GRANULDISK Granule Combi User manual

Granule Combi®
User manual
Art. no. EN162080912
GRANULDISK AB retains the right to make technical changes to the products.
No responsibility is taken for any printing errors.
1. TECHNICAL DATA........................................................................................ 4
2. OPERATING INSTRUCTIONS.......................................................... 5
3. DAILY CLEANING.......................................................................................12
4. HACCP OPERATION AND HYGIENE
DOCUMENTATION...................................................................................15
5. TROUBLESHOOTING and ALARMS.....................................16
Contents
EN

2
Declaration of Conformity
The Manufacturer:
GRANULDISK AB
Jägershillgatan 15
SE-213 75 MALMÖ, Sweden
declares that the following machinery:
The GRANULDISK system Granule Combi®
Granule Combi is a unique Combi dishwasher which combines the award winning Granule Optimised
Washing Technology with the traditional dishwashing technique for plates, cutlery and most of the
crockery.
Basic conception
a) the equipement, to which the CE Mark has been affixed, complies with the Machinery Directive,
2006/42/EC.
b) is besides the provisions under a) manufactured according to the following directives: the EC Low
Voltage Directive 2006/95/EC and the EMC Directive 2004/108/EC
c) is manufactured in conformity with the following harmonised standards: EN 60204-1:2006, EN
55014-1, EN 60335-2-58, EN 60439-1, EN 55022, EN ISO 13850:2008, EN ISO 13857:2008,
EN 61000-6-3 and EN 61000-6-2
d) is manufactured in accordance with EN 1717 and fitted with a type AB back flow protection device
with airgap in accordance with EN 13077:2008.
Malmö, Sweden 29.12.2009
Signed on behalf of GRANULDISK AB
GRANULDISK AB Jägershillgatan 15
21375MALMÖ
Phone: [phone]
Fax: [phone]
...............................................
Peter Schön
President

3
To the user Safety regulations
Granule Combi is a Granule potwashing
machine – a potwashing machine for com-
mercial kitchens that is designed for wash-
ing pots and pans as well as crockery and
cutlery.
This manual is your guide for the correct
installation and use of the Granule Combi
potwashing machine.
GRANULDISK recommends that you study
the manual thoroughly to be sure that the
machine is installed and used correctly
and safely.
Ensure that the manual is always available
during the whole life of the machine.
GRANULDISK accepts no responsibility
for damage to the equipment or other
damage or injury caused by not following
the directions in this manual.
The plastic in the Granules is approved for
use in conjunction with food.
The machine uses hot water. Avoid contact
with the skin as there is a risk for scalding!
There is a risk for slipping if Granules are
left on the floor.
Formaldehyde, which is dangerous if
inhaled, may be formed if the Granules
catch fire.
Regarding the handling of detergent,
please see the detergent manufacturer’s
instructions.
Always lock the hood in its upper position
when daily cleaning is conducted.

