Grindmaster Cecilware GB Series User manual

Powdered Beverage Dispenser
Operator Manual
GB Models 1, 2, 3, 4, 5, & 6
Model GB3M10-LD Model GB5M10-LD
Safety Information..................2
Installation...............................3
Operation ................................6
Cleaning...................................8
Maintenance .........................10
Troubleshooting Guide.........13
Parts Diagram and List..........15
Wiring Diagrams ...................23
Thank you for purchasing this quality powdered beverage dispenser. For your safety and the safety of others,
read all warnings and the operator manual before installing or using the product. Properly instruct all operators.
Keep training records. For future reference, record serial number here:
Table of Contents
Model GB1HC
Grindmaster-Cecilware
4003 Collins Lane, Louisville, KY 40245 USA
Phone: [phone] Toll Free: 800.695.4500
Fax: [phone]
Web: gmcw.com Email: [e-mail]
©2016 Grindmaster-Cecilware
Printed in USA
0516 Form # CW-314-01
Part # 390-00013
Grindmaster-Cecilware provides the industry’s
BEST warranty. Visit gmcw.com for warranty
terms and conditions.

Lifting hazard. Single person lift could cause injury. Use assistance when moving or lifting.
For safe and proper operation, the appliance has to be placed in a stable, vertical position.
The appliance is not to be used by persons with reduced physical, sensory, or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction. Be sure to provide supervision
or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Children must be supervised to ensure they do not play with the appliance.
The appliance is only to be installed in locations where it can be overseen by trained personnel.
CAUTION
To avoid damaging unit, turn on power and wait for tank to fill with water before turning on heater.
Observe machine voltage configuration. Do not apply improper voltage to machine or damage to machine will
occur.
Do not use extension cord.
NOTICE
The appliance is not intended for outdoor use.
Do not clean with pressurized water or use in an area where pressurized water may be used.
Cleaning and maintenance shall be made only by properly trained persons with supervision.
WARNING
Safety Information
2 Cecilware®GB Series
Important Safety Information
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
For your safety and the safety of others, read all warnings and the operator manual before installing or using
the product.
DANGER: This term warns the user of imminent hazard that will result in serious injury or death.
WARNING: This term refers to a potential hazard or unsafe practice, which could result in serious injury or death.
CAUTION: This term refers to a potential hazard or unsafe practice, which could result in minor or moderate
injury.
NOTICE: This term refers to information that needs special attention or must be fully understood.

CAUTION: Lifting hazard. Single person lift could
cause injury. Use assistance when moving or lifting.
Water Inlet Connection:
NOTICE: This equipment is to be installed to comply
with the applicable Federal, State, or local plumbing
codes having jurisdiction. In addition:
1. A quick disconnect water connection or enough
extra coiled tubing (at least 2x the depth of the
unit) so that the machine can be moved for
cleaning underneath.
2. An approved backflow prevention device, such as
a double check valve to be installed between the
machine and the water supply.
The GB beverage dispenser is equipped with a 1/4"
Flare Water Inlet fitting, which is located on the left
side in the back of the base (when looking at the
machine from the front).
Water pipe connecting and fixtures directly connected
to a potable water supply shall be sized, installed, and
maintained in accordance with Federal, State, and
Local codes.
HIGHLY RECOMMENDED:
A WATER SHUT-OFF VALVE and A WATER FILTER,
preferably a combination Charcoal/Phosphate Filter, to
remove odors and inhibit lime and scale build up in the
machine.
Note: In areas with extremely hard water, a water
softener must be installed in order to prevent mineral
deposits that could result in malfunctioning of the
equipment and in order not to void the warranty.
Unpacking Instructions
Carefully unpack the GB Machine and inspect
immediately for shipping damage. Your GB Machine
was shipped in a carton designed to give it maximum
protection in normal handling. It was thoroughly
inspected before leaving the factory. In case of
damage, contact the shipper, not Grindmaster-
Cecilware.
After the machine has been unpacked and placed on a
counter, pull out the stainless steel drip tray. It should
contain the following:
• 1/4” Flare Water Inlet Fitting.
GB Series Cecilware®3
Installation

4 Cecilware®GB Series
DRIP TRAY DRIP TRAY
14 lb.14 lb.
2K- GB GB2-SKI
DRIP TRAY
4 lb. 4 lb.
GB2-LP
4 lb. 4 lb.
DRIP TRAY
GB2M-5.5
51
2lb. 51 2lb.
LAMP
SOCKET
LAMP
PRODUCT GUIDE
LAMP
STARTER
CORD SET
WHIP CHAMBER
DRIP TRAY
14 lb.
GB2-Super SKI
14 lb.
SHELF
CUP SIZE,
VOLUME
ADJUSTMENT
GRAM THROW,
STRENTH
ADJUSTMENT
HOT WATER SPOUT
CAPP. SPOUT [2]
RIGHT SIDE VIEW
FRONT VIEW GB3 SHOWN
SPOUT
LABEL AREA
DISPENSE BUTTON
PRODUCT LABEL
POWER SWITCH
PILOT LIGHT FOR
HEATER
RINSE SWITCH
DRIP TRAY
HI-LIMIT (TEMP)
WATER LEVEL CONTROL
DISPENSE VALVE
TANK ASS'Y
HEATER ASS'Y
AUGER MOTOR
THERMOSTAT
DRAIN HOSE W/PLUG
WATER INLET VALVE
POWER
CORD
RELAY/TIMER
WHIPPER MOTOR
BLOWER DUCT HOSE
DRIP TRAY
FAN/BLOWER
WATER INLET HOSE
Description and Location of Components
Note: Refer to following illustration for description and location of COMPONENTS and CONTROLS.
Installation (continued)

