Glacial 8LCH-KK-SSS-5i User manual
SAVE THIS MANUAL FOR FUTURE USE
WARNING:
TO REDUCE THE RISK OF INJURY, USER
MUST READ INSTRUCTION MANUAL
BEFORE OPERATING PRODUCT.
Model No. : 8LCH-KK-SSS-5i
SELF CLEAN hot and cold
water cooler and
SINGLE CUP COFFEE BREWER
USER MANUAL
The appearance of your product may
dier from the above illustration.
8LCH-KK-SSS-5i © 2016 Electrotemp Technologies Inc. PN: 5M011483XX00(E)
For service call: 1-844-452-2425
User of mineral water
please read descaling
instructions on the
page 13
FEATURES
Getting to know your Single Serve Turbo Brewer with
Self Cleaning Water Cooler for use with Coffee Capsule or
equivalently Pre-Packaged Coffee.
2
4
3
4. Turbo Heater provides plenty of hot
water. No waiting time between cups
of coffee. Direct supply of water from
5 gallons bottle means no refilling of
the coffee water tank. Combines the
benefits of premium quality water
with gourmet coffee to make a deli-
cious cup of coffee.
2. High temperature, preheated hot
water is ready to pour through your
Coffee Capsule, making a very fast,
yet fully developed cup.
3. No more thin, watery cups of
coffee. Brews at 201°F, a tem-
perature experts recommend for
full bodied, robust flavor extrac-
tion. A full 9°Fhotter than other
Single Cup Coffee Makers.
1. 2 in1 appliance saves on
valuable counter space.
12
3
5. Sophisticated Advanced Technology
System keeps water HOT and Energy
consumption down.
9. Steaming hot water makes rich, full flavored coffee out of regular Coffee Capsule
with your choice of bottled water.
7
8
7. Efficient refrigeration provides up to 1.6 gallon of
X-cold water per hour, while making an ice bank for
more and colder water. X-Cold technology uses ice
to chill the water to the lowest average temperature
in the industry.
6. Continuous dispensing for 6cups of coffee,
no waiting time for heating water. Easy to
use intuitive prompt menu.
8. Dispenses water for 5 cup sizes, 4
oz, 6 oz, 8 oz, 10 oz and 12 oz.
Coffee Capsule conveniently
stored. Properly hot water allows to
make an America favorite Medium
Roasted Coffee for Smooth and
Rich Flavour. Other Brewers with
lower water temperature rely on
dark roast for more flavour.
5
6
4
10. Exceptional hot tank performance and safety efficient,
produce hotter water at all times, has a great insulation,
triple safety, good for mineral water use.
a. Our patented design maintain steady 201°F
temperature of hot water.
b. Superior Mineral based insulation keeps heat
where it belongs.
c. Hot Tank Triple safety includes temperature
regulating and high temperature thermostats plus
fusible link, that melts when overheated.
d. External heater allows use of mineral water without
causing heating element failure due to calcification,
as it is common in the hot tank with the internal heaters
Decalcification required once per year only when used with tap or
Spring/mineral water.
e. Patent Pending design of Turbo Heating makes more and hotter
water in the shortest time.
10
11. Superior technology
Patented technology allows for the water tempera-
ture to be controlled within 1 degree F while on
standby. 20 years designed life time. External
heater makes it ideal for use with mineral water.
12. Compliance with ozone emissions.
Prevents slime build up in your water
cooler. Low voltage DC12V Ozonana-
tor is operated by control board.
Ozone emission into an ambient air
meets UL/CSA/OSHA regulations
(<50ppb per 24 hours). Electrical con-
trol panel easily accessible from the
rear of the cabinet.
11
12
5
SOUND’S YOU MIGHT HEAR
Although all functions are very quiet, you might hear following sound’s:
1. When without display cooler plugged in, air pump for an ozone start to work and last for 12 seconds.
After start up it will work every 4 hours for same period of time.