4
1. Technical data
Weight.......................................................426 kg (filled machine), 333 kg (empty machine)
Tank volume ..............................................83 litres
Granule amount .........................................8 kg
Wash power...............................................10 % Granule concentration
Wash water temperature ............................65 °C
Rinse water temperature............................85 °C
Combi mode
Wash programmes.....................................Eco 1 min, 30 s
Short 2 min (20 sec longer with steam reduction)
Normal 2 min, 30 s (20 sec longer with steam reduction)
Rinse water volume....................................4 litres/programme
Capacity (combi mode) ..............................33 baskets/hour (500 x 500 mm)
Sound pressure level ISO 11203.................52,0 dB(A)
Pot-washing mode
Wash programmes w Granules ...................Eco 2 min, 20 s
Short 3 min, 30 s (30 sec longer with steam reduction)
Normal 5 min, 30 s (30 sec longer with steam reduction)
Wash programmes w/o Granules ................40 sec shorter than with Granules
Rinse water volume....................................4 litres/ECO programme
8 litres/short, normal programme
To achieve 3600 HUE according to NSF/ANSI 3 - 2007, 8 litres is necessary.
Capacity (pot wash) ...................................6 + 1 GN 1/1, 65 mm deep or 3 GN 1/1 200 mm and 4 GN 65 mm,
or equivalent in other items
Sound pressure level ISO 11203.................64,6 dB(A)
Loading volume .........................................190 litres (Ø 650 mm x H 570 mm)
Design ......................................................Round rotating stainless steel basket
Voltage** ..................................................400 V (standard); 3-phase, earth
230, 415 V (option); 3-phase, earth
Fuse** ......................................................400, 415 V: 25 A (cold water option 32 A)
230 V: 40 A
Frequency .................................................50 Hz
Maximum power ........................................12,6 kW (cold water option 17,6 kW)
Wash pump motor (pot wash) .....................2,6 kW
Wash pump motor (combi mode) ................0,7 kW
Rinse pump motor .....................................0,37 kW
Wash tank element*...................................9 kW (cold water option 14 kW)
Rinse tank element*...................................9 kW (cold water option 14 kW)
Encapsulation class ...................................IP55
Hot water ..................................................½” (DN15), 55-65°C, 3-7°dH
NB! Reverse osmosis water and totally softened water must not be used.
Water pressure/flow h.w. ...........................1-6 bar, 15 litres per min
Cold water.................................................½” (DN15), 3-7°dH
Water pressure / flow c.w. .........................1-6 bar, 15 litres per min (3-6 bar when option steam reduction is fitted)
Recommended ventilation capacity.............500 m3/h (without steam reduction), 150 m3/h (with steam reduction)
Outflow .....................................................Pipe Ø 32 mm
Drain.........................................................Required capacity 100 ltr/min. The machine should not be placed directly above the drain.
* Not in use simultaneously
** For specific data regarding delivered machines, please see machine rating plate
NB; The Granule Combi is supplied with a 2,5 metres electric cable to be connected to an approved main electrical switch on the wall. Main switch is not included in the delivery.

2
5
1
3
4
2. Operating
Start up
1. Empty the Granule Collector with PowerGranules
into the wash tank. Tank grid need to be taken
out (picture 1).
2. Place the two tank grids in position (picture 2).
3. Put the basket wheel in place (picture 3).
4. Close the drain valve on the right hand side of
the machine (picture 4).
5. Switch on the main electrical switch.
NB! Never place items on top of the hood.

5
6
12
3 4 5
6 7
8
6
Filling with water
1. Press the Confirm button (1) in order to fill the
wash tank.
Fill wash tank?
2. If the hood is in the raised position, it will close
automatically before starting the filling.
3. The machine will now fill with water and heat up
to the correct temperature. On the panel, the
diodes for programme selection (3-5) flash out of
sequence with the diodes for washing with or
without Granules (6-7) during filling. The following
message is displayed:
XX°C XX°C
Filling the wash
tank
4. Filling and heating take about 20 minutes (stand-
ard; hot water connection, +55°C). For optional
cold water connection (+10 to 12°C), filling and
heating take about 40 minutes. If the correct
temperature has not been attained in the wash
tank after filling, the following message is dis-
played:
50°C 60°C
Heating the
wash tank, 65 C
5. Ready to use when the correct temperature has
been attained in the wash tank. The preselected
programme is now displayed:
65°C 85°C
Eco program
with Granules
wash time: 2:20
Preparing utensils for pot-wash
Scrape or rinse off all loose food remains before loading the
utensils (picture 6).
• Nosoakingorscrubbingisneeded.
• Nousageofhand-soap(toavoidfoamingwhich
could lead to extended problem)