GB Series Cecilware®5
Installation (continued)
1. HOPPERS: Depress the door latch on the left
side of the door and pull door open to access
the hoppers.
• The hoppers hold up to 14 lbs. (14 kg) of
Cappuccino product and up to 1.5 lbs. (0.7kg) of
freeze dried coffee product, depending on
model.
• To remove the hoppers swing the top
compartment door open and lift out the
hoppers.
• To reposition the hoppers in the
compartment, slide the hopper base back
between the rails until the 1/4" pin at the
bottom of the hopper base falls into the 1/4"
positioning hole of the compartment base
cover.
2. RINSE SWITCH: With the door open, the rinse
switch is located on the left side of the first
Whipper chamber.
• In the RINSE position, it disengages the
hopper motors and allows only water to be
dispensed.
• It is used for flushing out the Whipper
Chambers and to adjust the water dispense
valves for proper flow rates.
3. HEATER SWITCH: This switch is located inside
the cabinet behind the right hopper. Open door
and remove right hopper to access it.
• Its primary function is to shut off the heating
element during the initial priming, start-up
operation of the machine, or whenever the
tank is being drained for service.
Note: The Power Switch and Heater Switch must
be ON in order for the elements to operate.
4. POWER SWITCH: This switch is located on the
left side of the splash panel below the door. On
120V, 1.8 KW and 120/240 or 240V, 3 KW single
element machines the power switch controls all
power to the machine including the heater
elements.
Note: On 120/240V, 6 KW machines, the Power and
Heater Switches are independent of each other.
Both switches must be OFF in order for the
machine to be completely shut down.
5. WATER LEVEL CONTROLS: Under normal
conditions and operation, the water level in the
tank should not drop more than 1/2" (1.3cm)
from the probe. If it does, the tank is not
refilling fast enough. Check the water line and
water filter; they may need cleaning or
replacing.
1. Tank Control Board Part# 349-00012
(Export 240V Part# L706AL)
2. Water Inlet Valve Part# L462AL
(Export 240V Part# L426AL)
3. Water Level Sensor Part# K695QL
Start-up Procedure
NOTICE: Make sure that the Heater Switch, located
behind right hopper with door opened, is in the OFF
position.
1. Connect the 1/4" dia. copper waterline to the
1/4" flare water inlet fitting of the valve.
2. Plug the power cord(s) into a proper receptacle.
Note: GB8M10 units use two power cords. Each cord
must be plugged into a separate receptacle.
3. Activate the Power Switch (Toggle Up). The
door display panel, the red power indicator
light and the green dispense buttons will light
up and the tank will start filling. Allow
approximately 4-5 minutes for the tank to fill.
4. Activate the Heater Switch. Allow
approximately 10-30 minutes for the water to
reach a temperature of 190°F (88°C). The heat
up time will depend on the water inlet
temperature, the input voltage, and the
wattage of the elements in the machine.
5. Place a 8 oz. (240ml) or larger cup under the left
dispense nozzle, press and hold the left
dispense switch for 6 seconds. The machine will
dispense water at the rate of 1 oz. (30ml) per
second. Repeat it several times to check for
consistent output. Repeat same for the other
dispense switches. This procedure checks that
the dispense valves are not air-locked.
6. While the tank is heating, remove the hoppers,
load them with products, and reposition them
back in the machine. When the green ready
light comes on, the tank has reached its brew
temperature and the machine is ready to
dispense the first cup of Cappuccino.
Filling the Hoppers
1. To remove the hoppers, swing the top
compartment door open and lift out the
hoppers.
2. Fill each hopper with the correct product.
3. Reposition hoppers in the hopper
compartment, making sure the hoppers are
properly seated.
If you need help, call Grindmaster-Cecilware Technical
Service Department, [phone] or [phone]
(USA & Canada only) 8 AM - 6 PM EST.
Prior authorization must be obtained from
Grindmaster-Cecilware for all warranty claims.

6 Cecilware®GB Series
Your new powdered beverage dispenser is easy to
operate and maintain. Before you place it in service,
please have all personnel familiarize themselves with
these instructions. Keep this manual in a convenient
place for ready reference.
How to Operate
To dispense a cup of Cappuccino or Coffee:
• Place an 8 oz. (240ml) or larger cup under selected
drink dispense nozzle.
• For Manual units: Push and hold brew button until
cup is 2/3 full, then release button.
• For Automatic units: Press and Release button. Cup
will fill up automatically to its preset amount.
Adjustments
Water Flow Rate Adjustment
Adjust water flow rate to correct level in Whipping
Chamber.
The Dispense Valves are factory adjusted for a
maximum Flow Rate of 1 to 1.3 oz./sec (30-38 ml/sec).
[Approximate settings: 1.3 oz./sec (38 ml/sec) for
COFFEE and CAPPUCCINO]
Exceeding this Flow Rate will cause the Mixing Chamber
to overflow.
Note: To access the Water Dispense Valves, open door
and remove Hoppers.
Temperature Adjustment (Tank Control Board
Type)
1. Locate the Tank Control Board.
2. Press button under right side of display to increase
temperature.
3. Press button under left side of display to decrease
temperature.
4. Pressing both buttons simultaneously will reset to
default 190°F (88°C).
Temperature Adjustment (Thermostat Type)
1. Locate Thermostat: Remove the right side panel.
Thermostat is mounted on side of tank.
The GB beverage dispensers are factory set to
deliver hot brewing water at 190°F (88°C) with the
thermostat knob turned to full ON position. If
adjustments should be necessary to increase or
decrease the water TEMPERATURE, proceed as
follows:
Note: Set the Rinse Switch to ON. This will disengage
the Hopper Motors when dispensing water for
Temperature measurements.
2. To INCREASE the water temperature - With the
Thermostat Knob to its maximum clockwise
position, remove the knob and locate the slotted
adjustment screw inside the hollow thermostat
shaft. Using a narrow-bladed screwdriver, engage
slotted adjustment screw and turn it ¼ turn slowly
counter-clockwise.
Allow a few minutes for the temperature to reach
set level. The Heater Light will go ON, indicating the
heating element is activated, wait for it to go OFF,
indicating that the water has reached new set
temperature. Take a temperature reading and
repeat if necessary.
3. To DECREASE the water temperature - simply turn
the Thermostat Knob one notch counter-clockwise
to the next lower dial setting.
Display
Decrease
Increase
190°
Operation
WATER FLOW ADJUSTMENT
DISPENSE VALVE
TO ADJUST WATER FLOW RATE:
1. Open door and remove
hoppers. Locate Dispense
Valve behind hoppers,
mounted on tank.
2. Locate adjustment screw on
Dispense Valve.
3. Using Allen Key or flat
screwdriver rotate, 1/4 turn at
a time,
CLOCKWISE to decrease water
flow, or
COUNTERCLOCKWISE to increase
water flow.
4. Check water flow output,
after each 1/4 turn.
CORRECT WATER
LEVEL FOR MAX
FLOW RATE.
MIXING CHAMBER
Adjust Water Flow Rate so that the
water level reaches half way up in
the Mixing Chamber, as shown. TRIANGULAR RIB
DISPENSE CAP

