Grifco Gld-r2.5m User manual

Model GLD-SDO

Chamberlain Australia Pty Ltd

Unit 1, 75 Epping Rd North Ryde NSW 2113

Ph: 1800 GRIFCO

www.grifco.com.au

Ref: 114A4934F

• THIS OPERATOR IS TO BE INSTALLED AND SERVICED BY A TRAINED TECHNICIAN ONLY

• Compatible with Security+ 2.0®accessories

• Compatible with Grifco Battery Backup and myQ Internet Gateway

OPERATOR

SUPPLIED WITH GRIFCO

MONITORED ENTRAPMENT

PROTECTION

OPERATOR

SUPPLIED WITH GRIFCO

MONITORED ENTRAPMENT

PROTECTION

Commercial Sectional Door Operator

LS-Drive

GLD-SDO

LS-Drive Operator

GLD-R2.5M

Rail for (max) 2.5m High Door

GLD-R3.0M

Rail for (max) 3.0m High Door

INSTRUCTION MANUAL

Compatible

Reﬂective

Safety Beam

Compatible

WARNING: Important safety instructions

It is important for the safety of persons to follow all instructions.

SAVE these instructions

WARNING

CAUTION

WARNING

This commercial sectional door operator has been designed and tested to offer safe service provided it is installed, operated, maintained

and tested in strict accordance with the instructions and warnings contained in this manual.

Mechanical

Electrical

When you see these Safety Symbols and Signal Words on the

following pages, they will alert you to the possibility of serious

injury or death if you do not comply with the warnings that

accompany them. The hazard may come from something

mechanical or from electric shock.

When you see this Signal Word on the following pages, it will alert

you to the possibility of damage to your commercial door and/or

the commercial door operator if you do not comply with the

cautionary statements that accompany it.

Keep commercial door balanced. Sticking or binding doors must be

repaired. Commercial doors, door springs, pulleys, brackets and their

hardware are under extreme tension and can cause serious personal

injury. Do not attempt to loosen, move or adjust them. Call for commercial

door service.

Permanently fasten all supplied labels adjacent to the wall control as a

convenient reference and reminder of safe operating procedures.

Activate operator only when the door is in full view, free of obstructions

and operator is properly adjusted. No one should enter or leave the

building while the door is in motion.

An electrician must disconnect electric power to the commercial door

operator before making repairs or removing covers.

The actuating member of a biased-off switch is to be located within direct

sight of the door but away from moving parts. Unless it is key operated, it

is to be installed at a minimum height of 1500mm and not accessible to

the public.

Make sure that people who install, maintain or operate the door follow

these instructions. Keep these instructions in a safe place so that you can

refer to them quickly when you need to.

This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the

appliance.

Use the commercial sectional door operator for its intended purpose. The

GLD-SDO operator is designed lifting spring-balanced sectional doors.

Disengage all existing commercial door locks to avoid damage to

commercial door. Install the wall control (or any additional push buttons) in

a location where the commercial door is visible during operation . Do not

allow children to operate push button(s) or remote transmitter(s). Serious

personal injury from a closing commercial door may result from misuse of

the operator.

Do not wear rings, watches or loose clothing while installing or servicing a

commercial door operator.

To avoid serious personal injury from entanglement, remove all ropes

connected to the commercial door before installing the door operator.

After the installation a final test of the full function of the system and the

full function of the safety devices must be done.

When operating a biased-off switch, make sure that other persons are

kept away.

The operator cannot be used with a driven part incorporating a wicket

door (unless the operator cannot be operated with the wicket door open).

If the supply cord is damaged, it must be replaced by the manufacturer,

its service agent or similarly qualified persons in order to avoid a hazard.

Do not allow children to play with operator wall controls or remote

controls. Keep remote controls away from children.

Motor may become hot during operation. Appropriate clearance and/or

shielding should be supplied by the installer to ensure any cabling, wiring

and/or other items cannot come in contact with the motor. If temperature

rise exceeds 50°C all fixed wiring insulation must be protected, for

example, by insulating sleeving having an appropriate temperature rating.

THESE ARE IMPORTANT SAFETY INSTRUCTIONS. FOLLOW ALL INSTRUCTIONS AS INCORRECT

INSTALLATION CAN LEAD TO SEVERE INJURY OR DEATH

Installation and wiring must be in compliance with your local building and

electrical codes. Connect the power supply cord only to properly earthed

mains.

Moisture and water can destroy the electronic components. Make sure

under all circumstances that water moisture or storage moisture cannot

penetrate the electronics. The same applies for openings and cable

entries.

SAFETY SYMBOL AND SIGNAL WORD REVIEW

INTRODUCTION

CONTENTS

SAFETY SYMBOL AND SIGNAL WORD REVIEW .........................................................................................................2

INTRODUCTION ..............................................................................................................................................................3

OPERATOR SPECIFICATIONS...............................................................................................................................................................4

OPERATOR OVERVIEW .........................................................................................................................................................................5

CONTROL PANEL OVERVIEW...............................................................................................................................................................5

CARTON INVENTORY............................................................................................................................................................................6

TOOLS REQUIRED ................................................................................................................................................................................6

HARDWARE PROVIDED ........................................................................................................................................................................6

INSTALLATION ................................................................................................................................................................7

CONNECT RAIL TO OPERATOR ...........................................................................................................................................................7

TIGHTENING THE CHAIN ......................................................................................................................................................................7

