GridSense HighV Camera User manual

Highv Camera Manual -v1Nov7 2012.Docx page 1 of 18
Copyright
© Gri Sense Inc 2010-2012
The material presente in this manual is copyright protecte by Gri Sense Inc.
Any repro uction in whole or in part for any purpose without the prior written consent of
Gri Sense Inc is strictly prohibite .
Information in this ocument is subject to change without notice.
All tra emarks are the property of their respective owners.

Highv Camera Manual -v1Nov7 2012.Docx page 2 of 18
Table of Contents
Section Page
Table of Contents..............................................................................................................................................2
1 General Information .................................................................................................................................. 3
1.1 Intro uction ................................................................................................................................... 3
1.2 Warranty ........................................................................................................................................ 3
1.3 Applications ................................................................................................................................... 3
1.4 Approach Limits............................................................................................................................. 3
1.5 Camera Components ..................................................................................................................... 5
1.6 Specifications ................................................................................................................................ 7
1.7 Cautions......................................................................................................................................... 7
2 Using the HighV Camera .......................................................................................................................... 9
2.1 Assembly ...................................................................................................................................... 9
2.2 Operation .................................................................................................................................... 10
2.3 Camera Battery Removal for Charging or Replacement ............................................................... 13
2.4 Battery Charging for Camera ....................................................................................................... 14
2.5 Battery Charger LED Status ......................................................................................................... 14
3 Troubleshooting ...................................................................................................................................... 16
3.1 An roi Tablet oes not fin camera ........................................................................................... 16
3.2 An roi Tablet is stuck in “negotiating connection” mo e .......................................................... 16
4 Content Checklist .................................................................................................................................... 17
• Camera ........................................................................................................................................ 17
• Battery mo ule ............................................................................................................................ 17
• Camera Battery charger ............................................................................................................... 17
• An roi tablet/ rugge rubber case ............................................................................................. 17
• An roi charger ........................................................................................................................... 17
• Hotstick attachment for tablet..................................................................................................... 17
• Automotive DC inverter for charging camera an tablet .............................................................. 17

Highv Camera Manual -v1Nov7 2012.Docx page 3 of 18
1General Information
1.1 Introduction
Thank you for purchasing the HighV Inspection Camera. This booklet has been written to
help you familiarize yourself quickly an easily with the full range of features an
applications that this pro uct has to offer.
The HighV Inspection Camera uses a shiel e , high resolution wireless camera
provi ing the user with a tool to con uct close up inspections of live electricity assets
up to 345kV phase to phase.
The camera is installe on a hotstick an gui e from the groun or bucket truck
surveying energize lines or equipment. A live wireless image is transmitte back to
an An roi ® tablet running the Gri Sense HighV Camera App either attache to the
user en of the hotstick or alternatively han hel by supporting personnel.
The live image streaming from the camera can be capture by the touch of a button
within the An roi App. The images are store to an SD car within the tablet for further
inspection or use in a report.
1.2 Warranty
The HighV Inspection Camera is covere by a 1 year manufacturer’s
warranty. Please contact Gri Sense in or er to make a warranty claim.
Please inspect this new pro uct for any amage. Report any efects to your supplier, or
refer to the contact numbers in part 4 of this booklet for manufacturer etails.
1.3 pplications
For more information on applications please refer to the pro uct overview ocument or
contact your local supplier.
1.4 pproach Limits
The Live Line Inspection Camera is manufacture for safe use on energize equipment
up to an inclu ing 345kV phase to phase.

Highv Camera Manual -v1Nov7 2012.Docx page 4 of 18
Users must observe hotstick manufacturer’s ratings and standard approach
limits when using the HighV Camera. The HighV Camera offers NO user
protection.
•We advise that users add an additional 300mm/1’ clearance to the
standard hotstick approach limits at all times when mounting the screen to
the hotstick.

Highv Camera Manual -v1Nov7 2012.Docx page 5 of 18
1.5 Camera Components
•Camera: A high resolution camera an transmitter are house in an
insulate case that uses a stan ar universal spline (32mm) sunrise
attachment for connection to a hotstick. A fiberglass ro (touch probe)
attaches to the mounting bracket an is set to the camera’s focal length,
protecting the camera from irect lens amage. In a ition, a high intensity
LED light ring is embe e in the camera for use in low light applications.
Battery life of the camera is approximately 2 hours from full charge
(without LED illumination).

Highv Camera Manual -v1Nov7 2012.Docx page 6 of 18
•ndroid Tablet: The An roi Tablet is use as the vi eo receiver an image
capture evice. The An roi Tablet provi es the operator with a live
streaming high-resolution vi eo from the camera that can be han hel or
alternatively for single operator applications, attache to the lower part of
the hotstick with the supplie bracket. The “snapshot” button within the
An roi Tablet App recor s images irectly onto the An roi Tablet. The
An roi Tablet inclu es a rechargeable lithium ion battery pack that
provi es 7 hours continuous use from full charge.
•Battery Chargers: The Camera an An roi Tablet are supplie with in ivi ual
charging evices. This inclu es charging at:
o100 - 240V @ 50/60Hz
Also inclu e in the kit is a DC Inverter to provi e in-vehicle charging of the An roi
tablet an the Camera battery pack.
•Carry Case: For safe transport, the camera comes in a fully protective,
watertight, har cover case.