GB Series Cecilware®7
Operation (continued)
GB SKI SUPER - VOLUME AND PRODUCT STRENGTH ADJUSTMENTS
DRINK STRENGTH ADJUSTMENTS - by adjusting the Auger Speed.
I. UNITS WITH FIXED SPEED AUGER MOTORS-AC [CD150] - Fixed Auger Speed [95 RPM] and dispenses powder at a constant fixed rate.
Drink Strength adjustments can be made by adjusting the water flow rate on the Water Dispense Valves.
1. Remove Hoppers to access the Dispense Valve, located behind the hoppers.
2. Locate Flow Adjustment Screw on Dispense Valve.
3. Rotate adjustment screw Counterclockwise to INCREASE Flow Rate, Clockwise to DECREASE Flow Rate.
(Note: the water flow rate shouldnot exceed 1 to 1.3 oz./sec.)
Do not turn Adjustment Key more than 1/4 turn at atime without checking drink strength (ratio of water to powder).
II. UNITS WITH VARIABLE SPEED AUGER MOTORS-DC [CD151] - Variable Auger Speed [10 to 130 RPM]
Drink or Product Strength adjustments can be made by adjusting the Auger Motor RPM [knob on inside door panel],
which controls the amount of product being dispensed [gram throw]. The gram throw is factory preset at 7.
Because the consistency of each product varies, the customer can set the desired gram throw for each hopper.
The water flow rate on the Dispense Valves should remain fixed.
Note: the water flow rate shouldnot exceed 1-1.3 oz./sec to avoid spillage from dispense chamber.
DRINK SIZE ADJUSTMENTS
a. Manual Machines : Holddown the Dispense Button until desired amount is dispensed.
b. Automatic Machines with Timer L493A on Inside Door Panel NOT Programmable] & speed control
board L556A: To increase the volume, turn the dial to the next increment. [0-1 is equivalent to 2 sec.]
c. Automatic Machines with Programmable "Teach me"Timers [L576A or L582A]: These units do not
have acup sizeadjustment knob inside the door, since the timer is programmablefrom the dispense button.
PROGRAMMING FOR AUTOMATIC DISPENSE WITH BUZZER
1. Turn Power Switch ON (toggleswitch inside door).
2. PRESS and HOLD [red] STOP Button with one hand.
3. PRESS and HOLD [green] DISPENSE Button with other hand.
4. RELEASE [red] STOP Button ONLY.
5. Continue to HOLD [green] DISPENSE Button until buzzer sounds
for (4 SEC. DELAY),then RELEASE.
6. PRESS and RELEASE [green] DISPENSE Button. Product begins dispensing.
When it reaches the "DESIRED VOLUME",
7. PRESS and RELEASE [green] DISPENSE Button to SET "DESIRED VOLUME".
DISPENSE Button can be "jogged" to top off.
8. PRESS and RELEASE [red] STOP button to LOCK IN"DESIRED VOLUME".
Repeat steps 1 to 8 for each Dispense Button.
PROGRAMMING INSTRUCTIONS FOR MANUAL DISPENSE WITH BUZZER
1. PRESS AND HOLD STOP [red] BUTTON WITH ONE HAND.
2. PRESS AND HOLD DISPENSE [green] BUTTON WITH OTHER HAND.
3. RELEASE STOP [red] BUTTON.
4. CONTINUE TO HOLD [green] BUTTON AFTER BUZZER SOUNDS (4 SEC. DELAY).
5. RELEASE DISPENSE [green] BUTTON.
6. PRESS AND RELEASE STOP [red] BUTTON.
7. YOU ARE READY FOR MANUAL DISPENSE.
The Total Time The Water IsRunning IsAccumulated And Saved Into Memory. For Normal Operation,
Press and Release Dispense Button.
The Timers Have Been Factory Preset for 6 oz. Cups for Coffee; For 8 oz. Cups for Soup and Cappuccino.
To Change To Larger Or Smaller Cup Sizes [Volumes] Repeat Steps 1 To 8 Above.
TO CHECK VOLUME AND GRAM THROW DISPENSED (ratio):
1. Remove the product guide from the hopper and position areceptacleunder the hopper nozzleto catch the gram throw of product.
Also place ameasuring cup under extension tube to catch the water dispensed.
2. Push the dispense button and check the amount of product dispensed, amount of water dispensed, and time [use stop watch] to dispense that water.
3. The amount of of water dispensed in the measuring cup divided by the amount of time to dispense that water is the Water Flow Rate from Dispense
Valve.
FOR CAPPUCCINO: The machine is factory adjusted to dispense 4-4.5 gr./sec. per OZ. Cup. [32 grams Product per 8 oz. cup]
The recommended throw is 28-32 grams per 8 oz. cup for Cappuccino, with 80% fill.
FOR COFFEE: The machine is factory adjusted to dispense 0.3 gr./sec per OZ. Cup. [1.5 grams of coffee product per 5 oz. of liquid (in a6 oz. cup).
The recommended throw is 1.5 to 1.8 grams per 6 oz. cup of Coffee, with 80% fill.
STOP
WATER
HOT

