Gigaset GS270 User manual

Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / Cover_front_c.fm / 9/11/17
GS270
GS270 plus
You can also find the user guide
online on your smartphone

2
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Contents
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / GS270IVZ.fm / 9/11/17
Contents
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Gigaset GS270 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Start screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Illustration in the user guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Using the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Getting to know your device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Configuring the start screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Notifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Downloads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Fingerprint sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
“Do not disturb” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Additional functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Making calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Messages (SMS/MMS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Accounts and location detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Network connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Customer service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Manufacturer's advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Not all functions described in the user guide are available in all countries or from all
network providers.

3
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / overview.fm / 9/11/17
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Gigaset GS270
Overview
Gigaset GS270
1SIM/SD card slot 11 Rear camera
2Message LED 12 Flash / torch
3Front camera 13 Fingerprint sensor
4Receiver 14 Speaker
5Headset connector (3.5 mm jack)
6Volume button (top: +, bottom: –)
7On/Off button
8Touchscreen
9Microphone
10 Micro-USB socket
132 4
6
7
8
9
10
11
12
13
14
5

4
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Start screen
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / overview.fm / 9/11/17
Start screen
Notifications and Status bar
Icons show the arrival of notifications and
various states ( p. 80)
Access to notifications ( p. 20)
Access to quick settings ( p. 16)
Navigation buttons ( p.16)
Favourites bar
Access to the App menu and frequently
used apps ( p. 18)
Start screen display
Number of start screens / position of the
current start screen ( p. 20)
Area for apps and widgets
They can be placed anywhere ( p. 18)
Google search ( p.15)

5
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / user_guide_operating_steps.fm / 9/11/17
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Illustration in the user guide
Illustration in the user guide
Icons
Procedures
Example: Change the time for transitioning to the idle status
¤Settings Device – Display Sleep Select time
Warnings, the non-adherence to which can result in damage to devices or personal
injury.
Important information regarding function and appropriate handling or functions
that could generate costs.
Prerequisite for carrying out the following action.
Additional helpful information.
Step Follow this procedure
¤Tap the icon in the middle of the Favourites bar. The App menu
opens.
Note: You can skip this step if the app you want to open is on a
start screen.
¤Settings Tap the Settings app. The Settings menu opens.
¤Device – Display In the Device area, tap Display.
¤Sleep Tap Sleep.
¤Select time Tap the required time
= Selected, = Not selected

6
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Safety precautions
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / security_LUG.fm / 9/11/17
Safety precautions
General information
•For your own safety, only use original, approved accessories from Gigaset for your mobile phone. Using
incompatible accessories can damage the mobile phone and entail hazardous situations. Original acces-
sories can be purchased from Gigaset Customer Service (see Customer service ( p. 77).
•The mobile phone is not waterproof. The device or its accessories must therefore not be kept or charged
in damp environments (in bathrooms, shower rooms or kitchens, for example). Rain, moisture or any liquid
can contain minerals which can cause the electrical circuitry to corrode. There is a risk of electric shock, fire
or damage when the device is being charged.
•Permitted temperature range for charging and operation: 0-40°C.
High temperatures can shorten the life of electronic devices and damage the battery; plastic parts can
deform or melt. Using or keeping the mobile phone in refrigerated areas can result in condensation on the
inside of the telephone which will destroy the electronic circuitry.
•The mobile phone must not be used or kept in dusty or dirty places. Dust can be a reason for the mobile
phone to malfunction.
•Switch off your mobile phone when in potentially explosive areas and observe all warning signs. Poten-
tially explosive areas also include places where switching off vehicle engines is normally recommended. It
is at these kinds of places that flying sparks can be the cause of explosions or fires with resulting injuries,
and there may be a risk to life.
These areas include petrol stations, chemical factories, transport and storage systems for hazardous chem-
icals, spaces under ship decks, areas in which the air contains chemical substances or fine particles (such
as dust or metal powder particles).
•Short-circuiting, disassembling and modifying the mobile phone are not permitted because they present
a risk of injury, electric shock, fire or damage to the charger.
•The USB connection must be established with USB version 2.0 or higher.
•If the mobile telephone becomes hot, changes colour or shape or leaks whilst being used, charged or at
any other time, contact Gigaset Customer Service immediately.
Battery and charging
•The battery is built-in. Do not disassemble, weld and/or modify the battery. Do not keep the mobile tele-
phone where it is exposed to strong mechanical effects.
•The battery electrolyte coming into contact with eyes can cause a loss of eyesight. If electrolyte does enter
an eye, please do not rub the eye with a hand. Immediately wash the affected eye thoroughly with clear
water and consult a doctor. The electrolyte coming into contact with skin (or clothing) presents a risk of
skin burns. Immediately wash the skin or clothing thoroughly with soap and clear water, and consult a
doctor if required.
•The temperature of the mobile phone rises during the charging process. Do not store the mobile tele-
phone in the same place as flammable products as this poses a risk of fire.
•Do not charge the battery for longer than 12 hours.
•Only charge the device indoors. Whilst the phone is charging, do not use the phone for calls or dial any
numbers.
•The socket must be easily accessible during the charging process.
•Electrical storms pose a risk of electric shocks.
•Do not use the charger when the power cable is damaged because this poses a risk of electric shock and
fire.
Please read these instructions carefully. Failure to comply presents a risk of injury and damage to
a device, as well as breaches of applicable laws.
Please explain the contents of this document as well as the potential risks associated with using
this device to your children.
Dispose of used mobile telephones in line with the instructions (Chapter Waste and environmen-
tal protection ( p. 78).

