Glen BUILT-IN MICROWAVE OVEN User manual

Imported and Marketed in India by
Glen Appliances Pvt. Ltd.
Helpline : 0129-2254191
I-34, DLF Industrial Area, Phase I, Faridabad - 121 003
E-mail: [e-mail] Website: www.glenindia.com
USER’S GUIDE
BUILT-IN
MICROWAVE OVEN

Glass Tray
Oven Air Vent
Control Panel
Door Safety
Look System
Oven
Window
Roller Ring
Oven Window
Grill Rack
IDENTIFY YOUR BUILT-IN MICROWAVE
Micro
Defrost
Auto Menu
Convection
Grill
Combi
Clock/Timer
Start/Reset
Display Window
Time Setting
Control Panel
FRAME
Frame
Plastic Buckle
Bolts
Plastic Buckle
Setting Paper Base Setting Paper
Feet Mat
Bolts
CAVITY DIMENSIONS
550 mm
100
mm
Vent Vent
MICROWAVE CAVITY
Depth 550 mm
100 mm
Internal Width
566 mm
External Front
Height 366 mm
100 mm
450 mm
INSTALLATION
•
•This Microwave Oven weighs 18.5 kg and must be placed on a horizontal surface strong
enough to support this weight.
•The oven must be placed away from high temperature and steam.
•Do not place anything on top of the oven.
•Do not remove the turn-table drive shaft.
•As with any appliance, close supervision is necessary when used by children.
Warning: This appliance must be earthed
•The plug socket should be within easy reach of the power cord
•This oven requires 1.5 KVA for its input, consultation with service engineer is suggested when
installing the oven.
Caution: This oven is protected internally by AC 250V, 10 Amp Fuse.
Make sure all the packing materials are removed from the inside of the door.
1 2

•
as shown. Keep the buckle edge and the
paper's edge in one line. Then fasten the
plastic buckle and required bolts as per
the enlarged inset picture.
3. Put the Microwave Oven carefully into
the cabinet, placing the underside of the
Microwave Oven into the base plate now
created.
4. Keep the Microwave Oven in a
horizontal direction. Push the plastic
male buckle of the Frame into the plastic
female buckle as per enlarged diagram.
The Frame should now be installed.
Position the plastic buckle setting paper
OPERATING INSTRUCTIONS
SINGLE BUTTON HEATING
• Only with a single press of a button, you can start simple cooking, it is very convenient and
quick to heat a glass of water etc.
Example: To heat a glass of milk
a) Put a glass of milk onto the glass turntable, and close the door.
b) Press the button “Start/Reset”, the microwave oven will work on 100% power for
1 minute.
c) You will hear 5 beeps when cooking is completed.
MICROWAVE HEATING
This function has two options.
• Quick microwave heating (100% power)
Example: To heat food on 100% power for 5 minutes
a) Set cooking time to “5:00”
b) Press “Start/Reset”
Manual – operation microwave heating
Example: To heat food on 70% power for 10 minutes.
a) Press “Micro” button, select “70%” power,
b) Set time cooking to “10:00”
c) Press “Start/Reset”
There are 5 power levels and the longest microwave heating time is 60 minutes.
AUTO WEIGHT DEFROST
•
time.
Example: Defrost 0.50Kg frozen meat
You only need to select the food's weight, it can help you automatically adjust the power and
Touch Microwave Display
times power
1 100% P100
2 70% P70
3 50% P50
4 30% P30
5 10% P10
•
the base setting paper on the bottom
board of the cabinet cavity. Keep the
paper's front edge and cabinet outside
edge in one line. Then put the base on the
paper and adjust their holes as per the
hole position in the drawing. Then, fix the
required bolts.
Fix the cabinet as per diagram above. Put
3 4