Coolers with display are programmed to have ozone delivery pump to work every 4 hours starting
from 12 o’clock. Very low humming sound.
2. Water Filtration system delivers water to cold tank. Running water into cold tank can be heard also,
like a miniature water fall, or a fish aquarium. Very low sound.
Water pump sound is greater when filter is used, due to the added load.
If you need assistance call 1-844-452-2425.
There are two water level control devices. An Electronic sensor and mechanical float valve.
Electronic sensor activates solenoid shut off valve silently.
Mechanical float valve is similar to toilet bowl float valve. As water level nearing to be full, near
closing the valve higher pitch noise might be heard from the float valve.
This noise will last until cold water tank is full.
3. Hot tank water heater.
During the periods of maintaining steady temperature hot tank operates in silent mode.
When water is dispensed or pre-heat button is activated Turbo function will emit “kettle” like
moderate sound few minutes before it reaches the required temperature.
4. Refrigeration compressor works when water needs to be cooled. It has very low pitch humming
noise like your refrigerator
5. In some cases sound resulting from installation on hard flooring is present. Place Sound absorbing
mat under your cooler to eliminate this noise. Mat is supplied with your cooler.
ATTENTION
To avoid damage, malfunctioning and plugging up top piercing needle.
Do Not Use same K-Cup or an equivalently packed Single Serve Coffee Cup twice, do not use
Espresso cups, use only K-Cup or an equivalently packed Single Serve Coffee Cups made for drip
coffee use only.
If flow and amount of dispensed water deteriorates, use paper clip to clean top piercing needle, as
described in the manual. To wash the brewing pot dispense hot water without placing K-cup or
equivalent Single Serve Coffee Cup.
It is recommended to use purified water made by Reverse Osmosis, or Distilled, without mineralization.
This way internal valves and hot tank will not clog up with calcium deposits and help to keep your
machine trouble free without any need for descaling.
Please place water bottle and plug power cord into electrical outlet.
Wait until water is fully filled. Check for hot water faucet dispensing water.
Turn hot tank power switch on.
To fill bottle door must close and activate door switch.
If door got distorted during shipping, please twist it back into position.
6
SAFETY PRECAUTIONS
To reduce risk of injury and property damage, user must read this entire manual before
assembling, installing & operating combination unit providing coffee brewer and water
dispenser.
Failure to execute the instructions in this manual can cause personal injury or property
damage.
This product dispenses water at very high temperatures. Failure to use properly can cause
personal injury.
When operating this coffee brewer/water dispenser, always exercise basic safety precau-
tions, including the following unit :
• Prior to use, this unit must be properly assembled and installed in accordance with this manual.
• This unit is intended for coffee brewing and water dispensing only. Do NOT use with other
liquids. Do NOT use for other purposes. Never use any other liquid in the dispenser other than
known and microbiologically safe bottled water. Warranty is void if water cooler portion is used
for any other liquids including coffee, tea, juices, beer or wine. some fluids like juices may
develop harmful bacteria.
• For indoor use only. Keep unit in a dry place away from direct sunlight. Do NOT use outdoors.
• Install and use only on a hard, flat and level surface.
• Do NOT place dispenser into an enclosed space or cabinet.
• Do NOT operate dispenser in the presence of explosive fumes.
• Position back of dispenser no closer than 4 inches from wall and permit free airflow between
wall and dispenser. There must be at least 4 inches clearance on the sides of the dispenser to
permit airflow.
• Use only properly wired and grounded outlets.
• Do not use an extension cord with this unit.
• Use dedicated electrical outlet. Connected load is 14 amps.
• Always grasp plug and pull straight out from outlet lugs bent. Never unplug by pulling on power
cord.
• Do NOT use this unit if cord becomes frayed,or otherwise damaged.
• To protect against electric shock, do NOT immerse cord, plug, or any other part of cooler in
water or other liquids.
