GRIPPLE Express Instruction sheet

Manufacturer’s Recommendations
Manufacturer’s Recommendations
Install
Install
Release
Release
LOADS – Always use product within its stated Safe Working Load
(SWL).
LIFTING & MOVEMENT – Do not use for lifting, such as in a crane or
pulley situation, or for hanging services exhibiting movement or dynamic
behavior. Designed for hanging statically positioned services only.
INSTALLATION: Do not walk or stand on the Gripple product
installation.
PAINTING – Do not paint the Gripple Express fastener. Ensure that the
fastener is in its final position prior to applying any paint to the cable
assembly. Do not move Gripple fastener after painting.
CABLE – Always use Gripple supplied and specified cable. Never
use on coated cable or other cable. Trim any damaged filaments with
Gripple wire cutters before use.
ENVIRONMENT – Gripple products, including Stainless Steel, are
NOT suitable for use in chlorinated / swimming pool environments.
Use standard or Express Gripple hangers in DRY LOCATIONS
ONLY. Stainless Steel Gripple hangers are SUITABLE FOR DAMP
LOCATIONS.
LOADS – Always use product within its stated Safe Working Load
(SWL).
LIFTING & MOVEMENT – Do not use for lifting, such as in a crane or
pulley situation, or for hanging services exhibiting movement or dynamic
behavior. Designed for hanging statically positioned services only.
INSTALLATION: Do not walk or stand on the Gripple product
installation.
PAINTING – Do not paint the Gripple Express fastener. Ensure that the
fastener is in its final position prior to applying any paint to the cable
assembly. Do not move Gripple fastener after painting.
CABLE – Always use Gripple supplied and specified cable. Never
use on coated cable or other cable. Trim any damaged filaments with
Gripple wire cutters before use.
ENVIRONMENT – Gripple products, including Stainless Steel, are
NOT suitable for use in chlorinated / swimming pool environments.
Use standard or Express Gripple hangers in DRY LOCATIONS
ONLY. Stainless Steel Gripple hangers are SUITABLE FOR DAMP
LOCATIONS.
For further technical assistance, please contact:
Gripple Inc. 1611 Emily Lane / Aurora, IL 60502 Phone: [phone] Email: [email protected]
For further technical assistance, please contact
Gripple Inc. 1611 Emily Lane / Aurora, IL 60502 Phone: [phone] Email: [email protected]
INST-XP-USA
www.gripple.com/us
INST-XP-USA
www.gripple.com/us
Installation GuidelinesExpress
Express Installation Guidelines
LUBRICATION – Do not apply oil or any other lubricant to the Gripple
fastener or any other part of the cable assembly.
JOINING – Never join two cable ends together in-line. Only pass the free
end of the cable in a continuous loop through both channels of the Gripple
fastener. The angle inside the Gripple formed loop must not exceed 60˚.
HANGING AT AN ANGLE TO VERTICAL – Ensure that the load
calculation considers the effect of ‘side load’. For example, at an angle
of 60˚ to vertical, the SWL is reduced by 50%. (See published technical
information on website or in Product Guide.)
DUCTING: When installing wraparound hangers on round/spiral ducting
or pipes, the final inclusive angle of the assembly should not exceed 60˚.
Y-FIT: Legs on Y-Fit hangers are not be installed at angles greater than
60˚.
Failure to comply with these recommendations may result in product malfunction and
possible damage to property or person and will invalidate the Gripple warranty. Gripple
products are warranted to conform to the manufacturer’s published specifications at
the time of shipment and to be free from defects in materials and workmanship. No
other warranty, whether express or implied, including any warranty of merchantability
or fitness for purpose, shall exist in connection with the
sale or use of any Gripple product.
LUBRICATION – Do not apply oil or any other lubricant to the Gripple
fastener or any other part of the cable assembly.
JOINING – Never join two cable ends together in-line. Only pass the free
end of the cable in a continuous loop through both channels of the Gripple
fastener. The angle inside the Gripple formed loop must not exceed 60˚.
HANGING AT AN ANGLE TO VERTICAL – Ensure that the load
calculation considers the effect of ‘side load’. For example, at an angle
of 60˚ to vertical, the SWL is reduced by 50%. (See published technical
information on website or in Product Guide.)
DUCTING: When installing wraparound hangers on round/spiral ducting
or pipes, the final inclusive angle of the assembly should not exceed 60˚.
Y-FIT: Legs on Y-Fit hangers are not be installed at angles greater than
60˚.
Failure to comply with these recommendations may result in product malfunction and
possible damage to property or person and will invalidate the Gripple warranty. Gripple
products are warranted to conform to the manufacturer’s published specifications at
the time of shipment and to be free from defects in materials and workmanship. No
other warranty, whether express or implied, including any warranty of merchantability
or fitness for purpose, shall exist in connection with the
sale or use of any Gripple product.
