Tripp Lite U444-06N-2H-MST User manual

1
Owner’s Manual
USB 3.1 Type-C™to Dual
HDMI 4K Adapter with MST
Model: U444-06N-2H-MST
USB Type-C and USB-C are trademarks of USB Implementers Forum
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate peace of mind.
You could also win an ISOBAR6ULTRA surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
All trademarks are the property of their owners.
Español 9 • Français 17 • Русский 25
18-12-226-933912.indb 1 1/25/2019 9:57:08 AM

2
Product Features
• Transmit data from a USB Type-C source
to two ultra high definition (UHD) HDMI
displays
• Supports USB DisplayPort Alternate Mode,
allowing you to transmit an audio/video
signal via the USB Type-C port on your
smartphone, tablet, Ultrabook or computer
• Supports HDMI 1.4 video resolutions up to
3840 x 2160 (4K x 2K) @ 30 Hz, as well as
HDCP 1.4 compatibility
• Supports 36-bit Deep Color (12 bits per
channel) max
• Thunderbolt 3™ port compatible
• SST and MST functions transmit the same
source content to two displays or different
content to each display
• Slim design is perfect for travel and stores
easily in your laptop bag when not in use
• Plug-and-Play—no software or drivers
required
18-12-226-933912.indb 2 1/25/2019 9:57:08 AM

3
Package Contents
System Requirements
Optional Accessories
• U444-06N-2H-MST
• Owner’s Manual
• USB Type-C or Thunderbolt 3 device that
supports USB DisplayPort Alternate Mode
• HDMI monitor(s)
• P568-Series High-Speed HDMI Cables
• P569-XXX-CERT Premium High-Speed HDMI
Cables with Gripping Connectors
18-12-226-933912.indb 3 1/25/2019 9:57:08 AM

4
Installation
1. Connect the USB Type-C connector on the
adapter to the USB Type-C port on your
smartphone, tablet, Ultrabook or computer.
2. Connect the HDMI ports on the adapter to a
monitor using HDMI cables (such as
Tripp Lite’s P568-Series HDMI cables).
3. The video images will appear on the add-on
monitors. Customize how video is displayed
on the add-on monitor using your device’s
display settings.
Note: Mac OS X does not support MST for NVIDIA and
Intel graphics processors, limiting video display on the
connected monitors to mirror mode.
18-12-226-933912.indb 4 1/25/2019 9:57:08 AM

5
Specifications
Connectors
Input USB-C (Male)
Output 2x HDMI (Female)
Video
Maximum Resolution 3840 x 2160 @ 30 Hz
Color Depth 36-bit Deep Color
(12 bits per channel)
Environmental
Operating Temperature 32° to 113°F
(0° to 45°C)
Storage Temperature 14° to 158°F
(-10° to 70°C)
Operating Humidity 10% to 85%,
Non-Condensing
Storage Humidity 5% to 90%,
Non-Condensing
18-12-226-933912.indb 5 1/25/2019 9:57:08 AM

6
Warranty and
Product Registration
3-Year Limited Warranty
TRIPP LITE warrants its products to be free from defects in
materials and workmanship for a period of three (3) years
from the date of initial purchase. TRIPP LITE’s obligation
under this warranty is limited to repairing or replacing (at its
sole option) any such defective products. To obtain service
under this warranty, you must obtain a Returned Material
Authorization (RMA) number from TRIPP LITE or an authorized
TRIPP LITE service center. Products must be returned to
TRIPP LITE or an authorized TRIPP LITE service center with
transportation charges prepaid and must be accompanied by
a brief description of the problem encountered and proof of
date and place of purchase. This warranty does not apply to
equipment, which has been damaged by accident, negligence
or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE.
Some states do not permit limitation or exclusion of implied
warranties; therefore, the aforesaid limitation(s) or exclusion(s)
may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF
THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any
costs, such as lost profits or revenue, loss of equipment, loss
of use of equipment, loss of software, loss of data, costs of
substitutes, claims by third parties, or otherwise.
18-12-226-933912.indb 6 1/25/2019 9:57:08 AM

7
Warranty and
Product Registration
Product Registration
Visit www.tripplite.com/warranty today to register your new
Tripp Lite product. You’ll be automatically entered into a
drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply.
See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
18-12-226-933912.indb 7 1/25/2019 9:57:08 AM

8
Warranty and
Product Registration
Any changes or modifications to this equipment not expressly
approved by Tripp Lite could void the user’s authority to operate
this equipment.
WEEE Compliance Information for Tripp Lite Customers
and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment
(WEEE) Directive and implementing regulations,
when customers buy new electrical and electronic
equipment from Tripp Lite they are entitled to:
• Send old equipment for recycling on a one-for-one,
like-for-like basis (this varies depending on the
country)
• Send the new equipment back for recycling when
this ultimately becomes waste
Use of this equipment in life support applications where failure
of this equipment can reasonably be expected to cause the
failure of the life support equipment or to significantly affect its
safety or effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice.
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
18-12-226-933912.indb 8 1/25/2019 9:57:08 AM

9
Manual del Propietario
Adaptador USB 3.1 Type-C™
a Dos HDMI 4K con MST
Modelo: U444-06N-2H-MST
USB Type-C y USB-C son marcas comerciales registradas del USB
Implementers Forum
1111 W. 35th Street, Chicago, IL 60609 EE UU
www.tripplite.com/support
Copyright © 2019 Tripp Lite. Todos los derechos reservados
Todas las marcas registradas son propiedad de sus respectivos dueños.
English 1 • Français 17 • Русский 25
18-12-226-933912.indb 9 1/25/2019 9:57:08 AM

10
Características del Producto
• Transmita datos desde una fuente USB
Type-C a dos pantallas HDMI de Ultra Alta
Definición [UHD]
• Soporta USB DisplayPort Modo Alterno,
permitiéndole transmitir una señal de audio
y video mediante el puerto USB Type-C
en su smartphone, tableta, Ultrabook o
computadora
• Soporta resoluciones de video HDMI 1.4
hasta 3840 x 2160 (4K x 2K) @30 Hz, así
como compatibilidad con HDCP 1.4
• Soporta Color Verdadero de 36 bits (12 bits
por canal) máximo
• Compatible con puertos Thunderbolt 3™
• Las funciones SST y MST transmiten el
mismo contenido fuente a dos pantallas o
contenido diferente a cada pantalla
• Su diseño esbelto es perfecto para viajar y
se almacena fácilmente en su maletín para
laptop cuando no está en uso
• Conectar y Usar—No requiere software ni
controladores
