About This Publication
This catalog is not updated during the model year and should not be used for
ordering purposes. It is intended as a source of basic information. All illustrations
and specifications in this literature are based on the latest product information
available at the time of publication. General Motors reserves the right to make
changes at any time without notice. For further details, consult your local dealer.
Care must be taken during customer installation of equipment and wiring to
ensure that all holes drilled in the body are corrosion protected, properly sealed
and that vehicle wiring harnesses, piping or other components have not been
displaced or damaged. Aftermarket equipment installers must be mindful of
applicable Federal Motor Vehicle Safety Standards. This information can be
obtained directly from the National Highway Traffic Safety Administration.
Adding non-dealer accessories or making modifications to the vehicle can affect
vehicle performance, aerodynamics, and overall top speed.
These vehicles are equipped with an air bag system. The air bag system in your
police vehicle includes frontal driver and passenger air bags, front seat back side
impact air bags, front knee air bags or knee bolsters and side curtain air bags.
Customer installed equipment such as security barriers behind the front seats
should not be mounted so that the barrier ends are within the side air bag
deployment zones. The sensors and other components for the air bag system
must not be relocated to accommodate the installation of customer furnished
equipment; please refer to the service manual for sensor and other component
locations. For information concerning instrument panel top pad mounted
equipment and air bag system deployment zones, see the air bag information
section in this catalog and the vehicle owners manual.
A note about vehicle alterations by independent suppliers: This catalog shows
pictures of vehicles that have been altered or upfitted with equipment or
components supplied to Chevrolet or its dealers by independent suppliers.
Chevrolet is not responsible for the safety or quality of design features, materials
or workmanship of any alterations by a supplier.
Copyright 2018 General Motors. All rights reserved. Chevrolet and the Chevrolet Emblem are registered
trademarks of General Motors LLC.

INDEX
·  UPDATES FOR 2018 TAHOE
4WD POLICE PACKAGE
 ·  STANDARD FEATURES
 ·  POWERTRAIN & EMISSIONS
·  COLORS & INTERIOR TRIM
·  SPEEDOMETER/CLUSTER DISPLAY
·  RADIO SCREEN DISPLAY
·  OPTIONAL EQUIPMENT
·  ONSTAR® 4GLTE Wi-FiSERVICE PLANS
·  SPECIFICATIONS
·  ILLUSTRATION HIGHLIGHTS
·  LOADING ZONES
·  WIRING DIAGRAMS
·  AIRBAG DIMENSIONS
·  AIRBAGS FAQ
·  STABILITRAK
·  MAINTENANCE AND WARRANTY

2018 TAHOE 4WD
POLICE PACKAGE 9C1
2018 TAHOE 4WD PURSUIT
Shown with aftermarket equipment
Fullyaccessibleunderbodysparetirestandard New Chevrolet MyLink Radio
2018 Municipal Specification Guide

2018 TAHOE 4WD
POLICE PACKAGE 9C1
1
UPDATES FOR 2018
12-03-17
New (IO5) Chevrolet MyLink Radio
NEW FEATURES
• (IO5) Chevrolet MyLink Radio with 8" diagonal color touch-screen
• (UDD) 4.2" diagonal multi-color Driver Information Center
• (UK3) Steering wheel-mounted audio, Cruise Control and Driver Information Center controls
• Optional (PCW) Enhanced Driver Alert Package, includes (JF4) Power-adjustable pedals,
(UEU) Forward Collision Alert, (TQ5) IntelliBeam headlamps, (UHY) Low Speed Forward
Automatic Braking, (UHX) Lane Keep Assist with Lane Departure Warning and Safety
Alert Driver Seat
• (G9K) Satin Steel Metallic
• (G2X) Havana Brown Metallic (No longer available to order as of 11-20-17)
• (UJM) Tire Pressure Monitor System now includes Tire Fill Alert
• LED signature daytime running lamps
DISCONTINUED
• (GWT) Champagne Silver Metallic
• (IO3) AM/FM stereo with CD player
• (UDC) One-color Driver Information Center

2018 TAHOE 4WD
POLICE PACKAGE 9C1
2
2018 TAHOE 4WD
POLICE PACKAGE 9C1
2
1. Requires a compatible mobile device, active ONSTAR® service and data plan. 4G LTE service available in select markets. Visit ONSTAR®.com for coverage map, details and system limitations.
Data plan provided by AT&T.
2. Always use safety belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner’s Manual for more information.
3. Does not include emergency or security services. Visit ONSTAR®.com for coverage map, details and system limitations
4. Visit ONSTAR®.com for coverage map, details and system limitations
5. MyLink functionality varies by model. Full functionality requires compatible Bluetooth and smartphone, and USB connectivity for some devices
6. Not compatible with all devices.
STANDARD 9C1 INTERIOR FEATURES
AIR CONDITIONING Dual-zone automatic, includes front and rear air conditioning with electronic controls
ASSIST HANDLES Front passenger and second row outboard; front passenger assist handle is deleted when passenger side
spotlamp is ordered
AUDIO SYSTEM Chevrolet MyLink Radio5with 8" diagonal color touch-screen, AM/FM stereo with seek-and-scan and
digital clock, includes Bluetooth® streaming audio for music and select phones; voice-activated
technology for radio and phone; and Shop with the ability to browse, select and install apps to your
vehicle. Includes 4 USB ports and 1 auxiliary jack. The 8-inch diagonal color touch-screen slides up to
reveal a password-protected area behind the display with space for cell phones, wallets or other
valuables. Additionally, a USB port6gives you one more place to charge your devices. Includes 6
Speakers and Single-slot CD/MP3 player.
BLUETOOTH® 1Bluetooth® cell phone connectivity Displayed on radio screen (see standard equipment illustrations section)
Bluetooth® microphone is same location as ONSTAR®. It is located on the headliner in front of driver's sun visor.
Bluetooth® phone conversations are broadcast over the 4 front speakers. The speakers are located in the left front
door/right front door/left side of dash/right side of dash
COMPASS Displayed on Speedometer Cluster (see Picture on Speedometer/Cluster page)
CONSOLE, OVERHEAD Includes Rear Seat Panoramic Mirror, Map lights, Passenger airbag indicator and Sunglasses holder
CRUISE CONTROL Electronic with set and resume speed
DRIVER INFORMATION CENTER 4.2" diagonal multi-color.
FLOOR COVERING Black rubberized vinyl floor and load floor behind second row seats, see illustration section for description
(carpeting and carpeted floor mats are available, see option B30 and B58 see available options page)
GLASS Deep-tinted, all windows (except for windshield, and driver/front-passenger side glass which are light-tinted).
Front doors have a 24.6% UV transmission Rear door and cargo glass is 12% +/- 3% transparency and front
glass has 70% minimum. Non-tinted, solar absorbing glass available (see options page for descriptive).
GLOVE BOX Locking door without courtesy light (uses ignition key)
LIGHTING Interior LED with courtesy lights, door handle or remote entry activated, illuminated entry and map lights
MIRROR, INSIDE Rearview, manual day/night.
NAVIGATION Available only with active ONSTAR®2account that includes Turn-by-Turn directions plan; directions are
displayed as text on radio. Does not include map view navigation screen.
OCCUPANT SENSING SYSTEM Automatic Occupant Sensing System, sensor indicator inflatable restraint, front passenger
ONSTAR® ONSTAR® Basic Plan3, ONSTAR® Guidance4and ONSTAR® 4G LTE with Wi-Fi See ONSTAR® section for Availability and
Available Plans
OUTSIDE TEMPERATURE Displays in top right corner of radio screen (see standard equipment illustrations section)
RESTRAINT SYSTEM2Three point safety belts, driver and front passenger with pretensioners, dual stage driver and front passenger
frontal airbags, driver and passenger knee bolsters, front passenger sensing system with frontal airbag ON/OFF
indicator, rollover sensor, dual head curtain airbags for front and second row outboard occupants3and front
seat-back mounted thorax-pelvic airbags; head curtain airbag extends to cargo area.
NOTE: Safety belt extenders are available in 9 inch (part number 19259268) through our dealer at no charge
SEATS, FRONT CLOTH 40/20/40 individual seats, 3 passengers with 10-way power driver seat adjuster (fore/aft, up/down, tilt,
recline, and lumbar), and 6-way power passenger seat adjuster. Adjustable outboard head restraints and
storage pockets. Center seat section can be deleted (9U3) for 15" of open floor space
(see front seats and interior trim illustration page for description).
SEAT, REAR CLOTH split-folding 60/40 bench seats includes folding center armrest with cup holders, outboard seating
position headrests and reclining rear seat back. (Vinyl 2nd row seat option 5T5) 3rd row seats not available (see
front seats and interior trim illustration page for description).
SPEEDOMETER/CLUSTER Digital Speedometer and 150 mph certified analog speedometer, 1 mph increments and digital trip odometer
with gauges for engine oil pressure, fuel, battery volts, coolant temperature and tachometer. Driver Information
Center displays engine hours, warnings, and backup sensor proximity status while in reverse.
(see message listing for additional features).
STEERING WHEEL Tilt-wheel with cruise control and column mounted gear shift lever.
STEERING WHEEL CONTROLS Mounted audio and cruise controls, includes Driver Information Center controls
SURVEILLANCE FEATURE Body Control Module calibration is available to disable all automatic interior and exterior lighting. Feature
requires connection to BCM by customer. Feature operates with or without SEO 9G8, delete Daytime Running
Lamps and Automatic Headlamps.
(see Interior/Exterior Lamps Control page)
TEEN DRIVER MODE A configurable feature that can be programmed through your radio that lets you activate customizable vehicle
settings associated with a key fob, to encourage safe driving behavior. It can limit certain vehicle features, and
it prevents certain safety systems from being turned off. An in-vehicle report gives you information on your
driving habits.
The four-wheel drive Tahoe Police Package (9C1) has been designed for police work up to, and including, high-speed emergency
vehicle operations. GM restricts the sale of police vehicles and they are not to be sold to retail customers. Model CK15706 (four-wheel
drive) with equipment group 1FL is required when ordering 9C1 Police Package. Content, Options and Specications shown are for
Police and Special Service Vehicles only which differ from retail civilian model.

