Grizzly G0812 User manual

MODEL G0812
13" X 18" METAL-CUTTING BANDSAW
OWNER'S MANUAL
(For models manufactured since 2/16)
COPYRIGHT © JANUARY, 2017 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#BL18559 PRINTED IN TAIWAN V1.01.17

This manual provides critical safety instructions on the proper setup,
operation, maintenance, and service of this machine/tool. Save this
document, refer to it often, and use it to instruct other operators.
Failure to read, understand and follow the instructions in this manual
may result in fire or serious personal injury—including amputation,
electrocution, or death.
The owner of this machine/tool is solely responsible for its safe use.
This responsibility includes but is not limited to proper installation in
a safe environment, personnel training and usage authorization,
proper inspection and maintenance, manual availability and compre-
hension, application of safety devices, cutting/sanding/grinding tool
integrity, and the usage of personal protective equipment.
The manufacturer will not be held liable for injury or property damage
from negligence, improper training, machine modifications or misuse.
Some dust created by power sanding, sawing, grinding, drilling, and
other construction activities contains chemicals known to the State
of California to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement and other masonry products.
• Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals:
Work in a well ventilated area, and work with approved safety equip-
ment, such as those dust masks that are specially designed to filter
out microscopic particles.

Table of Contents
INTRODUCTION............................................... 2
Contact Info.................................................... 2
Manual Accuracy ........................................... 2
Identification ................................................... 3
Controls & Components ................................. 4
Machine Data Sheet ...................................... 6
SECTION 1: SAFETY....................................... 9
Safety Instructions for Machinery .................. 9
Additional Safety for .................................... 11
Horizontal Metal Bandsaws ......................... 11
SECTION 2: POWER SUPPLY ...................... 12
SECTION 3: SETUP ....................................... 14
Unpacking .................................................... 14
Needed for Setup ......................................... 14
Inventory ...................................................... 14
Cleanup ........................................................ 15
Site Considerations ...................................... 16
Lifting & Placing ........................................... 17
Anchoring to Floor ....................................... 18
Assembly ..................................................... 18
Test Run ...................................................... 20
Recommended Adjustments ........................ 22
SECTION 4: OPERATIONS ........................... 23
Operation Overview ..................................... 23
Blade Selection ............................................ 24
Changing Blade ........................................... 26
Tensioning & Tracking Blade ....................... 27
Blade Breakage ........................................... 28
Blade Care & .............................................. 29
Break-In ....................................................... 29
Blade Speed ................................................ 29
Blade Speed Chart ...................................... 30
Chip Inspection Chart .................................. 31
Feed Rate .................................................... 32
Work Stop .................................................... 32
Vise .............................................................. 34
Angle Cuts ................................................... 36
Blade Guides ............................................... 37
Coolant ......................................................... 38
Coolant System............................................ 38
Operation Tips ............................................. 39
Workpiece Inspection................................... 40
SECTION 5: ACCESSORIES......................... 41
SECTION 6: MAINTENANCE......................... 42
Schedule ...................................................... 42
Cleaning & Protecting .................................. 42
Lubrication ................................................... 42
Hydraulic System ......................................... 45
Tensioning/Replacing Belt ........................... 47
Coolant System Service .............................. 48
Machine Storage .......................................... 50
SECTION 7: SERVICE ................................... 51
Troubleshooting ........................................... 51
Blade Brush ................................................. 54
Downfeed Stop Bolt ..................................... 54
Blade Guide Bearings .................................. 55
Squaring Blade with Table ........................... 56
Limit Switches .............................................. 57
Angle Stops.................................................. 58
SECTION 8: WIRING...................................... 61
Wiring Safety Instructions ............................ 61
Electrical Overview ...................................... 62
Component Locations .................................. 62
Electrical Panel Photo .................................. 63
Electrical Panel Wiring Diagram .................. 64
Control Panel Wiring .................................... 65
Main Motor Wiring ........................................ 66
Hydraulic Pump Wiring ................................ 66
Coolant Pump Wiring ................................... 67
Limit Switch Wiring ...................................... 68
Hydraulic System Diagram .......................... 69
SECTION 9: PARTS....................................... 70
Frame ........................................................... 70
Drive Wheel & Motor.................................... 72
Base & Vise ................................................. 74
Electrical ...................................................... 77
Labels & Cosmetics ..................................... 78
WARRANTY & RETURNS ............................. 81

