Gigabyte GC-WB300D User manual

GC-WB300D
GC-WB150
User’s Manual
12WE6-WIFIBT-30AR

- 2 -
English
Step 1:
Install the Wi-Fi/Bluetooth card in a PCI
Express x1 slot. Connect one end of the USB
cable to the USB connector on the Wi-Fi/
Bluetooth card.
Step 2:
Connect the other end of the USB cable to
the F_USB connector on the motherboard.
Antenna Connector
Antenna Connector
Wi-Fi/Bluetooth Card
USB Connector
Antenna
USB Cable
Chapter 1 Installing the Wi-Fi/Bluetooth Card

- 3 -
English
Step 4:
Then move the antennas to a place where
the signal is good.
Step 3:
Tighten the two antenna cables to the
antenna connectors on the Wi-Fi/Bluetooth
card respectively.

- 4 -
English
The Wi-Fi Share utility is supported in Windows 7 only.
After installing the Wi-Fi/Bluetooth card, install the
drivers and utilities in the operating system. Insert
the included driver disk and when the autorun screen
appears, install all of the items that are listed. Follow
the on-screen instructions to install the drivers and
utilities in sequence.
2-1 Installing the Drivers and Utilities
2-2 Using the Wi-Fi Share Utility
After the installation, the Wi-Fi Share icon will
appear in the notication area. Right-click this icon
to display conguration options.
Option Descriptions
Option Description
Manage Wi-Fi Share Opens the Wi-Fi Share Manager
Local Share Directory Goes to the directory where shared les are located (Wi-Fi
Share Mode)
Mode Choice Selects which mode to operate
Setting Congures further settings depending on the mode selected
Reset Router Reset the Wi-Fi Share utility
Live Update Updates Wi-Fi Share online
Help Displays the help le
About Displays the Wi-Fi Share version
Exit Exits Wi-Fi Share
The Wi-Fi Share utility allows you to congure how your Wi-Fi/Bluetooth card will act. First it can turn
your computer into a virtual wireless access point (Virtual Router Mode), which allows WiFi-capable
computers or mobile devices to access the Internet through the virtual wireless access point. Second,
it can be congured to let your computer share data to another computer by simply dragging the data
from your computer to the target computer (Wi-Fi Share Mode). Third, it surely can be used as a
normal wireless LAN card (Wi-Fi Mode Only).
Chapter 2 Installing the Drivers and Utilities

- 5 -
English
Mode Selection
Wi-Fi Share provides three modes for users to select as follows:
A. Virtual Router Mode
The Virtual Router Mode turns your computer into a virtual wireless access point (WAP). Refer to the
steps below for detailed congurations.
Step 1:
Right-click the Wi-Fi Share icon in the notication
area and select Mode Choice > Virtual Router
Mode to turn your computer into a virtual wireless
AP. Then select Setting.
Step 2:
When the Wi-Fi Share Settings dialog box appears,
select a currently running network connection you
want to share from the Share Connection list. Then
click Save. The Password represents the network
security key which is required when other computer
wants to access the Internet through the virtual
wireless AP. You can keep the default password or
create your own one.
Conguring your computer:
Conguring the computer that wants to access the Internet through the virtual wireless AP:
Step 1:
Left-click the Internet Access icon in the notication
area. When the Currently connected to list
appears, select the virtual wireless AP you want to
connect to and click Connect.

- 6 -
English
Step 2:
When the Connect to a Network dialog box appears,
enter the security key of the network connection the
virtual wireless AP is sharing and click OK.
Step 3:
After the connection, the Currently connected to
list shows that this computer is currently using the
network connection shared by the virtual wireless
AP.
B. Wi-Fi Share Mode
The Wi-Fi Share Mode allows two computers with Wi-Fi Share Mode enabled to share les to each
other. Note: Be sure to turn off the rewall on both computers before using Wi-Fi Share Mode.
Step 1:
Make sure the two computers are installed with
the Wi-Fi Share utility and have Wi-Fi Share Mode
enabled. On the desktop of the source computer,
right-click the Wi-Fi Share icon in the notication
area and select Mode Choice > Wi-Fi Share Mode.
Then select Manage Wi-Fi Share to open the Wi-Fi
Share Manager.

- 7 -
English
Step 2:
The Wi-Fi Share Manager will display the other
computer with Wi-Fi Share Mode enabled (the
target computer).
Step 3:
Go the directory where the le/folder that you want
to share is located. Drag the le/folder to the target
computer displayed on the Wi-Fi Share Manager.
Step 4:
When asked whether to send the le/folder to the
target computer, click Yes. The TX light will be on
when the le/data is being sent.

- 8 -
English
Step 5:
The confirmation message will also appear on
the target computer, asking whether to accept the
le/folder from the source computer. Click Yes to
conrm. You must respond in 15 seconds. The RX
light will be on when the le/data is being received.
Step 6:
The data will be automatically stored to a folder in
the My Documents\AirFileDownloads directory in
the target computer, which is named according to
the receiving time. To directly access this directory
later, you can also right-click the Wi-Fi Share icon
in the notication area and select Local Shared
Directory.
C. Wi-Fi Mode Only
In this mode, the Wi-Fi/Bluetooth card is set as a normal wireless LAN card and needs to connect to
a wireless access point to get Internet connection.

