Whenyou installing AGPcard,please make surethefollowing
notice isfullyunderstood and practiced.IfyourAGPcardhas "AGP
4Xnotch"(showbelow),please make sureyourAGPcardisAGP4X
(1.5V).
Donotuse AGP2Xcard(3.3V)inthismotherboard.Itwill burnand
damagethemotherboardduetoIntel®845(E/G)/850(E)chipset
can'tsupportAGP2X(3.3V).
Example1:Diamond VipperV770 golden fingeriscompatiblewith2X/4X
mode AGPslot. It can be switched between AGP2X(3.3V)or4X(1.5V)
mode byadjusting the jumper.The factorydefaultforthiscardis2X(3.3V).
If you install thiscardinGA-8ID2003 Series(oranyAGP4Xonly)
motherboardswithoutswitching the jumperto4Xmode (1.5V),itwill burnthe
motherboard.
Example2:SomeATiRage 128 Prographics cardsmade by"PowerColor",
the graphics cardmanufacturer&someSiS305 cards,theirgolden fingeris
compatiblewith2X/4XmodeAGPslot, buttheysupport2X(3.3V)only.If you
install thiscardinGA-8ID2003 Series(oranyAGP4Xonly)motherboards,
itwill burnthe motherboard.
Note:Although Gigabyte'sAG32S(G)graphics cardisbased on ATiRage
128 Prochip,the design ofAG32S(G)iscompliancewithAGP4X(1.5V)
specification.Therefore,AG32S(G)will workfine withIntel®845(E/G)/
850(E)based motherboards.

Theauthorassumes no responsibilityforanyerrorsor
omissionsthatmay appearinthisdocumentnordoes
theauthormake acommitmenttoupdatetheinforma-
tion containedherein.
Third-partybrandsand names arethepropertyoftheir
respective owners.
Please do notremove anylabelson motherboard,this
may voidthewarrantyofthismotherboard.
Duetorapidchangeintechnology,someofthe
specificationsmightbeoutofdatebeforepublication
ofthisbooklet.

Declaration ofConformity
We,Manufacturer/Importer
(full address)
G.B.T.TechnologyTräding GMbH
AusschlagerWeg41,1F,20537 Hamburg,Germany
declarethatthe product
(description ofthe apparatus,system,installation towhichitrefers)
MotherBoard
GA-8ID2003
isinconformitywith
(referencetothe specification underwhichconformityisdeclared)
inaccordancewith89/336 EEC-EMCDirective
oEN55011 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
industrial,scientificand medical(ISM
high frequency equipment
oEN61000-3-2*
TEN60555-2
Disturbancesinsupplysystemscause
byhouseholdappliancesand similar
electricalequipment“Harmonics”
oEN55013 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
broadcastreceiversand associated
equipment
oEN61000-3-3*Disturbancesinsupplysystemscause
byhouseholdappliancesand similar
electricalequipment“Voltage fluctuations”
oEN55014 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
householdelectricalappliances,
portabletoolsand similarelectrical
apparatus
TEN50081-1Genericemission standardPart1:
Residualcommercialand lightindustry
TEN50082-1GenericimmunitystandardPart1:
Residualcommercialand lightindustry
oEN55015 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
fluorescentlampsand luminaries
Genericemission standardPart2:
Industrialenvironment
oEN55081-2
Immunityfromradiointerferenceof
broadcastreceiversand associated
equipment
Genericemission standardPart2:
Industrialenvironment
oEN55082-2
TEN55022 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
information technologyequipment
lmmunityrequirementsforhousehold
appliancestoolsand similarapparatus
oENV55104
Cabled distribution systems;Equipment
forreceiving and/ordistribution from
sound and television signals
EMCrequirementsforuninterruptible
powersystems(UPS)
oEN50091-2
oEN55020
oDINVDE0855
opart10
opart12
(ECconformitymarking)
TCEmarking
Themanufactureralsodeclares theconformityofabove mentionedproduct
withtheactualrequiredsafetystandardsinaccordance withLVD73/23 EEC
Safetyrequirementsformainsoperated
electronicand related apparatusfor
householdand similargeneraluse
oEN60950
oEN60065
Safetyofhouseholdand similar
electricalappliances
oEN60335
Manufacturer/Importer
Signature:
Name:
(Stamp)Date:January29,2003
TEN60555-3
TimmyHuang
TimmyHuang
oEN50091-1
Safetyforinformation technologyequipment
including electricalbussiness equipment
Generaland Safetyrequirementsfor
uninterruptiblepowersystems(UPS)

