings table
Settings Typeof cooking
High (HI - 9) Start most foods, bring water to a
boil, pan broiling
Medium high (7 - 8) Continuea rapidboil, fry,deep fat fry
Medium (5 - 6) Maintain a slow boil, thicken sauces
and gravies or
steam vegetables
Medium Low (2 - 4) Keep foods cooking, poach, stew
Low (LO - 1) Keep warm, melt, simmer
Fig. 2

11
OVEN CONTROL FUNCTIONS
READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN.
For satisfactory use of your oven, become familiar with the various keypad functions of the oven as described below.
Please Note: The time of day must first be set in order to properly operate the oven.
Broil — Use to select the
variable Broil feature. Up and down arrow keypads—
Use along with the function pads to
select oven temperature, , time of
day, clean time and minute timer.
Bake — Use to select the
bake feature.
Clean — Use to
select the self-
cleaning cycle. A 2
or 3 hour self-clean
time may be
selected.
Oven, Preheat & Door Locked indicator lights — The "Oven" light will glow each time
the oven turns on to maintain the set oven temperature. The "Preheat" light will glow when
the oven is first set to operate, or if the desired temperature is set higher than the actual
oven temperature. The "Door Locked" light will flash when the oven door locks and unlocks
or when using Self-clean (Clean) or the oven door lockout is activated. The indicator light will
glow constantly after the door locks.
Feature indicator lights—
These light to show which
feature is in use.
Clock Set —
Use to set
the time of
day.
Clear/Off PAD— Use to
clear any function
previously entered except
the time of day and
minute timer. Press
Clear/Off to stop
cooking. Also the Clear/
Off pad is used to
activate oven lockout
feature.
Timer On/Off— Use
to set or cancel the
minute timer. The
minute timer does not
start or stop cooking.
Also,
Timer On/Off pad is
used to set the
continuous bake
feature.

12
SETTING OVEN CONTROLS
1. Press .
2. Press the to increase the time in one minute
increments. Press and hold the to increase the time
in 10 minute increments. The timer can be set for any
amount of time from 1 minute to 11 hours and 59
minutes.
If the pad is pressed first, the minute timer will
advance to 11 hours and 59 minutes.
3. When the set time has run out, the timer will beep 3
times and will continue to beep 3 times every 60
seconds until is pressed.
To make changes to the timer while it is in use:
While the timer is active and shows in the display, press
and hold the or to increase or decrease the
time remaining.
Changing between the temperature display
modes (°F or °C)
The electronic oven control is set to display in Fahrenheit
(°F) from the factory.
To change the temperature to display °C (Celsius) or
from °C to °F (control should not be set for Bake or
Self-clean when setting this feature):
1. Press . "— —" appears in the display.
2. Press and hold until "HI" appears in the display.
3. Press and hold until F or C appears in the
display.
4. Press the or to switch between the display
modes (°F to °C or °C to °F).
5. Press any control keypad to return to normal operating
mode.
To set the timer:
The minute timer serves as an extra timer in the kitchen
that will beep when the set time has run out. The timer can
be used alone or while using other oven features. When
the timer is active, to briefly view information for any other
active feature, press the keypad for that feature.
Timer
Setting the clock
When the appliance is first powered up or when the power
supply to the appliance has been interrupted, the display
will flash "12:00". The time of day must first be set in order
to properly operate the oven.
NOTES
To set the clock:
1. Press once (do not hold keypad down).
2. Within 5 seconds, press and hold the or until
the correct time of day appears in the display.
• The clock cannot be changed when self-clean is active.
• (Some models) To turn the clock OFF or ON in the
display press and hold for 15 seconds (acceptance
tone will sound) and then release. This feature does
not remove the set time of day from the memory of the
control. When the display is turned OFF the time of day
will reappear for a few seconds any time the pad
is touched.
Changing between continuous bake
setting or 12-Hour Energy Saving feature
The oven control has a built-in 12-Hour Energy Saving
feature that will shut off the oven if the control is left on for
more than 11 hours and 59 minutes. The oven can be
programmed to override this feature for continuous baking.
