Greiner Vibrograf ACS 900 Installation instructions

Greiner Vibrograf AG
Mittelstrasse 2
4900 Langenthal
Switzerland
T: [phone]
F: [phone]
[email protected]
www.greinervibrograf.ch
Änderungen vorbehalten
Seite 1 / 2
Copyright by Greiner Vibrogaf AG
1 Inspection and small maintenance for ACS 900
Area
Check or
Clean
Replace if
necessary
Remark
Body
Clean body with a soft towel. Do not use
aggressive cleaning liquid.

Doors / Side panels
Clean the doors and side panels with a soft towel.
Do not use aggressive cleaning liquid.

Filter
Check the filter pads; they can be cleaned. If too
dirty, replace them.


Filter pad
9650.01F.011
Plate
Clean the plate with a soft towel. Do not use
aggressive cleaning liquid.

Rubber discs
Clean the rubber discs with a soft towel. Do not
use aggressive cleaning liquid.
If too used, replace it.


4× Rubber disc (cover)
0322.350.014
1 × Rubber disc (basket holder)
0322.310.030
Contacts of ultrasonic
Check and clean the ultrasonic contacts inside of
the machine (in the whole where the ultrasonic
tank is positioned)
Switch off the device and disconnect the
power cable before doing this.

Ultrasonic tank
Check and clean the contacts on the underside of
ultrasonic tank.

Mechanic
Check if play in the mechanic or large Vibration
during spinning.

Contact service centre

Greiner Vibrograf AG
Mittelstrasse 2
4900 Langenthal
Switzerland
T: [phone]
F: [phone]
[email protected]
www.greinervibrograf.ch
Änderungen vorbehalten
Seite 2 / 2
Copyright by Greiner Vibrogaf AG
2 Repair
Problem
Possible cause
Possible helps
No function
ACS 900 not switched on
Press the power switch
Power cord not plugged
Insert cable
Fuse blown
Replace fuse
Building no power
Check power supply
Error message on display
Mechanical defect
Contact Service Centre
Ultrasonic is not running
Ultrasound in the program
not selected
Activate in the program
Ultrasound cannot be
selected in the program
Contact Service Centre
Heating is not running
Heating in the program not
selected
Activate in the program
Heating defective
Contact Service Centre
Vibration, mechanical Noise,
especially during spinning
Play of mechanic
Contact Service Centre
Plate is not centered
Mechanical defect
Contact Service Centre
Keyboard does not respond
Keyboard defective
Contact Service Centre
Cleaned parts are not clean
Liquids are too dirty
· Liquids are too old
· Liquids are too long in the
ACS 900
Check liquids and replace if
necessary
Baskets touch glasses
Plate is not centered
Contact Service Centre
ACS 900 makes noises
Mechanical defect
Contact Service Centre
General remarks:
Do not use more than 0.55l of liquid for each bath.
The ultrasonic goblet is not waterproof.