2018 TAHOE 4WD
POLICE PACKAGE 9C1
3
THEFT DETERRENT SYSTEM Vehicle PASS-Key® III+ and content theft (unauthorized entry, or entry without use of keyless remote fob,
sounds horn and lamps flash). Content Theft Alarm Disable, option UTQ must be ordered.
VISORS Padded with cloth trim, extends on rod; driver and front passenger illuminated vanity mirrors
WARNING TONES Headlamp on, key-in-ignition, driver and right-front passenger safety belt unfasten, backup sensor with warning
tone and turn signal on
WINDOW OPERATION Power with driver express up/down and lockout features
STANDARD 9C1 EXTERIOR FEATURES
ASSIST STEPS Black, mounted between front and rear wheels
BODY SIDE MOLDINGS Optional (see options page)
CAPLESS FUEL FILL The vehicle has a capless refueling system and does not have a fuel cap. The filling nozzle must be fully
inserted and latched prior to starting fuel flow.
NOTE: Overfilling the fuel tank by more than three clicks of a standard fill nozzle may cause vehicle performance issues, including engine stalling
and damage to the fuel system, fuel spills, potential fuel fires
DEFOGGER Electric, rear window
DOOR HANDLES Body color
DOOR LOCKS Power programmable; Lockout is disabled; see LOCK-OUT PROTECTION description shown under
STANDARD 9C1 ELECTRICAL FEATURES below. Door locks can be programmed via radio settings menu (see
standard equipment illustrations section). Lock cylinder not available on passenger front door or rear liftgate.
Child safety door and window locks individually controlled electronically by driver door mounted switches.
Includes 2 remote transmitters.
FASCIA, FRONT Body color with police specific lower extension for increased brake cooling and ground clearance. Fascia
comes with tow hook openings but does not include tow hooks. For tow hooks see Option V76 Recovery
Hooks on exterior options page.
FASCIA, REAR Body color with step pad
FOG LAMPS Not available
HEADLAMPS Dual LED with flash-to-pass feature, automatic exterior lamp control and daytime running lamps. Daytime
running lamps are LED Signature Lighting. To disable daytime running lamps and automatic lamps control, see
option 9G8 on the available options page. Altering headlamp assembly is not recommended, General Motors
is not responsible for the effects of any modifications.
HORNS Dual note
KEYS Two-sided, random code, for ignition, driver door and glove box.
Six additional keys are available (maximum 8 keys can be programmed per vehicle). Fleet keyed-alike is
available; see Options 6E2 or 6E8.
KEYLESS ENTRY REMOTES Includes two extended-range transmitters with non-functional panic button; stealth mode feature includes
exterior lamps and horn disable as default setting. Remote feedback is programmable via radio settings if light
and or horn lock/unlock notification is desired. Daytime running lamps will remain illuminated when optional
(BTV) remote start is activated. Additional transmitters are available; (see options page for descriptive).
LUGGAGE RACK Not available
MIRRORS, OUTSIDE Heated power-adjustable, manual-folding, color keyed, driver-side includes spotter mirror
RADIO ANTENNA Located in rear quarter glass
REAR LIFTGATE Manual open/close with liftgate/liftglass latch exterior release switch or release via remote fob
REAR VISION CAMERA Rear camera view radio screen display with audible warning (see illustration section for description)
REAR PARK ASSIST Sensors on rear bumper to assist with parking and avoiding objects while in reverse.
TIRES Goodyear P265/60R17 all-season, V-rated, blackwall, (see standard equipment illustrations section) includes
matching spare tire
TIRE PRESSURE MONITOR Tire Pressure Monitoring System. Standard spare wheel not equipped with TPM sensor. Includes Tire Fill Alert
WITH TIRE FILL ALERT in addition to the DIC warning when a tire has low pressure, this feature provides audible and visual indication
when air is being added to the low tire to aid in achieving optimal tire pressure.sensor; must be programmed
when mounted (see standard equipment illustrations section).
TIRE, SPARE Full-size spare, lockable with outside winch-type carrier mounted under frame at rear.
(includes TPM sensor - not programmed)
UNDER HOOD LAMP Not available
WINDSHIELD Solar absorbing shaded upper with acoustic laminated glass
WINDSHIELD WIPERS Intermittent, with rain sensing
WHEELS 17" x 8" black steel (includes matching full-size spare)
WHEEL CENTER CAP Bolt-on metal, black finish

