Grand Canyon Gas Logs MVKE I KN User manual

Grand Canyon Gas Logs
3515 East Atlanta Avenue, Phoenix, Arizona 85040
602-344-4217 • grandcanyongaslogs.com 01_2022_V1
BATTERY ELECTRONIC
WITH REMOTE CONTROL
For Natural or Propane Gas
WARNING: If the information in this
manual is not followed exactly, a
re or explosion may result causing
property damage, personal injury,
or loss of life.
FOR YOUR SAFETY: Do not store
or use gasoline or other ammable
vapors and liquids in the vicinity of
this or any other appliance.
INSTALLER: Leave this manual with appliance. CONSUMER: Retain this manual for future reference.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier,
call the re department.
– Installation and service must be performed by a
qualied installer, service agency, or the gas supplier.
WARNING
Grand Canyon Gas Logs burner system is to be installed only in a solid-fuel-burning replace with a working ue
constructed of noncombustible material. Solid fuels shall not be burned in a replace where the unit is installed.
The installation, including provisions for combustion, ventilation air, and required minimum permanent vent
opening, must conform with the National Fuel Gas Code (ANSI Z223.1/NFPA 54)\ and applicable local building
codes. In Canada, the installation must conform with the Natural Gas and Propane Storage and Handling Instal-
lation Code (CSA-B-149.1). A damper stop clamp is included to maintain the minimum permanent vent opening
and to prevent full closure of the damper blade. The chimney damper must be xed fully opened when burn-
ing the unit. The burner system is designed to burn with yellow ames; thus, adequate ventilation is
absolutely necessary. If any of these parameters are not met, the warranty could be voided.
Grand Canyon Gas Logs
3515 East Atlanta Avenue, Phoenix, Arizona 85040
602-344-4217 • grandcanyongaslogs.com 04_2022_V1
INSTALLER: Leave this manual with appliance. CONSUMER: Retain this manual for future reference.
WARNING
MODELS:
MVKE I KN
MVKE I KLP
Features:
• Intermittent Pilot Ignition
• Non-standing ame-sensing pilot
• Remote Included
Burner capability
• 2 Burner - 2BRNST
• 3 Burner - 3BRNST
• Kiva • Glass
• Jumbo/Jumbo Slim/Jumbo ST
We recommend that our gas hearth products be
installed and serviced by professionals who are
certied in the U.S. by the National Fireplace Institute
(NFI) as NFI Gas Specialists.
Installation & Owner's Manual

1
GrandCanyonGasLogs.com [email protected]
Important Information .................................................................2
Specications .............................................................................2
Bill of Materials - Parts List........................................................3
Wire Diagram - Battery Powered................................................4
Installation ..................................................................................5
Lighting Instructions.................................................................. 11
Troubleshooting........................................................................12
Warranty ...................................................................................13
NOTE: Changes may change without notice, Changes will be shown on updated versions.
TABLE OF CONTENTS

