System Installation Guide
1-i
GS-SR101T
1U Rack Mount Server
SYSTEM INSTALLATION
GUIDE

System Installation Guide
1-ii
INDEX
1. INTRODUCTION 1-1
1.1. PREFACE 1-1
1.2. FEATURES 1-1
2. HARDWARE INVENTORY 2-1
3. SYSTEM INSTALLATION 3-1
3.1. CHASSIS COVER REMOVAL 3-1
3.2. PROCESSOR INSTALLATION 3-2
3.3. FAN+HEATSINK INSTALLATION 3-4
3.4. SYSTEM RAM INSTALLATION 3-6
3.5. INSTALLING HANDLE 3-7
3.6. REINSTALL TOP COVER 3-8
3.7. HARD DISK DRIVE INSTALLATION 3-9
3.8. FRONT SIDE 3-14
3.9. LED INDICATORS 3-14
3.10. BACK SIDE 3-15
3.11. CONNECTOR ICONS 3-16

System Installation Guide
1-1
1. INTRODUCTION
1.1. Preface
Using this manual will help you get the most from your
Rack Mount Server. Keeping the manual with your Rack
Mount Server to refer when you want information and
help.
In order to get the optimal usage out of your Rack Mount
Server and you should remember the following:
 Read through all the instruction for your Rack
Mount Server .
 Keep the area free of static electricity and magnetic
fields. These can damage the Server .
 When cleaning the server or its components, apply
the proper cleaning solution or sprays only on the
cloth ,not to the server or its components .
1.2. Features
Our Rack Mount Server use 1U Chassis and support the
following features:
Processor Support
 Dual Socket 370 for Intel FC-PGA Coppermine and
Tualatin processor Up to 1 GHz and above
 Optimal CPU Keep Out Zone for Type C Heat-sink
 100/133MHz FSB
 AUTO detect CPU voltage
BIOS
 AMI BIOS on 4M bit flash ROM

System Installation Guide
1-2
 Auto configure IDE HDD type
 Multiple boot options
 User setting for hardware monitoring
 DMI 2.0 compliant
Chipset
 VIA Apollo Pro Family AGP set
( VT82C694T ,VT82C686B ) Chipset
 ATI Rage XL 2X VGA Chip with 8MB Video
Memory
 PROMISE PDC20265R with RAID 0 or 1 support
 Dual Intel 82559 LAN chip
Memory Support
 Four 25 degree angled 168 Pin DIMM sockets for
SDRAM modules
 Supports up to 2GB PC-100/PC-133 Error
Checking and Correction (ECC) either un-buffered
or registered memory and VCM SDRAM
 Supports only 3.3V SDRAM DIMM
Storage Controller
 Max 4 IDE ATA channels ( 2 x ATA-66 and 2 x
ATA-100 for IDE RAID 0 or 1 )
 Support front-accessible 2 hot-swap drives featuring
IDE ATA-100 transferring rate
 44MB Floppy Disk Drive ( Slim type )
 High Speed IDE CD-ROM Drive ( Slim type)
Networking
 On board dual LAN, Ethernet 10/100 WOL (Wake

System Installation Guide
1-3
On LAN)
 Adaptive fail over feature
 Load balance feature
I/O Expansion Slot
 PCI raisers , 1 slot ,support 33MHz & PCI 2.2
compliant
Build-in I/O ports
 1 x PS/2 Keyboard port
 1 x PS/2 Mouse port
 1 x COM port
 1 x VGA port
 1 x LPT port
 2 x RJ-45 ports
 2 x USB ports
Power
 Total output power 250 W
 Input : Rating switch full range 90V~250V 47~63
Hz
Operating Temperature
 5 to 40 degree C
Thermal Solution
 Special-designed Heat-sink and hi-efficiency
chassis fans for dual 1 GHz plus processor thermal
solution

System Installation Guide
1-4
Other Features
 Support Wake On LAN ( WOL )
 Support External Modem Ring On
 Optional DOC solution for embedded
Internet/Networking Applications
O/S Support
 Windows NT ,Windows 2000 ,Linux ( RED HAT
7.0 , Netware 5.0
Chassis Dimensions
 Height 44.45 mm ( 1.75 In. )
 Width 482.6 mm ( 19.0 In. )
 Depth 609.6 mm ( 24.0 In. )
 System weight 11.8 Kg ( 26 lbs )