FASTENING RAIL TO OPERATOR .........................................................................................................................................................7

HEADER BRACKET POSITIONING ........................................................................................................................................................8

INSTALL HEADER BRACKET.................................................................................................................................................................8

POSITION THE OPERATOR...................................................................................................................................................................9

MOUNT THE OPERATOR TO THE CEILING ..........................................................................................................................................9

FASTEN THE DOOR BRACKET .............................................................................................................................................................9

ATTACH DOOR ARM TO TROLLEY.....................................................................................................................................................10

TESTING AND OPERATING THE MANUAL RELEASE .........................................................................................................................10

COMMISSIONING .........................................................................................................................................................11

PROGRAMMING TRAVEL LIMITS AND FORCE SETTINGS .................................................................................................................11

INSTALL THE ENTRAPMENT PROTECTION SYSTEM.........................................................................................................................12

SETTING TIMER-TO-CLOSE (TTC) ......................................................................................................................................................13

ATTACHING BATTERY BACKUP UNIT (OPTIONAL) ............................................................................................................................13

TYPES OF SECURITY +2.0 TRANSMITTERS.......................................................................................................................................14

COMMISSIONING REMOTE TRANSMITTERS .....................................................................................................................................14

COMMISSIONING myQ........................................................................................................................................................................15

MAINTENANCE AND CARE..........................................................................................................................................16

USING YOUR OPERATOR ...................................................................................................................................................................16

TROUBLESHOOTING....................................................................................................................................................17

DIAGNOSTICS ...............................................................................................................................................................18

SERVICE AND REPAIR PARTS.....................................................................................................................................19

CHAMBERLAIN LIMITED WARRANTY.........................................................................................................................20

WARNING

OPERATOR SPECIFICATIONS

TYPICAL DOOR INSTALLATION

Power Specifications

Main AC Power Supply 230-240 Vac 50Hz

Max. Pull Force 1,200N

Power 225W

Operating Temperature +5°C to +40°C

Door Specifications

Max Door Height 3.0m

Max Door Weight 160kg

Max Lift under Spring Tension 20kg

Normal Torque 8Nm

Maximum Door Area Commercial Spring-Balanced Sectonal Doors up to 15m²

Max. Door Cycles 50 cycles / day

Dimensions

Operator Length 370mm Rail Length GLD-R2.5m: 3,822mm / GLD-R3.0M: 4,322mm

Operator Height 100mm Rail Height 46.5mm

Operator Width 200mm Rail Width 88mm

Total installed dimensions GLD-SDO-R2.5M: 3,972mm (L) x 150mm (H) x 200mm (W)

GLD-SDO-R3.0M: 4,472mm (L) x 150mm (H) x 200mm (W)

Compliance AS/NZS 60335-1

AS/NZS 60335-2-103

Transmitter Specifications

Hand Transmitters 64 devices

Keypad Transmitters 2 devices

Operator Frequency 433.30 / 433.92 / 434.54 MHz

Transmitter Management Compatible with STAR1000EVO (accessory sold separately)

Usage Indoor Use Only

Door Types

Commercial spring-balanced sectional

door with curved track, up to 3.0m

high and up to 15m² in area.

A 240V General Purpose Outlet (GPO) ie. Power Point must be available in close proximity to the operator.

This fitting is not part of the operator hardware and must be supplied by the consumer.

INTRODUCTION

OPERATOR OVERVIEW

CONTROL PANEL OVERVIEW

Control Panel is accessible under the cover on the rear of the operator.

Operator

4. Learn Button

5. Indicator LED

1. Up

2. Stop

3. Down

6. External Accessory Power (30V DC)

7. Terminal Blocks

Operator Mounting

Bracket

Hanging bracket

BBU

connection

Power

cord

Rail

Header Bracket Trolley

J-Bar

Door Connection Bracket

Door arm

Manual Release

1. Up Button Used for initial programming, driving the door

up and for displaying diagnostic codes - Digit 1

2. Prog Button Used to program door limits and other features

3. Down Button

Used for initial programming, to drive the door

down and for displaying diagnostic codes -

Digit 2

4. Learn Button Used for programming remote access devices,

myQ and manual learning of forces

5. Indicator LED Used to indicate various programming modes

External

Accessory

Power

30 Vdc 50mA available. Constant supply

7. Terminal Blocks

Used to configure external accessories. See

chart below for the function of each terminal

block.

No. Function Colour Polarity Comment

0E-Serial port Green +ve Serial Communication Input

1Trigger input Red +ve Dry Contact input for access control accessories

2 Ground White -ve Common terminal for access control accessories

2 Ground White -ve Common terminal for Safety Beams

3Safety Beam Grey +ve Safety Beam Input: (compatible with supplied safety beams only)

4Emergency Stop Green +ve Dry Contact input for Emergency Stop N/C

5Emergency Stop Green -ve Common terminal for Emergency Stop

624Vdc power supply Black +ve Accessory power output: (24 Vdc 150 mA) when between open and close limits (regulated)

724Vdc power supply White -ve Accessory power output: (24 Vdc 150 mA) when between open and close limits (regulated)

Terminal Block Functions

INTRODUCTION

012234567

TOOLS REQUIRED

HARDWARE PROVIDED

CARTON INVENTORY

The commercial sectional door operator is supplied in two separate cartons.

GLD-SDO contains the operator, fitting hardware and accessories.

