Gorenje BCD 522 Technical manual

EN
www.gorenje.comwww.gorenje.com
DETAILED
INSTRUCTIONS FOR USE
OF UPRIGHT
REFRIGERATOR AND
FREEZER

2
We thank you for the confidence you have shown by purchasing
our appliance which is designed to simplify your life. To make the use of the
product easier, we have supplied detailed instructions for use, and installation
instructions supplied on a separate sheet. The instructions should allow you to
learn about your new appliance as quickly as possible.
We wish you find a lot of pleasure in its use.
The appliance is intended solely for household use.
The refrigerator is intended for storing fresh food at temperatures above 0°C.
The freezer is intended for freezing fresh food and for long-term storage of
frozen food (up to one year, depending on the type of food).
Please visit our website where you can enter your appliance model number,
indicated on the rating plate or the warranty sheet, to find detailed description
of your appliance, tips on use, troubleshooting, service information, instructions
for use etc.
http://www.gorenje.com
Important safety warning
!

3
CONTENTS
INTRODUCTION
APPLIANCE
DESCRIPTION
DEFROSTING
AND CLEANING
THE APPLIANCE
4 IMPORTANT NOTES AND PRECAUTIONS
4 SAFETY AND WARNING INFORMATION
11 INSTALLING YOUR NEW APPLIANCE
21 APPLIANCE DESCRIPTION
22 OPERATING THE APPLIANCE
26 USING YOUR APPLIANCE
36 HELPFUL HINTS AND TIPS
37 CLEANING AND CARE
40 TROUBLESHOOTING
43 DISPOSAL OF THE APPLIANCE
MISCELLANEOUS

4
IMPORTANT NOTES AND
PRECAUTIONS
For your safety and correct usage, before installing and
first using the appliance, read this user manual carefully,
including its hints and warnings. To avoid unnecessary
mistakes and accidents, it is important to make sure that all
people using the appliance are thoroughly familiar with its
operation and safety features. Save these instructions and
be sure that they remain with the appliance if it is moved
or sold, so that anyone using it throughout its life, will be
properly informed on its usage and safety notices.
For the safety of life and property, keep the precautions of
these user's instructions as the manufacturer is not
responsible for damages caused by omission.
Safety for children and others who are vulnerable people
According to EN standard
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances.
SAFETY AND WARNING
INFORMATION
!

5
According to IEC standard
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Keep all packaging away from children as there is risk of
suffocation.
• If you are discarding the appliance, pull the plug out of
the socket, cut the connection cable (as close to the
appliance as you can) and remove the door to prevent
children playing from suffering an electric shock or from
closing themselves inside it. I
• f this appliance, featuring a magnetic door seals, is to
replace an older appliance having a spring lock (latch) on
the door or lid, be sure to make the spring lock unusable
before you discard the old appliance. This will prevent it
from becoming a death trap for a child.
General safety
• WARNING —This appliance is intended to be used in
household and similar applications such as
-staff kitchen areas in shops, offices and other working
environments;
-farm houses and by clients in hotels, motels and other
residential type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
!

6
• WARNING — Do not store explosive substances such
as aerosol cans with a flammable propellant in this
appliance.
• WARNING — If the supply cord is damaged, it must
be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
• WARNING — Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
• WARNING — Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
• WARNING — Do not damage the refrigerant circuit.
• WARNING — Do not use electrical appliances inside the
food storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
• WARNING — The refrigerant and insulation blowing
gas are flammable. When disposing of the appliance,
do so only at an authorized waste disposal centre. Do
not expose to flame. WARNING —When positioning
the appliance, ensure the supply cord is not trapped or
damaged.
• WARNING —Do not locate multiple portable socket-
outlets or portable power supplies at the rear of the
appliance.
Replacing the LED
• WARNING—The LED light must not be replaced by the
user! If the LED light is damaged, contact the customer
helpline for assistance.
Refrigerant
The refrigerant isobutene (R600a) is contained within the
refrigerant circuit of the appliance, a natural gas with a high
level of environmental compatibility, which is nevertheless