FCC Part15,SubpartB,Section 15.107(a)and Section 15.109
(a),Class BDigitalDevice
DECLARATIONOFCONFORMITY
PerFCC Part2Section 2.1077(a)
ResponsiblePartyName:
Address:
Phone/Fax No:
hereby declaresthattheproduct
ProductName:
Conformstothefollowing specifications:
Thisdevice complieswithpart15 oftheFCC Rules.Operation is
subjecttothefollowing twoconditions:(1)Thisdevice maynot
causeharmfuland(2)thisdevicemustacceptanyinferencereceived,
including thatmaycauseundesiredoperation.
RepresentativePerson’sName:
Signature:EricLu
SupplementaryInformation:
ModelNumber:
17358 RailroadStreet
CityofIndustry,CA 91748
G.B.T.INC.(U.S.A.)
[phone]/[phone]
Motherboard
GA-8ID2003
Date:
ERICLU
January29,2003

USER'SMANUAL
GA-8ID2003 Series
P4Titan SeriesMotherboard
Pentium®4ProcessorMotherboard
Rev.2002
12ME-8ID2003-2002

-2-
GA-8ID2003 SeriesMotherboard
English
TableofContent
ItemChecklist ..................................................................................... 4
WARNING! .......................................................................................... 4
Chapter1Introduction ......................................................................... 5
FeaturesSummary......................................................................................... 5
GA-8ID2003 SeriesMotherboardLayout ...................................................... 7
Chapter2HardwareInstallation Process .............................................. 8
Step 1:Install the CentralProcessing Unit(CPU)........................................ 9
Step 1-1:CPUInstallation ........................................................................................... 9
Step 1-2:CPUHeatSinkInstallation ......................................................................... 10
Step 2:Install memorymodules.................................................................. 11
Step 3:Install expansion cards.................................................................... 12
Step 4:Connectribbon cables,cabinetwiresand powersupply............. 13
Step 4-1:I/OBack PanelIntroduction ....................................................................... 13
Step 4-2:ConnectorsIntroduction ............................................................................. 15
Chapter3BIOSSetup ....................................................................... 27
The MainMenu (Forexample:BIOSVer.:F1)......................................... 28
StandardCMOSFeatures........................................................................... 30
Advanced BIOSFeatures............................................................................. 33
Integrated Peripherals................................................................................. 35
PowerManagementSetup .......................................................................... 39
PnP/PCIConfigurations................................................................................ 42

TableofContent
English
-3-
PCHealthStatus........................................................................................... 43
Frequency/Voltage Control........................................................................... 45
Top Performance.......................................................................................... 47
Load Fail-SafeDefaults................................................................................ 48
Load Optimized Defaults.............................................................................. 49
SetSupervisor/UserPassword..................................................................... 50
Save&ExitSetup .......................................................................................... 51
ExitWithoutSaving ....................................................................................... 52
Chapter4TechnicalReference.......................................................... 55
Block Diagram.............................................................................................. 55
@BIOS™Introduction .................................................................................. 56
EasyTune™4Introduction .......................................................................... 57
FlashBIOSMethod Introduction ................................................................. 58
Method 1:Q-Flash................................................................................................... 58
Method 2:BIOSFlashUtility................................................................................... 60
Method 3:@BIOSUtility.......................................................................................... 71
2-/4-/6-ChannelAudioFunction Introuction *.................................. 73
Chapter5Appendix.......................................................................... 81
"*"ForGA-8ID2003-Ponly

