Gorenje Plus GDV664XL User manual

Operating Instructions GDV664XL

CONTENTS
2FRONT PANEL
3SAFETY INSTRUCTIONS
4
BEFORE WASHING FOR THE FIRST
TIME
6LOADING THE DISHWASHER
9USING THE DISHWASHER
13SETTINGS
17CARE AND CLEANING
19TROUBLESHOOTING
23INFORMATION FOR TEST INSTITUTE
25TECHNICAL INFORMATION
26INSTALLATION
28SERVICE
29PROGRAMME CHART
30YOUR NOTES
FRONT PANEL
1 32 5 6 9 10 11 12 13 14
7 8
4
1 On/Left-on mode
2 Programme selector
3 Programme symbol
4 Display
5 Rinse aid indicator
6 TAB (3-in-1/all-in-one
detergent)
7 Salt indicator
8 Child lock (button lock)
9 High temperature
10 Long dry
11 Delayed start
12 Set time (for the Time
program)
13 Time saver
14 Start/Stop
The panel is fitted with touch buttons with audible feedback (see the chapter Settings).
NOTE!
•Two minutes after the last button press, the panel backlight enters energy saving mode. Close and
reopen the door, or press the On/Left-on mode button, to reactivate the panel.
2

SAFETY INSTRUCTIONS
GENERAL
•Read the operating instructions and keep them
in a safe place!
•Never use the dishwasher for any purpose
other than that specified in these operating
instructions.
•Do not load the dishwasher door or
dishwasher baskets with anything other than
dishes.
•Never leave the dishwasher door open as
someone may trip on it.
•Use only dishwasher detergent!
•This machine can be used by children aged 8
and upwards, and by people with reduced
physical capacity, mental ability, memory loss
or lacking experience and knowledge. These
individuals must be supervised when using the
machine or have instructions on how to use
the machine and understand the risks that can
occur. Cleaning of the machine must not be
carried out by children without supervision.
•Children must be watched to ensure they do
not play with the dishwasher.
•Damaged mains cables must only be replaced
by a qualified electrician.
•This dishwasher is for household or similar
use, such as:
- staff kitchens in shops, offices and other
workplaces.
- farms.
-for guests at hotels, motels and other types
of accommodation.
- bed & breakfast hotels.
•Never place dishes with solvent residues in
the dishwasher due to the risk of explosion.
Nor may dishes that contain ash, wax or
lubricants be washed in the dishwasher.
WARNING!
Knives and other pointed items must be placed
with the points down in the cutlery basket or
horizontally in other baskets.
INSTALLATION
See the section Installation.
CHILD SAFETY
•Always close the door and start the
programme immediately after you have added
the detergent.
•Keep children away from the dishwasher when
the door is open. Some detergent may remain
inside!
•Do not allow children to use or play with the
dishwasher. Be especially vigilant when the
door is open.
WARNING!
Children must be supervised –dishwasher
detergent is corrosive!
Store detergent and rinse aid out of the reach
of children! If anyone swallows dishwasher
detergent, they should immediately drink one
or two glasses of milk or water. Do not attempt
to induce vomiting. Contact a doctor! If anyone
gets dishwasher detergent in their eyes, rinse
(for at least 15 minutes) with plenty of water.
Activate child lock (button lock)
You can activate the child lock (button lock) to
prevent children from starting the dishwasher
(see the section Settings).
WINTER STORAGE/TRANSPORT
•Store the dishwasher where the temperature
remains above freezing.
•Avoid long transport distances in very cold
weather.
•Transport the dishwasher upright or laying on
its back.
OVERFLOW GUARD FUNCTION
The overflow protection starts pumping out the
machine and turns off the water supply if the
water level in the dishwasher exceeds the normal
level. If the overflow protection is triggered, turn
off the water supply and call the service
department.
3

