Sune Technology Q-Roi User manual

Your best partner for better driving
SUNE TECHNOLOGY CO.,LTD
No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN
TEL:[phone] FAX:[phone]
Http://www.sune-tech.com
Shop http://www.carnavi-tech.com
SKYPE:sune_tech or hsin_han99
CarNavi-Tech

Warning
When installing the main unit, do not remove or alter existing
vehicle fasteners, including nuts, bolts, screw, clips, and fittings.
Never detach, move or alter existing vehicle wiring, including
electrical grounds and straps. Alteration of existing vehicle
components may make vehicle unsafe to operate. Should be
no any electronic devices or magnetic pole around installation
place.
Air bags are vital part of a safety system. Never install main unit
in a way which will alter air bag wiring or interfere with air bag
deployment. Air bags must function properly in the event of an
accident.
Before installing, check the location of pipe, tank, electrical
cables and others.
Read and follow the instruction manual.
Wiring location must not interfere driving, get in or out from car.
Use electrical tape to insulate the ends of all wires, even if they
are not used. Proper insulation prevents arcs, shocks and fires.
When installation is complete, test all vehicle electrical systems
to ensure they operate correctly, including lights, horn, brake
lights, and emergency flashers.
According to our sales policy, any problems caused by user’s
mistake, careless can not be guaranteed.
Caution
All steps of installation should be done by well-trained specialist.
During installation ignition key should be taken off and after all
installation finish connect power cable with interface for the last
step.
Do not install the main unit in places where it ma be exposed to
dew condensation (around the air conditioning hose, etc), or in
locations where it may come in contact with water, high levels of
moisture, dust or oily smoke
Install wiring in a manner in which cables will not come in contact
with metal parts. The wiring may be damaged by contact with
metal parts, resulting in fire and shocks. Avoid all contact with hot
surfaces when wiring the main unit. High temperatures may
damage wiring, causing shorts, arcing and fires.
Kindly check all parts are in the box, when receiving the product, if
anything missing, inform to the supplier or manufacturer.
Warning / Caution
CarNavi-Tech

Index
1. General spec
2. System Diagram
3. Components
4. Setting up Dip S/W
5. Installation diagram
6. Pin Specification of Connector Installation Diagram
7. Cautions before Installation
8. Installation
9. Quality Warranty
CarNavi-Tech

1. General Spec
OS
Android 4.2.2 (Jelly Bean)
CPU
Telechips TCC8930 (1GHz Cortex A9 DualCore)
Display
OEM LCD
Internal Memory
DDR3 1GB RAM + 8GB eMMC
External Memory
SDHC Slot Support (up to 64GB)
Function
A/V Input x 3,
Rear Cam Input x 1,
CAN(Controller Area Network) x 2,
Mic x 1,
External Speaker x 1 (mono),
External Audio Out x 1(Car Aux),
Output
LVDS ( thru Video Interface),
RGB (thru Sub-Board)
Touch Type
Resistive Touch
GPS
SiRF
Resolution
800*480 or 1024*480
USB
USB 2.0 x 5 (USB x 4, OTG USB x 1)
Input Voltage
12V
Temperature
operating 0 C to 60 C
Storage -20 C to 60 C
Languages
multi-languages
CarNavi-Tech

2. System Diagram
Application
Processor
DDR3
1GB
eMMC
Flash
Memory
8GB
Video
Decoder
Audio
Decoder
/Encoder
Image Scaler
LVDS
Transmitter
Microprocessor
With
2 CAN ports
CAN
Transceivr
CAN
Transceive
USB HUB
Audio Amp.
Touch
Screen
Controller
LCD Display
Rear Camera
DVD Player
Other Composite
Video Signal
Speakers
Touch
Screen
Button CAN
data
Steering wheel
CAN data
USB Devices
- USB memory
- Hard Disc
- Wifi dongle
- BlueTooth dongle
- 3G / LTE dongle
- Other USB
Accessories
Microphone
CarNavi-Tech

3. Components
MODE switch cable* 1ea
(HARETC0001)
USB cable * 2ea
(HARETC0027)
REAR CAMERA cable * 1ea
(HARETC0002)
Speaker * 1ea
(SPEAKE0001)
AV/BT Cable * 1ea
(HAVCAB0016)
GPS Antenna * 1ea
(GPSANT0006)
Multi cable * 1ea
(HARETC0068)
Power cable 16P * 1ea
(HPOWER0041)
Microphone cable * 1ea
(MICPHO0001)
TOUCH cable * 1ea
(HTOUCH0007)
LVDS cable* 1ea
(HALVDSC0020)
3G dongle * 1ea(Option)
(ETCETC0116)
WIFI dongle * 1ea(Option)
(ETCETC0110)
Sub-bard * 1ea
(QCPASS0000)
FFC cable* 1ea
(FFCABL0000)
Bolt* 4ea Bolt* 3ea
CarNavi-Tech

4. Setting up Dip Switch(I/F)
PIN
Function
Dip S/W Selection
1
No Use
2
No Use
3
No Use
4
No Use
5
No Use
6
No Use
7
No Use
8
Booting options
ON : Start with Q-ROI
OFF : Start with OEM
※Please make sure to disconnect the power cable of the interface and reconnect
the power cable again to apply the dip switch setting whenever changing DIP switch.
Otherwise, DIP switch setting will not be applied.
※ ON : DOWN / OFF : UP
CarNavi-Tech

