Gigabyte GA-8VM533 User manual

Whenyou installing AGPcard,please make surethefollowing notice
isfullyunderstood and practiced.IfyourAGPcardhas "AGP4X
(1.5V)notch"(showbelow),please make sureyourAGPcardisAGP
4X(1.5V).
Caution:AGP2XcardisnotsupportedbyGA-8VM533.You might
experience systemunabletobootup normally.Please insertanAGP4X
card.
Example1:Diamond VipperV770 golden fingeriscompatiblewith2X/4X
mode AGPslot. It can be switched between AGP2X(3.3V)or4X(1.5V)mode
byadjusting the jumper.The factorydefaultforthiscardis2X(3.3V).
The GA-8VM533 (oranyAGP4Xonly)motherboardsmightnotfunction
properly,ifyou install thiscardwithoutswitching the jumperto
4X(1.5V)mode init.
Example2:SomeATiRage 128 Prographics cardsmade by"PowerColor",
the graphics cardmanufacturer&someSiS305 cards,theirgolden fingeris
compatiblewith2X(3.3V)/4X(1.5V)mode AGPslot, buttheysupport2X(3.3V)
only.The GA-8VM533 (oranyAGP4Xonly)motherboardsmightnotfunction
properly,If you install thiscardinit.
Note:Although Gigabyte'sAG32S(G)graphics cardisbased on ATiRage
128 Prochip,the design ofAG32S(G)iscompliancewithAGP4X(1.5V)
specification.Therefore,AG32S(G)will workfine withGA-8VM533 based
motherboards.
AGP4Xnotch

Theauthorassumes no responsibilityforanyerrorsor
omissionsthatmay appearinthisdocumentnordoes the
authormake acommitmenttoupdatetheinformation
containedherein.
Third-partybrandsand names arethepropertyoftheir
respective owners.
Please do notremove anylabelson motherboard,thismay
voidthewarrantyofthismotherboard.
Duetorapidchangeintechnology,someofthe
specificationsmightbeoutofdatebeforepublication of
thisbooklet.

Declaration ofConformity
We,Manufacturer/Importer
(full address)
G.B.T.TechnologyTräding GMbH
AusschlagerWeg41,1F,20537 Hamburg,Germany
declarethatthe product
(description ofthe apparatus,system,installation towhichitrefers)
MotherBoard
GA-8VM533
isinconformitywith
(referencetothe specification underwhichconformityisdeclared)
inaccordancewith89/336 EEC-EMCDirective
oEN55011 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
industrial,scientificand medical(ISM
high frequency equipment
oEN61000-3-2*
TEN60555-2
Disturbancesinsupplysystemscause
byhouseholdappliancesand similar
electricalequipment“Harmonics”
oEN55013 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
broadcastreceiversand associated
equipment
oEN61000-3-3*Disturbancesinsupplysystemscause
byhouseholdappliancesand similar
electricalequipment“Voltage fluctuations”
oEN55014 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
householdelectricalappliances,
portabletoolsand similarelectrical
apparatus
TEN50081-1Genericemission standardPart1:
Residualcommercialand lightindustry
TEN50082-1GenericimmunitystandardPart1:
Residualcommercialand lightindustry
oEN55015 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
fluorescentlampsand luminaries
Genericemission standardPart2:
Industrialenvironment
oEN55081-2
Immunityfromradiointerferenceof
broadcastreceiversand associated
equipment
Genericemission standardPart2:
Industrialenvironment
oEN55082-2
TEN55022 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
information technologyequipment
lmmunityrequirementsforhousehold
appliancestoolsand similarapparatus
oENV55104
Cabled distribution systems;Equipment
forreceiving and/ordistribution from
sound and television signals
EMCrequirementsforuninterruptible
powersystems(UPS)
oEN50091-2
oEN55020
oDINVDE0855
opart10
opart12
(ECconformitymarking)
TCEmarking
Themanufactureralsodeclares theconformityofabove mentionedproduct
withtheactualrequiredsafetystandardsinaccordance withLVD73/23 EEC
Safetyrequirementsformainsoperated
electronicand related apparatusfor
householdand similargeneraluse
oEN60950
oEN60065
Safetyofhouseholdand similar
electricalappliances
oEN60335
Manufacturer/Importer
Signature:
Name:
(Stamp)Date:October2,2003
TEN60555-3
TimmyHuang
TimmyHuang
oEN50091-1
Safetyforinformation technologyequipment
including electricalbussiness equipment
Generaland Safetyrequirementsfor
uninterruptiblepowersystems(UPS)