2018 TAHOE 4WD
POLICE PACKAGE 9C1
4
2018 TAHOE 4WD
POLICE PACKAGE 9C1
4
1. E85 is 85% ethanol and 15% gasoline.
STANDARD 9C1 ELECTRICAL FEATURES
AUXILIARY POWER, FRONT 170-Amp ignition and main power supply wiring at lower center of instrument panel: 120-amp primary
battery ignition controlled relay power and 50-amp auxiliary battery power
(see specifications page for description)
AUXILIARY POWER, REAR 100-amp cargo area (auxiliary battery powered) (see standard equipment illustrations section)
LOCK-OUT PROTECTION Lockout Protection is not available with the Tahoe Police and Special Service Vehicle. When locking is
requested with the driver door open and the key in the ignition, all doors will lock and remain locked. The
key-in-ignition audible warning will sound while the driver door is open. The locked driver door can be closed
with the key in the ignition. If running, the engine will remain running.
POWER OUTLETS 110-volt (3 prong outlet) located in the lower center stack. 110 volt, 60 Hertz power outlet is rated 150 watts
(1.36 amps at 110v). Overload power before automatic shut off is 275 watts for 10 seconds or 418 watts for 1
second. Also includes four auxiliary 12-volt outlets including one on the instrument panel, one in the center
fold-down seat storage, and two in the cargo area. Outlet power is configurable to be Battery Powered at all
times or Ignition Controlled Power. See the Standard Equipment Section for description of selecting Outlet
power configuration.
WIRING DIAGRAMS See Wiring Section for description; also see Tahoe Police Package owner’s manual supplement
(located in glove box folder with standard owner’s manual)
STANDARD 9C1 CHASSIS FEATURES
AERO SHUTTERS Aero shutters are designed to close when operating conditions permit. The shutters are located on the front
of the A/C condenser under hood to divert airflow around the front of the truck reducing wind drag and
improves fuel economy. When the cooling system requires more air flow the shutters automatically reopen,
ensuring proper air flow through the radiator
AIR CLEANER High-capacity
ALTERNATOR 170-amp high output with idle boost based on battery energy level (see specifications page for description)
AXLE 3.08 Ratio with heavy-duty locking differential
BATTERIES Primary 720 CCA, 80 amp-hour rating with battery rundown protection (may be configured to protect
customer installed equipment). Isolated, Auxiliary 730 CCA, 70 amp-hour battery without battery run-down
protection for customer installed equipment. (see specifications page)
BRAKES Heavy-duty 4-wheel anti-lock front and rear disc with vacuum boost power assist. Includes Front brake
cooling air deflectors
COOLING Heavy-duty high-capacity radiator, electric fans and extended life coolant; coolant hoses are EPDM (ethylene-
propylene-diene monomer) rubber; silicone hoses are not required (coolant is DEX-COOL good for 5
years/150,000 miles, protects from -34° F to +265° F and against rust and corrosion)
ENGINE 5.3L EcoTec3 V8 with direct injection, variable valve timing (VVT), Active Fuel Management (AFM), aluminum
block, Flex Fuel1 includes air conditioning wide open throttle cut off (see powertrain page for description and
emissions, see also specifications page)
EXHAUST Aluminized stainless-steel muffler and tailpipe
FRAME Full perimeter, modular with hydroformed rails (includes ground straps. See Radio Suppression below.)
FUEL TANK CAPACITY 26 gallon (98 liters)
HILL START ASSIST This feature is designed to prevent the vehicle from rolling, either forward or rearward, during vehicle drive off.
OIL COOLERS Engine oil, oil-to-coolant heat exchanger in passenger side of coolant radiator. Transmission oil, oil-to-coolant
heat exchanger in upper portion of the AC condenser (see standard equipment illustrations section)
PROP SHAFT 4 inch diameter aluminum
RADIO SUPPRESSION Grounding straps, at five locations (see standard equipment illustrations section).
REAR DIFFERENTIAL Heavy-duty locking
SPARK PLUGS Extended life - iridium tip
STABILITRAK The stability system is capable of recognizing high performance driving with a Track Detect Mode.
When continuous high performance driving occurs in 2WD or Auto 4WD Mode, the stability system will
automatically enter Competition Mode. When engaged, the message "Competition Mode" will appear in the
DIC and the Traction Control OFF and StabiliTrak OFF lights will illuminate. (see illustration section for
StabiliTrak button location)
Competition mode can be disengaged by any of these four methods:
-Discontinue high performance driving for approximately 2 minutes
-Place transmission shift lever into Park for a brief period of time
-Press and hold button to completely disable Traction Control and press again to re-enable all stability
systems
-Turn engine off
STEERING Electric power-assisted rack and pinion (see standard equipment illustrations section)

2018 TAHOE 4WD
POLICE PACKAGE 9C1
5
SUSPENSION, FRONT Heavy-duty, police-rated. Includes specific spring rates, ride height, shock tuning and stabilizer bar.
SUSPENSION, REAR Multi-link, coil springs and stabilizer bar
TRAILERING EQUIPMENT SAE Class II hitch with 2 inch (51 mm) square receiver. Trailer may weigh up to 4,000 pounds (1,844 kg) with
proper hitch selection. See the Owners Manual for additional information.
TRANSMISSION Enhanced calibration 6-speed automatic with overdrive and tow/haul mode. Electronically-controlled
transmission provides protection against over-revving the engine in low gear and a mechanical low gear
blockout is not required; if a driver manually selects low gear and fails to manually upshift to high gear, the
powertrain control module automatically protects the drivetrain. The transmission is calibrated to maintain
lower gears when driving aggressively. This enhances vehicle control while driving through corners and when
throttling up to exit a corner, keeping the transmission in one gear instead of upshifting and downshifting
avoids "hunting" for a gear state
TRANSFER CASE Autotrac, 2-speed electronic with rotary control, includes neutral position for dinghy towing (2HI, 4AUTO, 4HI,
4LO, and Neutral setting)
See owners manual procedure for shifting into N (Neutral) and shifting out of N (Neutral).
UNDER BODY SHIELD, FRONT Two-piece, heavy-duty aluminum front underbody shield starting behind front bumper and running to 2nd
cross-member protecting front underbody and oil pan (see standard equipment illustrations section)
WARRANTY See Maintenance and Warranty information for additional information.

2018 TAHOE 4WD
POLICE PACKAGE 9C1
6
2018 TAHOE 4WD
POLICE PACKAGE 9C1
6
FE9 FEDERAL EMISSIONS, Use for ordering vehicles that will be registered in all states except California,
Connecticut, Delaware, Maine, Maryland, Massachusetts, New Jersey, New York, Oregon, Pennsylvania, Rhode
Island, Vermont and Washington State.
YF5 CALIFORNIA EMISSIONS, Use for ordering vehicles that will be registered in California.
NE1 EMISSIONS, Use for ordering vehicles that will be registered in Connecticut, Delaware, Maine, Maryland,
Massachusetts, New Jersey, New York, Oregon, Pennsylvania, Rhode Island, Vermont or Washington State.
NB8 EMISSIONS, Required when option code FE9 “FEDERAL EMISSIONS” is ordered for delivery to a dealer
located in California, Connecticut, Delaware, Massachusetts, Maryland, New Jersey, New York, Oregon,
Pennsylvania, Rhode Island and Washington State for a purchaser who will be registering the vehicle outside
California, Connecticut, Delaware, Maine, Maryland, Massachusetts, New Jersey, New York, Oregon,
Pennsylvania, Rhode Island, Vermont and Washington State. Do not use for vehicles that will be registered in
California, Connecticut, Delaware, Maine, Maryland, Massachusetts, New Jersey, New York, Oregon,
Pennsylvania, Rhode Island, Vermont or Washington State.
NC7 EMISSIONS, Required when option code YF5 “CALIFORNIA EMISSIONS” or option code NE1 "CT/DE/ME/MD/
MA/NJ/NY/OR/PA/RI/VT/WA EMISSIONS" is ordered for delivery to a dealer located in any state except
California, Connecticut, Delaware, Maine, Maryland, Massachusetts, New Jersey, New York, Oregon,
Pennsylvania, Rhode Island, Vermont and Washington State for a purchaser who will be registering the vehicle
in one of these states or sold as permitted below under “EPA Policy on the Sale of California Emission
Vehicles”.
NB9 EMISSIONS, Required when option code YF5 is ordered for delivery to a dealer located in Connecticut,
Delaware, Maine, Maryland, Massachusetts, New Jersey, New York, Oregon, Pennsylvania, Rhode Island,
Vermont and Washington State. Required when option code NE1 is ordered for delivery to a dealer located in
California.
NOTE: For more 2018 Emissions requirements contact your local dealer (reference 2018 Model Year GM Vehicles Emission
Requirements Bulletin number GM 17-17 issued August 22, 2017)
NOTE: The 2018 Chevrolet Tahoe Police Patrol Vehicle and Special Service Vehicle with the 5.3L Engine (L83) with Emission Option
Codes FE9, NE1 and YF5 is certied to EPA Tier 2 Bin 5 standards and qualies as ULEV 125 (Ultra Low Emission Vehicle) under
California Air Resources Board (CARB) requirements, meaning it is 50-state certied.
Emission Standard: FFV BIN125/ULEV125 LDT3-LDT4 /LDT2
EPA engine family or test group: JGMXT05.3382
1. E85 is 85% ethanol and 15% gasoline.
ENGINE TRANSMISSION AXLE
OPTION TYPE DISPLACEMENT FUEL OPTION TYPE OPTION RATIO
CODE LITERS/CU. IN. SYSTEM CODE CODE
L83 V8 5.3/325 Active fuel MXO/MYC 6L80 GU4 3.08
management 6-speed
FlexFuel
1
auto. with OD
POWERTRAIN
EMISSIONS - MUST BE SPECIFIED