8 Cecilware®GB Series
NOTICE: All sanitizing agents in the food zone must
comply with 21 CFR 178.1010.
Sanitize all food dispensing units periodically. All parts
to be sanitized must be cleaned first. Cleaning and
sanitizing frequency must follow state and local health
department regulations.
Daily maintenance:
1. Rinse whipper chambers
• Position a container under dispense tubes.
• Move rinse switch to "rinse".
• Push and hold each dispense button 3 to 5 sec.
• Move rinse switch to "serve".
Note: On manual dispense machines, push and hold the
dispense buttons for 10 seconds.
2. Empty drip tray, wash, rinse, and sanitize.
3. The outside of the machine can be cleaned with
warm soapy water and a damp cloth.
Weekly maintenance:
1. Product hopper cleaning
• Rotate product guides up, remove hoppers from
machine.
• Empty powder into pans.
• Pull off product guides.
• Remove agitator wheels.
• Unscrew and remove front and back auger locks.
• Remove auger.
• Wash, rinse, sanitize, and air dry all small parts.
• Wash & scrub hoppers and agitator wheel recesses
with bristle brush. Rinse, sanitize, and allow to air
dry.
• Reassemble all hoppers.
• Pour powder into hoppers.
• Install all hoppers into unit.
2. Whipper chamber cleaning
• Remove dispense caps by turning and lifting.
• Remove mixing bowls by lifting and pulling.
• Remove product tubes by pulling down.
• Twist off whipping chambers clockwise.
• Pull off whipper blades.
• Twist off whipper chamber mounts clockwise.
• Remove O-rings.
• Remove tray by pulling levers down.
• Remove both powder trays by pulling levers out.
• Wash, rinse, and sanitize small parts and interior
machine surfaces.
• Reassemble all small parts.
Note: When reassembling, align flat keyway inside
blade with flat keyway of motor shaft. Push the
whipper blade all the way on.
Sanitizing
1. Prepare a sanitizing solution in accordance with
local health department regulations. You may also
refer to the US Food and Drug Administration
regulation 21 CFR 178.1010 “Sanitizing Solutions”
and US Environmental Protection Agency 40 CFR
18.940 “Tolerance exemptions for active and inert
ingredients for use in antimicrobial formulations
(Food-contact surface sanitizing solutions)”.
2 Follow the instructions provided with the sanitizing
agent.
3 Let all sanitized parts drain and air dry. DO NOT
WIPE THEM DRY.
Cleaning

GB Series Cecilware®9
Cleaning (continued)
AUGERBUSHING-BACK
AGITATOR GEAR
AGITATOR WIRE
AUGERBUSHING FRONT
AUGER
PRODUCT GUIDE
DISPENSE CUP
MIXING CHAMBER
WHIPPERCHAMBER
WHIPPERBLADE
'O'-RING #125
MOUNTING BASE
TWIST TO REMOVE
SLINGERDISC
BASE MOUNT GROMMET
MIXBOWL SOCKET
AUGERMOTOR
NUT[2]
EXTENSION TUBE
FLANGE/ NUT

Maintenance
Lit Display Replacement
WARNING Riskof electrical shock. Turn off power to unit before replacing bulb or starter.
To replace the picture inside metal door:
Lift up the two end tabs on top of door with a pointed object or flat head screwdriver.
Pull the entire picture frame out. Open up the two clear panels and replace picture.
Tuck clear plastic panel inside bracket at top.
Be sure to tuck clear panel under bracket before sliding frame assembly inside door.
The longer metal tab side goes in the front.
To replace the picture inside molded door:
Remove molded door front by removing side screws. Slide out clear plastic panel with picture.
Replace picture and slide the plastic panel w/ new picture into the door frame. Then put front molded door back
on with screws on the sides.
PRODUCT
LABEL
10 Cecilware®GB Series
PRODUCT
LABEL
To repla
c

GB Series Cecilware®11
Recommended preventive maintenance
1) Dispense Valves
• Check all dispense valves for lime build-up.
• Drain the water tank to just below the level of
the dispense valves.
• Remove the valves and clean. (Take these valves
apart byhand as shown).
• Replace the assembly as needed (L467AL -120V
or L676AL - 230V import).
• Replace the valve into the tank and refill tank.
• Repair Kit M491QL.
2) • Check all chamber mounts for signs of wear:
• Product runningdown the front of the unit.
• Product built up on the back of chamber
mount.
• Remove chamber mount.
• Clean and re-lubricate motor shaft using food
grade lubricant only.
• Replace with new chamber mount.
3) • Clean out vent motor, trough, and tubing.
• Lift up black tabs, remove trough drawer.
• Clean and replace trough drawer.
• Remove hose assembly from the motor.
• Clean out and replace hose.
WATERFLOW ADJUSTMENT
Maintenance (continued)
Dispense Valve
Chamber Mount

Component Tests
Dual Probe Test
If lack of water persists, check the probe as follows:
1. Turn on the power and water supply.
2. Check inside the tank to make sure the water is
below the Probe.
3. Pull the BLUE wire and terminal OFF the Probe rod.
If water still does not flow after the wire is
disconnected from the Probe, the problem may be
in the Tank Control Board.
4. If water starts flowing into the tank, the Probe may
be grounded, due to excessive liming. Check with
Ohm meter. Clean probe.
Water Inlet Valve Test
1. Turn power OFF. If the water level rises inside a
partially filled tank, the Water Inlet Valve is leaking.
2. Disconnect wires from the Water Inlet Valve coil and
connect a 2 wire line cord to the terminals. Plug it
into a 115V outlet. If water flows in and stops when
you pull it out, the Valve is working correctly.
Repeat this test a few times. The problem may be
in the Probe or Water Level Control Board.
3. If the water does not flow in when the cord is
plugged into an electrical outlet, the Solenoid coil
may be damaged, opened or the valve may have an
obstruction preventing the water from flowing in.
Clean or replace it.
Out of Product Sensor Test
1. Remove Hopper from cabinet, place the palm of
your hand up against the 1 inch diameter round
sensor at the back of the hopper chamber.
2. Listen for relay clicking on and off as you move your
hand towards and away from the sensor.
3 If relay clicks, system is operating OK.
4 Replace with a full hopper and listen for the relay
click.
5 If all this checks out and the out of product light
does not go off, then there must be defective
wiring. See wiring diagram.
Dual Probe Liquid Level Controller Test
(For models manufactured 2015 and prior)
Check the Controller as follows:
1. Make sure there is power input to the Controller at
the terminals AC1 & AC2
Your voltmeter should read 115 Volts. It should read
the same at terminals AC1 & FILL when the water
level is low. This is the output power to actuate the
coil of the Solenoid Valve to open it. The lack of
voltage at terminals AC1 & L-LEVEL or H-LEVEL
indicates that the Controller is not working
properly.
2. Make sure all wire connections are tight, including
ground.
3. If after this, the Controller is still failing to open the
Water Inlet Valve, replace it.
12 Cecilware®GB Series
HOSE NUT ASSY
WATERINLET VALVE
OUT OF PRODUCT
SENSOR
DUAL
PROBE
BLUE
DUAL PROBE LIQUIDLEVEL
CONTROLLER
T5
NL1
4321
GROUNDING
PLATE IN
BACK OF THE
BOARD
GROUND
TERMINAL
SS WATER LEVEL CONTROL CCA
TO PROBE
TO
SOLENOID
SINGLE L398C [120V]
DUAL L690A [120V]
SINGLE L399C[220V]
DUAL L706A [220V]
Maintenance (continued)