FCC Part15,SubpartB,Section 15.107(a)and Section 15.109(a),
Class BDigitalDevice
DECLARATIONOFCONFORMITY
PerFCC Part2Section 2.1077(a)
ResponsiblePartyName:
Address:
Phone/Fax No:
hereby declaresthattheproduct
ProductName:Motherboard
Conformstothefollowing specifications:
Thisdevice complieswithpart15 oftheFCC Rules.Operation is
subjecttothefollowing twoconditions:(1)Thisdevice maynot
causeharmfuland(2)thisdevicemustacceptanyinferencereceived,
including thatmaycauseundesiredoperation.
RepresentativePerson’sName:
Signature:EricLu
SupplementaryInformation:
ModelNumber:GA-8VM533
17358 RailroadStreet
CityofIndustry,CA 91748
G.B.T.INC.(U.S.A.)
[phone]/[phone]
Date:
ERICLU
October2,2003

USER'SMANUAL
GA-8VM533
P4Titan SeriesMotherboard
Pentium®4ProcessorMotherboard
Rev.1002
12ME-8VM533-1002

-2-GA-8VM533 Motherboard
English
TableofContent
ItemChecklist ..................................................................................... 4
WARNING! .......................................................................................... 4
Chapter1Introduction ........................................................................ 5
FeaturesSummary......................................................................................... 5
GA-8VM533 MotherboardLayout .................................................................. 7
Block Diagram................................................................................................ 8
Chapter2HardwareInstallation Process ........................................... 11
Step 1:Install the CentralProcessing Unit(CPU)...................................... 12
Step 1-1:CPUInstallation ......................................................................................... 12
Step 1-2:CPUCooling Fan Installation ..................................................................... 13
Step 2:Install MemoryModules.................................................................. 14
Step 3:Install expansion cards.................................................................... 16
Step 4:Connectribbon cables,cabinetwiresand powersupply............. 17
Step 4-1:I/OBack PanelIntroduction ....................................................................... 17
Step 4-2:ConnectorsIntroduction ............................................................................. 19
Chapter3BIOSSetup ....................................................................... 27
The MainMenu (Forexample:BIOSVer.:F1)......................................... 28
StandardCMOSFeatures........................................................................... 30
Advanced BIOSFeatures............................................................................. 33
Integrated Peripherals................................................................................. 35
PowerManagementSetup .......................................................................... 38

TableofContent
English
-3-
PnP/PCIConfigurations................................................................................ 41
PCHealthStatus........................................................................................... 42
Frequency/Voltage Control........................................................................... 43
Load Fail-SafeDefaults................................................................................ 45
Load Optimized Defaults.............................................................................. 46
SetSupervisor/UserPassword..................................................................... 47
Save&ExitSetup .......................................................................................... 48
ExitWithoutSaving ....................................................................................... 49
Chapter4TechnicalReference......................................................... 51
@BIOS™Introduction .................................................................................. 51
EasyTune™4Introduction .......................................................................... 52
FlashBIOSMethod Introduction ................................................................. 53
Method 1:Q-Flash................................................................................................... 53
Method 2:@BIOSUtility.......................................................................................... 66
6-ChannelAudioFunction Introduction ...................................................... 68
Xpress RecoveryIntroduction ...................................................................... 71
Chapter5Appendix.......................................................................... 75

