Gigabyte MB10-DS1 User manual

MB10-DS1
BIOS Setup
User’s Guide
Rev.1.0

II
Copyright
© 2022 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specifications and features in this manual may be made by GIGABYTE without prior
notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
Documentation Classifications
In order to assist in the use of this product, GIGABYTE provides the following types of documentation:
 User Manual: detailed information & steps about the installation, configuration and use of this product
(e.g. motherboard, server barebones), covering hardware and BIOS.
 User Guide: detailed information about the installation & use of an add-on hardware or software
component (e.g. BMC firmware, rail-kit) compatible with this product.
 Quick Installation Guide: a short guide with visual diagrams that you can reference easily for
installation purposes of this product (e.g. motherboard, server barebones).
Please see the support section of the online product page to check the current availability of these documents.
For More Information
For related product specifications, the latest firmware and software, and other information please visit our website
at http://www.gigabyte.com
For GIGABYTE distributors and resellers, additional sales & marketing materials are available from our reseller
portal: http://reseller.b2b.gigabyte.com
For further technical assistance, please contact your GIGABYTE representative or visit
https://esupport.gigabyte.com/ to create a new support ticket
For any general sales or marketing enquiries, you may also message GIGABYTE server directly by email:
[e-mail]

III
Table of Contents
COPYRIGHT II
DISCLAIMER II
DOCUMENTATION CLASSIFICATIONS II
FOR MORE INFORMATION II
TABLE OF CONTENTS III
BIOS SETUP 5
Main Menu 7
Advanced Menu 10
iSCSI Configuration 11
Trusted Computing 12
AST2400 Super IO Configuration 13
Serial Port Configuration 15
PCI Subsystem Settings 18
Network Stack Configuration 20
CSM Configuration 21
Post Report Configuration 23
NVMe Configuration 24
USB Configuration 25
Chipset Configuration 26
IntelRCSetup 27
Processor Configuration 28
Pre-socket Configuration 30
Advanced Power Configuration 31
CPU P-State Control 32
CPU HWPM Control 33
CPU C State Control 34
CPU T State Control 35
CPU Advanced PM Turning 36
Memory Configuration 37
Memory Thermal 38
Memory Map 39
Memory RAS Configuration 40
IIO Configuration 41
IOAT Configuration 42
PCH Configuration 44
PCH Devices 45
PCH SATA Configuration 46
USB Configuration 48
Miscellaneous Configuration 49
Server ME Configuration 50

IV
Runtime Error Logging 51
Whea Configuration 52
Memory Error Enabling 53
PCI/PCI-E Error Enabling 54
Server Management 55
System Event Log 56
View FRU Information 57
BMC network Configuration 58
IPv6 BMC Network Configuration 59
Security Menu 60
Key Management 62
Boot Option Menu 63
Exit Menu 64
BIOS BEEP CODES 66
BIOS POST Beep code (AMI standard) 66

5
BIOS Setup
System BIOS
BIOS (Basic Input and Output System) records hardware parameters of the system in the EFI on the
motherboard. Its major functions include conducting the Power-On Self-Test (POST) during system startup,
saving system parameters, loading the operating system etc. The BIOS includes a BIOS Setup program that
allows the user to modify basic system configuration settings or to activate certain system features. When the
power is turned off, the battery on the motherboard supplies the necessary power to the CMOS to keep the
configuration values in the CMOS.
To access the BIOS Setup program, press the <DEL> key during the POST when the power is turned on.
• When changing the system configuration settings
• When redefining the communication ports to prevent any conflicts
• When modifying the power management configuration
• When changing the password or making other changes to the security setup
• When a configuration error is detected by the system and you are prompted (“Run Setup”
message) to make changes to the BIOS setup
NOTE: If you repeatedly receive Run Setup messages, the battery may be bad. Ask qualified technician for
assistance.
NOTE: The screenshots used in this guide display default system values. These values may not be the same
those found in your system.