GB Series Cecilware®13
Troubleshooting Guide
Before you call for help, please read the following:
Problem Possible Cause Solution
Merchandiser Display not lit.
No power.
Dispensing unit unplugged. Reconnect dispensing unit.
No power from Terminal Block. Check the Terminal Block for loose wire.
Defective light assembly. Replace LED board.
No water when Rinse Switch
is ON.
Water supply OFF. Turn water ON.
Clogged inlet screen (Water Inlet
Valve).
Disconnect water line and clean inlet
screen.
Inoperative Water Inlet Valve. Check connection, if needed replace
Valve.
Loose electrical connection. Check all electrical connections.
No product when Dispense
Button is pressed.
No product in Hopper. Add product.
Auger not working. Engage Hopper/Nut to Motor Gear
(See pg 9).
Damaged, loose, or missing Agitator
Gear.
Replace Agitator Gear (See pg 9).
Inoperative Auger Motor or Relay. Check connections of Motor, Relay, and/or
Switch; if needed replace components.
Hopper outlet clogged. Clean Hopper and check Cartridge Heater.
Faulty Coupling. Replace damaged Coupling components.
Water does not shut off.
Water keeps dispensing.
Leaking Water Inlet Valve. Clean/check fittings of Water Inlet Valve.
Replace Water Inlet Valve if needed. See
Water Inlet Valve Test.
Inoperative Dispense Switch. Check Switch connections. Replace
Dispense Switch if needed.
Inoperative Rinse Switch. Check Rinse Switch connections.
Replace Rinse Switch if inoperative.
Clogged/stuck Water Dispense Valve. Clean or unclog Water Dispense Valve.
Replace Dispense Valve if inoperative.
No water is going into tank at
all.
Water Inlet Valve malfunction. Check Solenoid. Replace if necessary.
See Water Inlet Valve Test.
Water Level Sensor/ Probe malfunction. Check Probe. Replace if necessary. See
Dual Probe Test.
Solid State Level Control Board. Check Water Level Controls. Replace if
necessary. See Dual Probe Liquid
Level Controller Test.
Water will not stop flowing
into water tank.
Water Level Probe malfunction. Check Probe. Replace if necessary. See
Dual Probe Test.
Solenoid (Water Inlet Valve)
malfunction.
Check Solenoid. Replace if necessary. See
Water Inlet Valve Test.
Solid State Water Level Control
malfunction.
Check the Water Level Controls. Replace if
necessary. See Dual Probe Liquid Level
Controller Test.
Water is not heating up in the
water tank.
Heater Switch is OFF. Turn Heater Switch ON.
Thermostat is OFF. (Only models with
separate Thermostat)
Turn Thermostat ON. Turn Knob
Clockwise.
Loose connection on Thermostat. Make sure all wires and terminals on
Thermostat are tight.
Hi-Limit Temperature Switch is
defective.
Replace the Hi-limit.
Heater is burned out or defective. Replace the Heater.
WARNING: To reduce the risk of electrical shock, unplug the dispenser power cord before repairing or
replacing any internal components of the unit. Before any attempt to replace a component, be sure to check all
electrical connections for proper contact.

Troubleshooting Guide (continued)
If you still need help, call Grindmaster-Cecilware Technical Service Department, [phone] or [phone]
option 2 (USA & Canada only) (Monday through Friday 8 AM - 6 PM EST). Please have the model and serial number
ready so that accurate information can be given.
Prior authorization must be obtained from Grindmaster-Cecilware for all warranty claims.
Grindmaster-Cecilware provides the industry’s BEST warranty. Visit our website at GMCW.com for
warranty terms and conditions.
14 Cecilware®GB Series

