Grundig GBR-IC02 User manual

GBR-IC02.21.1.28.07.2011
Owner´s Manual
EN
© ASP AG
IP Cameras & Domes
GBR-IC02 Ceiling Flush Mount Adapter

Content:
1. Introduction 1
2. Package Contents & Needed Items 1
3. Installation 1
1. Introduction
The Indoor Dome Cameras GCI-H0522V and GCI-K0322V can be mounted with this
optional Ceiling Flush Mount Adapter. The items and tools needed for the in-ceiling
installation are listed as follows.
2. Package Contents & Needed Items
These parts are included:
Tools Needed:
- Tool for drilling
- Phillips Screw Driver
- Security Torx (included in the package of the camera)
3. Installation
Step 1:
Use a Security Torx to unscrew the two
Torx screws on the side of the Dome Cover,
as shown in the figure, and open the Dome
Cover. The Security Torx is included in the
package.
1
English

Step 2:
Press both sides of the Inner Cover and
remove it from the Dome Camera unit.
Step 3:
Unscrew the module-fastened screw, as
indicated in the picture.
Step 4:
Press the sides of the snap-on module, as
indicated in the figure, and detach it from
the Dome Camera’s housing.
Step 5:
Please screw off the conduit entry block of
the Dome Camera. To do this, users may
use a coin.
2English

Step 6:
Attach the Camera Housing Base to the
Flush Mount Adapter’s top plate, aligning
the camera’s rear cable entry with the entry
hole on the Flush Mount Adapter’s top plate.
Step 7:
Align the three Captive Screws with the
mating screw holes on the Camera Housing
Base. Then tighten the three Captive
Screws as shown in the figure.
Step 8:
Position the supplied adhesive-backed
Ceiling Stickers onto the ceiling where the
Camera will be mounted, and cut the ceiling
hole using the template as a guide.
(Diameter: 174 mm)
Step 9:
Run the Ethernet cable (and a power cable
if needed) through the desired cable entry
and insert the Dome Camera with the
attached Flush Mount Adapter into the
opening.
3
English

Step 10:
Secure the Unit to the ceiling. Do not over-
tighten the 3 fixing screws. If you use a
power tool, the slip clutch should be set to
the lightest setting or the clamps could be
damaged.
Step 11:
The Flush Mount Adapter’s Wing Clamps
will draw the Dome Camera Housing to the
ceiling board until it is completely flush with
the board.
Bottom View of the installed Flush Mount
Adapter
Step 12:
Attach the Snap-on Camera Module to the
Dome Camera Housing. Please install the
Camera Module with the terminal blocks
facing the side of the cable entry.
4English

Step 13:
Tighten the Module-fastening Screw.
Step 14:
Connect the Ethernet cable to the camera’s
network connector. Please refer to the
Camera Quick Guide for details regarding
the Camera Connector Definition.
Step 15:
Reinstall the Plastic Inner Cover.
Step 16:
Close the Dome Cover and tighten the two
Security Screws.
5
English

Step 17:
Align the 3 holes in the Trim Ring with the
retaining Nut on the Flush Mount Adapter
and snap the Trim Ring in place to
complete the installation.
Specifications GBR-IC02
Suitable for GCI-H0522V; GCI-K0322V
Body material Steel
Colour White
0.38 kgWeight
Drill-hole Ø 174 mm
Dimensions (wxhxd) 215,2 x 200,6 x 184 mm
Dimensions
6English