-4-
GA-8ID2003 SeriesMotherboard
English
ItemChecklist
Computermotherboardsand expansion cardscontainverydelicateIntegrated Circuit(IC)chips.To
protectthemagainstdamagefromstaticelectricity,youshouldfollowsomeprecautionswheneveryou
workon yourcomputer.
1.Unplug yourcomputerwhen working ontheinside.
2.Useagroundedwriststrapbeforehandlingcomputercomponents.Ifyoudonothaveone,touch
bothofyourhandstoasafelygrounded objectortoametalobject, suchasthe powersupply
case.
3.Holdcomponentsbythe edgesand trynottouchthe ICchips,leadsorconnectors,orother
components.
4.Placecomponentson agrounded antistaticpadoron the bag thatcamewiththecomponents
wheneverthe componentsareseparated fromthe system.
5.EnsurethattheATXpowersupplyisswitched offbeforeyou plug inorremovethe ATXpower
connectoronthemotherboard.
Ifthemotherboardhasmountingholes,buttheydon'tlineup withtheholesonthebaseandthereare
noslotstoattachthe spacers,do notbecomealarmedyou can still attachthespacerstothemounting
holes.Justcutthebottomportionofthespacers(thespacermaybe alittlehardtocutoff,sobe carefulof
yourhands).Inthiswayyou can still attachthe motherboardtothe basewithoutworrying aboutshort
circuits.Sometimesyoumayneed tousetheplasticspringstoisolatethe screwfromthe motherboard
PCBsurface,becausethe circuitwiremaybe nearbythe hole.Becareful,don'tletthe screwcontact
anyprintedcircuitwriteorpartson thePCBthatarenearthe fixinghole,otherwiseitmaydamage the
boardorcauseboardmalfunctioning.
Installing themotherboardtothechassis…
WARNING!
TheGA-8ID2003orGA-8ID2003-Pmotherboard
IDEcablex1/Floppycablex1
CD formotherboarddriver&utility
GA-8ID2003Seriesuser'smanual
I/OShield
Quick PCInstallation Guide
RAIDManual
2PortUSB Cablex1
4PortUSB Cablex1
SPDIF-KITx1(SPDIFOutKIT)
IEEE 1394 Cablex1
AudioCombo Kitx1
(SURROUND-Kit+SPDIFOutKIT)
MotherboardSettingsLabel

Introduction
English
-5-
FormFactor—19.6cmx29.5cmATXsizeformfactor,4layersPCB
Motherboard—GA-8ID2003SeriesMotherboard:
GA-8ID2003and GA-8ID2003-P
CPU—Socket478 forIntel®MicroFC-PGA2Pentium®4processor
—SupportIntel®Pentium®4(Northwood,0.13 m)processor
—SupportIntel®Pentium®4ProcessorwithHTTechnology#
—Intel®Pentium®4400/533MHzFSB
—AutodetectandoptimizedsettingforPentium®4processor
—2nd cachedependson CPU
Chipset—ChipsetIntel®845 HOST/AGP/Controller
—ICH2I/OControllerHub
Memory—3168-pinDIMM sockets
—SupportsPC-100/PC-133 SDRAM(Auto)
—Supportsonly3.3VSDRAMDIMM
—Supportsup to2GB(Max)
I/OControl—ITE8712
Slots—1AGPslot4X(1.5V)devicesupport
—5PCIslotsupports33MHz&PCI2.2compliant
On-BoardIDE—2IDEbusmaster(DMA33/ATA66/ATA100)IDEportsforupto4
ATAPIdevices
—SupportsPIOmode3,4(UDMA33/ATA66/ATA100)IDE&ATAPI
CD-ROM
On-BoardPeripherals—1Floppyportsupports2FDD with360K,720K,1.2M,1.44M
and 2.88Mbytes
—1ParallelportsupportsNormal/EPP/ECPmode
—2Serialports(COMA&COMB)
—4xUSB 1.1(2bycable)
—1FrontAudioconnector
tobe continued......
Chapter1Introduction
Features Summary

