GOAT BLUE Series STEREO CHORUS User manual

STEREOCHORUS
GOAT-DESIGN.JP2022
-BLUESERIES-
MANUAL

GOATBLUESERIES/STEREOCHORUS
-BLUESERIES-
③SWEEPSPEED:LEDflashesto
indicatethesetspeed.Thecontroller
controlsthecharacteranddepthof
thechoruseffect.
②HEADROOMLED:Usedtocheck
theinternalsignallevel.
AdjustthePREAMPLEVELsothat
theredcoloroftheLEDlightsup
onlymomentarilywhentheguitaris
playedhard.
Reference:HumbuckingPU"0".
:SinglePU"+6"or"0
①PREAMPLEVEL:Usedtosetthe
bestoperatingleveloftheinternal
circuitrytominimizedistortionand
noise.Changingthissettingdoes
notchangetheoutputsignallevel.
⑥ON/OFFLED:Lightsupwhenthe
effectisonandturnsoffwhenthe
effectisbypassed(effectoff).
④DEEPCHORUS:Infinitelyvariable
normaldelayfornormalchorusand
longdelayforadistinctdupla
effect.
⑤⑤DIRECTMIXER:
Determineshowthechorus
settingismixedinstereoor
mono.Byswitchingthese
switches,thedepthofthe
choruseffectcanbeadjusted
inthreelevels.
ControllerDescription

-BLUESERIES-
Operation
IfyouwanttousetheSTEREOCHORUSrightaway,followthe
instructionsinthischapter.However,westronglyrecommend
thatyoureadtherestofthemanualimmediatelytofully
understandandusethecapabilitiesofthissophisticated
signalprocessor.
1.makesurethatthepowertotheamplifierorotherdevice
towhichyouareconnectingisturnedoffbeforeconnecting
theSTEREOCHORUS.
Note:UsetherecommendedACadapter.
Usealkalinebatteries,theoperatingtimeisapproximately2
hours.
ConnecttheOUTjacksoftheSTEREOCHORUStotwo
channelsofastereoamplifierormixer,ortotwoguitar
amplifierswiththeirrespectivecables.Ifyouneedamono
output,connectonlytheLEFTOUT(MONO)outputjackto
thesoundsystemwithasinglecable.3.
SetthePREAMPLEVELtozeroandsettheDEEPCHORUS
knobtotheOFFposition.Ifusingmono,settheDIRECT
MIXERmixertotheNORMALorEQUALposition.4.
ConnectaguitarorkeyboardoutputtotheINPUTjack.Ifyou
areusingaGENERATOR,connectitsoutputtotheSTEREO
CHORUSINPUT(MONO).5.
TheSTEREOCHORUShasanamplificationlevelof1,which
meansthattheinputsignallevelisthesameastheoutput
level,sosetthesoundsystemvolumetothesamelevelas
whentheSTEREOCHORUSisnotinuse.6.
6.turnontheSTEREOCHORUSbeforeturningonthe
amplifiersinordertoavoidnoisefromthespeakerswhenthe
poweristurnedon.
YouarenowreadytousetheSTEREOCHORUSinnormal
chorusmode.AdjustthePREAMPLEVELsothattheredLED
turnsonforamomentwhenyouplaytheguitarhard.
Reference:HumbuckingPU"0".
SinglePU"+6"or"0
GOATBLUESERIES/STEREOCHORUS

-BLUESERIES-
FunctionDescription
Preamp/Level(PREAMP/LEVEL)
ThePREAMPLEVELcontrollerisusedtoadjustthelevelof
theincomingaudiosignaltotheinternalgainoftheSTEREO
CHORUS.Settingittothebestpositionwillminimizeboth
distortionandnoise.Theoutputleveldoesnotchangeatany
position.
TheHEADROOMLEDindicatesthelevelofthesignalpassing
throughtheinternalcircuitry.TheredLEDindicatesthatthe
levelisapproachingthedistortionpointandshouldnotbelit
toooften.IftheredLEDlightsfrequently,turndownthe
PREAMPLEVELcontrolleronestep.TheyellowLEDindicates
thebestsignallevelwiththeleastnoise.IftheyellowLED
doesnotlightupatall,turnupthePREAMPLEVELcontroller
onestep.
Fornormalline-levelsignals,0isgenerallythebestposition.If
youareconnectingaguitardirectly,setittothe+6position.
Ifyouareconnectingagenerator,setthePREAMPLEVEL
controllerto-6.Ineithercase,watchtheLEDsandtogglethe
switchestofindthebestoperatingpoint.
Note:Ifdistortionisfeltevenatthe-6position,turndownthe
level(output)oftheeffectsystemusedinthepreviousstage.
CHORUS
Thecenterdelaytimecanbeinfinitelyvariedfrom20ms
(normal)to40ms(long)withtheDEEPCHORUS.Thesweep
oscillatorvariesthisdelayintwoways,from20to24
millisecondsorfrom40to44milliseconds.Thenormal
chorusdelaytimeisjustlongenoughtocreateatruestereo
image,butthelongerchorusdelaycreatesastrongereffect,
givingtheimpressionthatthetwosourcesareindependent.
TheSWEEPSPEEDcontrollercontrolsalow-frequency
oscillator(LFO)forvaryingthetimedelay.Thefrequencyof
thissweeposcillatorcanbesetfrom1Hzto0.25Hz(from
onecyclepersecondtoonecycleeveryfourseconds),and
thespeedisindicatedbyablinkingSWEEPSPEEDLED.The
slowerthespeed,thesmallerthephasingeffect,butthe
fasterthespeed,thestrongerthevibrato-likerhythmiceffect
andthelargerthepitchchange.Thenatureofthechorus
effectisalsogreatlyaffectedbytheoutputswitchsetting.
(PleaserefertotheDIRECTMIXERdescription.)
*MaximizingDEEPCHORUSincreasesthespeedto50%.
GOATBLUESERIES/STEREOCHORUS