• Ensure this unit is unplugged prior to cleaning.
• Never allow small children to dispense coffee or hot water without proper and direct
supervision. Unplug unit to prevent unsupervised use by small children.
• Service should be performed only by a certified technician. Please contact us at 1-844-452-
2425 for assistance, between 9 AM and 5 PM Monday to Friday eastern time.
WARNING
7
SAFETY PRECAUTIONS - Electrical Requirements
WARNING
WARNING
Electrical Shock Hazard
GROUNDING INSTRUCTIONS
For a grounded, cord-connected water cooler:
This water cooler must be properly wired for correct polarity and grounded. In the event of a mal-
function or breakdown, grounding will reduce the risk of electrical shock by providing a path of least
resistance for electric current. This water cooler is equipped with a cord having an equipment-
grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that
is properly installed and grounded in accordance with all local codes and ordinances.
Improper connection of the equipment-grounding conductor can result in a risk of
electric shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the
appliance is properly wired or grounded.
Do not modify the plug provided with the appliance, if it will not fit the outlet, have a proper outlet
installed by a qualified electrician. Do not bend or remove prongs.
“Please make sure that ELECTRICAL OUTLET IS PROPERLY WIRED
TO CORRECT SIZED CIRCUIT BREAKER OR FUSE AND PROPERLY
GROUNDED. MUST BE WIRED TO HAVE CORRECT POLARITY.”
Plug into a grounded 3 prong outlet. Make sure power prongs(lugs) and ground prong are in good
condition, hot bent or altered in any ways. Do not remove ground prong. Do not use an adapter. Do
not use an extension cord.
Failure to follow these instructions can result in death, fire, or electrical shock.
Dedicated power outlet 115/120 volt, 60 Hz., AC only, 15- amp, fused electrical supply is required. A
time-delay fuse or circuit breaker is recommended. Do not overload the circuit, provide separate
circuit, to serve only this appliance.
This water cooler is equipped with a power supply cord having a 3 prong grounding plug.
To minimize possible shock hazard, the cord must be plugged into a mating, 3 prong, grounding-type
outlet, grounded and wired in accordance with local codes and ordinances. If a mating outlet is not
available user is responsible to have properly grounded outlet installed by a qualified electrician.
If codes permit and a separate ground wire is used, it is recommended that a qualified electrician
determine that the ground path is adequate.
Do not ground to a gas pipe.
Check with a qualified electrician if you are not sure the water cooler is properly wired and grounded.
Do not use a fuse in the neutral or ground circuit. It must be installed in the power line only.
This appliance is not intended for use by persons (including children)with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervi-
sion or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
8
Features ......................................................................................................
Sound’s You Might Hear ................................................................................
Attention .........................................................................................................
Safety Precautions .........................................................................................
Safety Precautions-Electrical Requirements..................................................
Key Information for Future Use ......................................................................
Specifications ..............................................................................................
Parts & Features .........................................................................................
Assembly .......................................................................................................
Installation ..................................................................................................
Dispensing Coffee ..........................................................................................
Descaling Your Coffee Brewer/Water Cooler.................................................
Operation .......................................................................................................
Proper Care & Cleaning ................................................................................
How to Adjust Water Temperature for High Altitude to Avoid Boiling ............
How to Adjust Water Filling Amount ..............................................................
How to Cancel Blow Off to Dry Cups with Open Bottom ...............................
Troubleshooting ............................................................................................
Correct Upper Needle Seal Installation ..........................................................
How To Reset Hot Tank Safety Switch ..........................................................
Opening Inspection Porthole ..........................................................................
Cleaning Under Control Board In Case Of Severe Spill Of Liquids ................
How to Open Control Board Enclosure for an Inspection ..............................
2
5
5
6
7
8
9
9
10
10
11
13
14
16
18
18
18
19
24
25
26
26
27
TABLE OF CONTENTS
KEY INFORMATION FOR FUTURE USE
For future support please record your serial number (located on
label on back of the unit) and date purchased. Staple your
receipt to manual.
