GRASS VALLEY LDX FLEX User manual

3922 496 32101 June 2013 v3.1
Package v10
LDX Series
User’s Guide
Software Upgradable Camera Platform

Declaration of Conformity
We, Grass Valley Nederland B.V., Kapittelweg 10, 4827 HG Breda, The
Netherlands, declare under our sole responsibility that this product is in
compliance with the following standards:
- EN60065 : Safety
- EN55103-1: EMC (Emission)
- EN55103-2: EMC (Immunity)
following the provisions of:
a. the Low Voltage directive 2006/95/EC
b. the EMC directive 2004/108/EC
FCC CLASS A Statement
This product generates, uses, and can radiate radio frequency energy and if
not installed and used in accordance with the instructions, may cause
interference to radio communications.
It has been tested and found to comply with the limits for a CLASS A digital
device pursuant to part 15 of the FCC rules, which are designed to provide
reasonable protection against such interference when operated in a
commercial environment.
Operation of this product in a residential area is likely to cause interference in
which case the user at his own expense will be required to take whatever
measures may be required to correct the interference.
Copyright
Copyright Grass Valley Nederland B.V. 2013. Copying of this document and
giving it to others, and the use or communication of the contents thereof, are
forbidden without express authority. Offenders are liable to the payment of
damages. All rights are reserved in the event of the grant of a patent or the
registration of a utility model or design. Liable to technical alterations in the
course of further development.
Trademarks
Grass Valley is a trademark of Grass Valley, Inc. All other tradenames
referenced are service marks, trademarks, or registered trademarks of their
respective companies.
Website
Visit the Grass Valley public website to download the latest user’s guide
updates and additional information about your broadcast product:
www.grassvalley.com

LDX Series Software Upgradable Camera Platform User’s Guide (v3.1) 3
Table of contents
Chapter 1 – Introduction
1.1 Welcome. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
1.1.1 About this guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.1.2 Related documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.2 Technology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
1.2.1 Xensium-FT imagers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.2.2 Superior digital processing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.2.3 Designed for the operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.3 Camera versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
1.4 GV-eLicense Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
1.5 Key features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
1.6 List of accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Chapter 2 – Installation
2.1 Mounting a lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.2 EC 270 EyeCatcher viewfinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.2.1 Mounting the viewfinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.2.2 Positioning the viewfinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.2.3 Distance viewing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.3 AJ-MC700 Microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.4 LDK 5301/10 Tripod adapter plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.5 Adjusting the shoulder pad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.6 Exchanging the camera adapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.6.1 Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.6.2 Attaching the adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.6.3 Detaching the adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.7 LDK 5020/05 Universal Transport Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.8 Packing for return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Chapter 3 – Configurations
3.1 Transmission systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.2 3G Fiber configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.3 3G Triax configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.4 SuperXpander configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Chapter 4 – Operating instructions
4.1 Using the camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.1.1 Switching on the power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.1.2 Controlling the camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.2 Location of controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.3 Using the OCP 400. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

4 LDX Series Software Upgradable Camera Platform User’s Guide (v3.1)
4.4 Using the camera menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
4.4.1 Entering the camera menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
4.4.2 Finding your way . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
4.4.3 Leaving the camera menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.4.4 Making value changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4.4.5 Undoing changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
4.5 User buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
4.5.1 Left side panel buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
4.5.2 Lens buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
4.5.3 Handgrip button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
4.6 Viewfinder controls (EyeCatcher only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
4.7 Viewfinder information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
4.7.1 Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.7.2 On screen marker indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
4.7.3 Viewfinder LED indicators (EyeCatcher only). . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.7.4 Information screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
4.7.5 Focus assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
4.7.6 Viewfinder zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
4.8 Lens operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
4.8.1 Back focus adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.8.2 CLASS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
4.8.3 Auto Iris . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
4.8.4 Extended Iris . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
4.8.5 Precision focus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
4.8.6 Lens indicators in the viewfinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
4.9 Controls on the camera adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
4.9.1 Overview of controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
4.9.2 Powering the camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
4.9.3 Selecting monitoring signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
4.9.4 Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
4.9.5 Intercom. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
4.10 Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
4.10.1 Call button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
4.10.2 PickMe button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
4.10.3 Private data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
4.10.4 Tracker tally signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
4.11 Managing files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
4.11.1 Scene files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
4.11.2 Operator files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
4.11.3 Lens files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
4.11.4 Standard files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
4.12 Access and security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
4.12.1 User level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
4.12.2 Selecting the user level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
4.12.3 Disable camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
4.12.4 Access control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Chapter 5 – Video setup
5.1 Video settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
5.1.1 Standard settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
5.1.2 Video mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
5.1.3 Sensitivity mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
5.1.4 Color bar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