GB Series Cecilware®15
Parts Diagram and List
Hopper Illustrations
HOPPERASS'YCD104, 7LB, 18" HEIGHT x3"W, W/NYLON AUGER
HOPPERASS'YCD120, 5.5LB, 14" HEIGHT x3"W, W/NYLON AUGER
HOPPERASS'YCD68A, 4LB, 11.5" HEIGHT x3"W, W/NYLON AUGER
HOPPERASS'YCD313, 1LBCOFFEE,7.875" HEIGHT x3"W, W/NYLON AUGER
HOPPERASS'YCD105 (14 lb; 18" HEIGHT X6.25"SQ) W/NYLON AUGER
HOPPERASS'YCD99A (8 lb; 11.5" HEIGHT X6.25"SQ) W/NYLON AUGER
P- HOPPERASS'YCD308 LT& CD309 RT 10 LB, 14"H, W/NYLON AUGER
P- HOPPERASS'YCD177 LT& CD178 RT 8LB, 11.5"H, W/NYLON AUGER
AUGERBUSHING-BACK CD279
AGITATOR GEAR CD117
Agitator Gear with wire CD256
Agitator Gear with spring CD182
AGITATOR WIRE
HOPPERCOVERCD106
HOPPERCD104
HOPPERCD120
HOPPERCD68A
AUGERBUSHING FRONT CD277
NYLON AUGERCD130
(22.5Øx18mmPT)
W/"O" RING CD139
PRODUCT GUIDE CD70A
DISPENSE CUP
CD61A-white / CD272-black
MIXING CHAMBER
CD137-white / CD275 black
WHIPPERCHAMBER
STRAIGHT CD63A-white
STRAIGHT CD316-black
SLANTEDCD362-white
WHIPPERBLADE CD64A
M379A 'O'-RING #125
MOUNTING BASE CD65A-white / CD317-black
TWIST TO REMOVE
SLINGERDISC CD124
BASE MOUNT GROMMETCD66A
MIXBOWL SOCKETCD67A
CD67A W/O-RING M378A CD100
W/O-RING M480A
AUGERMOTOR
CD175 90rpm AC
CD87A 44rpm AC (COFFEE)
CD151 90rpm DC (Portion Control)
AUGERBUSHING FRONT CD102
WITH 0-RING CD103
NYLON AUGERCD130
(22.5Øx18mmPT)
W/"O" RING CD139
PRODUCT GUIDE CD70A
EXTENSION TUBE
M467A - white
H306A-stainless steel
COVERCD160
HOPPERCD105
HOPPERCD99A
AGITATOR CD14 1
AUGERMOTOR
CD175 90rpm AC
CD87A 44rpm AC (COFFEE)
CD151 90rpm DC (Portion Control)
M379A 'O'-RING #125
TWIST TO REMOVE
SLINGERDISC CD124
BASE MOUNT GROMMETCD66A
MIXBOWL SOCKETCD67A
CD67A W/O-RING M378A CD100
W/O-RING M480A
WHIPPERBLADE CD143 or CD64A
NYLON AUGERCD130
(22.5Øx18mmPT)
W/"O" RING CD139
PRODUCT GUIDE CD70A
WHIPPERBLADE CD64A
M379A 'O'-RING #125
TWIST TO REMOVE
SLINGERDISC CD124
MIXBOWL SOCKETCD67A
CD67A W/O-RING M378A
CD100 W/O-RING M480A
AUGERMOTOR
CD175 90rpm AC
CD87A 44rpm AC (COFFEE)
CD151 90rpm DC (Portion Control)
BASE MOUNT GROMMETCD66A
HOPPERCOVER
HOPPERCD177 Left shown
AGITATOR GEAR CD117
Agitator Gear with wire CD256
Agitator Gear with spring CD182
AGITATOR WIRE
NUT [2] CD278
AUGERBUSHING FRONT CD277
AUGERBUSHING-BACK CD279
NUT [2] CD278
HOPPERCD308 Left shown
AUGERBUSHING-BACK CD279
NUT [2] CD278
HOPPERCD313
DISPENSE CUP
CD61A-white / CD272-black
MIXING CHAMBER
CD137-white / CD275 black
MOUNTING BASE CD65A-white / CD317-black
EXTENSION TUBE
M467A - white
H306A-stainless steel
DISPENSE CUP
CD61A-white / CD272-black
MOUNTING BASE CD65A-white / CD317-black
EXTENSION TUBE
M467A - white
H306A-stainless steel
FLANGE/ NUT CD271
FLANGE/ NUT CD271
FLANGE/ NUT CD271
HOPPERASS'YCD338, 5LB, 14"HEIGHT x2.5"W, W/NYLON AUGERHOPPER
ASS'YCD339, 4LB, 12.5"HEIGHT x2.5"W, W/NYLON AUGER
HOPPERCOVERCD187
HOPPERCD338
HOPPERCD339
AUGERBUSHING-FRONT CD277
PRODUCT GUIDE CD70A
DISPENSE CUP CD61A
MIXING CHAM. CD137
EXTENSION TUBE M467A WHIPPERBLADE CD64A
M379A 'O'-RING #125
MOUNTING BASE CD65A
TWIST TO REMOVE
SLINGERDISC CD124
MIXBOWL SOCKETCD67A
CD67A W/O-RING M378A CD100
W/O-RING M480A
BASE MOUNT GROMMETCD66A
AUGERBUSHING-BACK CD279
AGITATOR WIRE
NUT [2] CD278
FLANGE/ NUT CD271
AUGERMOTOR
CD175 90rpm AC
CD87A 44rpm AC (COFFEE)
CD151 90rpm DC (Portion Control)
NYLON AUGERCD130
(22.5Øx18mmPT)
W/"O" RING CD139
AGITATOR GEAR CD117
Agitator Gear with wire CD256
Agitator Gear with spring CD182
WHIPPERCHAMBER
STRAIGHT CD63A-white
STRAIGHT CD316-black
SLANTEDCD362-white
WHIPPERCHAMBER
STRAIGHT CD63A-white
STRAIGHT CD316-black
SLANTEDCD362-white
WHIPPERCHAMBER
STRAIGHT CD63A-white
STRAIGHT CD316-black
SLANTEDCD362-white
MIXING CHAM. CD137
CD65X - ORANGE GROMMET