You will need this information to obtain warranty service.
Product:
Model Number :
Serial ID Number:
Date of Purchase:
Store:
SELF CLEAN hot and cold water cooler and SINGLE
CUP COFFEE BREWER
8LCH-KK-SSS-5i
9
SPECIFICATIONS
PARTS & FEATURES
Power Supply
Refrigerant Type
Max Cold Water Power
Cold Capacity / Hour
Cold Temp Range
Hot Water Power
Hot Capacity / Hour
Hot Temp Range
Product Dimensions
Net Weight
Cover Tray
Lid of the Coffee Brewer
Coffee Brewer Control panel
Child safety button
Control: Hot Water
Toddlers Safety Latch
Control: Cold Water
Faucet Nozzle For Coffee
Faucet Nozzle For Cold/Hot Water
LED Night Light
Drip Tray For Coffee
Drip Tray
Door
Bottle Tray
Hot Water Switch
Cold Energy Saving Switch
Power Cord
Carry Handle
Drain Plug
Condenser
AC 120V~/60Hz / 12 Amp
R-134A
100W
6 L/H
3°C – 10°C / 37.4°F – 50°F
1400W
9 L/H
80°C – 94°C / 176°F – 201°F
32 W x 38.2 D x 105.6 H (cm)
12.6 W x 15 D × 41.6 H (inch)
18.6 kg / 41 Ibs
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
5
4
6
8
10
11
12
13
14
20
19
18
9
17
16
7
3
15
Note: This model is energy efficient. It has electronic, non-adjustable thermostats for cold
and hot water, produces extra hot and ice cold waters.
ASSEMBLY
INSTALLATION
WARNING
Keep plastic bags away from children.
1. Remove dispenser from packaging.
2. Unpack drip tray and insert into dispenser.
3. Remove protective packaging from around probe.
4. Properly dispose of all packaging materials.
1. Place water cooler upright.
2. Locate water cooler on a hard and level surface in a cool shaded location ,
free of kitchen grease and oil, near a grounded wall outlet.
Notice: Do NOT plug in power cord yet.
3. Position water cooler so the back is at least 4 inches from wall and there
are at least 4 inches of clearance on both sides.
4. To minimize vibration and noise, make sure dispenser is level.
Notice: Do NOT plug in power cord yet.
Make sure RED power switch is turned OFF before plugging power cord
into an outlet for the first time.
Check if water filled hot tank by dispensing hot water, Trun RED power
swith ON.
10
11
DISPENSING COFFEE
Operating Instructions:
1. Make sure you have turned on RED hot water switch at the back. See No. 15 on page 9.
2.
3.
4.
Touch “PRE-HEAT” button. If “READY”
light is not ON.
a. Open lid and place a COFFEE
CAPSULE when “ ” LED is
flashing.
b. Press coffee capsule down by
your hand to pierce bottom of the
capsule.
c. If Brewer was switched off, wait up to 10 minutes until the Ready light is
ON. If “READY” light is flashing, it indicates there is not enough water in
storage tank. Wait until water is pumped up. Check if bottle has water.
Ready light will go on only when hot water tempera-
ture is 201°F. Water temperature goes down to 176°F
if Brewer was not used for 8 hours. Ready light might
keep on flashing if water level is low. Please check the
bottle.
5.
By default 8 oz, middle cup is pre selected
for you. If you wish to have different size cup,
touch your choice of 4, 6, 8, 10and 12 oz.
6.
Place a coffee cup on top
of brewers drip tray.
DO NOT OPEN LID when “ ” RED light is on.
START
INFU-
SION
READY
PRE-
HEAT/ INFU-
SION
START
READY
PRE-
HEAT/
INFU-
SION
START
READY
PRE-
HEAT/
INFU-
SION
START
READY
PRE-
HEAT/
INFU-
SION
START
READY
PRE-
HEAT/
12
8.
