GRASS VALLEY DMC 1000 User manual

3922 496 30601 March 2010 v4.0
DMC 1000
User’s Guide
Digital Media Camcorder
Software version 12.4

Declaration of Conformity
We, Grass Valley Nederland B.V., Kapittelweg 10, 4827 HG Breda, The
Netherlands, declare under our sole responsibility that this product is in
compliance with the following standards:
- EN60065 : Safety
- EN55103-1: EMC (Emission)
- EN55103-2: EMC (Immunity)
following the provisions of:
a. the Low Voltage directive 2006/95/EC
b. the EMC directive 2004/108/EC
FCC Class A Statement
This product generates, uses, and can radiate radio frequency energy and if
not installed and used in accordance with the instructions, may cause
interference to radio communications.
It has been tested and found to comply with the limits for a class A digital
device pursuant to part 15 of the FCC rules, which are designed to provide
reasonable protection against such interference when operated in a
commercial environment.
Operation of this product in a residential area is likely to cause interference in
which case the user at his own expense will be required to take whatever
measures may be required to correct the interference.
Copyright
Copyright Grass Valley Nederland B.V. 2010. Copying of this document and
giving it to others, and the use or communication of the contents thereof, are
forbidden without express authority. Offenders are liable to the payment of
damages. All rights are reserved in the event of the grant of a patent or the
registration of a utility model or design. Liable to technical alterations in the
course of further development.
Trademarks
Grass Valley and Infinity are trademarks of Grass Valley, Inc. All other
tradenames referenced are service marks, trademarks, or registered
trademarks of their respective companies.
Website
Visit the Grass Valley public website to download the latest user’s guide
updates and additional information about your broadcast product:
www.grassvalley.com

DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 3
Table of contents
Chapter 1 – Introduction
1.1 About this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.2 Technology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
1.2.1 Xensium™ imager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.2.2 Advanced camcorder technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.2.3 IT-based recording media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.2.4 On-board selectable compression . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.2.5 Ultimate connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.2.6 User interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.2.7 Enhancing your workflows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.3 Key features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
1.4 Infinity type numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
1.5 Quick reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
1.6 User’s guide overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Chapter 2 – Attaching parts
2.1 Mounting a lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.2 Viewfinder (2-inch) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.2.1 Mounting the viewfinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.2.2 Positioning the viewfinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.2.3 Mounting a wide angle eyepiece. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
2.3 Mounting a microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
2.4 Attaching a battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
2.5 Adjusting the shoulder pad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
2.6 Attaching a carrying strap. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
2.7 Mounting a top light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
2.8 Wireless microphone receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
2.9 Tripod adapter plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
2.10 Anchoring the camcorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Chapter 3 – General set-up
3.1 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.1.1 Battery supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.1.2 External power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3.1.3 Power switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3.2 Using the side panel display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3.3 Push buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
3.4 Assignable buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
3.4.1 Operation panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
3.4.2 Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
3.4.3 Carrying handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3.5 Lens settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

4DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
3.6 Viewfinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
3.6.1 Viewfinder set-up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
3.6.2 Viewfinder markers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
3.6.3 Viewfinder LED indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
3.6.4 Viewfinder on-screen display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
3.7 Side panel home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
3.7.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
3.7.2 Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
3.8 Camera status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
3.9 Lights and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
3.9.1 Tally indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
3.9.2 Media indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
3.10 Playback indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
3.11 Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
3.11.1 Video monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
3.11.2 External SDI signal monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
3.11.3 Audio monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
3.12 Time and date settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Chapter 4 – Menu navigation
4.1 Menu navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
4.2 User levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
4.3 Side panel menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
4.3.1 Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
4.3.2 Side panel menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
4.3.3 Function buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
4.3.4 Menu structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
4.4 Viewfinder menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
4.4.1 Viewfinder menu structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
4.4.2 Entering the viewfinder menu system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
4.4.3 Finding your way . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
4.4.4 Leaving the viewfinder menu system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
4.4.5 Making changes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
4.4.6 Undoing changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
4.5 User files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
4.5.1 Scene files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
4.5.2 Production files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
4.5.3 Lens files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
4.5.4 Operator files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Chapter 5 – Video setup
5.1 Input and output connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
5.1.1 Digital connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
5.1.2 Analog connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
5.2 Colour bars . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
5.3 Standard video settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
5.4 Gain selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
5.5 Working with optical filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69

DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 5
5.6 Colour temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
5.6.1 Presets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
5.6.2 Memory positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
5.6.3 Continuous white balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
5.6.4 Selecting the color temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
5.7 Auto white balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
5.8 Exposure time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
5.9 Contrast button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
5.10 Video menu adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
5.10.1 Detail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
5.10.2 Skin detail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
5.10.3 Knee. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
5.10.4 Gamma . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
5.10.5 Matrix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
5.10.6 Color saturation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Chapter 6 – Audio setup
6.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81
6.2 Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
6.2.1 Front microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
6.2.2 Rear line or microphone inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
6.2.3 Digital audio sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
6.2.4 Wireless microphone (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
6.2.5 Audio mixer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
6.2.6 Gain settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
6.3 Recording audio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
6.3.1 Select source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
6.3.2 Set recording levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
6.4 Audio monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
6.5 Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
6.5.1 Rear outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
6.5.2 Digital audio outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
6.5.3 SDI embedded audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
6.6 General audio settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
6.6.1 Audio Headroom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
6.6.2 Test tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
6.7 Intercom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
6.7.1 Audio connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
6.7.2 Intercom channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
6.7.3 Talk buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
6.7.4 Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
6.7.5 Return channels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
6.7.6 Incoming channels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
6.7.7 Intercom routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
Chapter 7 – Recording setup
7.1 Main format settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
7.1.1 Video standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
7.1.2 Recording compression . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
7.1.3 Recording from external video sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
7.2 Time code settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
7.3 Genlock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

6DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
7.4 Recording buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
7.5 Recording media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
7.5.1 REV PRO media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
7.5.2 CompactFlash cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
7.5.3 External USB media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
7.6 Systemized configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100
7.6.1 Basic configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100
7.6.2 Network configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100
7.6.3 Network setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
7.6.4 User level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
7.6.5 Intercom. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
7.6.6 Remote Tally and ISO recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
7.6.7 Remote recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Chapter 8 – Shooting
8.1 Getting a picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
8.1.1 Viewfinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
8.1.2 Recall standard video values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
8.1.3 Exposure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
8.1.4 Video adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
8.1.5 Audio adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
8.1.6 Frame and focus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
8.2 Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
8.2.1 Start recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
8.2.2 Stop recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
8.3 Quick review. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
Chapter 9 – Clip management
9.1 Thumbnails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
9.1.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
9.1.2 Thumbnail information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108
9.2 Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
9.2.1 Playback monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
9.2.2 Transport buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
9.2.3 Menu button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
Chapter 10 – Communications
10.1 Setting up communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
10.2 USB connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
10.3 Ethernet connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
10.4 IEEE 1394 connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
10.5 FTP connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
Chapter 11 – Specifications
11.1 Specifications for DMC 1000. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115

DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 7
11.2 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
11.2.1 Audio input connectors (Rear1 and Rear2) . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
11.2.2 Audio output connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
11.2.3 Front microphone connector (Front1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
11.2.4 Front microphone connector (Front1 and Front2) . . . . . . . . . . . . . . . . . . . . . . 117
11.2.5 Headphones output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
11.2.6 Headset microphone input (MicRear) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
11.2.7 Power input connector (DC in). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
11.2.8 Accessory output connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
11.3 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
11.4 Compression profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
11.4.1 JPEG 2000 profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
11.4.2 DV25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
11.4.3 1080P JPEG 2000 profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
11.4.4 MPEG-2 I-frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
11.4.5 1080P MPEG-2 I-frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122
11.4.6 MPEG-2 D10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
11.4.7 1080P MPEG-2 Long GoP (closed GoP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
11.4.8 1080i MPEG-2 Long GoP (closed GoP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
11.4.9 720P MPEG-2 Long GoP (closed GoP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Chapter 12 – Side panel menu
12.1 Audio menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
12.2 Video menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
12.3 Setup menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
12.4 System menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Chapter 13 – Viewfinder menu
13.1 VF menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
13.2 Video menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
13.3 Setup menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
13.4 Audio menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
13.5 System menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Chapter 14 – Maintenance
14.1 Updating software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
14.1.1 Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
14.1.2 Update procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
14.2 Licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
14.2.1 Obtaining a license . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
14.2.2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
14.3 Black calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
14.4 Touch screen calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
14.5 Cleaning the touch screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174
14.6 Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
14.7 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .176

8DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
End-of-life product recycling
Grass Valley’s innovation and excellence in product design also extends to the programs we’ve
established to manage the recycling of our products. Grass Valley has developed a
comprehensive end-of-life product take back program for recycle or disposal of end-of-life
products. Our program meets the requirements of the European Union’s WEEE Directive and
in the United States the requirements of the Environmental Protection Agency, individual state
agencies or local agencies.
Grass Valley’s end-of-life product take-back program assures proper disposal by use of Best
Available Technology. This program accepts any Grass Valley branded equipment. Upon
request, a Certificate of Recycling or a Certificate of Destruction, depending on the ultimate
disposition of the product, can be sent to the requester.
Grass Valley will be responsible for all costs associated with recycling and disposal, including
freight, however you are responsible for the removal of the equipment from your facility and
packing the equipment ready for pickup.
For further information on the Grass Valley product take back system please contact Grass
Valley at + 800 80 80 20 20 or [phone] from most other countries. In the US and
Canada please call 800-547-8949 or 530-478-4148. Ask to be connected to the EH&S
Department. In addition, information concerning the program can be found at:
www.grassvalley.com/environment
Software licenses for this product
The Infinity Digital Media Camcorder incorporates software code that is licensed under the
GNU General Public License (GPL) and the GNU Lesser General Public License (LGPL). Under
these licenses customers have the right to obtain, modify, and redistribute the relevant source
code. You can find the relevant source code packages at:
www.technicolor.com/open-software
You can also obtain a copy of the source code from Technicolor on CD-ROM. A fee for
creation, handling and postage will be charged. To request a CD-ROM with the source code,
send an e-mail to [e-mail]
The Infinity Digital Media Camcorder incorporates software code that is licensed under the
MIT license. The Infinity Digital Media Camcorder incorporates software code that is licensed
under the Modified BSD license.The text of these licenses is available at:
www.technicolor.com/open-software
The Infinity Digital Media Camcorder incorporates Info-ZIP (Copyright 1990-2007 Info-ZIP. All
rights reserved.) The full text of this license is available at:
www.info-zip.org/license.html

DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 9
Warnings
To prevent fire or shock hazard, do not expose the camcorder to rain or moisture and avoid
using it in humid or damp places.
To avoid electrical shock, do not remove covers or panels. Refer servicing to qualified
personnel only.
To prevent risk of overheating, ventilate the unit correctly. Do not cover air vents with stickers
or attachments.
In case of an emergency ensure that the battery pack and the external power supply are
disconnected.
Connect the camcorder to a power source with the specified voltage rating.
When using an external power supply it must be connected to earth potential.

