Glass Expansion Elegra User manual

Instructions for the
Elegra Humidifier
INS-0255
The Elegra Humidifer is supplied with:
The instrument gas line will be one of the following:
Part Number Description
70-803-1225 Elegra humidier
70-803-1505 Nebulizer gas line with 2 ratchet ttings
70-803-1105 DC Fitting Type 13/31 with Ratchet Connector
EL-1 EzyLok kit
Part Number Description
70-803-0969 DC Fitting Type 11 with Ratchet Connector
70-803-1105 DC Fitting Type 13/31 with Ratchet Connector
70-803-1086 DC Fitting Type 12 with Ratchet Connector
70-803-1070 DC Fitting Type 21 with Ratchet connector
70-803-1049 DC Fitting Type 22 with Ratchet Connector
70-803-1449 DC Fitting Type 23 with Ratchet Connector
70-803-1311 DC Fitting Type 41 with Ratchet Connector
Page 2Version 3Glass Expansion®
Elegra Humidifer Diagram
Gas Outlet
Gas Inlet
To Nebulizer
To Spectrometer
gas port
Page 3Version 3Glass Expansion®
Initial Filling with water
Installation of the gas inlet
To ll the Elegra humidier, unscrew the top cap and place it aside. The membrane coil
will remain attached to the cap. Take care not to damage it, particularly when screwing
the cap back on. Fill the reservoir with deionized water to just below the blue line. Push
the membrane into the reservoir and then loosely screw the cap on until you feel it stop.
Tighten it one-quarter of a turn further. This will ensure an adequate seal. Do not
over-tighten.
Assembly of the Elegra Humidifier
Figure 1 - Gas line 70-803-1105 shown as example.
Figure 2
6mm (¼”) PVC
argon tubing
4mm nylon
argon tubing
EzyLok argon
connector
EzyLok hose
adaptor
Hose clip
For Elegra models with instrument-specic gas connector: Push the gas connector
directly into the nebulizer gas port on the spectrometer. (Figure 1)
For other ICP models: Use P/N EL-1 in combination with P/N 70-803-1105 to join the
Elegra’s instrument gas line to your spectrometer’s gas tube. (Figure 2)
Page 4Version 3Glass Expansion®
Installation of the gas outlet
Operating the humidifer
Two alternative tubes are supplied for the gas outlet to the nebulizer. For DC nebulizer
models with a ratchet tting, use the tube with a ratchet tting on both ends (P/N 70-803-
1505). For other nebulizers use P/N 70-803-1105 in combination with P/N EL-1 (Ezylok
Kit). In either case, connect the ratchet tting to the Elegra gas outlet (marked NEB on cap)
as described above.
Connect the other end to the nebulizer gas inlet using the ratchet tting (for 70-803-1505)
or the Ezylok kit (for 70-803-1105).
Once the reservoir is lled and gas lines connected, the humidier is in-line.
When the inlet valve is in the ON position, the gas passes through the membrane coil and
is humidied. When the valve is in the BYPASS position, the gas bypasses the membrane
coil and is not humidied. The valve should be moved smoothly and quickly between the
ON and BYPASS positions. The gas ow is shut off if the valve is positioned between ON
and BYPASS.
Page 5Version 3Glass Expansion®
Replenishing the water reservoir
Assembly of the membrane for the Elegra
When the water level drops below the red
line on the reservoir, the performance of the
humidier could suffer. Shut off the plasma
and disconnect the nebulizer and gas lines
from the instrument. Unscrew the cap and
ll as per the initial lling procedure.
Hold the Elegra cap with rotating female Luer lock assembly facing outwards. Insert one
end of the membrane rmly into the Elegra cap outlet whilst rotating female Luer lock in the
direction of the arrow (Figure 2). Now repeat to secure the other end of the membrane.
Page 6Version 3Glass Expansion®
Figure 1. Figure 2.
Female Luer
Lock
Asia Pacic
6 Central Boulevard, Port Melbourne, VIC
3207, Australia
Telephone: +61 3 9320 1111
Email: [email protected]
For more information please visit www.geicp.com or contact one of our ofces
below.
Version 3.0
Americas
31 Jonathan Bourne Drive, Unit 7 Pocasset,
MA 02559, USA
Telephone: 508 563 1800
Email: [email protected]
Europe
Friedenbachstrasse 9, 35781 Weilburg,
Germany
Telephone: +49 6471 3778517
Email: [email protected]