Changingto continuousbake setting:
1. Press and hold for 5 seconds until acceptance
tone sounds, " — — hr" will appear in display for
continuous cooking. The current time of day will return
to the display.
2. To cancel the continuous bake setting, press and hold
for 5 seconds until acceptance tone sounds.
"12hr" will appear in display indicating that the control
has returned to the 12-Hour Energy Saving feature.

13
NOTES
NOTES
Setting oven lockout
The oven control may be programmed to lock
the oven door and lockout the oven control
keypadfunctions.
To set the oven lockout feature:
1. Press and hold for 3 seconds. “Loc” will appear
in display, the “Door Locked” indicator light will flash
and the motor driven door lock will begin to close
automatically. Allow about 15 seconds for the oven
door to lock. Once the oven door is locked, the current
time of day will appear in the display.
2. To cancel oven lockout feature, press and hold
for 3 seconds. The control will unlock the oven door
and resume normal oven operations.
SETTING OVEN CONTROLS
Setting bake
The oven may be programmed to bake at any temperature
from 170°F to 550°F (77°C to 287°C). The factory preset
automatic bake temperature is 350°F (177°C).
To set bake:
1. Press . "— — —" appears in the display.
2. Within 5 seconds, press the or . The display
will show "350°F (177°C)." By pressing and holding
the or , the temperature can then be adjusted
in 5°F increments (1°C if the control is set to display
Celsius).
3. As soon as the or pad is released, the oven
will begin heating to the selected temperature. When
the displayed temperature reaches the desired baking
temperature, the preheat indicator light will turn OFF.
4. To cancel bake, press .
To change the oven temperature after bake has
started:
1. Press . Visually check the set bake temperature.
2. Press the keypad to increase or keypad to
decrease the set temperature to the desired new oven
temperature.
• The indicator light located above the pad will glow
while the timer is active.
• The timer will display hours and minutes until 1 hour
remains. Once less than 1 hour remains, the timer will
count down in minutes and seconds. Once the timer has
less than 1 minute remaining only seconds will display.
• The timer does not start or stop the cooking process.
•DO NOT open the oven door while the “Door Locked”
indicator light is flashing. Allow about 15 seconds for the
oven door to completely finish locking. Once the oven
door is locked, the current time of day will appear in
the display.
• If any control keypad is pressed when the oven lockout
feature is active, “Loc” will appear in the display until
the control keypad is released. This indicates that the
oven lockout feature is still active.
The oven indicator light on the electronic display will
turn ON and OFF when using the Bake feature and when
preheating. This is normal and indicates that the oven is
cycling to maintain the selected baking temperature.
When the preheat indicator light turns OFF (the control
will beep 3 times) your oven is ready.
NOTE
Dark or dull pans absorb more heat than shiny
bakeware resulting in dark or overbrowning of foods. It
may be necessary to reduce the oven temperature or
cook time to prevent overbrowning of some foods. Dark
pans are recommended for pies. Shiny pans are
recommended for cakes, cookies and muffins.
IMPORTANT
To cancel the timer before the set time has run out:
Press once .

14
SETTING OVEN CONTROLS
To set broil:
1. Arrange the oven rack while oven is still cool.
2. Press . " — — "will appear in display.
3. Press and hold the or until the desired broil
setting level appears in the display. Press the for HI
broil or the for LO broil. Most foods may be broiled
at the HI broil setting. Select the LO broil setting to
avoid excess browning or drying of foods that should be
cooked to the well-done stage.
4. For optimum results, preheat oven for 5 minutes
beforeadding food.
5. Place insert on the broil pan (if equipped), then place
the food on broil pan insert (if equipped - See Fig. 2).
6. Place the broiler pan and insert on the desired oven
rack (Refer to Fig. 1).
7. Open the oven door to the broil stop position when
broiling.