2018 TAHOE 4WD
POLICE PACKAGE 9C1
7
TIRES v-sPEED RATED
MANUFACTURER QUANTITY SIZE SPEED RATING TYPE
GOODYEAR 5 P265/60R17 V All season BW
NOTE: Due to specific requirements for performance durability and safety, GM recommends only
the original equipment tires for replacement
Tire Plies = Tread 6 ply; 2 Polyester, 2 Steel, 2 Nylon, Sidewall, 2 Polyester
Tire Chains - If the vehicle has 265/65R18, P265/65R18, P275/55R20, or P285/45R22 size tires, do not use tire
chains. There is not enough clearance. Tire chains used on a vehicle without the proper amount of clearance can cause
damage to the brakes, suspension, or other vehicle parts. The area damaged by the tire chains could cause loss of
control and a crash. Use another type of traction device only if its manufacturer recommends it for the vehicle's tire
size combination and road conditions. Follow that manufacturer's instructions. To avoid vehicle damage, drive slow
and readjust or remove the traction device if it is contacting the vehicle. Do not spin the wheels. If traction devices are
used, install them on the rear tires. If the vehicle has P255/70R17 or P265/70R17 size tires, use tire chains only where
legal and only when necessary. Use chains that are the proper size for the tires. Install them on the rear tires only. Do
not use chains on the front tires. Tighten them as tightly as possible with the ends securely fastened. Drive slowly and
follow the chain manufacturer's instructions. If the chains contact the vehicle, stop and retighten them. If the contact
continues, slow down until it stops. Driving too fast or spinning the wheels with chains on will damage the vehicle.
MSP Blue 9V2 WA-5665
Woodland Green 9V5 WA-9015
Victory Red
1
5T4 WA-9260
Wheatland Yellow (86U) 9W3 WA-253A
Dark Toreador Red — WA-334D
SEO PAINT AVAILABLE
COLOR DESCRIPTION SEO CODE WA#
Note: Will require 5 orders before sending to plant
1 – Requires SEO (5T4) Exterior body colored parts
AVAILABLE INTERIOR COLOR Actual colors may vary
HOU
Black
Cloth
5T5
Black
Vinyl
AVAILABLE EXTERIOR COLORS Actual colors may vary
* Additional Charge.
** No longer available to order as of 11-20-17
GBA
Black
G1M
Blue Velvet
Metallic
G1E
*Siren Red
Tintcoat
GAZ
Summit
White
GXG
Tungsten
Metallic
GMU
Pepperdust
Metallic
GAN
Silver Ice
Metallic
G9K
Satin Steel
Metallic
G2X
**Havana
Brown
Metallic

2018 TAHOE 4WD
POLICE PACKAGE 9C1
8
2018 TAHOE 4WD
POLICE PACKAGE 9C1
8
FRONT SEATS AND INTERIOR TRIM
REAR SEATS AND INTERIOR TRIM
STANDARD Cloth front 40/20/40 Individual Seats (AZ3) 3-Occupant, Center seat can be unbolted for removal.
Center fold-down armrest with USB, Auxiliary Jack and Auxiliary Power connection and lockable seat cushion
storage. STANDARD 10-way power driver seat, includes power lumbar and power recline. STANDARD 6-way
power front passenger seat. Outboard seat back thoracic-pelvic airbags.
STANDARD Cloth Second Row 60/40 Split-folding Bench Seat (AT6) Includes folding center armrest with
cup holder
NOTE: Third row seating is not available and roof rail airbags extend into cargo area.
OPTIONAL - A95 BUCKET SEATS Cloth Bucket Seats with Console (Option A95) Driver and Passenger Front
Bucket Cloth Seats, with integrated retail console. 10-way Power Driver and Passenger Seats with Outboard-
Seat Back Pelvic Airbag and driver seat-mounted Front Center Airbag.
Not recommend for vehicles intended to be up-fitted with aftermarket equipment.
OPTIONAL - SEO 5T5 VINYL REAR SEAT Vinyl Second Row 60/40 Split-folding Bench Seat (Option 5T5)
• Front cloth and vinyl rear seat
combination is available by ordering
option 5T5 and requires Jet Black (HOU)
• Center seat can be unbolted for removal
Seat Code Seat Trim Color Color Code
AZ3 Cloth Jet Black HOU
• Front cloth and vinyl rear seat
combination is available by ordering
option 5T5 and requires Jet Black (HOU)
Seat Code Seat Trim Color Color Code
AZ3 & 9U3 Cloth Jet Black HOU
• Color is based on front seat choice
Seat Code Seat Trim Color Color Code
AT6 Cloth Jet Black HOU
• Front cloth and vinyl rear seat
combination is available by ordering
option 5T5 and requires Jet Black (HOU)
• Console cannot be deleted
• SD card reader not available
Seat Code Seat Trim Color Color Code
A95 Cloth Jet Black HOU
• Front cloth and vinyl rear seat
combination is available by ordering
option 5T5 and requires Jet Black (HOU)
Seat Code Seat Trim Color Color Code
5T5 Vinyl Jet Black HOU
OPTIONAL - SEO 9U3 20% SEAT DELETE Cloth Front 40/40 Individual Seats (AZ3 & Option 9U3) Deletes
center seat to provide 15" of open space between Driver and Passenger Seat. STANDARD 10-way power driver
seat, includes power lumbar and power recline. Outboard seat back thoracic-pelvic airbags. STANDARD 6-way
power front passenger seat. A separate cable and connection kit for the USB, Auxiliary Jack and Auxiliary Power
is provided in the vehicle when the center seat is deleted.