10 DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
Cautions
To ensure continuous high performance from the camcorder take the following cautions into
consideration:
• Refer mounting and installation of optional boards to qualified service personnel.
• Use recommended accessories only.
• Do not subject the camcorder to severe shocks or vibration.
• Do not expose the camcorder to extreme temperatures.
• Do not leave the camcorder in direct sunlight or close to heating appliances for extended
periods.
• Do not allow sunlight to shine directly into the viewfinder.
• Avoid extreme highlights as these can cause various kinds of optical reflections.
• Do not allow laser beams to shine into the lens as this could damage the imagers.
• Always turn off power after use.
• Remove the media before storing the camcorder for an extended period.
• Clean the camcorder and its attachments regularly, especially contact areas such as the
touch screen and hand grip. For cleaning the touch screen refer to the maintenance
section.
Internal batteries
• To avoid the risk of explosion always replace the battery with a correct type.
• Dispose of used batteries according to the instructions of the manufacturer of the battery.
• Remove the battery before storing the camcorder for an extended period.
Tripod installation
• This camcorder can be mounted on a tripod. For safe installation and operation of the
tripod refer to the manufacturer’s documentation.
• The typical configuration for this camcorder (camera with a standard HD lens, 2-inch
viewfinder, battery and a top light mounted, total weight 10.2 kg (22.5 lbs) has proved to
be stable when used on a tripod with the following specifications: height 1.45 m (57 in),
leg distance at floor level of 0.80 m (31.5 in).These values are recommendations only.
Always check the mechanical stability of the unit before using it.

DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 11
Attention
About the Xensium imager
• The Xensium imager used in the Infinity camcorder is equipped with an electronic rolling
shutter. When shooting under (artificial) low-frequent fluorescent lighting conditions the
image may be affected by intensity variations.
About the side panel display
• The camcorder’s side panel display is a TFT display that is manufactured using high
precision technology that yields a quality of 99.99% or higher. However, it is possible that
one or more pixels may constantly display a single color or be permanently off. This does
not indicate a defective display and your recorded data is not affected.
• Exposing the display to direct sunlight or very bright light sources for extended periods
may damage the unit. It is recommended that you close the display with the screen facing
the camcorder body when not using it.
About REV PRO disks
• When a REV PRO disk is not in use, always store it in its protective case.
• Avoid handling the disk by the front edge (the edge that inserts into the drive).
• If you suspect a disk is defective, replace it immediately. Do not continue to use it as this
could damage the drive.
• If a disk is difficult to insert, make sure that the logo is facing away from the camcorder
and try again. Never force a disk into or out of the REV PRO drive; this could damage the
drive and the disk.
• Avoid exposing REV PRO disks to direct sunlight, extreme temperatures or moisture.
• Avoid exposing REV PRO disks to strong magnetic fields such as those produced by
monitors or speakers.
• Avoid dropping a REV PRO disk. This could cause damage to the disk.

12 DMC 1000 Digital Media Camcorder User’s Guide (v4.0)

DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 13
Chapter 1 - Introduction
Chapter 1
Introduction
1.1 About this guide
The purpose of this user’s guide is to present a detailed functional description of the Infinity
DMC 1000 camcorder. It provides the necessary information to use the camcorder in different
configurations and in various workflows. The guide is so designed that it can be used as an
introduction to those who are new to the camcorder, as a simple procedural guide to those
who wish to setup and start shooting immediately, and as a reference work.
☞Note ☞Note
This user’s guide describes the functionality of the camcorder based on Software version 12.4.
When your camcorder is not updated to this version, refer to section 14.1 on page 167 for
information about updating your camcorder.
1.2 Technology
The Grass Valley™ Infinity™ Digital Media Camcorder signifies a revolutionary step in ENG and
EFP acquisition — combining the best of Grass Valley’s multiple Emmy® award-winning
camcorder engineering with leading IT recording and connectivity technologies. This
camcorder is part of the Infinity Series line of products — designed from the ground up to
bring all the benefits of advanced technologies to the broadcast and production industries. This
line represents the current and future approach to acquisition and recording, delivering
affordable, open and truly flexible systems.
• HD/SD multi-format support including 1080i50/59.94, 1080p23.98/25/29.97 (optional),
720p50/59.94, 576i50 and 480i59.94.
• Flexible video encoding/decoding options, including JPEG2000, DV and MPEG-2 and D10
(optional).
• Choice of removable recording/playback media including integrated Grass Valley
REV PRO™ and CompactFlash® slots.
• Video, audio and metadata content are written in the open OP-1A MXF-based wrapper.
• Traditional inputs and outputs.
• Supports multiple IT-based interfaces: USB 2.0, IEEE 1394 and Gigabit Ethernet.

