GoPro Hero 3 Silver edition User manual

USER MANUAL

2 3
To download this user manual in a different language, visit
gopro.com/support.
Pour télécharger ce manuel de l’utilisateur dans une autre langue,
rendez-vous sur gopro.com/support.
Wenn Sie dieses Benutzerhandbuch in einer anderen Sprache
herunterladen möchten, besuchen Sie gopro.com/support.
Per scaricare questo manuale utente in un’altra lingua, visita
gopro.com/support.
Para descargar este manual de usuario en otro idioma, visite
gopro.com/support.
Para baixar este manual do usuário em outro idioma, acesse
gopro.com/support.
このユーザーマニュアルの他言語版をダウンロードするに
は、 gopro.com/supportにアクセスしてください。
若要下載其他語言版本的使用說明書，請前往：
gopro.com/support。
如需下载本用户手册的其他语言版本，请访问
gopro.com/support。
twitter.com/GoPro
youtube.com/GoProfacebook.com/GoPro
instagram.com/GoPro
/ Join the GoPro Movement

4 5
/ Table of Contents
Camera Housing 61
Using the Mounts 66
Frequently Asked Questions 69
Customer Support 70
Trademarks 70
Regulatory Information 70
Optional Accessories 6
The Basics
8
Camera Status Screen 10
Camera Menus 11
Getting Started 12
Camera Modes 16
Camera Settings 23
Capture Settings 33
Set Up 37
Connecting to the GoPro App 46
Storage and microSD Cards 48
System Requirements 49
Transferring Files to a Computer 51
Playback 52
Battery 54
Important Messages 60
/ Table of Contents

6 7
Suction Cup Head Strap + QuickClip
Surfboard Mounts Tripod Mounts
Wrist Mount Fetch (Dog Harness)
See more at gopro.com.
Floaty Backdoor
/ Wear It. Mount It. Love It.™
Battery BacPac™The Frame
LCD Touch BacPac™Chesty (Chest Harness)
Smart Remote Jaws: Flex Clamp
3-Way Side Mount
/ Optional Accessories

8 9
9. HERO Port
10. Battery Door
11. Wireless On/Off Button [ ]
12. Audio Alert
13. Microphone
/ The Basics
1. Camera Status Lights (red)
2. Shutter/Select Button [ ]
3. Camera Status Screen
4. Wireless Status Light (blue)
5. Power/Mode Button [ ]
6. Micro HDMI Port
(cable not included)
7. microSD Card Slot
(microSD card not included)
8. Mini-USB port
(supports composite A/C
cable/3.5mm stereo mic
adapter, not included)
/ The Basics

10 11
The camera status screen displays the following information about
HERO3+ Silver modes and settings:
1. Camera Modes/FOV
(field of view)
2. Capture Setting Modes
(not shown)
3. Resolution/fps
(frames per second)
4. Time Interval Settings
(not shown)
5. Counter
6. Time/Storage/Files
7. Battery Life
Note: The icons that appear on the camera status screen vary by mode.
MODES
CAMERA SETTINGS
CAPTURE SETTINGS WIRELESS
SET UP
/ Camera Menus
*Playback appears only if the camera is connected to a TV or LCD Touch BacPac (optional accessory,
sold separately).
/ Camera Status Screen

12 13
4. Be sure the camera is powered off.
5. Charge the battery by connecting the camera to a computer
using the included USB cable. The red status light turns on during
charging and turns off when the battery is fully charged.
The included lithium-ion battery comes partially charged. No damage
occurs to the camera or battery if used prior to a full charge.
For more battery information, see Battery.
WARNING: Use caution when using your GoPro as part of your
active lifestyle. Always be aware of your surroundings to avoid
injury to yourself and others. Abide by all local laws when using
this camera.
/ Getting Started/ Getting Started
CHARGING THE BATTERY
1. Remove the camera from its housing.
2. Remove the camera side door and insert a microSD, microSDHC™
or microSDXC™card into the card slot. A microSD card with a Class
10 or UHS-1 rating is required.
3. Open the camera backdoor, insert the battery and close the
camera back door.
Slim housing surfboard mount installation
Slim housing remove camera Slim housing insert camera
Slim housing closed Swapping housing doors
Quick Release Buckle + Thumb Screw + Slim housing = Complete Unit