7
flammable. During transportation and installation of the
appliance, ensure that none of the components of the
refrigerant circuit becomes damaged.
The refrigerant (R600a) is flammable.
• WARNING — Refrigerators contain refrigerant andgases
in the insulation. Refrigerant and gases must be disposed
of professionally as they may cause eye injuries or
ignition. Ensure that tubing of the refrigerant circuit is
not damage prior to proper disposal.
Caution:risk of fire
If the refrigerant circuit should be damaged:
• Avoid opening flames and sources of ignition.
• Thoroughly ventilate the room in which the appliance is
situated.
It is dangerous to alter the specifications or modify this
product in any way.
Any damage to the cord may cause a short circuit, fire, and/
or electric shock.
!Electrical safety
• The power cord must not be lengthened.
• Make sure that the power plug is not crushed or
damaged. A crushed or damaged power plug may
overheat and cause a fire.
• Make sure that you can access the main plug of the
appliance.
• Do not pull the main cable.
• If the power plug socket is loose, do not insert the power
plug. There is a risk of electric shock or fire.

8
• You must not operate the appliance without the interior
lighting lamp cover.
• The fridge is only applied with power supply of single
phase alternating current of 220~240V/50Hz. If
fluctuation of voltage in the district of user is so large
that the voltage exceeds the above scope, for safety
sake, be sure to apply A.C. Automatic voltage regulator
of more than 350W to the fridge. The fridge must
employ a special power socket instead of common one
with other electric appliances. Its plug must match the
socket with ground wire.
Daily use
• Do not store flammable gass or liquids in the appliance,
There is a risk of an explosion.
• Do not operate any electrical appliances in the appliance
(e.g.electric ice cream makers,mixers etc.).
• When unplugging always pull the plug from the mains
socket,do not pull on the cable.
• Do not place hot items near the plastic components of
this appliance.
• Do not place food products directly against the air outlet
on the rear wall.
• Store pre-packed frozen food in accordance with the
frozen food manufacture’s instructions.
• The appliances manufactures storage recommendations
should be strictly adhered to.Refer to relrelevant
instructions for storage.
• Do not place carbonated or fizzy drinks in the
freeze compartment as it creates pressure on the
container,which may cause it to explode,resulting in
damage to the appliance.
• Frozen food can cause frost burns if consumed straight
from the freezer compartment.
• Do not place the appliance in direct sunlight.

9
• Keep buring candles,lamps and other items with naked
flames away from the appliance so that do not set the
appliance on fire.
• The appliance is intended for keeping food stuff and/
or beverages in normal household as explained in this
instruction booklet The appliance is heavy.Care should
be taken when moving it.
• Do not remove nor touch items from the freezer
compartment if your hands are damp/wet,as this could
cause skin abrasions or frost/freezer burns.
• Never use the base,drawers, doors etc. to stand on or as
supports.
• Frozen food must not be refrozen once it has been
thawed out.
• Do not consume ice popsicles or ice cubes straight from
the freezer as this can cause freezer burn to the mouth
and lips.
• To avoid items falling and causing injury or damage to
the appliance, do not overload the door racks or put too
much food in the crisper drawers.
• WARNING - Food needs to be packed into bags before
it is put into the refrigerator. Liquids need to be stored in
bottles or capped containers in order to avoid a spill, as
the design structure of the product is not easy to clean.
Caution!
Care and cleaning
• Before maintenance, switch off the appliance and
disconnect the mains plug from the mains socket.
• Do not clean the appliance with metal objects, steam
cleaner, ethereal oils, organic solvents or abrasive
cleansers.
• Do not use sharp objects to remove frost from the
appliance. Use a plastic scraper.

10
Installation Important!
• For electrical connection carefully, follow the instructions
given in this manual.
• Unpack the appliance and check if there are damages on
it. Do not connect the appliance if it is damaged. Report
possible damages immediately to the place you bought
it. In this case retain packing.
• It is advisable to wait at least four hours before
connecting the appliance to allow the oil to flow back in
the compressor.
• Adequate air circulation should be around the appliance,
lacking this leads to overheating. To achieve sufficient
ventilation, follow the instructions relevant to installation.
Wherever possible the back of the product should not be
too close to a wall to avoid touching or catching warm
parts (compressor, condenser) to prevent the risk of a
fire, follow the instructions relevant to installation.
• The appliance must not be locate close to radiators or
cookers.
• Make sure that the mains plug is accessible after the
installation of the appliance
Service
• Any electrical work required to do the servicing of the
appliance should be carried out by qualified electrician or
competent person.
• This product must be serviced by an authorized Service
Center, and only genuine spare parts must be used.
1) If the appliance is Frost Free.
2) If the appliance contains freezer compartment.