14 DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
Chapter 1 - Introduction
1.2.1 Xensium™ imager
The Infinity Digital Media Camcorder uses the Grass Valley Xensium imagers which offer a
wider dynamic range and improved signal-to-noise performance when compared to other
CMOS imagers.
The imaging chips are at the heart of professional camera design, and Grass Valley has
continually worked to achieve high resolution, wide contrast handling and low noise. Coupled
with Grass Valley's broad spectrum digital signal processing it is set to deliver remarkable
pictures in uncompromised HD resolutions.
1.2.2 Advanced camcorder technology
The Infinity Digital Media Camcorder provides a choice of video formats and standards
selectable within the camcorder. You can choose from 576i50, 480i59.94, 1080i50,
1080i59.94, 720p50, 720p59.94. Additionally, video formats 1080p23.98, 1080p25,
1080p29.97 are available as a cost-option. Standard-definition (SD) formats are selectable in
either 16:9, 4:3 or letterbox aspect ratios. This makes the camcorder ideal for multi-format
acquisition and for straightforward migration from standard definition (SD) to high definition
(HD) within your workflow. The camcorder provides digital imaging for crystal-clear quality with
advanced 22-bit accurate video processing for image control.
1.2.3 IT-based recording media
The Infinity Digital Media Camcorder uses off-the-shelf REV PRO removable disks and
professional-grade CompactFlash solid-state memory as recording and playback media. The
extremely durable REV PRO removable disks provide the portability, and cost-effectiveness of
videotape with the speed, flexibility, and ease-of-use of true nonlinear media such as hard
disks.
Professional-grade CompactFlash memory is a commercially available solid-state technology
that delivers the high level of performance needed for demanding professional video
applications. These cards are small, lightweight and extremely durable. Professional-grade
CompactFlash cards currently hold up to 32 GB with sufficient throughput for both SD and HD
recording, playback and ingest.
Both REV PRO and CompactFlash media offer unprecedented advantages in terms of usability,
price and performance. They offer many additional benefits for video professionals such as
nonlinear random access to video files and non-degrading archival storage.
1.2.4 On-board selectable compression
Infinity Series products provide you a choice of compression schemes and bit rates, giving you
the option to select what is best for your workflow today and in the future. The Infinity Digital
Media Camcorder supports JPEG2000, DV and D10 and MPEG-2 (optional) compression,
assignable via the camcorder’s user interface.
The DV codec is 25 Mb/s 4:2:0 (PAL) or 4:1:1 (NTSC), making it ideal for immediate use in your
workflow today.
JPEG2000 compression can be used for both SD and HD acquisition. It provides high-
efficiency compression, 10-bit 4:2:2 encoding and no blocking artifacts —and is fully scalable.
Industry-standard MPEG-2 compression is available as an option and can be used for a variety
of HD compression profiles, including I-frame and Long GoP.

DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 15
Chapter 1 - Introduction
1.2.5 Ultimate connectivity
The Infinity Digital Media Camcorder connects using both traditional and IT interfaces.
Traditional inputs and outputs include BNC connectors for (HD-)SDI, CVBS, Time Code, AES
digital audio and XLRs for analog audio. The camcorder comes with three USB 2.0 connectors
(two hosts and one device), one IEEE 1394 connector and a HDMI display connector. It can
also connect to an external storage device (such as a hard drive or flash memory stick) via
USB. The Gigabit Ethernet port provides compatibility with the C2IP camera control system.
1.2.6 User interface
Camcorder operators can manipulate the camcorder through traditional controls for standard
operation and through a touch screen display. The built-in user interface supports video
monitoring, clip management, audio setup and metering, and detailed camcorder
configuration.
You can also use the LCP 400 wireless application to control the camcorder. Running on a
Windows Mobile PDA or TouchPhone, it gives you access to all camera menus and settings —
and lets you change them while shooting. It displays audio levels and, thanks to its low
latency, lets you make critical adjustments to e.g. audio parameters. You can create and edit
metadata such as names, dates, slugs, locations and even camera settings before, during or
after recording.
1.2.7 Enhancing your workflows
The Infinity Digital Media Camcorder enhances your existing workflow today, while allowing
you to move to more efficient IT workflows in the future. You can use the camcorder’s storage
media just like videotape in tape-based workflows. The only difference is that you use digital
media recorders and digital media drives as tape machine substitutes. However, Infinity Series
products offer more than videotape replacement. In nonlinear editing environments, for
example, you can also connect a REV PRO drive or CompactFlash card reader to a workstation
for direct access and low cost.

16 DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
Chapter 1 - Introduction
1.3 Key features
• Three Xensium™ based 2/3-inch CMOS imagers with advanced image processing
functions:
– Full 1920 x 1080 active-pixel matrix
– Superior noise performance
• HD/SD multi-format support including 1080i50/59.94, 720p50/59.94, 576i50 and
480i59.94 video standards
• Optional 1080p23.98, 1080p25, 1080p29.97 video standards.
• Recording and playback to and from Grass Valley REV PRO and professional
CompactFlash® insertable media and external devices
• Large internal video buffer for instant recording and switch-over mechanism
• Video, audio and metadata content are written in the open OP-1A MXF based wrapper
• Supports DV25, JPEG2000, and MPEG-2 (optional) compression schemes:
– DV compression (25 Mb/s) for NTSC (4:1:1) and PAL (4:2:0)
– JPEG2000 high-efficiency compression for SD (4:2:2) and HD (4:2:2)
– MPEG-2 and D10 compression (requires DMC 1120 MPEG-2 compression board)
• Traditional inputs/outputs include BNC connectors for HD-SDI or SDI (selectable, with or
without embedded audio), CVBS, timecode, AES/EBU digital audio and XLR outputs for
analog audio
• IT-based interfaces:
– Three high-speed USB 2.0 connectors (two host and one device)
– IEEE 1394 connector
– HDMI viewfinder connector, allows connection to alternative HD and HD-ready
displays
– Gigabit Ethernet
• C2IP remote control over IP connections
• Configurable four-channel audio router with selectable input sources
• Built-in 3.6-inch TFT color touch screen with user interface for:
– Audio setup and metering
– Video setup and monitoring
– Recording setup and metadata
– Clip management
– Detailed camera configuration

DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 17
Chapter 1 - Introduction
1.4 Infinity type numbers
Type number Unit
Camcorder:
DMC 1000/10 Infinity Digital Media Camcorder (with REV PRO 35 drive)
DMC 1000/20 Infinity Digital Media Camcorder (with REV PRO XP/ER drive)
DMC 1100 Infinity 2-inch CRT black and white HD viewfinder
Options:
DMC 1120 Infinity DMC MPEG-2 HD/SD compression board (kit)
DMC 1130 Infinity DMC 1080P 24/25/30 video modes option (license)
DMC 1180 Infinity DMC Stereo front microphone connector option (kit)
Accessories:
LCP 400 Wireless Local Control Panel (application)
OCP 400/10 Operational Control Panel
AJ-MC700 Standard mono front microphone (kit)
LDK 5020/05 Universal transport case
LDK 5020/60 Infinity DMC carrying bag
LDK 5020/70 Infinity DMC camera glove
LDK 5022 Infinity DMC raincover
LDK 5031/10 Tripod adapter plate
LDK 5390 Wide angle eyepiece for 2-inch viewfinder
LDK 5391 Long eyepiece ocular for 2-inch viewfinder
LDK 5901 External power supply unit (100 W)

