Gigabyte G481-HA0-00 Owner's manual

Model Name: G481-HA0-00
GBT P/N: 6NG481HA0MR-00-*
Release Date: 2018/07/02
NOTICE: This document has released under
A Non-Disclosure Agreement to:
CUSTOMER:
PROJECT: G481-HA0
This Document has been released from:
Company: GIGABYTE TECHNOLOGY CO., LTD
Approved By:
Checked By:
Released By:
Ref.No/ Rev: 1.0
Assembly Notice

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 2/21
1Overview.................................................................................................... 3
1.1Document History...................................................................................................3
1.2Purpose....................................................................................................................3
1.3Screw Torque Table ................................................................................................4
2Procedure for System assembly ............................................................. 5
2.1Step 1.......................................................................................................................5
2.2Step 2.......................................................................................................................6
2.3Step 3.......................................................................................................................7
2.4Step 4 1st GPGPU assembly..................................................................................8
2.5Step 5 2nd to 8th GPGPU assembly.......................................................................10
2.6Step 6 9th GPGPU assembly.................................................................................12
2.7Step 7.....................................................................................................................13
2.8Step 8.....................................................................................................................13
2.9Step 9.....................................................................................................................14
2.10Step 10............................................................................................................15
2.11Step 11 10th GPGPUassembly.......................................................................16
2.12Step 12............................................................................................................17
2.13Step 13............................................................................................................17
2.14Step 14............................................................................................................18
2.15Step 15............................................................................................................19
2.16Step 16............................................................................................................20
2.17Step 17............................................................................................................21

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 3/21
1 Overview
1.1 Document History
Item Revision Description Date Originator
1 0.1 1st release 2018-07-02 張建誠
1.2 Purpose
This document defines the particular Gigabyte requirements for standard server
assembly at DVT stage. The purpose is to ensure the method of assembly be transfer to the
factory.

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 4/21
1.3 Screw Torque Table
(Screw Spec) (Screwdriver Type) (Suggestion
Torque) (Remark)
Screw type: M3x5L
2598EG-1C003-S00 #2 5kg/cm0.5

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 5/21
2 Procedure for System assembly
Step Method Part number /
Board model name Q’ty Comment
1 Remove top cover and take off fan duct, loosen the 40 FAN BKT thumb screw and
remove the 40 fan kit.
2.1 Step 1

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 6/21
Step Method Part number /
Board model name Q’ty Comment
2
Remove the 40 fan kit and open the GPU tray.
Loosen the PCIE BKT screws and take out
the PCIE BKE.
please keep the
screws on hand
please keep the
screws on hand
2.2 Step 2
Remove
screws
Remove PCIE

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 7/21
Step Method Part number /
Board model name Q’ty Comment
3 Plug in short GPU Power cable with GPGPU 25CRI-100002-B0R 8 Total needs to
assembly 8 units
2.3 Step 3
Before plug in the GPGPU power
cable, please bend the cable as
b
elow.

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 8/21
Step Method Part number /
Board model name Q’ty Comment
4
4.1 Please follow the arrowhead to insert the
GPGPU into GPU fan duct then 4.2 lock it on
PCIE/B and fasten it with 2* M3x5L, then 4.3
power cable assembly on GPU Power /B.
2.4 Step 4 – 1st GPGPU assembly
1
2

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 9/21
3

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 10/21
Step Method Part number /
Board model name Q’ty Comment
5
5.1 Please follow the arrowhead to insert the
GPGPU into GPU fan duct then 5.2 lock it on
PCIE/B and fasten it with 2* M3x5L, then 5.3
power cable assembly on GPU Power /B.
2.5 Step 5 – 2nd to 8th GPGPU assembly
1
2

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 11/21
3
3rd to 8th GPGPU assembly please follow
2ndGPGPU card assembly SOP.

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 12/21
Step Method Part number /
Board model name Q’ty Comment
6 Put back the GPGPU Tray and take off the
M3x5L screws on the tray top.
please keep the
screws on hand
2.6 Step 6 – 9th GPGPU assembly

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 13/21
Step Method Part number /
Board model name Q’ty Comment
7 Take off the screws from GPU BKT and
takeoff the PCIE BKT
please keep the
screws on hand
8 Plug in the long GPU Power cable with
GPGPU 25CRI-300002-B0R 1
2.7 Step 7
2.8 Step 8

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 14/21
Step Method Part number /
Board model name Q’ty Comment
9 Please follow the arrowhead to insert the GPGPU into GPU BKT and fasten 2 x pcs
M3x5L screws
2.9 Step 9

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 15/21
Step Method Part number /
Board model name Q’ty Comment
10
When done the GPU to assembly it with BKT,
put it on tray and fasten it with 3pc
M3 x 5L screws. Put power cable with
GPU Power/ B and trim the cable.
2.10Step 10
Step Method Part number / Q’ty Comment
When assembly the
GPGPU cable, please
notice to the power
connector and trim the
cables.

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 16/21
Board model name
11 Take of the M3x5L screws from GPU BKT tray
please keep the
screws on hand
2.11 Step 11- 10th GPGPU assembly

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 17/21
Step Method Part number /
Board model name Q’ty Comment
12 Take off the GPU BKT screws and take off
the PCIE BKT.
please keep the
screws on hand
13 Plug in the long GPU Power cable and
assembly it with GPGPU 25CRI-300002-B0R 1
2.12Step 12
2.13 Step 13

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 18/21
Step Method Part number /
Board model name Q’ty Comment
14 Follow the arrowhead to make GPU insert into GPU BKT, and fasten it with 2pcs
M3x5L screws.
2.14Step 14

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 19/21
Step Method Part number /
Board model name Q’ty Comment
15
When done the GPU to assembly it with BKT,
put it on tray and fasten it with 3pc M3
x 5L screws. Put power cable with GPU
Power/ B and trim the cable.
2.15Step 15
Step Method Part number / Q’ty Comment
When assembly the
GPGPU cable, please
notice to the power

Work Instruction System integration
engineering department
Issued Date: 2018-07/02
Revised Date: Document Ref. Number: Revision: 0.1 Pages: 20/21
Board model name
16 Assembly the 40 Fan kit and fasten it with Thumb screws then put the fan cable with clip
then trim it.
2.16 Step 16
