When you installing AGP card, please make sure the following notice is fully understood and
practiced. If your AGP card has "AGP 4X/8X(1.5V) notch" (show below), please make sure your
AGP card is AGP 4X/8X(1.5V).
AGP 2X(3.3V) card is not supported by VIA K8T800 chipset. You might experience system unable
to boot up normally. Please insert an AGP 4X/8X(1.5V) card.
Read Me First !
AGP 4X/8X notch

5 Read Me First
English
Installing the motherboard to the chassis…
If the motherboard has mounting holes, but they don't line up with the holes on the base and there
are no slots to attach the spacers, do not become alarmed you can still attach the spacers to the
mounting holes. Just cut the bottom portion of the spacers (the spacer may be a little hard to cut off,
so be careful of your hands). In this way you can still attach the motherboard to the base without
worrying about short circuits. Sometimes you may need to use the plastic springs to isolate the
screw from the motherboard PCB surface, because the circuit wire may be near by the hole. Be
careful, don't let the screw contact any printed circuit write or parts on the PCB that are near the
fixing hole, otherwise it may damage the board or cause board malfunctioning.
Preparing Your Computer
Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips. To
protect them against damage from static electricity, you should follow some precautions whenever
you work on your computer.
1. Unplug your computer when working on the inside.
2. Use a grounded wrist strap before handling computer components. If you do not have
one, touch both of your hands to a safely grounded object or to a metal object, such as
the power supply case.
3. Hold components by the edges and try not touch the IC chips, leads or connectors, or
other components.
4. Place components on a grounded antistatic pad or on the bag that came with the
components whenever the components are separated from the system.
5. Ensure that the ATX power supply is switched off before you plug in or remove the ATX
power connector on the motherboard.
The manufacturer assumes no liability for any damage, caused directly or indirectly, by improper
installation of any comfortable performing the installation, consult a qualified computer technician.
Damage to system components, and injury to yourself may result if power is applied during
installation.

- 6 -GA-K8VT800(Pro) Motherboard
English
Table of Content
Read Me First ! ....................................................................................... 4
Chapter 1 Introduction ............................................................................ 8
1-1 Item Check List ............................................................................ 8
1-2 Features Summary ................................................................................ 8
1-3 GA-K8VT800(Pro) Motherboard Layout ............................................. 11
1-4 Block Diagram - GA-K8VT800(Pro).................................................... 12
Chapter 2 Hardware Installation Process ............................................. 15
Step 1: Installing Processor and CPU Cooling Fan.................................. 16
Step 2: Installing Memory Modules ........................................................... 18
Step 3: Installing expansion cards ............................................................ 20
Step 3-1: AGP Card Installation..................................................................................... 20
Step 4: Connect ribbon cables, cabinet wires and power supply ............ 21
Step 4-1: I/O Back Panel Introduction........................................................................... 21
Step 4-2: Connectors Introduction ................................................................................. 23
Chapter 3 BIOS Setup ......................................................................... 39
The Main Menu (For example: BIOS Ver. : F1a) ...................................... 40
Standard CMOS Features......................................................................... 42
Advanced BIOS Features .......................................................................... 45
Integrated Peripherals .............................................................................. 47
Power Management Setup ....................................................................... 52
PnP/PCI Configurations ............................................................................. 55
PC Health Status........................................................................................ 56

Table of Content
English
- 7 -
Frequency/Voltage Control ........................................................................ 58
Load Fail-Safe Defaults ............................................................................. 60
Load Optimized Defaults ........................................................................... 61
Set Supervisor/User Password .................................................................. 62
Save & Exit Setup ....................................................................................... 63
Exit Without Saving ................................................................................... 64
Chapter 4 Technical Reference ........................................................... 67
@BIOS™Introduction ................................................................................. 67
EasyTune™4 Introduction ......................................................................... 68
Flash BIOS Method Introduction ............................................................... 69
2- / 4- / 6-Channel Audio Function Introduction ........................................ 79
Jack-Sensing Introduction......................................................................... 85
UAJ Introduction ........................................................................................ 87
Xpress Recovery Introduction ................................................................... 89
Chapter 5 Appendix ............................................................................. 97