5. Installation Diagram
SD Card
REAR CAM
POWER
cable
GPS
SPK
Speaker
REAR (12V OUT)
GND
TOGGLE
MIC
Provided LVDS cable
POWER cable
ACC
CAN1-
H
N.C
AUX-GND
A OUT(R)
CAN2-
H
GND
N.C
A OUT(L)
CAN1-L
CAN2-L
FRONT
SAFE
REAR
MMI
AUX-ON
Monitor It will be Plug
& Play
CarNavi-Tech

6. Pin Specification of Connector
Power LVDS-OUT AV MULTI USB USB MIC
15
16
1
2
15
16
14
11
10
9
8
7
6
5
4
3
2
1
AUDIO OUT(R)
AUDIO OUT(L)
AUDIO OUT GROUND
AUX-ON
CAN2-L
CAN1-L
REAR
MMI
CAN2-H
CAN1-H
SAFE
ACC
GROUND
FRONT
AUDIO OUT(R)
AUDIO R Output
AUDIO OUT(L)
AUDIO L Output
AUDIO OUT
GROUND
AUDIO Output GROUND
AUX-ON
Not available
MMI
Not available
CAN2-L
Connect with
Car CAN2-Low
CAN2-H
Connect with
CAN2-High
CAN1-L
Connect with
Car CAN1-Low
CAN1-H
Connect with
CAN1-High
REAR
Connect with Car Lame
cable
SAFE
Not available
FRONT
Not available
ACC
Connect Car ACC
GROUND
Connect Car GROUND
<Power Cable>
<Multi Cable>
1
2
3132
AUDIO OUT (L)
AUDIO OUT (L)
VIDEO IN1
FRONT-C
VIDEO OUT1
AUDIO OUT (R)
AUDIO OUT (R)
FRONT-C
VIDEO OUT1
QSOL
VIDEO IN1
REAR-C
SPEAKER
QSOL
QSOL
REAR-C
VIDEO OUT2
QSOL
REAR
IR-AV2
VIDEO OUT2
SPEAKER
REAR
IR-AV1
TOGGLE
QSOL
QSOL
TOGGLE
GPS
GPS
GPS
GPS
AUDIO OUT(L)
AUDIO L Input
AUDIO OUT(R)
AUDIO R Inut
VIDEO IN1
VIDEO Input1
REAR-C
Connect Rear Camera
VIDEO
FRONT-C
Not available
VIDEO OUT2
VIDEO Output2
VIDEO OUT1
VIDEO Output1
SPEAKER
Connect with Speaker
QSOL
Not available
REAR
Connect Rear Camera
IR-AV2
Connect external
device IR Cable
IR-AV1
Connect external
device IR Cable
TOGGLE
Connect QDIS Button
Cable (For switching
mode)
GPS
Connect GPS Cable
32
31
29
26
22
30
28
25
21
17
27
24
20
16
12
23
19
15
11
8
18
14
10
7
5
13
9
6
4
3
2
1
<AV Cable>
BT
BT
BT
BT
BT
BT
BT
BT
AUDIO IN3(R)
VIDEO IN3
AUDIO IN3(L)
AUDIO IN2(L)
VIDEO IN2
BT
BT
AUDIO IN3(R)
AUDIO IN3(L)
VIDEO IN3
AUDIO IN2(R)
VIDEO IN2
BT
Not available
AUDIO IN3(R)
AUDIO R Input3
AUDIO IN3(L)
AUDIO L Input3
VIDEO IN3
VIDEO Input3
AUDIO IN2(R)
AUDIO R Input2
AUDIO IN2(L)
AUDIO L Input2
VIDEO IN2
VIDEO Input2
1
2
1920
CarNavi-Tech

7. Cautions before Installation
Ignition key should be taken off before starting installation, interface
power connection must be the last step in installation.
Power cable should be separated when connecting interface.
Should be no any electronic devices or magnetic pole around
installation place.
All steps of installation should be done by well-trained specialist.
Dismantling without manufacturer’s permission can not be
guaranteed, (No permission to break attached label on the board.)
Kindly check all parts are in the box, when receiving the product, if
anything missing, inform to the supplier or manufacturer.
Install GPS away from electromagnetic devices such as black boxes,
Hi-Pass and etc.
Advisable to Install GPS at the edge of dash board or a front window
or a rear window.
Install GPS antenna mounted on window or roof facing to Sky .
According to our sales policy, any problems caused by user’s
mistake, careless can not be guaranteed.
CarNavi-Tech

8. Installation
-8-
- Please dismantle a monitor and head unit as above.
CarNavi-Tech

-9-
- Disconnect a FFC cable connected between a command and a monitor.
8. Installation
CarNavi-Tech

-10-
- Take away the cover of the board
8. Installation
CarNavi-Tech

-11-
- Disconnect the OEM FFC from the connector.
8. Installation
- Disconnect the OEM FFC from the connector.
CarNavi-Tech

-12-
8. Installation
- Connect supplied FFC cable to connectors where OEM FFC were connected.
Supplied FFC cable
Supplied FFC cable
CarNavi-Tech

-12-
- Please screw 3 numbers of supports as above.
8. Installation
CarNavi-Tech

-12-
- Please connect FFC cables as above.
8. Installation
OEM Supplied FFC
CarNavi-Tech

-12-
①Please the original FFC cables(CN101/CN102)pass through the supplied board.
②Please connect the original FFC cable(CN102) to LCD out.
③Please connect OEM FFC to touch in and supplied cables to touch out.
FFC cables pass through pointed spaces
8. Installation
CarNavi-Tech

-12-
- Please connect FFC cables
8. Installation
Supplied FFC cable
OEM
OEM
CarNavi-Tech

-12-
- Please do not put the cover of the board
8. Installation
- Please screw bolts
※ Remove
the cover