LDX Series Software Upgradable Camera Platform User’s Guide (v3.1) 5
5.2 Gain. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
5.3 Gamma . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
5.3.1 Gamma correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
5.3.2 Gamma curve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
5.3.3 Gamma presets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
5.4 Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
5.4.1 Contrast adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
5.4.2 Black Stretch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
5.5 Knee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
5.5.1 Knee (in PowerCurves mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
5.5.2 Knee (in Compatibility mode). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
5.6 Optical filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
5.7 Exposure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
5.7.1 Exposure time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
5.7.2 Lighting correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
5.7.3 V-Shift (vertical acquisition shift) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
5.7.4 Variable exposure time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
5.8 Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
5.8.1 Color Temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
5.8.2 Color Tint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
5.8.3 Color Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
5.8.4 Selecting color temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
5.8.5 Variable color temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
5.8.6 Auto White Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
5.8.7 Saturation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
5.8.8 Color Protect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
5.8.9 Secondary color correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
5.9 Sharpness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
5.9.1 Detail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
5.9.2 Texture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
5.9.3 Detail Equalizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
5.9.4 Skin Detail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
5.10 Image control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
5.10.1 Freeze Frame. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
5.10.2 Reverse Scan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Chapter 6 – Camera menu reference
6.1 Reference tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
6.2 Operator Toolbox menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
6.3 Production Setup menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
6.4 Creative Control menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
6.5 Configuration menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
6.6 Licenses menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
6.7 Diagnostics menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
6.8 Service menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Chapter 7 – Maintenance
7.1 Installing eLicenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
7.1.1 About eLicenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
7.1.2 Installation procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
7.2 Black calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
7.3 Formatting the SD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

6 LDX Series Software Upgradable Camera Platform User’s Guide (v3.1)
Chapter 8 – Connectors
8.1 Camera head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
8.1.1 Viewfinder connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
8.1.2 Network connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
8.1.3 USB connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
8.1.4 HDMI connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
8.1.5 Lens interface connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
8.1.6 Front Mic connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
8.2 Camera adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
8.2.1 Back panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
8.2.2 Transmission connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
8.2.3 Audio/VF connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
8.2.4 HD-SDI(B)/VF connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
8.2.5 HD-SDI(A) connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
8.2.6 Microphone 1 + 2 connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
8.2.7 Intercom headset connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
8.2.8 Power output connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
8.2.9 Script light connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
8.2.10 Power input connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
8.2.11 Side panels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115
8.2.12 Reference input / teleprompter output connector . . . . . . . . . . . . . . . . . . . . . .115
8.2.13 Auxiliary connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115
8.2.14 Tracker connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
8.3 Main video signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117
Chapter 9 – Specifications
9.1 Specifications for LDX Series camera head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
9.1.1 General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
9.1.2 Camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
9.1.3 Video modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
9.1.4 Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
9.1.5 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
9.2 Specifications for LDX 5421 3G Fiber adapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
9.2.1 Technical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121
9.2.2 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121
9.3 Specifications for LDX 5419 3G Triax adapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . .122
9.3.1 Technical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122
9.3.2 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122

LDX Series Software Upgradable Camera Platform User’s Guide (v3.1) 7
End-of-life product recycling
Grass Valley’s innovation and excellence in product design also extends to the programs we’ve
established to manage the recycling of our products. Grass Valley has developed a
comprehensive end-of-life product take back program for recycle or disposal of end-of-life
products. Our program meets the requirements of the European Union’s WEEE Directive and
in the United States from the Environmental Protection Agency, individual state or local
agencies.
Grass Valley’s end-of-life product take back program assures proper disposal by use of Best
Available Technology. This program accepts any Grass Valley branded equipment. Upon
request, a Certificate of Recycling or a Certificate of Destruction, depending on the ultimate
disposition of the product, can be sent to the requester. Grass Valley will be responsible for all
costs associated with recycling and disposal, including freight, however you are responsible for
the removal of the equipment from your facility and packing the equipment ready for pickup.
For further information on the Grass Valley product take back system please contact Grass
Valley at + 800 80 80 20 20 or [phone] from most other countries. In the US and
Canada please call 800-547-8949 or 530-478-4148. Ask to be connected to the EH&S
Department. In on, information concerning Grass Valley’s environmental policy can be found at:
www.grassvalley.com/about/environmental-policy