16 Cecilware®GB Series
Parts Diagram and List (continued)
Hopper Illustrations
HOPPER CD152
MIXING CHAM. CD137
HOPPER CD98A
HOPPER COVER CD106
HOPPER CD144
HOPPER ASS'YCD144, 5.5LB, 14"Hx 3"W, W/WIRE AUGER CD101
HOPPER ASS'YCD152, 4LB, 11.5"H x3"W, W/WIRE AUGER CD101
HOPPER ASS'YCD98A, 4LB, 11.5"H x3"W, W/WIRE AUGER CD74A or CD153
HOPPER ASS'YCD163 (14 lb; 18" HEIGHT X6.25"SQ) W/WIRE AUGER
HOPPER ASS'YCD162 (11 lb; 14" HEIGHT X6.25"SQ) W/WIRE AUGER
HOPPER ASS'YCD161 (8 lb; 11.5" HEIGHT X6.25"SQ) W/WIRE AUGER
HOPPER ASS'YCD185, 5LB, 14"HEIGHT x2.5"W, W/WIRE AUGER
HOPPER ASS'YCD155, 4LB, 12.5"HEIGHT x2.5"W, W/WIRE AUGER
P- HOPPER ASS'YCD179 (LEFT) CD180 (RIGHT) 10 LB,
14"HEIGHT, W/WIRE AUGER
AUGER BUSHING-FRONT CD277
CD306 [W/CD74 &CD153]
WIRE AUGER
CD101 (22.5Øx18mmPT)
CD74A (17Øx12mmPT)
CD153 (17Øx9mmPT)
HOPPER COVER CD187
HOPPER CD185
HOPPER CD155
AUGER BUSHING-FRONT CD277
PRODUCT GUIDE CD70A
DISPENSE CUP CD61A
MIXING CHAM. CD137
EXTENSION TUBE M467A WHIPPER BLADE CD64A
M379A 'O'-RING #125
MOUNTING BASE CD65A
TWIST TO REMOVE
SLINGER DISC CD124
MIXBOWL SOCKET CD67A
CD67A W/O-RING M378A
CD100 W/O-RING M480A
BASE MOUNT GROMMET CD66A
AUGER BUSHING-BACK CD279
MOTOR CD151 DC 90rpm
(Portion Control)
WIRE AUGER CD101
(22.5Øx18mmPT)
AGITATOR GEAR
CD117 [W/CD101]
CD97A [W/ CD153A or CD74A]
CD320 [coffee W/ CD74A]
DC MOTOR CD151 90rpm
(Portion Control)
COVER CD160
HOPPER CD163
HOPPER CD162
HOPPER CD161
AUGER BUSHING-FRONT CD102
W/"O" RING CD103
PRODUCT GUIDE CD70A
DISPENSE CUP CD61A
MIXING CHAM. CD137
EXTENSION TUBE M467A
DC MOTOR CD151 90rpm
(Portion Control)
AGITATOR CD14 1
AGITATOR WIRE
AUGER BUSHING-BACK CD279
M379A 'O'-RING #125
MOUNTING BASE CD65A
TWIST TO REMOVE
SLINGER DISC CD124
BASE MOUNT GROMMET CD66A
MIXBOWL SOCKET CD67A
CD67A W/O-RING M378A
CD100 W/O-RING M480A
AUGER BUSHING
FRONT CD277
PRODUCT GUIDE CD70A
DISPENSE CUP CD61A
MIXING CHAM. CD137
EXTENSION TUBE M467A
WIRE AUGER
CD149 (22.5Ø x24.8mmPT)
CD74A coffee (17Øx18mmPT)
WHIPPER BLADE CD64A
M379A 'O'-RING #125
MOUNTING BASE CD65A
TWIST TO REMOVE
SLINGER DISC CD124
MIXBOWL SOCKET CD67A
CD67A W/O-RING M378A
CD100 W/O-RING M480A
BASE MOUNT GROMMET CD66A
AUGER BUSHING-BACK CD279
MOTOR CD151 DC 90rpm
(Portion Control)
AGITATOR GEAR
CD117 [W/ CD101]
CD97 [W/ CD153 OR CD74A]
CD320 [coffee W/ CD74A]
AGITATOR WIRE
HOPPER COVER
HOPPER CD179 Left shown
AGITATOR GEAR
CD117 [W/ CD101]
CD97 [W/ CD153 OR CD74A]
CD320 [coffee W/ CD74A]
AGITATOR WIRE
M379A 'O'-RING #125
MOUNTING BASE CD65A
TWIST TO REMOVE
SLINGER DISC CD124
BASE MOUNT GROMMET CD66A
MIXBOWL SOCKET CD67A
CD67A W/O-RING M378A
CD100 W/O-RING M480A
WHIPPER BLADE CD143 or CD64A
DISPENSE CUP CD61A
PRODUCT GUIDE CD70A
WIRE AUGER
CD101 (22.5Øx18mmPT)
CD74A (17Øx12mmPT)
CD153 (17Øx9mmPT)
NUT [2] CD278
NUT [2] CD278
NUT [2] CD278
AUGER BUSHING-BACK CD279
NUT [2] CD278
FLANGE/ NUT CD271
FLANGE/ NUT CD271
FLANGE/ NUT CD271
FLANGE/ NUT CD271
WHIPPER CHAMBER
STRAIGHT CD63A-white
STRAIGHT CD316-black
SLANTED CD362-white
WHIPPER CHAMBER
STRAIGHT CD63A-white
STRAIGHT CD316-black
SLANTED CD362-white
WHIPPER CHAMBER
STRAIGHT CD63A-white
STRAIGHT CD316-black
SLANTED CD362-white
WHIPPER CHAMBER
STRAIGHT CD63A-white
STRAIGHT CD316-black
SLANTED CD362-white
EXTENSION TUBE M467A WHIPPER BLADE CD143 or CD64A

GB Series Cecilware®17
Parts Diagram and List (continued)
Tank Assembly

Parts Diagram and List (continued)
Unit Assembly (GB3M shown)
CCW
Serve
Rinse
ON
POWER
CCW
CCW
INSTANTCOFFEE/DECAFF
INSTANDTESPRESSO
ON
OFF
HEATER
18 Cecilware®GB Series
*See Metal Parts List

GB Series Cecilware®19
*See Metal Parts List
Parts Diagram and List (continued)
Unit Assembly (GB2 SKI-SUPER shown)
WATER
HOT
CCW
CCW
CCW