21 GrandCanyonGasLogs.com [email protected]
IMPORTANT INFORMATION
CHECK TO BE SURE THAT THE PROPER FUEL GAS IS BEING
USED WITH THIS CONTROL SYSTEM.
The installation, including provisions for combustion and ventilation air, must conform with
local codes, or in the absence of local codes, with the National Fuel Gas Code
(ANSI Z223.1/NFPA 54).
This component and its individual shutoff valve must be disconnected from the gas-supply
piping system when testing at pressures that exceed 1/2 psig. This is accomplished by closing
the gas-supply line valve.
A replace screen must be in place when the gas burner system is in operation.
Unless other provisions for combustion air are provided, the screen shall have an opening(s)
for introduction of combustion air.
WHEN GLASS FIREPLACE ENCLOSURES (DOORS) ARE USED, OPERATE
THE BURNER SYSTEM WITH THE GLASS DOORS FULLY OPEN; BOTH
SIDES IF THE FIREPLACE IS A SEE-THROUGH TYPE.
This appliance may be installed in an aftermarket, permanently located, manufactured
(mobile) home where not prohibited by local codes. Installation of appliances designed for
manufactured homes or mobile homes must conform with Manufactured Home Construction
and Safety Standard, Title 24 CFR, Part 3280in the U.S.; or with CAN/CSA Z240 MH in Can-
ada; or with ANSI/NCSBCS A225.1/NFPA 501A, Manufactured Home Installations Standard
when such as standard is not applicable.
Do not use this appliance if any part has been underwater. Immediately call a qualied service
technician to inspect the appliance and to replace any part of the control system and any gas
control that has been underwater.
TO PREVENT VALVE DAMAGE AND FAILURE:
IT IS CRITICAL THAT THE HEAT SHIELD BE PLACED CORRECTLY OVER THE VALVE/CONTROL
MODULET BATTERY PACK PRIOR TO OPERATION.
KEEP LAVA, VERMICULITE, EMBERS/GLASS AND ALL FOREIGN OBJECTS AWAY FROM THE PILOT
ASSEMBLY, VALVE ASSEMBLY, AND HEAT SHIELD DURING MEDIA PLACEMENT AND AT ALL TIMES
Refer to the burner owner’s manual for minimum rebox dimensions.
Model BTUs
N.G. L.P.
120k 180kMVKE
SPECIFICATIONS
MAX BTU OUTPUT

3
GrandCanyonGasLogs.com [email protected]
BILL OF MATERIALS
# Model # Description Qty
1 3V-BAT 3V DEXEN BATTERY PACK (2 D-CELL BATTERIES INCLUDED) 1
2 3V-PIL-24 24" NATURAL GAS 3V PILOT ASSEMBLY 1
3 6003V 6003-NAT 3.5" W.C., 3/8" X 3/8" STRAIGHT THRU: W/1/4" PILOT FITTING 1
4 LP-VAL* LP Pressure Regulator For 6003V 3V Valve 10" W.C. 1
5 LP-PIL* 3V Dexen Propane Pilot Orice 1
6 6K-WIR GM6K TO 6003V WIRE HARNESS (12" VAL WIR, 84" SWITCH/BAT WIR) 1
7 GM6KA 6K MODULE FOR 3V ING MODULE 1
8 HEAT-BAT Battery Electronic Battery/Receiver Heat Shield w/Insulation 1
9 HEAT-VAL Battery Electronic Valve/Module Heat Shield w/Insulation 1
10 49-86 49 SERIES 3/8 X 1/2 90* ELBOW 2
11 T200-9898-10 WHISTLE FREE FLEX 1/2 X 10 1
12 GAS-GCRK Grand Canyon Remote Kit 1
13 GRD Ground Wire 1
*Propane Models ONLY
9
7
13
3
10 10 2
11
12
12
8
1
6
4
5
LP-VAL
LP-PIL

43 GrandCanyonGasLogs.com [email protected]
WIRE DIAGRAM - BATTERY POWERED
Remote
Receiver
Ground

5
GrandCanyonGasLogs.com [email protected]
STEP BY STEP INSTALLATION
This Battery Electronic control system must be installed by a qualied gas
professional. These instructions MUST be followed to ensure proper performance
and safety. Failure to do so could result in serious injury or death.
Battery electronic valve system is shipped pre-assembled with ttings and heat shields already attached.
For systems ordered “Assembled” the valve system is pre-assembled and tested at the factory before shipping.
Perform the installation with extreme care ensuring not to damage the valve, module or wiring harness
connections. It is also recommended that the valve assemble is performed outside of the replace.
Pre-Installation –
For assembly of control system to an existing gas log system, ensure that all the media has been removed and
the burner is clear of all dust and debris. Check to ensure that the valve system and burner are labeled for the
gas type supplied to the replace (Natural Gas or Propane). Also check to ensure that the proper gas pressure
is supplied to appliance (Minimum 5" W.C Natural Gas, Minimum 10" W.C Propane).
This Battery Electronic Control must be installed by a qualied professional
service technician. Instructions must be followed carefully when installing
to ensure proper performance.
These instructions must be used as a supplement to the instructions supplied with the Grand Canyon
Gas Logs burner system. Follow the burner system instructions and make adjustments as appropriate
for the addition of a battery electronic system. Use gas pipe sealing compound that is resistant to all
gasses (or Teon tape) and apply to all male pipe connections. DO NOT apply pipe sealing compound
to any are connections. Make sure that all connections are tight.
Installation –
Remove all burner components for the burner kit and
the valve control system parts. Locate the silver gas
control valve, (2) 3/8" FIP x ½" Flare brass elbows,
Velcro & green control module. Using pipe sealing
compound insert each of the brass ttings into the
valve tightly, with the connections facing the bottom
of the valve, Fig.1. Attach the green control
module to the valve as shown in the picture.
NOTE: Orient the valve so that the gas inlet is on the
right and the gas outlet is on the left. The gas outlet is
on the same side as the pilot assembly connection.
Gas In
Gas Out
Fig. 1