-6-
GA-8ID2003 SeriesMotherboard
English
HardwareMonitor—CPU/Systemfan revolution detect
—CPUtemperaturedetect
—CPUOverheatWarning
—Systemvoltage detect
—CPU/Systemfan fail warning
On-BoardSound —RealtekALC201**/ALC650*CODEC
—Line In/Line Out/MicIn**
—Line Out/2frontspeaker*
—Line In/2rearspeaker(bys/wswitch)*
—MicIn/center&subwoofer(bys/wswitch)*
—SPDIFOut*/SPDIFIn*
—CD_In/AUX_IN/GamePort
PS/2Connector—PS/2Keyboardinterfaceand PS/2Mouseinterface
BIOS—Licensed AWARD BIOS,2MbitFWH
—SupportsQ-Flash
AdditionalFeatures—PS/2Keyboardpasswordpoweron
—PS/2Mousepoweron
—STR(Suspend-To-RAM)
—ACRecovery
—USB KB/Mousewakeup fromS3
—Polyfuseforkeyboard,USB,gameportover-currentprotection
—Supports@BIOS
—SupportsEasyTune 4
Jumperless Overclocking —OverClock (CPU/DDR/AGP)byBIOS
Pleasesetthe CPUhostfrequency inaccordancewithyourprocessor'sspecifications.
Wedon'trecommend you tosetthe systembusfrequency overthe CPU'sspecification because
thesespecificbusfrequenciesarenotthe standardspecificationsforCPU,chipsetand mostofthe
peripherals.Whetheryoursystemcan run underthesespecificbusfrequenciesproperlywill
depend on yourhardwareconfigurations,including CPU,Chipsets,SDRAM,Cards…etc.
"#"HTfunctionalityrequirementcontent:
Enabling the functionalityofHyper-Threading Technologyforyourcomputersystemrequiresall
ofthe following platformcomponents:
-CPU:AnIntel®Pentium4ProcessorwithHTTechnology
-Chipset: AnIntel®ChipsetthatsupportsHTTechnology
-BIOS:ABIOSthatsupportsHTTechnologyand hasitenabled
-OS:Anoperation systemthathasoptimizationsforHTTechnology
"*"ForGA-8ID2003-Ponly
"**"ForGA-8ID2003 only

HardwareInstallation Process
English
-7-
2X_DET
GA-8ID2003 Series MotherboardLayout
GA-8ID2003
KB_MS
COMA
LPTGAME
LINE_IN
LINE_OUTMIC_IN
USB
ATX_12V
CD_IN
F_AU DIO
F_PANEL
BATTERY
SYS_FAN
IC H2
SOCKET478
CPU_FAN
ATX
FDD
IDE1
IDE2
ITE8712
PCI1
PCI2
PCI3
DIMM2 DIMM1
CODEC
F_USB1
COMB
DIMM3
BIOS
PCI4
PCI5
AUX_IN
CI
AGP
P4Titan
PWR_LED
Intel845
CLR_PWD
SUR_CEN*
SPDIF_IO*
"*"ForGA-8ID2003-Ponly
*

-8-
GA-8ID2003 SeriesMotherboard
English
Tosetupyourcomputer,youmustcompletethe followingsteps:
Step 1-Install the CentralProcessingUnit(CPU)
Step2-Install memorymodules
Step3-Install expansion cards
Step 4-Connectribboncables,cabinetwires,andpowersupply
Step5-Setup BIOSsoftware
Step6-Installsupportingsoftwaretools
Chapter2HardwareInstallation Process
Step2
Step4
Step4
Step1
Step4
Step3
Step1