11
INSTALLING YOUR NEW
APPLIANCE
IMPORTANT: This refrigerator is designed for indoor, household use only.
Temperature
This refrigerator is intended for use in a location where the temperature
ranges from a minimum of 16 °C to a maximum of 43 °C. The preferred room
temperature range for optimum performance, which reduces electricity usage
and provides superior cooling, is between 16 °C and 32 °C. It is recommended
that you do not install the refrigerator near a heat source, such as an oven or
radiator.
Exterior and Dimensions
A Refrigerator doors
B Handles
C Freezer door
D Convertible freezer door

12
Ventilation
Adequate air circulation around the refrigerator is required for ecient
operation.
To ensure proper ventilation, maintain the recommended clearances.
Recommended Clearances
A 100mm Above
B 50mm Behind
C 50mm Each Side
NOTE: If you place the refrigerator next to a fixed wall, leave 1471.4 mm minimum
space to allow the door to swing open.
Electrical Requirements
Before you move your refrigerator into its final location, it is important to make
sure you have the proper electrical connection.
Recommended Grounding Method
A 220-240 volt, 50 Hz, AC only 15- or 20-amp fused, grounded electrical
supply is required. It is recommended that a separate circuit serving only your
refrigerator be provided. Use an outlet that cannot be turned o by a switch. Do
not use an extension cord.
NOTE: Before performing any type of installation or cleaning, disconnect the
refrigerator from the electrical source. When you are finished, reconnect the
refrigerator to the electrical source and reset the temperature controls to the
desired setting.

13
Unpack the Refrigerator
IMPORTANT: Handle with care when moving refrigerator to avoid either
damaging the refrigerant tubing or increasing the risk of a leak.
Remove the Packaging
Remove tape and glue residue from surfaces before turning on the refrigerator.
Rub a small amount of liquid dish soap over the adhesive with your fingers.
Wipe with warm water and dry.
NOTE: Do not use sharp instruments, rubbing alcohol, flammable fluids, or
abrasive cleaners to remove tape or glue. These products can damage the
surface of your refrigerator. For more information, see “Refrigerator Safety.”
• Dispose of/recycle all packaging materials.
• If the refrigerator has been placed in a horizontal or tilted position for any
period of time wait 4 hours before plugging it in to allow the oil to settle into
the compressor.
When Moving Your Refrigerator:
Your refrigerator is heavy. When moving the refrigerator for cleaning or service,
be sure to cover the floor with cardboard or hardboard to avoid floor damage.
Always pull the refrigerator straight out when moving it. Do not wiggle or “walk”
the refrigerator when trying to move it, as floor damage could occur.
Clean Before Using
After you remove all of the packaging materials, clean the inside of the
refrigerator before using it. See the cleaning instructions in “Refrigerator Care.”
Important information to know about glass shelves and covers:
Do not clean glass shelves or covers with warm water when they are cold.
Shelves and covers may break if exposed to sudden temperature changes or
impact, such as bumping. Tempered glass is designed to shatter into many small,
pebble-size pieces. This is normal. Glass shelves and covers are heavy. Use both
hands when removing them to avoid dropping.
Installation Positioning
This aplication perform well from N to T. The Appliance may not work properly if
it is left for a longer period at a temperature above or below the inciated range.
Climate class Ambient temperature
SN +10 to +32
N +16 to +32
ST +16 to +38
T +16 to +43

14
Door Removal (only if needed)
Measure the refrigerator to make sure it will fit through the doorway. If the
refrigerator cannot pass easily through the doorway, follow the instructions
to remove the two refrigerator compartment doors and the front panel of the
freezer drawer.
WARNING! Electrical Shock Hazard
Disconnect power before removing doors.
Reconnect ground wire before operating.
Failure to do so could result in death or electric shock.
Tools you will need (Not provided)
Allen Wrench (4 mm) Wrench (8 mm)
Philips Screwdriver
Remove the doors
IMPORTANT: Keep the refrigerator doors closed until you are ready to lift them
from the cabinet.
1. Unplug refrigerator or disconnect power.
2. Using a Philips screwdriver, remove the three screws attaching the hinge
cover, and then remove the hinge cover with the entire harnesses attached.
Screws
3. Separate the two connectors on the left side door. To remove the wire
connector, press the top of the connector (B) and separate it from the other
one. To remove the water coupler from the honge, twist and pull the clips
from the coupler.
Remove the water line (C) while pressing the movable part (D) of the water
line coupler.