7
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / security_LUG.fm / 9/11/17
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Safety precautions
Headset
•If you wear headphones whilst out walking or running, please ensure that the cord does not wrap itself
around your body or objects on your person.
•Only wear headphones in dry environments. The static electricity which builds up on the headphones can
discharge via your ears as an electric shock. The static electricity can discharge if you touch the head-
phones with your hand or touch bare metal before connecting with the mobile phone.
Use in hospitals / medical devices
•The function of medical equipment near your mobile phone can be impaired. Bear in mind the technical
conditions of the environment in question (such as in doctors’ surgery).
•If you use a medical device such as a pacemaker, please consult the manufacturer of the product before
using your mobile phone. You will be provided information on the sensitivity of the device to external,
high-frequency energy sources.
•Heart pacemakers, implantable cardioverter defibrillators:
When you switch on your mobile phone, ensure that the distance between the phone and an implant is at
least 152 mm. To reduce potential interference, use the mobile phone on the opposite side to the implant.
Please switch the mobile phone off immediately if interference occurs. Do not keep the mobile phone in
a shirt pocket.
•Hearing aids, cochlear implants:
Some digital wireless devices can interfere with hearing aids and cochlear implants. Please consult the
manufacturers of these products if interference occurs.
•Other medical devices:
If you and the people around you use other medical devices, please contact the relevant manufacturer for
information on whether such devices are protected from radio frequency signals in the environment. You
can also consult your doctor about this.
Emergency calls
•Make sure the mobile phone is switched on and connected to the GSM network. Enter the emergency
number as required and speak.
•Tell the person at the emergency call centre your location.
•Do not end the conversation until the person at the emergency call centre asks you to.
Children and pets
•Keep the mobile phone, chargers and accessories out of the reach of children and pets. Children and/or
pets can swallow the small parts, posing a risk of suffocation and other hazards. A child may only use the
mobile phone under the supervision of an adult.
Playing games
•Playing games on the mobile phone for long periods may mean assuming an unhealthy body posture.
Take a 15 minute break every hour. Stop immediately if you feel unwell during game play. Consult a doctor
straight away if your condition persists.
Aeroplanes, vehicles and road safety
•Switch off your mobile phone in aeroplanes.
Please observe applicable restrictions and regulations. Wireless devices can interfere with the function of
aeronautical equipment. Follow the instructions issued by flight personnel when using your mobile
phone.
•The absolute priority for every vehicle driver and everyone in a vehicle is safety on the roads and for road
users.
Using a mobile phone whilst driving can be distracting and therefore lead to dangerous situations. You
can also be violating applicable laws.
High volumes can impair hearing. Listening to music or conversation with headphones set to a
loud volume can be unpleasant and permanently impair hearing.
To prevent loss of hearing, do not have the volume turned up too high for long periods.