65 GrandCanyonGasLogs.com [email protected]
INSTALLATION
Locate the 7-wire wiring harness. Follow Fig. 1, by
inserting the wiring harness long terminal block into the
green control module and the short terminal block into
the top of the valve. Using the screws provided,
connect the (2) black wires to the valve & the green
ground pilot wire. Ensure connections are tight for
ground contact.
Fig. 2

7
GrandCanyonGasLogs.com [email protected]
On the end of the 7-wire wiring harness, locate the
(2) brown wires as well as the red & black wires.
The (2) brown wires are your switch wires that will con-
nect to your remote and the red & black wires are your
power in connection to the battery pack. Next locate
the (2) black wires connected to the terminal block of
the receiver box. Using the provided spade connec-
tions, connect one black wire to one of the brown wires
and the other black wire to the last brown wire. Next
connect the red/black wire from the battery pack to the
red/black wires on the 7-wire wiring harness.
Red to red and black to black.
NOTE: This is also a good time to insert the (4) AA
batteries into the receiver and the (2) D-Cell batteries
into the control systems battery pack. For syncing the
remote to the receiver please follow the instructions
provided with the remote/receiver system.
Information for remote syncing is on
GrandCanyonGasLogs.com
under Resorces menu, in Valve section.
INSTALLATION

87 GrandCanyonGasLogs.com [email protected]
INSTALLATION
Locate the pilot mounting bracket on the burner
system. Each Grand Canyon Gas Logs burner
style has a pilot mounting bracket designed
for easy installation and fast ignition.
NOTE: For ANY pilot assembly, ensure that one ame
of the pilot assembly is shooting towards the sensor
and the other ame is shooting to the ignition holes of
the burner. For burner systems (2-Burner, Kiva) pilot
brackets are located on the back of the burner, for
burner systems (3-Burner, Jumbo/Jumbo Slimline,
Glass) pilot brackets are located on the side of the
burner. When facing the burner, it is recommended
that the pilot and valve system be mounted
on the left side of the burner.
Refer to Fig 3, inserting the screw through the pilot
bracket, then attach the ground wire and nally
screwing the screw into the pilot assembly screw hole.
Fig. 3

9
GrandCanyonGasLogs.com [email protected]
INSTALLATION
Coil the wire using proper aluminum tube bending
techniques and insert the pilot tube are connection
into the left side of the valve. Finally locate the “S” & “I”
wires connected to the pilot assembly and insert them
into the green control module.
Locate the valve/ control module to the left side of the
burner. Then connect the 10" x ½" whistle free ex line
to the gas outlet of the valve and the gas inlet of the
burner. Using proper wrench, tighten the connections.
Using the long valve heat shield, cover the valve and
control module. This is a tight t and ensure that
none of the connections get pinched.
Run the extra length of the wiring harness behind the
burner. Then locate the battery pack/receiver on the
right-hand side of the burner. Cover the Battery pack/
receiver with the battery pack heat shield.

