Gison GPW-220 User manual

GPW-220
Pneumatic Waterfed Sander
Maintenance Manual
GISON MACHINERY CO., LTD
No.2, Alley 105, Lane 68, Sec. 2,
Sinan Rd., Wurih, Taichung 414, Taiwan
Tel [phone]
Fax [phone]
E-Mail [e-mail]
http //www.gison.com

1
Tools Needed
You will need the following tools
 Screw Driver  3mm Hex. Spanner  2mm Hex. Spanner
 Selection of Dismantling Tools
Tools For Disassembling Cylinder ssy.
Socket ix Stand Bearing Diassembling Shaft
218027 220050-1 218050-2
6.1mm Shaft Bearing Diassembling Base Bearing Diassembling Base
218050-3 218050-5 218050-5
Tools For ssembling Cylinder ssy.
Rotor Disassembling Shaft Oil Compress Shaft ront Plate Base
218051-2 218051-3 218051-4
Bearing Compress
Shaft 1 Rear Plate Base Bearing Compress Shaft 3
218051-5 218051-6 218051-7

2
7
9
3
6
2
8
1
Steps Of Dismantling GPW-220
Disassembling Instructions ssembling Instructions


 Disassemble Exhaust Plate Set (1),
Take off Cylinder ssembly (2).


 Remove Pad (3) by using spanner.


 Loosen Locking Screw Cap (6) and
take off Spindle ssembly (7).


 Take off Water Inlet Transfer Pos
(8).


 Take off Oil Seal (9).


 Assemble Spindle ssembly (7) and
tighten Locking Screw Cap (6).


 Put Cylinder ssembly (2) in the
Housing.


 Place Exhaust Plate Set (1) behind
Cylinder and loosen it.


 Assemble the Oil Seal (9) and
Water Inlet Transfer Pos (8).


 Load Pad (3) on spindle.


 WARNING ！
！！
！
Please follow above Disassembling and Assembling Instructions; otherwise the
Oil Seal (9) may be broken. It will cause water leaking and damage the tool.
B
C

3
38
40
Screw Driver
42
41
Water Regulator Set
M5x0.8
30
( ) Maintenance of Water Regulator ssy.
 Unscrew Screw (36) with Screw Driver and take off Shifting
Knob (35).
 Use pliers to remove Spring Pin (34) and take off Bushing
(32).
 Insert Cap Screw ‘M5 x 0.8’ into Exhaust Plate Set (30), tap
the Cap Screw gently using a hammer or using hand presser to
pull out Water Regulator Set . Check and clean inside.

4
C linder Assembl
(18~26)
3mm Hex. Spanner
Reverse Exhaust Plate Set
27
2mm Hex. Spanner
17
31
28
29
(B) Maintenance Steps For Cylinder ssy.
 Loosen Cap Screw (31) using 3mm Hex. Spanner and remove
Reverse Exhaust Plate Set (30).
 Take off Gasket (29), Water Inlet Tube (17), Rubber Sleeve
(28) and Cylinder Bushing (27).
 Loosen Set Screw (42) using 2mm Hex. Spanner and pull out
Cylinder ssembly (18~26).
Caution :
When reassembling Cylinder (21) Assembly, firstly put the
Cylinder (21) in right place and rotate Spindle ssembly
(3~8) and check if it spins smoothly. Tighten the Screws (42)
on ront Plate in clockwise direction by using 2mm Hex.
spanner. Secondly tighten 4 Cap Screw (31) and check again if
spindle rotates freely. If not, disassemble Cylinder Assembly
and investigate the problem.

5
22
Rotor Disassembling
Shaft (218051-2)
C linder Assembl
(18~26)
C linder Fix Stand
(218050-1)
Exploded View
Rear Plate Ass . (24,25)
Front Plate Ass . (18,19)
23
21
26
(B-1) Replacing Consuming Parts
 Put Cylinder ssembly (18~26) on Cylinder Fix Stand
(220050-1).
 Place Rotor Disassembling Shaft (218051-2) on top of
Cylinder ssembly (18~26), use hand presser to
disassemble (Exploded View) and change Blades (23).
Cylinder Fix Stand
(220050-1)

6
18
Bearing Disassembling
Base (218050-5)
18
Bearing Disassembling
Shaft (218050-2)
19
6.1mm Shaft (218050-3)
Bearing Disassembling
Shaft (218050-2)
Bearing Disassembling
Base (218050-5)
25
24
(B-2) Steps For Dismangling Front Plate ssy.
Place Front Plate ssembly (18,19) on Bearing Disassembling
Base (218050-5) and use Bearing Disassembling Shaft
(218050-2) to separate Cylinder Cap (19) and Bearing (18).
(B-3) Dismangling Steps For Rear Plate ssy.
Put Rear Plate ssembly (24,25,54) on Bearing Disassembling
Base (218050-5) and use Bearing Disassembling Shaft
(218050-2) and 6.1mm Shaft (218050-3) to separate Rear
Cylinder Cap (24) and Bearing (25).

7
Rear Plate Base
(218051-6)
Rear Plate Ass .
(24,25)
22
Bearing Compress
Shaft (218051-5)
23
(B-4) ssembling Steps For Cylinder ssy.
 Press Bearing (25) into Rear Plate (24).
 Place Rear Plate ssembly (24,25,54) on Front Plate Base
(218051-6), press Bearing Compress Shaft (218051-5) into
Rotor (22) and press it into Rear Plate ssembly
(24,25,54).Place 4 Blades (23) into the groove of Rotor (22).
Front Plate Base
(218051-4)
24
Bearing Compress
Shaft (218051-7)
25

8
Assembl Shown
On Setp 3
Bearing Compress
Shaft (218051-5)
19
18
18
 Place Cylinder (21) on the assembly shown on Setp 2 and
ensure the Spring Pin (20) matches the small ixed Hole in
Rear Cylinder Cap (24).
 Plate Cylinder Cap (19) on the assembly shown on Step 3,
press in Bearings (18) using Bearing Compress Shaft
(218051-5).
Assembl Shown
On Setp 2
Fixed Holes
Bearing Compress
Shaft (218051-5)
21

9
Spindle Assembl
(3~8)
Socket
(218027)
10
1
1/2" Impact Wrench
(C) Maintenance Steps For Spindle Ass .
 Place Socket (218027) on Locking Screw Cap (10) and loosen
it using 1/2” Impact Wrench.
 Take off Spindle ssembly (3~8).

10
Rotor Disassembling
Shaft (218051-2)
7
8
4
3
Gasket
(218050-4)
5
(C-1) Replacing Consuming Parts
 Use pliers to remove Locking Key (5), take off Bearing (8)
and Spiral Gear (7) for changing consuming parts.
 Put Rotor Disassembling Shaft (218051-2) on top of
Spindle (4) and use hand presser to separate Spindle (4) and
Bearing (3) for changing Bearing (3).