8 LDX Series Software Upgradable Camera Platform User’s Guide (v3.1)
Important information
Read these instructions carefully and retain them for future reference. Regularly check the
Grass Valley website (www.grassvalley.com) for new updates of this and other user’s guides.
During installation and operation of this equipment, local building safety and fire protection
standards must be observed.
Whenever it is likely that safe operation is impaired, the apparatus must be made inoperative
and secured against any unintended operation. The appropriate servicing authority must then
be informed. For example, safety is likely to be impaired if the apparatus fails to perform the
intended function or shows visible damage.
Any changes or modifications not expressly approved in this manual could void your authority
to operate this equipment.
Cautions and Warnings
Read and comply with the warning and caution notices that appear in the manual.
Warnings indicate danger that requires correct procedures or practices to prevent death or
injury to personnel.
Cautions indicate procedures or practices that should be followed to prevent damage or
destruction to equipment or property.

LDX Series Software Upgradable Camera Platform User’s Guide (v3.1) 9
Warnings
To prevent fire or shock hazard, do not expose the unit to rain or moisture. If the unit is in a wet
or damp environment, a rain cover must be used to protect it for personal safety reasons.
To avoid electrical shock, do not remove covers or panels. Refer servicing to qualified
personnel only.
In case of an emergency ensure that the power is disconnected.
Connect the product only to a power source with the specified voltage rating.
To prevent risk of overheating, ventilate the camera correctly. Do not block the hot airflow
coming from the outlet on the right side of the camera adapter.

10 LDX Series Software Upgradable Camera Platform User’s Guide (v3.1)
Precautions
To ensure continual high performance from the camera take the following precautions into
consideration:
• Avoid damp places. If the environment is wet or damp a rain cover must be used to
protect the unit.
• Do not subject the unit to severe shocks or vibration.
• Do not expose the camera to extremes of temperature.
• Do not leave the unit in direct sunlight or close to heating appliances for extended periods.
• Do not allow sunlight to shine into the viewfinder.
• Do not allow laser beams to shine into the lens as this could damage the imagers.
• Avoid extreme highlights as these can cause various kinds of optical reflections.
• Be careful when connecting and disconnecting Triax or Fiber cables.
• Do not mix units from different types of camera systems (HD with SD, Triax with 3G Triax)
• Do not connect Grass Valley camera systems with other manufacturer’s camera system
parts.
• Make connections swiftly and firmly to avoid false error messages.

LDX Series Software Upgradable Camera Platform User’s Guide (v3.1) 11
Triax cable systems
• Only connect a Triax cable from the same LDX/LDK camera family to the unit.
• Do not allow system earth currents to exceed 1.5 A in the outer shield of the Triax cable or
0.2 A in other cable shields.
• To avoid excessive earth currents in a Triax system, galvanically separate the power earth
connection of equipment connected to the camera from the camera earth.
• It is strictly prohibited to short circuit the inner and outer shields of a Triax cable used to
connect a camera to an XCU.
Galvanic separation
Because of the nature of Triax systems, with long distances between camera and XCU, the risk
of earth currents flowing is greater. These earth currents can result in damage to the
equipment.
For example, a monitor connected directly to a video output of the camera is powered locally.
The earthing point of the monitor’s power supply can be at a different potential with respect to
the earthing point of the XCU. If the power earth of the monitor is also the video earth, then
this earth potential is transferred to the camera via the shield of the BNC connector. The
difference in earth potential between the camera and the XCU results in an earth current in the
Triax system.
To prevent earth currents from flowing in the Triax system, we recommend galvanic separation
of earthed equipment connected to the camera. This separation can be achieved by using an
isolation transformer between the local power outlet and the equipment connected to the
camera. Alternatively, use equipment that has a double insulation and therefore does not
require an earth connection.