109 GrandCanyonGasLogs.com [email protected]
INSTALLATION
Insert the assembled burner and control system into the
replace centering the burner left to right and front to
back. With the provided ex line and brass connection
tting connect the gas inlet into the replace to the gas
inlet on the valve control system. NOTE: Make sure
the battery pack/receiver is located in the front right on
the replace. DO NOT place the battery pack/receiver
underneath the burner or in the back of the replace.
Using soapy water, spray the gas connections to ensure
there are no leaks once the gas supply is turned on.
NEVER use an open ame to check for leaks.
Follow the burner installation manual as well as the log
placement guide for nal set-up.
This includes the embers, vermiculite (LP Only),
lava rock and logs.

1211
GrandCanyonGasLogs.com [email protected]
BATTERY LIGHTING INSTRUCTIONS
FOR YOUR SAFETY, READ BEFORE LIGHTING
WARNING: Ifyoudonotfollowtheseinstructionsexactly,areorexplosionmayresultcausing
  propertydamage,personalinjuryorlossoflife.
A. Thisapplianceisequippedwithanignitiondevicethatautomaticallylightsthepilot.DONOTattempt
 tolightthepilotbyhand.
B. BEFOREOPERATING,smellallaroundtheapplianceareaforgas.Besuretosmellnexttotheoorbecausesome
 gasisheavierthanairandwillsettleontheoor.
WHAT TO DO IF YOU SMELL GAS
  •Donotlightanyappliance.
  •Donottouchanyelectricswitch;donotuseanyphoneinyourbuilding.
  •Immediatelycallyourgassupplierfromaneighbor’sphone.Followthegassupplier’s
   instructions.Ifyoucannotreachyourgassupplier,calltheredepartment.
C. Useonlytheremotetolightthepilot.Thisvalvewillnotoperateifthepilotisnotlitandstable.
D. Donotusethisapplianceifanyparthasbeenunderwater.Immediatelycallaqualiedservicetechnicianto
 inspecttheapplianceandtoreplaceanypartofthecontrolsystemandanygascontrolwhichhasbeen
 underwater.Attemptedoperationmayresultinreorexplosionresultinginpropertydamage,personalinjury
 orlossoflife.
REMOTE LIGHTING
CAUTION:DONOTattempttolightthepilotbyhand.
Note: Iftheremotedoesnotfunction,andbatterieswithanadequatepower
   levelareinstalled,refertotheTRANSMITTERFUNCTIONsection.
Note: Step1maynotberequiredifpreviouslydoneduringanearlierlighting.
1. Locatethe3-positionswitchontheremotereceiverandslidetheswitch
 totheREMOTEposition.
2. LocatetheremotetransmitterandpresstheONbutton.Theignition
 sequencewillbegin.Theremotereceiverwillemitanaudible“beep”;
 thentheigniterwillbegintospark.Afterthepilotlightsandisestablished,
 thevalvewillautomaticallyopenandtheburnerwilllight.
Note: Theignitionsequencewilltakeapproximately5seconds.
WARNING: If the pilot fails to light or if the burner fails to light
(within 5 seconds of pilot lighting), press the OFF button on
the remote transmitter and/or slide the switch to the OFF
    position.Allowve(5)minutesforanygasintheunitto
    dissipate,thenrepeatsteps1and2above.
IF YOU SMELL GAS, SEE STEP B ABOVE.
Ifthepilotfailstolightafterseveraltries,turnallcontrol/remotesystem
componentstoOFFandcontactaqualiedprofessionalservicetechnician.
SHUTTING DOWN
For remote shut down,presstheOFFbuttonontheremotetransmitter.
Ifremoteisunavailable,slidetheswitchontheremotereceivertothe
OFFposition.
PILOT APPEARANCE
Periodicallycheckthepilotforproperamepattern.Thepilotameshould
encirclethegeneratortip,andisresetatthefactory.
Ifthepilotameburnsincorrectly;shutdowncompletelyandcontacta
qualiedprofessionaltechnician.
BatteryPilot