9.
10. To fill next cup repeat procedures from 3 to 7, after ready light is ON.
11. PRE-Heat
If coffee brewer was not in use for 8 hours, temperature would go back to standby of 80°C/176°F and
all the lights would turn off. To make coffee require to touch PRE-HEAT button again.
Wait few seconds
for coffee to start
pouring.
7.
Unlock button will be flashing. Touch UNLOCK and touch “START” button within 2 seconds.
Wait until red light changes into
green then open lid.
INFU-
SION
START
READY
PRE-
HEAT/
INFU-
SION
START
READY
PRE-
HEAT/
INFU-
SION
START
READY
PRE-
HEAT/
Your brewer and water cooler share a low watt density, external hot water tank heater. If has a larger
area to spread heat comparing to ordinary internal water heating elements. You may experience a
buildup of mineral scale or calcium deposits, depending on mineral content of the water. Still, build up
occurs at a much slower rate than with an internal heaters. Mineral scale is non-toxic, however it can
affect the brewer's performance by interfering with internal valves. Descaling your brewer helps main-
tain clean internal parts that come in contact with water.
If you are using mineral or filtered water, the brewer should be descaled every year to ensure optimal
performance or whenever there are white deposits in the hot water tank. It is possible for calcium
deposits to build up faster, making it necessary to descale more often. If you use distilled or RO water
descaling is not required.
This is how to descale your hot water tank:
Step 1. Make sure you have at least half a gallon of undiluted white vinegar on hand.
You will also need a 1½ gallon jug and access to a sink.
Step 2. Switch off the cooler by unplugging power cord. Remove the 5 gallons bottle. Drain all the
water out through the drain at the back. Replace the drain plug.
Step 3. Place the probe into the container with vinegar.
Step 4. Plug the power cord into an outlet. Hold the reset switch for the door to start the cooler and
get the pump working. Fill the cooler with vinegar.
Step 5. Check if hot tank is full of vinegar by dispensing it from hot water faucet.
Step 6. Remove the container filled with the vinegar and close the door.
Step 7. Turn on the Hot Water Switch (see #15 on page 9) and allow it to sit for at least 30 minutes.
Step 8. After the prescribed period of time, unplug the cooler, drain the vinegar through the drain on
the back.
Step 9. Rinse by closing the drain and placing a 5 gallons bottle or other container with tap water
inside of the compartment with the probe inserted into it. Plug the cooler back in to fill the hot
and cold tank with tap water.
Step 10. Rinse with tap water until smell goes away .
Step 11. Turn on the Hot Water Switch (see #15 on page 9) and let it sit for 30 minutes.
Step 12. Drain the water through the back drain again by following previous instructions.
Step 13. Repeat rinsing until the vinegar smell is gone and there is no sign of calcium deposits left
(they may get dissolved or show up as small white crystals).
Step 14. Place the 5 gallons bottle back and enjoy your brewer/water cooler once again.
DESCALING YOUR COFFEE BREWER / WATER COOLER
13
This water cooler part of combination unit is intended for water cooling only, Do NOT use other
liquids. Do NOT use for other purposes. Warranty is void if used for any other liquids including
coffee, tea, juices, beer or wine. Using other liquids can be dangerous to your health.
This water cooler has been designed to fit standard water bottles with a 3, 5 or 5.2 gallons
capacity. Do NOT use alternative bottles. Avoid using disposable bottles, since they lack
rigidity.
Initial Set Up
Do NOT plug in until instructed to do so below.
1. Allow unit to sit upright for 4 hours.
2. This model uses a pump to pull water from the bottle to the reservoirs.
a. Please do the following:
• Open door and place fresh bottle in front of tray.
• Clean bottle cap and neck. Using soft cloth soaked in bleach solation.