8
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Safety precautions
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / security_LUG.fm / 9/11/17
SIM card, memory card and data connector cable
•Do not remove the card from the mobile phone whilst data is being sent or received as this presents a risk
of data loss and damage to the mobile phone or memory card.
•Charges might apply when establishing Internet connections via the SIM card.
Defective devices
•The installation and repair of products are the sole preserves of qualified maintenance personnel.
•Dispose of faulty devices carefully or have them repaired by our Customer Service team. These devices
could interfere with other wireless services.
•Careless handling of the mobile phone, such as dropping it, can shatter the display and damage the elec-
tronic circuitry and sensitive parts inside.
•Do not use the device if the display is cracked or shattered. Fragments of glass or plastic can injure hands
and face.
•In the event of malfunction of your mobile phone, battery or accessories, please contact a Gigaset Service
Centre for an inspection.
Other important information
•Never point the flash light directly at the eyes of people or animals. Pointing a flash light too near to human
eyes poses a risk of temporary loss of eyesight or impairment of vision.
•The device can heat up when running power-intensive apps or programs for longer periods. This is normal
and has no bearing on the performance of the device.
•When the device warms up, please put it aside for a while and stop the program you were running. Coming
into contact with a hot device can cause minor skin irritations such as redness.
•Do not apply lacquer to the mobile phone. Lacquer and paint can damage the parts of the mobile phone
and may cause malfunction.

9
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / starting.fm / 9/11/17
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Getting started
Getting started
Contents of the package
•A Gigaset GS270 smartphone
•A battery
•A charger cable with power adapter
Getting started
Inserting SIM and SD cards
You can insert two nano SIM cards or one nano SIM card and one micro SD card in the smart-
phone.
¤Open the SIM/SD card slot. To do this, poke a pointed
implement into the small opening on the SIM/SD card slot
and press.
¤Pull out the card slot.
¤Place the nano SIM card(s) / micro
SD card in the card slot.
¤Replace the SIM/SD card slot and push down until it clicks
into place.
Do not exert any force when inserting the SIM or the memory card because doing so
might damage the card slot.
The device detects SD cards with a storage capacity
of 32 GB. Higher capacity cards (to 128 GB) can be
used if formatted on the GS270 (not from a PC).
SIM 2SIM 1 SDSIM 1
or

10
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Getting started
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / starting.fm / 9/11/17
Charging the battery
¤Plug the Micro-USB connector of the charger cable
provided into the Micro-USB socket of the smartphone
¤Connect the power adapter to the USB connector of the
charger cable and connect it to the power source.
The Message LED lights red during the charging process (
p. 3). The device is charged once the Message LED lights green
and the charge icon in the Status bar is filled completely.
Switching on the device
¤Keep the On/Off button pressed until the device vibrates.
When you are requested to unlock the SIM card,
¤use the keypad to enter the PIN of the SIM card
When switching on the device for the first time, a wizard starts which guides you through the
initial configuration.
Wizard for configuring the device
When you switch on your phone for the first time, you are automatically guided through the
most important configuration steps.
Selecting the language
The set language is displayed.
¤Select another language as required tap
Inserting SIM cards
This screen is only shown when no SIM card is inserted:
¤Insert card now ( p. 9)
Insert SIM card later: Skip
Establishing a WLAN connection
Wireless networks (WLANs) in range are displayed.
¤Tap the required WLAN Enter the WLAN password Connect . . . A connection to the
selected WLAN is established
So your phone does not discharge during set-up, keeping it connected to the power
is recommended until set-up is complete.
<Back: Check and change as required settings already configured.
Next > Apply the setting on the screen and jump to the next screen.
Skip Configure the setting later.

