gMFC Ghere v1.0 User manual

gMFC
Ghere MIDI Foot Controller
v1.0
Operating Instructions
November 2007
Copyright © 2007 Ghere Audio Solutions

orward

Table of Contents
I. Background
II. Safety Concerns
III. Controls and Connections
IV. Operating Guidelines
V. Technical Specifications
VI.

I. Background

II. Safety Concerns
!! Do not use the gM C® while taking a bath or shower !!
!! Do not eat the gM C® !!
!! The gM C® is designed to assist in making music. Very
loud music. Use ear-plugs to save your ears !!
** The actual safety concerns will be given in the future, when I have actually thought them through **

III. Controls and Connections
A) Patch Down / Patch Jump Program Button
B) Patch Up / Bank Select / Bank Program / Tuner Toggle
C) Effects Toggle (6 – 9) / Solo Toggle (0)
D) Patch Jump (1 – 5)
E) Power Switch
) MIDI OUT – Standard MIDI 5 Pin DIN emale
G) 3 Digit 7 Segment LED Display.
H)5V DC Charge receptacle (coming soon)
A
B
C
D
E F

IV. Operating
Basic operations of the gM C® are fairly straightforward. By default, the foot-
controller is set to bank 0. The bottom row of buttons (1 – 5) are the patch jump
buttons. They can be programmed to jump to any patch from 1 to 99. The top row of
buttons (6 – 0) are the effects on/off buttons. They are factory set in the following
manner:
Button Number Control
6, 7, 8, 9 MIDI cc # 2, 3, 4, 5
toggle respectively.
0Solo toggle for the
Digitech 2120 Artist VGS
The buttons on the right (A & B) are multifunction command buttons. In
standard mode, the A button sends a patch down command, and the B button sends a
patch up command. When you hold either button, the gM C® enters into two different
modes. Holding the A button enters into Patch-Jump mode. Holding the B button
enters into Bank Select/Utility mode.
Patch-Jump mode:
Patch-Jump mode is activated by holding the A button down for approximately 1
second. The display will go blank. This indicates that the gM C® is ready to receive a
program. To enter a patch to jump to, simply press the numbered buttons to enter the
desired patch number. or example to jump to patch 64, do the following:
1. Hold the A button until the display blanks.
2. Press the 6 button on the gM C®. The display shows 6 indicating which button was pressed.
3. Press the 4 button on the gM C®.
4. The display will now show “64” and a patch change command has been send to the midi
device.
**note: Due to program flow, if you press the A or B key as the first key after the display blanks,
a value of 10x or 11x is entered into the device. Where x would be the next button pressed. This
allows you to enter values up to 119 into the device. The Digitect ® device this was designed for
can only accept user programs up to 100, so I did not fully implement patch jumps past 99. eg.
Hold A, press A again, then press 5. The gM C® send a patch change of 105 to the MIDI
device.

Bank Select mode:
Bank Select mode is used to set which bank the gM C® will select patch jump
information from. Bank Select mode is activated by holding the B button down for
approximately 1 second. When activated, the display will show the current bank that is
selected. The default at power-on is zero. Press any of the number buttons to switch to
the bank that corresponds to that button. or example, to switch to patch bank 8, the
steps are:
1. Press and hold B for 1 second. The display will show the current bank.
2. Press 8.
3. The gM C® has switched to bank 8 and will display the current patch in use.
Utility mode:
Patch-Jump programming:
Once Bank Select mode is activated, the B button can be pressed again to
program which patch the patch-jump buttons will select. To program one of the patch-
jump butotns (1 – 5) the execute the following procedure.
1. Select the patch which you wish to set the button to jump to using any method you choose.
2. Press and hold the B button to enter Bank Select mode. The current bank is displayed.
3. Press the B button again. You are now ready to set the button that will jump to the patch you
have currently selected.
4. Choose any of the Patch-Jump buttons (1 – 5). Press that button.
5. The gM C® goes back to normal mode, and will now jump to the patch you just programmed
when that button is pressed again.
Tuner mode toggle:
To activate the tuner mode on a Digitech® 2120 Artist®, do the
following:
1. Press and hold the B button for one second.
2. Press the B button two more times.
3. The tuner mode on the Artist® unit will be activated.
4. Press any button to toggle tuner mode off.