-4-GA-8VM533 Motherboard
English
ItemChecklist
Computermotherboardsand expansion cardscontainverydelicateIntegrated Circuit(IC)chips.To
protectthemagainstdamagefromstaticelectricity,youshouldfollowsomeprecautionswheneveryou
workon yourcomputer.
1.Unplug yourcomputerwhen working ontheinside.
2.Useagroundedwriststrapbeforehandlingcomputercomponents.Ifyoudo nothave
one,touchbothofyourhandstoasafelygroundedobjectortoametalobject, suchas
the powersupplycase.
3.Holdcomponentsbythe edgesand trynottouchthe ICchips,leadsorconnectors,or
othercomponents.
4.Placecomponentsonagroundedantistaticpad oronthebag thatcamewiththe
componentswheneverthe componentsareseparatedfromthe system.
5.EnsurethattheATXpowersupplyisswitched offbeforeyou plug inorremovetheATX
powerconnectoronthemotherboard.
Ifthemotherboardhasmountingholes,buttheydon’tlineupwiththeholesonthebaseandthereare
noslotstoattachthe spacers,do notbecomealarmedyoucan still attachthespacerstothe mounting
holes.Justcutthe bottomportion ofthe spacers(the spacermaybe alittlehardtocutoff, sobecareful
ofyourhands).Inthiswayyou can stillattachthe motherboardtothe basewithoutworryingaboutshort
circuits.Sometimesyou mayneedtousetheplasticspringstoisolatethe screwfromthemotherboard
PCBsurface,becausethe circuitwiremaybe nearbythe hole.Becareful,don’tletthe screwcontact
anyprinted circuitwriteorpartsonthe PCBthatarenearthe fixing hole,otherwiseitmaydamagethe
boardorcauseboardmalfunctioning.
Installing themotherboardtothechassis…
WARNING!
The GA-8VM533 motherboard 2 PortUSB Cablex1
IDEcablex1/Floppycablex1 4 PortUSB Cablex1
CD formotherboarddriver&utilitySPDIF-KITx1(SPDIFOutKIT)
GA-8VM533 user'smanualIEEE 1394 Cablex1
I/OShieldAudioCombo Kitx1
Quick PCInstallation Guide (SURROUND-Kit+SPDIFOutKIT)
RAIDManualMotherboardSettingsLabel
GC-SATACard(Optional)SATARAIDManual
(Manual;SATAcablex1;Powercablex1)SATAcablex1

Introduction
English
-5-
FormFactor—24.5cmx20.8cmMicroATXsizeformfactor,4layersPCB
CPU—Socket478 forIntel®MicroFC-PGA2Pentium®4processor
—SupportIntel®Pentium®4(Northwood)processor
—SupportIntel®Pentium®4ProcessorwithHTTechnology*
—Intel®Pentium®4533/400MHzFSB
—2ndcache dependsonCPU
Chipset—VIAP4M533 Memory/AGP/PCIController(PAC)
—VIAVT8235Integrated PeripheralController(PSIPC)
Memory—2184-pinDDRsockets
—SupportsDDR266/DDR200DIMM
—Supportsup to2GBDDR (Max)
—Supportsonly2.5VDDR DIMM
I/OControl—ITE8705
Slots—1AGPslotsupports4Xmode(1.5V)
—3PCIslotsupports33MHz&PCI2.2compliant
On-BoardIDE—2IDEbusmaster(UDMA33/ATA66/ATA100/ATA133)IDEports
forup to4ATAPIdevices
—SupportsPIOmode3,4(UDMA33/ATA66/ATA100/ATA133)IDE
&ATAPICD-ROM
On-BoardPeripherals—1Floppyportsupports2FDD with360K,720K,1.2M,1.44M
and 2.88Mbytes
—1ParallelportsupportsNormal/EPP/ECPmode
—1Serialport(COMA),1VGAport
—6USB 2.0/1.1ports(2xRear,4xFrontbycable)
—1FrontAudioconnector
Chapter1Introduction
tobe continued......
Features Summary