6
Entering BIOS Setup
1. Turn on the server and the monitor.
If the server is already turned on, close all open applications, then restart the server.
2. During POST, press DEL
If you fail to press DEL before POST is completed, you will need to restart the server. The Setup Main menu
will be displayed showing the Setup’s menu bar. Use the left and right arrow keys to move between
selections on the menu bar.
BIOS Setup Program Function Keys
< →><←> Move the selection bar to select the screen
< ↑><↓> Move the selection bar to select an item
<Enter> Execute command or enter the submenu
<+> Increase the numeric value or make changes
<-> Decrease the numeric value or make changes
<F1> Show descriptions of general help
<F3> Restore the previous BIOS settings for the current submenus
<F9> Load the Optimized BIOS default settings for the current submenus
<F10> Save all the changes and exit the BIOS Setup program
<Esc> Main Menu: Exit the BIOS Setup program
Submenus: Exit current submenu
Main
This setup page includes all the items of the standard compatible BIOS.
Advanced
This setup page includes all the items of AMI BIOS special enhanced features.
(ex: Auto detect fan and temperature status, automatically configure hard disk parameters.)
Chipset
This setup page includes all the submenu options for configuring the functions of the Platform Controller Hub.
Server Management
Server additional features enabled/disabled setup menus.
Security
Change, set, or disable supervisor and user password. Configuration supervisor password allows you to restrict
access to the system and BIOS Setup.
A supervisor password allows you to make changes in BIOS Setup.
A user password only allows you to view the BIOS settings but not to make changes.
Boot
This setup page provides items for configuration of the boot sequence.
Save & Exit
Save all the changes made in the BIOS Setup program to the CMOS and exit BIOS Setup. (Pressing <F10>
can also carry out this task.)
Abandon all changes and the previous settings remain in effect. Pressing <Y> to the confirmation message will
exit BIOS Setup. (Pressing <Esc> can also carry out this task.).

7
Main Menu

8
Parameter Description
Project Name Displays the project name information.
Project Version Displays version number of the BIOS setup utility.
Build Date and Time Displays the date and time when the BIOS setup utility was created.
BMC Information(Note1)
BMC Firmware Version(Note1) Displays BMC firmware version information.
SDR Information Displays BMC SDR information.
FRU Information Displays BMC FRU information.
Processor Information
Name/ Brand String/ Frequency/
Processor ID/ Stepping/ Count/ Microcode
Revision
Technical specifications for the installed processor.
Memory Information(Note2)
Total Memory Determines how much total memory is present during the POST.
Frequency Technical specifications for the installed memory.
Onboard LAN Information(Note3)
LAN1 MAC Address Displays LAN MAC address information.
LAN2 MAC Address Displays LAN MAC address information.
System Date Set the date following the weekday-month-day- year format.
System Time Set the system time following the hour-minute- second format.

9
NOTE!
1. Functions available on selected models.
2. This section will display capacity and frequency information of the memory that the customer has
3. The number of LAN ports listed will depend on the motherboard / system model.

10
Advanced Menu
The Advanced menu display submenu options for configuring the function of various hardware
components. Select a submenu item, then press Enter to access the related submenu screen.

11
iSCSI Configuration
Parameter Description Option
iSCSI Initiator Name
A
dd an Attempts Press [Enter] for configuration of advanced items.
Delete Attempts Press [Enter] for configuration of advanced items.
Change Attempt Order Press [Enter] for configuration of advanced items.

12
Trusted Computing
Parameter Description Option
Configuration
Security Device Support Select Enabled to activate TPM support feature. Enable
[Disable]
Current Status Information Display current TPM status information.

13
AST2400 Super IO Configuration
Parameter Description Option
A
ST2600 Super IO
Configuration
Super IO Chip Displays the super IO chip information
Serial Port 1 Configuration
(Note1)
Press [Enter] for configuration of advanced items.
Serial Port 2 Configuration
(Note1)
Press [Enter] for configuration of advanced items.
Serial Port 1/2 Enable/Disable the Serial Port (COM). When set to
Enabled allows you to
configure the Serial port 1/2 settings. When set to
Disabled, displays no
configuration for the serial port.
[Enabled]
Disabled
Change Settings (Note2) Select an optimal settings for Super IO Device. [Auto]
IO=3F8h; IRQ=4;
IO=3F8h; IRQ=3, 4, 5, 6, 7,
9, 10, 11, 12;
IO=2F8h; IRQ=3, 4, 5, 6, 7,
9, 10, 11, 12;
IO=3E8h; IRQ=3, 4, 5, 6, 7,
9, 10, 11, 12;
IO=2E8h; IRQ=3, 4, 5, 6, 7,
9, 10, 11, 12;