12
GrandCanyonGasLogs.com [email protected]
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
1. Pilot will not light a Obstruction in pilot gas supply or
pilot gas-supply line is kinked
b. Inadequate gas pressure
c. Air in line
a. Clear out obstruction.
Replace pilot gas-supply line if
kinked
b. Have gas pressure checked by
installer or gas supplier
c. Air should clear; attempt to relight
2. No spark at pilot a. Loose wires
b. Dead batteries
c. Faulty remote
a. Check all wires are securely in
place
b. Replace batteries
c. Replace remote system control
appropriate
3. Pilot lights, but main
burner will not
a. Wire leads are not connected to
proper valve terminals
b. Batteries too low for voltage
output
c. Defective valve
a. Make sure all wire leads are tight
and attached to proper terminals
(see wiring diagram section pg 4)
b. Replace with new ones
c. Replace valve
4. Burner system not burning
properly
a. Low ame/uneven ame a. Check for low gas pressure;
should have operating pressures
of 5" w.c. for natural gas, 11" w.c.
for propane at manifold
5. Burner system shuts
down during operation
a. Glass doors closed, causing
excessive heat buildup
b. Pilot electrode not properly set to
pilot location
c. Heat shield not in place
a. Open glass doors
b. See INSTALL (page 8)
c. Place heat shield over valve
Battery Pack/Receiver
d. Batteries going low (cause)
e. Install new batteries (solution)
6 Intermittent ignitor spark
during use (main burner
has been burning for well
over a minute).
a. Embers covering pilot
assembly
a. Clear all foreign material from
around the pilot assembly
Periodically inspect the pilot assembly and valve controls and maintain them free of obstruction or debris. If the pilot ame is
not blue with possibly yellow tips and does not impinge on the electrodes or if the pilot does not stay lit, contact a qualied
professional service technician to service the pilot system.

13
GrandCanyonGasLogs.com [email protected] 14
Burner:
Grand Canyon Gas Logs burners carry a life time warranty
against manufacture defects or breakage as long as the appliance
is installed inside and by a professional installer. In the event a
defect or breakage occurs a replacement will be available for pick-
up from the dealer at which the burner was originally purchased.
This warranty is limited to original purchaser only. Indoor burners
installed outside carry a (1) year warranty.
Electrical and Valves:
Grand Canyon Gas Logs valves, remotes & receivers carry a (2)
year warranty against breakage or defects from date of purchase,
by original purchaser, and must be installed be a licensed profes-
sional installer. This warranty only covers use with Grand Canyon
Gas Logs burners and logs. In the event a defect or breakage
occurs a replacement will be available for pick-up from the dealer
at which the burner was originally purchased. Batteries are not
covered under this warranty. ODS pilot assemblies carry a (1)
year warranty.
WARRANTY CARD
Warranty claim
Purchased from (Showroom name)___________________________________________________________________
City _____________________________________________________________ State____________________________
Day/Month/Year ___________________________________________________________________________________
Model purchased__________________________________________________________________________________
YOUR INFORMATION
Name: ___________________________________________________________________________________________
City _____________________________________________________________ State____________________________
Phone Number____________________________________ Email ___________________________________________
Date of install_____________________________________________________________________________________
Copy & Mail to:
Grand Canyon Gas Logs
3515 E. Atlanta Ave., Phoenix, AZ 85040
WARRANTY

13 GrandCanyonGasLogs.com [email protected] 14
DO NOT RETURN TO
STORE!
STOP CALL US FIRST
For immediate help with installation, product information or
if your product arrives damaged, please call our toll free number at:
1-602-344-4217
(Monday - Friday, 8:00AM - 5:00PM, AZ Mountain Time)
or email us at:
[email protected]
OUR STAFF IS READY TO PROVIDE ASSISTANCE

All rights reserved U.S.A,
04_2022_V1
Thank you for choosing Grand Canyon Gas Logs,
we appreciate all our customers and hope you have many years of
enjoyment of our products.
Take a look at our other products
from our RPG Brands family of companies