a) Press “Defrost” button LED will display “dFE”, Rotate the knob “Time setting” until
“0.50” display.
b) Press “Start/Reset”
AUTO-MENU
•You only need to select the food type and weight, it will automatically adjust the power and
time.
Example: Auto cooking 0.40Kg fish
a) Press “Auto menu” button until “A-5” display
b) Rotate the knob “Time setting” until “0.40” display.
c) Press “Start/Reset”
Touching Times
Reheat Potato Pizza Meat Fish Chicken
A-1 A-2 A-3 A-4 A-5 A-6
1 0.10 0.20 0.10 0.10 0.20 0.20
2 0.20 0.30 0.20 0.20 0.30 0.40
3 0.30 0.40 0.30 0.30 0.40 0.60
4 0.40 0.50 0.40 0.40 0.50 0.80
5 0.50 0.60 0.50 0.50 0.60 1.00
6 0.60 0.70 0.60 0.60 0.80 1.20
7 0.90 0.80 1.00 1.40
8 1.10 1.00 1.60
9 1.30 1.30 1.80
10 1.50 1.50 2.00
Weight
(Kg)Menu
GRILL
•
minutes).
Example: Cooking food with grill for 20 minutes
a) Press “Grill” until the LED displays “G-1”
b) Set cooking time “20.00”
c) Press “Start/Reset”
•When grilling, the food isn't heated by microwave, heat is radiated from the metal heater at
st
the top of the oven. When grill is working, the cooking time has 2 stages. After the 1 half of
the cooking, the program will automatically pause and sound 2 beeps, indicating you to
open the oven and turn food over, after turning over, close the door, press “Start/Reset”
nd
button, the cooking will continue for the 2 half, if you do not want to turn the food over, the
oven will re-start after 1 min pause.
You may press “Grill” button to select such functions: (the longest cooking time is 60
COMBINATION COOKING
This appliance offers you a choice of three methods of combination cooking.
Option 1 Convention + Microwave (230ºC convention + 40% microwave), display “C-1”
This is ideal for roasting and baking etc.
Option 2 Grill +Convection (50% grill + 230ºC convention, display “C-2”) for fast crisping etc.
Option 3 Grill + Microwave (45% grill + 55% microwave), display “C-3” for fast crisping etc.
Example: Cooking food using option 3 for 30 minutes.
a) Press “Combi” button to select “C-3”
b) Set cooking time for 30 minutes
c) Press “Start/Reset”
CONVECTION COOKING
•This oven can be used as a convention oven and can be programmed to reach a desired
temperature for pre-heating. The temperature setting will default to 230˚C, you may press
“Convention” button to set the different temperature.
Example: To set the oven to pre-heat to 200ºC.
a) Press “Convention” button to set 200ºC temperature.
b) Press “Start/Reset”
•When the pre-heating is completed, the appliance will stop work and emit 2 beeps to remind
you to place the food in the oven. Set the convection cooking temperature and time and start
cooking. The longest pre-heating time will be 30 minutes.
CONVECTION FUNCTION
Example: Convection cooking, To set the pre-heated oven to cook for 20 minutes at 200ºC.
a) Press “Convection” button to choose convection cooking, press “Convection” button to
choose 200ºC temperature.
b) Set cooking time for 20 minutes
c) Press “Start/Reset”
CLOCK
The oven can be used as a clock.
Example: To input current time 16:30
a) Press “Clock/Timer”, the clock symbol will flash in display. Rotate the “Time setting”
knob to set “16:00”.
b) Press “Clock/Timer” again, rotate the “Time setting” knob to set “16:30”
c) Press “Clock/Timer” again, the clock setting is finished, the time start to go on working.
5 6

TIMER
•
automatically stop operation after finishing cooking. (You should set the clock before using
timer function).
Example: the current time of microwave oven is 16:30, to set cooking at 18:15 on 70% power for
10 minutes.
a) Press “Clock/Timer” and set time to 18:15 (same procedure as setting clock).
b) Press “Micro” to set 70% power.
c) Input cooking time 10 minutes by rotating the knob “Time Setting”.
d) Press “Start/Reset”
•If you don't set power and cooking time (omit B and C steps), and directly press “Start/Reset”
button, the microwave oven will work only as a clock, there will be 10 beeps at 18:15, but no
other function will run.
CHILD-SAFETY LOCK
•To activate the child safety lock, press “Auto Menu” and “Clock/Timer” button at the same
time for 2 seconds. Press “Auto Menu” and “Clock/Timer” button, at the same time for 2
seconds again, it will unlock this function.
START/RESET
a. In the course of operation, pressing “Start/Reset” button will stop operation.
b. If any program was set before pressing start, pressing this button will cancel all the set
program.
CLEANING & MAINTENANCE
1. Turn the oven off and remove the power plug from the wall socket before cleaning.
2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven
walls, wipe with a damp cloth. The use of harsh detergent or abrasives is not recommended.
3. The outside oven surface should be cleaned with a damp cloth. To prevent damage to the
operating parts inside the oven, water should not be allowed to seep into the ventilation
openings.
4. Do not allow the Control Panel to become wet. Clean with a soft, damp cloth, Do not use
detergents, abrasives or spray-on cleaners on the control panel.
5. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth.
This may occur when the microwave oven is operated under high humidity conditions and
in no way indicates malfunction of the unit.
6. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm
soapy water or in a dishwater.
7. The roller ring and oven cavity floor should be cleaned regularly to avoid excessive noise.
Simply wipe the bottom surface of the oven with mild detergent, water or window cleaner
and dry. The roller ring may be washed in mild soapy water or dish washer. Cooking vapour
collects during repeated use but in no way affects the bottom surface or roller ring wheels.
After cleaning, be sure to replace the roller ring in the proper position.
The timer function helps the microwave oven begin automatic cooking at set time, and
8. Remove odors from your oven by combining a cup of water with the juice and skin of one
lemon in a deep microwaveable bowl. Microwave for 5 minutes, wipe thoroughly and dry
with a soft cloth.
9. When it becomes necessary to replace the oven light, please consult a dealer to have it
replaced.
SAFETY PRECAUTIONS
1. Always have the glass tray, roller arms, coupling and roller track in place when operating the
oven.
2. Do not use the oven for any reason other than food preparation, such as for drying clothes,
paper, or any other nonfood items, or for sterilizing purposes.
3. Do not operate the oven when empty. This could damage the oven.
4. Do not cook any food surrounded by a membrane, such as egg yolks, potatoes, chicken
livers, etc. without first being pierced several times with a fork.
5. Do not insert any object into the openings on the outer case.
6. Do not at any time remove parts from the oven such as the feet, coupling, screws, etc.
7. Do not cook food directly on the glass tray. Place food in/on proper cooking utensil before
placing in the oven.
8. Cookware not to use in your microwave oven
•Do not use metal pans or dishes with metal handles.
•Do not use anything with metal trim.
•Do not use paper covered wire twist-ties on plastic bags.
•Do not use melamine dishes as they contain a material which will absorb microwave
energy. This may cause the dishes to crack or char and will slow down the cooking
speed.
•Do not use Centura Tableware. The glaze is not suitable for microwave use. Corelle
Livingware closed handle cups should not be used.
•Do not cook in a container with a restricted opening, such as a pop bottle or salad oil
bottle, as they may explode if heated in a microwave oven.
•Do not use conventional meat or candy thermometers. There the thermometers
available specifically for microwave cooking. These may be used.
9. Microwave utensils should be used only in accordance with manufacturer's instructions.
10. Do not attempt to deep-fry foods in this oven.
11. Please remember that a microwave oven only heat the liquid in a container rather than the
container itself. Therefore, even though the lid of a container is not hot to the touch when
removed from the oven, please remember that the food/liquid inside will be releasing the
same amount of steam and/or spitting when the lid is removed as in conventional cooking.
12. Always test the temperatures of cooked food yourself especially if you are heating or cooking
food/liquid straight from the oven, but allow it to stand for a few minutes and stir food/liquid
to distribute heat evenly.
7 8