14
NOTE!
1. Advanced items prompt when this item is defined.
2. This item appears when Serial Port is set to Enabled.

15
Serial Port Configuration
Parameter Description Option
COM1/2 Console Redirection
(Note1)
Select whether to enable console redirection for
specified device. Console redirection enables the
users to manage the system from a remote location.
Enabled
[Disabled]
COM2 Serial Over LAN Console
Redirection Settings
Press [Enter] to configure advanced items.
Please note that this item is configurable when
COM1/Serial Over LAN & COM2 Console
Redirection is set to Enabled.
Terminal Type Selects a terminal type to be used for console
redirection.
VT100
VT100+
[ANSI]
VT-UTF8
Bits per second Selects the transfer rate for console redirection. 9600
19200
38400
57600
[115200]
Data Bits Selects the number of data bits used for console
redirection.
7
[8]
Parity
A
parity bit can be sent with the data bits to detect
some transmission errors.
Even: parity bit is 0 if the num of 1's in the data bits is
even.
Odd: parity bit is 0 if num of 1's in the data bits is
odd.
Mark: parity bit is always 1. Space: Parity bit is
always 0.
Mk dS Pi d ll f
[None]
Even
Odd
Mark
Space

16
Stop Bits Stop bits indicate the end of a serial data packet. (A
start bit indicates the beginning). The standard
setting is 1 stop bit. Communication with slow
devices may require more than 1 stop bit.
[1]
2
Flow Control Flow control can prevent data loss from buffer
overflow. When sending data, if the receiving buffers
are full, a 'stop' signal can be sent to stop the data
flow. Once the buffers are empty, a 'start' signal can
be sent to re-start the flow. Hardware flow control
uses two wires to send start/stop signals.
[None]
Hardware
RTS/CTS
VT-UTF8 Combo Key Support Enable/Disable the VT-UTF8 Combo Key Support. [Enabled]
Disabled
Recorder Mode (Note) When this mode enabled, only texts will be send.
This is to capture Terminal data.
Enabled
[Disabled]
Recorder Mode (Note) When this mode enabled, only texts will be send.
This is to capture Terminal data.
[Enabled]
Disabled
Resolution 100x31 (Note) Enable/Disable extended terminal resolution. Enabled]
Disabled
Legacy OS Direction Resolution On Legacy OS, the Number of Rows and Columns
supported redirection.
[80x24]
80x25
Putty KeyPad (Note) Selects Function Key and KeyPad on Putty. [VT100]
LINUX
XTERMR6
SC0
ESCN
VT400
Redirection After BIOS POST This option allows user to enable console redirection
after O.S has loaded.
[Always Enable]
Boot Loader
Legacy Console Redirection
Settings
Press [Enter] to configure advanced items.
Selects a COM port for Legacy serial redirection.
[COM1]
COM2
Serial Port for Out-of-Band
Management / Windows
Emergency Management
Services (EMS) Console
Redirection (Note)
EMS console redirection allows the user to configure
Console Redirection Settings to support Out-of-Band
Serial Port management.
Enabled
[Disabled]
Serial Port for Out-of-Band EMS
Console Redirection Settings
Press [Enter] to configure advanced items.
Please note that this item is configurable when
Serial Port for Out-of-Band Management EMS
Console Redirection is set to Enabled.
Out-of-Band Mgmt Port Microsoft Windows Emerency Management Service
(EMS) allows for remote management of a Windows
Server OS through a serial port.
[COM1/Serial Over LAN]
COM2.
Terminal Type Selects a terminal type to be used for console
redirection.
VT100
VT100+
[
ANSI
]
VT
-
UTF8
Bits per second Selects the transfer rate for console redirection. 9600
19200
38400
57600
[115200]
Flow Control Flow control can prevent data loss from buffer
overflow. When sending data, if the receiving buffers
are full, a 'stop' signal can be sent to stop the data
flow. Once the buffers are empty, a 'start' signal can
be sent to re-start the flow. Hardware flow control
uses two wires to send start/stop signals.
[None]
Hardware RTS/CTS
Software Xon/Xoff
Parity
A
parity bit can be sent with the data bits to detect
some transmission errors.
Even: parity bit is 0 if the num of 1's in the data bits is
even.
Odd: parity bit is 0 if num of 1's in the data bits is
odd.
[None]
Even
Odd
Mark
Space

17
Stop Bits Stop bits indicate the end of a serial data packet. (A
start bit indicates the beginning). The standard
setting is 1 stop bit. Communication with slow
di i th 1t bit
[1]
2
NOTE!
 Advanced items prompt when this item is defined.