Safe Working Load
Size Max Load (lbs)
No. 1 33
No. 2 100
Safe Working Load
Size Max Load (lbs)
No. 1 33
No. 2 100
Hanger Angles
If cable is suspended at an angle
from vertical, an additional sideways
load is applied which reduces
the load capacity of the overall
suspension. Please see published
technical information regarding this
net effect on Safe Working Load.
Legs on Y-Fit hangers not to be
installed at angles greater than 60˚
Hanger Angles
If cable is suspended at an angle
from vertical, an additional sideways
load is applied which reduces
the load capacity of the overall
suspension. Please see published
technical information regarding this
net effect on Safe Working Load.
Legs on Y-Fit hangers not to be
installed at angles greater than 60˚
1. Thread cable into No. 1 or
No. 2 Gripple Express.
1. Thread cable into No. 1 or
No. 2 Gripple Express.
2. Pull cable through.
2. Pull cable through.
3. Loop around ceiling or service
attachment point and pass tail
end of cable through other hole
of Gripple Express.
3. Loop around ceiling or service
attachment point and pass tail
end of cable through other hole
of Gripple Express.
1. Make sure load is supported.
2. Press the button on the top (Gripple
Express No. 2) or slide the button on the
side (Gripple Express No. 1), to release the
Gripple Express fastener from the cable and
adjust the height of the service.
1. Make sure load is supported.
2. Press the button on the top (Gripple
Express No. 2) or slide the button on the
side (Gripple Express No. 1), to release the
Gripple Express fastener from the cable and
adjust the height of the service.
60˚
60˚

INST-XP-USA
www.gripple.com/us
INST-HF-USA
www.gripple.com/us
UL File No. E228153 No. 1
Up to 25 lbs
No. 2
26-100 lbs
Loop
Stud*
Toggle
Y-Fit
UL File No. E251132* No. 2
26-100 lbs
Loop
UL File No. E251132* No. 2
26-100 lbs
Loop
* Note: The suitability of the Stud end fixing for use in concrete was not part of UL investingation
* Note: The suitability of the Stud end fixing for use in concrete was not part of UL investingation
* EMT Conduit up to 6” diameter
* EMT Conduit up to 6” diameter
(CONDUIT AND CABLE HARDWARE)
24TV
(CONDUIT AND CABLE HARDWARE)
24TV
Suitable for use in Air Handling Spaces in accordance with Section
300.22 (C) and (D) of the National Electrical Code, and rules
12-010 (3), (4), and (5), and 12-020 of the Canadian Electrical
Code, Part 1.
Suitable for use in Air Handling Spaces in accordance with Section
300.22 (C) and (D) of the National Electrical Code, and rules
12-010 (3), (4), and (5), and 12-020 of the Canadian Electrical
Code, Part 1.
** Y-Fit Hanger is not part of CSA approval
** Y-Fit Hanger is not part of CSA approval
For further technical assistance,
please contact:
Gripple Inc.
1611 Emily Lane / Aurora, IL 60502
Phone: [phone]
Email: [email protected]
www.gripple.com/us
LOOP
BARREL
For attaching to a 1/4” male thread product.
LOOP
V-BRACKET ACCESSORY
Front or side mount light fixture clip for fluorescent
light fixtures.
Front Mount Side Mount
LOOP
LOOP
For choking around bar joists, beams, and roof trusses.
LOOP
STUD
For anchoring into concrete ceilings, and metal decking or
brackets
LOOP
TOGGLE / Y-TOGGLE
For inserting into pre-drilled holes of light fixtures or metal
decking
LOOP
HOOK / Y-HOOK
For snapping onto light fixtures, beam & purlin clips, or cable
basket & tray.
LOOP
EYELET
For bolting to fixtures or services, wood beams, or
brackets.
LOOP
90˚EYELET
For shot firing into concrete or steel. Can be used
with mechanical anchors.
2
2 2 3
1
1 1
For further technical assistance,
please contact:
Gripple Inc.
1611 Emily Lane / Aurora, IL 60502
Phone: [phone]
Email: [email protected]
www.gripple.com/us
LOOP
BARREL
For attaching to a 1/4” male thread product.
LOOP
V-BRACKET ACCESSORY
Front or side mount light fixture clip for fluorescent
light fixtures.
Front Mount Side Mount
LOOP
LOOP
For choking around bar joists, beams, and roof trusses.
LOOP
STUD
For anchoring into concrete ceilings, and metal decking or
brackets
LOOP
TOGGLE / Y-TOGGLE
For inserting into pre-drilled holes of light fixtures or metal
decking
LOOP
HOOK / Y-HOOK
For snapping onto light fixtures, beam & purlin clips, or cable
basket & tray.
LOOP
EYELET
For bolting to fixtures or services, wood beams, or
brackets.
LOOP
90˚EYELET
For shot firing into concrete or steel. Can be used
with mechanical anchors.
2
2 2 3
1
1 1
UL File No. E228153 No. 1
Up to 25 lbs
No. 2
26-100 lbs
Loop
Stud*
Toggle
Y-Fit