System Installation Guide
2-1
2. Hardware Inventory
When you unpack your GS-SR101 Rack Mount Server,
Check that all the items that you ordered are present in
good condition. Review the inventory checklist below to
be sure that the components and optional components
that you ordered are included. If anything is miss or
damage, contact your retailer as soon as possible.
 Chassis
 Power Supply ( Installed )
 Motherboard GA-6VTXDR ( Installed )
 Manuals (M/B user’s Manual & System
Installation)
 Hard Disk Drive Tray x 2
 Flat Screw # 6-32 * 5L x 12 ( For HDDs)
 Fan + Heat sink x 2
 Case Handle x 2
 Flat Screw M4*10L x 4 ( For Handle )
 Support CD x1
 Support Floppy Disk x 2

System Installation Guide
3-1
3. System Installation
Note: Please remove the protection plastic cover from
top and bottom side first. If not, the system heat could
not spread from top and bottom side.
3.1. Chassis Cover Removal
Use screwdriver to remove the two screws on the chassis
top cover . ( Fig 1 ) And then slide the top cover out of
the system .( Fig 2 )
Fig-1
Fig-2

System Installation Guide
3-2
3.2. Processor Installation
To install Socket 370 CPU, lifts up bar located next to
the Socket.
And then insert Socket 370 CPU inside Socket, and push
the lever bar back into original position. (Fig-3 & Fig-4 )
CPU-1 CPU-2
Fig-3

System Installation Guide
3-3
Figure 4

System Installation Guide
3-4
3.3. Fan+Heatsink Installation
Click Fan+Heatsink to CPU socket 370 and plug the Fan
power cable to the each CPU cooling Fan connector on
the motherboard . ( Fig-5 )
Make sure the Fan wire is click on the
HeatSink .( Fig-6 )
Figure 5
Figure 6

System Installation Guide
3-5
For CPU1 ,Fan power cable connect to J13 (CPU1
FAN) connector and for CPU2, Fan power cable
connect to J15 (CPU2 Fan) Connector. Note to make
sure the connector is plugged into the header in the
correct and click well. ( Fig-7 )
Figure 7
J13-CPU1 Fan Connector
J15-CPU2 Fan Connector

System Installation Guide
3-6
3.4. System RAM Installation
The motherboard has 4 Dual Inline Memory Module
(DIMM) sockets. The BIOS will automatically detect
memory type and size. To install the memory module,
just push it into the DIMM slot. (Fig-8 )
Fig-8

System Installation Guide
3-7
3.5. Installing Handle
Get Handle and screw from the accessories box. And
then mount the handle on the front panel .( Fig-9 &
Fig-10 )
Fig-9
Fig-10

System Installation Guide
3-8
3.6. Reinstall Top Cover
After the above steps (3.1 to 3.5 ) were finished then
slide a top cover to a chassis (Fig-11 )and use
screwdriver to reinstall the 2 screws on the top
cover .( Fig-12 )
Fig-12
Fig-11

System Installation Guide
3-9
3.7. Hard Disk Drive Installation
Get the quick-swap Hard Disk tray from the accessories box.
And then connect the HDD data cable and Power cable to
Hard Disk Drive. Note IDE data cable Red Line is make sure
to connect Hard Disk Drive pin 1. (Fig-13 & Fig-14)
HDD Power Cable
HDD Data Cable Pin 1
Fig-14
Fig-13

System Installation Guide
3-10
After the above step, mount HDD to HDD tray with
the screw ( Fig-15 ) ,and put HDD tray into the
chassis .( Fig-16 )
Fig-15
Fig-16

System Installation Guide
3-11
When you put HDD tray into the chassis, make sure
that the lever is at
a 90 degree angle to the chassis .( Fig-17 )
Otherwise ,damage may occur to lever. After that
push HDD tray to chassis carefully and make sure
the HDD tray is click into Chassis. (Fig-18)
Fig-17
Fig-18

System Installation Guide
3-12
And then push lever to lock HDD tray into the chassis.
(Fig-19)
Fig-19
If you do not making sure that the lever is at a
90-degree angle to the Chassis ,the HDD tray click
may be damage .( Fig-20 )
HDD Tray Click
Fig-20