7
7
8
9
10 11
Loading pots- and pans
All utensils must be loaded with the inside facing
the spray pipes, thus outwards. It is important that
all items are firmly in place when being washed.
NB! Only slightly soiled trays to be placed upside
down in the bottom of the basket.
Inserting and removing the basket
The basket is loaded on an adjoining table. Press
the arrow button to open the hood. Slide the wash
basket into the machine. The basket is designed so
that you clearly feel when the basket is placed
correctly.
Check that nothing is sticking out from the basket’s
sides or bottom. Downward movement of the hood
or basket rotation must not be hindered.
See picture 7.
GD 102 Standard wash basket (19999)
It is possible to load 6 x GN 1/1 or 1/2 containers
by sliding them into the basket. Either 6 x 65 mm
deep containers or 3 x 65 mm deep containers plus
3 x deep containers. The 7th GN 1/1 container to
be placed upside down in the basket (only slightly
soiled). See Picture 7.
Possible to load 6 x GN 1/3.
Possible to load 12 x small GN containers. Choose
among GN1/4, GN 1/6, GN1/9.
See picture 8.
Possible to load 6 x ABC containers.
Picture 9.
GD 150 Multipurpose insert for GN 2/1 and
larger trays and grids (19992)
Possible to load 2 x GN 2/1. Picture 10.
Possible to load grids, chopping boards, baking
trays, flat trays and GN 1/1 lids. See picture 11.

12
13
14
15
8
GD 152 Multiflex holder (20554)
Accessory for loading 3-5 saucepans, small bowls,
sieves etc. Picture 12.
GD 750 Saucepan holder (13756)
Possible to load pots, saucepans, bowls and small-
er preperation containers. Containers from approx
60 mm to 170 mm deep can be washed.
Possible to load ladles, whisks, spatulas and similar
in the net basket in the middle of the holder.
This accessory is placed in the standard wash
basket, and fixed by small pegs in the bottom of the
basket. See Picture 13.
GD 754 Flexible pot holder (13789)
Possible to place larger pots and preparation
containers. Stretch the rubber band around the
item. Be careful when fastening and releasing the
rubber bands as the hooks may cause harm.
See picture 14.
GD 130 Folding Combi Table (19570)
Can be installed on front or on either side of the
machine. Picture 15.

9
14
17
16
12
3 4 5
6 7
8
18 Control Panel
1. Confirm button is used to answer “yes” to a
question shown in the display window.
2. STOP button is used to stop all ongoing activities
in the machine and to reset alarms.
3. Start Eco programme
4. Start Short programme
5. Start Normal programme
6. Washing with Granules
7. Washing without Granules
8. Hood up and down
Loading of crockery and cutlery
1. Place the items to be washed in a wash basket.
2. Rinse off any remaining bits of food.
3. Press the arrow button to open the hood.
4. Push the wash basket into position in the machine.
The basket wheel is designed so that you feel when
the basket is positioned correctly.
NB! When washing glasses, an insert must be used
to separate the glasses.
See picture 16.
GD 657 Standard wash basket (19882)
Wash basket for plates and crockery, 500x500 mm
Capacity: 18 dinner plates or 12 soup plates.
See picture 17.

19
10
Start and Operation
1. Press the Confirm button (1)
• Iftemperatureislowerthan65°Cinwashtank
at the time of the first start, once the wash
tank has been filled, the machine will continue
heating.
• Washingattoolowtemperatureincreasesthe
risk of foaming and the items not being hygi-
enically clean.
• Reprogrammingmaybecarriedoutbyauthor-
ised personnel only.
2. When a programme is chosen, a 10 seconds
detection phase will follow while the machine
determines which type of wash basket has been
placed in the machine. This is done automatically
and does not require the operator to decide
whether to run a programme in combi or pot-
wash mode.
3. For pot-washing, select washing with or without
Granules (6) or (7). For slightly soiled pans or
specific items with Granule “traps” (i.e perforated
containers), choose without Granules. Normal to
heavily soiled pots and pans, choose the power-
ful Granule cycles to blast the utensils clean.
4. Select required wash time ECO (3), short (4) or
normal (5)
Eco 2 min 20 s (with Granules),
1 min 40 s (without Granules)
Short 3 min, 30 s (with Granules),
2 min, 50 s (without Granules)
+ 30 sec with optional steamreduction
Normal 5 min, 30 s (with Granules),
4 min, 50 s (without Granules)
+ 30 sec with optional steamreduction
5. When the light goes out, the wash programme is
complete and the hood rises automatically. The
display now shows the last programme run, e.g.
Blinking!
6. Close the hood by pressing button (8) if you are
not running another wash programme straight
away. It saves energy and reduces evaporation
from the wash tank.
7. For combi-mode, select desired length of pro-
gramme by pressing ECO (3), short (4) or normal
(5) buttons.
Eco 1 min 30 s
Short 2 min
+ 20 sec with optional steamreduction
Normal 2 min, 30 s
+ 20 sec with optional steamreduction
This will automatically start the chosen pro-
gramme. When the light goes out, the wash
programme is complete and the hood rises
automatically. Please see no 6. above for further
instructions.
Stopping the machine while in operation
• Switchtowashingwithwater(6)forabout30
seconds in order to rinse off all Granules. Then
press STOP (2)
• Inemergency;JustpressSTOP(2)
NB! Utensils may have remains of detergent and
should be washed again before they are taken out
of the machine. Never drain an emergency stopped
machine! (Granules left in the pump without water
will jam the pump impeller.)
Inspecting the pots and pans
• Visiblycheckthepotsandpansaftereach
programme.
• TomakesurenoGranulesareleft.Pleaseturnall
washware (baskets, pans etc) upside down,
before taking out the items from the machine.
• RemoveanyGranulesthatmaybestuckin
corners, sharp angles and other inaccessible
places (Picture 19).
65°C 85°C
Eco program
with Granules
Time remaining: 2:10
65°C 85°C
Eco program
with Granules
wash time: 2:20
62°C 59°C
Heating the
wash tank, 65°C