-6-GA-8VM533 Motherboard
English
HardwareMonitor—CPUfan revolution detect
—CPUtemperaturedetect
—Systemvoltage detect
—CPUfan fail warning
On-BoardLAN—BuilitinVIA6103 Chipset
—1RJ45 port
On-BoardSound —VIAVT1616 CODEC
—Line Out/2frontspeaker
—Line In/2rearspeaker(bys/wswitch)
—MicIn/center&subwoofer(bys/wswitch)
—CD_In
PS/2Connector—PS/2Keyboardinterfaceand PS/2Mouseinterface
BIOS—LicensedAwardBIOS
—SupportsQ-Flash
AdditionalFeatures—PS/2Keyboardpoweron bypassword
—PS/2Mousepoweron
—STR(Suspend-To-RAM)
—ACRecovery
—Polyfuseforkeyboardover-currentprotection
—USB KB/Mousewakeup fromS3
—Supports@BIOS
—SupportsEasyTune 4
Pleasesetthe CPUhostfrequency inaccordancewithyourprocessor'sspecifications.
Wedon'trecommend you tosetthe systembusfrequency overthe CPU'sspecification because
thesespecificbusfrequenciesarenotthe standardspecificationsforCPU,chipsetand mostofthe
peripherals.Whetheryoursystemcan run underthesespecificbusfrequenciesproperlywill
depend on yourhardwareconfigurations,including CPU,Chipsets,Memory,Cards…etc.
"*"HTfunctionalityrequirementcontent:
Enabling the functionalityofHyper-Threading Technologyforyourcomputersystemrequiresall
ofthe following platformcomponents:
-CPU:AnIntel®Pentium4ProcessorwithHTTechnology
-Chipset: AnVIAChipsetthatsupportsHTTechnology
-BIOS:ABIOSthatsupportsHTTechnologyand hasitenabled
-OS:Anoperation systemthathasoptimizationsforHTTechnology

Introduction
English
-7-
GA-8VM533 MotherboardLayout
GA-8VM533
KB_MS
COMA
ATX_12V
CD_IN
F_AU DIO
F_PANEL
BAT
VIA8235
VIAP4M533
SOCKET478
CPU_FAN
ATX
FDD
IDE2
PCI1
PCI2
PCI3
DDR1
CODEC
ITE8705
BIOS
F_USB2
VGA
IDE1
VT6 103
F_USB1
PWR_LED
USB LAN
AUDIO
DDR2
LPT

-8-GA-8VM533 Motherboard
English
MII
Block Diagram
VIA
P4M533
VIA
VT8235
CPUCLK+/-(100/133MHz)
SystemBus
533/400MHz
AGPCLK66 MHz
33 MHz
14.318 MHz
48 MHz
LPCBUS
AGP4X
3PCI
PCICLK
(33MHz)
RJ45
AC97 Link
6USB
Ports
ATA33/66/
100/133
IDEChannels
VT6103
24 MHz
33 MHz
Floppy
LPTPort
PS/2KB/Mouse
1COMPort
MIC
LINE-IN
LINE-OUT
Pentium4
Socket478
CPU
6Channel
CODEC
200/266MHz
DDR
AGPCLK
66MHz
MCHCLK(100/133MHz)
CLK
GEN
MCHCLK(100/133MHz)
CPUCLK+/-(100/133MHz)
AGPCLK(66MHz)
PCICLK(33MHz)
USBCLK(48MHz)
14.318 MHz
33 MHz
PCIBUS33MHz
66MHz V_Link
V_Link(66MHz)
VGAPort
BIOS
IT8705

Introduction
English
-9-

-10 -GA-8VM533 Motherboard
English

-11 -HardwareInstallation Process
English
Chapter2HardwareInstallation Process
Tosetupyourcomputer,youmustcompletethe followingsteps:
Step 1-Install the CentralProcessingUnit(CPU)
Step2-Install memorymodules
Step3-Install expansion cards
Step 4-Connectribboncables,cabinetwires,andpowersupply
Congratulations!Youhaveaccomplishedthe hardwareinstallation!
Turnon thepowersupplyorconnectthepowercabletothepoweroutlet. Continue withthe
BIOS/softwareinstallation.
Step2
Step4
Step4
Step4
Step1
Step3

-12 -GA-8VM533 Motherboard
English
Step1:Install theCentralProcessing Unit(CPU)
Step1-1:CPUInstallation
Angling the
rod to650
1.Anglingtherodto65-degreemaybe
feelakind oftight,andthen continue
pulltherodto90-degreewhenanoise
"cough"made.
2.Pull therodtothe90-degreedirectly.
Pin1indicator
3.CPUTop View
Pin1indicator
4.LocatePin1inthe socketand
lookfora(golden)cutedgeonthe
CPUuppercorner.Then insert
the CPUintothe socket.
Socket
Actuation
Lever
Beforeinstalling theprocessor,adheretothefollowing warning:
1.Please make suretheCPUtypeissupportedbythemotherboard.
2. Ifyou do notmatchtheCPUsocketPin1and CPUcutedgewell, itwill
cause improperinstallation.Please changetheinsertorientation.