GLD-R2.5m or GLD-R3.0M contain the complete, assembled rail and some hardware.

GLD-BBU24V is a separate accessory, supplied in its own carton.

Mounting Hardware

Cable Clips x 4

Safety Beams

Grifco 4-Channel

Transmitter

(1) Wall plug

(2) R clip

(3) Hexagonal head screw M8x25

(4) Hexagonal head screw M8x20

(5) Clevis pin 8mm

(6) Clevis pin 6mm

(7) Screw ST6 x 50 mm

(8) Screw ST6,3 x 18 mm

(9) Nut M8

(10) Flat washer M8

(11) Cable Clips

Operator

Mounting

Bracket Header

Bracket

Rail

Door

Connection

Bracket

J-Bar

Hanging

Brackets

Door arm

Manual Release

INSTALLATION

(1) 4x

(5) 1x (6) 2x (7) 4x (8) 8x

(10) 4x

(9) 4x

(4) 2x (11) 4x(3) 2x(2) 3x

GLD-SDO

GLD-BBU24V

(optional)

GLD-R2.5m or

GLD-R3.0M

STEP 2

TIGHTEN THE CHAIN

STEP 3

FASTEN RAIL TO OPERATOR

36 - 38mm

(1)

(3)

(4)

(2)

M8 Screws

Note: The spring must be able to compress and bounce during

operation. Final tensioning can be performed after installation if

necessary. Over tightening the chain may overload the system and

cause excessive wear.

1. Tension the chain by adjusting the nut (1), on the pulley assembly,

clockwise until the spring is engaged.

2. Continue tightening to compress the spring and remove all the

slack in the chain. DO NOT OVERTIGHTEN but ensure chain is firm.

3. Adjust the spring to 36-38 mm as indicated in the diagram.

1. If using the hanging brackets to mount to ceiling, slide 1 x

M8 hex head screw into either side of the rail (1). Slide

screws 300mm from end of rail.

2. Position the rail drive sprocket (inside the rail) over the

operator motor shaft (2) and push down to install. Ensure

motor shaft adaptor (3) is in place.

3. Secure the rail on the operator with the Operator Mounting

Bracket (4) using ST6,3 x 18 mm screws.

This completes the assembly of the door operator to the rail.

STEP 1

CONNECT RAIL TO OPERATOR

Your door operator and rail are packed in two separate cartons. Remove the operator, rail and all the hardware in preparation for

assembly. The chain is pretensioned from the factory, however, it is advisable to check the tension and adjust if necessary as outlined in

step 2.

INSTALLATION

WARNING

Before beginning installation of the operator

check the door is in good mechanical condition,

opens and closes properly and correctly balanced

INSTALLATION

STEP 4

HEADER BRACKET POSITIONING

The header bracket must be fastened rigidly

to a structural support. Reinforce the wall

with a 40mm board if necessary.

With the door closed, mark the vertical centre

line of the door. Extend line upward onto header

wall above door.

Open door to the highest point of travel. Draw

an intersecting horizontal line 50mm above door

plane. This is enough space to provide travel

clearance of the door beneath the rail.

STEP 5

INSTALL HEADER BRACKET

Drill and secure the Header Bracket using the most suitable

variation of holes. If using the wood screws provided, uses a

4.5mm pilot drill. If securing to a metal fixture, self tapping “tek”

screws may be more suitable.

STEP 6

ATTACH RAIL TO HEADER BRACKET

Position the assembled operator on the floor below the header

bracket. Use foam packing material as a protective base.

NOTE: If the door spring is in the way have someone hold the

operator securely on a temporary support to allow the rail to

clear the spring.

• Position the rail bracket against the header bracket

• Align the bracket holes and fit the two 6mm Clevis Pins (2)

either side of the header bracket and secure with R Clips (3) on

the outer side of the bracket.

(2)

(3)

INSTALLATION

STEP 7

POSITION THE OPERATOR

Disengage the trolley mechanism (see section

“Operating the manual release”) and slide it back

towards the operator. Secure the hanging push arm

up into the rail assembly temporarily using tape or

rope, to avoid a hazard.

1. Raise the operator onto support (eg ladder)

2. Open the door completely, place a 50 mm spacer

between the door and the rail (as shown)

3. The final positioning of the rail should be relatively

parallel to the horizontal door panels.

1. Postion the operator as in the previous step. Check the rail is

centred over the door. Ensure the hanging brackets are on the

Operator end of the rail in a position as close to the operator as

possible (1).

2. If hanging the operator below the ceiling, bend the hanging

brackets provided, and secure to both the ceiling (2) and the rail

mounting screws (3).

3. If mounting directly onto the ceiling, drill appropriate holes through

the top of the rail. Use a minimum of 2 screws to fix to the ceiling.

Screw the rail directly into a structural support on the ceiling (4).

Ensure screw head height does not exceed 6mm (5) to avoid the

screw head interfering with the trolley movement.

4. Check the operator is securely centred over the door. Remove the

50 mm spacer, and any other assembly tools. Operate the door

manually and check for unrestricted operation.

STEP 8

MOUNT THE OPERATOR TO THE CEILING

STEP 9

FASTEN THE DOOR BRACKET

The door bracket must be securely fastened to the frame or a

structural support on the door.

Mounting position for Sectional Doors

1. Align the bracket on the centre line, measure down 100-300 mm

from the door top edge.

2. Secure the bracket in this position, using the most suitable

variation of holes available.