11
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / starting.fm / 9/11/17
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Getting started
Setting up a Google account
If you have another device on which emails, contacts, calendar entries and other information is
managed, you can transfer this information.
Transferring the account settings from another device
¤Select Copy Google accounts, apps and data from another device Next . . . Run the
steps as described
or
¤Select No, thanks Next
Logging in to the existing Google account
¤Enter the email address and password of your Google account.
or
Creating a new account
¤Enter the email address and password for a new Google account.
Entering a name
You can enter a name to personalise apps.
¤Enter First name and as required Surname using the keypad Next
Setting up email
Gmail is set up once you log in to your Google account.
This is where you can set up email addresses for other mail accounts. The mails are also displayed
in the Gmail app.
¤Select provider Enter access details Next
If you do not want to set up any more email accounts: Not now
Setting up protection for the phone
Protect your smartphone from unauthorised use.
Fingerprint
¤Add fingerprint Next . . . A wizard opens to guide you through the necessary steps.
Additional information p. 27
or
PIN, pattern or password
¤Configure PIN, pattern or password Next Select Pattern | PIN | Password Next
Specify whether the selected protection applies also for starting the device
¤Enter pattern, PIN or password Next Repeat Confirm
The other device has NFC (Near Field Communication).

12
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Getting started
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / starting.fm / 9/11/17
Settings for notifications
¤Select how notifications are displayed when the phone is locked Next
Using Google services
Various services are displayed.
¤Use the switch to enable/disable the service you want to use Next
Settings for the start screen
The start screen is displayed. You can specify various settings for the start screen.
¤Touch and hold the wallpaper on the start screen
Changing the wallpaper:
¤Wallpapers . . . Images saved on the device are displayed Select the wallpaper Tap
Choose wallpaper from
Making widgets available on the start screen:
¤Widgets . . . The available widgets are displayed Touch and hold the required widget . . .
The start screen is displayed Position the widget and release it at the required position
Your smartphone is now ready to use.
Performing this step also means you accept the conditions of use and data protection
declaration of Google.

13
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / operating.fm / 9/11/17
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Getting to know your device
Using the device
Getting to know your device
Switching the device on and off
Switching on
¤Press and hold the On/Off button Unlock the display if required (if a display lock is set up
to protect against unauthorised starting) . . . The device is started
Display lock: p. 53
Unlocking the SIM card
¤Enter the PIN for the SIM card OK
Removing notifications (if available)
Notifications p. 20
When a display lock is set up to protect against unauthorised use
¤Unlock the display . . . The start screen is displayed
Display lock: p. 53
Switching off
¤Press and hold the On/Off button Tap Power off OK
Switching on and off at certain times
Automatically switch the smartphone on and off at certain times.
¤Settings System – Schedule power on & off Enable/disable the functions
with the switches Tap the time currently set for switching on and off . . .
Set the time at which you want to switch the device on or off:
¤Time Set the time OK
Select the days on which the schedule is to apply:
¤Repeat Select the days OK
Save the setting: Done
Clear notification: ¤Swipe to the left or right
Deal with notification later: ¤Swipe upwards to the Notifications bar
You can also switch the smartphone to Aeroplane mode. This only disables the
wireless functions, the other device functions remain available.
Before you can use the device after automatic switch-on, you must unlock the
SIM card and the display.
12:32

14
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Getting to know your device
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / operating.fm / 9/11/17
Switching the device to and ending idle mode
Switching the device to idle mode
¤Briefly press the On/Off button
Setting the period of inactivity for transitioning to idle mode
¤Settings Device – Display Sleep Select period
Ending idle mode
¤Briefly press the On/Off button Remove any notifications as required Unlock the display
Using the touchscreen
Movements and gestures for using the touchscreen:
Tapping
¤Briefly touch the screen with your finger
Examples:
Start an app, and select function or setting: tap the element
Enter text: Tap a text field . . . A keypad is shown
Touching and holding
¤Keep your finger on an element until it responds.
Dragging and releasing
¤Touch and hold the element Move your finger across the screen to the place required
Release the element
Example: Moving apps on the start screen
Swiping or dragging
¤Move your finger quickly across the screen without stopping
Example: Switching between the start screens
Double tapping
¤Tap the screen twice quickly in succession.
Example: Zooming. Only possible for special screens (such as websites or maps).
If the device is not used for a defined time, it automatically switches to idle mode.
Some apps can be accessed directly from idle mode with a fingerprint ( p. 27) or
code ( p. 23).
Zoom in: ¤Tap twice quickly in succession
Zoom back out: ¤Tap twice again