18
PCI Subsystem Settings
Parameter Description Option
PCI Express Slot # I/O ROM When enabled, This setting will initialize the device
expansion ROM for the related PCI-E slot.
[Enabled]
Disabled
Onboard LAN #1 I/O ROM
Option
Configure onboard LAN device and initialize device
expansion ROM.
iSCSI
[PXE]
Onboard LAN1 Controller Enable/Disable onboard LAN controller. [Enabled]
Disabled
Onboard LAN #1 I/O ROM Enable/Disable onboard LAN#1 device and
initialize device expansion ROM.
[Enabled]
Disabled

19
PCI Latency Timer Value to be programmed into PCI Latency Timer
Register.
[32 PCI Bus Clocks]
64 PCI Bus Clocks
96 PCI Bus Clocks
128 PCI Bus Clocks
160 PCI Bus Clocks
192 PCI Bus Clocks
224 PCI Bus Clocks
248 PCI Bus Clocks
VGA Palette Snoop Enable/Disable VGA Palette Registers Snooping. Enabled
[Disabled]
A
bove 4G Decoding Enable/Disable memory mapped I/O to 4GB or
greater address space (Above 4G Decoding).
[Enabled]
Disabled
SR-IOV Support If the system has SR-IOV capable PCIe devices, this
item Enable/Disable Single Root IO Virtualization
Support.
Enabled
[Disabled]
PCI Express Settings Press [Enter] for configuration of advanced items.
Relaxed Ordering Enable/Disable PCI Express Device Relaxed
Ordering feature.
Enabled
[Disabled]
Extended Tag When this feature is enabled, the system will allow
device to use 8-bit Tag field as are quester.
Enabled
[Disabled]
No Snoop Enable/Disable PCI Express Device No Snoop
option.
[Enabled]
Disabled
Maximum Payload Set maximum payload for PCI Express Device or
allow system BIOS to select the value.
[Auto]
128 Bytes
256 Bytes
512 Bytes
1024 Bytes
2048 Bytes
4096 Bytes
Maximum Read Request Set maximum Read Request size for PCI Express
Device or allow system BIOS to select the value.
[Auto]
128 Bytes
256 Bytes
512 Bytes
1024 Bytes
2048 Bytes
Extended Synch When this feature is enabled, the system will allow
generation of Extended Synchronization patterns.
Enabled
[Disabled]
Link Training Retry Define the number of Retry Attempts software will
take to retrain the link if previous training attempt
was unsuccessful. Press <+> / <-> keys to increase
or decrease the desired values.
Link Training Timeout (us) Define the number of Microseconds software will
wait before polling 'Link Training' bit in Link Status
register. Press <+> / <-> keys to increase or
decrease the desired values. Value rang is from 10
to 10000 us.
Unpopulated Links When this item is set to 'Disable Link, the system will
operate power save feature for those unpopulated
PCI Express links.
[Keep Link ON]
Disable Link

20
Network Stack Configuration
Paramete
r
Description Option
Network stack (Note) Enable/Disable UEFI network stack.
When this item is enabled, advanced items show up.
Enabled
[Disabled]
Ipv4 PXE Support Enable/Disable Ipv4 PXE feature. [Enabled]
Disabled
Ipv6 PXE Support Enable/Disable Ipv6 PXE feature. [Enabled]
Disabled
PXE boot wait time Wait time in seconds to press ESC key to abort the PXE
boot.
Press the <+> / <-> keys to increase or decrease the
desired values.
Media detect count Number of times the presence of media will be checked.
Press the <+> / <-> keys to increase or decrease the
desired values.
NOTE!
 Advanced items prompt when this item is defined.