50 mm spacer

should be used to

determine the correct

mounting position

Rail should be mounted

50mm above the highest

point of door travel

(1)

(2)

(3)

(4)

(5)

6mm MAX

(height of

bolt head)

100 - 300mm

STEP 10

ATTACH DOOR ARM TO TROLLEY

Make sure the door is fully closed. Pull the manual release cord to

disengage the trolley. Slide the trolley to around 300mm from the

header bracket.

1. The Door Arm is already preassembled to the trolley.

2. Install the J-Bar onto the door bracket using the Clevis pin (1) and

R-Clip (2) supplied.

3. Move the Door Arm and J-Bars together and secure using two

bolts and nuts provided (3).

4. Ensure the angle of the Door Arm is around 20° from vertical,

when the door is fully closed.

STEP 11

TESTING AND OPERATING THE MANUAL RELEASE

DO NOT DISENGAGE THE OPERATOR WITH CHILDREN, PERSONS OR OTHER OBJECTS

INCLUDING MOTOR VEHICLES WITHIN THE DOORWAY.

(The door is under significant tension and if the door has developed a fault or incorrect tension, it

may be unsafe and may fall rapidly.)

The manual release mechanism enables the door to be manually operated during power outages

or in an emergency.

The RED Manual Release cord is preassembled to the trolley. When the operator is installed the

handle should be no higher then 1.8 metres from the floor. The cord may need to be extended.

Attach the manual release Instruction Label around the cord as shown below.

DO NOT USE THE RED HANDLE TO OPEN AND CLOSE THE DOOR.

To operate the Manual Release. The door

should be fully closed if possible.

1. Disengage: Pull the manual release rope

and handle down to disconnect. This will

disengage the trolley, allowing the door to

be moved by hand, UP and DOWN as

many times as needed.

2. Re-engage: Pull the manual release rope

towards the motor until it springs back to its

original horizontal position. This will

re-engage the trolley, and when the door

passes the trolley position it will

automatically re-engage the operator.

INSTALLATION

WARNING

Connect Electric Power

TO AVOID INSTALLATION DIFFICULTIES, DO NOT RUN THE DOOR OPERATOR UNTIL INSTRUCTED TO DO SO

Connect to properly fused and earthed power outlet.

- Ensure all ropes and installation tools have been removed from the door

- When the operator is switched ON, the operator light flashes a number of times and then remains ON.

(1)

(2) (3)

RISK OF ENTRAPMENT

Repeat Safety Reverse Test monthly. Door

must reverse on contact with a 40mm obstacle

placed on the floor. Make necessary adjustments.

AUTOMATIC DRIVE:

Keep away from the area of the door since it may

operate unexpectedly.

EMERGENCY RELEASE:

To release, pull down firmly on the red handle.

www.grifco.com.au

www.grifco.co.nz

STEP 12

PROGRAM THE TRAVEL LIMITS AND FORCE SETTINGS

Travel limits regulate the points at which the door will stop when moving UP or DOWN. The

travel limit buttons are located under the access cover on the rear panel (Figure 1)

NOTE: This operator uses a POSITION TAB attached to the chain which activates a

mechanical passpoint during the door travel. The indicator LED will blink when this occurs. If

the passpoint is not activated during the door travel process, the travel limits can't be

programmed.

TO PROGRAM THE TRAVEL LIMITS:

1. Press the PROG Button until the UP arrow button and indicator LED begin to flash (figure 2).

2. Press and hold the UP arrow button until the door is in the desired OPEN limit position (figure 3).

NOTE: The UP and DOWN Arrow Buttons can be used to move the door up and down as

needed.

3. Once the door is in the desired OPEN limit position press and release the PROG Button. The

DOWN Arrow Button will begin to flash (figure 4).

4. Press and hold the DOWN Arrow Button until the door is in the desired CLOSED position (fig 5).

NOTE: The UP and DOWN Arrow Buttons can be used to move the door up and down as

needed.

5. Once the door is in the desired CLOSED limit position press and release the PROG Button. The

UP Arrow Button will begin to flash (figure 2).

SETTING THE FORCE (AUTO):

6. Press and release the UP Arrow Button to test the OPEN limit. When the door has travelled to the

programmed OPEN limit, the DOWN Arrow Button will begin to flash.

7. Press and release the DOWN Arrow Button to test the CLOSED limit. The door will travel to the

programmed CLOSED limit position.

The indicator LED will stop flashing. The travel limits and force setting has now been set. Proceed to

test safety reverse system.

SETTING THE FORCE (MANUAL LEARN IF REQUIRED):

1. Open the rear access panel. Locate the yellow Learn button.

2. Push the yellow Learn button twice to enter operator into force adjustment mode. The LED

indicator light will flash quickly.

3. Push the programmed remote control or push the UP/DOWN arrow button on the control panel.

The door will travel to the CLOSED limit position. Push the remote control again, the door will

travel to the OPEN position.

4. Press and release the DOWN Arrow Button to test the CLOSED limit position. The door will travel

to the programmed CLOSED limit position.

The LED indicator light will stop flashing when the force has been set. The door must travel through

a complete cycle, UP and DOWN, in order for the force to be set properly. If the operator cannot

open and close your door fully, inspect your door to insure that it is not sticking or binding.

The Force Setting has now been set manually.

COMMISSIONING

WHEN SETTING THE TRAVEL

LIMITS, ENSURE PEOPLE ARE

CLEAR OF THE MOVING DOOR

TO AVOID INJURY.