2018 TAHOE 4WD
POLICE PACKAGE 9C1
9
2018 TAHOE 4WD
POLICE PACKAGE 9C1
9
UNITED STATES CERTIFIED SPEEDOMETER/CLUSTER
(CANADIAN SIMILAR)
SPEEDOMETER CERTIFICATION
CALIBRATION
Specifications at ambient temperature of -10 to 120
degrees F (-23 to 49 Celsius). Inaccuracies due to
vehicle speed sensing are included.
ACTUAL VEHICLE SPEED INDICATED SPEED
0 TO 120 MPH +/- 2 MPH
0 TO 193 KPH +/- 3 KPH
The speedometer calibration is for the
5.3L engine, automatic transmission with
a 3.08 axle and P265/60R17 V-rated tires
STEERING WHEEL MENU CONTROLS
DRIVER INFORMATION CENTER
DIC MAIN MENU
INFO
NAVIGATION
OPTIONS
PHONE
AUDIO
Speed
Trip A
Trip B
Fuel Range
Oil Life
Tire Pressure
Fuel Economy
Timer
Engine Hours
Transmission Fluid
Off-Road
Blank Page
ACTIVE INFO PAGES as listed in
DIC main menu item OPTIONS above

2018 TAHOE 4WD
POLICE PACKAGE 9C1
10
Remote keyless entry/lock feedback
and courtesy lighting are programmable
through radio menu. Factory default
condition for Remote Keyless Entry
feedback and exit lighting is enabled in
Surveillance Mode (exterior lamps do
not flash, horn does not sound).
RADIO DISPLAY SCREEN AND RADIO CONTROLS
SETTINGS MENU
Time and Date
Rear Seat Reminder
Language
Valet Mode
Teen Driver
Radio
Vehicle
Climate and Air Quality
Collision/Detection System
Comfort and Convenience
Chime Volume
Auto Wipe in Reverse Gear
Lighting
Vehicle Locator Lights
Exit Lighting
Power Door Locks
Auto Door Lock
Auto Door Unlock
Delayed Door Lock
Bluetooth®
Device Management
Ringtones
Voice Mail Numbers
Text Message Alerts
Apple Carplay
Android Auto
Voice
Display
Calibrate Touchscreen
Turn Display Off
Rear Camera
Guidance Lines
Rear Park Assist Symbols
Return to Factory Settings
Software Information
WiFi

2018 TAHOE 4WD
POLICE PACKAGE 9C1
11
OPTIONAL EQUIPMENT & FEATURES
INTERIOR
RWU CARGO AREA ORGANIZER - Collapsible
UTQ CONTENT THEFT ALARM DISABLE - Flashing lamps and horn warning disable
(To avoid inadvertent alarm activation this option is recommended for customers that do not intend on using keyless entry remote fobs)
PCW ENHANCED DRIVER ALERT PACKAGE - Includes (JF4) Power-adjustable pedals, (UEU) Forward Collision Alert, (TQ5) IntelliBeam headlamps,
(UHY) Low Speed Forward Automatic Braking, (UHX) Lane Keep Assist with Lane Departure Warning and Safety Alert Driver Seat
B30 FLOOR COVERING - Color keyed carpeting (includes rear cargo floor)
AAK FLOOR LINER ALL WEATHER - 1st and 2nd rows, bright finish badge. Requires (B30) color-keyed floor covering. Not available with (VAV)
All-weatherr floor mats.
RIB FLOOR LINER PACKAGE - All-Weather, includes 1st, 2nd and 3rd row coverage. Requires (B30) color-keyed carpeting floor covering. Not
available with (AAK) all-weather floor liner, (VAV) all-weather floor mats.
B58 FLOOR MATS - Color keyed carpeted front and 2nd row included and only available with B30 Floor Covering
(not available with vinyl floor covering)
VAV FLOOR MATS - All weather (Dealer Installed) Requires (B30) floor covering
^ 6E2 KEY COMMON - All vehicles in fleet, provides a single key cut with a specific code that is common to the door lock and ignition of all the
vehicles in the vehicle fleet; this key code is an alternate to SEO 6E8 key common, complete vehicle fleet; An unlimited number of ignition
keys may be programmed to a vehicle. Not compatible with Caprice or Impala. Not compatible with 2014 or older Tahoe.
6E8 KEY COMMON - All vehicles in fleet, provides a single key cut with a specific code that is common to the door lock and ignition of all the
vehicles in the vehicle fleet; this key code is an alternate to SEO 6E2 key common, complete vehicle fleet; An unlimited number of ignition keys
may be programmed to a vehicle. Not compatible with Caprice or Impala. Not compatible with 2014 or older Tahoe.
AMF KEYLESS ENTRY TRANSMITTERS - Fleet Package includes 6 additional transmitters. Transmitters are not programmed. Each transmitter,
including the two standard with the vehicle, must be programmed together by the customer or a dealer at customer expense. Transmitter
programming is not a warranty item. See programming remote key transmitter instructions. Vehicle specific, common fleet transmitter
frequency is not available
5HP KEYS - 6 additional, keys are not programmed to vehicle. Each key, including the 2 delivered with the vehicle, must be programmed at the same
time by the customer or a dealer at customer expense. Key programming is not a warranty item. A maximum of 8 random code keys can be
programmed. If a key is lost, all remaining keys must be reprogrammed with the replacement key. (see optional equipment illustrations section)
6C7 LAMP, AUXILIARY DOME - Red and white LED dome lamp is located on the headliner between front row seats. Wired independently from
standard dome lamp.
UEO ONSTAR DELETE - Standard Bluetooth functionality remains. OnStar 4G LTE is deleted when UEO OnStar Delete is ordered
JF4 PEDALS - Power-adjustable for accelerator and brake.
6N6 REAR DOOR LOCKS AND HANDLES INOPERATIVE - Rear power locks are inoperable at rear door but operate from drivers position, rear
doors can be opened only from outside the vehicle.
6N5 REAR DOOR WINDOW SWITCHES INOPERATIVE - Rear windows only operate from drivers position
UJ5 REAR SEAT DVD ENTERTAINMENT SYSTEM - Includes dual DVD headrests and two analog headphones (dealer-installed). It is "A/D" on
PPV 1FL and Special Service 1FL
SFJ REFLECTIVE WINDOW SHADE
BTV REMOTE VEHICLE STARTER SYSTEM - Includes remote keyless entry
A95 SEAT & CENTER CONSOLE - Driver and Passenger Front Bucket Cloth Seats, with integrated retail console. 10-way Power Driver and
Passenger Seats with Outboard-Seat Back Pelvic Airbag and Driver Inboard Seat Back Airbag.
Not recommend for vehicles intended to be up-fitted with aftermarket equipment.
5T5 SEAT - Front cloth with vinyl rear seat (see front seats and interior trim illustration page for description)
9U3 SEAT DELETE FRONT CENTER - 20% center section removed, Power driver and passenger bucket seats in base cloth trim. Derived from RPO
(AZ3) 40-20-40 split bench seat with the 20% section removed. Does not include a floor console. All exposed floor area will remain
untrimmed. Not available with (A95) Bucket Seats. A separate cable connection kit for the USB, Auxiliary Jack and Auxiliary Power is provided
in the vehicle when the center seat section is deleted for installation by customer/upfitter in aftermarket console.
VRS SHADE - Cargo security