- 8 -GA-K8VT800(Pro) Motherboard
English
1-1 Item Checklist
TheGA-K8VT800(Pro)motherboard
CD for motherboard driver & utility
The GA-K8VT800(Pro) user's manual
Quick PC Installation Guide
GigaRAID manual(1)
GC-SATA Card (optional)
(Manual; SATA cable x 1; Power cable x 1)
IDE cable x 3 / Floppy cable x 1(1)
IDE cable x 1 / Floppy cable x 1(2)
Serial ATA cable x 2
USB & IEEE 1394 Cable x 1(1)
USB Cable x 1(2)
SPDIF Out Kit x 1(1)
I/O Shield
Motherboard Settings Label
Chapter 1 Introduction
Form Factor 30.5cm x 23.0cm ATX size form factor, 4 layers PCB
CPU Socket 754 for AMD AlthlonTM 64 processor (K8)
128K L1& 256K / 512K / 1M L2 cache on die
800MHz FSB
Support core frequencies in excess of 1.6 GHz(2800+) and faster
Chipset VIA K8T800 AGP/PCI Controller (PAC)
VIA VT8237 Integrated Peripheral Controller (PSIPC)
Memory 3 184-pin DDR DIMM sockets
Supports DDR400/DDR333/DDR266 DIMM
Supports unbuffered DIMMs with a 64-bit data bus with optional 8
bits of Error Correcting Code (ECC)
Supports 128MB/256MB/512MB/1GB DRAM
Supports up to 3GB DRAM (Max)
I/O Control ITE8705
Slots 1 AGP slot supports 8X/4X mode,
AGP3.0 8X interface at 533MHz
5 PCI slots support 33MHz & PCI 2.3 compliant
1-2 Features Summary
to be continued......
(1)For GA-K8VT800 Pro only (2)For GA-K8VT800 only

Introduction
English
- 9 -
On-Board IDE 2 IDE controllers provides IDE HDD/CD-ROM (IDE1, IDE2) with
PIO, Bus Master (Ultra DMA33/ATA66/ATA100/ATA133) operation
modes
IDE3 and IDE4 compatible with RAID, Ultra ATA133/100, IDE
Hardware Monitor CPU/System fan revolution detect
CPU/System temperature detect
CPU warning temperature
System voltage detect
CPU/System fan fail warning
CPU Smart Fan control (1)
Thermal shutdown function
On-Board Peripherals 1 Floppy port supports 2 FDD with 360K, 720K,1.2M, 1.44M
and 2.88M bytes
1 Parallel port supports Normal/EPP/ECP mode
2 Serial ports (COMA & COMB)
8 USB 2.0/1.1 ports (4 x Front by cable)
3 IEEE1394 ports (by cable) (1)
1 IrDA connector for IR
1 FrontAudio connector
On-Board LAN RTL Gigabit LAN (RTL8110S)(1)
RTL 10/100 LAN (RTL8100C)(2)
1 RJ45 ports
On-Board Sound Realtek ALC658 CODEC (UAJ)
Supports Jack Sensing function
Line Out / 2 front speaker
Line In / 2 rear speaker (by s/w switch)
Mic In / center & subwoofer (by s/w switch)
SPDIF In / Out
CD In / AUX In / Game port
On-Board SATA RAID '*' Built-in VT8237
Supports Disk striping (RAID0) or DISK Mirroring (RAID1)
Supports UDMA up to 150 MB/sec.
Up to 2 SATA devices(Note)
to be continued......
(1)For GA-K8VT800 Pro only (2)For GA-K8VT800 only
'*' If you want to find the detailed information for SATA RAID setup installation,
please download the VT8237 SATA Manual from GIGABYTE’s website.
(Note) It is recommended to use SATA (1.5Gb/s) hard disks.