-BLUESERIES-
Output(DIRECTMIXER)
UsetheMIXERswitchtopresettheratioofdirecttoeffect
mix.
HowdoIgetaprocesssignalonly?
SettheMIXERswitchtoWIDE(STEREO)anduseonlythe
RIGHTOUT.Ifyouwanttousethissignal,youwillneedan
externalmixerorotherequipment.
Note:TheMIXERcircuitisdesignedsothattheapparent
volumeisthesameatallswitchpositions;intheWIDE
(STEREO)position,theinputandoutputsignallevelsarethe
same(gain1),butwhensettomono,theoutputmayhave
peaksthatarehigherthantheinputsignal.Ifthesignalclips
whileinthemonopositionandthered"CLIP"HEADROOM
LEDlightsup,setthePREAMPLEVELcontrollerloweror
reducetheinputsignallevelifnecessary.
Notethatevenwhentheeffectisoff,theaudiosignalwillstill
passthroughthelow-noisebuffercircuitandmustbe
energizedortherewillbenosound.
Theapparentvolumedoesnotchangewhenswitchingfrom
chorustobypass.The3dBapparentvolumeincreasethat
normallyoccurswhenthechorussignalisreplacedwitha
directsignalinthemixisautomaticallycompensatedfor.
ExplanationofStereoOperation
◀◀WIDE▶▶  
LEFTOUTDirectsignal(100%) 
RIGHTOUTEffectssignal(100%)
◀NORMAL▶ 
LEFTOUTDirectsignalplus-10dbeffectsignal 
RIGHTOUTDirectsignalwith-10dbtoeffectsignal
■EQUAL■
LEFTOUT50%mixofdirectandeffectsignals 
RIGHTOUT50%mixofdirectandeffectsignals
Howtoapply
Forthebestchoruseffectonclean(undistorted)guitaror
pianoparts,usetheSWEEPSPEEDsettingatthe12o'clock
position(1/2Hz).Fordistortedguitarsounds,increasethe
sweepspeedtodeepentheeffectevenmore.Youcanalso
useDEEPCHORUStoextendthespatialpresence.
FunctionDescription
GOATBLUESERIES/STEREOCHORUS

-BLUESERIES-
PrincipleofOperation
Thepurposeofachorusistomakeasingleinstrumentsound
liketwoormoreinstrumentswithwell-definedpitchand
timing.Justasastringsectioncanbemadetosoundricher
andmorebeautifulthanasingleviolinwithitsfinelytuned
pitchandtiming,aguitarorkeyboardcanbemadetosound
morelifelikebyapplyingachorus.
Thechorusworksbysplittingtheinstrument'ssoundintotwo
differentsignals.TheSWEEPoscillatoraffectstheamountof
timedelay,whichdeterminesthedepthofthechorus.The
shorterthedelay,thehigherthepitchofthesignal;thelonger
thedelay,thelowerthepitch.AndthefastertheSWEEP
oscillatorbehaves,thefasterthedelaylengthensorshortens,
andthegreaterthepitchshift.
FunctionDescription
GOATBLUESERIES/STEREOCHORUS