20 Cecilware®GB Series
Parts Diagram and List (continued)
Parts List
ITEM DESCRIPTION GB-LP GBK GBM
GBM-5.5 GB-SKI GB-SUPER-SKI w/ TEACH-ME TIMERS GB6
1 TANK ASS’Y/TANK TOP ASS’Y - SEE METAL PARTS LIST - NEXT PAGE ßßßß ß ß
2 SILICONE HOSE [BREATHER FITTING] [ .375 I.D x 32”] M326A M326AL M326AL M326AL M326AL M326AL M326AL
3 SILICONE HOSE [DISPENSE VALVE] [ .313 I.D x 14.5”] M324A M324AL M324AL M324AL M324AL M324AL M324AL
4 SILICONE HOSE [WATER INLET] [.375 I.D. x 13”] M326A M326AL M326AL M326AL M326AL M326AL M326AL
5 CHECK VALVE [PREVENTS BACKFLOW] [suggested – not supplied] L463AL L463AL L463AL L463AL L463AL L463AL
6 HOSE NUT ASS’Y OR FITTING 359-00098 - - - 359-00029 -
7 WATER INLET VALVE 120V (230V, 50HZ USE L426AL)CD257 L462AL L462AL L462AL L022A L462AL
8 FUSE HOLDER (120/240V ONLY) - - - - C396AL -
9 BUSSMAN SC25 FUSE (GB'S 120/240V ONLY) - - - - CE181 -
10 POWER CORD (230V, 50 HZ USE C112AL) C032SL C032SL C032SL C032SL C032SL C032SL
11 TERMINAL BLOCK FOR 120V [WAS B117A] [FOR 240V USE B116A] 60105 - - - B157AL 60112CWL
12 RELAY CONTROL GB5M, 5K, GB6 L533AL L533AL - - L533AL
13 TANK CONTROL BOARD 349-00012 (FOR 230V 50HZ USE L706AL)ßßßß ß ß
13 [PRIOR TO 10/15 - DUAL WATER LEVEL CONTROL BOARD
USE L690AL - 120V & L706A - 220V)
13 [older SINGLE WATER LEVEL CONTROL BOARD
L398A - 120V & L399A - 220V]
14 STEPDOWN TRANSFORMER (240/120V only) - - - - CE187L -
15 SPEED CONTROL BOARD [Controls Auger Speed GRAM THROW] - - - - L556AL -
16 TRANSFORMER [use w/DC motor & Speed Control CCA] - - - - CF29AL -
17 RELAY, OMRON B129AL B129AL B129AL B129AL B129AL B129AL
18 FAN CD56AL & ELBOW INSERT CD108 [USE FOR GB1, 1SKI, 2, 3, 6 ONLY] ß ß ß ß ß ß
FAN CD224L w/ RW31Q Fan Housing Ass’y [GB4, 5, 2SKI ]
FAN CD166L [230V 50HZ ]
19 DUCT HOSE [for Exhaust Fan] CA214L CA214L CA214L CA214L CA214L CA214L
20 3/4" FEET (SET OF 4) M042AL M042AL M042AL M042AL M042AL M042AL
21 RINSE SWITCH [GB1, GB5 & GB6-L069AL; GB2-L299AL; ßßßß ß ß
GB3-L446AL; GB4 L470AL]
22 POWER SWITCH & HEATER SWITCH (120V) OR [FOR 120/240V USE L299A]L069AL L069AL L069AL L069AL L069AL L069AL
23 HEATER INDICATOR LIGHT (amber C002AL, red C165AL) Use C072AL for GB1MLD C002AL C002AL C002AL C002AL C002AL C165AL
24 GRILL - SEE METAL PARTS LIST - NEXT PAGE ß ß ß ß ß ß
25 DRIP TRAY - SEE METAL PARTS LIST - NEXT PAGE ßßßß ß ß
26 WHIPPER MOTOR-short shaft (ONE PER HOPPER) CD350L CD350L CD350L CD350L CD350L CD350L
(240V- CD399L) (old style CD75AL)
27 SLINGER DISC (ONE PER HOPPER) CD124L CD124L CD124L CD124L CD124L CD124L
28 GROMMET CHAMBER MOUNTING (TWO PER HOPPER) CD66AL CD66AL CD66AL CD66AL CD66AL CD66AL
29 CHAMBER MOUNT (ONE PER HOPPER) CD65AL CD65AL CD65AL CD65AL CD65AL CD65AL
30 “O” RING # 125 (used w/ grommet CD66AL)M379A M379A
31 WHIP BLADE (old style used CD64AL) (ONE PER HOPPER) CD353L CD353L CD353L CD353L CD353L CD353L
32 EXTENSION TUBE PLASTIC (ONE PER HOPPER) M467AL M467AL M467AL M467AL M467AL M467AL
33 WHIP CHAMBER (Straight – CD63AL) OR (Slanted – CD362L)CD63AL ßß CD362L CD63AL CD362L
(ONE PER HOPPER)
34 MIXING CHAMBER [ALTERNATE CD62AL W/ RECTANGULAR WING] CD137L CD137L CD137L CD137L CD137L CD137L
(ONE PER HOPPER)
35 DISPENSE CAP OR SPLASH GUARD (ONE PER HOPPER) CD61AL CD61AL CD61AL CD61AL CD61AL CD61AL
36 “O” RING (#110) (used w/socket CD67A) M378A M378A
37 MIXING BOWL SOCKET (ONE PER HOPPER) CD67AL CD67AL CD67AL CD67AL CD67AL CD67AL
38 DISPENSE BUTTON (GB L455A) / (GB Ski Super L584A) STOP SWITCH L455AL L455AL L455AL L455AL L584AL L455AL
39-43 REPLACE WITH DOOR LIGHTING ASSEMBLY ßßßß ß ß
234-00131 – LIGHTING ASSEMBLY, DOOR, GB1MLP/2LP
234-00132 – LIGHTING ASSEMBLY, DOOR, GB3LP/OATMEAL
234-00133 – LIGHTING ASSEMBLY, DOOR, GB3M5.5/10
234-00134 – LIGHTING ASSEMBLY, DOOR, GB4M5.5/GB5M10
44 DOOR LATCH 61234 U008AL M705ALM705AL61234 M705AL
45 DOOR ASS’Y - SEE METAL PARTS LIST - NEXT PAGE ßßßß ß ß
46 CLEANING INSTRUCTIONS N978AL NQ28AL N978AL N978AL N978AL N978AL
PROGRAMMING INSTRUCTIONS - - - - NF58AL -
47 TIMER “TEACH ME” [PROGRAM. dispense Time/Cup Size]-Single - - - - L576AL -
[Triple L582A] or TIMER [NOT PROGRAM.] - - - - - -
[use w/pot. L577A & dial/cup size labels: NF32A/33A/34A]
48 POTENTIOMETER - USED W/SPEED CONTROL BD [GRAM THROW DIAL] - - - - L557AL -
LABEL, GRAM THROW DIAL- [GB2 NF30A; GB3 ND81A; GB4 NF31A] - - - - NF30AL
49 PRODUCT GUIDE (CHUTE) GB1SKI use , GB2SKI use CD234L CD70AL CD70AL CD70AL ßCD70AL CD70AL
50
HOPPER ASS’Y WITH COVER [w/NYLON auger] OR CD68AL -
ßCD105L CD105L CD180L
& CD185L
HOPPER ASS’Y WITH COVER [w/WIRE auger] (GB1M and GB1HC use CD99AL;
GBM5.5 use CD144L; GB3M10 and GB5M10 use CD185L & CD180L)CD98AL CD155L
51 AC AUGER MOTOR (240V use CD167L)CD175L CD175L CD175L CD175L CD175L CD175L
DC AUGER MOTOR 90 RPM CD151 [W/Screw P443A] Portion Control - Optional - - - - CD151L -
52 SIDE PANELS - SEE METAL PARTS LIST - NEXT PAGE ß ß ß ß ß ß
56 LAMP HOLDER B216AL B216AL B216AL B216AL B216AL B216AL
57 TWIN TUBE BULB 16W
(240V-USE CE80AL TWIN 18W) CE82AL CE82AL CE82AL CE82AL CE82AL CE82AL