-13 -HardwareInstallation Process
English
Step1-2:CPUCooling FanInstallation
1.Fasten the cooling fan supporting-
baseontothe CPUsocketon the
motherboard.
Beforeinstalling theCPUcooling fan,adheretothefollowing warning:
1.Please use Intelapprovedcooling fan.
2.Werecommend you toapplythethermaltapetoprovidebetterheat
conduction betweenyourCPUand cooling fan.
(TheCPUcooling fanmightstick totheCPUduetothehardening of
thethermalpaste.During thiscondition ifyou trytoremove thecool-
ing fan,you mightpull theprocessoroutoftheCPUsocketalonewith
thecooling fan,and mightdamagetheprocessor.To avoidthisfrom
happening,wesuggestyou toeitheruse thermaltapeinsteadof
thermalpaste,orremove thecooling fanwithextremecaution.)
3.Make suretheCPUfanpowercableispluggedintotheCPUfan
connector,thiscompletes theinstallation.
Please refertoCPUcooling fanuser'smanualformoredetail
installation procedure.
2.Makesurethe CPUfan isplugged
tothe CPUfan connector,than
installcomplete.

-14 -GA-8VM533 Motherboard
English
Beforeinstalling thememorymodules,adheretothefollowing warning:
1.Please notethattheDIMM modulecanonlyfitinonedirection dueto
theonenotch.Wrong orientation will cause improperinstallation.
Please changetheinsertorientation.
Step2:Install MemoryModules
The motherboardhas2dualinline memorymodule(DIMM)sockets.The BIOSwill automatically
detectsmemorytype and size.Toinstall the memorymodule,justpushitverticallyintothe DIMM
socket. The DIMM modulecan onlyfitinone direction due tothe notch.Memorysizecan vary
betweensockets.
DDR
Notch

-15 -HardwareInstallation Process
English
DDRIntroduction
1.The DIMM slothasanotch,sothe DIMM
memorymodulecan onlyfitinone direction.
2. Insertthe DIM M memorymoduleverticallyinto
the DIMM slot. Then pushitdown.
3.Closethe plasticclipatbothedgesofthe DIMM
slotstolock the DIMM module.
Reversethe installation stepswhen you wish
toremovethe DIMM module.
Established on the existing SDRAMinfrastructure,DDR (DoubleDataRate)memoryisahigh
performanceand cost-effectivesolutionthatallowseasyadoption formemoryvendors,OEMs,
andsystemintegrators.
DDR memoryisagreatevolutionarysolution forthe PCindustrythatbuildsonthe existing
SDRAMarchitecture,yetmakethe awesomeadvancesinsolvingthe systemperformance
bottleneck bydoubling thememorybandwidth.Nowadays,withthehighestbandwidthof
3.2GB/sofDDR400 memoryand completelineofDDR400/333/266/200 memorysolutions,DDR
memoryisthebestchoiceforbuilding high performanceand lowlatencyDRAMsubsystemthat
aresuitableforservers,workstations,and fullrangeofdesktopPCs.

-16 -GA-8VM533 Motherboard
English
Step3:Install expansion cards
1.Read the related expansion card'sinstructiondocumentbeforeinstall the expansioncardintothe
computer.
2.Removeyourcomputer'schassiscover,screwsand slotbracketfromthecomputer.
3.Press the expansion cardfirmlyintoexpansion slotinmotherboard.
4.Besurethe metalcontactsonthe cardareindeedseated inthe slot.
5.Replacethescrewtosecurethe slotbracketoftheexpansion card.
6.Replaceyourcomputer'schassiscover.
7.Poweron the computer,ifnecessary,setup BIOSutilityofexpansion cardfromBIOS.
8. Install related driverfromtheoperating system.
AGPCard
Pleasecarefullypulloutthe small white-
drawablebarattheend oftheAGPslotwhen
you trytoinstall/Uninstall the AGPcard.
Pleasealign theAGPcardtotheonboard
AGPslotand press firmlydownonthe slot.
MakesureyourAGPcardislockedbythe
small white-drawablebar.