11
12
3 4 5
6 7
8
20 PowerGranules
• SpeciallydesignedtoworkwithGranulePot-and
pan washing machines from GRANULDISK.
• Ensurethebestwashresultaswellasthelong-
est working life both for themselves and the
machine.
• WarrantyonlyappliesifPowerGranulesfrom
GRANULDISK are used in the machine.
• Theplasticmaterialisapprovedforusein
conjunction with food.
• Forspotlesscleanresult,pleasecontrolthe
recommended level (8 kg) of Granules every day
when collecting the PowerGranules. Top up with
PowerGranules if the level goes under the
8 kg mark.
• Pleasefollowtherecommendedexchangeof
PowerGranules communicated by the GD Memo™
(message in display occurs every 2500 Granule
cycle).
• WornoutGranulesshouldbehandledascombus-
tible material.
Language selection
To change the language settings;
1. Press the STOP button, release it and wait for 3
seconds.
2. Press the (4) “short programme” button, five
times.
3. The display shows the following;
4. Press the Confirm button (1) for “select”.
5. Scroll using the buttons for eco (3) or normal (5)
programme, to step through the list of languages.
6. Select a language by pressing the Confirm button
(1); OK.
7. Press STOP button (2) to quit programming
mode.
Language
English
Select Back
Language
< English >
OK Cancel

12
21
23
24
22
12
3. Daily cleaning
A. Collecting and cleaning PowerGranules
using the Granule Collector
1. Use the Granule collector
2. Place the Granule collector on the basket wheel
(picture 21). It is important to place the collector
as closely to the hood as possible.
3. Close the hood and start the special Granule
collecting programme, as described below.
Granule Collecting Programme;
•FirstpresstheSTOPbutton(2)
•PressShortprogramme(4)andGranulepro-
gramme (6) buttons at the same time for 3
seconds.
4. Take out the filled Granule collector and flush
(shower) the Granules with clean water thoroughly.
Make sure no food remains are left.
5. Check the Granule level against the marker for 8
kg in the Granule collector. (picture 22)
6. Top up with new Granules if needed.
NB. Too many or too few Granules will impair wash
results. Too many can also cause blocking of the
spray nozzles.
NB. Do not use disinfectant or other cleaning
products when cleaning the Granules. The residue
from these products will cause foaming in the
machine with poor wash result as a consequence.
B. Cleaning inside the tank
1. Press STOP button (2) and open drain valve to
empty wash tank. See picture 23.
2. Secure the hood in it’s upper position (picture 29).
3. Switch off at the main electrical switch.
4. Lift out the basket wheel. Then lift out the two
tank grids. Clean and flush the parts with water.
See picture 24.
5. Flush the inside of the tank with clean water.