12 LDX Series Software Upgradable Camera Platform User’s Guide (v3.1)
Fiber-optic transmission units
Laser safety statement (for Europe)
Fiber-optic transmission units are classified as a “Class 1 Laser Product” according to
EN 60825-1, Safety of Laser products. CLASS 1 laser products are considered safe and do not
result in biological hazard if used according to the instructions.
Laser safety statement (for US)
Fiber-optic transmission units are ified as a “Class 1 Laser Product” according to
21CFR 1040.10 of the US Food and Drug Administration (FDA) Center for Devices and
Radiological Health.
WARNING
Use of controls, adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
WARNING
To ensure proper use of this product, please read this instruction manual carefully and retain
for future reference. Should the unit ever require maintenance, contact an authorized service
location.
Fiber-optic cable precautions
Fiber-optic cables and connectors are easily damaged; take the following precautions into
account:
• Do not bend the cable beyond the minimum permissible bend range specified for the
cable.
• Avoid kinks in the cable.
• Avoid subjecting the cable to a high tension force (even momentarily).
• Do not twist the cable when connecting it to equipment.
• Insert connectors straight and fully into their corresponding sockets.
• In fiber-optic cable systems always put the dust caps on cable and panel connectors
immediately after disconnecting a cable. Keep the dust caps clean.
CLASS 1
LASER PRODUCT
LASER KLASSE 1
PRODUKT

LDX Series Software Upgradable Camera Platform User’s Guide (v3.1) 13
Cleaning fiber-optic connectors
WARNING
Always switch off power before cleaning the connectors.
WARNING
Never clean an optical connector attached to a fiber that is carrying light.
Particles of foreign matter on the tip of a ferrule can have a disabling effect on fiber-optic
transmission. Fiber-optic connectors need to be cleaned every time they are mated and
unmated; it is essential that fiber-optic users develop the necessary discipline to always clean
the connectors before they are mated.
Use a commercially available cleaning kit specifically designed for fiber-optic connectors and
follow the manufacturer's instructions carefully.
• The connector sections to be cleaned include the tips and sides of ferrules, the interior
walls of alignment sleeves, and the interior and exterior of connector shells.
• For plugs, the interior surfaces of alignment sleeves and the tips of ferrules are to be
cleaned with a cleaning stick treated with the appropriate fluid. (Cleaning sticks with a
slender design are available that allow alignment sleeves to be cleaned without having to
detach them.)
• For jacks, it is important to clean both the tips and sides of the completely protruding
ferrules.
• Both the male and female connector shells tend to attract dust and metal particles, so it is
important to clean both the insides and outsides.
• The fiber end face and ferrule must be absolutely clean before it is inserted into a
transmitter or receiver.
• Mate the connector immediately! Don't let the connector lie around and collect dust
before mating.
• Air can be used to remove lint or loose dust from the port of a transmitter or receiver to be
mated with the connector. Never insert any liquid into the ports.

14 LDX Series Software Upgradable Camera Platform User’s Guide (v3.1)

LDX Series Software Upgradable Camera Platform User’s Guide (v3.1) 15
Chapter 1 - Introduction
Chapter 1
Introduction
1.1 Welcome
The LDX Series comprises a range of high-end live production camera heads using Xensium-FT
imagers. An LDX Series camera head contains optics, imagers and digital image processing
electronics, while the transmission system (3G Fiber or 3G Triax) can be selected by docking an
interchangeable transmission adapter to the camera head. The dockable principle allows the
greatest flexibility and cost-effective solutions in multiple applications.
1.1.1 About this guide
The purpose of this guide is to present a detailed description of how to operate an LDX Series
camera head equipped with a dockable transmission adapter. It provides the information
necessary to use the camera in different configurations and with various attachments. This
guide describes all operating features of the camera so it can be used to its full potential.
This guide is so designed that it can be used as an introduction to those who are new to the
camera, as a simple procedural guide to those who wish to set-up and start shooting
immediately, and as a reference work to be consulted as required during the long life of the
camera.
1.1.2 Related documents
Before proceeding, check the Grass Valley website at www.grassvalley.com for the latest
version of this user’s guide and additional information:
• User’s guide updates, data sheets, brochures and application notes.
• Camera software updates, release notes and installation instructions.