8. Broil on one side until food is browned. Turn and broil
food on other side.
9. When finished broiling press .
Use the broil feature to cook meats that require direct
exposure to radiant heat for optimum browing results.
When broiling always remember to arrange the oven
racks while oven is still cool. Position the rack as
suggested in the broil settings table (See Figs. 1 & 3).
Setting broil
Suggested broil settings table
Food Rack position Setting Cook time in minutes
1st side 2nd side Doneness
Steak 1” thick 5th or 7th* Hi 6 4 Medium
Steak 1” thick 6th or 7th* Hi 7 5 Medium-well
Steak 1” thick 6th or 7th* Hi 8 7 Well
Pork chops 3/4” thick 6th Hi 8 6 Well
Chicken-bone in 5th Lo 20 10 Well
Chicken-boneless 6th Lo 8 6 Well
Fish 6th Hi 13 n/a Well
Shrimp 5th Hi 5 n/a Well
Hamburger 1” thick 7th* Hi 9 7 Medium
Hamburger 1” thick 6th Hi 10 8 Well
Insert
Broil pan
Fig. 1
Fig. 3
Fig. 2
NOTE
Always pull the oven rack out to the oven rack stop
position before turning or removing the food.
*Use the off-set rack (some models) if you choose to use oven rack position 7.
2
3
4
5
6
1
7
To insure proper results when broiling use ONLY Electrolux
Home Products, Inc. approved broil pan & insert.
CAUTION
The broiler pan and the insert (some models) allows
grease to drain and be kept away from the high heat of
the broiler. DO NOT use the pan without the insert. DO
NOT cover the insert with foil; the exposed grease could
ignite. DO NOT use the broil pan without the insert or
cover the insert with aluminum foil. The exposed fat
could ignite.
WARNING
Should an oven fire occur, close the oven door and turn
the oven OFF. If the fire continues, use a fire
extinguisher. DO NOT put water or flour on the fire. Flour
may be explosive.

15
SETTING OVEN CONTROLS
Operating the interior oven light
The interior oven light will automatically turn ON when the
oven door is opened and will turn OFF when closed.
Press the interior oven light rocker switch located on the top
left-hand control panel to turn the interior oven light ON and
OFF whenever the oven door is closed.
Your appliance has been factory calibrated and tested to
ensure an accurate baking temperature. For the first few
uses, follow your recipe times and temperature
recommendations carefully. If you think the oven is cooking
too hot or too cool for your recipe times, you can adjust the
control so the oven cooks hotter or cooler than the
temperature displayed.
To adjust oven temperature:
1. Press .
2. Set the temperature to 550°F (287°C) by pressing and
holding the keypad.
3. Within 2 seconds, press and hold until the 2 digit
display appears. Release the keypad. The display
now indicates the amount of degrees offset between
the original factory temperature setting and the current
temperature setting. If the oven control has the original
factory calibration, the display will read "0."
4. The temperature can now be adjusted up or down 35°F
(19°C), in 5°F increments by pressing and holding the
or . Adjust until the desired amount of offset
appears in the display. When lowering the oven
temperature, a minus sign (-) will appear before the
number to indicate that the oven will be cooler by the
displayed amount of degrees.
5. When you have made the desired adjustment, press
to go back to the time of day display.
Adjusting the oven temperature
NOTES
• Oven temperature adjustments made will not affect the
broil or self-cleaning feature temperatures.
• If the display is set for Celsius, adjustments made will
be in 1°C increments each press of the or
keypads.
•DO NOTUSE oven thermometers such as those found
in grocery stores to check the temperature settings
inside your oven. These oven thermometers may vary
as much as 20 to 40 degrees from actual
temperatures.
The interior oven light is located on the upper left rear wall
of the oven interior and is covered with a glass shield held
by a wire holder. The glass shield must be in place
whenever the oven is in use.