15
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / operating.fm / 9/11/17
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Getting to know your device
Spreading apart / pinching together your fingers
¤Place two or more fingers on the screen at the same time
Example: Scaling screen content. Only possible for special screens (such as Google Maps and
Chrome).
Start screen
A start screen is displayed when you switch on or unlock the
device, and no app is open.
Elements on the start screen p. 4
You can create several start screens and configure them as you
wish - to be able to quickly access favourite apps and content
( p. 18).
Returning to the start screen from any user situation
¤Tap the Navigation button . . . The start screen which
was open last time is displayed
Switching between start screens
¤Swipe left or right to the required start screen.
Browse smartphone and Internet
At the top of every start screen is Google search, enabling you to search on your smartphone and
browse the Internet.
Entering a search term
¤Tap the Search bar Enter a search term using the keypad
Search using voice entry
¤Tap the Microphone icon Speak your search term into the microphone
Additional information Google Help
Zoom in: ¤Spread your fingers apart
Zoom out: ¤Pinch your fingers together

16
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Getting to know your device
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / operating.fm / 9/11/17
Switching between start screens and apps
At the bottom of every screen are three Navigation buttons:
When the Navigation buttons are not shown: Tap the bottom of the screen
Quick settings
The quick settings enable you to access frequently used settings from all user situations, such as
screen lighting, WLAN, Bluetooth and similar settings.
Opening the quick settings
¤From the Status bar, swipe down . . . The most important quick settings are displayed
¤Swipe down again, or tap in the top right . . . More quick settings are displayed Swipe
left/right to display all the quick settings
Icons of the quick settings p. 80
Enabling and disabling a function
¤Tap the setting . . . Settings are white when enabled and not shown when disabled
Changing a setting
Settings for which there are more options (e.g. WLAN or Bluetooth) have a small arrow next to
the name.
¤Tap the name under the icon Change the setting as required
Editing quick settings
You can make available more quick settings, remove any not used and rearrange the icons.
¤Tap Edit . . . Quick settings not being used are shown at the bottom Touch and keep your
finger on the icon, and drag it to the required position
Finish editing: Tap in the top left
Restore to default settings: Tap Reset
Opens the screen last viewed, even if it belongs to another app. You can go back several
times (only as far as the start screen).
Opens the start screen which was open last time.
Opens an overview of the apps and browser tabs used last time.
Open an app: ¤Tap it
Close an app: ¤Swipe the app left or right

17
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / operating.fm / 9/11/17
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Getting to know your device
Setting vibration and ringtone with the On/Off button
¤Press and hold the On/Off button
The currently selected setting is underlined.
¤Tap the setting you want to enable
Writing and editing text
Use the Google keypad to write text.
Opening the keypad
¤Tap a place where text can be entered
You can enter letters, digits and special characters.
Switching between entry of letters and digits / special
characters: Tap
Adding text
Whilst text is being entered, suggestions from the keypad dictionary are shown above the
keypad.
Editing text
Enable ringtone Enable vibration
Disable ringtone
Entering letters and symbols: ¤Tap a key
Entering uppercase letters: ¤Tap the shift key ( )
Enabling/disabling Caps Lock: ¤Double tap the shift key ( )
Showing umlauts: ¤Touch and hold the key
Using a suggestion: ¤Tap the word . . . The word is included and a space is
inserted automatically
Positioning the cursor: ¤Tap the place in the text where you want to position
the cursor
Moving the cursor: ¤Swipe left or right on the text
Selecting text: ¤Touch and hold a word Select more or less text
with tabs on both sides
Deleting a character: ¤Touch and hold the backspace key
Cutting and copying text: ¤Touch and hold the text Tap Cut or Copy
Pasting text: ¤Touch and hold the cursor Tap Paste