16 LDX Series Software Upgradable Camera Platform User’s Guide (v3.1)
Chapter 1 - Introduction
1.2 Technology
1.2.1 Xensium-FT imagers
An LDX Series camera head uses custom-designed 2/3-inch CMOS Xensium-FT imagers that
offer superior performance and ultimate flexibility. Native high-definition video formats 1080p,
1080i and 720p (available video modes are depending on the camera version) are produced at
the touch of a button.
Progressive frame sampling is the native imaging mode, providing complete frame samples.
The entire imager surface is used for image sampling—there are no interline transfer channels
which introduce aliasing artifacts.
Xensium-FT imagers have a high dynamic range and high linear sensitivity across all lens
apertures. There is no shutter and no vertical smear effect.
1.2.2 Superior digital processing
The advanced video processing of the camera is done with floating point precision while all
major camera functions are processed in the digital domain, including knee, gamma, detail,
matrix and color correction.
To make images look their best, the LDX Series cameras incorporate TrueTexture™—a unique
feature to preserve texture throughout all processing parameters.
Chromatic lens aberration correction (CLASS) offers impressive sharpness improvements on
the outer regions of the image by canceling out shifts in color registration. This algorithm
works in conjunction with lens data, using industry standard lens interface protocols.
For Première, Elite and WorldCam versions, the Dynamic Detail Equalizer provides more
control over image sharpness than ever before. Detail enhancement can be fine-adjusted for
each individual tonal range.
For Elite and WorldCam versions, video contrast adjustment offers unmachted creative control
over the luminance levels of the picture: shadows, midtones and highlights can be adjusted
individually while natural transitions between the areas are maintained.
The LDX Series provides enhanced colorimetry, -matching, and picture performance. Color
temperature and tint are just two of the parameters that can be simultaneously adjusted
across multiple cameras.
1.2.3 Designed for the operator
The LDX Series offers even more operational excellence. Button layouts as well as control
knobs are ergonomically designed to allow the operator to find the right adjustments easily.
Full control flexibility is possible thanks to well dimensioned control knobs. With the easily
accessible separated info button, operational information can de displayed in the viewfinder
instantaneously.
The user-friendliness of LDX cameras has been further improved by using a streamlined
camera menu structure that allows operators to access commonly used functions more
quickly. The camera menu is arranged around operational, video setup, creative setup and
system configuration.
Another imaging innovation is ArtTouch™, an intuitive interface between the operator and hard
wired controls, which significantly enhances artistic possibilities during live broadcast.
ArtTouch includes smart coupling of video control functions.

LDX Series Software Upgradable Camera Platform User’s Guide (v3.1) 17
Chapter 1 - Introduction
1.3 Camera versions
The LDX Series consists of four camera versions: LDX Flex™, LDX Première™, LDX Elite™,
and LDX WorldCam™. Each camera offers exceptional performance, with increased
functionality as you go up the range. LDX Flex delivers 720p or 1080i (depending on the
version) while LDX Première provides standard multi-format 1080i and 720p acquisition.
LDX Elite adds 1080PsF, while LDX WorldCam incorporates all of the features of the LDX Elite
and adds effortless 1080p production as well—with the same sensitivity as shooting 1080i.
See the table below for an overview of the features of the four different camera versions:
eLicense upgrade program: can be upgraded to
LDX Première
can be upgraded to
LDX Elite
can be upgraded to
LDX WorldCam
Imager Next-generation Xensium-FT
Sensitivity @ 2000 lux F12 typical (all 50 Hz modes) / F11 typical (all 59.94 Hz modes)
Signal-to-Noise ratio 60 dB (typical)
Video modes 1080i or 720p 1080i, 720p 1080i, 720p,
1080PsF
1080i, 720p,
1080PsF, 1080p
Sensitivity modes Nominal Nominal, High Quality Nominal, High Quality,
High Sensitivity
Nominal, High Quality,
High Sensitivity
1080p with full sensitivity No No No Ye s
Effects filters (optical) No Yes Yes Yes
CLASS Horizontal Horizontal + Vertical Horizontal + Vertical Horizontal + Vertical
PowerCurves Knee Control No No Yes Yes
Depth of Field (DoF) indicator
in the viewfinder
No No Ye s Ye s
Reverse Scan (Horizontal/
Vertical flip)
No Yes Yes Yes
TrueTexture™Ye s Ye s Ye s Ye s
Skin Detail 2.0 (depending on
Zoom and Focus level)
No Yes Yes Yes
Dynamic Detail equalizer No Ye s Ye s Ye s
Variable Color Protect No No Yes Yes
Dynamic Aperture correction No No Ye s Ye s
Color Temperature
Measurement
No Yes Yes Yes
Horizontal + Vertical image
Shift
No Ye s Ye s Ye s
Secondary Color Correction 2 sets 2 sets 6 sets 6 sets
Flex Première Elite WorldCam

