GL 677
EC5BµC7E945

Important safety instructions
When using electrical appliance basic safety precautions should be followed, including the
following:
Warning:
1. Read all instructions before using the appliance.
cook or dry food. It is not designed for industrial or laboratory use.
possibility of ignition.
8. Warning:
be taken when handle the container.
skin burns.
before cooking.

25. Warning:
30. Caution:
CAUTION: Hot Surface
Keep the appliance and its cord out of reach of children less than 8 years.

INSTALLATION
1. Make sure all the packing materials are removed from
the inside of the door.
2. Inspect the oven after unpacking for any visual
damage such as:
Misaligned Door
Damaged Door
Dents or Holes in Door Window and Screen
Dents in Cavity
If any of the above are visible, DO NOT use the
oven.
3. This Microwave Oven weighs 1 .5 kg and must be
placed on a horizontal surface strong enough to
WARNING-THIS APPLIANCE MUST BE EARTHED.
1. The plug socket should be within easy reach
of the power cord
2. This oven requires 1.5 KVA for its input.
consultation with service engineer is
suggested when installing the oven.
support this weight.
4. The oven must be placed away from high temperature
and steam.
5. DO NOT place anything on top of the oven.
6. DO NOT remove the turn -table drive shaft.
7. As with any appliance, close supervision is necessary
when used by children.
CAUTION:This oven is protected internally by
ac 250V,10 Amp Fuse.
IMPORTANT
The wires in this mains lead are coloured in accordance with the following code:
Green-and-yellow : Earth
Blue : Neutral
Brown : Live
As the colours of the wires in the mains leads of the appliance may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is marked with the
letter E or by the earth symbol coloured green of green-and-yellow.
The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.
4
8

SAFETY INSTRUCTIONS FOR GENERAL USE
Listed below are, as with all appliances, certain rules to follow and safeguards to assure top performance from
this oven:
1. Always have the glass tray, roller arms, coupling and roller track in place when operating the oven.
2. Do not use the oven for any reason other than food preparation, such as for drying clothes, paper, or any
other nonfood items, or for sterilizing purposes.
3. Do not operate the oven when empty. This could damage the oven.
4. Do not use the oven cavity for any type of storage,such a papers, cookbooks, etc.
5.Do not cook any food surrounded by a membrane,such as egg yolks,potatoes,chicken livers,etc without
first being pierced several times with a fork.
IMPORTANT SAFETY INSTRUCTIONS
-WARNING: When the appliance is operated in the combination mode, children should only use the oven under adult
supervision due to the temperatures generated; (Only for the model with grill function)
-WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a
competent person;
-WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation
that involves the removal of a cover which gives protection against exposure to microwave energy;
-WARNING: liquids and other foods must not be heated in sealed containers since they are liable to explode.
-WARNING: Only allow children to use the oven without supervision when adequate instructions have been given
so that the child is able to use the oven in a safe way and understands the hazards of improper use;
- The oven must have sufficient air flow.Keep 10 cm space at back;15 cm at both sides and 30cms from top of the
oven.Don't remove oven's feet, do not block air events of the oven.
- Only use utensils that are suitable for use in microwave ovens.
- When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition;
- If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any flames;
- Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling
the container;
- The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before
consumption, in order to avoid burns;
- Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode,
even after microwave heating has ended;
- When cleaning surfaces of door, door seal, cavity of the oven, use only mild, nonabrasive soaps, or detergents
applied with a sponge or soft cloth.
- The oven should be cleaned regularly and any food deposits removed;
- Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect
the life of the appliance and possibly result in a hazardous situation;
- If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
9