2018 TAHOE 4WD
POLICE PACKAGE 9C1
12
2018 TAHOE 4WD
POLICE PACKAGE 9C1
12
EXTERIOR
B86 BODY SIDE LOWER DOOR MOLDINGS - Body-color. Not available with (TGK) Special paint or (B85) bright bodyside moldings
B85 BODY SIDE LOWER DOOR MOLDINGS - Bright bodyside. Not available with (B86) body-color bodyside moldings
9G8 DELETE DAYTIME RUNNING LAMPS AND AUTOMATIC HEADLAMPS - Exterior lamps are operated manually and automatic headlamps
deleted. (S ee Surveillance Feature Manual Lamp Control in standard illustration section)
5T4 EXTERIOR BODY COLOR PARTS - SEO 5T4 Exterior body colored parts. Victory Red special painted exterior body parts in lieu of glossy
Black color normally installed with special painted bodies, Victory Red painted parts will consist of front fascia, rear bumper fascia, rear
liftgate handle, and door handles. Mirrors, rear D-pillar appliqué and liftgate spoiler will remain Black. Requires SEO (TGK) special paint solid,
special paint color Victory Red WA-9260 and (V76) recovery hooks.
9V2 EXTERIOR BODY COLORED PARTS - Blue WA-5665 applied to front and rear fascia all other non-metal body parts will remain black, same as
(TGK) special paint solid. Includes opening in front fascia without recovery hooks (requires TGK special paint solid) Recovery hooks (V76)
optional.
6J7 FLASHER SYSTEM HEADLAMPSAND TAIL LAMPS- DRL compatible, headlamp flasher module with control wire to permit separate front and
rear lamp flashing
AKP NON-TINTED GLASS - Solar absorbing (replaces deep-tinted glass on rear doors and cargo area)
VK3 LICENSE PLATE - Front mounting package (included on orders with ship-to states that require front license plate) (see optional equipment
illustrations section)
VLG REAR-FASICA CLOSEOUT Available with (GAN) Silver Ice Metallic, (GAZ) Summit White or (GBA) Black exterior colors. Not available with
(S6N) Trailer hitch insert.
V76 RECOVERY HOOKS, BLACK - Two front frame-mounted. Required on all models sold to Alaska, Guam, Hawaii, Puerto Rico and Virgin Islands. All
Tahoe 9C1 Police and 5W4 Special Service Vehicles will include front fascia recovery hook openings but does not include the hooks .
See optional equipment illustrations section.
TGK SPECIAL PAINT SOLID - One color all normally body-colored non-sheet metal parts will be gloss Black. This includes front and rear facias,
liftgate handle and applique, D-pillars and upper liftgate applique. Mirrors and door handles will be grained Black parts. B85 body-side
moldings are not available except with SEO option 5T4 exterior body-colored parts. Required with any SEO paint selection may require
extended lead time
VQK SPLASH GUARDS - Molded black
7X6 SPOTLAMP - Left hand, separately fused, Not available with (7X7) left and right-hand spotlamps (see optional equipment illustrations section)
7X7 SPOTLAMPS - Left and right hand, separately fused (see optional equipment illustrations section)
NOTE: Factory installation of spotlamps are recommended. Special tooling is used to locate and drill the spotlamp shaft hole in the pillars. (Interior trim covers provided with factory
installed lamps are not available as service parts). Field installation of spotlamps must not interfere with proper deployment of the roof rail airbag in the event of a crash.
S6N TRAILER HITCH INSERT - Black rubber square with a logo that closes out the receiver (see optional equipment illustrations section)
(Dealer installed)
Q5U WHEELS - Bright machined aluminum, 17” x 8” (43.2 cm x 20.3 cm), includes (RM7) 17” x 8” (43.2 cm x 20.3 cm) full-size, steel spare.
ELECTRICAL
WX7 WIRING - For customer connection to front door and windshield pillar speakers. Front speakers are not connected to the vehicle radio; radio
audio signals are routed to the rear speakers
6J3 WIRING - For grille lamps and siren speaker
6J4 WIRING - For horn/siren circuit, in-line connection for customer furnished switch
UT7 GROUND STUDS - Two interior mounted left and right side M10 studs in cargo area. Driver side includes 5 feet of 8 gauge ground wire.
CHASSIS
1LR BRAKE SYSTEM, CITY - Modified Police City Brake Package. Uses base friction material that wears better at lower temperatures and city
service. The city brakes are not optimal for track performance. The front rotors are Duralife but do not have the radial drilled holes. The parts are
physically interchangeable for service, however the parts should be substituted as complete four wheel sets.
R9Y FLEET FREE MAINTENANCE CREDIT - This option code provides a credit in lieu of the free oil changes, tire rotations and inspections (2
maximum), during the first 24 months and 24,000 miles period for this ordered vehicle. The invoice will detail the applicable credit. The
Customer will be responsible for all oil changes, tire rotations and inspections cost for this vehicle.
NOTE: Dealer is unable to credit customer on vehicles not originally ordered with (R9Y) option.
K05 HEATER - Engine block
9C1 IDENTIFIER FOR PPV - Includes (K47) high-capacity air cleaner, (KW7) 170 amp high output alternator, (K4B) 730 cold-cranking amps
auxiliary battery, electrical power & vehicle signals for customer connection located at the center front floor. Auxiliary battery circuit for
customer connection located in the rear cargo area, (UN9) radio suppression package, (Z56) heavy-duty, police-rated suspension, front
independent torsion bar, and stabilizer bar and rear, multilink with coil springs, (QAR) P265/60R17 all-season, v-rated tires, (ZAK) P265/60R17
all-season, V-rated spare tire, Police brakes, (NZZ) underbody shield, (RAP) Black steel wheels w/bolt on center caps, Certified speedometer,
delete roof rails, (ATD) third row seat delete, (NQH) active 2-speed transfer case (4WD only).

2018 TAHOE 4WD
POLICE PACKAGE 9C1
13
2018 TAHOE 4WD
POLICE PACKAGE 9C1
13
ONSTAR®, 4G LTE WITH Wi-Fi and SIRIUS XM RADIO AVAILABILITY
Impala Tahe Tahoe Suburban Suburban Silverado Cargo Passenger
1FL 9C1 SSV 1FL 3500HD SSV Van Van
ONSTAR® SERVICE PLANS
Basic Plan S S S S S O* S S
UE1 S S S S S O S S
VV4 S S S S S O S S
PQF O O O O O O O O
PQG O O O O O O O O
PQH O O O O O O O O
PQI O O O O O O O O
PQL O O O O O O O O
PQM O O O O O O O O
PQP O O O O O O O O
PQQ O O O O O O O O
PQT O O O O O O O O
PRD O O O O O O O O
PRE O O O O O O O O
PRF O O O O O O O O
UEO - ONSTAR® Delete N/A O O O N/A N/A O O
* Included when UE1 is ordered
ONSTAR® 4G LTE WITH Wi-Fi SERVICE PLANS
ROV O O O O O O O O
ROW O O O O O O O O
SIRIUS XM SATELLITE RADIO
U2K S N/A N/A N/A S S O O
PR6 O N/A N/A N/A O O O O
PR7 O N/A N/A N/A O O O O
PR8 O N/A N/A N/A O O O O
GM COMMERCIAL LINK
P0G O O O O O O O O
P0H O O O O O O O O
P0I O O O O O O O O
S = Standard
O = Optional
N/A = Not Available
Description of option codes attached or spinning the wheels with chains on will damage the vehicle.