13
26
25
27
AB
28
6. Clean and flush Granule damper with water
(picture 25). Clean the perforated surface of the
Granule damper to ensure that there are no
Granules left there.
7. Check that the sealing strip for the Granule
damper is undamaged.
8. Clean and flush bottom sieve (A) with water. To
make cleaning easier, bottom sieve can be
unscrewed (picture 26).
9. Wipe off level sensor (B) (Picture 26).
10. Wipe grease off hood seals.
11. Check that the rollers supporting basket wheel
rotate freely.
12. Check the operation of the tap on the overflow
drain. Clean if required. Picture 27.
13. The top should be wiped off as required or at
least once a month.
14. The sieve for the Combi-pump at the bottom of
the wash tank has to be cleaned once a month.
Use a washing-up brush or equivalent to brush
away any dirt that may have been building up in
front of the sieve. Then flush with water.
Picture 28.
NB! The outside of the machine must not be washed
with high-pressure water.
C. Replacement of cleaned items
1. Replace all items
• Putbackbottomsieveifithasbeenunscrewed.
• Putbacktankgrids.
• Putbackbasketwheel.

14
12
3 4 5
6 7
8
29
14
D. Over night and at longer stoppages
• Ensurethatwashtankiscompletelyemptyafter
cleaning.
• Anywaterremaininginthebottomshouldbe
removed with a sponge or similar absorbent.
• Raisehoodtoitshighestpositionandpreventit
from descending with the peg provided (picture
29). Leave peg there as long as the machine is
shut down.
• PowerGranulesshouldbestoredinGranule
collector standing in the machine.
• Afteralongstoppage;checkoperationofthe
machine according to service manual, possibly
with the assistance of a service engineer.
E. GD Memo™
GD Memo is an integrated function which informs
the user of the machine’s most important
maintenance requirements.
1.Time to change wash water
“Washing without Granules” button (7) flashes and
the message “change water” is shown in the
display. The message disappears once the water
has been changed or can be reset by pressing
STOP button (2) and release. Then wait 5 sec and
press the “without Granules” button (7) five times.
This reminder appears after every 25 wash cycles.
2.Time to change PowerGranules
“Washing with Granules” button (6) flashes and the
message “change Granules” is shown in the display.
This information disappears once the Granules have
been changed and this has been acknowledged by
pressing the STOP button (2) and release. Then
wait 5 sec and press the “washing with Granules”
button (6) nine times and the short programme
button (4) once. A Granule change reminder ap-
pears after every 2500 wash cycles.
3.Time for service
The STOP button (2) flashes and the message
“service” is shown in the display. This information
can only be reset by an authorised service
engineer once a maintenance service has been
completed. A service reminder appears after
every 8000 programmes or once a year.

15
4. HACCP Hygiene and Operation Documentation
GRANULDISK Documentation Tool, GDTdirect™, is
an integrated function for the documentation of the
dishwashing machine’s operating parameters and
critical hygiene control points, HACCP.
• OperatingDataforthelast100washpro-
grammes run can be viewed directly in the
control panel window.
• Anexternalcomputercanbelinkedtothema-
chine and operating data stored in separate files
so that all historical data can be saved. Windows
2000 or Windows XP is a system requirement for
connecting an external computer. Please contact
your dealer for more information and installation.
Reading the Data through the control panel
1. Press STOP button (2), release it and wait 3
seconds.
2. Press “short programme” (4), five times.
3. Use button “eco programme” (3) or button
“normal programme (5) until you see “read
operating data” in the display. Confirm your
choice by pressing Confirm button (1).
4. Operating data for the last programme run is
shown in the display;
090121 15:19 SG 65/85 OK
The information is defined as follows;
• Date;090121 2009,January,21st
• Time;15.19 3.19p.m
• Programmetype;E,S,NequivalenttoECO,
Short and Normal programmes.
• Forcombimodetheprogrammesareindicated
by CE, CS and CN, for combi ECO, combi Short
and combi Normal.
• WashingwithGranules;indicatedbymeansof
a “G”, otherwise this box is left blank.
• 65;indicatestheaveragetemperatureinthe
wash tank during washing.
• 85;indicatesminimumtemperatureintherinse
tank during rinsing.
• OK;indicatesthattherinsewatervolumeis
correct in accordance with factory values; if
the set values have been changed, NA (not
applicable) is displayed.
NB! If the wash programme has been cancelled due
to an operating error or technical error, the tem-
perature indication is not included and “error” plus
an error code appears in its place.
090121 15:19 SG Error 103
5. To view information on programme run previ-
ously, scroll backwards and forwards in the list
using button “eco programme” (3) or button
“normal programme” (5).
6. To end scrolling and leave the list, press Confirm
button (1).
7. Press the STOP button (2) to return to operating
mode.

