Good Way USB3DP4KB User manual
USB 3.0 to 4K DP Adapter
User's Manual
i
Table of Contents
SAFETYINSTRUCTIONS..........................................1
COPYRIGHT........................................................1
TRADEMARKS......................................................1
REGULATORYCOMPLIANCE.............................2
FCCCONDITIONS................................................2
CE....................................................................2
WEEEINFORMATION...........................................2
INTRODUCTION...............................................3
FEATURES...........................................................3
PACKAGECONTENTS............................................4
SYSTEMREQUIREMENTS.......................................4
PRODUCTOVERVIEW......................................5
SPECIFICATION....................................................6
CONNECTION..................................................8
INSTALLATION.................................................9
VERIFYINGTHEINSTALLATION...............................11
DISPLAYCONFIGURATION..............................13
DESCRIPTIONOFTHESETTINGS.............................14
ii
MULTI‐MONITORCONFIGURATION........................16
EXTENDEDMODE...............................................17
MIRRORMODE.................................................18
SETTHEPRIMARYMONITOR.................................19
WINDOWSSHORTCUT........................................19
UNINSTALLINGTHEDRIVER............................20
TECHNICALSUPPORT.....................................22
1
Beforeattemptingtoconnect,operateoradjustthisproduct,
pleasesaveandreadtheUser'sManualcompletely.Thestyle
oftheproductshowninthisUser'sManualmaybedifferent
fromtheactualunitduetovariousmodels.
Safety Instructions
Alwaysreadthesafetyinstructionscarefully:
KeepthisUser’sManualforfuturereference
Keepthisequipmentawayfromhumidity
Ifanyofthefollowingsituationarises,getthe
equipmentcheckedbyaservicetechnician:
- Theequipmenthasbeenexposedtomoisture.
- Theequipmenthasbeendroppedanddamaged.
- Theequipmenthasobvioussignofbreakage.
- Theequipmenthasnotbeenworkingwellor
cannotgetittoworkaccordingtotheUser’s
Manual.
Copyright
Thisdocumentcontainsproprietaryinformation
protectedbycopyright.Allrightarereserved.Nopartof
thismanualmaybereproducedbyanymechanical,
electronicorothermeans,inanyform,withoutprior
writtenpermissionofthemanufacturer.
Trademarks
Alltrademarksandregisteredtrademarksarethe
propertyoftheirrespectiveownersorcompanies.
2
Regulatory Compliance
FCC Conditions
Thisequipmenthasbeentestedandfoundtocomply
withPart15ClassBoftheFCCRules.Operationis
subjecttothefollowingtwoconditions:(1)Thisdevice
maynotcauseharmfulinterference.(2)Thisdevice
mustacceptanyinterferencereceivedandinclude
interferencethatmaycauseundesiredoperation.
CE
Thisequipmentisincompliancewiththerequirements
ofthefollowingregulations:EN55022:CLASSB
WEEE Information
For EU (European Union) member users: According to the
WEEE (Waste electrical and electronic equipment)
Directive, do not dispose of this product as household
waste or commercial waste. Waste electrical and electronic
equipment should be appropriately collected and recycled
as required by practices established for your country. For
information on recycling of this product, please contact
your local authorities, your household waste disposal
service or the shop where you purchased the product.
3
Introduction
The USB 3.0 to 4K DisplayPort Adapter is a device
which enables connection to 4K Ultra HD display
device to a computer using USB 3.0 port. It will make
your legacy PC with old graphics card to support 4K
resolution easily. Besides, with this convenient design,
it can connect up to 6 display devices to a computer
without installing extra video cards. Once the driver has
been installed, the USB-attached monitor will be
enabled immediately without any rebooting process of
operating system after plugging the USB adapter.
System performance is an important issue when using
multiple monitors. Another benefit of this adapter is that
it occupies little computer resource; ensuring users get
quality display without comprising computer
performance.
Features
SupportsHighResolutionupto3840x2160Pixels
BackwardscompatiblewithHD/Legacymonitors
Accessto4KUltraHDdisplaysforlegacyPCs
Supportsupto6USBdisplaysimultaneously
ExtendandMirrormodesupport
USBbus‐powered
4
Package Contents
USB3.0to4KDPAdapterx1
USBCable x1
CD(DriverandUser’sManual)x1
QuickInstallationGuide x1
System Requirements
OperatingSystems:
Windows®
7/Windows®8/Windows®8.1
5
Product Overview
MicroUSBconnector:ConnecttoanavailableUSB
connectoronacomputer.
DisplayPortconnector:Connecttoadesired
DisplayPortdevice,including4KUltraHDdisplay
monitor.Toconnectdifferenttypesofmonitors,
youmayneedaconverter.
DisplayPort
Connector
MicroUSB
Connector
6
Specification
ConnectorHost
Interface
USB3.0
VideoOutputDisplayPortConnector
Host
Upstream
Link
USB3.0MicroBTypeConnector
ConnectivityUpto6adaptersonacomputer
PowerPowerModeBus‐powered
Power
Consumption
OperatingMode:370mAapprox.