2018 TAHOE 4WD
POLICE PACKAGE 9C1
14
2018 TAHOE 4WD
POLICE PACKAGE 9C1
14
ONSTAR® BASIC PLAN FOR 5 YEARS
Includes limited vehicle mobile app features, Monthly Diagnostics Report and Dealer Maintenance Notication. Basic Plan available for 5
years from the date of vehicle delivery and is transferable. Does not include Emergency, Security or Navigation services.
UE1 - ONSTAR® GUIDANCE PLAN FOR 6 MONTHS
Includes Automatic Crash Response, Stolen Vehicle Assistance, Roadside Assistance, Turn-by-Turn Navigation, Advanced Diagnostics
and more (trial excludes Hands-Free Calling minutes). Visit www.ONSTAR®.com for coverage map, details and system limitations.
Services vary by model. ONSTAR® acts as a link to existing emergency service providers. Not all vehicles may transmit all crash data.
VV4 - ONSTAR® 4G LTE
Available built-in Wi-Fi hotspot offers a fast and reliable Internet connection for up to 7 devices; includes data trial for 3 months or
3GB (whichever comes rst). Requires (UE1) ONSTAR® Guidance plan. Available Wi-Fi requires compatible mobile device, active
ONSTAR® service and data plan. Data plans provided by AT&T. Visit ONSTAR®.com for details and system limitations.
PQF - ONSTAR® 6 MONTHS OF ONSTAR® PROTECTION SERVICE
Provides 6 months of Protection service in addition to the 6 months of standard Guidance Plan trial service that is included in the price
of the vehicle (trial excludes Hands-Free Calling minutes). Total service duration is 12 months. Requires UE1 ONSTAR®. Requires one of
the following Fleet or Government order types: FLS, FNR, FRC, FBC, FGO or FEF. Not available with PQI, PQL, PQM, PQP, PQQ, PQT,
PRE and PRF. Not available with a ship-to of Puerto Rico or the Virgin Islands. Available to order in addition to PQG, PQH or PRD.
PQG - ONSTAR® 18 MONTHS OF ONSTAR® PROTECTION SERVICE
Provides 18 months of Protection service in addition to the 6 months of standard Guidance Plan trial service that is included in the price
of the vehicle (trial excludes Hands-Free Calling minutes). Total service duration is 24 months. Requires UE1 ONSTAR®. Requires one
of the following Fleet or Government order types: FLS, FNR, FRC, FBC, FGO or FEF. Not available with PQI, PQL, PQM, PQP, PQQ, PQT,
PRE and PRF. Not available with a ship-to of Puerto Rico or the Virgin Islands. Available to order in addition to PQF, PQH or PRD.
PQH - ONSTAR® 30 MONTHS OF ONSTAR® PROTECTION SERVICE
Provides 30 months of Protection service in addition to the 6 months of standard Guidance Plan trial service that is included in the
price of the vehicle (trial excludes Hands-Free Calling minutes). Total service duration is 36 months. Requires UE1 ONSTAR®. Requires
one of the following Fleet or Government order types: FLS, FNR, FRC, FBC, FGO or FEF. Not available with PQI, PQL, PQM, PQP, PQQ,
PQT, PRE and PRF. Not available with a ship-to of Puerto Rico or the Virgin Islands. Available to order in addition to PQF, PQG or PRD.
PQI - ONSTAR® 6 MONTHS OF ONSTAR® SECURITY SERVICE
Provides 6 months of Security service in addition to the 6 months of standard Guidance Plan trial. Requires UE1 ONSTAR®. Requires
one of the following Fleet or Government order types: FLS, FNR, FRC, FBC, FGO or FEF. Not available with PQF, PQG, PQH, PQP, PQQ,
PQT service that is included in the price of the vehicle (trial excludes Hands-Free Calling minutes). Total service duration is 12 months.
PRD and PRF. Not available with a ship-to of Puerto Rico or the Virgin Islands. Available to order in addition to PQL, PQM or PRE.
PQL - ONSTAR® 18 MONTHS OF ONSTAR® SECURITY SERVICE
Provides 18 months of Security service in addition to the 6 months of standard Guidance Plan trial service that is included in the price
of the vehicle (trial excludes Hands-Free Calling minutes). Total service duration is 24 months. Requires UE1 ONSTAR®. Requires one
of the following Fleet or Government order types: FLS, FNR, FRC, FBC, FGO or FEF. Not available with PQF, PQG, PQH, PQP, PQQ,
PQT, PRD and PRF. Not available with a ship-to of Puerto Rico or the Virgin Islands. Available to order in addition to PQI, PQM or PRE.
PQM - ONSTAR® 30 MONTHS OF ONSTAR® SECURITY SERVICE
Provides 30 months of Security service in addition to the 6 months of standard Guidance Plan trial service that is included in the price
of the vehicle (trial excludes Hands-Free Calling minutes). Total service duration is 36 months. Requires UE1 ONSTAR®. Requires one
of the following Fleet or Government order types: FLS, FNR, FRC, FBC, FGO or FEF. Not available with PQF, PQG, PQH, PQP, PQQ,
PQT, PRD and PRF. Not available with a ship-to of Puerto Rico or the Virgin Islands. Available to order in addition to PQI, PQL or PRE.
PQP - ONSTAR® ADDITIONAL 6 MONTHS OF ONSTAR® FLEET GUIDANCE SERVICE
Provides 6 months of Fleet Guidance service in addition to the 6 months of standard Guidance Plan trial service that is included in the
price of the vehicle (plan excludes Hands-Free Calling minutes). Total service duration is 12 months. Requires UE1 ONSTAR®. Requires
one of the following Fleet or Government order types: FLS, FNR, FRC, FBC, FGO or FEF. Not available with PQF, PQG, PQH, PQI, PQL,
PQM, PRD and PRE. Not available with a ship-to of Puerto Rico or the Virgin Islands. Available to order in addition to PQQ, PQT or PRF.
PQQ - ONSTAR® ADDITIONAL 18 MONTHS OF ONSTAR® FLEET GUIDANCE SERVICE
Provides 18 months of Fleet Guidance service in addition to the 6 months of standard Guidance Plan trial service that is included in the
price of the vehicle (plan excludes Hands-Free Calling minutes). Total service duration is 24 months. Requires UE1 ONSTAR®. Requires
one of the following Fleet or Government order types: FLS, FNR, FRC, FBC, FGO or FEF. Not available with PQF, PQG, PQH, PQI, PQL,
PQM, PRD and PRE. Not available with a ship-to of Puerto Rico or the Virgin Islands. Available to order in addition to PQP, PQT or PRF.
PQT - ONSTAR® ADDITIONAL 30 MONTHS OF ONSTAR® FLEET GUIDANCE SERVICE
Provides 30 months of Guidance service in addition to the 6 months of standard Guidance Plan trial service that is included in the price
of the vehicle (plan excludes Hands-Free Calling minutes). Total service duration is 36 months. Requires UE1 ONSTAR®. Requires one
of the following Fleet or Government order types: FLS, FNR, FRC, FBC, FGO or FEF. Not available with PQF, PQG, PQH, PQI, PQL, PQM,
PRD and PRE. Not available with a ship-to of Puerto Rico or the Virgin Islands. Available to order in addition to PQP, PQQ or PRF.
ONSTAR® SERVICE PLANS