- 10 -GA-K8VT800(Pro) Motherboard
English
On-Board IDE RAID(1)Onboard GigaRAID IT8212F chipset
Supports data striping (RAID 0) or mirroring (RAID 1) or
striping+mirroring (RAID 0 + RAID 1)
Supports JBOD function
Supports concurrent dualATA133 IDE controller operation
Support ATAPI mode for HDD
Supports IDE bus master operation
Support ATA133/RAID mode switch by BIOS
Displays status and error checking messages during boot-up
Mirroring supports automatic background rebuilds
Features LBA and Extended Interrupt 13 drive translation in
controller onboard BIOS
On-Board IEEE1394 (1)Built-in Ti TSB43AB23
PS/2 Connector PS/2 Keyboard interface and PS/2 Mouse interface
BIOS Licensed AWARD BIOS
Supports Dual BIOS (1)
Supports Face Wizard (1)
Supports Q-Flash
Additional Features PS/2 Keyboard power on by password
PS/2 Mouse power on
External Modem wake up
STR(Suspend-To-RAM)
Wake on LAN (WOL)
AC Recovery
Poly fuse for keyboard over-current protection
USB KB/Mouse wake up from S3
Supports Thermal Shutdown function
Supports Easy Tune4
Supports @BIOS
Overclocking Over Voltage (CPU/DDR/AGP) by BIOS
Over Clock (CPU/DDR/AGP) by BIOS
Please set the CPU host frequency in accordance with your processor's specifications.
We don't recommend you to set the system bus frequency over the CPU's specification because
these specific bus frequencies are not the standard specifications for CPU, chipset and most of the
peripherals. Whether your system can run under these specific bus frequencies properly will
depend on your hardware configurations, including CPU, Chipsets, SDRAM, Cards…etc.
(1)For GA-K8VT800 Pro only

Introduction
English
- 11 -
VIA VT8237
USB
(1)For GA-K8VT800 Pro only (2)For GA-K8VT800 only
CD_IN
GA-K8VT800(Pro)
KB_MS
COMB
LPT
USB LAN
ATX_12V
SOCKET 754
CPU_FAN
IDE1
IDE2
DDR2
COMA
PWR_LED
BAT
PCI1
PCI2
PCI3
F_USB1
ITE8705
MAIN
BIOS
CODEC
PWR_FAN(1)
VIA K8T800
DDR3
PCI4
PCI5
GAME
F_AUDIO
AUX_IN
IR
IDE3(1)
GigaRAID
IT8212(1)
BACKUP
BIOS(1)
SATA1
RAM_LED
ATX
SYS_FAN
NB_FAN(1)
IDE4(1)
DDR1
SPDIF_IO
SUR_CEN
AUDIO
F_PANEL
1-3 GA-K8VT800(Pro) Motherboard Layout
F2_1394(1)
INFO_LINK
AGP
FDD
SATA0
F1_1394(1)
RTL8100C(2) RTL8110S(1)
TSB43AB23(1)
F_USB2
CLR_PWD

- 12 -GA-K8VT800(Pro) Motherboard
English
1-4 Block Diagram - GA-K8VT800(Pro)
VIA
K8T800
VIA
VT8237
CPUCLK+/- (200MHz)
AGPCLK66MHz
33 MHz
14.318 MHz
48 MHz
AGP slot
4X/8X
AGPCLK
(66MHz)
5 PCI
PCICLK
(33MHz)
AC97 Link
8 USB
Ports
ATA66/100/133
IDE Channels
CLK
GEN
CPUCLK+/- (200MHz)
AGPCLK (66MHz)
PCICLK (33MHz)
USBCLK (48MHz)
14.318 MHz
33 MHz
IT8705
24 MHz
33 MHz
Game Port
Floppy
LPT Port
COM
Ports
AC97
CODEC
MIC
LINE-IN
LINE-OUT
Dual BIOS(1)
66MHz V_Link
V_Link (66MHz)
2 SATA
Ports
AMD
AlthlonTM 64
processor (K8)
System Bus
800MHz DDR400/333/266 DIMM
DDR RAM
RJ45
RTL8110S(1)
RTL8100C(2)
LAN
TSB43AB23(1)
3 IEEE1394(1)
IDE3
(1)
IDE4
(1)
GigaRAID
IT8212(1)
(1)For GA-K8VT800 Pro only (2)For GA-K8VT800 only
PS/2
KB/Mouse

