Gigabyte GA-P85-D3 User manual

GA-P85-D3
User's Manual
Rev. 2001
12ME-P85D3-2001R

Copyright
©2014 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without prior
notice.
No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or
by any means without GIGABYTE's prior written permission.
For quick set-up of the product, read the Quick Installation Guide included with the product.
In order to assist in the use of this product, carefully read the User's Manual.
For product-related information, check on our website at: http://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0" means
the revision of the motherboard is 1.0. Check your motherboard revision before updating motherboard
BIOS, drivers, or when looking for technical information.
Example:
Motherboard
GA-P85-D3
Jan. 24, 2014
Jan. 24, 2014
Motherboard
GA-P85-D3

- 3 -
Table of Contents
GA-P85-D3 Motherboard Layout....................................................................................4
GA-P85-D3 Motherboard Block Diagram .......................................................................5
Chapter 1 Hardware Installation .....................................................................................6
1-1 Installation Precautions ................................................................................... 6
1-2 Product Specications..................................................................................... 7
1-3 Installing the CPU ............................................................................................ 9
1-4 Installing the Memory .................................................................................... 10
1-5 Installing an Expansion Card......................................................................... 10
1-6 Back Panel Connectors ................................................................................. 10
1-7 Internal Connectors ....................................................................................... 12
Chapter 2 BIOS Setup ..................................................................................................18
2-1 Startup Screen............................................................................................... 18
2-2 M.I.T. .............................................................................................................. 19
2-3 System Information........................................................................................ 24
2-4 BIOS Features ............................................................................................... 25
2-5 Peripherals..................................................................................................... 28
2-6 Power Management....................................................................................... 31
2-7 Save & Exit .................................................................................................... 32
Chapter 3 Appendix......................................................................................................33
Drivers Installation .................................................................................................... 33
Regulatory Statements............................................................................................. 34
Contact Us ................................................................................................................ 36

- 4 -
GA-P85-D3 Motherboard Layout
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5GA-P85-D3 motherboard
5Motherboard driver disk 5Two SATA cables
5User's Manual 5I/O Shield
KB_MS CPU_FAN
LGA1150
ATX
GA-P85-D3
AUDIO
B_BIOS
DDR3_1
DDR3_2
BAT
F_PANEL
ATX_12V_2X4
Intel®B85
R_USB30
CODEC
CLR_CMOS
M_BIOS
HDMI COMA
USB_LAN
PCIEX16
PCI1
PCI2
PCIEX4
PCIe to PCI
Bridge
Realtek®
GbE LAN
iTE®
Super I/O
DDR3_3
DDR3_4
SPDIF_IN
SATA3 1 0
3 2
PCIEX1
SYS_FAN3
F_USB30
SYS_FAN2
SYS_FAN1
R_USB
PCI3
PCI4
SATA2 5 4
F_AUDIO F_USB2
F_USB1LPTSPDIF_O
COMB

- 5 -
GA-P85-D3 Motherboard Block Diagram
For detailed product information/limitation(s), refer to "1-2 Product Specications."
PS/2 KB/Mouse
DMI 2.0 FDI
CPU CLK+/- (100 MHz)
Dual BIOS
DDR3 1600/1333 MHz
LPC Bus
PCIe CLK
(100 MHz)
PCIe CLK
(100 MHz)
PCI Express Bus
1 PCI Express x16
x1
LAN
RJ45
Realtek®
GbE LAN
x1
1 PCI Express x1
x4
1 PCI Express x4
PCI Express Bus
x16
2 SATA 3Gb/s
8 USB 2.0/1.1
4 USB 3.0/2.0
LPT
4 SATA 6Gb/s
iTE®
Super I/O COM
HDMI
LGA1150
CPU
S/PDIF Out
S/PDIF In
Line Out (Front Speaker Out)
MIC (Center/Subwoofer
Speaker Out)
Line In (Rear Speaker Out)
CODEC
Intel®B85
4 PCI
PCI Bus
PCI CLK
(33 MHz)
x1
PCIe to PCI
Bridge
Dual Channel Memory