18 LDX Series Software Upgradable Camera Platform User’s Guide (v3.1)
Chapter 1 - Introduction
1.4 GV-eLicense Program
The unique LDX Series Grass Valley eLicense program offers great flexibility in format support
and feature set availability. Within the eLicense program there are two different ways to
upgrade a camera: using a perpetual or a temporary (7-day) license.
• A perpetual license provides a permanent upgrade from any lower camera model in the
range to any higher model in the range.
• A temporary license provides a 7-day upgrade, so the same flexibility is available, but for a
lower weekly cost.
Multiple licenses may be purchased to upgrade cameras by more than one level (e.g., LDX Flex
to LDX WorldCam) or to extend 7-day upgrade licenses.
1.5 Key features
LDX Flex/LDX Series features:
• Ultimate flexibility with next-generation Xensium-FT imagers:
– Frame Transfer (FT) technology ensures no smear
– Increased sensitivity
– Improved digital noise reduction
– TrueTextureTM: texture is preserved throughout all processing parameters
• Unmatched operational performance:
– Available in two versions: 1080i50/60 or720p50/60
– ArtTouch™: Smart coupling between many video functions.
– Perfect picture matching across the complete LDX Series as well as the LDK installed
base
– Ergonomically designed camera head with easy access to control buttons, articulated
areas and a large rotary control.
– The clever PickMe button places the camera operator in the middle of the action and
provides a great help for fast event handling in the field
– Suitability for 3D productions
– Horizontal chromatic lens aberration and sharpness solution (CLASS) compatible with
many digital lenses
– Advanced secondary color corrector with 2 sets for color hue, saturation and
luminance adjustment.
• Fully compatible with Gras Valley’s 3G fiber and 3G triax transmission systems.
• Compatible with Grass Valley’s C2IP control systems and RefleX SuperXpander.

LDX Series Software Upgradable Camera Platform User’s Guide (v3.1) 19
Chapter 1 - Introduction
LDX Première
• All LDX Series camera features
• All LDX Flex camera features
• Switchable video formats: 1080i50/60 and 720p50/60
• Horizontal and vertical chromatic lens aberration and sharpness solution (CLASS)
compatible with many digital lenses
• Dynamic Detail Equalizer with an extensive range of parameters
• Advanced secondary color corrector with 6 sets for color hue, saturation and luminance
adjustment.
LDX Elite features
• All LDX Series camera features
• All LDX Première camera features
• Switchable video formats: 1080PsF (artistic), 1080i50/60, 720p50/60
• PowerCurves knee control provides an almost unlimited control over the wide dynamic
range of the imaging system
• Depth of field indicator to aid the operator while shooting
LDX WorldCam features
• All LDX Series camera features
• All LDX Elite camera features
• Switchable video formats: 1080p50/60 (3G), 1080PsF (artistic), 1080i50/60, 720p50/60
• Effortless 1080p50/60 acquisition with no increased lighting requirement

20 LDX Series Software Upgradable Camera Platform User’s Guide (v3.1)
Chapter 1 - Introduction
1.6 List of accessories
System components
LDK 4475 Reflex SuperXpander
LDK 4800 HD/HS Triax Repeater
Viewfinders
EC 270 2.7-inch LCD HD color ocular viewfinder
LDK 5307 7-inch LCD HD color viewfinder
LDK 5309/10 9-inch LCD HD color viewfinder
LDK 5302/60 2-inch CRT HD B/W ocular viewfinder
Accessories
LDK 5031/10 Tripod plate
LDK 8111/37 Dynamic headset (double muff) with XLR-5 connector
LDK 8111/51 Dynamic headset (single muff) with XLR-5 connector
LDK 6985/30 Universal LDK/LDX Camera script board
LDK 5020/05 Universal transport case
LDK 5020/01 Carrying bag
LDK 5901/00 External power supply unit (100 W)