15
4. Remove the 3 screws (E) fixed on the hinges, with a Wrench (8 mm) and 1
ground screws (F) attached to the hinge with Philips (+) screwdriver. Remove
the upper left door hinge (G).
5. Use your both hands to open the door more than 90°. Lift it up and take it o.

16
6. If necessary, remove the 2 hex head bolts hinges (I) with an Allen wrench
(5 mm). Remove the lower left door hinge (H).
Allen Wrench
Replace the doors
1. If removed, reinstall the botoom hinge.
2. Using two or more people, set the refrigerator door onto the bottom hinge.
3. Insert the top hinge into the top of the door.
4. Using the three screws removed earlier, fasten the top hinge to the top of the
cabinet.
NOTE: Left-hand door only, replace the ground screw into the top hinge,
reattach the wire harness, reconnect the water line, make sure the clips are
properly connected to the coupler.
5. Repeat steps 1 through 4 to replace the opposite door.
6. Using the three screws removed earlier, reinstall the top hinge cover and
control panel to the top of the cabinet.
Use of water storage box
1. The user pulls out the ice box in the direction of the arrow.

17
2. Open the lid of the ice box and add water to it.
3. Close the lid and push back into the ice box in the direction of the arrow.
NOTE:
• The icebox can hold up to 4.2L of water.
• If the water storage box is not in place, the icon on the control panel
flashes.
• If the user has more than 7 days of travel planned, it is recommended to clean
the ice.
• When the tank is repositioned, the pump will reverse the water from the ice
maker. After about a minute, a few drops of water will fall out of the ice outlet,
which is normal.

18
Complete the Installation
WARNING - Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove the ground prong from the power cord plug.
Do not use an adapter.
Do not use an extension cord.
Failure to do so can result in death, fire or electrical shock.
1. Plug in to a grounded 3 prong outlet.
NOTE: This refrigerator begins operating as soon as it is connected to the
power supply.
2. Move the refrigerator into its final location, making sure to maintain the
recommended clearance.
Level Refrigerator (if needed)
The refrigerator must be level to maintain optimal performance and appearance.
1. Turn the leveling feet on the bottom, front of the cabinet to raise or lower that
side of the refrigerator until the refrigerator is level side to-side.
2. Turn both feet, by the same amount, to slightly raise the front of the
refrigerator. This will make it easier for the doors to close.
NOTE: Having someone push against the top of the refrigerator takes some
weight off the leveling feet. This makes it easier to turn the feet.
Rotate the adjustable feet clockwise to raise or raise counter-clockwise to
lower your refrigerator. To make sure that the doors close automatically, tilt
the top of your refrigerator backward about 10mm to 15mm. If necessary, use
a spanner wrench to adjust the feet.
A C
B
A
C
B
Adjustable foot
Roller
Roller
10mm to 15mm

19
Align Doors (if needed)
The gaskets is used to align doors, you can find them in the manual bag.
small gasket 3pcs
big gasket 1 pcs

20
Opening and Closing Doors
Providing room for doors to open
Make sure that you have enough room in front of your refrigerstor to swing the
doors open.
The four doors can be opened and closed either separately or together.
• There is a mullion on the left-hand side refrigerator compartment door.
• When closing the left-hand door, the mullion folds behind the right-hand door
joining the two doors.
• The temperature of the door frame is controlled to help prevent moisture
from developing on the mullion. The temperature of the surface may be warm,
which is normal, and will not aect the performance of the refrigerator.
NOTE: Before closing the left-hand door, make sure the mullion is folded inward.
If the mullion is pulled outward it may become damaged when you try to close
the door.