Without a properly installed safety

reversal system, persons

(particularly small children) could be

SERIOUSLY INJURED or KILLED by

a closing door.

• Incorrect adjustment of door

travel limits will interfere with proper

operation of safety reversal system.

• NEVER use force adjustments to

compensate for a binding or

sticking door.

• After ANY adjustments are made,

the safety reversal system MUST be

tested. Door MUST reverse on

contact with 40 mm high object laid

flat on floor.

Safety Beams must be used for all

installations. Installers should

ensure that the doors are installed

in a compliant manner as per

AS/NZS 60335-2-103.

Safety Beams are not needed to

perform the travel limits and force

setting as described here.

WARNING

Figure 2

Figure 1

Figure 3

Figure 4

Figure 5

COMMISSIONING

STEP 13

INSTALL THE ENTRAPMENT PROTECTION SYSTEM

NOTE: LS-Drive is supplied with a pair of monitored entrapment protection

safety beams. They must be installed for the operator to function.

LS-Drive is also compatible with GPS15 Reflective Safety Beams, however

it is not compatible with the GLCPS Light Curtain Protector System.

The Safety Beams are supplied preassembled, complete with two Safety

Beams, wiring and wall brackets. (fig1 & fig2)

Install the mounting brackets and Safety Beams to either side of the inside of

the door, and at a height of no greater than 100 mm off the floor.

The brackets are designed to be used for Wall or Floor fixing, with a variety of

hole combinations to achieve the desired results.

Drill the required holes and install the brackets with wall plugs and screws

provided. Ensure they do not obstruct the door movement.

Wiring Process:

Align the Safety Beams to face each other and tighten if necessary. The wiring

should exit from the bottom of the housing to maintain the correct IP rating and

continued operation.

One sensor is a Sending Eye, the other is a Receiving Eye. Try to avoid

positioning these in direct sunlight as this may interfere with the operation of the

beams.

Run both sets of wire back to the operator CONTROL PANEL. Use the

channels provided on either side of the rail extrusion and secure with the 4

supplied cable clips to ensure cable does not come loose. Mount a cable clip at

either end of the rail - and either side of the rail (figure 4)

Remove Power from the Operator:

At the Operator end, cut the wires to the correct length and strip each back

around 10 mm.

Twist both White wires together and install into terminal 2 (White terminal) (fig 3)

Twist both Grey wires together and install into terminal 3 (Grey terminal) (fig 3)

The Safety Beams are a 2 wired system connected in a parallel configuration.

Reinstall Power to the Operator:

When aligned correctly the Red LED on each sensor will remain “ON

constantly”.

If incorrectly aligned both LEDs will “flash”.

Correct the alignment if necessary.

The operator is now ready to be checked for correct IR Beam operation.

Test Operation

Press the Up button in the Control Panel and check the door travels smoothly

to the open limit position.

If there are no issues detected, press the Down button and check the door

travels to the closed limit position. Open and close the door again, and

obstruct the IR beam while closing to check the door stops and reverses to the

open limit position.

If the door and operator are functioning correctly proceed to the next step.

Figure 1

Figure 2

Figure 3

Figure 4 Channels for

safety beam

cables

Cable clip

To prevent entrapment, install The Safety

Beams no higher than 100 mm above the floor.

Disconnect power to the operator before

installing the safety beams.

WARNING

White x 2 Grey x 2

COMMISSIONING

STEP 14

SETTING TIMER-TO-CLOSE

Operation:

This feature allows the door to automatically close from a fully open

position after a specified time. The delay can be set from 10 to 180

seconds in 10 second increments, by using the buttons on operator

control panel.

If the door encounters an obstruction while closing, the door will stop

and return to the OPEN limit position. The LED indicator light will

then flash 10 times.

To Activate TTC, or change a preset time:

1. Start with the door fully CLOSED.

2. Enter into TTC Activation mode by pressing both PROG and

DOWN buttons together for 3 seconds (figure 2). Release when

the LED indicator light flashes twice.

3. Press the UP button once for each 10 second increment required

of TTC (figure 3. eg. twice for 20 seconds). Press the DOWN

arrow button to reduce, if needed.

4. Press and release the PROG button to save this time

(figure 4), LED indicator light will flash once. TTC is now activated.

TEST: Operate the door to the OPEN limit position. Keep clear of the

Safety Beams and check the door closes after the preset time.

When TTC is set, wireless transmitters and wired trigger inputs

will send an "open-only" command to the operator.

To Deactivate TTC:

1. Enter into TTC Activation mode by pressing both PROG and

DOWN buttons together for 3 seconds (figure 2). Release when

the LED indicator light flashes twice.

2. Press and release the PROG button to save (figure 4), LED

indicator light will flash once. TTC is now deactivated.

STEP 15

ATTACHING BATTERY BACKUP UNIT (OPTIONAL)

LS-Drive is compatible with the separate Grifco Battery Backup accessory GLD-

BBU24V. The BBU should be attached after the LS-Drive has been installed.

1. TURN MAINS POWER OFF BEFORE PROCEEDING

2. Remove plugs on either side of the BBU to reveal mounting holes.

3. Mount the BBU to the ceiling, wall or on top of the rail.

4. Plug the BBU into the operator's BBU socket, located on top of the operator,

near where the power cord is connected

5. Turn mains power back on

6. Unit will now function under BBU power. BBU will automatically charge and

remain fully charged

7. Operate the door with and without mains power connected to test BBU

functionality.

