Goddess WFD 815 M8S User manual

ELECTRONIC WASHING MACHINE
GODDESS WFD 815 M8S
INSTRUCTION MANUAL
BEFORE USING THE WASHING MACHINE, YOU SHOULD
CERTAINLY READ THE INFORMATION IN USER’S MANUAL

ENG
ENG - 2
THE CONTENTS
SECTION 1: BEFORE USING ............................................................................. 3
Safety warnings .................................................................................................... 3
Recommendations ................................................................................................ 3
SECTION 2: INSTALLATION .............................................................................. 4
Removal of transportation screws ........................................................................ 4
Adjustment of feet ................................................................................................. 4
Electrical connection ............................................................................................. 5
Water supply connection ...................................................................................... 5
Water drain connection ......................................................................................... 6
SECTION 3: TECHNICAL SPECIFICATIONS ..................................................... 6
SECTION 4: CONTROL PANEL .......................................................................... 7
Start/Pause button ................................................................................................ 7
Function indicator lights ........................................................................................ 7
Function buttons ................................................................................................... 8
Temperature knob ................................................................................................. 8
Program knob ....................................................................................................... 8
SECTION 5: WASHING YOUR LAUNDRY ......................................................... 8
Before washing ..................................................................................................... 9
Running the machine ............................................................................................ 10
SECTION 6: MAINTENANCE AND CLEANING ................................................. 12
Water inlet lters ................................................................................................... 12
Pump lter ............................................................................................................ 14
Detergent drawer .................................................................................................. 15
Siphon plug ........................................................................................................... 15
The cabinet ........................................................................................................... 15
The drum .............................................................................................................. 16
Remove of your machine from lime ...................................................................... 16
SECTION 7: PRACTICAL INFORMATION ......................................................... 16
SECTION 8: AVOIDING MINOR FAULTS ........................................................... 18
SECTION 9: AUTOMATIC FAILURE DETECTION SYSTEM ............................. 19
SECTION 10: INTERNATIONAL WASHING SIGNS ........................................... 20

ENG
ENG - 3
SECTION 1: BEFORE USING
SAFETY WARNINGS
• Do not use a multiple socket or extension cord.
• Do not insert a plug with damaged or broken cord into the socket.
• If the cord is damaged it should be replaced by the manufacturer or appointed service agent
in order to avoid a hazard.
• Never remove the plug from the socket by pulling from the cord section.
Remove the plug by holding.
• Do not plug the power supply with wet hands.
• Never touch the machine with wet hands or feet.
• Never open the detergent drawer while the device is running.
• Never force to open the door of the machine while the machine is running.
• Since the machine can reach high temperatures while running, do not touch the drain hose
and water during draining.
• In case of any failure, first unplug the device and close the water tap.
Do not attempt to repair. Please apply to the nearest authorized service station.
• Do not forget that the packing material of your machine may be hazardous for children.
• Do not let your children play with the washing machine.
• Keep your pet away from your machine.
• Your machine should only be used by adults within the information written in this manual.
• Your machine is designed for use in house environment.
Warranty will be invalid if you use it for commercial purposes.
• The appliance should not be put on a carpet which can block the air ventilation on the bottom
side.
RECOMMENDATIONS
• The detergent or softener in contact with air for a long time will dry and stick to your detergent
drawer.To avoid this put your detergent and softener into the detergent drawer just before
washing.
• It is recommended that you use pre-washing program for only very dirty clothes.
• Please do not exceed the maximum loading capacity.
• The appliance is not intended for use by people (including children) with reduced physical,
sensor yor mental capabilities , or lack of experience and knowledge , unless they have been
given supervision or instruction concerning use of the appliance by a preson responsible for
their safety.Children should be supervised to ensure that they don’t play with the appliance.
• If you will not use your machine for a long time, unplug your machine, close the water supply
and leave the door open in order to keep the inside of the machine dry and for prevention
from unpleasant odour.
• As a result of the quality control procedures, a certain amount of water may remain in your
machine. This is not harmful for your machine.