CLEANING
When cleaning the edge around the door, use
only a slightly damp cloth. Do not spray water
around the edge! Moisture can make its way into
the lock, which contains electrical components.
PACKING MATERIAL
Please sort waste materials in accordance with
local guidelines.
DISPOSAL
•When the dishwasher has reached the end of
its service life and is to be disposed of, it
should immediately be made unusable. Pull
out the power cable and cut it as short as
possible.
•The dishwasher is manufactured and labelled
for recycling.
•Contact your local authority for information
about where and how your dishwasher should
be correctly recycled.
BEFORE WASHING FOR THE FIRST
TIME
DEAR GORENJE+ CUSTOMER!
We hope that you will have many years of use
from your new machine.
The machine has many features. To make the
most of its functions, we recommend that you
read the operating instructions before using the
machine. The operating instructions include
information on how you can help protect the
environment.
PROGRAMME KEY
Some dishwashers include programme keys in
different languages. Attach the programme key
in the desired language to the top of the door.
THE WATER SOFTENER
In order to achieve good dishwashing results, the
dishwasher needs soft water (water with low
mineral content). Hard water leaves a white
coating on dishes and the dishwasher.
Water hardness is specified using the following
scales: The German water hardness scale (°dH)
and the French water hardness scale (°fH). A
water supply with a water hardness in excess of
6°dH (9°fH) must be softened. This is done
automatically with the aid of the built-in water
softener. In order for the softener to function
optimally, it must be adjusted to the hardness of
the water supply.
Contact the local waterworks to check the water
hardness in your area. Once you have adjusted
the water softener, use detergent and rinse aid
doses suitable for soft water.
ADJUSTING THE WATER SOFTENER
In section Settings on page 16 the process for
setting the water softener is described. Do not
forget to put salt in the salt compartment after
you have set the water softener.
4

FILL UP THE SALT
Before you begin using a dishwasher with a water
softener, you must fill the salt compartment with
salt. Use large grain salt or special dishwasher salt.
WARNING!
Top up the salt just before running a
programme. To avoid the risk of rust stains, the
dishwasher must be rinsed immediately after
topping up the salt.
Never pour dishwasher detergent into the salt
compartment. This destroys the water softener!
Do as follows the first time:
1 Unscrew the lid as illustrated.
2 Place the funnel supplied with the dishwasher
in the salt compartment top-up hole. First,
pour in about 1 l of water.
3 Then add salt, a maximum of 1.5 kg, until the
compartment is full.
4 Wipe up any excess salt so that the lid can be
screwed on firmly.
5 Run a programme to ensure that any salt in
the dishwasher is rinsed away.
Salt compartment lid
Refill salt indicator
When the salt needs topping up, the above
symbol lights on the display.
When the salt runs out, unscrew the cap and fill
the container with salt. Water is only needed the
first time! Wipe clean and tighten. Run a
programme to ensure that any salt in the
dishwasher is rinsed away.
NOTE!
After topping up, it may take a while before the
symbol goes out.
TOP UP WITH RINSE AID
Drying is faster and a better result is achieved if
you use rinse aid. You will also achieve a better
dishwashing result with clear and spotless dishes.
1 Open the rinse aid compartment lid.
2 Carefully top up with rinse aid. Only add rinse
aid to the level marked max.
3 Wipe up any splashes of rinse aid around the
compartment.
4 Close the lid firmly.
Refill rinse aid indicator
When the rinse aid needs topping up, the above
symbol lights on the display.
NOTE!
After topping up, it may take a while before the
symbol goes out.
SETTING THE RINSE AID DOSAGE
The section Settings describes how to set the rinse
aid dosage. Rinse aid dispensing can be set from
(Off) to (High dose). (Factory
settings: )
Increase the rinse aid dosage:
•If the dishes have water marks.
Decrease the rinse aid dosage:
•If the dishes have a sticky white/blue film.
•If the dishes are streaked.
•Build-up of foam. If you have very soft water,
the rinse aid can be diluted 50:50 with water.
5