14 15
POWERING ON + OFF
To Power On:
Press the Power/Mode button [ ]. The red camera status lights flash
three times and the sound indicator emits three beeps. Once the camera
status screen displays information, your camera is on.
To Power Off:
Press and hold the Power/Mode button [ ] for two seconds. The red
camera status lights flash several times and the sound indicator emits
seven beeps.
PRO TIP: Want to turn your HERO3+ into a one-button camera that
automatically starts recording video or Time Lapse photos when it
turns on? See One Button for more information.
/ Getting Started
CAMERA SOFTWARE UPDATES
To get the latest features and best performance from your HERO3+ Silver
camera, make sure you’re using the most current camera soware.
You can update your camera soware via the GoPro App, GoPro
soware or at gopro.com/getstarted.
CAMERA DEFAULT SETTINGS
The HERO3+ Silver powers up with the following default settings:
Video 960p60 fps
Photo 10MP (megapixels)
Burst Photo 10 photos in 1 second
Time Lapse 0.5 seconds
Wireless Off
To change your Video or Photo settings, see Camera Settings.
/ Getting Started

16 17
/ Camera Modes
VIDEO
To record video, verify that the camera is in Video mode. If the Video
icon [ ] does not appear on your camera status screen, press the
Power/Mode button [ ] repeatedly until it appears.
To Start Recording:
Press the Shutter/Select button [ ]. The camera beeps once and
the red camera status lights flash while recording.
To Stop Recording:
Press the Shutter/Select button [ ]. The red camera status lights
flash three times and the camera emits three beeps.
If the memory card is full or the battery is out of power, your camera
automatically stops recording. Your video is saved before the camera
powers off.
See Video Resolutions/FPS/FOV Modes in Camera Settings for
resolution settings.
PRO TIP: Want to see your videos and photos on the big screen?
Connect your HERO3+ Silver directly to your TV/HDTV. See Playback
for more information.
/ Camera Modes
OVERVIEW
The HERO3+ Silver features several camera modes. To cycle through
the modes, press the
Power/Mode button [ ] repeatedly .
The modes appear in the following order:
Video Record video
Photo Capture a single photo
Burst Capture up to 10 photos in one second
Time Lapse Capture a series of photos at timed
intervals
Settings Adjust camera settings
Playback
Play back video and photos. Appears
only if camera is connected to a TV or
LCD Touch BacPac (optional accessory,
sold separately).
PRO TIP: Use Burst to capture fast-moving subjects.

18 19
BURST
In Burst mode your camera takes multiple photos in short time
intervals3 photos/1 second, 5 photos/1 second and 10 photos/
1 second.
To capture a Burst photo series, verify that the camera is in Burst
mode. If the Burst icon [ ] does not appear on your camera status
screen, press the
Power/Mode button [ ] repeatedly until it appears.
To Capture Burst Photos:
Press the Shutter/Select button [ ]. The red camera status lights
flash and the camera beeps multiple times.
The camera status screen displays BUSY while the camera processes
these files. Once BUSY disappears, the camera is ready for the next action.
See Options in Camera Settings for interval settings.
/ Camera Modes
To capture a photo, verify that the camera is in Photo mode. If the
Photo icon [ ] does not appear on your camera status screen,
press the
Power/Mode button [ ] repeatedly until it appears.
To Capture a Photo:
Press the Shutter/Select button [ ]. The camera beeps two
times, the red camera status lights flash and the counter on the
camera status screen increases by one.
See Photo Resolution Modes in Camera Settings for photo
resolution settings.
/ Camera Modes

20 21
/ Camera Modes
SETTINGS
The Settings menu allows you to adjust these camera settings:
Video Resolution
Photo Resolution
Time Lapse Interval
Burst Photo Rate
See Camera Settings to make changes, learn how to navigate menu
options and read more details on each setting.
TIME LAPSE
Time Lapse mode captures a series of photos at intervals of 0.5, 1, 2,
5, 10, 30 or 60 seconds.
To capture a Time Lapse series, verify that the camera is in Time
Lapse mode. If the Time Lapse icon [ ] does not appear on your
camera status screen, press the
Power/Mode button [ ] repeatedly
until it appears.
To Capture Time Lapse Photos:
Press the Shutter/Select button [ ]. The camera initiates countdown
and the red camera status lights flash each time a photo is taken.
To Stop Time Lapse Photos:
Press the Shutter/Select button [ ]. The red camera status lights
flash three times and the camera emits three beeps.
See Time Lapse in Camera Settings for interval settings.
/ Camera Modes

22 23
SETTINGS
To Enter the Settings Menu:
1. Verify that the camera is in the Settings mode. If the Settings icon
[ ] does not appear on your camera status screen, press the
Power/Mode button [ ] repeatedly until it appears.
2. Press the Shutter/Select button [ ] to enter the Settings
menu [ ].
3. Use the Power/Mode button [ ] to cycle through the various
Settings options.
4. Press the Shutter/Select button [ ] to select the desired option.
5. To exit, hold down the Shutter/Select button [ ] for two seconds
or cycle through to [ ] and press the Shutter/Select button
[ ] to select it.
/ Camera Settings/ Camera Modes
PLAYBACK
Play back video and photos by connecting your HERO3+ Silver to a TV
(requires micro HDMI, composite or combo cable, sold separately).
You can also play back video and photos on the LCD Touch BacPac
(optional accessory, sold separately). The Playback icon [ ] appears
only if the camera is connected to a TV or LCD Touch BacPac.
See Playback for more information on viewing your videos and photos.

