GLUCKSTEIN ELEMENTS 39655-HBCLED User manual

USE AND CARE GUIDE
LED OUTDOOR WALL SCONCE
THANK YOU
We appreciate the trust and confidence you have placed in Gluckstein Elements through the purchase of this LED outdoor wall sconce. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Gluckstein Elements!
Item # 1001 651 035
Model# 39655-HBCLED
Questions, problems, missing parts? Before returning to the store,
call Gluckstein Elements Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-833-695-2045
HOMEDEPOT.CA
HOMEDEPOT.COM
GLUCKSTEINELEMENTS.COM

2
Table of Contents
Safety Information
Warranty
LIMITED WARRANTY
WHAT IS COVERED
The manufacturer warrants this lighting fixture to be free from defects in materials and workmanship for a period of three (3 years from
date of purchase. This warranty applies only to the original consumer purchaser and only to products used in normal use and service. If
this product is found to be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the
product at the manufacturer’s discretion, provided that the product has not been damaged through misuse, abuse, accident, modifications,
alterations, neglect, or mishandling.
WHAT IS NOT COVERED
This warranty shall not apply to any product that is found to have been improperly installed, set up, or used in any way not in accordance
with the instructions supplied with the product. This warranty shall not apply to a failure of the product as a result of an accident, misuse,
abuse, negligence, alteration, faulty installation, or any other failure not relating to faulty material or workmanship. This warranty shall not
apply to the finish on any portion of the product, such as surface and/or weathering, as this is considered normal wear and tear. The
manufacturer does not warrant and specifically disclaims any warranty, whether express or implied, of fitness for a particular purpose,
other than the warranty contained herein. The manufacturer specifically disclaims any liability and shall not be liable for any consequential
or incidental loss or damage, including but not limited to any labor/expense costs involved in the replacement or repair of said product.
Contact the Customer Service Team at 1-833-695-2045 or visit www.HOMEDEPOT.ca. / HOMEDEPOT.com. /GLUCKSTEINELEMENTS.com.
2
2
2
Table of Contents
Safety Information
Warranty
Pre-installation 3
3
Planning Installation
Tools Required 3
3
4
5
7
Hardware Included
Package Contents
Installation
Care and Cleaning
Troubleshooting 7
IMPORTANT:
Inspect the wire insulation for any cuts,
abrasions,or exposed copper that may have occurred during
shipping. If there is a defect in the wire, do not continue the
assembly process.
CAUTION: Before starting installation of this fixture or
removal of a previous fixture, disconnect the power by turning
off the circuit breake or by removing the fuse at the fuse box.
Read all instructions before assembling and installing.
Consult a qualified electrician for installation of this fixture.
If you have any non-electrical questions about this fixture, please
contact our Customer Service Team at 1-833-695-2045 or visit
www.HOMEDEPOT.ca. / HOMEDEPOT.com. /
GLUCKSTEINELEMENTS.com.
Please reference your item number 1001 651 035 or UPC 773546319034.
Keep your receipt and these instructions for proof of purchase.

Pre-Installation
PLANNING INSTALLATION
Read all instructions before assembly and installation. To avoid damaging this product, assemble it on a soft, non-abrasive surface, such as
carpet or cardboard. Inspect each part for defects that may have occurred during shipping. Keep your receipt and these instructions for
proof of purchase.
TOOLS REQUIRED
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Safety goggles
Wire strippers
Phillips screwdriver Flathead screwdriver
DD
CCAA BB
Wire cutters Ladder Caulk
Part Description Quantity
AA Wire nut 3
BB Outlet box screw 2
CC Ground screw 1
DD Install screw
EE 1
2
Mounting plate
3
EE
HOMEDEPOT.CA / HOMEDEPOT.COM / GLUCKSTEINELEMENT.COM
Please contact 1-833-695-2045 for further assistance.

4
Pre-Installation (continued)
PACKAGE CONTENTS
Part Description Quantity
A Fixture body 1
B
A
B Glass 1

Installation
1Installing the mounting plate
Install the mounting plate (EE) to the junction box
(not included) with the supplied outlet box screws (BB).
2Making the electrical connections
NOTE: Always use wire nuts (AA) to connect wires and
push all excess wires and connections back into the
junction box (not included).
WARNING: Turn off the power at the main fuse box.
Wrap the ground wire from the fixture around the ground
screw (CC) on the mounting plate (EE), and then connect the
ground wire from the fixture to the ground wire from the
junction box.
Connect the black wire of the power supply (not included) to
the black wire of the fixture (included) and connect the white
wire of the power supply (not included) to the white wire of
the fixture (included).
5
BB
EE EE
CC
AA
Connect the fixture wires as follows:
WHITE WIRE WHITE WIRE
FROM FIXTURE
FROM FIXTURE
FROM FIXTURE
GROUND WIRE
BLACK WIRE BLACK WIRE
GROUND WIRE
FROM HOUSE
FROM HOUSE
FROM HOUSE
HOMEDEPOT.CA / HOMEDEPOT.COM / GLUCKSTEINELEMENT.COM
Please contact 1-833-695-2045 for further assistance.

6
Installation (continued)
3Mounting the fixture body
Attach the fixture body (A) to the mounting plate (EE)
and secure it with the supplied install screws (DD).
Put the glass (B) into the cooling cup and turn the
glass to the right until it is tightened
4Applying the caulk
Once the fixture body (A) is mounted on the wall, caulk
(not included) the space between the wall and the upper
3/4 area of the fixture body (A) to prevent water seeping
into the junction box. Leave the bottom 1/4 area uncaulked
for drainage of any water which might leak into the enclosure.
A
B
EE
DD
Cooling cup
A

Care and Cleaning
Troubleshooting
The fixture will not light.
The LED is burned out.
□ Replace the fixture.
The power is off.
□ Make sure power supply is on.
There is a faulty wire connection.
□ Check wiring.
There is a faulty switch.
□ Test or replace the switch.
The fuse blows or the circuit breaker
trips when the light is turned on.
There are crossed wires or power wire is
grounding out.
□
Check the wire connections.
□ Contact a qualified electrician or call the
Customer Service Team at 1-833-695-2045.
P Prroobbllemem P PoosssisibblleeCCaauusese C CoorrrreectctiivveeAAccttiionon
7 HOMEDEPOT.CA / HOMEDEPOT.COM / GLUCKSTEINELEMENT.COM
Please contact 1-833-695-2045 for further assistance.

Questions, problems, missing parts? Before returning to the store,
call Gluckstein Elements Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-833-695-2045
HOMEDEPOT.CA
HOMEDEPOT.COM
GLUCKSTEINELEMENTS.COM
Retain this manual for future use.