16
5. Troubleshooting and alarms
The meaning of the error codes can be read out from the table below.
• Errorcode100,109,116,118,132arealsodisplayedwithanErrormessagetextshownintheMeaning
column.
• Whenanerrorcodeisdisplayed,theprogramisalwayscancelled.
• Aftercheckingandtakingcareoftheproblem,the alarm can be reset by pressing the STOP-button.
Error code Meaning Cause Remedy
001 Programme cancelled by operator This error code is displayed only when
operating data is read in GDTdirect™ 3.x.
101 Motor circuit breaker for
wash pump tripped
The motor is overloaded Contact a service engineer!
102 Motor circuit breaker for
combi pump tripped
The motor is overloaded Contact a service engineer!
103 Motor circuit breaker for
rinse pump tripped
The motor is overloaded Contact a service engineer!
104 Overheating protector for
rinse tank tripped
The rinse tank heater element has
overheated
Contact a service engineer!
105 Overheating protector for
wash tank tripped out
The wash tank heater element has
overheated
Contact a service engineer!
106 Overheating protector for
one of the heater elements
tripped out
One of the heater elements has
overheated
Contact a service engineer!
107 Temperature not reached in
wash tank
The wash water in the wash tank
does not reach its preset tempera-
ture quickly enough after the filling
process.
Reset the alarm by pressing the STOP
button. If the alarm recurs, contact a
service engineer!
108 Temperature not reached in
rinse tank
The rinse water in the rinse tank
does not reach its preset tempera-
ture during the wash process
Reset the alarm by pressing the STOP
button. If the alarm recurs, contact a
service engineer!
110 Temperature sensor in wash
tank or rinse tank non
operational. Most probably
in wash tank.
The temperature sensor in the
wash tank or rinse tank is broken.
Most probably in wash tank.
Contact a service engineer!
111 Temperature sensor in wash
tank or rinse tank non
operational. Most probably
in rinse tank.
The temperature sensor in the
wash tank or rinse tank is broken.
Most probably in rinse tank.
Contact a service engineer!
112 Water level too low in rinse
tank
The level in the rinse tank has
fallen erroneously.
Contact a service engineer!
113 Water level too low in wash
tank
The level in the wash tank has
fallen erroneously.
Contact a service engineer!
114 Long wash tank filling time Wash tank filling time exceeded 20
minutes.
Check the water supply to the machine. Reset
the alarm by pressing the STOP button.
Contact a service engineer if problem persist.
115 Long rinse tank filling time Rinse tank filling time exceeded 5
minutes.
Check the water supply to the machine. Reset
the alarm by pressing the STOP button.
Contact a service engineer if problem persist.
116 Low water level, problem
with foam
Foam forming in the machine Detergent designed for washing up by hand
must not be used. Change the wash water.
Contact your detergent supplier if you still the
problems with foam formation persist. Reset
the alarm by pressing the STOP button.
117 Long rinse time Too long rinse time. The correct
rinse volume is not reached in
time.
Contact a service engineer!