-2- Model G0812 (Mfd. Since 2/16)
We stand behind our machines! If you have ques-
tions or need help, contact us with the information
below. Before contacting, make sure you get the
serial number
and manufacture date from the
machine ID label. This will help us help you faster.
Grizzly Technical Support
1815 W. Battlefield
Springfield, MO 65807
Phone: [phone]
Email: [email protected]
We want your feedback on this manual. What did
you like about it? Where could it be improved?
Please take a few minutes to give us feedback.
Grizzly Documentation Manager
P.O. Box 2069
Bellingham, WA 98227-2069
Email: [email protected]
Contact Info
We are proud to provide a high-quality owner’s
manual with your new machine!
We
made every effort to be exact with the
instruc-
tions, specifications, drawings, and photographs
in this manual. Sometimes we make mistakes, but
our policy of continuous improvement also means
that
sometimes the machine
you receive is
slightly different than shown in the manual
.
If you find this to be the case, and the difference
between the manual and machine leaves you
confused or unsure about something
,
check our
website for an updated version. W
e post
current
manuals and
manual updates for free
on our web-
site at
www.grizzly.com.
Alternatively, you can call our Technical Support
for help. Before calling, make sure you write down
the
Manufacture Date and Serial Number
from
the machine ID label (see below). This information
is required for us to provide proper tech support,
and it helps us determine if updated documenta-
tion is available for your machine.
Manufacture Date
Serial Number
Manual Accuracy
INTRODUCTION

Model G0812 (Mfd. Since 2/16) -3-
Identification
To reduce your risk of
serious injury, read this
entire manual BEFORE
using machine.
Become familiar with the names and locations of the controls and features shown below to better understand
the instructions in this manual.
Belt Cover
Wheel Cover
Blade Guide
Knob
Front View Headstock
Blade Guide Scale
Blade
Guide Arm
Work Stop
Control
Panel
Hydraulic Tank Splash Guard
Chip Collection
Drawer
Rear View
Vise Handwheel
Auto Stop
Adjustment Lever
Blade Speed
Adjustment
Knob
Blade Tension
Handwheel
Fixed Vise
Jaw
Vise Locks
Movable
Vise Jaw
Coolant
Control Valve

-4- Model G0812 (Mfd. Since 2/16)
Controls &
Components
A. Power Lamp: Indicates main power to
machine is turned ON.
B. Feed Rate Dial: Controls rate at which blade
feeds into workpiece.
C. Emergency Stop Button: Stops all machine
functions. Twist clockwise to reset.
D. Coolant Pump Switch (
STAND BY
START << I
OFF
1
2
3
456
7
8
9
0
HIGHLOW
A
E
M
H
BC
F
I
J
K
L
G
D
STOP
): Low-pressure
setting (
STAND BY
START << I
OFF
1
2
3
456
7
8
9
0
HIGHLOW
A
E
M
H
BC
F
I
J
K
L
G
D
STOP
) supplies cutting fluid to blade
through fluid nozzles. High-pressure setting
(
STAND BY
START << I
OFF
1
2
3
456
7
8
9
0
HIGHLOW
A
E
M
H
BC
F
I
J
K
L
G
D
STOP
) supplies coolant to spray gun, and (
STAND BY
START << I
OFF
1
2
3
456
7
8
9
0
HIGHLOW
A
E
M
H
BC
F
I
J
K
L
G
D
STOP
)
turns coolant pump motor OFF.
E. Raise Headstock Button (
B
A
C
DEFGH
I J
K
L
): Hydraulically
raises headstock. Continues raising blade
until lower limit switch activates or button is
released.
F. Lower Headstock Button (
B
A
C
DEFGH
I J
K
L
):
Hydraulically lowers headstock. Lowers at
rate determined by feed rate dial (B).
G. Hydraulic Motor Button (
B
A
C
DEFGH
I J
K
L
): Turns hydrau-
lic motor ON.
H. Stop Button: Stops all machine functions
when pressed. Press again to reset.
I. Blade Start Button(
B
A
C
DEFGH
I J
K
L
): When pressed,
turns saw blade motor ON and starts saw
blade. IMPORTANT: For blade start button
to work, hydraulic motor button (G) and vise
close button (J) must be pressed first, and
headstock must be raised.
J. Vise Close Button (
STAND BY
START << I
OFF
1
2
3
456
7
8
9
0
HIGHLOW
A
E
M
H
BC
F
I
J
K
L
G
D
STOP
): Hydraulically clos-
es vise to secure workpiece during cut.
IMPORTANT: As a safety precaution, vise
close button must be pressed in order for
blade start button (I) to function.
K. Vise Open Button (
STAND BY
START << I
OFF
1
2
3
456
7
8
9
0
HIGHLOW
A
E
M
H
BC
F
I
J
K
L
G
D
STOP
): Hydraulically opens
vise to release workpieces between cuts.
L. Pedestal Lock: Loosen to move control
panel to desired location for operation and
tighten to secure. IMPORTANT: To avoid
headstock hitting control panel during opera-
tion, swivel control panel out of way to ensure
it is not in path of headstock.
Refer to Figures 1–5 and the following descrip-
tions to become familiar with the basic controls
and components of this machine. Understanding
these items and how they work will help you
understand the rest of the manual and stay safe
when operating this machine.
To reduce your risk of
serious injury, read this
entire manual BEFORE
using machine.
Control Panel
Figure 1. Model G0812 control panel.
A
E
IHG K
Figure 2. Control panel pedestal lock location.
C
B
DF
J
L