BBU Wall or Ceiling Mounting Instructions

Remove the plugs from the BBU screw holes. Mount the BBU to the wall or

ceiling using the 2 screws provided. Ensure that the screws are secured to a

structural part of the wall or ceiling

Door may operate unexpectedly, therefore do not allow

anything to stay in the path of the door.

WARNING

Battery Backup

connection

socket

Mounting holes

(x2)

Mounting

screws

provided

(x2)

Indicator LED

Door Fully Closed

Indicator LED

ndicator LED

Figure 1

Figure 2

Figure 3

Figure 4

STEP 16

COMMISSIONING REMOTE ACCESS DEVICES

NOTE: The transmitter supplied with your operator is

preprogrammed by the factory.

Program the Receiver to Match Additional Transmitter Codes:

Using the yellow “LEARN” Button

1. Press and Hold the button on the hand-held remote or wall

button that you wish to use (1).

2. Press and release the yellow “LEARN” buton on the operator (2).

3. Release the remote button. When the LED indicator flashes the

operator has learned the code. If you release the remote control

push button before the operator light flashes, the operator will not

learn the code.

Now the operator will activate when the remote control push

button is pressed.

To Erase all Remote Control Codes

1. Press and Hold the yellow “LEARN” button on the operator until

the indicator LED goes ON, and continue holding for approx. 6

seconds, until the indicator LED goes out.

2. Release the button, all codes are now erased.

Wireless Keypad E840G

To set the keyless entry PIN:

1. Locate the yellow “LEARN” button on the door operator.

2. Press and release the yellow “LEARN” button. The LED indicator

light will glow steadily.

3. Enter a 4-digit personal identification number (PIN) of your choice

on the keypad.

4. Press and hold the ENTER button. Check to see if the operator

light flashes. Release the ENTER button after the light flashes.

To change an existing keyless entry PIN:

1. Enter the existing programmed PIN that you want to change.

2. Press and hold the # button until the LED indicator light flashes

twice.

3. Enter the new 4-digit PIN of your choice, then press the ENTER

button. The light will flash once.

4. To test, enter the new PIN, then press the ENTER button. The

operator will activate.

Activate the operator only when door is in full view,

free of obstruction and properly adjusted. No one

should enter or leave garage while door is in motion.

Do not allow children to operate push button(s) or

remote(s). Do not allow children to play near the door.

WARNING

2. Yellow Learn Button

Locate the Yellow Learn

Button

Press & Release Yellow

Learn Button

Enter a 4-digit code of

your choice

Press & hold the Enter

Button until the Operator

light flashes

After the lights flash

release the Enter button

COMMISSIONING

COMMISSIONINGCOMMISSIONING

STEP 17

COMMISSIONING myQ

myQ INTERNET GATEWAY (not provided)

LR-Drive is compatible wth Chamberlain Group's myQ connectivity

feature.

You will need a broadband internet connection to use the Internet

Gateway.

PROGRAMMING myQ

Please refer to the myQ manual supplied with the Internet

Gateway.

STAR1000EVO

Transmitter

Managment

Device

E960G

4-Channel Keyring

Transmitter

E943G

3-Channel Visor

Transmitter

E138G

2-Channel

Wall

Transmitter

E840G

Wireless

Security

Keypad

All Grifco remote access devices feature Security +2.0 technology. This

advanced platform cuts through interference, and ensures consistent,

reliable, long range operation of your commercial door.

With inbuilt perpetual rolling code technology, Grifco Security +2.0

transmitters are safe and secure. All devices feature exceptional battery life,

easy conﬁguration and long range.

TYPES OF SECURITY +2.0 REMOTE ACCESS DEVICES

MAINTENANCE AND CARE

USING YOUR OPERATOR

1. Your operator can be activated by any of the following devices:

• Operator control panel: Up and Down Buttons

• The Outside Keyswitch or Keyless Entry System (if you have

installed either of these accessories).

• The Remote Control Transmitter. Hold the push button down until

the door starts to move.

2. Opening the Door Manually: DOOR SHOULD BE FULLY CLOSED IF POSSIBLE. Weak or broken springs could allow an open door to

fall rapidly. Property damage or serious personal injury could result.

The door can be opened manually by pulling the release handle down. To reconnect the door, pull the manual release rope towards

the motor until it springs back to its original horizontal position.

Do not use the manual release handle to pull the door open or closed.

3a. When TTC is not set.

When the Operator is Activated by Remote Control:

1. If open, the door will close. If closed, the door will open.

2. If closing, the door will stop.

3. If opening, the door will stop.

4. If the door has been stopped in a partially open or closed

position, it will reverse direction.

5. If an obstruction is encountered while closing, the door will

reverse to the OPEN limit position.

6. If an obstruction is encountered while opening, the door will

stop and reverse for a short distance.

7. The Safety Beam uses an invisible beam which, when

broken by an obstruction, causes a closing door to open

and prevents an open door from closing.

4. The operator lights will turn on under the following conditions: when the operator is initially plugged in; when power is restored after

interruption or when the operator is activated. Lights will turn off automatically after 2-1/2 minutes.

CARE OF YOUR OPERATOR

Once a Month

• Disconnect power cord when performing service or maintenance.

• Manually operate door. If it is unbalanced or binding, call a qualified door technician.