17
Error code Meaning Cause Remedy
118 Drain valve not closed The drain valve was opened during
all modes except stop mode.
Close the drain valve. Reset the alarm by
pressing the STOP button.
120 Basket drive shaft stuck The basket is prevented from
rotating, the program is inter-
rupted and the hood raised.
Check that nothing is stuck between the
basket and the basket wheel.
121 Motor circuit breaker for
booster pump tripped
The motor is overloaded, the
programme is cancelled.
Contact a service engineer!
122 Incorrect downwards hood
movement
The hood was not closed within 25
seconds.
Contact a service engineer!
123 Incorrect upwards hood
movement
The hood was not opened within
20 seconds.
Check the incoming water. Reset the alarm
by pressing the STOP button. If the alarm
recurs, contact service personnel.
124 The crush protection has
been activated.
Something is preventing the hood
from moving down. The hood is
opened.
Remove whatever is obstructing the hood
movement. Reset by pressing the STOP
button.
125 Incorrect hood movement,
safety sensor
The safety switch has not given the
correct signal within 5 seconds of
the hood being raised.
Contact a service engineer!
126 The crush protection
function is faulty
The crush protection is not
working correctly.
Contact a service engineer!
127 The safety switch is faulty The safety switch is not working
correctly.
Contact a service engineer!
128, 129,
130, 131
System error, control card
non operational
A control card component is
broken.
Contact a service engineer!
132 Clean Level sensor The level sensor in wash tank may
be dirty, or water in wash tank have
not been totally drained at start up if
the machine has been shut down for
more than 4 hours.
Empty the wash tank and clean the level
sensor in the wash tank. Reset the alarm by
pressing the STOP button.
140 One of the temperature
sensors has returned a
false reading
One of the temperature sensors
may be broken.
Cut the power to the machine completely by
switching the machine off at the wall socket.
Wait 30 seconds. Switch the power back on.
If the fault recurs, repeat the procedure
once again. If the fault persists, contact
service and ask them to replace one of the
temperature sensors.
142 Basket sensor indicating
error
Basket sensor that detects type of
basket is indicating error.
Remove wash basket and run a programme.
Place empty pot washing basket (round) in the
machine and start a programme. If the
programme does not start, please contact
service personnel.
You can run the machine in Pot Washing mode
while waiting for service. In Standby mode
press a program button and Granule button
together for 2 seconds (for Granule wash),
and programme button and water
button (for water wash only). Please read
instruction regarding glass breakage before
performing this operation (page 18).

18
Course of actions when finding
shattered glass in a Granule Combi
1. Equipment:
• Thickprotectivegloves
• Vacuumcleanerfor water
2. Please follow these steps in this particular order:
• Shutmachineoff,leavehoodintoppositionand
insert the peg
• Drainwaterfrommachinebyopeningthedrain
valve
• Removebasketandbasketdriveringfromthe
machine
• PUT THE PROTECTION GLOVES ON
• Removethespraynozzlesandcleanthemfrom
any glass
• Removeshatteredglassfromthebottomgrids
• Removethebottomgrids
• Removelargerpiecesofglassbyhand
• Use the vacuum cleaner to remove Granules
and remaining small pieces of glass
• Shut the drain valve and fill the machine
with water again
• RunaprogramwithoutGranules
• Drainthemachineagain
• Checkwashpipesoncemoreandremoveany
remaining glass
• Refit the wash nozzles
• Checkwashtankforanyremainingglassand
remove by either hand or vacuum cleaner
• Refitbottomgrids
• AddNEW Granules (8 kg) and fill the machine
again
The machine is now ready to be used again.
3. IMPORTANT
• NEVERallowglassand/orporcelaintobe
washed in pot wash mode
• Shatteredglassisverysharpandcaneasily
damage both the machine and people –
HANDLE WITH CARE!
• Granulesmixedwithshatteredglassmightbe
handled as combustible material – HANDLE
WITH CARE!

19
Granule Combi®
COMBI mode
Operation / Opération / Start und Betrieb / Funzionamento
+3 sec.
AB
Art.nr: 20795 Rev.Date: 2009-05-01 BA
xxx?
1
1
2
GRANULDISK
Jägershillgatan 15
SE-213 75 MALMÖ
Sweden
Tel: [phone]
Fax: [phone]
[e-mail]
www.granuldisk.com
C

2020
Notes