• Remove entire plastic cap from bottle.
• Push down on probe head until it is seated.
• Push bottle inside of compartment.
• Close the door gently.
CAUTION
OPERATION
NOTICE: Fit all round bottles. When using a 5 gallons rectangular bottle, slide into place as shown in illustration below.
3. Plug cord into a properly wired and grounded dedicated wall outlet.
a. Water will be pumped into the hot and cold water reservoirs from the bottle.
4. Turn hot and cold water power switches at the back of combination unit to ON.
a. The red switch controls the heating of water. If you do not want hot water, leave this switch OFF.
(needed for coffee brewer)
b. The blue switch controls the cooling of water. If you do not want cold water, leave this switch OFF.
14
A
B
Dispense Hot Water
This unit dispenses water at temperatures that can severe burns. Avoid direct contact with hot
water. Keep small children and pets away from unit while dispensing. Never allow small
children to dispense hot water without proper and direct supervision.
Note: After setup, hot water will be available in 15-20 minutes.
1. Position suitabe cup securely below hot water tap.
a. The left arrow below the hot water control indicates the location of the hot water tap.
b. The target holes in the grill help align the flow of water. This unit dispenses water at a fast rate. To
avoid splashes, hold cup as close to the tap as possible.
2. Push hot water release button (red) inward and depress control downward to start flow.
CAUTION HOT WATER
Notice:
• At initial start-up it will take about 3 minutes for the reservoirs to fill.
• Door must be closed to operate water pump.
• If the lights continue to flash, your bottle may be empty. If problems persist, Call 1-844-452-2425 for
assistance.
Initial Rinsing of Water Lines
This unit has been tested and sanitized prior to packing and shipping. However, during transit odors
from shipping containers can accumulate in the tank and lines. To remedy, please follow the instruc-
tions below.
1. Allow cooler to fill with water as per initial setup instructions.
2. Plug unit in turn hot water switch ON.
3. Wait for 30 minutes.
4. Drain unit completely using drain plug at the back.
Be carefue, water is hot.
Dispense Cold Water
Note: After setup, the cooler will take up to 1 hour to get water to cold
temperature. During this time the compressor may run continuously. This
is normal.
1. Position bottle, glass, pitcher or cooking pot securely below cold water
tap.
a. The right arrow below the cold water control indicates the location of
the cold water tap.
b. The target holes in the grill help align the flow of water. This unit
dispenses water at a fast rate. To avoid splashes, hold cup as close
to the tap as possible.
2. Depress right control downward to start flow.
3. Release control once desired fill level is achieved.
15
General Cleaning
Perform: As needed (every 6 months under normal conditions)
Time Required: 5 minutes.
Note: Do NOT use abrasive materials or chemical cleaners.
1. Unplug power cord from wall outlet.
2. Clean cabinet surfaces with a soft cloth and warm soapy water.
3. Wipe dust from back of dispenser to improve efficiency.
4. Remove drip tray assembly by sliding it forward. Remove cover. Wash drip tray and grice by hand
with soapy water.
5. Wipe stainless steel parts of the cabinet with unscented baby oil (mineral oil).
PROPER CARE & CLEANING
3. Release control once desired fill level is achieved.
4. For dispensing coffee see instructions for “how to brew coffee”.
Replace an Empty Bottle
Notice: When your bottle is empty the water cooler will beep intermittently.
You may also hear a sucking sound when the bottle empties. This is normal and is another
way to be alerted that your bottle is empty.
Replace empty bottle as soon as you notice it is empty. If unavailable, leave door ajar or
unplug cooler to stop beeping noise and flashing lights.
There may be a small amount of water left in the bottle. This is normal.
1. Open door and slide bottle out.
2. Remove probe from bottle:
• Pull probe straight up until completely out of bottle.
• Hang probe on the door to prevent contamination.
3. Install fresh bottle:
• Place fresh bottle in front of bottle compartment.