18 DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
Chapter 1 - Introduction
1.5 Quick reference
The illustrations on the following pages show the location and name of the controls on the
camcorder. The table lists the controls and references the location in the manual where more
information can be found.
SelectRec
Audio Level
Exp.
Time Auto
White
Operate Gain Output White Bal.
User 1 User 2
Monitor
Warning
Save
Std.
Recall
Marker
Stby +
-
Cam
Bars
Clear
ND 1/4
ND 1/16
ND 1/64
1
2
3
4
+
-
Contrast
Operate switch
Contrast button
Marker button
Filter
selection switch
Gain selection
switch
Warning volume
Monitor volume
Standard recall
button
Assignable buttons
White balance
selection switch
Color bar switch
Audio front
level control
Record
button Menu select button Menu rotary control
Exposure time
switch Auto white balance switch
Level 1
Level 2
Side panel
display
Audio level
control 1
Audio level
control2
Monitoring
speaker Push
buttons Navigation control
Backlight/display
button Camera status
display
Power switch
Zoom control
12
3
4

DMC 1000 Digital Media Camcorder User’s Guide (v4.0) 19
Chapter 1 - Introduction
Control name Paragraph reference
Backlight / Display button “Lights and indicators” on page 50
Camera Status Display (CSD) “Side panel home screen” on page 46
Monitoring speaker “Monitoring” on page 51
Side Panel Display (SPD) “Side panel home screen” on page 46
Audio level 1 control “Recording audio” on page 84
Audio level 2 control “Recording audio” on page 84
Navigation control “Side panel menu” on page 55
Push buttons “Push buttons” on page 39
Filter selection switch “Working with optical filters” on page 69
Warning volume control (future use)
Monitor volume control “Monitoring” on page 51
Standard recall button “Standard video settings” on page 67
Assignable buttons (User 1 and User 2) “Assignable buttons” on page 40
White balance selection switch “Auto white balance” on page 72
color bar switch “Colour bars” on page 66
Gain selection switch “Gain selection” on page 68
Operate switch (future use)
Contrast button “Viewfinder” on page 42
Marker button (future use)
Filter selection switch “Working with optical filters” on page 69
Exposure time switch “Exposure time” on page 74
Auto white balance switch “Auto white balance” on page 72
Menu rotary control “Viewfinder menu” on page 59
Menu select button “Viewfinder menu” on page 59
Audio front level control “Recording audio” on page 84
Record button “Recording” on page 105
Power switch “Power supply” on page 35
Zoom control “Carrying handle” on page 41

20 DMC 1000 Digital Media Camcorder User’s Guide (v4.0)
Chapter 1 - Introduction
REVPro
Open
2
1
CF
Network 2 Network 1 USB B USB A
Audio Out11-17V 7A
11-17V
1A max.
Crisp
Tally Zebra Option
Contr. Bright.
Audio
In 1
MicLine +48V
In 2
MicLine +48V
USB
connector IEEE 1394 connector
Top tally
light
Rear tally
light Rear tally
light
Media bay
cover switch
REV PRO
media bay
REV PRO
status indicator/
eject button
CompactFlash
status indicator/
eject button (2x)
CompactFlash
card bays (2x)
Tally on/off
switch Zebra on/off switch VF text switch
Crispening
control Contrast control Brightness control
USB A host
connector
(USB B device
connector)
Ethernet 1
connector
(Ethernet 2
connector)
Audio out
connector
Audio
input 2
Audio
input 1 Line/Mic switches (2)
DC in
connector
Accessory
output connector
Headset
microphone
Headphones
output
Lens
connector
Microphone
connector
HDMI/Viewfinder
connector
Digital output (BNC)
Digital input (BNC)
Analog output (BNC)
Analog input (BNC)
12
3
4
5
6
7
Record switch
BOTTOM VIEW
