Gira 5110 00 User manual

Operating instructions
32591122 / 10867569 / 14.11.2022
RF/TP media coupler/repeater
Order no. 5110 00

RF/TP media coupler/repeater
Table of Contents
1 Safety instructions.............................................................................................................3
2 Device components...........................................................................................................3
3 Function ............................................................................................................................4
4 Operation as media coupler or segment coupler ..............................................................5
5 Operation as RF repeater without routing function ...........................................................6
6 Information for electrically skilled persons ........................................................................6
6.1 Mounting and electrical connection........................................................................ 6
6.2 Commissioning ...................................................................................................... 7
7 Technical data...................................................................................................................8
8 Accessories.......................................................................................................................8
9 Warranty............................................................................................................................9
2 / 9
32591122 10867569 14.11.2022

1 Safety instructions
Electrical devices may only be mounted and connected by electrically skilled
persons.
Serious injuries, fire or property damage possible. Please read and follow manual
fully.
The radio communication takes place via a non-exclusively available transmission
path, and is therefore not suitable for safety-related applications, such as emergency
stop and emergency call.
This manual is an integral part of the product, and must remain with the end cus-
tomer.
2 Device components
Image1: Device components
(1) KNX connection (TP)
(2) Programming button
(3) Status LED
Red lit up: Prog. mode
Red flashing quickly: Filter function deactivated
Red flashing slowly: Safe-state mode active
Yellow flashing: telegram traffic
Yellow lit up: Repeater prog. mode (for devices with marking "I04" or higher)
(4) Antenna (RF)
3 / 9
32591122 10867569 14.11.2022
RF/TP media coupler/repeater

3 Function
System information
This device is a product of the KNX system and complies with the KNX directives.
Detailed technical knowledge obtained in KNX training courses is a prerequisite to
proper understanding.
The range of a radio system depends on various external circumstances. The range
can be optimised by the choice of installation location. The product documentation for
this device contains application basics for the KNX radio system.
Planning, installation and commissioning are carried out using ETS version 5 or
higher. You can find the up-to-date product database, technical descriptions and De-
claration of Conformity on our Internet site.
Overview of device versions
Devices with marking "I00": no KNX Data Secure compatibility. Secure commission-
ing of other devices via media coupler is not possible with this device version.
Devices with marking "I01" or higher: KNX Data Secure compatibility from ETS5.7.3.
Secure commissioning of other devices via media coupler is possible without restric-
tions from this device version. KNX Data Secure offers protection against manipula-
tion in building automation and can be configured in the ETS project. Detailed spe-
cialist knowledge is required.
Devices with marking "I04" or higher: use as segment coupler possible for commis-
sioning with ETS version 6.0.5 or higher.
The devices are update-capable. Firmware updates (e.g. I01 -> I04) can be carried
out conveniently using a special ETS application program. See the technical docu-
mentation for details.
Simplified Declaration of Conformity
Hereby Gira Giersiepen GmbH & Co. KG declares that the radio system type
Order no. 5110 00
corresponds to the directive 2014/53/EU. You can find the full article number on the
device. The complete text of the EU Declaration of Conformity is available under the
Internet address: www.gira.de/konformitaet
Intended use
– Connection of KNX radio networks with grid-bound KNX lines
– Increasing radio range in KNX radio networks (repeater operation)
– Mounting in appliance box with dimensions according to DIN 49073
4 / 9
32591122 10867569 14.11.2022
RF/TP media coupler/repeater

Image2: Media coupler and RF participant
Image3: Media coupler and RF participant, supplemented by repeater
(5) Media coupler or segment coupler
(6) KNX power supply with choke
(7) Repeater
(8) Power supply
4 Operation as media coupler or segment coupler
Media coupler: The physical address is the address of a line or a backbone coupler
x.y.0 and must match the logical topology of the KNX system.
Segment coupler: The physical address is the address of a normal KNX participant
x.y.z (z≠0) and must match the logical topology of the KNX system.
Observe the instructions in the technical documentation regarding the address.
Power is supplied via the KNX bus cable.
With operation as a media coupler or segment coupler, the repeater function
can also be activated.
5 / 9
32591122 10867569 14.11.2022
RF/TP media coupler/repeater