• Clean fresh bottle with a soft cloth and warm soapy water or bleach solution then wipe
with clean wet cloth.
• Remove entire plastic cap from top of bottle.
• Insert probe into bottle.
• Push down on probe until it is seated.
• Slide bottle onto bottle compartment.
• Gently close the door.
16
Sanitizing
Perform: Perform half Yearly, if required.
Time Required: 15 minutes.
Note: Do it prior to loading a fresh bottle.
1. To Clean the probe assembly unplug power cord from wall outlet.
2. Move combination unit away from wall and turn it 90 degrees in either
direction.
3. Turn power switches to OFF.
4. Remove water bottle and probe from water bottle.
5. Place a 2 gallons or larger bucket under the probe assembly.
6. Romove air filter and wash in soapy water.
7. Submerge probe in water and wash by hand if dirty. Rinse properly
by submerging in water.
8. Use a spray bottle to spray dispensing nozzles of water faucets with
a mild chlorine solution (1 teaspoon of unscented bleach in 12 oz of
water).
9. After 1 minute, rinse by spraying the nozzles with tap water.
10. Place probe into bottle filled with tap water. Install in cooler and
close door.
11. Dispense 1 Gallon of water from both faucets.
12. Remove bottle with tap water.
13. Install bottle with fresh water.
14. Dispense 1 gallon of water from both faucets.
15. If bleach smell still present repeat rinsing cycle.
16. Drain an water through drain plug at the back as deseribed .
17. Replace plug.
18. Place bottle with bottled water. Place probe into bottle.
19. Close the door and plug power cord into well outlet.
Air Filer
17
A
B
18
HOW TO ADJUST WATER TEMPERATURE FOR HIGH ALTITUDE TO AVOID BOILING
HOW TO ADJUST WATER FILLING AMOUNT
In order to extract most of flavor from your Single Serve Cup your Brewer works at 201°F. It is
good for elevations under 2500 feet.
- Immediately after power cord is plugged into the electrical outlet, you will hear an audible signal.
- At the same time, touch buttons “PREHEAT” and “START” for 1 seconds, to enter into SET
mode. You will see all five (5) cup sizes' LED icons flashing.
- For altitude under 2800 Feet, you should touch button for “8 oz” for 1 second, until “8 oz” LED will
flash. Then touch START button to SET.
- For altitude under 5000 Feet, you should touch “10 oz” button for 1 second, until “10 oz” LED will
flash. Then touch START button to SET.
- For altitude under 7000 Feet elevation, you should touch “12 oz” button for 1 second, until “12 oz”
LED will flash, then touch START button to SET.
- Immediately after power cord is plugged into the electrical outlet, you will hear an audible signal.
- At the same time , touch together buttons for “10 oz” and “START” for 1 second, water will start
dispensing from the Brewer. When water reaches required level desired for middle cup setting
touch “START” button to stop dispensing. Setting for middle cup is completed. Output settings for
the other cups will be adjusted accordingly.
HOW TO CANCEL BLOW OFF TO DRY CUPS
(Suitable in case of open bottom cups or weakly glued lids. )
- Immediately after power cord is plugged into the electrical outlet, you will hear an audible signal.
- At the same time, touch together buttons for “PREHEAT” and “8 oz” for 1 second, to enter into
SET mode. My Cup light starts flashing.
- Touch “START” button to cancel Blow Off function. LED light for K-cup picture will turn OFF.
NOTE: This model has memory chip to retain your settings. To return to factory settings unplug
the power cord and plug back again after 3 seconds, Hold “PREHEAT” and “UNLOCK” at the
same time.
IMPORTANT NOTE: Please touch "8 oz + 10 oz + 12 oz" simultaneously
If you want to set the addtional setting when unit is already plugged in.
19
TROUBLESHOOTING
Attention:
Wet out of the Box:
Your machine was functionally tested using reverse osmosis filtered water, the same as used by 5
gallons water bottlers.
