GoPass NAV-436 User manual

1
NAV-436 Car Navigator
User’s Manual

2
Contents
1 Application Area ........................................................................................ 3
2 Features .................................................................................................... 3
3 Product Description................................................................................... 3
3.1 Product specification............................................................................... 3
3.2 Key Instruction...................................................................................... 5
3.3 Indicator LED Instruction ........................................................................ 5
4 GPS Accessories List.................................................................................. 6
5 Operation Instruction................................................................................ 6
5.1 Power On/Off ........................................................................................ 6
5.2 Touch-Screen Emendation....................................................................... 7
5.3 Music ................................................................................................... 8
5.4 Audio Out ........................................................................................... 10
5.5 Video ................................................................................................. 10
5.6 Picture View........................................................................................ 13
5.7 E-Book ............................................................................................... 15
5.8 GPS Monitor........................................................................................ 17
5.9 Language Setting................................................................................. 19
5.10 Backlight Setting................................................................................ 20
5.11 Volume Setting .................................................................................. 21
5.12 Power Supply Setting.......................................................................... 22
5.13 Time Setting...................................................................................... 23
5.14 System Information............................................................................ 24
5.15 Style Setting ..................................................................................... 25
5.16 Navigation Software Operation............................................................. 26
5.17 Bluetooth Hand Free Operation (Optional).............................................. 28
5.18 Video Input Setting (Optional) ............................................................. 31
5.19 Review Lens Function Instruction (Optional)........................................... 31
5.20 USB Synchronization Software Installation............................................. 32
6 Notice...................................................................................................... 38
7 Q&A......................................................................................................... 38

3
1 Application Area
All 4.3 inch GPS products of our company
2 Features
4.3” (16:9) WQVGA, 480x272 pixels, 262K color TFT LCD with touch screen
Built-in 2W 2 channel stereo speaker
GPS module: Mstar/SiRF III high sensitivity receiver(use actual configuration as accurate
one)
User friendly touch screen operation and press-key
Built in GPS antenna
SD Quickly run Navigation software from SD card
Audio : mp3,wav, midi files, etc
Video : asf,avi,mp4,wmv
Picture: BMP,JPG,PNG,GIF;
Built in li-on battery, use DC power or car adapter for charge
Two LED color direction:
orange LED is for battery charge，when GPS is charging, the orange LED is lighting after the
power is full, the orange LED will be off, and the green LED will be light.
Built in Bluetooth, support Hands-free(Optional)
Video in: Composite CVBS, PAL and NTSC
The unit will auto-change to rearview lens and display the condition of back view while
reverse car (Optional)
3 Product Description
3.1 Product specification
Circumstance Parameter
Working Temperature
Range -10°C to +60°C
Storage Temperature
Range -20°C to +70°C
Working Humidity Range 45% to 80%RH
Storage Humidity Range 30% to 90%RH
System Parameter
Main Frequency 300MHz/400MHz (use actual configuration as accurate one)
CPU SAMSUNG S3C2440A-30/ S3C2440A-40
(use actual configuration as accurate one)
Memory 64MB
Capacity 64MB
Navigation Software
Storage SD card
Operation System WINDOWS CE 4.2 NET

4
Basic Parameter
Video In CVBS
Video in Pressure 1.2 V(Vpp)
LCD size 4.3 inch
LCD Pixels 480*272
Audio Power
Consumption Earphone two track 0.25W/CHANEL, single track 8Ohm/2W
Average Power
Consumption 1.5W
Standby Power
Consumption <20mW
Battery 800mAh Li-Polymer battery
Battery Time Continue working for 3hrs or standby 200hrs
GPS hardware Parameter
GPS module MSTAR MSB2112/SIRF III
(use actual configuration as accurate one)
Frequency 1.575GHZ
C/A CODE 1.023 MHZ chip rate
Channels MSTAR：12Channels/SIRF：20Channels
Tracking Sensitivity -161dBm
Orientation Precision 10m, 2D RMS; 5m, 2D RMS, WAAS enable
Speed 0.1m/s
Data Update Rate 1HZ
Recapture Time Average 0.1s
Hot Boot Time < 3s
Warm Boot Time Average 38s
Cold boot Time < 100 s
Most Orientation Length 18,000m
Most Speed 515m/s
Acceleration < 4g
Built-in Antenna Pressure 3.3V±5%
External Antenna
Electricity 15mA

5
3.2 Key Instruction
Mark Instruction Mark Instruction
A Power Key B MENU Key
C SD card slot D Lock switch
E DC jack F Volume key
G Stero headphone jack H AV jack
I Mini USB jack J Bray exit
K Reset jack L Stylus
M Battery cover
Press “MENU” key when you use navigation, music, video, the GPS will return to program
interface
Long press “MENU” key, the GPS will enter into touch screen revision
Long press “POWER” for 3 seconds to turn on or off the GPS, short press “POWER” key to
enter into or wake up “SLEEP”;
Press “RESET” to rest the system;
Press lock key to lock the GPS
3.3 Indicator LED Instruction
Orange LED is for battery charge，when GPS is charging, the orange LED is lighting，
After the power is full, the orange LED will be off, and the green LED will be light.