HardwareInstallation Process
English
-9-
Step1:Install theCentralProcessing Unit(CPU)
Step1-1:CPUInstallation
Please make suretheCPUtypeissupportedbythemotherboard.
Ifyou do notmatchtheCPUsocketPin1and CPUcutedgewell, itwill cause
improperinstallation.Please changetheinsertorientation.
Angling the
rod to650
1.Anglingtherodto65-degreemaybefeela
kindoftight,andthencontinuepulltherodto
90-degreewhenanoise"cough"made.
2.Pull the rodtothe 90-degree directly.
Pin1indicator
3.CPUTop View
Pin1indicator
4.LocatePin1inthe socketand look
fora(golden)cutedge on theCPU
uppercorner.TheninserttheCPU
intothesocket.
Socket
Actuation
Lever

-10 -
GA-8ID2003 SeriesMotherboard
English
Step1-2:CPUHeatSinkInstallation
Please use Intelapprovedcooling fan.
Werecommend you toapplythethermaltapetoprovidebetterheat
conduction betweenyourCPUand heatsink.
(TheCPUcooling fanmightstick totheCPUduetothehardening ofthe
thermalpaste.During thiscondition ifyou trytoremove thecooling fan,you
mightpull theprocessoroutoftheCPUsocketalonewiththecooling fan,and
mightdamagetheprocessor.To avoidthisfromhappening,wesuggestyou to
eitheruse thermaltapeinsteadofthermalpaste,orremovethecooling fanwith
extremecaution.)
Make suretheCPUfanpowercableispluggedintotheCPUfanconnector,
thiscompletes theinstallation.
Please refertoCPUheatsinkuser'smanualformoredetail installation
procedure.
1.Hookone endofthe coolerbracket
tothe CPUsocketfirst.
2.Hookthe otherend ofthe cooler
brackettothe CPUsocket.

HardwareInstallation Process
English
-11 -
Please notethattheDIMM modulecanonlyfitinonedirection duetotheone
notch.Wrong orientation will cause improperinstallation.Please changethe
insertorientation.
SDRAM
1.The DIMMslothastwonotch,sothe
DIMM memorymodulecan onlyfitin
onedirection.
2. Insertthe DIMM memorymodule
verticallyintothe DIMM socket. Then
pushitdown.
3.Closethe plasticclipatbothedgesofthe DIMM socketstolock the DIMM module.
Reversethe installation stepswhen you wishtoremovethe DIMM module.
Step2:Install memorymodules
The motherboardhas3dualin-line memorymodule(DIMM)sockets.The BIOSwill automatically
detectsmemorytype and size.Toinstall the memorymodule,justpushitverticallyintothe DIMMSocket
.The DIMM modulecan onlyfitinone direction due tothe twonotch.Memorysizecan varybetween
sockets.

-12 -
GA-8ID2003 SeriesMotherboard
English
Step3:Install expansion cards
1.Read the related expansioncard'sinstructiondocumentbeforeinstall the expansion cardintothe
computer.
2.Removeyourcomputer'schassiscover,screwsand slotbracketfromthecomputer.
3.Press the expansion cardfirmlyintoexpansion slotinmotherboard.
4.Besurethe metalcontactsonthe cardareindeedseated inthe slot.
5.Replacethescrewtosecurethe slotbracketoftheexpansion card.
6.Replaceyourcomputer'schassiscover.
7.Poweron the computer,ifnecessary,setup BIOSutilityofexpansion cardfromBIOS.
8. Install related driverfromtheoperating system.
AGPCard
Pleasecarefullypull outthe small white-drawable
baratthe endofthe AGPslotwhenyoutrytoinstall
/uninstall the AGPcard.Pleasealign the AGP
cardtothe onboardAGPslotand press firmly
downon the slot. MakesureyourAGPcardis
locked bythe small white-drawablebar.
When an AGP2x(3.3V)cardisinstalled the 2X_DETwill lightup,indicating anon-
supported graphics cardisinserted.Informing usersthatsystemmightnotbootup normally
due toAGP2x(3.3V)isnotsupported bythe chipset.