A small quantity of water may be left after testing.
If during car transportation some water had leaked out, it will not affect the workings of the machine.
Please wipe water off of the cooler and let it sit overnight before plugging in.
If you are using this Single Serve Coffee Brewer at the altitude in exc-ess if 2500 feet, you migh
observe water dripping from the coffee dispensing nozzle.
Please follow instructions in the manual for Altitude correction.
Your Brewer works at higher water temperature. At higher elevation it may pre-boil, or boil causing
water spill.
Hot water spills occasionally from the coffee dispensing nozzle.
Reason: - If machine is located at the altitude higher then 1500 Feet elevation over sea level, water
may become agitated or boil at lower temperature and cause spill over.
Correction: Follow instructions to make correct settings:
- Immediately after power cord is plugged into the electrical outlet, you will hear an audible signal.
- At the same time, touch buttons “PREHEAT” and “START” for 1 seconds, to enter into SET mode.
You will see all five (5) cup sizes' LED icons flashing.
- For altitude under 2800 Feet, you should touch button for “8 oz” for 1 second, until “8 oz” LED will
flash. Then touch START button to SET.
- For altitude under 5000 Feet, you should touch “10 oz” button for 1 second, until “10 oz” LED will
flash. Then touch START button to SET.
- For altitude under 7000 Feet elevation, you should touch “12 oz” button for 1 second, until “12 oz”
LED will flash, then touch START button to SET.
Lids are blown off from K-cups.
Reason: - Some K-cups have problems maintaing consistent quality and may fail. Try to use
K-cups from other production batch.
Correction: - To remove blow dry function follow procedure described on page 18, called "How to
cancel blow off to dry cups".
No hot water. Preheat LED light just blinks, cold is fine, no hot.
Reason: - Possibly high limit thermal fuse had blown.
Correction: - Check if Hot Water Switch at the back is in ON position. Check if bottle has water.
If problem persist call service center at 1-844-452-2425 and report the problem.
If required, replacement unit will be shipped to you. Please drain water as per manual and pack
cooler into original packing material and call service center to arrange pick up of returned unit.
20
• Check the hose connections from water pump to the dispensing probe.
No Hot Water:
After the weekend or long absence water level in the hot tank might be lower slow due to evaporation.
Just hold Hot Water dispensing button longer until cold water fills the hot hot tank and allow hot water to
flow.
HOT WATER FLOW IS SLOW OR NON-EXISTENT
When mineral water is used calcium deposit will block passageways in the hot tank.
This blockage can be observed by the gradual slow down in the flow rate.
Use Lime, Calcium and Rust Remover (available at hardware stores) to dissolve calcium deposits.
Follow manufacturer’s instructions for use of LCR Remover.
Alternatively can use 20% lemon acid solution
Dissolve 20 oz of lemon acid powder in 3 quarts of warm water.
- Unplug power cord.
- Drain water out of the cooler using drain at the back. If it is plugged up, dispense all water via faucets.
- Leave drain at the back open for sufficient time to have water leak out of the drain.
- Close drain and feed water into cooler using coolers own probe. Use a small container to feed water.
Close door to activate door switch.
- Leave it soaking for 24 hours.
- Drain lemon acid solution via drain at the back.
- To rinse, fill container with tap water and feed water into cooler.
- Drain water periodically using drain at the back.
This procedure must be repeated at 3 to 6 months intervals depending on mineral content and usage of
water cooler.
Water cooler does not operate
• Make sure the power cord is properly connected to a dedicated working outlet.
• Make sure power switches are turned on. Make sure the cooler is plugged in and the circuit breaker
is not tripped. If needed, use another receptacle and confirm there is electricity going to the cooler.
• Please test carefully.
No water is coming from the taps
• Check the hose connections from the water pump to the probe in the bottle, they must be well
connected to avoid air leaks.
Table of contents