Video Resolution640x480 720x400* 720x480
768x576 800x600 832x642
800x480 848x480 1024x600
1024x768 1152x864 1152x870
1280x720 1280x768 1280x800
1280x960 1280x1024 1360x768
1366x768 1368x768 1400x1050
1440x900 1600x900 1600x1200
1680x1050 1920x1080 1920x1200
2048x1080 2048x1152 2048x1280
2048x1536 2560x1440 2560x1600
3840x2160
Notethatinterlacedmodesand
reducedblankingmodesarenot
supported.
7
Supported
DisplayMode
ExtendedDesktop(Default),
MirroredDesktop,PrimaryDisplay
Supported
Operating
System
Windows®7,Windows®8,
Windows®8.1
Physical
Properties
HousingABS(Plastic)
ColorBlack
Dimension75.5(L)x44(W)x13.9(H)mm
Weight30.2g
Working
Environment
Operation
Temperature
10~40degree
Storage
Temperature
‐20~70degree
ComplianceCE,FCC
8
Connection
Makesurethedevice(Desktop,Laptop…)isDisplayPort
embeddedorbundledanyadapter/connectorwith
DisplayPort.
UsingMulti‐Adapter
(ExtendedMode)
*Abletoconnectupto
6displays
9
Installation
Note that the screenshots on this user's manual may
vary slightly from each operating system.
Windows®7/ Windows®8/ Windows®8.1
1. Insert the provided CD into your disc drive.
2. Click Run Setup.exe to start the installation.
Caution: DO NOT connect the adapter to a
computer before installing the provided driver.
10
NOTE:
If the AutoPlay does not appear automatically,
locate and double-click on the Setup.exe file in the
driver folder to launch the setup.
Enter the administrator password and then click Yes
to start the installation if a User Account Control
dialog box appears.
3. Click I Accept for the next step.
11
4. Be patient with the installation procedure.
5. Connect the adapter to a computer after the driver
installation is completed. For connection details,
refer to the chapter of Connection.
6. When the operating system detects the adapter, the
reminder message will appear on the system tray.
Verifying the installation
To verify the driver of the adapter, follow the step below.
1. Following the path to open the device manager.
Windows®7:
Control Panel\ System and Security\ Systems\
Device manager
12
Windows®8/ Windows®8.1:
Settings\ Control Panel\ System and Security\
System\ Device manager
2. You will find DisplayLink Adapter device listed as
below.
NOTE:
If you cannot find the driver in the list, the driver may
not be properly installed. Please delete the item,
unplug the adapter and repeat the installation steps.
USB3.0UHDDisplayPortAdapter
13
Display configuration
NOTE: The following screenshots in this section are
using Windows®7 operating system. It may not match
your operating system but the definitions of buttons, tabs
and menus are the same.
Utility settings
The supplied utility allows configuring the display mode,
screen rotation, screen resolution, and physical
arrangement of your monitors.
1. Click utility icon in Windows System Tray.
NOTE: If you cannot find the icon in Windows System
Tray, click arrow icon to bring up icon list to find it.
2. Select a preferred option, and then click it using
mouse.
14
Description of the settings
Options Description
Screen Resolution Click to select an available resolution.
Note that this function is invalid in
mirror mode, as the resolution is
defined as the resolution of the
primary monitor
Screen Rotation Rotate the screen according to the
desired orientation
Extend Extend the screen according to the
desired orientation
Extend to The cursor can extend to desired
screen via left/right/above/below way
moving
Set as Main
Monitor
Set this screen to the main screen
Mirror Duplicate the primary monitor to the
monitor which connects with the
adapter
Off Turn off the monitor
Optimize for video Optimize the video quality when
playing back. Text may appear less
clear when enabling
Fit to TV Adjust the size of Windows Desktop
on the TV
15
NOTE: This function works only when
one add-on monitor is connected.
Besides, this option will also only work
in extended mode. The add-on
monitor will change to the extended
mode if selecting this option while in
mirror mode.
Extend Submenu
Displaylink
manager
Enable the Windows screen resolution
page
Check for updates Check the latest driver and download
if available
Audio Setup Enable the Windows audio
configuration page. This function
works only in specific models.
Video Setup Enable the Windows screen resolution
page.
16
Multi-monitor configuration
An extra DisplayPort monitor can be connected through
the adapter directly. Once the extra monitor is connected,
it can be configured to use either “mirror mode”,
“extended mode” or be the primary display.
PositionthemouseanywhereontheWindowsDesktop,
Right‐clickandselectScreenResolution.
Alternatively,clicktheutilityicon intheWindows
SystemTray,andthenselectVideoSetup.
17
Extended mode
1. Refer to the Multi-monitor configuration section
to bring up the configuration window.
2. In the Display drop-down menu, select the
preferred monitor.
3. Select Multiple Displays > Extend these displays.
4. Click OK to confirm and exit.
5. Once the setting is completed, simply drag and
drop the application icons or the opened windows to
the add-on monitor. However, some applications
may not support to display on the extended desktop.
2
3
4