6. Do not insert any object into the openings on the outer
case.
7. Do not at any time remove parts from the oven such as
the feet, coupling, screws, etc.
8. Do not cook food directly on the glass tray. Place food
in/on proper cooking utensil before placing in the oven.
9. IMPORTANT-COOKWARE NOT TO USE IN YOUR
MICROWAVE OVEN
Do not use metal pans or dishes with metal handles.
Do not use anything with metal trim.
Do not use paper covered wire twist-ties on plastic bags.
Do not use melamine dishes as they contain a material
which will absorb microwave energy. This may cause
the dishes to crack or char and will slow down the
cooking speed.
Do not use Centura Tableware. The glaze is not suitable
for microwave use. Corelle Livingware closed handle
cups should not be used.
Do not cook in a container with a restricted opening,
such as a pop bottle or salad oil bottle, as they may
explode if heated in a microwave oven.
Do not use conventional meat or candy thermometers.
There are the thermometers available specifically for
microwave cooking. These may be used.
10. Microwave utensils should be used only in
accordance with manufacturer's instructions.
11. Do not attempt to deep-fry foods in this oven.
12. Please remember that a microwave oven only
heats the liquid in a container rather than the
container itself.Therefore, even though the lid
of a container is not hot to the touch when
removed from the oven, please remember that
the food/liquid inside will be releasing the same
amount of steam and/or spitting when the lid is
removed as in conventional cooking.
13. Always test the temperature of cooked food
yourself especially if you are heating or cooking
food/liquid for babies. It is advisable never to
consume food/liquid straight from the oven but
allow it to stand for a few minutes and stir food/
liquid to distribute heat evenly.
14. Food containing a mixture of fat and water,
e.g.stock,should stand for 30-60 seconds in the
oven after it has been turned off. This is to allow
the mixture to settle and to prevent bubbling when
a spoon is placed in the food/liquid or a stock cube
is added.
15. When preparing/cooking food/liquid and remember
that there are certain foods, e.g. Christmas
puddings, jam and mincemeat, which heat up very
quickly. When heating or cooking foods with a high
fat or sugar content do not use plastic containers.
16. Cooking utensil may become hot because of heat
transferred from the heated food. This is especially
true if plastic wrap has been covering the top and
handles of the utensil. Potholders may be needed
to handle the utensil.
17.To reduce the risk of fire in the oven cavity:
(a)Do not overcook food. Carefully attend microwave
oven if paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
(b)Remove wire twist-ties from bags before placing
bag in oven.
(c)If materials inside the oven should ignite, keep oven
door closed, turn the oven off at the wall switch, or
shut off power at the fuse or circuit breaker panel.
FEATURE DIAGRAM
(1) Door Safety Lock System
(2) Oven Window
(3) Roller Ring
(4) Glass Tray
(5) Control Panel
(6) Grill rack
6
10

(1) DISPLAY WINDOW
(4) MICRO
(7) AUTO MENU
(2) GRILL
(3) DEFROST
(10
(11) TIME SETTING
) START
(9) PAUSE/CANCEL
(5) MEMORY
(8) CLOCK/TIMER
(6) COMBI
COMPUTER CONTROL PANEL
11

400
food
a) Press the button "Auto defrost" ,
b) Rotate the knob "Time setting" to set the weight 500g.
c) Press "Start"
"dEF" will be displayed .
S
3.Auto weight defrost
Time setting 400
12
The longest microwave heating time is 60 minutes;
Microwave power have 5 settings,and it’s P100、P70、P50、P30 and P10 from high to low power.
P100
P100
P70
“P70”
P100

g
Weight
Touching Times
100
200
300
400
500
1
2
3
4
5
6
7
8
9
10
600
500
400
300
200
100
600
800
1000
500
400
300
200
600
700
800
900
1000
500
400
300
200
100
600
500
400
300
200
1001
2
Menu A-1
Rice
A-2
Vegetable
A-3
Meat
A-4
Bread
A-5
Fish
A-6
5. Memory cooking function:
This function can memorize some useful cooking programes to avoid reseting time and power operation.
a) If no memory has been set press "memory" "1" will be displayed, input cooking power and time, press
"memory" again, the set program will be memorized. If you press "Start" instead of "memory" button, the
oven will start work, and the program also will be memorized.
b) It there is any memory has been set already, when you press "memory" button, "1" will be displayed, the
oven will operate according to the memorized program after you press "Start" button.
The programe will not be kept when the electrity is off.
6. Grill
This function has two patterns, you may press "Grill" to select such functions: (the longest cooking time is
60 minutes).
Example: Cooking food with G-1 for 20 minutes
A) Press "Grill" until the LED displayed "G-1".
B) Set cooking time "20:00"
C) Press ""
When grilling, the food isn't heated by microwave, heat is radiated from the metal heater at the top of the oven.
When grill is working, the cooking time has 2 stages, after the 1st half of the cooking, the program will
automatically pause and sound 2 beeps, indicating you to open the oven and turn food over, close the door
after turn the food over, press "Start" button, the cooking will continue for the 2nd half. If you do not want to turn
the food over, the oven will re-start after 1 min pause.
13
Noodles
Grill power have 2 settings,and it’s G-1 and G-2 from high to low power.
Remark:Noodle in marked by lot,Each lot is around 100-150g.