Introduction
English
- 13 -

- 14 -GA-K8VT800(Pro) Motherboard
English

Hardware Installation Process
English
- 15 -
To set up your computer, you must complete the following steps:
Step 1- Installing Processor and CPU Cooling Fan
Step 2- Installing Memory Modules
Step 3- Installing Expansion Cards
Step 4- Connect ribbon Cables, Cabinet Wires, And Power Supply
Chapter 2 Hardware Installation Process
Step 2
Step 4
Step 3
Step 4
Step 1
Step 4
Congratulations! You have accomplished the hardware installation!
Turn on the power supply or connect the power cable to the power outlet. Continue with the
BIOS/software installation.

- 16 -GA-K8VT800(Pro) Motherboard
English
Step 1: Installing Processor and Heatsink
1.1 The installation of the processor and heatsink is performed in four main steps:
Step 1-1. Processor insertion
Step 1-2. Applying thermal grease
Step 1-3. Heatsink attachment
Step 1-4. Connecting processor fan power
These steps are described in detail in the following paragraphs.
Before installing the processor and heatsink, adhere to the following warning:
1. The processor will overheat without the heatsink and/or fan, resulting in permanent
irreparable damage.
2. Never force the processor into the socket.
3. Apply thermal paste between the processor and heatsink.
4. Please make sure the CPU type is supported by the motherboard.
5. If you do not match the CPU socket Pin 1 and CPU cut edge well, it will cause improper
installation. Please change the insert orientation. Please use AMD approved cooling
fan.
Step 1-1. First, check the processor pins to see that none are bent. Move the socket lever to the
unlocked position as shown in Figure 1 & Figure 2.(90 to the plane of the motherboard) prior to
inserting the processor. The A1 pin location is designated on the processor by a copper triangle that
matches up to a triangle on the socket as shown in Figure 3. Align the processor to the socket and
gently lower it into place. Do not force the processor into the socket.
Figure 1.Angling the rod
to 65-degree maybe feel
a kind of tight , and then
continue pull the rod to 90-
degree when a noise
“cough” made.
Figure 2.Pull the rod to
the 90-degree directly.
Angling the
rod to 650Socket
Actuation
Lever
Figure 3. A1 pin location on the Socket and
Processor.Move the socket lever to the locked
position while holding pressure on the center of the
processor.

Hardware Installation Process
English
- 17 -
Step1-2. When the processor is installed in the socket, apply thermal grease to the processor(as
shown in Figure 4) prior to installing the heatsink. AMD recommends using a high thermal
conductivity grease (such as Shin-Etsu types G751 or G749, or an equivalent product) for
the thermal interface material rather than a phase change material. Phase change materials
develop strong adhesive forces between the heatsink and processor.
Removing the heatsink under such conditions can cause the processor to be
removed from the socket without moving the socket lever to the unlocked
position and then damage the processor pins or socket contacts.
** We recommend you to apply the thermal tape to provide better heat conduction between your
CPU and heatsink. (The CPU cooling fan might stick to the CPU due to the hardening of the
thermal paste. During this condition if you try to remove the cooling fan, you might pull the
processor out of the CPU socket alone with the cooling fan, and might damage the processor.
To avoid this from happening, we suggest you to either use thermal tape instead of thermal
paste, or remove the cooling fan with extreme caution.)
Figure 4. Application of Thermal Grease to the processor.
Step 1-4. Connect the fan power wires to the header on the motherboard as shown in Figure 7.
Figure 7. Connecting the Fan Power Wires
Step 1-3.Once the thermal grease has been applied to the processor, the heatsink can be attached to
the processor. Align the heatsink assembly with the support frame mating with the backer
plate standoffs as shown in Figure 5&6.
Figure 5&6 Alignment of Heatsink
Assembly with Standoffs