- 9 -
English
2-3 Using the Cloud Station Utility
The Cloud Station utility allows GIGABYTE’s iOSAPPs to communicate, share resources, and control
your desktop PC systems. Two GIGABYTE’s unique iOS APPs are available now: EasyTune Touch
and PictureView, both of which can be downloaded from the Apple store for free.
EasyTune Touch:
EasyTune Touch is a simple and easy-to-use application that allows users to remotely
control their system through Apple devices, including iPhone and iPAD. Detailed
functions are as follows:
Options Descriptions
Option Description
Tuner Allows you to change CPU/memory
frequency and voltage settings.
System Information Displays the system information,
including the CPU, motherboard,
and memory.
Hardware Monitor Allows you to monitor hardware
temperature, voltage, and fan
speed.
Remote Control Allows you to reboot or shut dwn your
computer.
Quick Boost Provides you with 3 levels of automatic
system tuning.
Connection Selects how iPhone/iPad will connect
to your computer.
PictureView:
The PictureView application is designed to allow users to quickly and effortlessly share
photographs from their iOS device directly to their computer. By simply selecting a
photo from the iOS device’s picture library, the user will then be instantly able to see
it on their PC desktop.
System Requirements:
•Windows 7
•i-Tunes
•iPhone 4, iPhone 3, and iPad series (iPhone 3 and iPad series only support Wi-Fi connection)

- 10 -
English
Three ways of connection:
Before using EasyTune Touch and PictureView, use one of the three ways below to connect your Apple
devices to the target computer: Wi-Fi, Bluetooth, and USB connections. iPhone 3 and iPad series only
support Wi-Fi connection and iPhone 4 series supports all of the three connections. Below we use
iPhone 4 as the demonstration Apple device. (Make sure i-Tunes is installed rst.)
A. Wi-Fi Connection:
Make sure your iPhone and computer are using the
same network connection.
Step 1:
Make sure your computer is connected to a network
connection.
After the Cloud Station utility is installed, the Cloud
Station icon will appear in the notication area.
You can right-click this icon and select Always run
on next reboot to launch this utility each time you
reboot the computer. To use EasyTune Touch and
PictureView on your iPhone/iPad, you must launch
the Cloud Station utility on your computer rst.
Using the Cloud Station:
Step 2:
On your iPhone, go to Settings>Wi-Fi and turn on
the Wi-Fi function. Then choose the same network
connection that your computer is currently using.

- 11 -
English
Using EasyTune Touch
Step 1:
Go to the main menu of the EasyTune Touch
application on your iPhone. Select Connection.
Step 2:
On the Connection page, select Wifi. iPhone
will begin to search for the computer using the
same network connection. When the computer is
displayed, select it. Then return to the main menu of
the EasyTune Touch application. Now you are able
to use the EasyTune Touch functions to remotely
control the target computer via the iPhone or check
hardware information.
Step 1:
Go to the main screen of the PictureView application.
In the photo gallery, select Connect.
Step 2:
On the Connection page, select Wifi. iPhone
will begin to search for the computer using the
same network connection. When the computer is
displayed, select it. Then return to photo gallery.
Using PictureView

- 12 -
English
B. BlueTooth Connection:
Step 1:
On your iPhone, go to Settings > Personal Hotspot
and turn on this function. Then go to Settings >
General > Bluetooth to turn Bluetooth on.
Step 2:
Now you have to pair the iPhone with your computer.
In the operating system of your computer, go to
Control Panel > Devices and Printers. Select
Add a device. Your computer will look for Bluetooth
devices and display them on the screen. When the
iPhone is displayed, select it and click Next.
Step 3:
Click the photo you want to share and your photo
will be shown instantly on the desktop of the target
computer.

- 13 -
English
Step 3:
A pairing code will appear on the screen. Click
Next. You iPhone will display a message with the
pairing code for you to conrm as well (refer to the
next screenshot).
Step 4:
When the iPhone displays the pairing code, press
Pair to conrm. After the pairing is successful, your
iPhone will show that it has been connected to your
computer.
Step 5:
Your computer will show that the iPhone has been
added to your computer successfully. Click Close
to return to the Control Panel > Devices and
Printers window.
Step 6:
Look for your iPhone device, right-click it, and select
Connect using > Access Point to complete the
conguration.
Now, you are ready to use EasyTune Touch or PictureView. Refer to the instructions on conguration
Wi-Fi connection and select Bluetooth connection.

- 14 -
English
C. USB Connection:
Step 1:
On your iPhone, go to Settings > Personal Hotspot
to turn on this function.
Step 2:
Connect your iPhone to your computer using the iPhone USB cable.
Step 3:
After the iPhone is connected to your computer, go
to Control Panel > Network and Sharing Center
> Change adapter settings. Make sure Apple
Mobile Device Ethernet is present. If not, re-check
the connection.
Now, you are ready to use EasyTune Touch or PictureView. Refer to the instructions on conguration
Wi-Fi connection and select USB connection.