To change the oven light bulb, see "Changing and replacing
the interior oven light" in the Care & Cleaning section.
interior oven
light switch

16
SELF-CLEANING
Preparing for a self-clean cycle
A self-cleaning oven cleans itself with high temperatures
(well above normal cooking temperatures) which eliminate
soils completely or reduces them to a fine powdered ash
you can wipe away with a damp cloth.
Adhere to the following self-clean precautions:
• DO NOT use oven cleaners or oven protective
coatings in or around any part of the oven interior.
• DO NOT clean the oven door gasket (See Fig. 1). The
woven material of the oven door gasket is essential
for a good seal. Care should be taken not to rub,
damage or remove the gasket.
• DO NOT use any cleaning materials on the oven door
gasket. Doing so could cause damage.
• Remove the broiler pan and insert, all utensils
andANYALUMINUMFOIL.Theseitemscannot
withstandhigh cleaning temperaturesand will
melt.
• Completelyremove ALL OVENRACKS and ANY
ACCESSORIES. If the oven racks are not
removed they will loose their special coating
properties and no longer slide in and out of the
oven cavity easily.
• Remove any excessive spillovers. Any spills on
the oven bottom should be wiped-up and removed
before starting the self-cleaning cycle. To clean, use
hot, soapy water and a cloth. Large spillovers can
cause heavy smoke or fire when subjected to high
temperatures. DO NOT allow food spills with a high
sugar or acid content (such as milk, tomatoes,
sauerkraut, fruit juices or pie filling) to remain on the
surface as they may leave a dull spot even after
cleaning.
•Clean any soil from the oven frame, the door liner
outside the oven door gasket and the small area at
the front center of the oven bottom. These areas
heat sufficiently to burn soil on. Clean with soap and
water. These areas are shown in white (See Fig. 1).
Fig. 1
•During the self-cleaning cycle, the outside of the
range can become very hot to the touch. DO NOT
leave small children unattended near the appliance.
•The oven bake and broil elements may appear to
have cooled after they have been turned OFF. The
elements may still be hot and burns may occur if
these elements are touched before they have cooled
sufficiently.
• DO NOT force the oven door open. This can damage
the automatic door locking system. Use caution when
opening the door after the Self-cleaning cycle is
completed. The oven may still be VERY HOT.
•The health of some birds is extremely sensitive to the
fumes given off during the Self-cleaning cycle of any
range. Move birds to another well-ventilated room.
CAUTION
IMPORTANT

17
1. Be sure the clock displays the correct time of day.
2. Press . “---” appears in the display.
3. Press the or keypad once. “3:00” will appear in
the display indicating that a 3 hour self-clean time is
set. To change to a 2 hour self-clean time press
keypad (2:00 will appear in the display).
As soon as the controls are set, the motor driven door
lock will begin to close automatically and the “LOCK”
indicator light will flash. DO NOT open the oven door
while the light is flashing (it takes about 15 seconds for
the oven door to lock).
Stopping or interrupting a self-clean cycle
If it becomes necessary to stop or interrupt a self-
cleaning cycle once it has been activated:
1. Press .
2. Once the oven has cooled down for about 1 HOUR and
the "LOCK" light has turned off, the oven door can be
opened.
3. Restart the self-clean cycle once all conditions have
been corrected.
NOTE
Setting a self-clean cycle
When the self-clean cycle has completed:
1. The time of day will appear in the display window and
the “Clean” and "LOCK" light will continue to glow.
2. Once the oven has cooled down for about 1 HOUR and
the "LOCK" light has gone out, the oven door can be
opened.
4. "CLn" will appear in the display during the self-clean
cycle and the "LOCK" light will glow until the self-
cleaning cycle is complete or cancelled and the oven
temperature has cooled.
Starting a self-clean cycle:
SELF-CLEANING
(Models with exposed lower
bake element only)
(For models with an exposed lower bake element ONLY)
The bake element may be tilted up using your hand from
the front of the bake element to clean or remove spills
from oven bottom if needed. Remove the bottom rack
before raising the element. Do not to raise the element
more than 4 or 5 inches from the resting position.