2018 TAHOE 4WD
POLICE PACKAGE 9C1
15
2018 TAHOE 4WD
POLICE PACKAGE 9C1
15
PRD - ONSTAR® 42 MONTHS OF ONSTAR® PROTECTION SERVICE
Provides 42 months of Protection service in addition to the 6 months of standard Guidance plan trial service that is included in the
price of the vehicle (trial excludes Hands-Free Calling minutes). Total service duration is 48 months. Requires UE1 ONSTAR®. Requires
one of the following Fleet or Government order types: FLS, FNR, FRC, FBC, FGO or FEF. Not available with PQI, PQL, PQM, PQP, PQQ,
PQT, PRE and PRF. Not available with a ship-to of Puerto Rico or the Virgin Islands. Available to order in addition to PQF, PQG or PQH.
PRE - ONSTAR® 42 MONTHS OF ONSTAR® SECURITY SERVICE
Provides 42 months of Security service in addition to the 6 months of standard Guidance plan trial service that is included in the price
of the vehicle (trial excludes Hands-Free Calling minutes). Total service duration is 48 months. Requires UE1 ONSTAR®. Requires one
of the following Fleet or Government order types: FLS, FNR, FRC, FBC, FGO or FEF. Not available with PQF, PQG, PQH, PQP, PQQ,
PQT, PRD and PRF. Not available with a ship-to of Puerto Rico or the Virgin Islands. Available to order in addition to PQI, PQL or PQM.
PRF - ONSTAR® ADDITIONAL 42 MONTHS OF ONSTAR® FLEET GUIDANCE SERVICE
Provides 42 months of Guidance service in addition to the 6 months of standard Guidance plan trial service that is included in the price of
the vehicle (trial and plan excludes Hands-Free Calling minutes). Total service duration is 48 months. Requires UE1 ONSTAR®. Requires
one of the following Fleet or Government order types: FLS, FNR, FRC, FBC, FGO or FEF. Not available with PQF, PQG, PQH, PQI, PQL,
PQM, PRD and PRE. Not available with a ship-to of Puerto Rico or the Virgin Islands. Available to order in addition to PQP, PQQ or PQT.
UE0 - ONSTAR®, DELETE
ROV - ONSTAR® WITH 4G LTE FOR FLEET (20GB/12 MONTHS)
Provides a built-in Wi-Fi hotspot to connect to the internet at 4G LTE speeds, includes AT&T 12GB data plan good for 12months. 1 -
Requires (UE1) ONSTAR® and (VV4) ONSTAR® with 4G LTE and one of the following order types FLS, FNR, FRC, FBC, FGO or FEF.
Not available with ROW. Visit www.ONSTAR®.com for vehicle availability, details and system limitations. Services and connectivity may
vary by model and conditions. 4G LTE service available in select markets. 4G LTE performance based on industry averages and vehicle
systems design. Some services require data plan.
ROW - ONSTAR® WITH 4G LTE FOR FLEET (36GB/24 MONTHS)
Provides a built-in Wi-Fi hotspot to connect to the internet at 4G LTE speeds, includes AT&T 24GB data plan good for 24
months. Requires (UE1) ONSTAR® and (VV4) ONSTAR® with 4G LTE and one of the following order types: FLS, FNR, FRC, FBC,
FGO or FEF. Not available with ROV. Visit www.ONSTAR®.com for vehicle availability, details and system limitations. Services and
connectivity may vary by model and conditions. 4G LTE service available in select markets. 4G LTE performance based on industry
averages and vehicle systems design. Some services require data plan.
P0G GM COMMERCIAL LINK 1 YEAR OF SERVICE - Includes 12 months of GM Commercial Link service. Provides access
and reporting for key vehicle information such as speed, location and maintenance through website and mobile application.
Eligible customers must sign up for an account at www.gmcommerciallink.com in order take advantage of this 12 month offer.
The Commercial Link service is included in the price of the vehicle. Total service duration is 12 months. Non-Transferrable. Non-
Refundable. Requires UE1 OnStar. Requires one of the following Fleet or Government order types: FLS, FNR, FRC, FBC, FGO or FEF.
Not available with (P0H) GM Commercial Link – 2 years of Service or (P0I) GM Commercial Link – 3 years of Service.
P0H GM COMMERCIAL LINK 2 YEARS OF SERVICE - Includes 24 months of GM Commercial Link service. Provides access
and reporting for key vehicle information such as speed, location and maintenance through website and mobile application.
Eligible customers must sign up for an account at www.gmcommerciallink.com in order take advantage of this 24 month offer.
The Commercial Link service is included in the price of the vehicle. Total service duration is 24 months. Non-Transferrable. Non-
Refundable. Requires UE1 OnStar. Requires one of the following Fleet or Government order types: FLS, FNR, FRC, FBC, FGO or FEF.
Not available with (P0G) GM Commercial Link – 1 year of Service or (P0I) GM Commercial Link – 3 years of Service.
P0I GM COMMERCIAL LINK 3 YEARS OF SERVICE - Includes 36 months of GM Commercial Link service. Provides access and
reporting for key vehicle information such as speed, location and maintenance through website and mobile application.
Eligible customers must sign up for an account at www.gmcommerciallink.com in order take advantage of this 36 month offer.
The Commercial Link service is included in the price of the vehicle. Total service duration is 36 months. Non-Transferrable. Non-
Refundable. Requires UE1 OnStar. Requires one of the following Fleet or Government order types: FLS, FNR, FRC, FBC, FGO or FEF.
Not available with (P0G) GM Commercial Link – 1 year of Service or (P0H) GM Commercial Link – 2 years of Service.
GM COMMERCIAL LINK
Wi-Fi SERVICE PLANS
ONSTAR® SERVICE PLANS (CONTINUED)

2018 TAHOE 4WD
POLICE PACKAGE 9C1
16
2018 TAHOE 4WD
POLICE PACKAGE 9C1
16
GENERAL
Model CK15706
Drive 4-wheel
Projected top speed (without equipment) 121 mph
Projected top speed in reverse (without equipment) 49 mph
NOTE: Adding nondealer accessories or making modifications to the
vehicle can affect vehicle performance, aerodynamics, and overall
top speed
EXTERIOR (in./mm)
Wheelbase 116.0/2946
Overall length 204.0/5182
Body width (without mirrors) 80.5/2045
Overall height* 72.4/1839
Lift in height* (Top of load floor to ground) 35.9/912
Step-in height 22.0/559
Front track width 68.7/1745
Rear track width 68.7/1744
Turning diameter curb to curb (ft./m) 39.3/999
Ground clearance* (rear axle) 8.5/216
Air intake height* 37.4/950
*Published dimensions indicated are at Base Curb Weight
FRONT COMPARTMENT (in./mm)
Head room (Maximum) 42.8/1087
Shoulder room 64.8/1646
Hip room 60.8/1544
Leg room (Maximum) 45.3/1151
REAR COMPARTMENT (in./mm)
Head room 38.7/983
Shoulder room 65.1/1654
Hip room 60.2/1529
Leg room 39.0/991
CARGO
Load floor length to center of front seat at floor (in./mm) 79.9/2029
Load floor length to center of 2nd seat at floor at seat (in./mm) 43.2/1097
Inside width between wheel house (in./mm) 49.3/1252
Cargo area height (in./mm) 40.9/1039
Cargo volume1maximum behind front seat (cu. ft./liters) 112.1/3174
Cargo volume1maximum behind second seat (cu. ft./liters) 54.0/1530
NOTE: For additional dimensional data go to: gmupfitter.com
PASSENGER COMPARTMENT
VOLUME INDEX (cu.ft./liters)
Passenger compartment volume index 120.7/3418
FUEL ECONOMY RATINGS (CITY/HIGHWY/COMBINED)
5.3L engine 4WD 16/22/18
NOTE: EPA estimated MPG label values. Actual mileage will vary with
options, driving conditions, driving habits and vehicle condition.
VEHICLE WEIGHT (lbs./kg.)
Seat Type 40/20/40 40/40
Standard Optional
GVWR3(Gross Vehicle Weight Rating) 7100/3221 7100/3221
FGAWR (Front Gross Axle Weight Rating) 3500/1588 3500/1588
RGAWR (Rear Gross Axle Weight Rating) 3800/1724 3800/1724
Base curb weight45480/2486 5442/2468
Payload51590/721 1628/738
Max. Trailer Towing64000/1814 4000/1814
NOTE: See owner’s manual supplement for loading information
1. Cargo and load capacity limited by weight and distribution.
3. Gross Vehicle Weight Rating (GVWR). When properly equipped, includes vehicle,
passengers, cargo and equipment.
4. Vehicle weight in operational status with 100% fuel, uids to factory ll, and standard
base equipment. Does not include driver, passenger or optional content.
5. These maximum payload ratings are intended for comparison purposes only. Before
you buy a vehicle or use it to haul people or cargo, carefully review the vehicle loading
section of the Owner’s Manual and check the carrying capacity of your specic vehicle
on the label on the inside of the driver’s door jamb.
6. Maximum Trailer Towing ratings are calculated assuming a minimally equipped vehicle
plus options necessary to achieve the rating plus driver. The weight of other optional
equipment, passengers and cargo will reduce the Maximum Trailer Towing your vehicle
can tow. See Order Guide for additional information.
SPECIFICATIONS
Specifications shown are for Police and Special Service Vehicles only which differ from retail civilian models