6
4 GPS Accessories List
GPS 1pcs
Stylus 1pcs
Car Adapter 1pcs
Car Bracket 1set
User Manual 1pcs
Warranty card 1pcs
USB cable 1pcs (optional)
Earphone 1pcs(Optional)
AC Adapter (optional)
AV cable (optional)
5 Operation Instruction
5.1 Power On/Off
Press “POWER” more than 3 seconds，working LED light, meanwhile you can see the
following picture,
Short press “POWER” when the unit is running，system will be sleeping, then press “POWER” ,
system could be get right in 1 second. Press “POWER” more than 3 seconds when the unit is
running, system will be power off, as the following picture,

7
5.2 Touch-Screen Emendation
Plug the Car Adapter / AC Adapter into the unit DC jack, system will enter into Program
interface in 6 seconds, as the following picture,
Press “ ” icon, enter into Setting interface, as the following picture,
In setting menu, press“ ” icon, enter into touch-screen setting, as the following picture,
Long press the cursor position according to the menu hint, emendation cursor will move to top
left corner, then press the cursor again, the cursor will move to nether left corner, nether right
corner and top right corner, just following the cursor to emendation; If emendation is success,
you will see “OK” in the screen, press the screen to save the emendation, then you can exit.

8
5.3 Music
In the program interface，press“ ’’, enter into music playback interface, as following
picture,
press “ ”, choose music file storage path, you can see the following information,
Choose your favorite music file, and press“ ” or double click the file you chose, return to
music playing interface, as the following picture,

9
Press “ ”, you can choose all files you need, as the following picture,
Press“ ” and return to music playback interface,
Press“ ”, you can append more music file, press“ ” and return to music playback
interface。
Press “ ” and play the music, or double click the file name to play.
Press “ ” to pause the music playing;
Press “ ” to play the next music file; Press “ ” to play the last music file;
Press “ ” to play circular; Press“ ” to play stochastic;
Press“ ”, the volume will be off;
Press“ ” to delete the file you chose; Press“ ” to delete all files;
Press “ ” to return to program interface;
Press “ ” to adjust the volume; Press ” to adjust rate of progress.

10
5.4 Audio Out
Plug earphone into earphone jack when you play music, then you can enjoy the music by
earphone, meanwhile, the loudhailer will be quiet.
5.5 Video
In the program interface, as following picture,
press“ ”，you can see video play back interface as following,
Press “ ”, choose video file storage path, enter into the following interface,

11
After choose the video file you need, press“ ” or double click file name, then return to video
playback interface, as following picture,
Or press“ ” to choose all files, as following picture,
Press” ” and return to video playback interface,
Press“ ” and append more video file, press“ ”, return to video playback interface

12
Press “ ” to play video; or you can double click video file name to play.
Press” ”, you can see the full screen, as following picture,
Press“ ”, volume will be quiet; Press “ ” volume will be normal;
Press“ ” to choose next video file; Press“ ” to choose last video file;
Press“ ” to delete file you chose; Press“ ” to delete all files
Press “ ” to exit;
Press “ ” to adjust volume;

13
5.6 Picture View
In the program interface, as the following picture,
Press “ ”, enter into picture browser interface, as following picture,
Press“ ”，choose picture file storage path and enter into the following interface,
After choose your favorite picture file, press“ ” or double click file name, then return to
“Image Viewer” interface,

14
Press“ ”, you can see the picture as full screen,
Press“ ” to browse the last picture;
Press “ ” to browse the next picture;
Press “ ” to browse the picture in slide mode;
Press “ ” to zoom out the picture;
Press “ ” to zoom in the picture;
Press “ ”, turn the picture to right 90℃;
Press “ ” to exit from “Image Viewer” interface

15
5.7 E-Book
Press “ ” enter into the E-book interface as following,
Press “ ”, choose storage path of E-book as the following,
Press . txt file or press “ ” as the following picture,

16
Press “ ”and “ ”, you can turn the page up or down;
Press “ ” to set the page turning, as following picture,
Press figure keyboard and input page,
Press “ ” to return to browser interface and turn to page layout you need;
Press “ ” to delete the number you input;
Press“ ” delete all number you input；
Press “ ” to return to browser interface

17
5.8 GPS Monitor
In the program interface, as the following picture,
Press “ ”, enter into setting interface,
Press GPS monitor “ ”, enter into GPS monitor interface,
1. Press “ ” to restore GPS satellite test.

18
2. Press “ ” enter into satellite data stream interface,
3. Press “ ”，enter satellite amount and signal interface,
4. Press “ ”, enter into longitude, latitude and time interface,
After get related information you need, press “ ” and return to program interface
Notice: Please test GPS monitor in naked and clear place, or you could not receive good
satellite signal.

19
5.9 Language Setting
In the system setting interface, as following,
Press“ ”, enter into language setting interface,
After choose the interface language you need, press“ ” and return to system setting
interface

20
5.10 Backlight Setting
In the system setting interface, as following,
Press“ ”, enter into Brightness setting interface,
After adjust backlight brightness and automatic closing time, press “ ” and return to
system setting interface.