• Check to be sure door opens & closes fully. Adjust limits and/or force if necessary.

Once a Year

• Disconnect power cord when performing service or maintenance.

• Internally the operator does not require additional lubrication.

• Lightly grease the chain and inside the rail assembly where the trolley slides. Be careful to use gloves around any sharp

metal edge or the rail.

3b. When TTC is set.

When the Operator is Activated by Remote Control:

1. If open, the door will not move, but the timer will reset

2. If closing, the door will stop and open.

3. If opening, the door will continue towards the open limit.

4. If the door has been stopped in a partially open or closed

position, it will open.

5. If an obstruction is encountered while closing, the door

will open.

6. If an obstruction is encountered while opening, the door

will stop and reverse for a short distance.

7. The Safety Beam uses an invisible beam which, when

broken by an obstruction, causes a closing door to open

and prevents an open door from closing.

Before opening the door manually, ensure

door is at its CLOSED limit position if possible.

WARNING

TROUBLESHOOTING

1. Operator doesn't operate from either door control or remote:

• Does the operator have electric power? Plug lamp into

outlet. If it doesn't light, check the fuse box or the circuit

breaker. (Some outlets are controlled by a wall switch.)

• Have you disengaged all door locks? Review installation

instruction warnings on page 1.

• Is there a build-up of ice or snow under door? The door

may be frozen to ground. Remove any obstruction.

• The door spring may be broken. Have it replaced.

2. Door operates from door control but not from remote:

• Replace batteries in the remote if necessary.

• If you have two or more remotes and only one operates,

review Program Your Operator, Remote and Keyless

Entry.

3. Remote has short range:

• Check the battery in the remote is fully charged.

• Change the location of the remote control in the car.

• A metal door, foil-backed insulation or metal siding will

reduce the transmission range.

4. Door reverses for no apparent reason and operator light flashes

10 times:

• Check Safety Beams. If the light on the Safety Beams is

flashing, correct the alignment.

• NOTE: Operator will not close without Safety Beams

connected.

5. The door opens and closes by itself:

• Make sure remote push button is not stuck "on".

6. Door stops but doesn't close completely:

• Repeat Programming the Travel Limits

• Repeat safety reverse test after any adjustment of door

arm length, close force or down limit adjustments.

7. Door opens but won't close:

• Check Safety Beams. If the light on the Safety Beams are

flashing, correct the alignment.

• If operator light does not flash and it is a new installation,

repeat Programming the Travel Limits.

8. Operator strains:

• Door may be unbalanced or springs are broken.

• Close door and use manual release rope and handle to

disconnect trolley.

• Open and close door manually.

• A properly balanced door will stay in any point of travel while

Being supported entirely by its springs. If it does not, call for

professional garage door service to correct the problem.

9. Operator hums briefly, then won't work:

• Garage door springs are broken. SEE ABOVE.

• If problem occurs on first operation of operator, door is

locked. Disable door lock.

• Repeat safety reverse test after adjustment is complete.

10. Operator won't activate due to power failure:

• Pull manual release rope and handle down to disconnect

trolley.

• Door can be opened and closed manually.

• When the power is restored, pull the manual release rope

back towards the motor until it springs back to its original

horizontal position. The next time the operator is activated,

the trolley will re-connect.

• The Outside Quick Release accessory (if fitted) disconnects

the trolley from outside the garage in case of power failure.

11. The operator runs, but the carriage does not move:

• Check the carriage is not disengaged from the operator

• Operate the manual release to reengage the operator.

• In a new installation, the preassembled Motor Shaft Adapter

may have fallen out of the chain sprocket assembly. This

adapter is installed during the manufacturing process and

may have dislodged.

12. The Up and DOWN arrow buttons on the control panel are

flashing in sequence:

• Check the diagnostic code on next page.

TROUBLESHOOTING

DIAGNOSTICS

The operator is programmed with self-diagnostic capabilities. The UP and DOWN arrows on the control panel indicate the diagnostic code.

DIAGNOSTIC CODE SYMPTOM POSSIBLE RESOLUTION

UP Arrow

Flashes

DOWN Arrow

Flashes

1 1 The operator will not close and

the courtesy light flashes.

Safety sensors wires may have been reversed, cut or

disconnected. Inspect the sensor wires for correct polarity,

damage or disconnections.

1 2 The operator will not close and

the courtesy light flashes.

There is a short circuit on the wires for the safety sensors. Inspect

safety sensor wire at all staple points and connection points and

replace wire or correct as needed.

1 4 The operator will not close and

the courtesy light flashes.

Safety sensors are misaligned or were momentarily obstructed.

Realign both sensors to ensure both LEDs are steady and not

flickering. Make sure nothing is hanging or mounted on the door

that would interrupt the sensors path while closing.

1 5 There is no door movement or

motor accelerates before

stopping suddenly.

No RPM pulses have been detected. Check the door manually for

balance, binding or obstructions. Internally the possible cause may

be the motor, logic board or RPM sensor. Try resetting door travel

limits. Contact service centre.

1 6 Door continues to move after

the motor stops.

RPM pulses have been detected after motor has turned off.

Possible broken spring. Check the door is correctly balanced and

not creeping up or down. Contact a door service centre.

2 1

Operator fails to operate. Possible logic board failure. Reboot operator by turning the mains

power OFF and then ON after 15 seconds. Reprogram the door

travel limits and force settings. Contact service centre.