HardwareInstallation Process
English
-13 -
Step4:Connectribbon cables,cabinetwires and
powersupply
Step4-1:I/OBack PanelIntroduction
uPS/2Keyboardand PS/2Mouse Connector
ThisconnectorsupportsstandardPS/2
keyboardandPS/2mouse.
PS/2MouseConnector
(6pinFemale)
PS/2KeyboardConnector
(6pinFemale)
u
v
wx
y
wParallelPortand SerialPorts(COMA/COMB)
Thisconnectorsupports2standardCOMports
and 1Parallelport. Devicelikeprintercan be
connected toParallelport; mouseand modem
etc.can beconnected toSerialports.
ParallelPort
(25pinFemale)
COMACOMB
SerialPort(9pinMale)
vUSBConnectorBeforeyou connectyourdevice(s)intoUSB
connector(s),pleasemakesureyourdevice(s)
suchasUSB keyboard,mouse,scanner,zip,
speaker...etc.HaveastandardUSB interface.
AlsomakesureyourOSsupportsUSBcontroller.
IfyourOSdoesnotsupportUSBcontroller,please
contactOSvendorforpossiblepatchordriver
upgrade.Formoreinformationpleasecontactyour
OSordevice(s)vendors.
USB 0
USB 1

-14 -
GA-8ID2003 SeriesMotherboard
English
xGame/MIDIPorts
yAudioConnectors
(ForGA-8ID2003 only)
Thisconnectorsupportsjoystick,MIDI
keyboardandotherrelateaudiodevices.
Afterinstall onboardaudiodriver,you may
connectspeakertoLineOutjack,microphoneto
MICInjack.DevicelikeCD-ROM,walkman
etccanbe connectedtoLine-Injack.
MICIn
Joystick/MIDI(15 pinFemale)
Line Out
Line In
AudioConnectors
(ForGA-8ID2003-Ponly)
MICIn
(Centerand Subwoofer)
Line Out
(Front
Speaker)
Line In
(RearSpeaker)
Afterinstall onboardaudiodriver,you may
connectspeakertoLineOutjack,microphone
toMICInjack.
DevicelikeCD-ROM,walkman etccan be
connected toLine-Injack.
Pleasenote:
You areabletouse2-/4-/6-channelaudio
featurebyS/Wselection.
Ifyou wanttoenable6-channelfunction,you
have2chooseforhardwareconnection.
Method1:
Connect"FrontSpeaker"to"Line Out"
Connect"RearSpeaker"to"LineIn"
Connect"Centerand Subwoofer"to"MICOut".
Method2:
Youcanrefertopage 22,andcontactyour
nearestdealerforoptionalSUR_CENcable.
Ifyou wantthedetail information for2-/4-/6-channelaudiosetup
installation,please refertopage73.

HardwareInstallation Process
English
-15 -
Step4-2:ConnectorsIntroduction
4
17
2
5
12*
10
8
716
6
14
3
11
1
18
1)ATX_12V10)BATTERY
2)ATX11)F_AUDIO
3)CPU_FAN 12)SUR_CEN*
4)SYS_FAN 13)CD_IN
5)FDD 14)AUX_IN
6)IDE1/IDE2 15)SPDIF_IO*
7)F_PANEL16)F_USB1
8)PWR_LED17)CI
9)2X_DET18)CLR_PWD
9
13
15*
"*"ForGA-8ID2003-Ponly

-16 -
GA-8ID2003 SeriesMotherboard
English
1)ATX_12V(+12VPowerConnector)
Thisconnector(ATX_12V)suppliesthe CPUoperation voltage (Vcore).If this"ATX_12Vconnector"
isnotconnected,systemcannotboot.
PinNo.Definition
1GND
2GND
3+12V
4+12V
2)ATX(ATXPower)
ACpowercordshouldonlybe connected toyourpowersupplyunitafterATXpowercableand
otherrelated devicesarefirmlyconnected tothe mainboard.
PinNo.Definition
1 3.3V
2 3.3V
3GND
4VCC
5GND
6VCC
7GND
8PowerGood
95VSB (stand by+5V)
10 +12V
11 3.3V
12 -12V
13 GND
14 PS_ON(soft on/off)
15 GND
16 GND
17 GND
18 -5V
19 VCC
20 VCC
43
21
20
111
10