NOTE
NOTES
• Whenever the self-clean feature is active you may
check the amount of time remaining in the self-clean
cycle by pressing the keypad. Remember the
range door cannot be opened until the range has
cooled sufficiently. You will need to add about 1
hour to the remaining time displayed before you can
use the range for cooking.
• When the oven is cool, wipe away any residue or
powdered ash with a damp cloth or paper towel.
CAUTION
• To avoid possible burns use care when opening the
oven door after the self-cleaning cycle. Stand to the
side of the oven when opening the door to allow hot
air or steam to escape.
•DO NOT force the oven door open. This can damage
the automatic door locking system. Use caution and
avoid possible burns when opening the door after the
self-cleaning cycle has completed. The oven may still
beVERY HOT.

18
CARE & CLEANING
•Chrome control panel (some models)
•Decorative trim (some models)
Surface type Recommendation
•Porcelainenamel broiler pan and broiler
pan insert (if equipped)
•Door liner & body parts
Use hot, soapy water and a cloth. Dry with a clean cloth.
For general cleaning , use hot, soapy water and a cloth. For more
difficult soils and built-up grease , apply a liquid detergent directly onto
the soil. Leave on soil for 30 to 60 minutes. Rinse with a damp cloth
and dry. Do not use abrasive cleaners on any of these materials;
they can scratch. To remove control knobs, turn to the OFF position;
grasp firmly and pull straight off the shaft. To replace knobs after
cleaning, line up the flat sides of both the knob and the shaft; then
push the knob into place.
Before cleaning the control panel, turn all controls to OFF and remove
the control knobs. To remove, pull each knob straight off the shaft.
Clean using hot, soapy water and a dishcloth. Rinse with a clean
water using a dishcloth. Be sure to squeeze excess water from the
cloth before wiping the panel; especially when wiping around the
controls. Excess water in or around the controls may cause damage to
the appliance.To replace knobs after cleaning, line up the flat sides of
both the knob and the shaft; then push the knob into place.
•Paintedand plasticcontrol knobs
•Painted body parts
•Painteddecorative trim
•Aluminum(trim pieces) &vinyl
Gentle scouring with a soapy scouring pad will remove most spots.
Rinse with a 1:1 solution of clear water and ammonia. If necessary ,
cover difficult spots with an ammonia-soaked paper towel for 30 to 40
minutes. Rinse with clean water and a damp cloth, and then scrub
with a soap-filled scouring pad. Rinse and wipe dry with a clean cloth.
Remove all cleaners or the porcelain may become damaged during
future heating. Do not use spray oven cleaners on the cooktop.
•Oven racks
•Oven door
Oven racks must be removed from oven cavity. Clean by using
a mild, abrasive cleaner following manufacturer's instructions. Rinse
with clean water and dry.
Use soap & water to thoroughly clean the top, sides and front of the
oven door. Rinse well. You may use a glass cleaner on the outside
glass of the oven door. Do not immerse the door in water. Do not
spray or allow water or the glass cleaner to enter the door
vents. Do not use oven cleaners, cleaning powders or any harsh
abrasive cleaning materials on the outside of the oven door.
Do not clean the oven door gasket. On Self-cleaning models the oven
door gasket is made of a woven material which is essential for a good
seal. Care should be taken not to rub, damage or remove this gasket.
See “Surface elements and drip bowls” in the Care & Cleaning
section.
•Surfaceelements and drip bowls
Cleaning recommendation table
Clean heavier soils from stainless steel with hot soapy water &
dishcloth. Rinse with clean water and a cloth. Finish buffing with a
stainless steel cleaner that is especially made for stainless steel. DO
NOT use cleaners with high concentrations of chlorides or chlorines. DO
NOT use harsh scrubbing cleaners. Always be sure to wipe up any left
over cleaner from the surface as bluish stains may occur during heating
that cannot be removed.