0
8
lock/Timer
lock/Timer
lock/Timer
9
11. Pause/Cancel
a) In the course of operation, pressing "Pause/Cancel" button will stop operation.
b) If any program was set before pressing start, pressing this button will cancel all the set program.
7. Combination Cooking
This appliance offers you a choice of two methods of combination cooking.
Example : Cooking food using C-2 for 30 minutes.
a) Press "Combi" button to select "C-2"
b) Set cooking time for 30 minutes
c) Press "Start "
14
Combi power have 2 settings,taking the reference of microwave power.It''s C-1 and C-2 from high to low power.
Under standby situation,To activate the child safety lock, press "Auto menu" and "Combi" at the same time
for 2 seconds. Press "Auto menu" and "Combi" at the same time for 2 seconds again, it will unlock the
machine.
Clock/Timer
P70
P70

75$16)250(5 0$*1(7521
++($7(5
7078517$%/(02725
)0)$102725
//$03
6:&7+(021,725,17(5/2&.6:,7&+
6:%6(&21'$5<,17(5/2&.6:,7&+
6:$35,0$5<,17(5/2&.6:,7&+
&,5&8,768%-(&772&+$1*(:,7+287127,&(
'22523(1('&22.2))&21',7,21
6&+(0$7,&',$*5$0
5
&
' 5<
1
5
' 5
&21752//(5
-3
-3
5<
. . *1'. 'B 6:
5<
+ 287
6:
5
7 ,1
1
3 287
&
5<
6:%
62
'
1(/
/
/
&
5
)
12,6(),/7(5
/
& )8
/)0 70
6:$
+
6+
)
&
6:&
)$
)
15

FULL BUILT-IN MICROWAVE
OVEN INSTALLATION MANUAL
vent
MIROWAVE LOCATION
vent
MICROWAVE OVEN CABINETRY
COMPONENTS
Cabinet measurement Requirements(illustrated above):
1. Cabinet's inner dimension in transverse direction is 566mm.
This is the minimum distance from the left batten to right batten. Do not alter.
2. Cabinet's inner dimension in longitudinal direction is 365mm.
This is the minimum distance from the left batten to right batten. Do not alter.
3. Cabinet's depth should be no less than 550mm.
4. Outside dimension of cabinet should be no less than 596mm,
as the frame length is 592mm.
5. Cabinet's board less than 15mm or 20mm thick.
YHQW
FRAME dimensions
Width 592mm
Height 390mm
Depth 20mm
Cavity dimensions
Width 566mm
Height 365mm
Depth 550mm
TRIM KIT SPECIFICATIONS
1ǃPlastic buckle setting paperǂǂ 1PCS
2ǃorientationǂǂǂ ǂǂ 1PCSǂǂǂ
3ǃbolt ǂǂǂǂǂǂØ4X103PCS
4ǃscrew coverǂ1PCS
5ǃbolt ǂØ4X35 1PCS
550
50
365 IMPORTANT SIZE
100
IMPORTANT SIZE
500

3ǃOpen the microwave oven,
fix the bolt (Component 5) and
beat it into the cabinet, then install
screw cover (Component 4)DŽ
2.Put the microwave oven into the cabinet and keep
the microwave oven in a horizontal direction and keep
the edge distance of two side as same.Then fix the
orientation on then back of microwave oven.
)5$0(ᅝ㺙䇈ᯢк
FRAME INSTALLATION STEPS
1.Cabinet must be finished as per cabinet dimensions.
Put the plastic buckle setting paper( Component 1)
on the bottom board of cabinet cavity.
Keep the paper's front edge and the cabinet
outside edge in one line. Then put
the orientation(Component 2) on the paper
and adjust their holes as per the hole position
in the drawing. Then fix the bolt (Component 3).

SPECIFICATIONS
RADIO INTERFERENCE
Microwave oven may cause interference to your radio, TV, or similar equipment. When interference occurs, it may be
eliminated or reduced by the following procedures.
a. Clean the door and sealing surface of the oven.
b. Place the radio, TV, etc. as far away from your microwave oven as possible.
c. Use a properly installed antenna for your radio, TV, etc. to get a strong signal reception.
BEFORE YOU CALL FOR SERVICE
1. If the oven will not perform at all, the display does not
appear or the display disappears:
a) Check to ensure that the oven is plugged in securely. If it
is not, remove the plug from the outlet, wait 10 seconds
and plug it in again securely.
b) Check the premises for a blown circuit fuse or a tripped
main circuit breaker. If these seem to be operating properly,
test the outlet with another appliance.
2. If the microwave power does not function:
a) Check to see whether the timer is set.
b) Check to make sure that the door is securely closed to
engage the safety interlocks. Otherwise, the microwave
energy will not flow into the oven.
IF NONE OF THE ABOVE RECTIFIES THE SITUATION, THEN CONTACT THE AUTHORIZED SERVICE AGENT.
Note:
The appliance is for household use for heating food and beverages using electromagnetic energy and for indoor
use only.
Power consumption:
Output:
Grill Heater:
Operating Frequency:
Outside Dimensions:
Oven Cavity Dimensions:
Oven Capacity:
Uncrated Weight:
230V~50Hz,1400W
900W
1200W
2,450MHz
510mm(W) X 382mm(D) X 303mm(H)
330mm(W) X 330mm(D) X212mm(H)
25 litres
Approx. 17.5kg


Table of contents
Other Glen Microwave Oven manuals