18
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Configuring the start screens
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / operating.fm / 9/11/17
Changing the keypad settings
You can change various keypad settings, such as the language for the keypad assignment, the
response to keypresses and the keypad design.
¤Settings Personal – Languages& input Virtual keyboard Android key-
board
Setting voice entry
If an app permits it, you can also enter text by speaking into the microphone. The function is
enabled by default.
Enable/disable voice input:
¤Settings Personal – Languages& input Virtual keyboard Manage
keyboards Enable/disable Google Voice input with the switch
Voice input settings:
¤Settings Personal – Languages& input Virtual keyboard Google Voice
input
Configuring the start screens
You can create several start screens and configure them as you wish - to be able to quickly access
favourite apps and content.
Tailoring the Favourites bar
At the bottom of every start screen is the Favourites bar, from which you are able to quickly
access the apps you use most frequently.
Removing apps from the Favourites bar
¤Touch and hold an app in the Favourites bar
¤Drag the app to the Remove button at the top of the screen and release your finger
or
¤Drag it to somewhere else on the screen and release your finger
Adding an app
¤Select the required app Touch and hold the app . . . The start screen is shown in the
background Drag the app to a free space in the Favourites bar and release your finger.
Opening the menu with all the apps: Tap the icon in the middle
The apps in the App menu are in alphabetical order.
Scrolling through the list: Swipe up or down

19
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / operating.fm / 9/11/17
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Configuring the start screens
Changing the wallpaper
¤Touch and hold the wallpaper Tap Wallpapers Select an image from the predefined
backgrounds or your own photo from My photos Tap Set wallpaper
Adding an app to a start screen
¤Open the App menu Look for the required app Touch and hold the app . . . Drag
the app to a free space in a start screen and release your finger
Adding a widget to a start screen
Widgets are components that are specifically intended to be displayed on a start screen,
e.g. a clock, a calendar extract for the current day, an important entry from the contact list or a
direct dial.
¤Touch and hold a free space on a start screen Tap Widgets
¤Touch and hold the required widget . . . Images for the start screen are shown in the
background Drag the widget to a free place on a start screen and release your finger
The sizes of some widgets can be changed:
¤Touch and hold a widget Release your finger . . . If the size of the widget can be changed,
you see a dotted frame on the edges Change the size of the widget by dragging the dots
Once the correct size is set: Tap anywhere outside the widget
Moving apps and widgets
¤Touch and hold an app or widget on a start screen Drag the app or widget to the required
position and release your finger, or drag it to the left or right to another start screen and
release your finger
Creating folders for apps
¤Touch and hold an app on a start screen Drag the app icon over another app icon
Adding apps:
¤Touch and hold an app Drag it to the folder
Renaming a folder:
¤Open the folder Tap the name . . . The keypad opens Delete the old name Enter
the new name
Removing an app or widget
¤Touch and hold an app or widget on a start screen Drag it up to option Remove and
release your finger
More wallpaper images can be downloaded from Google Play.

20
Template Go, Version 1, 01.07.2014 / ModuleVersion 1.0
Notifications
Gigaset GS270 / LUG International en / A31008-N1503-R101-1-7619 / operating.fm / 9/11/17
Adding, rearranging and removing start screens
The number of start screens set up is shown by dots above the Favourites. The bigger dot
indicates the position of the current start screen.
Adding start screens
¤Touch and hold an app Drag the app all the way to the right until a blank start
screen is shown Release your finger . . . A new start screen is created and the app is placed
on it
Rearranging start screens
¤Touch and hold a free space on a start screen . . . Images for the start screens are displayed in
the background Touch and hold an image for a start screen Drag it to the left or right to
the required position and release your finger
Removing a start screen
¤Remove all apps and widgets from a start screen (by deleting them or moving them to
another start screen) . . . When the last app or widget has been removed, the start screen is
deleted
Notifications
Notifications inform you about various events, such as the arrival of a new voice message or
email, appointments or wake-up calls.
Notifications are displayed as follows:
•In the Notifications bar:Swipe over the screen from the top down
An icon in the Notifications bar denotes which notifications are available ( p. 80).
•On the lock screen: when the phone starts and when returning from idle mode
•At the top of the screen whilst you are doing something else on your phone, such as reading
an email or watching a video
Changing the settings for displaying notifications: p. 21
Flashing of the Message LED ( p. 3) also indicates the following events:
•New email
•New message (SMS/MMS)
•Missed call
•Appointment notification
•Alarm