2 6 Unable to set travel limit down

direction. Passpoint has not

been recognised during

programming.

Check the passpoint module has been activated by the chain

Position Tab, during the door travel. Reset the travel limits.

4 1

Door is moving stops and or

reverses.

Manually open and close the door. Check for binding or

obstructions, such as a broken spring or door lock. If the door is

binding or sticking contact a trained door systems technician. If

door is not binding or sticking attempt to reprogram travel (refer to

“Program the Travel Limits and Force” section).

5 1

Door fails to operate or

operates erractically. External

accessory wiring failure.

Check the external wiring to the control panel terminal is wired

correctly. Turn off power, remove all external wiring (except safety

sensors), and retest door operation.

5 5 Door operator fails to operate Low internal voltage on the Logic Board, possible power

transformer or logic board failure. Service required, call a trained

service specialist.

SERVICE AND REPAIR PARTS

If the supply cord is damaged, it must be

replaced by the manufacturer, its service

agent or similarly qualified persons

in order to avoid hazard.

Power cord

026B0181

Passpoint assembly

002A1965

Transformer

041A4027

Transfer Board

041A0034

LED module

041A4002-1

Chassis cover assembly

002A1964

Motor shaft adapter (metal)

041A4017-1

Rail Replacement Parts

Position tab (chain)

041A4016

Trolley latch (chain)

041A0043

Trolley assembly

002A1962

Drive sprocket assembly

002A1963

Motor assembly

041A0227

PCB

041A0045

Chamberlain Australia Pty Limited / Chamberlain New Zealand Limited (Chamberlain) is committed to manufacturing and supplying high quality goods. As part of this

commitment, we seek to provide reliable service and support for our goods and are pleased to provide you, the original purchaser, with this Chamberlain Limited

Warranty.

We also provide the following statement as required by the Australian Consumer Law: In Australia, in addition to your rights under this Chamberlain Limited Warranty,

our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for

compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable

quality and the failure does not amount to a major failure.

Chamberlain’s warranty

Chamberlain warrants to the original purchaser of the Grifco product (Unit) that:

1 The LS-Drive Unit (including electric motor) is free from defects in materials and workmanship for a period of 24 months from the date of purchase or 20,000

cycles (whichever comes first).

2 During the applicable Chamberlain Warranty period, if you are concerned that the Unit or electric motor may be defective, call our service centre on the toll free

number below before removing the Unit and a Chamberlain technician will diagnose the problem. Once the problem has been diagnosed, subject to your rights

under the Australian Consumer Law with respect to major failures,

Chamberlain will provide you with:

1 parts for “do-it-yourself” repairs; or

2 shipping instructions for a factory repair or replacement.

If a factory repair or replacement is required, provided the defective part or Unit is returned to Chamberlain well-packaged and in accordance with Chamberlain’s

shipping instructions,

Chamberlain will, subject to your rights under the Australian Consumer Law with respect to major failures in relation to the Unit, repair or, at its option where

permissible, replace any defective part or Unit and return it to you at no cost; and

Exclusions

If our service centre determines that a warranty claim has been made in respect of a failure or defect arising under or out of any exclusion detailed below such that

the claim is not covered under this Chamberlain Limited Warranty, we may, subject to your other rights and remedies as a consumer, charge you a fee to repair,

replace and/or return the Unit to you.

This Chamberlain Limited Warranty does not cover any failure of, or defect in, the Unit due to:

1 non-compliance with the instructions regarding installation, operation, maintenance and testing of the Unit or of any product with which the Unit is used;

2 any attempt by a person other than an authorised installer to change settings, repair, dismantle, reinstall or move the Unit to another location once it has been

installed;

3 tampering, neglect, abuse, wear and tear, accident, electrical storm, excessive use or conditions other than normal commercial use;

4 use of the Unit in conjunction with controls which have not been supplied, or pre-approved, by Chamberlain;

5 problems with, or relating to, the commercial door or commercial door hardware, including but not limited to the door springs, door rollers, door alignment, hinges,

guides, slats and drums; or

6 problems caused by electrical faults.

If this Chamberlain Limited Warranty does not apply, you may have rights available to you under the Australian Consumer Law.

Liability – Australia only

Except as set out in the Australian Consumer Law (being Schedule 2 of the Competition and Consumer Act 2010) (as amended, consolidated or replaced):

1 all other guarantees, warranties and representations in relation to the Unit or its supply are excluded to the extent that Chamberlain can lawfully exclude them; and

2 under no circumstances will Chamberlain be liable for consequential, incidental or special damages arising in connection with the use, or inability to use, the Unit,

other than those which were reasonably foreseeable as liable to result from the failure.

Liability – New Zealand only

Except as set out in the Fair Trading Act 1986 and the Consumer Guarantees Act 1993 (as amended, consolidated or replaced):

1 all other guarantees, warranties and representations in relation to the Unit or its supply are excluded to the extent that Chamberlain can lawfully exclude them; and

2 under no circumstances will Chamberlain be liable for consequential, incidental or special damages arising in connection with the use, or inability to use, the Unit,

other than those which were reasonably foreseeable as liable to result from the failure.

Note

We request that you retain your sales docket or invoice as proof-of-purchase and attach it to this manual to enable you to establish the date of purchase in the

unlikely event of a warranty service being required. Chamberlain reserves the right to change the design and specifications of the Unit without prior notification. Some