5 Operation as RF repeater without routing function
The physical address of the radio repeater is the address of a normal KNX participant
x.y.z (z≠0) within the address range of the KNX radio system. Observe the instruc-
tions in the technical documentation regarding the address.
Power is supplied via a separate power supply (accessory) or via the connection to a
KNX line.
Do not use the unchoked 30 V output of a KNX power supply. The media
coupler may heat up to an impermissible temperature.
Repeater mode is active after the physical address is assigned. Once this hap-
pens, programming via bus line is blocked. Then the device can only be
reached by radio. To address the device via the bus line, reset the device to
default settings.
6 Information for electrically skilled persons
DANGER!
Mortal danger of electric shock.
Cover up live parts in the installation environment.
6.1 Mounting and electrical connection
Mounting and connecting the device
Mount in flush-mounted or surface appliance boxes.
In outdoor installations: Use appliance box IP55.
￭ For operation as media coupler/segment coupler: Connect the device to the
KNX bus cable via a bus terminal.
￭ For operation as repeater: Connect the device to a separate power supply or a
KNX bus cable via a bus terminal.
￭ Place the device in the appliance box.
￭ When laying the antenna, extend the antenna extended as much as possible.
If this is not possible, position the antenna behind the device in a circular ar-
rangement.
In the case of blank covers, do not place the antenna behind the metal sup-
porting frame.
Selecting installation location
– To ensure good transmission quality, keep a sufficient distance from any pos-
sible sources of interference, e.g. metallic surfaces, microwave ovens, hi-fi
and TV systems, ballasts or transformers.
6 / 9
32591122 10867569 14.11.2022
RF/TP media coupler/repeater

– Do not mount the media coupler near the earth or ground.
– Do not place KNX RF devices in metallic small distribution boards or boxes.
– If several adjacent media couplers are used, place them so their radio ranges
either do not overlap at all, or so they can receive each other. Check within a
system to see if a media coupler can be configured as a repeater.
Media couplers must be accessible even after mounting.
6.2 Commissioning
Commissioning of media coupler/segment coupler
Device connected, power switched on.
￭ Press the programming button.
The status LED lights up red.
￭ Download the physical address and domain address.
The status LED goes out.
￭ Download the filter table and parameters.
Activating the safe-state mode
￭ Disconnect the device connection terminal.
￭ Hold down the programming button.
￭ Reconnect the device connection terminal.
The device restarts. The status LED briefly lights up red and then yellow.
￭ Release the programming button as soon as the status LED starts flashing red
slowly.
Safe-state mode is active.
Activating RF repeater mode
Safe-state mode is activated.
￭ Press programming button again and hold about 2seconds until status LED
lights up yellow.
The device is in "Repeater prog. mode".
￭ Release the programming button.
￭ Commission the device with a physical address x.y.z (z≠0).
The device is in RF repeater mode.
Resetting the device to the factory setting
Safe-state mode is activated.
7 / 9
32591122 10867569 14.11.2022
RF/TP media coupler/repeater

￭ Press programming button again and hold about 5 seconds until status LED
goes out.
￭ Release the programming button.
The status LED lights red briefly and then yellow.
The device is reset to default setting.
7 Technical data
KNX RF
KNX medium RF1.R
Commissioning mode S-mode
Radio frequency 868.0 ... 868.6 MHz
Transmission capacity max. 20 mW
Transmitting range in free field typ. 100 m
Receiver category
(Data according to EN 300220)
2
KNX TP (media coupler/segment coupler operation)
KNX medium TP256
Commissioning mode S-mode
Rated voltage KNX DC 21 ... 32 V SELV
Current consumption KNX 3.9 ... 5.1 mA
Repeater operation
Rated voltage DC 24 V SELV
Degree of protection IP20
Protectionclass III
Ambient temperature -20 ... +45 °C
Storage temperature -25 ... +55 °C
Transport temperature -25 ... +70 °C
Relative humidity 10 ... 100 % (no moisture condensation)
Dimensions L×W×H 44x29x16 mm
8 Accessories
Power supply 24 V DC 300 mA Order no. 1296 00
8 / 9
32591122 10867569 14.11.2022
RF/TP media coupler/repeater

9 Warranty
The warranty is provided in accordance with statutory requirements via the specialist
trade. Please submit or send faulty devices postage paid together with an error de-
scription to your responsible salesperson (specialist trade/installation company/elec-
trical specialist trade). They will forward the devices to the Gira Service Center.
Gira
Giersiepen GmbH & Co. KG
Elektro-Installations-
Systeme
Industriegebiet Mermbach
Dahlienstraße
42477 Radevormwald
Postfach 12 20
42461 Radevormwald
Deutschland
Tel [phone] - 602-0
Fax [phone] - 602-191
www.gira.de
[email protected]
9 / 9
32591122 10867569 14.11.2022
RF/TP media coupler/repeater