13. Food containing a mixture of fat and water, e.g. stock, should stand for 30-60 seconds in the
oven after it has been turned off. This is to allow the mixture to settle and to prevent bubbling
when a spoon is placed in the food/liquid or a stock cube is added.
14. When preparing/cooking food/liquid remember that there are certain foods, e.g.
Christmas puddings, jam and mincemeat, which heat up very quickly. When heating or
cooking foods with a high fat or sugar content do not use plastic containers.
15. Cooking utensil may become hot because of heat transferred from the heated food. This is
especially true if plastic wrap has been covering the top and handles of the utensil.
Potholders may be needed to handle the utensil.
•To reduce the risk of fire in the oven cavity:
a. Do not overcook food. Carefully attend microwave oven if paper, plastic, or other
combustible materials are placed inside the oven to facilitate cooking.
b. Remove wire twist-ties from bags before placing bag in oven.
c. If materials inside the oven should ignite, keep oven door closed, turn the oven off at the
wall switch, or shut off power at the fuse or circuit breaker panel.
•If the door or door seals are damaged, the oven must not be operated until it has been
repaired by a competent person
•The oven must have sufficient air flow. Keep 10 cm space at back; 15 cm at both sides and 30
cms from top of the oven. Don't remove oven's feet, do not block air events of the oven.
•If smoke is observed, switch off or unplug the appliance and keep the door closed in order to
stifle any flames.
•If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard
• Warning: It is hazardous for anyone other than a competent person to carry out any service
or repair operation that involves the removal of a cover which gives protection against
exposure to microwave energy.
• Warning: liquids and other foods must not be heated in sealed containers since they are
liable to explode.
• Warning: Only allow children to use the oven under adult supervision.
Radio Interference
Microwave oven may cause interference to your radio, TV or similar equipment. When
interference occurs, it may be eliminated or reduced by the following procedures.
a) Clean the door and sealing surface of the oven.
b) Place the radio, TV etc. as far away from your microwave oven as possible.
c) Use a properly installed antenna for your radio, TV etc. to get a strong signal reception.
WARRANTY
This Built-in Microwave Oven is fully warranted against any defect arising out of defective
materials or faulty workmanship for a period of one year from the date of purchase. Should any
defect develop in this product, the customer should bring the product to the nearest authorised
service centre, where the company undertakes to get the product repaired free of charge.
This warranty is not valid if :
• The use and care instructions have not been followed.
• Defects are caused by accident, misuse, abuse or commercial use.
• The repair work is carried out by persons not authorised by the company.
• Any modification or alteration of any nature is made in the product.
• Normal wear & tear of the product is not covered under warranty
• The Bill/Cash memo and copy of warranty card is not presented.
Under no circumstances, whether based on limited warranty or otherwise shall the
company be liable for incidental, special or consequential damages. Use of product indicates
acceptance by you of the aforesaid terms and conditions.
PRODUCT NAME : BUILT-IN MICROWAVE OVEN
MODEL NO.:
SERIAL NO.:
BILL NO. & DATE:
NAME OF OWNER:
ADDRESS:
SPECIFICATIONS
*Subject to change without prior notice.
Power consumption 230V~50Hz, 1450W
Output 900W
Grill Heater 1200W
Convection 1350W
Operating Frequency 2,450 MHz
9 10