Model G0812 (Mfd. Since 2/16) -5-
M. Blade Guide Arm: Holds blade guide that
supports bandsaw blade. Arm is placed as
close to workpiece as possible during cutting
to prevent blade from twisting.
N. Blade Guide Scale: Displays position of
blade guide arm relative to workpiece.
O. Blade Speed Adjustment Knob: Controls
bandsaw blade speed. Rotate knob clockwise
to decrease blade speed or counterclockwise
to increase blade speed. IMPORTANT: To
avoid damaging machine, ONLY change
blade speeds while the motor is running.
P. Work Stop: Can be positioned on either
side of vise base to support repetitive cutting
operations. The stop is placed on same side
of machine where cut is made.
Q. Auto-Stop Adjustment Lever: Sets maxi-
mum headstock height. Adjust by changing
position of lower limit switch. This feature
is useful for speeding up repetitive cuts by
eliminating unnecessary headstock travel.
R. Blade Tension Handwheel: Increases or
decreases blade tension.
Vise Table
S. Movable Vise Jaw: Features quick release
that allows jaw width to be adjusted when
changing from one workpiece size to another.
T. Vise Handwheel: Rotate to manually position
movable vise jaw close to workpiece.
U. Vise Locks: Loosen to move vise base or
tighten to secure its position.
Figure 5. Vise table controls.
S
T
U
Headstock
Figure 3. Headstock controls and components.
O
MN
P
Figure 4. Additional headstock controls.
R
Q

-6- Model G0812 (Mfd. Since 2/16)
Machine Data Sheet
The information contained herein is deemed accurate as of 10/14/2019 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 3
Model G0812
MACHINE DATA
SHEET
Customer Service #: [phone] · To Order Call: [phone] · Fax #: [phone]
MODEL G0812 13" X 18" 2 HP INDUSTRIAL METAL
CUTTING BANDSAW
Product Dimensions:
Weight............................................................................................................................................................ 1345 lbs.
Width (side-to-side) x Depth (front-to-back) x Height........................................................................... 90 x 52 x 56 in.
Footprint (Length x Width)..................................................................................................................... 57 x 27-1/2 in.
Shipping Dimensions:
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight............................................................................................................................................................ 1446 lbs.
Length x Width x Height....................................................................................................................... 84 x 37 x 60 in.
Must Ship Upright................................................................................................................................................... Yes
Electrical:
Power Requirement........................................................................................................... 220V, Single-Phase, 60 Hz
Prewired Voltage.................................................................................................................................................. 220V
Full-Load Current Rating........................................................................................................................................ 20A
Minimum Circuit Size.............................................................................................................................................. 30A
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length................................................................................................................................................. 6 ft.
Power Cord Gauge......................................................................................................................................... 14 AWG
Plug Included........................................................................................................................................................... No
Recommended Plug Type................................................................................................................................... L6-30
Switch Type........................................................................................................................................ Magnetic Switch
Motors:
Coolant Pump
Horsepower................................................................................................................................................ 53 W
Phase............................................................................................................................................ Single-Phase
Amps........................................................................................................................................................... 0.3A
Speed................................................................................................................................................ 3440 RPM
Type..................................................................................................................................................... Universal
Power Transfer ............................................................................................................................... Direct Drive
Centrifugal Switch/Contacts Type................................................................................................................ N/A
Main
Horsepower................................................................................................................................................ 2 HP
Phase............................................................................................................................................ Single-Phase
Amps............................................................................................................................................................ 15A
Speed................................................................................................................................................ 1720 RPM
Type................................................................................................................. TEFC Capacitor-Start Induction
Power Transfer .................................................................................................................................. Belt Drive
Bearings........................................................................................................ Sealed & Permanently Lubricated
Centrifugal Switch/Contacts Type......................................................................................................... External