- 18 -GA-K8VT800(Pro) Motherboard
English
Before installing the memory modules, please comply with the following conditions:
1. Please make sure that the memory used is supported by the motherboard. It is
recommended that memory of similar capacity, specifications and brand be used.
2. Before installing or removing memory modules, please make sure that the computer
power is switched off to prevent hardware damage.
3. Memory modules have a foolproof insertion design. A memory module can be installed
in only one direction. If you are unable to insert the module, please switch the direction.
Step 2: Installing Memory Modules
The motherboard supports DDR memory modules, whereby BIOS will automatically detect memory
capacity and specifications. Memory modules are designed so that they can be inserted only in one
direction. The memory capacity used can differ with each slot.
DDR
Notch
Fig.1
The DIMM socket has a notch, so the DIMM memory module can
only fit in one direction. Insert the DIMM memory module vertically
into the DIMM socket. Then push it down.
Fig.2
Close the plastic clip at both edges of the DIMM sockets to lock the
DIMM module.
Reverse the installation steps when you wish to remove the DIMM
module.

Hardware Installation Process
English
- 19 -
DDR Introduction
Established on the existing SDRAM infrastructure, DDR (Double Data Rate) memory is a high
performance and cost-effective solution that allows easy adoption for memory vendors, OEMs, and
system integrators.
DDR memory is a great evolutionary solution for the PC industry that builds on the existing SDRAM
architecture, yet make the awesome advances in solving the system performance bottleneck by doubling
the memory bandwidth. Nowadays, with the highest bandwidth of 3.2GB/s of DDR400 memory and
complete line of DDR400/333/266/200 memory solutions, DDR memory is the best choice for building
high performance and low latency DRAM subsystem that are suitable for servers, workstations, and full
range of desktop PCs.
Recommended Memory Configurations (SS: Single -Sided, DS:Double-Sided)
Number of DIMMs
1
1
1
1
1
1
2
2
2
2
2
2
3
3
DIMM Socket Max. Memory Speed
DDR1 DDR2 DDR3
SS -- -- DDR 400
-- SS -- DDR 400
-- -- SS DDR 400
DS -- -- DDR 400
-- DS -- DDR 400
-- -- DS DDR 400
SS SS -- DDR 400
-- SS SS DDR 400
SS -- SS DDR 400
DS DS -- DDR 400
-- DS DS DDR 333
DS -- DS DDR 400
SS SS SS DDR 400
DS DS DS DDR 333
Please refer to the recommended memory configuration table below before installing memory.

- 20 -GA-K8VT800(Pro) Motherboard
English
Step 3-1: AGP Card Installation
Step 3 Install expansion cards
1. Read the related expansion card's instruction document before install the expansion card into the computer.
2. Remove your computer's chassis cover, screws and slot bracket from the computer.
3. Press the expansion card firmly into expansion slot in motherboard.
4. Be sure the metal contacts on the card are indeed seated in the slot.
5. Replace the screw to secure the slot bracket of the expansion card.
6. Replace your computer's chassis cover.
7. Power on the computer, if necessary, setup BIOS utility of expansion card from BIOS.
8. Install related driver from the operating system.
Please carefully pull out the small white-drawable bar at the end of the AGP slot when you try
to install / uninstall the AGP card. Please align the AGP card to the onboard AGP slot and
press firmly down on the slot. Make sure your AGP card is locked by the small white-
drawable bar.