24 25
VIDEO RESOLUTION/FPS/FOV MODES
You can change Resolution, fps (frames per second) and FOV ( field of
view) in the Video mode menu.
The HERO3+ Silver offers the following video capture modes:
Video
Resolution
NTSC/
PAL FOV Screen Resolution
1080p 60/50
30/25
Ultra Wide,
Medium,
Narrow
1920x1080, 16:9
960p 60/50
30/25 Ultra Wide 1280x960, 4:3
720p
120/100
60/50
30/25
Ultra Wide,
Medium,
Narrow
1280x720, 16:9
WVGA 120/100
60/50 Ultra Wide 848x480, 16:9
/ Camera Settings
Video Resolution Best Use
1080p
1080p60 is great for all shots, as high
resolution and frame rate yield stunning
results. Try 1080p30 when shooting with a
tripod or for fixed-mounted shots.
960p
Use for body-mounted shots. Provides the
largest viewing area and smooth results
for high-action capture. Use 960p60 when
slow motion is desired—use 960p30 when
shooting in low-light conditions.
720p
Best resolution and frame rate for handheld
shots. Use 720p120 or 720p60 when slow motion
is desired. Use 720p30 in low-light conditions.
WVGA
For smaller data files, this is standard
definition resolution. Also good when slow
motion is desired.
/ Camera Settings

26 27
PHOTO RESOLUTION MODES
The HERO3+ Silver captures photos at 10MP, 7MP and 5MP resolutions.
Any change to photo resolution affects photos captured in Photo,
Burst and Time Lapse modes.
Photo Resolution Field of View (FOV)
10MP Wide (default)
7MP Wide
5MP Medium
OPTIONS
Burst mode captures a series of photos when the Shutter/Select
button [ ] is pressed. Photos can be captured at the following rates:
3 photos in 1 second
5 photos in 1 second
10 photos in 1 second (default)
/ Camera Settings / Camera Settings
TIME LAPSE
You can use Time Lapse to capture continuous photos of any activity,
so you can choose the best ones later. Or you can stitch together Time
Lapse photos during editing to create a movie. Available intervals
range from 0.5 to 60 seconds.
Interval Examples
0.5-2 seconds Surfing, biking or other sport
2 seconds Busy street corner
5-10 seconds Sunset or moon rise
10-60 seconds Lengthy activities, such as
construction projects

28 29
CAPTURE SETTINGS MENU
Capture Settings allows you to adjust the following advanced
capture options:
Camera Orientation
Spot Meter
Looping Video
See Capture Settings for more information.
/ Camera Settings
SET UP MENU
The Set Up menu allows you to adjust the following camera settings:
Default mode at Power Up
NTSC/PAL
On Screen Display
Camera Status Lights
Sound Indicator
Manual Power Off
Month/Day/Year/Time
See Set Up for more information.
/ Camera Settings

30 31
WIRELESS CONTROLS
The camera’s built-in wireless allows your HERO3+ Silver to connect
to the remote (sold separately) or smartphone/tablet via the GoPro
App. When wireless is on, a wireless status icon appears on the camera
status screen and the blue wireless lights blink intermittently. When
you turn off wireless, the wireless status lights flash seven times.
To Turn Wireless On/Off:
Press the Wireless On/Off button [ ] to turn wireless on/off. The
most recently used wireless mode is active when wireless is turned on.
Note: Your camera cannot connect to the remote and the GoPro App at the same time.
/ Camera Settings / Camera Settings
DELETE
Delete the last file or all files and format the memory card. Deleting all
files is useful aer you transfer your files to your computer and want to
make room on your memory card for more content. LED lights blink
until the operation is complete.
NOTICE: If you select ALL, the memory card is reformatted, which
deletes every file on your card.
CANCEL (default)
LAST
ALL (Formats SD card)
To Delete LAST or ALL:
1. Verify that the camera is in the Settings mode. If the Settings icon
[ ] does not appear on your camera status screen, press the
Power/Mode button [ ] repeatedly until it appears.
2. Press the Shutter/Select button [ ] to enter the Settings
menu [ ].
3. Use the Power/Mode button [ ] to cycle through Settings to
locate the Trash [ ].
4. Press the Shutter/Select button [ ] to enter Delete.