Model G0812 (Mfd. Since 2/16) -7-
The information contained herein is deemed accurate as of 10/14/2019 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 2 OF 3
Model G0812
Hydraulic Pump
Horsepower............................................................................................................................................. 1/2 HP
Phase............................................................................................................................................ Single-Phase
Amps........................................................................................................................................................... 4.7A
Speed................................................................................................................................................ 1720 RPM
Type................................................................................................................................. TEFC Capacitor-Start
Power Transfer ............................................................................................................................... Direct Drive
Bearings........................................................................................................ Sealed & Permanently Lubricated
Centrifugal Switch/Contacts Type......................................................................................................... External
Main Specifications:
Operation Info
Blade Speeds............................................................................................................................... 95 – 380 FPM
Std. Blade Length.................................................................................................................................... 150 in.
Blade Length Range.......................................................................................................... 149-3/4 – 150-1/4 in.
Cutting Capacities
Cutting Height............................................................................................................................................ 13 in.
Angle Cuts................................................................................................................................. 60R – 45L deg.
Vise Jaw Depth.......................................................................................................................................... 18 in.
Vise Jaw Height..................................................................................................................................... 6-3/4 in.
Max. Capacity Rectangular Height at 90 Deg............................................................................................ 12 in.
Max. Capacity Rectangular Width at 90 Deg............................................................................................. 18 in.
Max. Capacity Round at 90 Deg................................................................................................................ 13 in.
Max. Capacity Rectangular Height at 30 Deg............................................................................................ 11 in.
Max. Capacity Rectangular Width at 30 Deg............................................................................................. 19 in.
Max. Capacity Round at 30 Deg................................................................................................................ 19 in.
Max. Capacity Rectangular Height at 45 Deg............................................................................................ 11 in.
Max. Capacity Rectangular Width at 45 Deg............................................................................................. 12 in.
Max. Capacity Round at 45 Deg................................................................................................................ 12 in.
Max. Capacity Rectangular Height at 60 Deg.............................................................................................. 7 in.
Max. Capacity Rectangular Width at 60 Deg............................................................................................... 8 in.
Max. Capacity Round at 60 Deg.................................................................................................................. 8 in.
Max. Capacity Rectangular Height at -45 Deg.......................................................................................... 11 in.
Max. Capacity Rectangular Width at -45 Deg............................................................................................ 12 in.
Max. Capacity Round at -45 Deg............................................................................................................... 12 in.
Construction
Table....................................................................................................................... Precision-Ground Cast Iron
Trunnions............................................................................................................................................. Cast Iron
Upper Wheel........................................................................................................................................ Cast Iron
Lower Wheel........................................................................................................................................ Cast Iron
Body........................................................................................................................................................... Steel
Stand.......................................................................................................................................................... Steel
Wheel Cover............................................................................................................................................... Steel
Paint Type/Finish...................................................................................................................................... Epoxy
Other
Wheel Size................................................................................................................................................. 16 in.
Blade Guides Upper..................................................................................................................... Carbide Steel
Blade Guides Lower..................................................................................................................... Carbide Steel
Coolant Capacity.................................................................................................................................... 7.5 gal.
Table Info
Table Size Length................................................................................................................................ 26-1/8 in.
Table Size Width................................................................................................................................... 7-3/4 in.
Table Size Thickness............................................................................................................................ 4-7/8 in.
Floor To Cutting Area Height............................................................................................................... 32-1/4 in.

-8- Model G0812 (Mfd. Since 2/16)
The information contained herein is deemed accurate as of 10/14/2019 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 3 OF 3
Model G0812
Other Specifications:
Country of Origin .............................................................................................................................................. Taiwan
Warranty ........................................................................................................................................................... 1 Year
Approximate Assembly & Setup Time .............................................................................................................. 1 Hour
Serial Number Location .................................................................................................................................. ID Label
ISO 9001 Factory .................................................................................................................................................. Yes
Certified by a Nationally Recognized Testing Laboratory (NRTL) .......................................................................... No
Features:
Coolant System with 7.5-Gallon Coolant Capacity
Heavy-Duty, Precision-Ground Cast-Iron Table
Variable-Speed Blade Control with Speeds from 95 – 380 FPM
Quick-Release Vise
Variable-Speed Hydraulic Feed Control
Pivoting Control Panel Arm for Convenient Access to Controls
Coolant Splash Guard
Built-in Spray Hose for Quick and Easy Cleanup
Miter Base Swivels 45-degrees left and 60-degrees right