-BLUESERIES-
SafetyPrecautions
GOATBLUESERIES/GENERATOR
Pleasebesuretoreadthisbeforeusingtheproduct.
Theprecautionslistedhereareintendedtoensuresafeandproperuseoftheproduct
andtopreventharmordamagetoyouorothers.Theyareimportantforyoursafety
andthesafetyofothersandforthemaintenanceoftheequipment,sopleaseread
themcarefullyandobservethem.
Observethefollowinginstructions
Donotdisassembleormodifythisequipment.
Neverattempttorepairorreplacepartsthatarenotspecifiedintheinstruction
manual.Alwaysconsultwithyourdealerorlauncher.
AlwaysplugtheACadapterintoa100VACpoweroutlet.
IfthereisdustontheplugoftheACadapter,wipeoffthedust.
Failuretodosomayresultinelectricshockorshortcircuit.
InstalltheproductnearanoutletsothatyoucaneasilyreachtheACadapterplug.
Ifanyofthefollowingoccurs,immediatelyturnoffthepowerandunplugthe
ACadapterfromthepoweroutlet:
○WhentheACadapterisdamaged○Whenaforeignobjectenterstheproduct
○Whentheproductmalfunctionsorbreaksdown*Whenrepairisrequired,contact
thedealer.
Neverdoanythingotherthanwhatisdescribedintheinstructionmanualforrepairor
replacementofparts.
DonotforciblybendtheACadaptercordorplaceitnearequipmentthatgenerates
heat.DonotplaceheavyobjectsontheACadaptercord.
Doingsomaydamagethecord,resultinginelectricshockorfire.
Donotusetheproductathighoruncomfortablevolumelevelsforlongperiodsof
time.
Prolongeduseathighvolumemaycausehearingloss.Ifyouexperiencehearingloss
ortinnitus,consultaphysician.
Donotputforeignobjects(flammableitems,coins,wires,etc.)inthisproduct.
Donotuseorstoretheproductinplaceswherethetemperatureisextremelyhigh
(e.g.,indirectsunlight,nearheatingequipment,ontopofheat-generatingequipment,
etc.).
Donotuseorstoretheproductinaplacewherethereisalotofvibration.
Donotuseorstoretheproductindustyplaces.
Donotuseorstoreinbathroomsorshowers.
Donotuseorstoretheproductinahumidplacesuchasoutdoorsintherainorina
placesubjecttowaterdripping.
Donotspillliquidsontheproduct.
Donotusethisproductwithwethands.
Keepbatteriesoutofthereachofchildren.
Ifabatteryisswallowed,consultaphysicianimmediately.
Caution:Disregardoftheseprecautionsmayresultinpersonalinjuryor
physicaldamage.
Donotusetheproductinaplacewherenormalventilationisnotobstructed.
Keeptheproductwellawayfromradios,televisions,electronicequipment,etc.
Iftheproductisusedincloseproximitytoaradio,television,orotherdevice,itmaybe
subjecttonoiseandmalfunction.Also,theproductmaymakenoisesonradios,TVs,
etc.
Whencleaningtheexterior,wipeitlightlywithasoft,drycloth.
WhenplugginginorunpluggingtheACadapterfromthepoweroutlet,besuretohold
theplug.
Whennotusingtheproductforalongtime,removethebatteriestopreventthem
fromleaking.
UnplugtheACadapterfromthepoweroutletwhennotusingitforalongtime.
DonotuseanACadapterotherthanthespecifiedone.
Donotwiretheproducttogetherwiththepowercordsofotherelectricalequipment.
Connecttoanoutletthatmatchestheratedpowerconsumptionoftheproduct.
Donotexposethebatterytoexcessiveheatsources(sunlight,fire,etc.).
Donotapplyexcessiveforcetoswitches,knobs,etc.
Donotapplyexcessiveforcetoswitches,knobs,etc.asthismaycausemalfunction.
Donotusebenzene,thinner,compound,orstrongflammablepolisherstocleanthe
exterior.
Donotplacetheproductonanunstablesurface.
Donotplacetheproductonanunstablesurface,asitmayfallandcauseinjuryor
damagetotheproduct.
Donotrideonorplaceheavyobjectsonthisproduct.
Doingsomaycausetheproducttofallorbedamaged,resultingininjuryordamage
totheproduct.
！
CAUTION
RISKOFELECTRICSHOCK
DONOTOPEN
CAUTION:Topreventelectricshock,donotremovethepanelorcover.
Donotattempttorepairorreplacetheproductbyyourselfasitis
verydangerous.
PleaseaskyourdealerorRancherCorporationforrepair.
Thissymbolisanalertsymbol.
Itindicatesthatgeneral
cautions,warnings,and
descriptionsofhazardsare
includedininstructionmanuals
andotherdocuments.
！
警告
Thissymbolwarnsthat
uninsulated"dangerous
voltage"existsinsidethe
equipmentandthatthereis
ariskofelectricshock.
！

-BLUESERIES-
INPUTImpedance・・・・・2MΩmin.
  Maximumlevel・・・・・2.8Vrms(+9dBv)
CHORUSFrequencyResponse・・・・・+1to-3dBat8KHz
 SweepSpeed(Normal)・・・・・.25to1Hz
  SweepSpeed(Long)・・・・・.12to.5Hz
  Pitchchange(Normal)・・・・・about1/4semitone
  S/NRatio・・・・・90dBorbetter
STEREOOUTPUTS 
MIXER3presets
  Impedance・・・・・100ohms

SizeW126,D126,H50(mm)
CURRENTCONSUMPTION
200mA(max.)
Powersupply(soldseparately)
ACadapter9VDCcenter-minus
*Thesespecificationsaresubjecttochangewithoutnotice.
Specifications
GOATBLUESERIES/STEREOCHORUS