32 33
/ Camera Settings
5. Use the Power/Mode button [ ] to cycle through options.
6. Select highlighted option by pressing the Shutter/Select button [ ].
7. To exit, hold down the Shutter/Select button [ ] for two seconds
or cycle through to [ ] and press the Shutter/Select button [ ].
PRO TIP: Use cautionby selecting ALL, the memory card will be
formatted, deleting every file on your SD card.
From the [ ] screen, press the Shutter/Select button [ ] to exit
the Settings menu.
PRO TIP: To exit from the Settings menu at any time press and hold
the Shutter/Select button [ ] for two seconds.
CAPTURE SETTINGS
To Enter the Capture Settings Menu:
1. Verify that the camera is in the Settings mode. If the Settings icon
[ ] does not appear on your camera status screen, press the
Power/Mode button [ ] repeatedly until it appears.
2. Press the Shutter/Select button [ ] to enter the Settings
menu [ ].
3. Use the Power/Mode button [ ] to cycle through Settings to
locate the Capture Settings menu [ ].
4. Press the Shutter/Select button [ ] to enter Capture Settings.
5. Use the Power/Mode button [ ] to locate the desired option
to change.
6. Press the Shutter/Select button [ ] to select the desired option.
7. Some options have a sub-menu. Use the Power/Mode button [ ]
to cycle through the sub-menus.
8. Press the Shutter/Select button [ ] to select the desired option
9. To exit, hold down the Shutter/Select button [ ] for two seconds
or cycle through to [ ] and press the Shutter/Select button
[ ] to select it.
/ Capture Settings

34 35
/ Capture Settings
You can customize the way your HERO3+ Silver captures video and
photos in the Capture Settings menu, with options for Upside Down,
Spot Meter and Looping Video.
UPSIDE DOWN
If you mount your camera upside down, you might have to rotate the
files during editing. This setting eliminates the need to flip your videos
or photos aer recording.
Setting Description
Right side up (default)
Camera upside down
SPOT METER
Turn on Spot Meter when filming from within a dark space pointing
the camera into a brighter setting, such as filming the outdoors from
within a car. When Spot Meter is turned on, [ ] appears in the
camera status screen.
OFF (default)
ON
LOOPING VIDEO
Looping video lets you record continuously and save only the best
moments, which helps to conserve space on your microSD card.
Looping Video Options Include:
Capture Setting Description
OFF (default)
Max video
If you do not stop recording to save the video,
camera records until memory card is full, and
then overwrites with a new video.
5 min video
If you do not stop recording to save the video,
camera records for 5 minutes, and then
overwrites the previous 5 minutes of video.
20 min video
If you do not stop recording to save the video,
camera records for 20 minutes, and then
overwrites the previous 20 minutes of video.
/ Capture Settings

36 37
Capture Setting Description
60 min video
If you do not stop recording to save the video,
camera records for 60 minutes, and then
overwrites the previous 60 minutes of video.
120 min video
If you do not stop recording to save the video,
camera records for 120 minutes, and then
overwrites the previous 120 minutes of video.
PRO TIP: Multiple chapter files are written to your memory card. This
allows for small segments of content to be overwritten during loop
recording. When viewing on a computer screen, you will see separate
files for each time segment. Use GoPro soware to combine the files
into a longer video.
From the EXIT screen, press the Shutter/Select button [ ] to exit
the Capture Settings menu.
PRO TIP: To exit from the Capture Settings menu at any time press
and hold the Shutter/Select button [ ] for two seconds.
/ Capture Settings
SET UP
To Enter the Set Up Menu:
1. Verify that the camera is in the Settings mode. If the Settings icon
[ ] does not appear on your camera status screen, press the
Power/Mode button [ ] repeatedly until it appears.
2. Press the Shutter/Select button [ ] to enter the Settings
menu [ ].
3. Use the Power/Mode button [ ] to cycle through Settings to
locate the Setup menu [ ].
4. Press the Shutter/Select button [ ] to enter Set Up.
5. Use the Power/Mode button [ ] to locate the desired option
to change.
6. Press the Shutter/Select button [ ] to select the desired option.
7. To exit, hold down the Shutter/Select button [ ] for two seconds
or cycle through to [ ] and press the Shutter/Select button
[ ] to select it.
/ Set Up

38 39
/ Set Up
DEFAULT MODE AT POWER UP
You can set the camera’s default mode at power up to any of the
following modes:
Video (default)
Burst
Time Lapse
ONE BUTTON
With One Button mode selected, the camera automatically begins
recording when powered on.
OFF (default)
ON
Note: One Button mode is disabled when the camera is connected to the Remote (sold separately) or
the GoPro App.
To Turn On One Button Mode:
In Setup, set One Button to ON. For details about how to change a
setting, see Set Up earlier in this section.
To Capture Video or Time Lapse with One Button Mode:
With the camera powered off, press and release the
Power/Mode button
[
]. If the default mode is set to Video, the camera automatically
powers on and begins capturing video. If the default mode is set to
Photo, Burst or Time Lapse, the camera automatically powers on and
begins capturing Time Lapse photos.
To Stop Recording:
Press and hold the
Power/Mode button [ ] for two seconds to stop
recording and power off the camera.
/ Set Up