•Stainless steel (some models)

19
CARE & CLEANING
Surface elements and drip bowls
To remove the surface elements and drip bowls:
1. Lift the edge of the drip bowl across from the terminal end.
Liftthesurface elementanddripbowl togetherjust
enough to clear the cooktop.
2. While holding the drip bowl and surface element, gently
pull the terminal end out from the terminal plug. If
equipped,DONOTremovethehold down clipfromthedrip
bowl.
Surface elements can be unplugged and removed to make
cleaning the drip pans easier. The surface elements clean
themselves when they are turned on. Food spilled on a hot
element will burn off. Food spilled on a COOL element may
be cleaned with a damp cloth—any remaining soil will burn
off the next time the element is used.
CAUTION
•Make sure drip bowls are in place - Absence of
these bowls during cooking may subject wiring or
components underneath to damage.
•Never immerse a surface element in water.
• Be sure the range is cool before removing surface
elements or drip bowls. Be careful not to bend terminal
ends when replacing surface elements after cleaning.
Cleaningdripbowls
Wash in hot, soapy water or in the dishwasher. Rinse and
dry while still warm. Hard to remove, burned on soil can be
removed by soaking the drip bowls for about 20 minutes in
a lightly diluted liquid cleanser or a solution of ammonia and
water (1/2 cup ammonia to 1 gallon of water). A nylon
scrubber may be used after soaking. DO NOT use abrasive
cleaners or steel wool, as they will scratch the surface.
Always rinse with clean water and polish dry with a soft
cloth.
To raise the cooktop for cleaning (some models):
1. Grasp the sides and lift from the front (See Fig. 2). Lift-up
rods will support the top in a raised position. Only lift the
topfar enoughto allowthe supportrods tosnap into place.
2. Cleanunderneath using a clean clothand hot,soapy water
3. To lower the top, gently push back on each rod to release
the notched support. Hold the range top and slide the lift
rods down into the range frame.
To replace drip bowls and surface elements :
1. Slidethe terminal end on theelement throughthe opening
in the drip bowl (See Fig. 1).
2. Align the element support to rest on the rim inside the drip
bowl. If your drip bowl is equipped with a hold down clip,
align the element support opposite the terminal end with
the slot in the hold down clip, and snap into place.
3. After the element is positioned in the drip bowl, line up the
terminal end with the terminal plug as shown.
4. Hold the surface element and drip bowl together as level
as possible and firmly push the terminal end into the
terminal plug. Make sure element terminal is seated
properlyinto terminalplug. Makesure the surface element
is level to reduce the hazard of pans sliding off the
element.
CAUTION
Fig. 2
•Protective liners—Do not use aluminum foil to line
surface drip bowls, or reflector pans. Only use
aluminum foil as recommended in this manual.
Improper installation of these liners may result in risk
of electric shock, or fire.
• When lowering the lift-up range cooktop, grasp the
sides with finger-tips only. Be careful not to pinch
fingers. DO NOT drop or bend the range cooktop when
raising or lowering. This could damage the cooktop
surface.
Fig. 1

20
Changing and replacing the interior oven
light (some models)
To replace the interior oven light bulb:
1. Turn electrical power off at the main source or unplug
the range.
2. Open oven door for access to interior oven light. Once
located, press wire holder to one side to release the
glass shield (See Fig.1).
3. Replace bulb with a new 40 watt appliance bulb.
4. Replace glass shield over bulb and snap wire holder
into place.
5. Turn power back on again at the main source (or plug
the range back in).
6. The clock will then need to be set with the correct time
of day. To reset, see “Setting the Clock” in this Use &
Care Guide.
Besure therange isunplugged andall partsare COOLbefore
replacing ovenlight.Wearaleather-faced glove for protection
against possible broken glass.
CAUTION
IMPORTANT
The glass shield and wire holder must be in place
whenever the oven is in use. This shield helps protect the
appliance bulb from high temperatures.
The interior oven light bulb is located on the rear wall of the
oven and is covered with a glass shield held by a wire
holder.
Fig.1
CARE & CLEANING