Highv Camera Manual -v1Nov7 2012.Docx page 7 of 18
1.6 Specifications
Phase
t
o
Phase
Rating
345
kV
Typical Kit Inclu es
•
Touch probe ro
•An roi Tablet
•hot-stick mount
•Camera an Tablet AC chargers
•Protective transportation case
H
o
t
Stick Mount
T
ransmission
Frequency Transmission
Range Transmission Power
Uni
v
e
r
sal
Sunrise
f
itting
2.4Hz GHz
Up to 65ft (20m) line of site
< 10mW EIRP
T
ransmission
Stan a
r
s
License
-
free
WiFi
Compliant to FCC, C Tick an CE stan ar s
Camera
T
ype
¼” Sony
®
Super HAD CCD
-
400 line
resolution
Camera Power
DC 12V +
-
10% (3.6W)
Zoom
10x
Focus Control
Auto
An roi
®
Tablet
7” TFT
active matrix
–
LED Backlight
Bat
t
e
r
y
Lithium
Ion
rechargeable
bat
t
e
r
y
pack
Camera
Bat
t
e
r
y
P
e
r
f
ormance
Tablet
Camera Battery Charging
Camera Enclosure Rating
2
hou
r
s
pe
r
f
ormance
6 hours
NEMA4/IP65
Housing Material
P
olymer
resin
Housing
Dielectric
Strength
Operating Temperature
Working Humi ity
> 25kV/mm
-10° C to +50° C
0% - 96%
Image Recor ing Format
JPEG,
AVI
1.7 Cautions
•Rating: The HighV Camera is rate for use on energize equipment up to 345 kV
phase to phase. At no time shoul it be use aroun or come into contact with
higher voltages.

Highv Camera Manual -v1Nov7 2012.Docx page 8 of 18
•Inspecting Energize Equipment: When using the camera to inspect energize
equipment, the operator must a here to all safety requirements an ratings of all
equipment inclu ing (but not limite to) the hotstick, bucket truck, approve
clearances, approach limits an work practice stan ar s.
•Touch Probe Ro : When operating the HighV Camera, the touch probe MUST be
installe an use at all times. This ro not only ensures the optimum focuse
istance for viewing equipment, but also protects the lens, lens cover an LED lights
from impact amage.

Highv Camera Manual -v1Nov7 2012.Docx page 9 of 18
2Using the HighV Camera
2.1 ssembly
•Camera
1. Remove camera an touch probe
2. Insert touch probe into hole in mounting
bracket
3. Mount camera to sunrise attachment on
hotstick an tighten butterfly nut firmly
•An roi Tablet
1. Remove Tablet an hotstick attachment from case
2. Attach bracket to hotstick
3. Insert Tablet into mount

Highv Camera Manual -v1Nov7 2012.Docx page 10 of 18
2.2 Operation
•To Power Camera On/Off: Press the power button locate on the battery mo ule.
•To Power An roi Table On/Off: Press the power button on the top of the tablet. PL

Highv Camera Manual -v1Nov7 2012.Docx page 11 of 18
•To begin using the HighV Camera, start the HighV Application from the tablet.

Highv Camera Manual -v1Nov7 2012.Docx page 12 of 18
•Recor ing Images:
1. Press the snapshot button for a still image or the recor button for vi eo.

Highv Camera Manual -v1Nov7 2012.Docx page 13 of 18
2. After capturing images or vi eos, they can be viewe by pressing the soft menu key an then
pressing the browse button.
2.3 Camera Battery Removal for Charging or Replacement
1. Rotate battery mo ule counter-clockwise
2. Gently pull battery out from the camera housing

Highv Camera Manual -v1Nov7 2012.Docx page 14 of 18
2.4 Battery Charging for Camera
1. Remove quick change battery mo ule from camera (as shown on previous page)
2. Plug supplie charger into wall outlet
3. Connect the charger lea to the charge socket on the battery mo ule
4. Switch on the Battery Mo ule
5. Check status light on the charger for charge status
2.5 Battery Charger LED Status
Soli Re (Charging)
Soli green (Charging complete)

Highv Camera Manual -v1Nov7 2012.Docx page 15 of 18

Highv Camera Manual -v1Nov7 2012.Docx page 16 of 18
3Troubleshooting
3.1 ndroid Tablet does not find camera
1. Check that the camera is turne on an that the LED’s are illuminate
2. Re-scan for camera
3.2 ndroid Tablet is stuck in “negotiating connection” mode
1. Restart the HighV Camera App
a. If the problem persists:
i. Power the camera on/off
ii. Verify that camera battery is charge

Highv Camera Manual -v1Nov7 2012.Docx page 17 of 18
4Content Checklist
€Camera
€Battery mo ule
€Camera Battery charger
€An roi tablet/ rugge rubber case
€An roi charger
€Hotstick attachment for tablet
€Automotive DC inverter for charging camera an tablet