ENG
ENG - 4
SECTION 2: INSTALLATION
You must pay attention to the following issues before using your washing machine.
REMOVAL OF TRANSPORTATION SCREWS
• Transportation screws, which are located at the back side of the machine,
must be removed before running the machine.
• Loosen the screws by rotating counterclockwise by a suitable wrench. (DIAGRAM-1)
• Remove the screws by pulling them. (DIAGRAM-2)
• To the holes where the transport screws have been removed, insert the plastic transport
screw taps found in the accessories bag. (DIAGRAM-3)
• The transportation screws, that have been removed from the machine should be kept in hand
for any other transportation necessities.
ADJUSTMENT OF FEET
• Do not install your machine on rugs or similar surfaces.
• For your machine to work silently and without any vibration, it should be settled on a at,
non-slippery and tough ground.
• You can adjust the balance of your machine from its feet.
• First, loosen the plastic adjustment nut.
• Adjust by rotating the feet upwards or downwards.
• After the balance has been reached, tighten the plastic adjustment nut again by rotating it
upwards.
• Never put cartons, wooden blocks or similar materials under the machine to balance
the irregularities on the level of the ground.

ENG
ENG - 5
ELECTRICAL CONNECTION
• Your washing machine works with 220-240V and 50Hz.
• A special grounded plug has been attached to the network cable of your washing machine.
This plug must denitely be inserted to a grounded socket with 10 ampere.
The fuse ow value of the electricity line attached to this should also be 10 ampere.
If you have no such sockets and fuses in your house, let it be made by a qualied electrician.
• Our company will not be responsible for any damages that may occur as a result
of usage without grounding.
• Insert the machine’s plug to a grounded socket which you can easly reach.
WATER SUPPLY CONNECTION
• Your machine has a single water (cold) inlet.
• To prevent from the leakages on the connection joints, 1 seal is included in the hose
packing.(Fit this seal on the end of the water inlet hose at the tap side.)
• Connect the end with bracket of the water inlet hose to the water inlet valve at the rear
of the machine and the other end to your tap. In situations where you are not assured,
let a qualied plumber make the connection works.
• Water pressure of 0,1-1 MPa from your tap will enable your machine to work more
efciently.(0,1 MPa pressure means water ow of more than 8 liters in 1 minute from
a fully opened tap)
• After connections are completed, check for the non-leakage of the connection joints
by turning on your tap completely.
• Be sure that water inlet hoses are not folded, broken or crushed.
• Mount the water inlet hoses to a 3”/4, geared water tap.

ENG
ENG - 6
WATER DRAIN CONNECTION
• Be sure that water inlet hoses are not folded, twisted, crushed or elongated by stretching.
• Water drain hose should be mounted at a height of minimum 60 cm, maximum 100 cm
from the ground.
• The end of the water drain hose may directly be tted to the dirty water outlet hole or a special
apparatus mounted on the outlet bracket of the wash-stand.
• Never attempt to extend the water drain hose by adding extra parts.
SECTION 3: TECHNICAL SPECIFICATIONS
Brand Goddess
Model WFD815M8S
Energy class A+
Voltage/Frekvency (V/Hz) (220-240) V / 50Hz
Electrical current (A) 10
Water presure (Mpa) Max. 1 Mpa/ Min. 0,1 Mpa
Power rating (W) 2100
Maximum dry laundry capacity (kg) 5
Recommended loading (kg) 4,5
Height (cm) 85
Width (cm) 59,6
Depth (cm) 41
Maximum spin cycle ( rpm ) 800

ENG
ENG - 7
SECTION 4: CONTROL PANEL
WFD815M8S (3 buttons, program knob)
1) Detergent drawer
2) Start/pause light
3) Function indicator lights
4) Program ready light
5) Program knob
6) Start/pause button
7) Function buttons
8) Program end light
START/PAUSE BUTTON
Used to start a selected program or pause during running.
WARNING!
It is required for the program knob to be brought to O (off) position before selecting
the program or changing a continuing program.
FUNCTION INDICATOR LIGHTS
When the start/pause button or any function button is pressed, the corresponding light
turns on.The light turns off when the function button or start/pause button is re-pressed,
or when the process the selected function is completed.
The function indicator lights are also used in failure detection system mentioned in section 9.

ENG
ENG - 8
FUNCTION BUTTONS
(depends on selected model – see the control panel of your washing machine)
Rinse hold
This function is recommended to be used when the clothes cannot be taken immediately
after the end of the program.This will prevent occurrence of wrinkles. When this button is
pressed, the last rinsing water is not drained. For the program to continue from the same
point, repress the same button.
Extra rinse
You can have one more rinsing done in addition to the rinses which your machine has
made in all washing programs by using this function.
Easy ironing
By using this function, you can ensure your clothes to come out less wrinkled after
the washing.
WARNING!
Functions vary depending on the model you have chosen. If you forgot to use additional
function and your machine starts to wash push the additional function button
if the indicator light is on. Additional function will be activated.If the indicator light is not
on, additional function will not be activated.
PROGRAM KNOB
With the program knob, you can select the program with which you desire to wash your clothes.
You can adjust the program selection process by turning the program knob in both directions.
You must be careful that the adjustment sign of the program knob is exactly on the program
you want to select. When you bring the program knob to O (off) position, while your machine
is running, your program will remain incomplete.
SECTION 5: WASHING YOUR LAUNDRY
• Plug the machine.
• Open the tap water.
First wash cycle
There may be water left inside your machine after factory tests and trials.It is recommended that
the rst wash cycle should be made without any laundry so that carry out this water; pour half
a measuring cup of normal allpurpose detergent into compartment 2 and select cotton program
at 90°C.

ENG
ENG - 9
BEFORE WASHING
Discrimination of your laundry
• Discriminate your clothes according to their types (cotton, synthetic, sensitive, woolen, etc.),
washing temperatures and level of dirtiness.
• Never wash your white and coloured clothes together.
• Since your new coloured clothes may shed dye on the rst wash, wash them separately.
• Be careful that no metal pieces are found on or in the pockets of your clothes, remove if there
is any.
• Zip and button your clothes.
• Remove the plastic or metal hooks of the curtains and laces or place them inside a washing
bag and tie.
Pull the textiles like trousers,knitted fabric,t-shirt and sweat shirt inside out.
Wash your small clothes like socks and handkerchiefs in a washing bag.
Wash up to 90˚C Wash up to 60˚C Wash up to 30˚C Not washable
in washing machine
Placement of the clothes into the machine
• Open the door of your machine.
• Fill your clothes in your machine in a well-spread manner.
• Place each cloth separately.
• When you shut the door of your machine, be careful that no cloth is jammed between
the cover and the gasket.
• Shut the door of your machine tightly otherwise your machine will not start the washing
process.

ENG
ENG - 10
Filling detergent in the machine
The quantity of the detergent that you will ll in your machine depends on the following criteria:
• Your detergent consumption will change according to the dirtiness level of your clothes.
For your slightly dirty clothes, do not pre-wash and put a small amount of detergent in the
compartment no.2 of the detergent drawer.
• For your excessively dirty clothes, select a program with pre-washing, ll Ľ portion
of the detergent you will put in compartment 1 in the detergent drawer and the remaining
portion in compartment 2.
• In your machine, use the detergents developed especially for automatic washing machines.
The quantities that will be used for your clothes are written on the packing of the detergents.
As the hardness of your water increases, the amount of the detergent to be consumed will
also increase.
• As the amount of your clothes increases, the amount of the detergent to be consumed will
also increase.
• Fill your softener in the softener compartment in your detergent drawer. Do not exceed
the MAX level. Otherwise, the softener will diffuse in the washing water via the siphon.
• The softeners with high density should be diluted with some water before lling in the drawer.
That is because the softener with high density obstructs the siphon and prevents the ow of
the softener.
• You can use uid detergents in all programs without pre-washing. For this, mount the uid
detergent level plate in the second compartment of the detergent drawer and arrange
the amount of uid detergent according to the levels on this plate.
RUNNING THE MACHINE
Program selection and features
Select the program and additional functions appropriate for your clothes from Table-1.
Start/Pause
By pressing this button, you can start the program you have selected or pause a running
program.
Starting the program
Adjust the program knob to a program you desire.
The program ready light will be on.
If you want, you can select one or more additional functions.
Run the program which you have selected by pressing the Start/Pause button.
Changing the program
If you have selected a program and you do not want if to continue:
Press the start/pause button.
Bring the program knob to O(off) status.
Adjust the program knob to the program you desire.
(You can select the program that you desire from Table-1).
The program ready light will be on.
By pressing the start/pause button, run the program which you have selected.
